CineMate® 520
home theater system
Owner's Guide │ Guía del usuario │ Notice d’utilisation
2 - English
Important Safety Information
Please read this owner’s guide carefully and save it for future reference.
The lightning ash with arrowhead symbol within an equilateral triangle alerts the user to the presence of
uninsulated, dangerous voltage within the system enclosure that may be of sufcient magnitude to
constitute a risk of electric shock.
The exclamation point within an equilateral triangle alerts the user to the presence of important operating
and maintenance instructions in the owner’s guide.
WARNINGS:
• To reduce the risk of re or electric shock, do not expose this product to rain or moisture.
• Do not expose this apparatus to dripping or splashing, and do not place objects lled with liquids, such as
vases, on or near the apparatus. As with any electronic products, use care not to spill liquids into any part
of the product. Exposure to liquids may create a failure and/or re hazard.
• Replace only with a AA (IEC LR06) alkaline battery (or batteries).
• Do not place naked ame sources, such as lighted candles, on or near the product.
CAUTIONS:
• Do not make unauthorized alterations to the product; doing so may compromise safety, regulatory
compliance, system performance, and may void the warranty.
• Long-term exposure to loud music may cause hearing damage. It is best to avoid extreme volume when
using headphones, especially for extended periods.
WARNING:
Contains small parts which may be a choking hazard. Not suitable for children under age 3.
WARNING:
This product contains magnetic material. Contact your physician if you have questions on whether this
might affect the operation of your implantable medical device.
NOTES:
• The product label is located on the bottom of the console.
• Where the mains plug or appliance coupler is used as the disconnect device, such disconnect device shall remain
readily operable.
• This product must be used indoors. It is neither designed nor tested for use outdoors, in recreational vehicles, or
on boats.
• The speaker wire and interconnect cables included with the system are not approved for in-wall installation.
Please check your local building codes for the correct type of wire and cable required for in-wall installation.
Bose Corporation hereby declares that this product is in compliance with the essential requirements
and other relevant provisions of Directive 1999/5/EC and all other applicable EU directive
requirements. The complete declaration of conformity can be found at: www.Bose.com/compliance
English - 3
Important Safety Information
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources, such as radiators, heat registers, stoves, or other apparatus (including ampliers)
that produce heat.
9. Protect the power supply or cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
10. Only use attachments/accessories specied by the manufacturer.
11. Unplug this apparatus during lightning storms or when unused for long periods of time.
12. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way:
such as power supply or cord is damaged; liquid has been spilled or objects have fallen into the apparatus; the apparatus
has been exposed to rain or moisture, does not operate normally, or has been dropped.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modications not expressly approved by Bose Corporation could void the user’s authority to operate
this equipment.
This device complies with part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
This Class B digital apparatus complies with Canadian ICES-003.
CAN ICES-3 (B) / NMB-3 (B)
This device complies with FCC and Industry Canada RF radiation exposure limits set forth for general population.
It must not be co-located or be operating in conjunction with any other antennas or transmitters.
The temperature range of this product is 32ºF (0ºC) to 113ºF (45ºC).
This symbol means the product must not be discarded as household waste, and should
be delivered to an appropriate collection facility for recycling. Proper disposal and
recycling helps protect natural resources, human health and the environment. For more
information on disposal and recycling of this product, contact your local municipality,
disposal service, or the shop where you bought this product.
4 - English
Names and Contents of Toxic or Hazardous Substances or Elements
Toxic or Hazardous Substances and Elements
Part Name
Lead
(Pb) Mercury
(Hg) Cadmium
(Cd) Hexavalent
(CR(VI)) Polybrominated
Biphenyl (PBB) Polybrominated
diphenylether (PBDE)
PCBs X O O O O O
Metal parts X O O O O O
Plastic parts O O O O O O
Speakers X O O O O O
Cables X O O O O O
O: Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for this part is below the limit
requirement in SJ/T 11363-2006.
X: Indicates that this toxic or hazardous substance contained in at least one of the homogeneous materials used for this part is
above the limit requirement in SJ/T 11363-2006.
Please complete and retain for your records:
Serial numbers can be found on the Acoustimass® module’s connector panel and on the
packaging for the remote control.
Module serial number: ________________________________________________________________
Remote serial number: ________________________________________________________________
Console serial number: ________________________________________________________________
Purchase date: _______________________________________________________________________
We suggest you keep your receipt with this owner’s guide.
Important Safety Information
Blu-ray Disc™ and Blu-ray™ are trademarks of the Blu-ray Disc Association.
HDMI is a trademark or registered trademark of HDMI Licensing LLC in the United States and other countries.
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
Manufactured under license under U.S. Patent #’s: 5,956,674; 5,974,380 and 6,487,535 & other
worldwide patents issued & pending. DTS, the DTS Symbol and DTS + the DTS Symbol are
registered trademarks & the DTS logos are trademarks of DTS, Inc. Product includes software. ©2010 DTS, Inc.
