Alcatel USA 8702-50 MDR-8000 User Manual MDR 8000 Radio Family Users Manual Issue 9

Alcatel USA Marketing, Inc. MDR-8000 MDR 8000 Radio Family Users Manual Issue 9

Contents

User manual 03

MDR-8000
Alcatel Part Number 3EM11931AA
3400 West Plano Parkway
Plano, Texas 75075-5813 U.S.A.
Issue 9, December, 2007
Microwave Digital Radios
Users Manual
NORTH AMERICA CUSTOMER SERVICE CENTER
24 HOURS PER DAY, 7 DAYS PER WEEK
PHONE the Call Center at
888-252-2832 (US and Canada)
or
613-784-6100 (International)
ALCATEL-LUCENT’S PRIMARY MISSION IS
SATISFYING OUR CUSTOMERS' QUALITY EXPECTATIONS.
The Call Center Agent (CSA)
Will help connect you with Technical Assistance (TAC)
Or assist you with a Repair and Return
• Phone-based technical support
• After-hour emergencies
• On-site technical support
• E-mail support ml-tac.support@alcatel-lucent.com
• Software and hardware upgrades
TAC
• Module repair
Repair and Return
• Training http://www.alcatel-lucent.com>support
– Technical Training
Other Services Offered
• Field Services
– Installation and test
• Customized and Comprehensive Service Agreements
• Registration http://www.alcatel-lucent.com>MyAccess
– Once registered
– From “MyAlcatel” go to “Alcatel Support Documentation”
–
Register for access to Documentation and e-mail Update notifications
For Product Change Notices (PCN), Product Documentations, etc.
– Software and Hardware upgrade documentation
Telephone Assistance, Normal Working Hours (CST 8am 5pm M-F)
TAC supports all Alcatel North America Microwave products. This includes routine questions and
emergency service.
Telephone Assistance, Emergency After-Hours
• Defined as loss of traffic, standby equipment, or network visibility on traffic-bearing systems.
• Available through our Customer Service Agents (CSA).
Contact Information Ask the Customer Service Agent (CSA) for a Microwave (MW) or a Network
Management Service engineer (NMS).
Please provide the following information to the Customer Service Agent (CSA):
• Last and First name
• Company name
• Telephone number
• City and state (Street address if applicable) or Site Name and Location
• Equipment type
• A brief description of the problem affecting their equipment
• Customer Priority: High, Medium, or Low.
• TL-9000 Severity as described below.
Creating a TAC Action Request (AR)
Critical
TL-9000 Severities Defined
Major
Minor Problems not classified as critical or major.
Problems severely affecting service, traffic, capacity, or network
management. They require immediate corrective action. (Ex.
Loss of network management capability, loss of traffic imminent
or existing).
Conditions seriously affecting system operation. They require
immediate attention. (Ex. processor outage, loss of standby
equipment, loss of remote access, or network managers).
TAC
Technical Assistance Center
T
able of Contents
TOC
-
1
Page
Section 1
General
1.1
INTRODUCTION
.............................................................................................
1
-
1
1.2
CONTENT
.......................................................................................................
1
-
1
Section 2
Operation
2.1
GENERAL
........................................................................................................
2
-
1
2.2
TURN-ON
........................................................................................................
2
-
1
2.3
USER SYSTEM INTERFACE (USI) PROVISIONING FUNCTION/OPERATION
......
2
-
2
2.4
OPERATING PROCEDURES
..............................................................................
2
-
2
2.4.1
Radio Receiver Manual Switching
.....................................................................
2
-
2
2.4.2
Radio Transmitter Manual Switching
.................................................................
2
-
5
2.4.3
Radio I/O Interface Manual Switching
..............................................................
2
-
5
2.4.4
MCS-11 Operation
..........................................................................................
2
-
7
2.4.5
Lamp Tests
.......................................................................................................
2
-
8
2.4.6
Alarm Checks
..................................................................................................
2
-
8
2.4.7
Orderwire Operation
.......................................................................................
2
-
8
2.4.8
Initiating Outgoing Orderwire Calls
..................................................................
2
-
8
2.4.9
Answering Incoming Orderwire Calls
................................................................
2
-
8
2.5
TURN-OFF PROCEDURE
...................................................................................
2
-
9
2.6
EMERGENCY OPERATION
..............................................................................
2
-
9
2.7
MODEM OPERATION
......................................................................................
2
-
9
2.8
CONTROLS, INDICATORS, TEST POINTS, AND CONNECTORS
.......................
2
-
9
Section 3
Interconnect
3.1
SECTION INTRODUCTION
..............................................................................
3
-
1
3.2
POWER CABLE CONNECTION
.......................................................................
3
-
1
3.3
PDU STRAPPING AND CONNECTIONS
...........................................................
3
-
4
3.4
SHELF/RACK ALARM CONNECTION
..............................................................
3
-
5
Page
TOC
-
2
3.5
MDR-8000 SYNCHRONOUS REPEATER CONNECTIONS
................................
3
-
5
3.5.1
Low Capacity DS1 Radios
................................................................................
