Users Manual II
CAEN UHF RFID READERS
COMMUNICATION PROTOCOL
Technical Information Manual
Revision n. 12
14/01/2011
CAEN UHF RFID Readers Communication Protocol – Technical Information Manual
2
Scope of Manual
The goal of this manual is to provide the basic information to work with the CAEN UHF RFID READERS Communication
Protocol.
Reference Document
[RD1] Reader Protocol 1.0 – Working Draft Version of 25 August 2004 – Document revision 33 - EPCGlobal
[RD2] EPC Radio Frequency Identity Protocols Class-1 Generation-2 UHF RFID Protocol for Communications at
860MHz – 960MHz – Version 1.0.9 – EPCGlobal
[RD3] ISO/IEC FDIS 18000-6:2003(E) – Information technology automatic identification and data capture
techniques – Radio frequency identification for item management air interface – Part 6: Parameters for air
interface communication at 860-960 MHz
CAEN RFID srl
Via Vetraia, 11 55049 Viareggio (LU) - ITALY
Tel. +39.0584.388.398 Fax +39.0584.388.959
info@caenrfid.it
www.caenrfid.it
© CAEN RFID srl – 2010
Disclaimer
No part of this manual may be reproduced in any form or by any means, electronic, mechanical, recording, or
otherwise, without the prior written permission of CAEN RFID.
The information contained herein has been carefully checked and is believed to be accurate; however, no responsibility
is assumed for inaccuracies. CAEN RFID reserves the right to modify its products specifications without giving any
notice; for up to date information please visit www.caenrfid.it.
Federal Communications Commission (FCC) Notice (Preliminary) 1
This device was tested and found to comply with the limits set forth in Part 15 of the FCC Rules. Operation is subject to
the following conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received including interference that may cause undesired operation. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial environment.
This device generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the
instruction manual, the product may cause harmful interference to radio communications. Operation of this product in
a residential area is likely to cause harmful interference, in which case, the user is required to correct the interference
at their own expense. The authority to operate this product is conditioned by the requirements that no modifications
be made to the equipment unless the changes or modifications are expressly approved by CAEN RFID.
1 This declaration only applies to FCC readers A828US, A829US, A528, R1230CB, R1260I.
CAEN UHF RFID Readers Communication Protocol - Technical Information Manual
3
Index
Scope of Manual .......................................................................................................................... 2
Reference Document ................................................................................................................... 2
Index.......................................................................................................................................... 3
List of Tables .............................................................................................................................. 3
1 Introduction ....................................................................................................................... 4
General Information .................................................................................................................... 5
2 Protocol Specification ......................................................................................................... 6
Attribute types ............................................................................................................................. 8
Command codes ........................................................................................................................ 12
3 ASYNCHRONOUS NOTIFICATION: PROTOCOL SPECIFICATION ........................................... 21
4 DEFAULT CONFIGURATION ............................................................................................... 23
5 EXAMPLES ........................................................................................................................ 25
Set Protocol Command .............................................................................................................. 26
Inventory Command .................................................................................................................. 27
List of Tables
Tab. 2.1: Attribute types .................................................................................................................... 11
Tab. 2.2: Command codes .................................................................................................................. 20
Tab. 3.1: Attribute types: Notification AVP List. ................................................................................ 22
Tab. 4.1: A928EUEU and A948EUEU Configuration parameters default values ............................... 24
Tab. 4.2: A928EUEU and A948EUEU Default composition of sources .............................................. 24
Tab. 4.3: A828EU A828AEUEU, A829EUEU, A946EUEU and A949EUEU Configuration parameters
default values ............................................................................................................................. 24
Tab. 4.4: A828EU A828AEUEU, A829EUEU, A946EUEU and A949EUEU Default composition of
sources ....................................................................................................................................... 24
CAEN UHF RFID Readers Communication Protocol – Technical Information Manual
4
1 Introduction
CAEN UHF RFID Readers Communication Protocol - Technical Information Manual
5
General Information
This document describes the message format of the communication protocol used by the host and the reader in order
to issuing commands and reply with responses.
The protocol is based on the Attribute Value Pair (AVP) schema and foresees a message header in order to identify the
message scope.
The command set and the firmware architecture draw inspiration from the Reader Protocol 1.0 specification draft from
EPCGlobal but, at now, this protocol is not fully compatible with the same last specifications.
Message fields are described left to right, with the most significant byte on the left and the least on the right.
CAEN UHF RFID Readers Communication Protocol – Technical Information Manual
6
2 Protocol Specification
CAEN UHF RFID Readers Communication Protocol - Technical Information Manual
7
CAEN UHF RFID Reader protocol uses two logical communication channels: one for synchronous commands and one
for asynchronous notifications. Command channel is mandatory and, at now, it is implemented on top of a TCP/IP
socket (port 1000) and on RS232 while notification channels are implemented only with sockets.
