Owner’s Manual
Roav VIVA X
Model: R5141
51005000687 V01
Table of Content
Important Safety Instructions 01
Introduction 01
Using Roav VIVA X 04
Connecting with Your Car 05
Using Roav VIVA X with Alexa 06
Charge Your Devices 07
Specifications 07
Notice 08
Trademark 09
Customer Service 10
01 02
Important Safety
Instructions
Please read and understand all instructions before using this product.
If damage is caused by failure to follow the instructions, the warranty
does not apply.
• Keep these instructions.
• Do not drop, puncture or disassemble this product.
• This product shall not be exposed to dripping or splashing liquids.
• Avoid long exposure to direct sunlight, which may cause damage.
• Exposing this product to open flames may cause it to explode.
• Do not use the product in strong magnetic fields.
• Use a dry, soft lint-free cloth to clean. Do not use any corrosive
cleaner or oil to clean.
Introduction
Features
• 2-port USB PowerIQ car charger by ANKER.
• Supports voice control via the Alexa services.
*
• Enables music on smartphone to be streamed to car’s radio via an
FM transmitter.
*
Read the AVS Card to learn more proper commands to ask Alexa.
What’s Included
Owner’s Manual
Quick Start Guide
Roav VIVA X
At a Glance
USB charging port LED ring indicator
Car charger connector Microphones
/
Multifunction button
Button Controls
Alexa Voice Service
Wake up
1
Press
Mute / Unmute microphone
1
Long press for 1 second
Calls
Answer / End call
1
Press
Reject call
2
Press two times
Timer & Alarm
Stop
1
Press
03 04
LED Indications
Status LED Ring Indicator
Power on
Lights up blue and circulates a cyan light.
Ready to pair
Pulses blue. (
Pulses blue for 5 minutes,
glows orange for 30 seconds and fades out
if no device
is detected)
No connection Fades out.
Connected
Glows blue for 5 seconds and then dims to 50%
of brightness.
Notification
Arrives: yellow light glows once.
Queues: yellow light pulses slowly.
Wake up
Expanding cyan light from upper left to bottom right.
Thinking
2 cyan lights rotate.
Speaking
Pulses cyan.
Finished
A cyan light dims from bottom right to upper left.
Incoming call
Pulses green.
During call
Lights up green.
Alarm & timer
Alternately pulses blue and cyan.
Volume
Expanding white light from upper left to bottom
right.
Microphone
muted
LED ring and microphone icon turn red.
Using Roav
VIVA X
Plug Roav VIVA X into your vehicle’s cigarette lighter socket.
Start the engine and Roav VIVA X will automatically power
on. The LED Ring Indicator will turn blue and a cyan light will
circulate around the LED Ring Indicator.
Download the Roav VIVA app from the App Store (iOS devices)
or Google Play (Android devices).
Open the app and create a Roav account.
Select “Roav VIVA X” as the device to be added.
05 06
Connecting
with Your Car
To enable the voice service feature through your car stereo, select one
of the two connection modes to connect your smartphone with the
car stereo. Once connected, you can control Roav VIVA X via the app.
For Vehicles with Built-in Bluetooth
Select [Bluetooth Mode] in the app and follow the on-screen instructions
to complete connection setup.
Warning: If you connect Roav VIVA X to your car stereo directly via
Bluetooth, the hands-free calling feature will not be available.
BT BT
For Vehicles without Built-in Bluetooth
FM transmitter is supported with Roav VIVA X. Select [FM Mode] in the
app and follow the on-screen instructions to complete connection setup.
When the FM frequencies of your car radio and in the app are tuned to
the same frequency, the audio is broadcasted via your car stereo. To get
the best audio performance, tune to an unoccupied frequency (one with
a lot of white noise)
*
.
BT FM
*How to find a frequency with white noise radio:
1. Turn on your car’s radio and adjust the volume to a level you can hear.
2. Try every FM frequency from 87.5-107.9 MHz (lowest to highest) on
your car radio. Remember frequencies that have white noise.
3. In the Roav VIVA app, tune the FM frequency to the same frequency
as the car radio's.
Using Roav VIVA
X with Alexa
Roav VIVA X comes with voice service. You can play music, get
navigation directions, manage everyday tasks, easily control
smartphones or other smart devices around you by using your voice.
Follow the on-screen instructions in the Roav VIVA app to login
with your Amazon account.
Press the multifunction button to activate the voice service.
Always say the wake word “Alexa” first and then your request.
Roav VIVA X will respond instantly.
To learn more proper commands to ask Alexa, read the AVS Card.
To explore more skills with Alexa, go to www.amazon.com/
MeetAlexa and download the Amazon Alexa app on your iOS or
Android device.
Alexa, .......
07 08
Charge Your
Devices
Roav VIVA X contains dual USB charging ports. You can charge two
devices at the same time with a maximum output of 5V/4.8A.
2.4A
2.4A
Specifications
Specications are subject to change without notice.
DC input: 12V - 24V
Power output: 5V 4.8 A Max
Bluetooth version: V4.1
Bluetooth transmission distance: 10 m / 393.7 in
FM frequency range: 87.5-107.9 MHz
FM transmission range: 2 m / 78.7 in
Operating temperature range: -4°F to 104°F / -20°C to 40°C
Storage temperature range: -40°F to 185°F / -40°C to 85°C
Notice
This product complies with the radio interference requirements of the
European Community.
BT Operating Frequency Range: 2402-2480 MHz
This product is designed and manufactured with high quality materials
and components, which can be recycled and reused.
This symbol means the product must not be discarded as household
waste, and should be delivered to an appropriate collection facility for
recycling. Proper disposal and recycling helps protect natural resources,
human health and the environment. For more information on disposal
and recycling of this product, contact your local municipality, disposal
service, or the shop where you bought this product.
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Warning:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates uses and can radiate radio frequency
energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radi
o communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or
more of the following measures: (1) Reorient or relocate the receiving antenna.
(2) Increase the separation between the equipment and receiver. (3) Connect the
equipment into an outlet on a circuit different from that to which the receiver is
connected. (4) Consult the dealer or an experienced radio/TV technician for help.
FCC Radio Frequency Exposure Statement
The device has been evaluated to meet general RF exposure requirements. The device can
be used in fixed/mobile exposure condition. The min separation distance is 20cm.
09 10
Trademark
Amazon, Alexa and all related logos are trademarks of Amazon.com,
Inc. or its affiliates.
Apple and the Apple logo are trademarks of Apple Inc., registered in
the U.S. and other countries. App Store is a service mark of Apple Inc.,
registered in the U.S. and other countries.
Google Play and the Google Play logo are trademarks of Google Inc.
“Android” is a registered trademark of Google Inc. in the United
States and other countries.
“iOS” is a registered trademark of Apple Inc. in the United States
and other countries.
The Bluetooth® word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc.
Other trademarks and trade names are those of their respective
owners.
Customer
Service
12-Month Limited Warranty
Lifetime Technical Support
support@goroav.com
+1 (800) 988 7973 (US) Mon-Fri 9:00 - 17:00 (PT)
+44 (0) 1604 936200 (UK) Mon-Fri 6:00 - 11:00 (GMT)
+49 (0) 69 9579 7960 (DE) Mon-Fri 6:00 - 11:00
@GoRoav @GoRoav
© Anker Technology Co., Limited. All rights reserved. ROAV and
the ROAV logo are trademarks of Anker Technology Co., Limited,
registered in the United States and other countries.