3
-
7
3.5.2
High Capacity DS3 Radios
...............................................................................3 - 7
3.5.3
High Capacity OC3 Radios
..............................................................................3 - 7
3.5.4
MDR-8000 Synchronous Repeater Compatibility Matrix
.....................................3 - 8
3.5.5
MDR-8000 Synchronous Repeater Cables
.........................................................3 - 8
3.6
DS1 CONNECTIONS (J303 IN AND J304 OUT)
..............................................3 - 9
3.7
DS1 REPEATER (J314 ON ONE SHELF TO J314 ON SECOND SHELF)
............3 - 11
3.8
DS3 LBO STRAPPING AND CONNECTIONS
.................................................3 - 12
3.9
DS3 LBO DS3 BNC CONNECTIONS (J21 THROUGH J26)
.............................3 - 13
3.10
DS3 LBO WAYSIDE DS1 CONNECTIONS (J201 IN AND J202 OUT)
.............3 - 14
3.10.1
Wayside DS1 Terminal
..................................................................................3 - 14
3.10.2
Wayside DS1 Repeater
..................................................................................3 - 14
3.11
DS3 REPEATER (J401 ON ONE SHELF TO J401 ON SECOND SHELF)
............3 - 16
3.12
FIBER OPTIC CABLE CONNECTIONS
.............................................................3 - 18
3.12.1
2 or 4 Fiber Management Panel
.....................................................................3 - 19
3.12.2
2x4 Fiber Switched Management Panel
..........................................................3 - 19
3.13
OC3/STM-1 AUX INTERFACE BOARD WAYSIDE DS1 CONNECTIONS
(J201 IN AND J202 OUT)
..............................................................................3 - 22
3.13.1
Wayside DS1 Terminal
..................................................................................3 - 22
3.13.2
Wayside DS1 Repeater
..................................................................................3 - 22
3.14
OC3/STM-1 REPEATER
(J203 ON ONE SHELF TO J203 ON SECOND SHELF)
...................................3 - 23
3.15
ETHERNET CABLE CONNECTIONS
...............................................................3 - 24
3.15.1
Automatic MDI/MDI-X Configuration
...............................................................3 - 24
3.15.2
Crossover Cable Option
.................................................................................3 - 25
3.15.3
Terminal Connections
.....................................................................................3 - 29
3.15.4
Repeater Connections
....................................................................................3 - 33
3.16
USI/CONTROLLER CABLE CONNECTION TO LAPTOP (J301)
.........................3 - 35
3.17
SERVICE CHANNEL CONNECTIONS
............................................................3 - 37
3.17.1
2-Wire Handset Connection
...........................................................................3 - 37
3.17.2
Service Channels Provisioning Options
............................................................3 - 39
3.17.3
Audio 1, Audio 2 (J316, J317) Connections
...................................................3 - 39
3.17.4
RS-232-1, RS-232-2 (J312, J313)
....................................................................3 - 43
Page
TOC - 3
3.18
MCS-11 CONNECTIONS
..............................................................................3 - 44
3.18.1
MCS-11 Master (J307)
...................................................................................3 - 45
3.18.2
MCS-11 Repeater-to-Spur Daisy Chain Connection (J308/J309)
.......................3 - 48
3.18.3
MCS-11 Spur Connection (J310)
....................................................................3 - 56
3.19
TMN CONNECTIONS
...................................................................................3 - 58
3.19.1
Installing Module
...........................................................................................3 - 58
3.19.2
Typical Interconnect Scenarios
........................................................................3 - 60
3.19.3
Front Access Connectors
.................................................................................3 - 64
3.19.4
MATING CABLES
..........................................................................................3 - 67
3.19.5
Front Panel Craft Interface Connector J5
..........................................................3 - 68
3.20
ELMC (J315, J318)
........................................................................................3 - 69
3.21
FOREIGN ALARM INTERFACE (J305)
.............................................................3 - 72
3.22
ALARM, STATUS, AND CONTROLS INTERCONNECT
.....................................3 - 75
3.22.1
Controller Bus
................................................................................................3 - 77
3.22.2
Control Inputs
................................................................................................3 - 77
3.22.3
Station Alarm Inputs/TBOS Interface
...............................................................3 - 77
3.22.4
Station Alarm Wiring
.....................................................................................3 - 78
3.22.5
Relay Alarm/Status Outputs
............................................................................3 - 79
3.22.6
Relay Control Outputs
....................................................................................3 - 80
Section 4 Initial Turnup
4.1
SECTION INTRODUCTION
..............................................................................4 - 1
4.2
RECOMMENDED SEQUENCE
.........................................................................4 - 1
4.3
SECURITY MANAGEMENT
..............................................................................4 - 2
4.4
LOAD MDR-8000 SOFTWARE ON PC
..............................................................4 - 2
4.5
TURN-ON PROCEDURE
...................................................................................4 - 4
4.6
ESTABLISH COM PORT
....................................................................................4 - 4
4.7
TEST PROCEDURES
..........................................................................................4 - 7
4.8
PROVISIONING RADIO
...................................................................................4 - 7
4.9
PROVISION ETHERNET FACILITY
....................................................................4 - 29
4.9.1
Auto-Negotiation
............................................................................................4 - 30
4.10
PROVISION DS1 FACILITY
.............................................................................4 - 32
Page
TOC - 4
Section 5 Maintenance
5.1
INTRODUCTION
.............................................................................................5 - 1
5.2
MAINTENANCE PHILOSOPHY
.........................................................................5 - 2
5.3
RECOMMENDED TEST EQUIPMENT
................................................................5 - 4
5.4
OPTIONAL TEST EQUIPMENT
..........................................................................5 - 4
5.5
PERSONAL COMPUTER (PC)/LAPTOP
..............................................................5 - 5
5.6
MDR-8000 ALARMS
........................................................................................5 - 7
5.7
ALARM MONITORING AND INSPECTION
.......................................................5 - 7
5.8
RECOMMENDED PERIODIC CHECKS
..............................................................5 - 8
5.9
RADIO TROUBLESHOOTING
...........................................................................5 - 8
5.9.1
Troubleshooting USI Alarms
..............................................................................5 - 8
5.9.2
Troubleshooting RCVR Lockup Problems
............................................................5 - 8
5.9.3
Troubleshooting Performance Screen Errors
.......................................................5 - 9
5.10
ETHERNET-SPECIFIC TROUBLESHOOTING
......................................................5 - 24
5.10.1
Troubleshooting Using Ethernet I/O Interface Module Front Panel Indicators ......5 - 24
5.11
TMN-SPECIFIC TROUBLESHOOTING
..............................................................5 - 26
5.12
MODULE REPLACEMENT
...............................................................................5 - 29
5.13
POWER SUPPLY REMOVAL AND REPLACEMENT
............................................5 - 32
5.14
CONTROLLER REMOVAL AND REPLACEMENT
...............................................5 - 33
5.15
DS3 I/O INTERFACE REMOVAL AND REPLACEMENT
.....................................5 - 37
5.16
OC3/STM-1/ETH I/O INTERFACE REMOVAL AND REPLACEMENT
................5 - 39
5.17
XMTR REMOVAL AND REPLACEMENT
...........................................................5 - 40
5.18
XMT CRYSTAL OSCILLATOR FREQUENCY CORRECTION
................................5 - 46
5.19
XMTR OUTPUT LEVEL CHECK (NO PA)
...........................................................5 - 47
5.20
IN-SERVICE XMTR CARRIER NULL ADJUSTMENT
USING SPECTRUM ANALYZER
.......................................................................5 - 48
5.21
XMTR OUTPUT LEVEL CALIBRATION
...............................................................5 - 56
5.22
RCVR REMOVAL AND REPLACEMENT
............................................................5 - 61
5.23
RCV CRYSTAL OSCILLATOR FREQUENCY CORRECTION
................................5 - 64
5.24
PA REMOVAL AND REPLACEMENT
................................................................5 - 65
5.25
PA OUTPUT LEVEL CALIBRATION
...................................................................5 - 67
5.26
CHANGING FREQUENCY
.............................................................................5 - 72
5.27
CLEANING
...................................................................................................5 - 72
TOC - 5
Section 6 User Guide
6.1
INTRODUCTION
.............................................................................................6 - 1
6.2
ANALOG SCREEN
..........................................................................................6 - 1
6.2.1
PA (DC MON)
.................................................................................................6 - 1