All the messages (commands, responses and notifications) are composed by a header and a body. In all cases the body
of the message is a list of attribute-value pairs. Responses always echo the Command AVP sent by the host.
All the packets for the control and notification channel share a common header format:
1 2 3
0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1
+-------------------------------+------------------------------+
| FIXED | Message ID |
+-------------------------------+------------------------------+
| Vendor ID |
+-------------------------------+------------------------------+
| Length |
+-------------------------------+
FIXED: Must be 0x8001 for commands and 0x0001 for responses.
Message ID: Id of the message. It is a sequence number used to map requests to its responses: a request and its
corresponding response have the same message ID (the id is local to the channel).
Vendor ID: Must be 21336: the IANA “SMI Network Management Private Enterprise Code” assigned to CAEN SpA.
Length: Encodes the length of the message (in bytes) including the header.
The header is followed by a list of AVPs the number of which depends on the command. Each AVP have the following
format:
1 2 3
0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1
+-------------------------------+------------------------------+
| RESERVED | Length |
+-------------------------------+------------------------------+
| Attribute Type | Attribute Value ……… |
+-------------------------------+------------------------------+
| ………[ until length is reached ]……… |
+--------------------------------------------------------------+
RESERVED: The first 16 bits are reserved for future extensions. All reserved bits must be set to 0 on outgoing messages
and ignored on incoming messages.
Length: Encodes the length of the AVP packet including the length and the reserved fields.
Attribute type: A 2 byte code identifying the attribute type.
Attribute value: The actual attribute value according to the type. It follows immediately after the Attribute Type field
and runs for the remaining bytes indicated in the Length (i.e. Length minus 6 bytes of header).
CAEN UHF RFID Readers Communication Protocol – Technical Information Manual
8
Attribute types
Code
Description
0x01
CommandName: the command to be executed. All the commands are specified in the relevant
table. Attribute value is 2 bytes long.
0x02
ResultCode: a code representing an indication on the result of the command. All the commands
are specified in the relevant table. Attribute value is 2 bytes long.
0x0E
EventType: the type of the notified event. Attribute value is 4 bytes long and can assume the
following values:
0x00 = Unknown Event
0x01 = Tag glimpsed
0x02 = Tag New
0x03 = Tag Observed
0x04 = Tag Lost
0x05 = Tag Purged
0x0F
TagIDLen: the length of the tag ID. Attribute value is 2 bytes long.
0x10
TimeStamp: an indication of the time. Attribute is 8 bytes long and must be interpreted as
follow:
- the 4 least significant bytes are the seconds elapsed from the 1 January 1970.
- the 4 most significant bytes are the micro-seconds.
0x11
TagID: the ID read from the tag. Attribute value has a maximum length of 12 bytes. For
ISO18000 tags only the first 8 bytes are significant while for EPC tags all the 12 bytes are
significant.
0x12
TagType: the tag’s type. Attribute value is 2 bytes long and can assume the following values:
0x00 = ISO18KB
0x01 = EPCC1G1
0x02 = ISO18KA
0x03 = EPCC1G2
0x05 = EPC119
0x1E
ChannelName: the name of the notification channel. Attribute value has a maximum length of
30 bytes.
0x1F
ChannelAddress: the address of the notification channel. Attribute value has a maximum length
of 30 bytes.
0x20
TriggerName: the name of the trigger. Attribute value has a maximum length of 30 bytes.
0x21
TriggerType: the type of the trigger. Attribute value has a maximum length of 30 bytes.
0x22
ReadPointName: a string representing the name of the read point. Attribute value has a
maximum length of 5 bytes and can assume the following values:
“Ant0”, “Ant1”, “Ant2”, “Ant3”
0x4D
TagValue: data read from the tag memory (when applicable). Attribute value has a maximum
length of 128 bytes.
0x4E
TagAddress: the memory location address of the tag where read or write data (when
applicable). Attribute value is 2 bytes long.
0x4F
RESERVED.
0x50
Length: a value representing the length of a parameter. Attribute value is 2 bytes long.