All Rights Reserved.
SoundTouch and the wireless note design are trademarks of Bose Corporation in the U.S. and other countries.
Wi-Fi is a registered mark of the Wi-Fi Alliance.
©2014 Bose Corporation. No part of this work may be reproduced, modied, distributed, or otherwise used without
prior written permission.
English - 5
Contents
Introduction
About your CineMate® 520 home theater system ......................................................... 7
System Features ........................................................................................................... 7
Introducing SoundTouch™ from Bose® .................................................................... 7
Unpacking the system ......................................................................................................... 8
Placement guidelines .......................................................................................................... 9
Sample system placement ......................................................................................... 9
Setting Up the Acoustimass® Module
Attaching the rubber feet to the Acoustimass module ................................................ 10
Connecting the Acoustimass module to power ............................................................. 11
Setting Up the Speakers
Connecting the front speakers .......................................................................................... 12
Connecting the rear speakers ............................................................................................ 13
Wall mounting the speakers .............................................................................................. 13
Setting Up the Console
Connecting the console to your TV’s HDMI ARC connector .......................................... 14
TVs without an HDMI ARC connector ............................................................................... 15
Use a secondary connection in the following configurations.............................. 15
Connecting the console to other sources ........................................................................ 15
Connecting to non-HDMI compatible sources ................................................................ 16
Audio-only sources ...................................................................................................... 16
Connecting the console to power ...................................................................................... 16
Starting Up the System
Installing the remote control’s batteries ......................................................................... 17
Powering on the system...................................................................................................... 17
Finishing Setup
Checking for sound ............................................................................................................... 18
Changing the language on the console ............................................................................ 18
Running the ADAPTiQ® audio calibration......................................................................... 19
6 - English
Using the System
Remote control buttons ...................................................................................................... 20
Programming the universal remote control ................................................................... 21
Consumer Electronics Control ................................................................................... 21
Test your HDMI-connected sources for CEC ............................................................ 22
Program the remote to control your source ............................................................ 23
Source selection ................................................................................................................... 24
Select a source connected to the Bose® system .................................................... 24
Select a source connected to your TV ...................................................................... 24
Universal source buttons and console connectors ........................................................ 24
Adjusting the volume .......................................................................................................... 25
Function buttons .................................................................................................................. 25
Programming a non-Bose remote control ....................................................................... 25
Getting System Information from the Display
Understanding messages on the display ........................................................................ 26
Using the System menu.............................................................................................. 26
Error messages ............................................................................................................. 28
Acoustimass module status indicator ............................................................................. 28
Care and Maintenance
Troubleshooting ................................................................................................................... 29
If your console cannot find the Acoustimass® module ......................................... 30
Factory reset the system ............................................................................................ 31
Reset a source button on the remote control ......................................................... 31
Service connectors on the Acoustimass® module ................................................. 31
Cleaning .................................................................................................................................. 32
Customer service .................................................................................................................. 32
Limited warranty .................................................................................................................. 32
Technical information .......................................................................................................... 32
Contents
English - 7
About your CineMate® 520
home theater system
The CineMate 520 system delivers spacious, true 5.1 surround sound from small,
high-performance speakers for consistent audio performance regardless of
content, source or room layout.
System Features
• Advanced Bose audio processing provides natural and lifelike sound.
• ADAPTiQ® audio calibration optimizes sound quality.
• Display provides access to system settings and information.
• HDMI™ connectivity allows easy setup and ensures high-quality audio from your
connected sources.
• Supports Consumer Electronics Control (CEC).
• Programmable universal remote can control your TV, cable/satellite box and
other connected sources.
• Hideaway wireless Acoustimass® module provides impactful bass sound.
• Speakers can be mounted on the wall or floor stands (kit available separately).
• Supports the SoundTouch™ wireless adapter (available separately).
Introducing SoundTouch™ from Bose®
With the SoundTouch™ wireless adapter (available separately), you can stream
Internet radio, music services (where available) and your music library. If you have
Wi-Fi® at home, you’re ready to enjoy your favorite music in any room you want.
Key Benefits
• Enjoy wireless access to Internet radio, music services and your music library.
• Stream your favorite music easily with personalized Presets.
• Works with your existing Wi-Fi® network.
• Free SoundTouch™ app for your computer, smartphone or tablet provides more
powerful control.
• Simply add additional systems at any time for a multi-room listening experience.
• Wide selection of Bose audio systems lets you choose the right solution for
any room.
Introduction
8 - English
Unpacking the system
Carefully unpack the carton and confirm that the following parts are included:
Acoustimass® module Console
(4) Speakers Center speaker Front speaker cable Rear speaker cable
Acoustimass
power cord
Console power cord HDMI cable ADAPTiQ® headset
Universal remote control Rubber feet
The appropriate power cords for your region are supplied.
