Conformity
AUTEC - Air series
1 Conformity
1.1 Conformity of frequency band 433.050-434.790MHz
Each AIR series' radio remote control working in the frequency band 433.050-434.790MHz
complies with the (R&TTE) Directive 1999/5/EC and its essential requirements.
Each radio remote control is also in conformity with the harmonised standards provided in
the EC Declaration of Conformity.
You can nd the EC Declaration of Conformity on the website www.autecsafety.com, in the
product page of the relevant transmitting unit.
1.2 Conformity of frequency band 915-928MHz: FCC and IC
An AIR series' radio remote control working in the frequency band 915-928MHz complies
with the essential requirements of the following regulations:
-FCC (Federal Communication Commission) Part 15
-IC (Industry Canada) RSS-102
Unit FCC ID IC Number
A8 transmitting unit OQA-A08LA0AM 9061A-A08LA0AM
AJM transmitting unit OQA-AJMDA0BM 9061A-AJMDA0BM
AJR transmitting unit OQA-AJRDA0BM 9061A-AJRDA0BM
AJS transmitting unit OQA-AJSDA0BM 9061A-AJSDA0BM
Transmitting unit
LK6/LK8 OQA-LKNLA1CM 9061A-LKNLA1CM
Transmitting unit
LK6 DF OQA-LKNDA1DM 9061A-LKNDA1DM
Receiving unit G
ACRS13-G OQA-RGAGA00M d9061A-RGAGA00M a b c
Receiving unit G
DCRS13 OQA-RGEBA00M d9061A-RGEBA00M a b c
Receiving unit L
ACRS13-L OQA-RLBHA00M d9061A-RLBCA00M a b c
Receiving unit M
ACRM15 OQA-RMCEA00M d9061A-RMCEA00M a b c
Receiving unit
HACRP8 OQA-RPDFA00M d9061A-RPDFA00M a b c
Receiving unit
MVRCAN OQA-RNFLA00M d9061A-RNFLA00M a b c
Receiving unit
MVRL9E OQA-RRLPA00M d9061A-RRLPA00M a b c
AUTEC - Air series
Frequencies 3
LIAIRE12-01
Receiving unit
DCRM24 OQA-RMGMA00M d9061A-RMGMA00M a b c
Receiving unit
ACRM5E OQA-RMHN00M d9061A-RMHNA00M a b c
a. Under Industry Canada regulations, this radio transmitter may only operate using an antenna
of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To
reduce potential radio interference to other users, the antenna type and its gain should be so
chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary
for successful communication.
b. This radio transmitter has been approved by Industry Canada to operate with the antenna types
listed below with the maximum permissible gain and required antenna impedance for each antenna
type indicated. Antenna types not included in this list, having a gain greater than the maximum
gain indicated for that type, are strictly prohibited for use with this device.
Antenna type Antenna gain Antenna impedance
Autec stylus λ/4 <0dBi 50 Ohm
c. Autec allows you to use only the dedicated antenna supplied either with the remote control or
as original spare part. The use of any other type of antenna is prohibited and will invalidate the
guarantee.
d. Place the antenna of the receiving unit in a position that ensures a minimum separation distance
of 20cm with all the people that can be in the working area.
1.2.1 Federal Communications Commission (FCC)
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Any changes or modications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
1.2.2 Industry Canada (IC)
This device complies with RSS-210 of the Industry Canada Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
2 Frequencies
AIR series radio remote controls can work at two dierent frequency bands: 433.050-
434.790MHz or 915.000-928.000MHz.
4
LIAIRE12-01
Frequencies
AUTEC - Air series
The radio remote controls' working frequency is dened by market-specic
laws and standards. In order for the system “machine+radio remote control”
to be compliant and therefore to be used, it shall comply with such laws and
standards: if it does not, the system may be impounded by competent bodies.
Autec cannot be held responsible if the radio remote control is set with
forbidden frequencies.
They automatically search for a free working frequency.
2.1 Frequency band 433.050-434.790MHz
2.1.1 Frequencies
The radio link between the units of Autec AIR series radio remote controls is established
at one of the frequencies permitted by the European standards in force when the system is
put on the market.
Frequencies used in the band 433.050-434.790MHz ..................................................... 64
RF power ................................................................................................................ <1mW
Channel spacing ...................................................................................................... 25kHz
2.1.2 Market
Air series' radio remote controls working in the frequency band 433.050-434.790 MHz can
be used within the EU (European Union), the EFTA (European Free Trade Association), in
Australia and in Singapore.
2.2 Frequency band 915-928MHz
2.2.1 Frequencies
The radio link between the units of Autec Air series radio remote controls is established at
one of the frequencies permitted by the US, Canadian and Australian standards in force
when the system is put on the market.
Frequencies used in the band 915-928MHz ................................................................ 255
RF power (FCC and IC) ................................................... meets FCC and IC requirements
Channel spacing ...................................................................................................... 50kHz
2.2.2 Market
Air series' radio remote controls working in the frequency band 915-928MHz can be used in
the US, Canadian and Australian markets.
Check on the technical data plate of the units in which markets the radio remote control can
be used.