6.2.2
TX (PWR MON)
...............................................................................................6 - 1
6.2.3
ATPC Voltage
..................................................................................................6 - 1
6.2.4
RX (RSL 1) dBm
................................................................................................6 - 1
6.2.5
RX (EYE MON)
................................................................................................6 - 1
6.2.6
RX (AFC MON)
................................................................................................6 - 1
6.2.7
Battery Voltage
................................................................................................6 - 1
6.3
DS1/E1 RADIO PERFORMANCE SCREEN
........................................................6 - 3
6.3.1
Repeater CRC Err Sec
......................................................................................6 - 3
6.3.2
Radio Severe Err Sec
........................................................................................6 - 3
6.3.3
Radio Outage Sec
............................................................................................6 - 3
6.3.4
Radio A and B Outage Sec
..............................................................................6 - 3
6.3.5
Radio CRC Err Sec
...........................................................................................6 - 3
6.3.6
Radio CRC Errors
.............................................................................................6 - 3
6.3.7
Radio Internal BER
............................................................................................6 - 3
6.3.8
Radio Average BER
..........................................................................................6 - 3
6.4
DS3 RADIO PERFORMANCE MONITORING SCREEN
......................................6 - 5
6.4.1
Line 1-3 DS3 Errors
..........................................................................................6 - 5
6.4.2
Line 1-3 DS3 BER
.............................................................................................6 - 5
6.4.3
Radio Errors
.....................................................................................................6 - 5
6.4.4
Radio Error Seconds
.........................................................................................6 - 5
6.4.5
Radio Severe Error
...........................................................................................6 - 5
6.4.6
Radio BER
.......................................................................................................6 - 5
6.5
OC3/STM-1 RADIO PERFORMANCE MONITORING SCREENS
........................6 - 6
6.5.1
OC3/STM-1 Errors
..........................................................................................6 - 6
6.5.2
OC3/STM-1 Error Seconds
..............................................................................6 - 6
6.5.3
OC3/STM-1 Severe Error Seconds
...................................................................6 - 6
6.5.4
OC3/STM-1 Severe Error Frame
.......................................................................6 - 6
6.5.5
OC3/STM-1 BER
.............................................................................................6 - 6
6.5.6
Line 1-3 DS1 Error Seconds
..............................................................................6 - 6
6.5.7
Radio Errors
.....................................................................................................6 - 6
TOC - 6
6.5.8
Radio Error Seconds
........................................................................................6 - 8
6.5.9
Radio Severe Error
...........................................................................................6 - 8
6.5.10
Radio BER
.......................................................................................................6 - 8
6.6
ETHERNET RADIO PERFORMANCE MONITORING SCREEN
.............................6 - 8
6.6.1
RF Receive
.......................................................................................................6 - 8
6.6.2
GPF Receive
....................................................................................................6 - 9
6.7
ETHERNET PERFORMANCE MONITORING SCREEN
........................................6 - 9
6.7.1
IN (To RF Transmit)
...........................................................................................6 - 9
6.7.2
OUT (From RF Receive)
...................................................................................6 - 10
6.8
DS1/E1 RADIO CONTROL SCREEN
..............................................................6 - 11
6.8.1
In-Service Controls
.........................................................................................6 - 11
6.8.2
System Loopback Controls
..............................................................................6 - 11
6.8.3
User Controls
.................................................................................................6 - 11
6.8.4
DS1 Line Loopback Controls
...........................................................................6 - 11
6.9
DS3 RADIO CONTROL SCREEN
....................................................................6 - 13
6.9.1
In-Service Controls
.........................................................................................6 - 13
6.9.2
System Loopback Controls
..............................................................................6 - 13
6.9.3
User Controls
.................................................................................................6 - 14
6.9.4
Wayside DS1 Line Loopback Controls
.............................................................6 - 14
6.10
OC3/STM-1 RADIO CONTROL SCREEN
........................................................6 - 16
6.10.1
In-Service Controls
.........................................................................................6 - 16
6.10.2
System Loopback Controls
..............................................................................6 - 16
6.10.3
User Controls
.................................................................................................6 - 16
6.11
ETHERNET RADIO CONTROL SCREEN
...........................................................6 - 18
6.11.1
In-Service Controls
.........................................................................................6 - 18
6.11.2
User Controls
.................................................................................................6 - 18
6.11.3
System Loopback
...........................................................................................6 - 19
6.11.4
DS1 Line Loopback
........................................................................................6 - 21
6.11.5
Inventory Screen
............................................................................................6 - 24
6 - 1
The information contained in this section is a summary of the sec-
tion with the same title, but not the same section number, on the
enclosed CD. “Refer to CD” is used throughout this section to refer
the reader to the detail information on the CD. Go to this section on
the CD for interactive links to the detail information referred to in
this section.
6USER GUIDE
6.1 INTRODUCTION
This section contains descriptions of screens not used or described in other sections.
Where there are operational differences, DS1/E1, DS3, and OC3/STM-1 and/or ETH
screens are shown separately.
6.2 ANALOG SCREEN
See Figure 6 - 1 and Figure 6 - 2. The Analog screen is used to display real-time analog
voltages and radio performance monitors for the ELMC address. Analog voltages are
updated automatically every second. Reset performance parameters to zero using the
Error Reset button (or hotkey F3) on the toolbar. TIME SINCE LAST RESET displays
the time in days, hours, minutes, and seconds since the last error reset.
6.2.1 PA (DC MON)
Indicates PA RF output level (Vdc).
6.2.2 TX (PWR MON)
Indicates XMTR module RF output level (Vdc).
6.2.3 ATPC Voltage
Indicates ATPC CONTROL signal output from controller to XMTR module(s) (Vdc).
6.2.4 RX (RSL 1) dBm
Indicates AGC MON output level from RCVR module (dBm).
6.2.5 RX (EYE MON)
Relative measure of noise level of receive signal (Vdc).
6.2.6 RX (AFC MON)
Indicates AFC MON output from single RCVR module (-3 Vdc = nominal frequency).
(The AFC MON signal is developed from the correction voltage applied to the crystal
oscillator on the single RCVR module.) Not provided by design and replaced with Path
Distortion on dual RCVR module.
6.2.7 Battery Voltage
Indicates battery power input (Vdc).
Note
6 - 2
Figure 6 - 1 Analog Screen (Single RCVR)
Figure 6 - 2 Analog Screen (Dual RCVR)
TRANSMIT Voltages
A B
PA (DC MON)
3.13 3.03
TX (PWR MON)
1.91 1.95
ATPC Voltage
0.74 0.76
RECEIVE Voltages
A B
RX (RSL 1) dbm
-45 dBm -53 dBm
RX (EYE MON)
0.09 0.19
RX (AFC MON)
-2.95 -2.95
Battery Voltage
-50.8 -51.0
LOCAL ANALOG
Communicating*
ELMC Address [F8]:
ELMC Description:
SILVERTON
J7915
Performance
Al
arm
S
tatus
A
na
l
og
M
on
i
tor
S
tat
i
on
Al
arm
P
rov
i
s
i
on
i
ng
U
ser
C
ontro
l
Tuesda
y
, Jul
y
29, 2003
*Voltage not the same as PA Front Panel Test Point
1:44:19 PM USI Version R1.06 Controller Version R1.06
LMW-3123B
01/29/04
TRANSMITTER
A B
PA (DC MON)
N/A N/A
COMMON
A B
Battery Voltage
-53.5 -53.5
TX (PWR MON)
5.00 3.25
ATPC Voltage
0.76 0.74
RECEIVER
A B
RX (RSL) (MN)
-26 dBm -29 dBm
RX (EYE MON) (MN)
0.53 0.94
Path Distortion (MN)
2 1
RX RSL (DV)
-62 dBm -33 dBm
RX (EYE MON) (DV)
0.73 1.03
Path Distortion (DV)
3 2
LOCAL ANALOG
Communicating***
ELMC Address [F8]:
ELMC Description:
SILVERTON
J7915
Tuesday July 29 2003
*Voltage not the same as PA Front Panel Test Point
1:44:19 PM USI Version R1 04 MDR 8000 OC3 Controller Version R1 04
LMW-9073
01/29/04
6 - 3
6.3 DS1/E1 RADIO PERFORMANCE SCREEN
See Figure 6 - 3. The Analog Monitor screen is used to display real-time analog voltages
and radio performance monitors for the ELMC address. Analog voltages are updated
automatically every second. Reset performance parameters to zero using the Error
Reset button (or hotkey F3) on the toolbar. TIME SINCE LAST RESET displays the
time in days, hours, minutes, and seconds since the last error reset.