Note: If part of the system is damaged, do not use it. Contact your authorized
Bose® dealer or Bose customer service. Refer to the contact sheet in
the carton.
Introduction
English - 9
Placement guidelines
To avoid wireless interference, keep other wireless equipment away from the
system. Place the system outside of and away from metal cabinets, away from
other audio/video components and away from direct heat sources.
Acoustimass®
module • Stand the Acoustimass module on its rubber feet along the same wall
as your TV, or along any other wall in the front third of the room.
• Choose a stable and level surface. Vibration can cause the
Acoustimass module to move, particularly on smooth surfaces like
marble, glass or highly polished wood.
• Make sure there is an AC (mains) outlet nearby.
Front speakers • Place one speaker to the left and one speaker to the right of the TV.
• Keep each speaker within 3 ft. (1 m) of the TV, if possible.
• If placing the speakers in an enclosed bookcase shelf, position them at
the front edge of the shelf.
Center speaker • Place the center speaker on a stable and level surface directly above or
below your TV.
Rear speakers • Place the rear speakers toward the back of the room behind you at ear
height (when seated) or higher, if possible.
Console • Place the console near your TV. Do NOT place the TV on top of
your console.
• Make sure there is an AC (mains) outlet nearby.
SoundTouch™
wireless
adapter
(available
separately)
• Place the SoundTouch™ wireless adapter within 1−6 ft. (.3−1.8 m) of
the console.
• If you have the SoundTouch™ wireless adapter, you can begin set up.
Refer to the SoundTouch™ wireless adapter’s owner’s guide for
more information.
Note: Do not connect the adapter to the console until prompted by the
SoundTouch™ app.
Sample system placement
Introduction
10 - English
Attaching the rubber feet to the
Acoustimass module
Attach the rubber feet to the Acoustimass module to protect your floor.
1. Turn the Acoustimass module upside down onto a soft surface to protect it
from being damaged.
2. Attach the rubber feet to the bottom of the Acoustimass module.
Bottom of Acoustimass module
Rubber foot
3. Place the Acoustimass module on its feet.
Caution: Do not place the Acoustimass module on its front, back end, side or
top when in use.
4. Remove all protective films. These may affect acoustic performance if left
in place.
Setting Up the Acoustimass® Module
English - 11
Connecting the Acoustimass module
to power
1. Plug the power cord into the connector on the Acoustimass module.
2. Plug the power cord into an AC (mains) outlet.
Setting Up the Acoustimass® Module
12 - English
Connecting the front speakers
1. Insert the front speaker cable’s L plug into the left speaker.
2. Insert the front speaker cable’s C plug into the center speaker.
3. Insert the front speaker cable’s R plug into the right speaker.
4. Insert the other end of the front speaker cable into the 6-pin
Speaker Connections connector on the console.
Setting Up the Speakers
English - 13
Connecting the rear speakers
1. Insert the rear speaker cable’s LR plug into the left rear speaker.
2. Insert the rear speaker cable’s RR plug into the right rear speaker.
3. Insert the other end of the rear speaker cable into the 4-pin
Speaker Connections connector on the console.
Wall mounting the speakers
You can mount the speakers on wall brackets, floor stands or table stands.
To purchase these accessories, contact your local Bose dealer or visit
www.Bose.com
CAUTION: Do not use any other hardware to mount the speakers.
Setting Up the Speakers
14 - English
Connecting the console to your TV’s
HDMI ARC connector
Use the Bose® HDMI cable to connect the console to your TV.
1. Disconnect your HDMI-connected sources, such as a cable/satellite box, DVD
or Blu-ray Disc™ player or game system, from your TV.
2. Insert one end of the Bose® HDMI cable into the TV connector on the console.
3. Insert the other end of the HDMI cable into your TV’s HDMI connector.
Note: Use your TV’s HDMI connector labeled ARC or Audio Return Channel
if available. If your TV does not have an HDMI ARC connector,
see page 15.
Setting Up the Console
English - 15
TVs without an HDMI ARC connector
If your TV does not have an HDMI ARC connector, you may need to make a
secondary connection to the console with an optical, coaxial or analog stereo
audio cable. Without this secondary connection, you may not hear audio from the
Bose® system.
Use a secondary connection in the following configurations
• You are using internal sources (such as Internet applications or an
over-the-air antenna).
• You are connecting sources to your TV.
Refer to your TV owner’s guide for more information.
Tip: If your TV has IN and OUT audio connector panels, use audio OUT for your
secondary connection.
Connecting the console to other sources
You can connect the console to other sources, such as a cable/satellite box, DVD
or Blu-ray Disc™ player or game system with an HDMI cable (available separately).
If your source is non-HDMI compatible, use different audio and video cables
(see page 16).
