Advanced Mobile Payment AMP6500 AMP 6500 User Manual
Advanced Mobile Payment Inc. AMP 6500 Users Manual
Users Manual
RF exposure assessment has been performed to prove that this unit will not
RF exposure information: The EIRP power of the device at maximal case is below
~ 45
Jan 2018
6500
The Microfit cable
6500
6500
1. The device should be covered by a pin shield over the pin entry area.
2. Avoiding the direct sunlight and the rain.
3. Place the device in a ventilated locality and keep good a heat dissipation condition.
Microfit
power or MDB power jack 6500
6500
High Performance 4 Core Processor + Secure CPU
1GB RAM, 8GB Flash memory, Support Micro TF Card, up to 32GB
5”, 720x1280 pixels, support capacitate touch screen
RS-232, Ethernet 10/100M, MDB
PCI PTS 5.X, EMV LEVEL 1&2, EMV Contactless, CE, FCC, Pay Pass
1 SAM, 1 TF card reader, MDB interface, Mircrofit port, proximity detector
12V DC, 2A (when using Micro fit), 24 ~ 45V DC (when using MDB)
(195x122x94mm)-(7.7x4.8x3.7’’)LxWxH
1 key for reset, 1 key for setup
Android OS 5.X
720g(1.6lbs)
-20℃ ℃(-4℉~ 113℉), 10% ~ 90% (non-condense)
-25℃ ~ 75℃(-13℉~167℉), 0% ~ 95% (non-condense)
IP65
IK08
6500
WATERPROOF
PROTECTION
SAM
TF
SIM
USB - host
Microfit
7
MDB
Audio
RS232
USB-device
Ethernet
Port cover
Menu for setup
Reset
SIM/SAM card cover
Tag label
9
Magnetic stripe card
User smart card slot
LCD
NFC leds
Antenna inductive zone
Camera
Infrared LED
Infrared sensor
Waterproof ring
5
4 core
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that
may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The
device can be used in portable exposure condition without restriction.
6500-CB
~ 45
MODULATION NFC 13.56MHz
the exemt condition, 20mW specified in EN62479: 2010.
generate the harmful EM emission above the reference level as specified in
EC Council Recommendation(1999/519/EC).