6.3.1 Repeater CRC Err Sec
Repeater CRC Errored Seconds, indicates number of seconds that contain coding viola-
tions, slips, or frame losses in the data over the repeater cable.
6.3.2 Radio Severe Err Sec
Radio Severe Errored Seconds, indicates number of seconds that contain a predeter-
mined number (N) of coding violations in the data over the RF path.
6.3.3 Radio Outage Sec
Radio Outage Seconds, indicates on-line RCVR errored seconds (number of seconds
that contain coding violations, slips, or frame losses in the data over the RF path).
6.3.4 Radio A and B Outage Sec
Radio A and B Outage Seconds, indicates on-line and off-line RCVR errored in the
same second.
6.3.5 Radio CRC Err Sec
Radio CRC Errored Seconds, indicates number of seconds that contain coding viola-
tions, slips, or frame losses in the data over the RF path.
6.3.6 Radio CRC Errors
Indicates number of errors in the data over the RF path.
6.3.7 Radio Internal BER
Indicates current BER of the data over the RF path.
6.3.8 Radio Average BER
Indicates average BER of the data over the RF path since last reset.
6 - 4
Figure 6 - 3 DS1/E1 Radio Performance Monitor Screen
LOCAL PERFORMANCE
Communicating*
ELMC Address:
lower
PERFORMANCE
0 DAYS , 02:24:39ELAPSED TIME:
Repeater CRC Err Sec
Radio Severe Err Sec
Radio Outage Sec
Radio A and B Outage Sec
Radio CRC Err Sec
Radio CRC Errors
Radio Interval BER
Radio Average BER
A B
0
0
0 0
0
0
0
0
0.00E-12
0
0
0
0
0
Thursday, March 16, 2000
2:15:29 PM
LMW-8005
01/29/04
3 WAYS TO OPEN ANALOG MONITOR SCREEN
3. PRESS F5 ON KEYBOARD
File
Analog and Performance Monitoring -- MDR-8000
View Setup Options
Alarm Status [F4] Perf Monitor [F5] Station Alarm [F6] Control [F7] Provisioning [F9]
2. CLICK HERE
Error Reset [F3]
Alarm Status
Performance
Station Alarm
Control
Provisioning
Inventory
Power Adjust
RSL
F4
F5
F6
F7
F9
F12
Ctl+T
Ctl+R
1. CLICK HERE
6 - 5
6.4 DS3 RADIO PERFORMANCE MONITORING SCREEN
See Figure 6 - 4. Reset performance parameters to zero using the Error Reset button
(or hotkey F3) on the toolbar. TIME SINCE LAST RESET displays the time in days,
hours, minutes, and seconds since the last error reset.
6.4.1 Line 1-3 DS3 Errors
Indicates total number of coding violations, slips, or frame losses in the DS3 line data.
6.4.2 Line 1-3 DS3 BER
Calculated from code violation count and data rate.
6.4.3 Radio Errors
Indicates number of coding violations, slips, or frame losses in the data over the RF
path.
6.4.4 Radio Error Seconds
Any second during which a code violation was detected.
6.4.5 Radio Severe Error
Any second during which the code violation count exceeds the number of errors that
could occur in one second at 1 X 10
-6
error rate.
6.4.6 Radio BER
Calculated from code violation count and data rate.
Figure 6 - 4 DS3 Radio Performance Screen
TRANSMITTER A B
Line 1 DS3 Errors
24462 24462
Elapsed Time: 1 Days, 02:41:23
RECEIVER A B
Line 1 DS3 Errors
22629 22640
Line 2 DS3 Errors
24461 24461
Line 2 DS3 Errors
22630 22615
Line 3 DS3 Errors
24461 24461
Line 3 DS3 Errors
55635 22615
Line 1 DS3 BER
5.6 E-8 5.6 E-8
Line 1 DS3 BER
5.2 E-8 5.2 E-8
Line 2 DS3 BER
5.6 E-8 5.6 E-8
Line 2 DS3 BER
5.2 E-8 5.2 E-8
Line 3 DS3 BER
5.6 E-8 5.6 E-8
Line 3 DS3 BER
5.2 E-8 5.2 E-8
Radio Errors
784 0
Radio Error Seconds
1 0
Radio Severe Error Seconds
27 28
Radio BER
3.3 E-9 1.0 E-14
LOCAL PERFORMANCE
Communicating*
ELMC Address:
ELMC Description:
SILVERTON
J7915
Monday, July 28, 2003 1:44:19 PM USI Version R1.07 Controller Version R1.07
LMW-3123A
01/29/04
6 - 6
6.5 OC3/STM-1 RADIO PERFORMANCE MONITORING SCREENS
See Figure 6 - 5, Figure 6 - 6, and Figure 6 - 7. Reset performance parameters to zero
using the Error Reset button (or hotkey F3) on the toolbar. TIME SINCE LAST RESET
displays the time in days, hours, minutes, and seconds since the last error reset.
6.5.1 OC3/STM-1 Errors
Indicates total number of coding violations, slips, or frame losses in the OC3/STM-1 data.
6.5.2 OC3/STM-1 Error Seconds
Any second during which a code violation was detected. Count is initiated during any
second that qualifies as Unavailable Second.
6.5.3 OC3/STM-1 Severe Error Seconds
Any second during which the code violation count exceeds the number of errors that
could occur in one second at 1 X 10
-6
error rate. Count is inhibited during any second
that qualifies as Unavailable Second.
6.5.4 OC3/STM-1 Severe Error Frame
Any second during which there is no start of frame for at least four consecutive frames.
6.5.5 OC3/STM-1 BER
Calculated from code violation count and data rate.
6.5.6 Line 1-3 DS1 Error Seconds
Any second during which a code violation was detected on the wayside DS1 line.
6.5.7 Radio Errors
Indicates number of coding violations, slips, or frame losses in the data over the RF
path.