1. Insert one end of an HDMI cable into your source’s HDMI (OUT) connector.
2. Insert the other end of an HDMI cable into the appropriate HDMI connector on
the console. For example, to connect a game system, connect an HDMI cable
to the GAME connector.
Connect other sources to the
appropriate HDMI connector
on the console.
Setting Up the Console
16 - English
Connecting to non-HDMI compatible sources
If your source is non-HDMI compatible, connect it to your TV using audio and video
cables (available separately). Refer to your TV owner’s guide for more information.
Tip: If your source has IN and OUT audio connector panels, use audio OUT.
Audio-only sources
If your audio-only source, such as a media or CD player, is non-HDMI compatible,
connect it to the console’s optical, coaxial or analog connector. You can use an
optical, coaxial or analog cable (available separately).
Note: After connecting your audio-only source, you must set the optical, coaxial or
analog input for the appropriate source. You can access these settings using
the System menu (see page 26).
Connecting the console to power
1. Plug the power cord into the Power connector on the console.
2. Plug the power cord into an AC (mains) outlet.
Setting up the Console
English - 17
Installing the remote control’s batteries
1. Slide open the battery compartment cover on the back of the remote control.
2. Insert the two provided AA (IEC-LR6) 1.5V batteries. Match the + and –
symbols on the batteries with the + and – markings inside the compartment.
3. Slide the battery compartment cover back into place.
Powering on the system
Press on the remote.
The console powers on.
The display defaults to CBL SAT for first time power on. Otherwise, the display
defaults to your last used source.
Note: The system powers off after sixteen minutes of inactivity. You can disable
AUTO OFF using the System menu (see page 26).
Starting Up the System
18 - English
Finishing Setup
Checking for sound
1. Power on your TV.
2. If you are using a cable/satellite box or other secondary source, power on
this source.
Tip: If your secondary source is connected to your TV, select the appropriate
TV input. You may need to use a different remote.
3. Power on the system.
4. Press the appropriate source button.
5. Check if sound is coming from the Bose® speakers.
Note: If you do not hear sound from the Bose speakers, see “Troubleshooting”
on page 29.
6. Press on the remote control. Check that no sound is coming from the TV
speakers.
Note: If you hear sound coming from your TV speakers, see “Troubleshooting”
on page 29.
Changing the language on the console
Use the remote control to change the language on the console.
1. Power on the system.
2. Press on the remote control.
3. Press until 10 LANGUAGE appears on the display.
4. Press and to select your language.
5. Press .
Tip: Look for the icon in the System menu if you select the wrong
language.
English - 19
Running the ADAPTiQ® audio calibration
The ADAPTiQ audio calibration customizes the sound of the system to the
acoustics of your listening area by taking five audio measurements. To perform
an audio calibration, you need 10 minutes when the room is quiet.
1. Put the ADAPTiQ headset on your head.
During the ADAPTiQ audio calibration, a microphone on the top of the
headset measures the sound characteristics of your room to determine
optimal sound quality.
2. Insert the ADAPTiQ headset cable into the connector on the console.
3. Press on the remote control.
4. Press until 14 ADAPTiQ appears on the display.
5. Press .
6. Follow the voice prompts until the system completes the process.
7. Unplug the ADAPTiQ headset from the console and store it in a safe place.
Note: If you move the system or any furniture, run ADAPTiQ again to ensure
optimal sound quality.
Finishing Setup
20 - English
Using the System
Remote control buttons
Use the remote to control sources connected to your system, adjust the system
volume, change channels, use playback functions, enable cable/satellite box
functions and navigate the System menu.
Navigation pad
Source selection
Lists recorded
DVR programs
TV aspect ratio
Closed captioning
Selects a source
connected to
your TV
Function buttons
(see page 25)
Teletext mode
Displays the Internet
TV home page
System menu
Playback
controls
Powers on/off the
Bose® system
Powers on/off a
selected source
Toggles between
SoundTouch™
(available separately)
and connector
Previous channel,
chapter or track
English - 21
Using the System
Programming the universal remote control
You can use the remote to control your TV, cable/satellite box, DVD or Blu-ray
Disc™ player, game system, DVR or other auxiliary source.
Consumer Electronics Control
The system supports Consumer Electronics Control (CEC). CEC allows you to
control multiple HDMI-connected sources without programming the remote. You
can turn on/off CEC using the System menu (see page 26).
Your source may support CEC, but refer to it with a different name. Refer to your
source owner’s guide for more information.
CEC controls sources connected to
the console’s HDMI connectors.
Tip: You may need to use your source’s system menu to enable CEC. Refer to your
source owner’s guide for more information.
22 - English
Test your HDMI-connected sources for CEC
Test each of your sources for CEC using the remote control.
Note: Your HDMI-connected source may not support CEC. Refer to your source
owner’s guide for more information.
