Bilian Electronic BL-LW05-2M 3070-8D mould User Manual integration manual

Shenzhen Bilian Electronic Limited 3070-8D mould integration manual

Contents

integration manual

12.83dBm(b.g.n),11.8dBm(n/HT40)
FCC ID: GGOBL-LW05-2M
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
For product available in the UAS/Canada market, ony channel 1-11 can be operated, selection of
other channels is not possible.
IMPORTANT NOTE:
Integration is strictly limited to mobile/fixed categorized end-products where a separation distance
of at least 20 cm between the radiating part and any human body can be assured during normal
operating conditions.
IMPORTANT NOTE:
In the event that these conditions can not be met (for example certain laptop configurations or
co-location with another transmitter).then the FCC authorization is no longer considered valid and
the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will
be responsible for re-evaluating the end product (including the transmitter) and obtaining a
separate FCC authorization.
IMPORTANT NOTE:
This module is intended for OEM integrator only and the OEM integrators are instructed to ensure
that the end user has no manual instructions to remove or install the device. The OEM integrator is
still responsible for the FCC compliance requirement of the end product, which integrates this
module.
LABEL OF THE END PRODUCT:
The final end product must be labeled in a visible area with the following “Contains TX FCC ID:
GGOBL-LW05-2M”. If the size of the end product is smaller than 8x10cm, then additional FCC
part 15.19 statement is required to be available in the users manual: This device complies with
Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