Figure 6 - 5 OC3/STM-1 Radio, OC3/STM-1 Facilities Performance Screen
WaySide DS1Radio OC3
Error Seconds 10 0
TRANSMITTER (IN) A B
Errors 942 0
Severe Error Seconds
100 0
Severe Error Frame Seconds
2 0
BER
1.0 E-8 0
Time Since Errors Reset: 0 Days, 00:00:00
Error Seconds 12 0
RECEIVER (OUT) A B
Errors 1192 0
Severe Error Seconds
120 0
Severe Error Frame Seconds
30 0
BER
5.2 E-7 1.0 E-14
Monda
, Jul
28, 2003
3:30:05 PM USI Version R1.04 Controller Version R1.04MDR-8000 OC3
LMW-5072
01/29/04
6 - 7
Figure 6 - 6 OC3/STM-1 Radio, Wayside DS1 Facilities Performance Screen
Figure 6 - 7 OC3/STM-1 Radio, Radio Performance Screen
ELMC Address:
ELMC Description:
LOCAL PERFORMANCE
WAYSIDE DS1RADIO
Communicating**
OC3
Line 2 DS1 Error Seconds 0 0
TRANSMITTER A B
Line 1 DS1 Error Seconds 12 0
Line 3 DS1 Error Seconds 0 0
Time Since Errors Reset: 0 Days, 00:00:00
Line 1 DS2 Error Seconds 0 0
RECEIVER A B
Line 1 DS1 Error Seconds 15 0
Line 1 DS3 Error Seconds
s
0 0
Monday, August 20, 2001 3:30:05 PM USI Version R1.01 Controller Version R1.01MDR-8000 OC3
LMW-5073
01/29/04
WAYSIDE DS1OC3
Performance
Alarm Status Station Alarm User Control ProvisioningError Reset Analog Monitor
ELMC Address:
ELMC Description:
LOCAL PERFORMANCE
Radio
Communicating***
657
Error Seconds 27 0
Errors
RECEIVER A B
2143 0
Severe Error Seconds
5 0
Severe Error Frame Seconds
1 0
BER
5.2 E-7 0
Radio Outage Sec
Radio A and B Outage Sec
0
0
Time Since Errors Reset: 0 Days, 00:00:00
Monday, July 28, 2003 3:41:41 PM USI Version R1.04 Controller Version R1.04MDR-8000 OC3
R101
OC3 6GHz Top
LMW-5074
01/29/04
6 - 8
6.5.8 Radio Error Seconds
Any second during which a code violation was detected. Count is initiated during any
second that qualifies as Unavailable Second.
6.5.9 Radio Severe Error
Any second during which the code violation count exceeds the number of errors that
could occur in one second at 1 X 10
-6
error rate. Count is inhibited during any second
that qualifies as Unavailable Second.
6.5.10 Radio BER
Calculated from code violation count and data rate.
6.6 ETHERNET RADIO PERFORMANCE MONITORING SCREEN
See Figure 6 - 8. Reset performance parameters to zero using the Error reset button on
the toolbar. TIME SINCE LAST RESET displays the time in days, hours, minutes and
seconds, since the last error reset.
6.6.1 RF Receive
6.6.1.1 Errors
Indicates total number of coding violations, slips, or frame losses in the Ethernet data.
6.6.1.2 Error Seconds
Any second during which a code violation was detected. Count is initiated during any
second that qualifies as Unavailable Second.
6.6.1.3 Severe Error Seconds
Any second during which the code violation count exceeds the number of errors that
could occur in one second at 1x 10
-6
error rate. Count is inhibited during any second
that qualifies as Unavailable Second.
6.6.1.4 Severe Error Frame Seconds
Any second during which there is no start of frame for at least four consecutive frames.
6.6.1.5 BER
Calculated from code violation count and data rate.
6.6.1.6 Radio Outage Sec
Radio Outage Seconds, indicates on-line RCVR errored seconds (number of seconds
that contain coding violations, slips, or frame losses in the data over the RF path).
6.6.1.7 Radio A and B Outage Sec
Radio A and B Outage Seconds, indicates on-line and off-line RCVR errored in the
same second.
6 - 9
Figure 6 - 8 Ethernet Radio, Radio Performance Screen
6.6.2 GPF Receive
6.6.2.1 Errors
Indicates total number of coding violations, slips, or frame losses in the Ethernet data.
6.6.2.2 Error Seconds
Any second during which a code violation was detected. Count is initiated during any
second that qualifies as Unavailable Second.
6.6.2.3 Severe Error Seconds
Any second during which the code violation count exceeds the number of errors that
could occur in one second at 1 x 10
-6
error rate. Count is inhibited during any second
that qualifies as Unavailable Second.
6.6.2.4 Severe Error Frame Seconds
Any second during which there is no start of frame for at least four consecutive frames.
6.7 ETHERNET PERFORMANCE MONITORING SCREEN
See Figure 6 - 9. Reset performance parameters to zero using the Error reset button on
the toolbar. TIME SINCE LAST RESET displays the time in days, hours, minutes, and
seconds since the last error reset.
6.7.1 IN (To RF Transmit)
6.7.1.1 Average Bytes/Sec
Indicates average number of frame bytes per second in the Ethernet RCV/radio XMT
data.
C
ommunicating
*
RF RECEIVE A
0
Errors
2
Error seconds
2
Severe Error Seconds
2
Severe Error Frame Seconds
1.0 E-14
BER
2
Radio Outage Sec
2
Radio A and B Outage Sec
GFP RECEIVE AB
0
0
0
0
1.1 E-14
B
4
Errors 0
12
Error Seconds 0
12
Severe Error Seconds 0
4 0
Severe Error Frame Seconds
2.9 E-12 1.5 E-12
BER
EthernetRadio
MDR-1202
08/15/05
6 - 10
6.7.1.2 Total Frames
Indicates number of valid Ethernet frames in the Ethernet RCV/radio XMT data.
6.7.1.3 Error Frames
Frame Check Sequence (FCS) error count indicates the number of Ethernet frames
with errors in the Ethernet RCV/radio XMT data.
6.7.1.4 Dropped Frames
Indicates number of Ethernet frames dropped due to errors in the Ethernet RCV/radio
XMT data or lack of buffer space.
Figure 6 - 9 Ethernet Radio, Ethernet Performance Screen
6.7.2 OUT (From RF Receive)
6.7.2.1 Average Bytes/Sec
Indicates average number of frame bytes per second in the Ethernet XMT/radio RCV
data.
9, 084, 928
LOCAL
PERFORMANCE
(RS 232)
Communicating*
IN (to RF TRANSMIT) A
Average Bytes / Sec
8.655579 E+9
Total Frames
0
Error Frames
65, 520
Dropped Frames
Time Since Errors Reset: 3 Days, 23:45:55
9, 519, 104
OUT (from RF RECEIVE) A
Average Bytes / Sec
1.164721 E+10
Total Frames
5, 431, 296
Error Frames
5, 431, 296
4, 013, 824
B
1.804514 E+9
0
43, 682
0
B
1.316459 E+9
34995
34742
Dropped Frames
EthernetRadio
MDR-1203
08/15/05
6 - 11
6.7.2.2 Total Frames
Indicates number of valid Ethernet frames in the Ethernet XMT/radio RCV data.
6.7.2.3 Error Frames
Frame Check Sequence (FCS) error count indicates the number of Ethernet frames
with errors in the Ethernet XMT/radio RCV data.
6.7.2.4 Dropped Frames
Indicates number of Ethernet frames dropped due to errors in the Ethernet XMT/radio
RCV data, or lack of buffer space.