1. Power off the Bose® system.
2. Prepare your source:
• If you are testing your TV, power off your TV.
• If you are testing another source, power off the source. Power on your TV.
3. Press the button for the source you are testing.
The source button glows. The source and system power on.
4. To ensure your source works properly with your remote control, press a variety
of buttons that correspond with your source’s functions.
If your source does not perform one of the functions, program the remote
control (see page 23).
Using the System
English - 23
Program the remote to control your source
If your source does not support CEC, you can program the remote to control
your source.
1. Power on your source.
2. Locate the code for your source’s brand in the Universal Remote Device Codes
book (provided).
3. On the remote control, press and hold the appropriate source button until all
six source buttons glow, then release.
For example, to program your TV, press and hold .
Only the appropriate source button glows.
4. On the number keypad, enter the code for your source’s brand.
Note: If all six buttons blink three times, you entered an invalid code.
Repeat steps 3 and 4.
5. Press + on the volume button.
6. Test the source for basic functions:
• TV: press the channel buttons. Press . The settings menu appears.
Press and to navigate.
• Cable/satellite box: press . The programming guide appears.
Press and to navigate.
• DVD or Blu-ray Disc™ player: press . The settings menu appears.
Press and to navigate.
• Game system: press and to navigate through your menu.
7. If your source responds to basic functions, press to save
your settings.
If your source does not respond
Use the remote control’s code scanner to find the code for your source.
1. Press + on the volume button to try another code.
Note: If all six buttons blink three times, you have cycled through all codes for
your source.
2. Test the source for basic functions (see step 6 in “Program the remote to
control your source”).
3. Repeat steps 1 and 2 until your source responds.
4. Press to save your settings.
Note: Your source may not be compatible with universal remote controls. Refer to
your source owner’s guide for more information.
Using the System
24 - English
Source selection
You can switch between sources by pressing the appropriate source button on the
remote control. Before you begin, program the remote to control your source
(see page 23).
Select a source connected to the Bose® system
If your source is connected to the console and does not use CEC, follow this
procedure to set the console to the appropriate mode and turn on the source.
1. Power on the system.
2. Press the button for the source you want to control.
The source button glows.
3. Press .
The source powers on.
Select a source connected to your TV
If your source is connected to your TV, follow this procedure to select the
appropriate TV input.
1. Power on the system, your TV and the appropriate source.
2. Press to select the correct input on your TV.
You may need to press several times to select the TV input for
the source.
On some TVs, displays a menu. Use the remote control to choose the
correct TV input and close this menu.
Universal source buttons and
console connectors
The source buttons on your remote control correspond with the connectors on
the back of the console. For example, corresponds with the BD-DVD
HDMI connector.
Your source buttons work with any source that is connected to the corresponding
connector. If you have a secondary DVD or Blu-ray Disc™ player and connect it to
the CBL-SAT connector, it can be programmed to work with .
If you are using the optical, coaxial, or analog connectors, you must set the input
for the appropriate source. You can access these settings using the System menu
(see page 26).
Using the System
English - 25
Adjusting the volume
On the remote control:
• Press + to increase the volume.
• Press – to decrease the volume.
• Press to mute or unmute the audio.
Note: If you hear sound coming from your TV, see “Troubleshooting” on page 29.
Function buttons
The red, green, yellow and blue buttons on the remote control correspond with the
color-coded function buttons on your cable/satellite box or teletext functions.
• Cable/satellite box functions: refer to your cable/satellite box owner’s guide.
• Teletext functions: correspond with color-coded page numbers, headings or
shortcuts on a teletext display.
Programming a non-Bose remote control
You can program a non-Bose remote control, such as your cable/satellite box
remote, to control the system. Refer to your non-Bose remote control owner’s
guide or cable/satellite website for instructions.
Once programmed, the non-Bose remote controls basic functions such as power
on/off and volume.
Using the System
26 - English
Getting System Information from the Display
Understanding messages on the display
The display on the front of the console allows you to access the System menu and
shows system information and icons.
Using the System menu
Use the System menu to adjust audio levels, turn on/off features (such as
AUTO OFF), change the language, set the coaxial, analog and optical inputs for a
particular source, run ADAPTiQ®, pair your Acoustimass® module with the console
or factory reset the system.
1. Press on the remote.
2. Press and to scroll through the System menu.
3. Press and to adjust the settings.
4. Press .
Display System state
1 AUDIO COMP Off: (Default) No change to audio track.
Enhance dialogue: Increases the level of dialogue and
sound effects at low volume settings while
providing full audio impact at high volume settings.
Smart volume: Reduces the range of volume levels in a
movie soundtrack so the difference between extremely
loud outbursts and soft sounds is less noticeable.
2 AUDIO/VIDEO SYNC Adjusts the audio delay to synchronize audio and video.
3 HDMI-CEC On: (Default) Enables CEC (see page 21).
Off: Disables CEC.
