Beijing Smartmi Electronic Technology CJXJSQ02ZM Smartmi Evaporative Humidifier User Manual
Beijing Smartmi Electronic Technology Co., Ltd. Smartmi Evaporative Humidifier
User Manual
小米生态链产品包装图纸
历史
版本
版本号：
修改点：
修改人：
版本号：
修改点：
修改人：
版本号：
修改点：
修改人：
版本号：
修改点：
修改人：
版本号：
修改点：
修改人：
纹
理
方
向
专色：PANTONE Cool Gray 11C
材
质
工
艺
要
求
比例 1:1 单位 mm
智米纯净型加湿器使用说明书英文
2018.04.18
韩博
物料编号：
材质：太空梭哑粉105g
工艺：单色印刷、风琴4折
印刷要求：色相正确、印迹牢固、套印准确、
各色套印不露杂色，套印误差≤ 0.1mm
说明书边角为直角，不做R角
V0.9
商品ID SKU编码 商品名称 69码 产品型号
智米纯净型加湿器
Product Introduction
Safety Instructions
Specifications
Regulatory compliance information
Product Introduction Usage
Usage Usage
Repair and Installation
Control Panel Instructions Adding Water
Turning the Machine On and Off, and Changing Modes
Air Dry mode
Adjusting Brightness Reseing the Wi-Fi
Cleaning the Water Tank
If Air Dry mode is on:
Add water through the refilling port Add water into the water tank
Water Level Indicator Mode Indicator
Light Status Light StatusWater Level Current Mode
2 3
Control Panel
Exhaust / Water Refilling Port
Upper Casing
Evaporating Basin
Evaporating
Basin Knob
Water Tank
Water Level Limit
Lower Casing
Temperature and
Humidity Sensor
Water Level Indicator Mode Indicator
Suitable Water: Tap Water, Mineral Water, Purified Water
Note: If you fill past the maximum water level, the water level
indicator lights will flash and the machine will give o warning
beeps, and water should be stopped adding immediately.
Note: If you frequently use the humidifier,
we recommend cleaning it once a week.
You can rinse the water tank with clean water, or
wipe it down with a so cloth to ensure the
cleanliness of your humidifier, and prevent strange
odors produced by stagnant or dirty water.
You can directly add water through the refilling port
while the purifier is powered on. The water will flow
down into the tank, and the water level indicator will
change to reflect how much water has been added.
Stop when all the lights are on.
Take o the top half of the purifier, and directly add
water into the tank. Take care not to fill past the
maximum water level indicator.
Press the Power / Mode Buon to turn the machine on.
The first time you start the machine, it will default to
automatic mode. You can press the buon again to
switch modes. Holding the buon for 2 seconds will
turn the machine o.
Press the Wi-Fi / Light Buon to adjust brightness
between high, low, and o.
Quick Set-up
This product is compatible with the Mijia Smart
Platform. It can be controlled through the Mijia app,
supports the MIUI system, and can connect with other
Mijia smart products.
Search for “Mijia” through your
app store, or scan the QR code
below to install the Mijia app.
Enable your phone’s Bluetooth,
and go to the front page of the
Mijia app. Press the + in the
upper right corner, select Add
a Device, and select “Smartmi
2-in-1 Purifier and Humidifier”.
Aer adding the device, you
should see it on the front page
of the Mijia app.
Note: The machine will not turn on if the water level in
the tank is lower than the minimum water level. You will
have to add water to turn the machine on.
Note: You can turn the Air Dry mode on or o through
the Mijia app.
When the water level drops lower than 10%, the
humidifier will continue to operate for about 8 hours to
dry out the water tank, avoiding strange odors caused
by stagnant water.
If Air Dry mode is off:
When the water level drops lower than 10%, the
humidifier will automatically turn o.
Power / Mode Buon
Wi-Fi / Light Buon
On
On
Blinking O
O
Water Level < 10%
10% ≤ Water Level < 40%
40% ≤ Water Level < 60%
60% ≤ Water Level < 80%
80% ≤ Water Level < 100%
Water Level 100%
Over Max Water Level
Automatic Mode
Speed 1: Low
Speed 2: Medium
Speed 3: High
Automatic Mode: Automatically adjusts
humidifier based on current temperature
and humidity inside the room.