6.8 DS1/E1 RADIO CONTROL SCREEN
See Figure 6 - 10. The Control screen is used to enable or disable and display the status
of manual controls. Manual controls include equipment and function in-service con-
trols, system loopback controls, user controls, and DS1/E1 loopback controls. The green
square indicates control is enabled. Highlight and click on control name to change
state.
6.8.1 In-Service Controls
IN-SERVICE controls are used to force A or B transmitter, receiver, and I/O interface
modules on -or off-line. IN-SERVICE manual controls are also used to lock the A or B
transmitter ATPC function high (ATPC High Pwr Lock) or low (ATPC Low Pwr Lock).
6.8.2 System Loopback Controls
When enabled, SYSTEM LOOPBACK manual controls loop I/O receiver to I/O trans-
mitter (I/O LOOPBACK). I/O LOOPBACK is a local loopback function that can be used
to test the performance of a standalone radio.
6.8.3 User Controls
USER CONTROLS, defined by the customer and named on the User Control Names
Setup screen, are displayed and can be enabled or disabled if the optional AE-37( )
Relay Interface module is installed.
6.8.4 DS1 Line Loopback Controls
See Figure 6 - 11. When enabled, DS1 LINE LOOPBACK RCV to XMT manual controls
loop DS1/E1 lines individually (Line 1-16 loopback). DS1 LINE LOOPBACK RCV to
XMT is a far-end loopback function that can be used to test over-the-hop.
6 - 12
Figure 6 - 10 DS1/E1 Radio Control Screen
LOCAL CONTROL
Communicating
ELMC Address:
Description:
DURANGO
J7914
Thursday, March 16, 2000
10:15:49 AM
IN-SERVICE
A Transmitter On Line
B Transmitter On Line
A Receiver On Line
A I/O On Line
B I/O On Line
B Receiver On Line
A ATPC High Power Lock
B ATPC High Power Lock
A ATPC Low Power Lock
B ATPC Low Power Lock
Line 1 loopback
Line 2 loopback
Line 3 loopback
Line 4 loopback
Line 5 loopback
Line 6 loopback
Line 7 loopback
Line 8 loopback
Line 9 loopback
Line 10 loopback
Line 11 loopback
Line 12 loopback
Line 13 loopback
Line 14 loopback
Line 15 loopback
Line 16 loopback
SYSTEM LOOPBACK
I/O LOOPBACK
USER CONTROLS
GEN START
TWR LIGHT OVRD
User Control #3
User Control #4
User Control #5
User Control #6
DS1 LINE LOOPBACK RCV to XMT
2. CLICK HERE
3 WAYS TO OPEN CONTROL SCREEN
3. PRESS F7 ON KEYBOARD
File
Controls -- MDR-8000 DS1
View Setup Options
Alarm Status [F4] Perf Monitor [F5] Station Alarm [F6] Control [F7] Provisioning [F9]
Alarm Status
Performance
Station Alarm
Control
Provisioning
Inventory
Power Adjust
RSL
F4
F5
F6
F7
F9
F12
Ctl+P
Ctl+R
1. CLICK HERE
LMW-1006
01/29/04
ACTIVE
HIGHLIGHT AND SELECT "YES"
ON CONFIRMATION MESSAGE
TO ENABLE FUNCTION
6 - 13
Figure 6 - 11 DS1/E1 Loopback
6.9 DS3 RADIO CONTROL SCREEN
See Figure 6 - 12. The Control screen is used to enable or disable and display the status
of manual controls. Manual controls include equipment and function in-service con-
trols, system loopback controls, user controls, and DS1/E1 loopback controls. The green
square indicates control is enabled. Highlight and click on control name to change
state.
6.9.1 In-Service Controls
IN-SERVICE controls are used to force A or B transmitter, receiver, and I/O interface
modules on-or off-line. IN-SERVICE manual controls are also used to lock the A or B
transmitter ATPC function high (APC High Pwr Lock) or low (APC Low Pwr Lock).
6.9.2 System Loopback Controls
See
Figure 6 - 13
.When enabled, SYSTEM LOOPBACK manual controls loop I/O
receiver to I/O transmitter (I/O LOOPBACK). I/O LOOPBACK is a local loopback func-
tion that can be used to test the performance of a standalone radio.
MUX
XMT
RCV
DEMUX
I/O INTFC
MODULE
XMTR
MODULE
LMW-6072
07/05/04
I/O INTFC
MODULE
RCVR
MODULE
DS1 LINE ( ) LOOPBACK
(PER DS1)
I/O LOOPBACK
(ALL DS1s)
6 - 14
6.9.3 User Controls
USER CONTROLS, defined by the customer and named on the User Control Names
Setup screen, are displayed and can be enabled or disabled if the optional AE-27()
Relay Interface module is installed.
6.9.4 Wayside DS1 Line Loopback Controls
See Figure 6 - 13. When enabled, DS1 LINE LOOPBACK RCV to XMT manual controls
loop DS1/E1 lines, individually (Line 1-16 loopback). DS1 LINE LOOPBACK RCV to
XMT is a far-end loopback function that can be used to test over-the-hop.
Figure 6 - 12 DS3 Radio Control Screen
File
Controls
MDR 8000
DS3
View Setup Options
Alarm Status Performance Station Alarm User Control ProvisioningAnalog Monitor
F4 F5 F6 F7 F8 F9
LOCAL CONTROLS
Communicating*
ELMC Address:
Description:
SILVERTON
A Transmitter On Line
B Transmitter On Line
A Receiver On Line
B Receiver On Line
A I/O On Line
B I/O On Line
A ATPC HIGH Power Lock
B ATPC HIGH Power Lock
A ATPC LOW Power Lock
B ATPC LOW Power Lock
J7915
IN-SERVICE
A I/O LOOPBACK
Line 1 Facility
Line 2 Facility
Line 3 Facility
Line 1 Equipment
Line 2 Equipment
Line 3 Equipment
B I/O LOOPBACK
Control #1
Control #2
Control #3
Control #4
Control #5
Control #6
SYSTEM LOOP-BACK
DS3 LINE LOOP-BACK
USER CONTROLS
Thursday, November 30, 2000 1:44:19 PM USI Version R1.02 Controller Version R1.02
LMW-3117
05/14/06
6 - 15
Figure 6 - 13 DS3 System Loopback
UNI XMT
ASIC ENFEC TO
XMTR
I/Q I/Q
UNI RCV
ASIC
DEFEC
FROM
RCVR
LMW-5056
07/05/04
I/Q I/Q
I/Q
DS3 LINE 1-3
DS3 I/O INTFC
FROM
CONTROLLER
DS3 LINE 1-3
LOOPBACK ENABLE
TO/FROM
DS3 LBO
I/O
LOOPBACK
(ALL DS3s)
SW SWITCH
LOOPBACK I/O
CONTROL
ENABLED
6 - 16
6.10 OC3/STM-1 RADIO CONTROL SCREEN
See
Figure 6 - 14
. and
Figure 6 - 15
The Control screen is used to enable or disable and dis-
play the status of manual controls. Manual controls include equipment and function in-
service controls, system loopback controls, user controls, and DS1/E1 loopback controls.