4 AUTO OFF Enable: (Default) The system powers off after sixteen
minutes of inactivity (no sound coming from the system).
Disable: The system will not automatically power off.
5 SIDE AUX Audio in: (Default) Sets the connector for an auxiliary
source.
Headphones: Sets the connector as a headphones
input.
Note: If set to Headphones input and a cable is
connected, the speakers are muted.
Disconnect your headphones when not in use.
6 BASS LEVEL Adjusts bass level.
7 TREBLE LEVEL Adjusts treble level.
8 CENTER LEVEL Increases or decreases the level of dialogue for movies
and TV.
English - 27
Getting System Information from the Display
Display System state
9 SURROUND LEVEL Adjusts the volume of the rear speakers relative to
front speakers.
10 LANGUAGE Changes the language on the console and ADAPTiQ®.
11 SET OPTICAL INPUT Sets the optical connector to Auto/TV (Default),
CBL SAT, BD DVD, GAME or AUX source.
12 SET COAXIAL INPUT Sets the coaxial connector to Auto/TV (Default),
CBL SAT, BD DVD, GAME or AUX source.
13 SET ANALOG INPUT Sets the analog connector to Auto/TV (Default),
CBL SAT, BD DVD, GAME or AUX source.
14 ADAPTIQ Starts the ADAPTiQ audio calibration process.
15 PAIR ACOUSTIMASS Reconnects the Acoustimass® module to the system.
16 FACTORY RESET Sets the System menu and ADAPTiQ to the
factory settings.
28 - English
Getting System Information from the Display
Error messages
Display System state
ERROR
Cannot find Acoustimass The Acoustimass® module is not connected to
the console.
<SOURCE>
No signal The source is not connected to the console, or the
source is connected to the console and powered off.
SIDE AUX
Nothing connected The source is not connected to the connector on
the console.
ERROR
Call Bose Call Bose® customer service. Refer to the contact
sheet in the carton.
Acoustimass module status indicator
The status indicator on the back of the Acoustimass module provides information
on system activity.
Indicator activity Acoustimass module state
Amber Connected to the console.
Blinking amber Disconnected from the console.
Slow blinking amber Available to make a wireless connection to the console.
Red System error.
English - 29
Troubleshooting
Problem What to do
No power • Secure the Acoustimass® module’s and console’s power cords.
• Reconnect the Acoustimass module’s and console’s power cords firmly
into an AC (mains) outlet.
• Use the remote control to power on the system.
• Factory reset the system (see page 31).
No sound • Unmute the system.
• Increase the volume.
• Plug the Acoustimass module and console into a live AC (mains) outlet.
• Insert the HDMI cable into a connector on your TV labeled ARC or Audio
Return Channel. If your TV does not have an HDMI ARC connector, use a
secondary audio cable in addition to the HDMI cable (see page 15).
• If using a secondary audio cable, insert the cable into a connector on your
TV labeled Output or OUT, not Input or IN.
• Secure all cable connections on the speakers, TV and connected sources.
• If your source is connected to your TV, select the correct TV input
(see page 24).
• Disconnect headphones when not in use.
• If connecting your source through the connector, enable Audio in
using the System menu (see page 26).
• If you are connecting headphones to the connector, enable
Headphones using the System menu (see page 26).
• If you see the error message Cannot find Acoustimass, pair the
Acoustimass module with the console (see page 30).
• Factory reset the system (see page 31).
Sound is
coming from
your TV
speakers
• Insert the HDMI cable into a connector on your TV labeled ARC or
Audio Return Channel (if available).
• Turn off your TV speakers (refer to your TV owner’s guide).
• Decrease your TV volume to its lowest setting.
Remote
control is
inconsistent
or does not
work
• Match the + and – symbols on the batteries with the + and – markings
inside the compartment (see page 17).
• Replace the battery (see page 17).
• Press the volume button on the remote control and see if the correct
source button flashes.
• If using CEC:
- Point the remote control at the console.
- Program the remote to control your source (see page 23).
• If you have programmed the remote to control your source:
- Point the remote control at the appropriate source.
- Ensure you have entered the correct code for your source’s brand.
- Program the remote with another code (see page 23).
Care and Maintenance
30 - English
Problem What to do
Poor or
distorted
sound
• Remove all protective films from the system.
• Secure all cable connections on the speakers, TV, and connected sources.
• If you see the error message Cannot find Acoustimass:
- Plug in the Acoustimass® module.
- Pair the Acoustimass module with the console (see “If your console
cannot find the Acoustimass® module”).
• If using the analog or connector, decrease the volume on your source.
• Factory reset the system (see page 31) and run the ADAPTiQ® audio
calibration (see page 19).
Intermittent
sound • Secure all cable connections on the speakers, TV, and connected sources.
• Move system away from potential interference, such as a wireless router,
cordless phone, television, microwave, etc.
