User Manual
Quick start guide
AirEther
Package Contents
PC Conguration
● AirEther
(LTE Indoor CPE)
● LAN Cable
● Quick start guide
● DC Adapter(5V1A)
Part name of Device
LED indicator USB connector
LANWAN
Device Label
For your computer to support Device,
please verify that the network device are
automatically nd in the device panel.
In a Windows environment :
Click “Start” > Settings > Select “Control Panel”
> Click “Network and Internet” > Click
“Network Connections” > Mouse right-click
“Local Area Connection” and Select “Properties”
12
3
1
Select “Internet Protocol Version4 (TCP/IPv4)”
Select “Obtain an IP address automatically”
and “Obtain DNS server address automatically”
Click “Properties” button
2
3
Click “OK” button
5
4
4
5
USIM cover
WAN LAN
Connection Method
LAN cableWAN cable
AirEther DC Adapter(5V1A)
LED Indicator
Indicator Color Function
Working : Red ON
Not connected(LTE, WAN)
WAN is enabled : Green ON
LTE is enabled : Green blinking
LTE RSSI(Received signal
strength indication) status :
Green ON
POWER
NET
RSSI
(1~3)
Logging into the built-in Web
Interface
Go to WEB “192.168.1.1” then press ENTER to
access the login screen.
1(one) year
Name
Address
Telephone number
E-mail
Purchase date
Quality warranty
period
Seller
Telephone number
Consumer
Trouble Shooting
Refer to the following if you are having trouble
connecting to the Internet :
1. Check the LED status of Device.
• Check if the POWER LED is illuminated.
• Check if the LED of LTE is illuminated.
• For LAN port, check if the lamp of the port
connected to the PC is illuminated.
2. Check the IP address of PC.
• For Windows 7/8/10
• Run [Command Prompt] and enter the
[ipcong] command to check the [IP address].
3. If IP Address is not normal – Set the IP Address
of the PC manually.
• For Windows 7/8/10
① Start > Control Panel > Network and Internet
> Network Connections > Mouse right-click
> Local Area Connection and Select Properties
② Click Properties of [Internet Protocol Version 4
(TCP/IPv4)] among Components.
③ Click [Use the following IP address].
④ Enter [192.168.1.2] for IP Address, [255.255.255.0] for
Subnet Mask, and [192.168.1.1] for Default Gateway.
Warranty Information
This product is the result of high-class
craftsmanship based on strict quality control
procedures.
• In case of Product failure or malfunction during
normal usage, your product will be repaired free of
charge within the Limited Warranty period.
• The Consumer shall bear any labor or parts charges
not covered by this Limited Warranty.
• At the request for repair, you must provide the
proof of purchase and the warranty.
• Keep the warranty in a safe location because it is
not reissued.
The Consumers shall have no coverage or benets
under this Limited Warranty if the Product has been :
• Subjected to inappropriate use, improper storage,
unauthorized repair, unauthorized modications,
neglect abuse, inadequate installation, misuse,
damage caused by shipping, etc.
• Damaged from re, ooding, windstorm, lighting,
earthquake, theft, blown fuse, internet viruses,
worms, Trojan Horses, etc.
• Treated with its Product Serial # removed or defaced.
⑤ Click [Use the following DNS Server Address].
⑥ For [Preferred DNS Server], enter the communication
company server of each country.
⑦ Click [OK]. Click [OK] again in the [Local Area Connection
Properties] window.
• For MAC OS X
① From the "Apple" menu, Choose “System Preference..“
② Click on the [Network] icon in the [Internet & Network] category.
③ Click on the [Ethernet] option from the left hand side of the
Network setting window.
④ Select [Manually] option from the [Congure] drop-down menu.
⑤ Enter [192.168.1.2] for IP Address, [255.255.255.0] for
Subnet Mask, and [192.168.1.1] for Default Gateway.
⑥ For [DNS Server], enter the communication company server
of each country.
⑦ Click [Apply].
4. Run [MS-DOS] or [Command Prompt] and then
perform PING Test with [192.168.1.1]
A message [Reply from 192.168.1.1: bytes=32 time=1ms TTL=64]
should appear when running [ping 192.168.1.1] command.
If the result of the Ping test does not arrive properly,
please contact the Customer Support Center.
FCC Part 15.105
This equipment has been tested and found to comply with the
limits for a class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference or television
reception, which can be determined by turning the equipment
o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Part 15.19
This device complies with part 15 of the FCC Rules. Operation is
subject to the condition that this device does not cause harmful
interference.
FCC Part 15.21
Changes or modifications not expressly approved by the
manufacturer (or party responsible) for compliance could void
the user’s authority to operate the equipment
“This equipment should be installed and operated with
minimum 20 cm between the radiator and your body.”
Method of folding Quick Start Guide
1
2
300mm
60mm
80mm
160mm