The green square indicates control is enabled. Highlight and click on control name to
change state.
6.10.1 In-Service Controls
IN-SERVICE controls are used to force A or B transmitter, receiver, and I/O interface
(OC3/STM-1) modules on-or off-line. IN-SERVICE manual controls are also used to lock
the A or B transmitter ATPC function high (ATPC High Power Lock) or low (ATPC Low
Power Lock).
6.10.2 System Loopback Controls
See
Figure 6 - 16
for SYSTEM LOOP-BACK. All loopbacks occur in the SMCRA on the I/O
interface module. Loopback functions in both directions are bridged type functions. Data
both loops back and continues. Loopbacks are named by facility in the direction of the loop.
When enabled, A/B OC3/STM-1 Facility loops the optical RCV/radio XMT input to the
radio RCV/optical XMT output. When enabled, A/B OC3/STM-1 Equipment loops the
demultiplexed RCV output of the DEMUX circuit into the input to the MUX circuit.When
enabled, A/B RC3 Equipment loops the output of the MUX circuit into the input of the
DEMUX circuit.
6.10.3 User Controls
USER CONTROLS, defined by the customer and named on the User Control Names Setup
screen, are displayed and can be enabled or disabled if the optional AE-27( ) Relay Inter-
face module is installed.
6 - 17
Figure 6 - 14 OC3/STM-1 Radio Control Screen (Single RCVR)
Figure 6 - 15 OC3/STM-1 Radio Control Screen (Dual RCVR)
Communicating*
ELMC
Address:
Description: DALLAS
A Transmitter Online
B Transmitter Online
A Receiver Online
B Receiver Online
A OC3 Input
B OC3 Input
A OC3 Output
B OC3 Output
A Wayside DS1 Online
B Wayside DS1 Online
RK201
IN-SERVICE
A ATPC High Power Lock
B ATPC High Power Lock
A ATPC Low Power Lock
B ATPC Low Power Lock
USER CONTROLS SYSTEM LOOP-BACK
ATPC POWER LOCK
Control #1
Control #2
Control #3
Control #4
A OC3 Facility
A RC3 Equipment
A OC3 Equipment
B OC3 Facility
B RC3 Equipment
B OC3 Equipment
Control #5
Control #6
Thursday, April 16, 2002 1:47:10 PM USI Version R1.01 MDR-8000 OC3 Controller Version R1.01
LMW-6084
01/29/04
LOCAL
CONTROLS
Communicating
ELMC Address:
A Transmitter On Line
B Transmitter On Line
A Receiver On Line
B Receiver On Line
A OC3 Input
B OC3 Input
DR301
IN-SERVICE
A OC3 Facility B OC3 Facility
A RC3 Equipment B RC3 Equipment
A OC3 Equipment B OC3 Equipment
SYSTEM LOOP-BACK
A Main A Diversity
B Main B Diversity
FORCED SWITCHING
A OC3 Output
B OC3 Output
Monday, July 28, 2003
1:06:08 PM USI Version R1.04 MDR-8000 OC3 Controller Version R1.04
LMW-9075
01/29/04
6 - 18
Figure 6 - 16 OC3/STM-1 Loopbacks
6.11 ETHERNET RADIO CONTROL SCREEN
See Figure 6 - 17. The Control screen is used to enable or disable and display the status
of manual controls. Manual controls include equipment and function in-service con-
trols, system loopback controls, user controls, and DS1 loopback controls. The green
square indicates control is enabled. Highlight and click on control name to change
state.
6.11.1 In-Service Controls
In service controls are used to force A or B transmitter, receiver, and I/O interface mod-
ules on-or off-line. IN-SERVICE manual controls are also used to lock the A or B trans-
mitter ATPC function high (ATPC High Power Lock) or low (ATPC Low Power Lock).
6.11.2 User Controls
USER CONTROLS, defined by the customer and named on the User Control Names
Setup screen, are displayed and can be enabled or disabled if the optional AE-27( )
Relay Interface module is installed.
MUX
Switch
CMD
Switch
CMD
OT/RR
OR/RT
RT
4 x 39
Translator
SMCRA
I/O INTFC XMTR
RR
RCVR
MDR-1094
12/14/04
OC3
Facility
LPBK
OC3
Equipment
LPBK
MUX
Switch
CMD
RC3
Equipment
LPBK
MUX
I
O
I
O
I
O
6 - 19
6.11.3 System Loopback
See Figure 6 - 18 for the system loopback functions. There are three system loopback
functions available on the Ethernet radio; Eth facility loopback, RC3 equipment loop-
back, and Eth equipment loopback. All loopbacks occur on the Ethernet I/O interface
module. The loopback functions are controlled by software via the SYSTEM LOOP-
BACK controls on the USI Control screen.
6.11.3.1 Eth Facility Loopback
Eth facility loopback is a local loopback function that can be used to test the perfor-
mance of a standalone radio. Eth Facility loopback is enabled by selecting A Eth Facil-
ity under SYSTEM LOOPBACK on the USI Control screen. This function loops the
Ethernet RCV/radio XMT (EthR/RT) input back into the Ethernet XMT/radio RCV
(EthT/RR) output. The actual loopback occurs in the PHY circuits on the I/O interface.
When enabled, the EthR/RT input is switched through the MUX to the EthT/RR out-
put. The Eth/R/RT input also continues through the MUX to the ETHRA FPGA.
Figure 6 - 17 Ethernet Radio, Ethernet Control Screen
201R2
LOCAL CONTROLS (RS-232)
Communicating**
IN-SERVICE IN-SERVICE
A Ethernet Facility
A Radio Equipment
A Ethernet Equipment
B Ethernet Facility
B Radio Equipment
B Ethernet Equipment
Control #1
Control #2
Control #3
Control #4
Control #5
Control #6
SYSTEM LOOP-BACK
Line 1 Facility
Line 2 Facility
Line 3 Facility
Line 4 Facility
Line 1 Equipment
Line 2 Equipment
Line 3 Equipment
Line 4 Equipment
DS1 LINE LOOP-BACK RCV to XMT
ELMC Address:
A Transmitter On Line
B Transmitter On Line
A Receiver On Line
B Receiver On Line
A Ethernet In Active
B Ethernet In Active
A Ethernet Out Active
B Ethernet Out Active
A Ethernet Online
B Ethernet Online
A DS1 Online
B DS1 Online
MDR-1204
08/08/05
6 - 20
Figure 6 - 18 Ethernet Loopbacks
6.11.3.2 RC3 Equipment Loopback
RC3 equipment loopback is a local loopback function that can be used to test the per-
formance of a standalone radio. RC3 Equipment loopback is enabled by selecting A
RC3 Equipment under SYSTEM LOOPBACK on the USI Control screen. This func-
tion loops the Eth RCV/radio XMT (EthR/RT) input back into the EthXMT/radio RCV
(EthT/RR) output. The actual loopback occurs in the ETHRA FPGA on the I/O inter-
face. When enabled, the radio XMT (RT) output is switched through the MUX in the
ETHRA, replacing the radio RC (RR) input. The radio XMT (RT) output also continues
to the XMTR RT output.