If your console cannot find the Acoustimass® module
The Acoustimass module and console are paired at the factory. However, if you
see the error message Cannot find Acoustimass on the display, perform this
pairing procedure:
1. Unplug the Acoustimass module.
2. Press on the remote control.
3. Press until 15 PAIR ACOUSTIMASS appears on the display.
4. Press .
Plug in Acoustimass appears on the display.
5. Plug the AC power cord into an AC (mains) outlet.
After the Acoustimass module connects to the console, Pairing complete
appears on the display.
Care and Maintenance
English - 31
Factory reset the system
To troubleshoot problems, reset the System menu and ADAPTiQ® to the
factory settings.
1. Press on the remote control.
2. Press until 16 FACTORY RESET appears on the display.
3. Press 5.
The system resets.
4. Run the ADAPTiQ audio calibration (see page 19).
Reset a source button on the remote control
If you are experiencing problems with a source button on the remote control, reset
the source button to the factory settings.
After performing this procedure, your source button is in CEC mode.
1. On the remote control, press and hold the appropriate source button until all
six source buttons glow, then release.
Only the appropriate source button glows.
2. On the number keypad, enter 0140.
Service connectors on the Acoustimass® module
The Service and Data connectors are for service use only. Do not insert any cables
into these connectors.
Care and Maintenance
32 - English
Cleaning
• Clean the surface of the system with a soft, dry cloth.
• Do not use any sprays near the system. Do not use any solvents, chemicals, or
cleaning solutions containing alcohol, ammonia or abrasives.
• Do not allow liquids to spill into any openings.
Customer service
For additional help, contact Bose® Customer Service. Refer to the contact sheet in
the carton.
Limited warranty
Your system is covered by a limited warranty. Details of the limited warranty are
provided on the product registration card that is in the carton. Please refer to the
card for instructions on how to register. Failure to register will not affect your limited
warranty rights.
The warranty information provided with this product does not apply in Australia and
New Zealand. See our website at www.bose.com.au/warranty or
www.bose.con.nz/warranty for details of the Australia and New Zealand warranty.
Technical information
Acoustimass® module
Power rating: 100-240V 50/60Hz 150W
Console
Power rating: 100-240V 50/60Hz 60W
Care and Maintenance
English - 33
Care and Maintenance
2 - Español
Información de seguridad importante
Lea atentamente esta guía del usuario y guárdela para consultarla en
el futuro.
Elsímboloderelámpagoconpuntadeechadentrodeuntriánguloequiláteroindicaalusuarioquelacaja
delsistemapuedecontenerunatensiónsinaislardemagnitudsucienteparaconstituirunriesgode
descarga eléctrica.
Elsignodeexclamacióndentrodeuntriánguloequiláteroavisaalusuariodequeexisteninstruccionesde
operación y mantenimiento importantes en la guía del usuario.
ADVERTENCIAS:
• Conelndereducirelriesgodedescargaeléctrica,noexpongaesteproductoalalluviaohumedad.
• Noexpongaesteaparatoasalpicadurasogoteo.Nocoloqueencimaocercadelaparatoobjetos
quecontenganlíquidos,comojarrones.Aligualqueconcualquierproductoelectrónico,evitequese
derramenlíquidosenloscomponentesdelproducto.Laexposiciónalíquidospuedeprovocaraveríaso
riesgo de incendio.
• SustituyalaspilasúnicamenteporpilasalcalinasAA(IECLR06).
• Nocoloquesobreelproductoocercadeéstellamasvivas,comoporejemplo,velas.
PRECAUCIONES:
• Norealicemodicacionesnoautorizadasdelproducto;encasocontrariopuedeponerenriesgola
seguridad,elcumplimientonormativo,elrendimientodelsistemayanularlagarantía.
• Laexposiciónprolongadaamúsicaagranvolumenpuedecausarlesionesauditivas.Eviteutilizarlos
auricularesaunvolumenextremo,enespecialdurantelargosperiodosdetiempo.
ADVERTENCIA:
Contienepiezaspequeñasquepuedensuponerriesgodeasxia.Noadecuadoparaniñosmenoresde3años.
ADVERTENCIA:
Este producto contiene material magnético. Consulte a su médico si tiene alguna duda acerca de los
efectosqueestopudieratenerenelfuncionamientodeundispositivomédicoimplantado.
NOTAS:
• Laetiquetadelproductoseencuentraenlabasedelaconsola.
• Siseutilizalaclavijaderedoelconectordelaparatocomodispositivodedesconexión,deberápoderaccionarse
fácilmente.
• Esteproductodebeutilizarseenespaciosinteriores.Noestádiseñadonihasidoprobadoparausoalairelibreni
en embarcaciones.