Speed 1: Low
Speed 2: Medium
Speed 3: High
Handling
Product Name Rated Voltage Capacity
Wi-Fi
Network
standby power
consumption：
Humidification
Rate
Rated Frequency
Rated Waage
Noise Generated
Product Type
Model Number
Dimensions
Gross Weight
Net Weight
Smartmi Evaporative
Humidifier
Installation
Power Cable
While in Use
Usage Restrictions
Please turn o and disconnect the machine before moving it.
Please empty the water tank before moving the machine.
To avoid risk of fire, shock, or damage:
Please install the machine according to the instructions provided to avoid electrical shock, fire,
bodily harm, or other dangers.
Do not connect the power cable until you have finished seing up the machine.
Plug the power cable into an appropriate socket.
Do not pull or stretch the power cable.
Disconnect the power cable before performing maintenance, or moving the machine.
If the power cable is damaged, send it to the manufacturer or a repair facility to be replaced by
professionals.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
CAUTION: To comply with the limits of the Class B digital device, pursuant to Part 15 of the FCC Rules, this device is comply
with Class B limits. All peripherals must be shielded and grounded. Operation with non-certified peripherals or non-shielded
cables may results in interference to radio or reception.
MODIFICATION: Any changes or modifications not expressly approved by the grantee of this device could void the user’s
authority to operate the device.
FCC RF EXPOSURE STATEMENT:
This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
FCC ID: 2AP98-CJXJSQ02ZM
If the purifier is tilted, it may misread the water level in the tank, or cause spills. Please ensure that
the device is even before use.
This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
Do not use under the following circumstances to avoid shock, fire, or other dangers:
Wi-Fi Indicator Light
Intake Port
Power Cable
Water Level Detector
1
1
4
7
5
The Smartmi 2-in-1 Purifier and Humidifier humidifies using evaporation, so it won’t produce a visible mist.
6
·
·
If the product starts producing a strange sound, odor, or gets very hot, cease use immediately.
Do not put your finger or other foreign objects inside the protective covering, intake port, exhaust
port, or other movable parts.
Do not allow hair or loose threads to get caught in the intake or exhaust ports.
Do not sit or lean on the machine.
Ensure adequate ventilation when used alongside household gas appliances (such as gas stoves or
water heaters) to avoid carbon monoxide poisoning.
If the alarm stops working, it may be caused by water accumulation in the upper casing. It will not
aect use. It should resume working normally aer the water has evaporated.
·
·
·
·
·
·
·
·
·
·
·
·
·
100-240V
240mL / h
CJXJSQ02ZM 50/60Hz
Evaporative
Humidifier
240 240 363 mm 8W
Approx. 4.3kg
Approx. 5.1kg
≤
47dB(A)
<
2.0W
Wi-Fi IEEE
802.11 b/g/n 2.4GHz
Approx. 4.0L
Manufacturer: Beijing Smartmi Electronic Technology Co., Ltd.
Address: 11-1102, Oce Building Rainbow City, NO.68 Qinghe Mid-Street, Haidian District, Beijing
Smartmi Evaporative Humidifier
Read this manual carefully before use, and retain it for future reference
Standard: Q/BJZMK0008-2018
YT-V1.0(20180531)
160
640
F
A
S
T
E
N
L
O
O
S
E
N
2
1
2
If your phone is unable to connect to the purifier,
press and hold both the Wi-Fi / Light buon and the
Power / Mode buon for 5 seconds. Once you hear
a beep, the Wi-Fi has been successfully reset.
Cleaning the Evaporating Basin
You can remove the evaporating basin and use a so
cloth to wipe down, or clean water to rinse o the basin.
You can also twist o the knob on the evaporating basin
to clean the individual discs that comprise the basin.
As illustrated below, you can twist
o the knob on the basin to remove
the individual disks that comprise
the basin.
Turn the humidifier o and disconnect the power cable
before cleaning the device