PHY
MAC FIFO GFP
RADIO
FRAME
MULDEM
ETH TX
DS1 LINE INTFC
ETH RX
SW
CMD
SW
CMD
SW
CMD
SW
CMD
SW
CMD
TI/DS1
FRAMING
ETH
EQUIP
LPBK
ETH
FACILITY
LPBK
ETH RC3 LPBK
(DATA + OH + WSDS1)
ETHRA FPGA
WS DS1 LINE 1
2
3
4
4
3
2
WS DS1 LINE 1
ETH-1046
01/25/06
6 - 21
6.11.3.3 Eth Equipment Loopback
Eth equipment Loopback is a farend loopback function that can be used to test the
over-the-hop performance of radios. Eth Equipment loopback is enabled by selecting A
Eth Equipment under SYSTEM LOOPBACK on the USI Control screen. This function
loops the radio RCV (RR) input into the radio XMT output. The actual loopback occurs
in the PHY circuits on the I/O interface. When enabled, the radio RCV (RR) input is
switched through the MUX in the ETHRA and through the MUX in the PHY, replacing
the Eth RCV/radio XMT (EthR/RT) output to the ETHRA. The radio RCV (RR) input
also continues through the MUX in the PHY to the EthT/RR output.
6.11.4 DS1 Line Loopback
There are two individual DS1 line loopback functions available on the Ethernet radio
Control screen; Line facility Loopback and Line Equipment Loopback. All loopbacks
occur on the Ethernet I/O interface module. The DS1 line loopback functions are con-
trolled by software via the DS1 LINE LOOPBACK controls on the USI Control screen.
6.11.4.1 DS1 Line Facility Loopback
See Figure 6 - 19 for functional block diagram. DS1 facility loopback is a local loopback
function that can be used to test the performance of a standalone radio. Individual
DS1 line facility loopback is enabled by selecting Line 1, 2, 3, or 4 Facility under DS1
LINE LOOPBACK on the USI Control screen. This function loops the DS1 RX1, 2, 3,
or 4 Tip and Ring inputs to the DS1 TX1, 2, 3, or 4 Tip and Ring outputs. The actual
loopback occurs in the QuadFalc FPGA on the I/O interface. When enabled, the DS1,
RX1, 2, 3, or 4 Tip and Ring inputs are switched through the MUX in the QuadFalc,
replacing the radio inputs from the ETHRA. The radio DS1 Rx1, 2, 3, or 4 Tip and Ring
output of the QuadFalc also continues to the ETHRA FPGA.
6.11.4.2 DS1 Line Equipment Loopback
See Figure 6 - 20 for a functional block diagram. DS1 Equipment Loopback is a farend
loopback function that can be used to test the performance of radios over the hop. Indi-
vidual Line Equipment facility loopback is enabled by selecting Line 1, 2, 3, or 4
Equipment under DS1 LINE LOOPBACK on the USI Control screen. This function
loops the DS1 TX1, 2, 3, or 4 Tip and Ring inputs from the RCV circuits on the ETHRA
to the DS1 RX1, 2, 3, or 4 Tip and Ring outputs of the QuadFalc to the XMT circuits in
the ETHRA. The loopback occurs in the QuadFalc FPGA on the I/O interface. When
enabled by the switch command, the DS1 TX1, 2, 3, or 4 Tip and Ring inputs are
switched through the MUX in the QuadFalc, replacing the radio DS1 inputs from the
AUX interface. The radio DS1 TX1, 2, 3, or 4 output of the QuadFalc continues to the
AUX interface board.
6 - 22
Figure 6 - 19 DS1 Facility Loopback – Ethernet
DS1 TX 3 T/R
DS1 TX 4 T/R
I
O
Switch
CMD
I
O
Switch
CMD
DS1 RX 2 T/R
I
O
Switch
CMD
DS1 RX 3 T/R
DS1 RX 4 T/R
I
O
Switch
CMD
DS1 RX 1 T/R
Quad Falc
DS1 TX 1 T/R
DS1 TX 2 T/R
AUX
INTFC
Board
ETHRA
FPGA
MDR-1164
04/28/05
CAUTION
Possibility of
Service
Interruption
Loopbacks cause loss of traffic on DS1 outputs
to X-connect.
Line 4 available in Terminal configuration.
Not available in Repeater configuration.
Note
6 - 23
Figure 6 - 20 DS1 Equipment Loopback – Ethernet
I
O
Switch
CMD
I
O
Switch
CMD
I
O
Switch
CMD
Switch
CMD
I
O
Quad Falc
DS1 TX 3 T/R
DS1 TX 4 T/R
DS1 RX 2 T/R
DS1 RX 3 T/R
DS1 RX 4 T/R
DS1 RX 1 T/R
DS1 TX 1 T/R
DS1 TX 2 T/R
AUX
INTFC
Board
ETHRA
FPGA
MDR-1171
05/31/05
CAUTION
Possibility of
Service
Interruption
Loopbacks cause loss of traffic on DS1 inputs
to ETHRA FPGA.
Line 4 available in Terminal configuration.
Not available in Repeater configuration.
Note
6 - 24
6.11.5 Inventory Screen
See Figure 6 - 21 for Inventory Screen. The inventory screen is used to display current
shelf inventory, including module type number, module part number, hardware revi-
sion, software revision (if applicable), serial number, and remarks (if any).
Inventory is automatically updated if modules are replaced. Manual changes to the
inventory list on the screen are performed only in the factory.
Figure 6 - 21 Inventory Screen
Tuesday, November 30, 2004 3:31:44 PM Universal USI Version P2.00q MDR-8000 OC3 Controller Version P3.13
Side A CommonSide B
ExportCancel Clear
Refresh
Store
Select All TYPE Part Number RV MRev ICS S/W REV Serial Number Misc
Transmitter UD-35AQ-4 3DH03236AD AA 01 01 CA02D546
Transmitter Cap Key N/A 3EM04177AB AB 02 01
00
CA07D577
Transmitter Oscillator N/A 3DH04123AC AB 01
Power Amplifier UD-16BB-2 3DH03218AA AA 03 01 L50W8389
Power Supply DS-35P-2 3DH03164AB AB 01 01 EM1
I/O Interface UD-36AQ-10 3EM03134AB AB 01 01 R02.01 CA09W929
CA09W146
Receiver AE 27AF-1 3DH03239AD
3EM04177AB
AA 01 01
01
CA02D619
Receiver Cap Key N/A
Receiver Oscillator N/A 3DH04123AC AA 01 00
02AB
ELMC Address: R101
LOCAL INVENTORY (RS-232)
Communicating***
Alcatel User Interface – [Universal USI -- Inventory]
F6
Performance
Alarm Status
F4
Station Alarm
F7 F9
User Control
F8F5
Prov. Save
F3
Provisioning
File View Setup Options
MDR-1162
11/21/06
Realization Variant - identifies
differences in design within
family item
Field Not Applicable
Manufacturing Revision -
identifies enhancement-type
changes
Item Change Status -
identifies source of part

Navigation menu