• Elcabledelaltavozyloscablesdeinterconexiónincluidosconelsistemanoestánhomologadosparainstalación
dentro de la pared. Consulte las normas de construcción locales para conocer el tipo correcto de cables
requeridosparainstalacióndentrodelapared.
BoseCorporationdeclaraporlapresentequeesteproductocumplelosrequisitosesencialesyotras
disposicionesrelevantesdelaDirectiva1999/5/CEytodoslosdemásrequisitosdedirectivas
aplicables de la UE. Encontrará la declaración de conformidad completa en
www.Bose.com/compliance
Español - 3
Información de seguridad importante
Instrucciones de seguridad importantes
1. Lealassiguientesinstrucciones.
2. Guarde estas instrucciones.
3. Tengapresentestodaslasadvertencias.
4. Siga todas las instrucciones.
5. No utilice este aparato cerca del agua.
6. Límpielosoloconuntraposeco.
7. Nobloqueelasaberturasdeventilación.Realicelainstalacióndeacuerdoconlasinstruccionesdelfabricante.
8. Noloinstalecercadefuentesdecalor,talescomoradiadores,salidasdeairecaliente,cocinasuotrosaparatos
(incluidosamplicadores)quegenerencalor.
9. Protejaelcableolafuentedealimentacióndeformaquenadielopiseniquedepinzado,enparticularcercade
enchufes,receptáculosdetomasmúltiplesyenellugarenquesaledelaparato.
10.Utilice solo conexiones y accesorios suministrados por el fabricante.
11. Desenchufeelaparatosiseproduceunatormentaeléctricaosinolovaautilizarduranteperiodosprolongadosdetiempo.
12.Todareparacióndebeserrealizadaporpersonalcualicado.Lleveeldispositivoarepararsipresentaalgúndaño
como,porejemplo,sielcabledealimentaciónestádañado,sisehanvertidolíquidososehancaídoobjetossobre
eldispositivoosiéstehaestadoexpuestoalalluviaohumedad;sinofuncionacorrectamenteosehacaídoalsuelo.
Nota: SehacomprobadoqueesteequipocumpleloslímitesparadispositivosdigitalesdeclaseB,deacuerdocon
elapartado15delasnormasdelaFCC.Estoslímitesestándiseñadosparaofrecerunaprotecciónrazonable
contralasinterferenciasperjudicialesenunainstalacióndoméstica.Esteequipogenera,utilizaypuedeirradiar
energíaderadiofrecuenciay,sinoseinstalayseutilizadeacuerdoconlasinstruccionessuministradas,podría
ocasionarinterferenciasperjudicialesparalascomunicacionesporradio.Noobstante,nosepuedegarantizar
quenosevayaaproducirestetipodeinterferenciasenunainstalaciónenparticular.Siesteequipoocasiona
interferenciasperjudicialesenlarecepciónderadiootelevisión,loquepuedecomprobarseencendiendoy
apagandoelequipo,serecomiendaqueintentecorregirlainterferenciamedianteunadelassiguientesacciones:
• Reorienteoreubiquelaantenareceptora.
• Aumentelaseparaciónentreelequipoyelreceptor.
• Conecteelequipoalatomadeuncircuitodiferentedelqueestáconectadoelreceptor.
• Consulteconsudistribuidoroconuntécnicoderadioytelevisión.
LoscambiosomodicacionesnoaprobadosexpresamenteporBoseCorporationpodríananularlaautorización
quetieneelusuarioparautilizaresteequipo.
Eldispositivocumplelaparte15delasnormasdelaFCCydeexencióndelicenciasRSSdeIndustryCanada.
Elfuncionamientoestásujetoalasdoscondicionessiguientes:(1)Estedispositivonopuedecausarinterferencias
nocivasy(2)estedispositivodebeaceptarcualquierinterferenciaquereciba,incluidaslasinterferenciasque
puedan causar un funcionamiento no deseado.
EsteaparatodeClaseBcumplelaespecicacióncanadienseICES-003.
CANICES-3(B)/NMB-3(B)
EstedispositivorespetaloslímitesdeexposiciónalaradiaciónderadiofrecuenciaestablecidosporlaFCCylas
normasderadiofrecuenciadeIndustryCanadaparalapoblacióngeneral.Nodebeubicarseniutilizarsejuntoa
ninguna otra antena o transmisor.
Elrangodetemperaturasdeesteproductovade0°Ca45°C.
Estesímbolosignicaqueelproductonodebedesecharsecomoresiduosdomésticosy
quedebellevarseauncentroderecogidaadecuadoparasureciclaje.Laeliminacióny
elrecicladoadecuadosayudaaprotegerlosrecursosnaturales,lasaluddelaspersonas
y el medio ambiente. Para obtener más información sobre la eliminación y el reciclado de
esteproducto,póngaseencontactoconsuayuntamiento,servicioderecogidade
residuos o el establecimiento donde compró este producto.

Navigation menu