0x51
BitRate: a value representing the RF BitRate. Attribute value is 2 bytes long and can assume the
following values:
0x0 – Transmit : DSB ASK 10kbit, Receive : FM0 10kbit
0x1 – Transmit : DSB ASK 10kbit, Receive : FM0 40kbit
0x2 – Transmit : DSB ASK 40kbit, Receive : FM0 40kbit
0x3 – Transmit : DSB ASK 40kbit, Receive : FM0 160kbit
0x4 – Transmit : DSB ASK 160kbit, Receive : FM0 400kbit
0x5 – Transmit : DSB ASK 40kbit, Receive : Miller M=2 160kbit
0x6 – Transmit : PR ASK 40kbit, Receive : Miller M=4 250kbit
0x7 – Transmit : PR ASK 40kbit, Receive : Miller M=4 300kbit
0x8 – Transmit : PR ASK 40kbit, Receive : Miller M=2 250kbit
Note: not all the value are supported by all the readers. For the list of mode supported by each
reader please refer to the reader’s user manual.
0x52
PowerGet: a value representing the RF power. Attribute value is 4 bytes long. (used for read the
current setting)
CAEN UHF RFID Readers Communication Protocol - Technical Information Manual
9
Code
Description
0x53
RESERVED.
0x54
Protocol: a value representing the air protocol. Attribute value is 4 bytes long and can assume
the following values:
0x00 = ISO18000-6B
0x01 = EPCC1G1
0x02 = ISO18000-6A
0x03 = EPCC1G2
0x56
ReadPointStatus: a value representing the antenna’s status. Attribute value is 4 bytes long and
can assume the following values:
0x00 = Bad: antenna is not connected or broken.
0x01 = Poor: antenna has a low quality connection.
0x02 = Good: antenna is well connected.
0x57
Boolean: a value representing a boolean data. Attribute value is 2 bytes long and can assume
the following values:
0x00 = FALSE.
Not 0x00 = TRUE.
0x58
IPAddress: a string representing an IP address formatted with the standard IP dotted decimal
format. Attribute value has a maximum length of 30 bytes.
0x59
IPNetMask: a string representing an IP netmask formatted with the standard IP dotted decimal
format. Attribute value has a maximum length of 30 bytes.
0x5A
IPGateway: a string representing an IP address formatted with the standard IP dotted decimal
format. Attribute value has a maximum length of 30 bytes.
0x5B
DESBEnable: used to enable/disable the Data Exchange Status Bit handling for ISO18000-6b and
EPC 1.19 anti-collision algorithm. Attribute value is 2 bytes long and can assume the following
values:
0x00 = Disable the DESB handling.
Not 0x00 = Enable the DESB handling.
0x5C
FWRelease: a string representing the device’s firmware revision. Attribute value has a maximum
length of 200 bytes.
0x5D
DESBStatus: used to check the Data Exchange Status Bit handling for ISO18000-6b and EPC 1.19
anti-collision algorithm. Attribute value is 2 bytes long and can assume the following values:
0x00 = DESB handling is not enabled.
Not 0x00 = DESB handling is enabled.
0x5E
EPCPWD: a value representing an EPC tag password. Attribute value is 2 bytes long.
0x5F
RFOnOff: used to start the generation of a continuous wave for test purposes. Attribute value is
2 bytes long and can assume the following vaules:
0x00 = Stop the wave generation.
Not 0x00 = Start the wave generation.
0x60
BaudRate: a value representing the baudrate setting of serial port. Attribute value is 4 bytes
long.
0x61
DataBits: a value representing the databits setting of serial port. Attribute value is 4 bytes long.
0x62
StopBits: a value representing the stopbits setting of serial port. Attribute value is 4 bytes long.
0x63
Parity: a value representing the parity setting of serial port. Attribute value is 4 bytes long and
can assume the following values:
0x00 = No parity
0x01 = Odd parity
0x02 = Even parity
0x64
FlowCtrl: a value representing the flow control setting of serial port. Attribute value is 4 bytes
long and can assume the following values:
0x00 = No flow control
0x01 = Hardware flow control
0x02 = Software flow control (not yet implemented)
0x65
DateTime: a value representing a date and time. Attribute value has a maximum length of 30
bytes. The data format is:
YYYY–MM–DD HH:MM:SS
CAEN UHF RFID Readers Communication Protocol – Technical Information Manual
10
Code
Description
0x66
SelUnselOp: a value representing the tag selection operation defined by the ISO18000-6B
protocol. Attribute value is 2 bytes long and can assume the following values:
0x00 = select equal
0x01 = select not equal
0x02 = select greater than
0x03 = select lower than
0x04 = unselect equal
0x05 = unselect not equal
0x06 = unselect greater than
0x07 = unselect lower than
0x67
Bitmask: a value representing the bitmask parameter of tag selection operations defined by the
ISO18000-6B protocol. Attribute value is 2 bytes long (only 8 least significant bits are used).
0x68
REESERVED.
0x69
IORegister: a value representing the status of the I/O lines of the reader. Where input lines are
separated from output ones, input lines are mapped on the less significant bits while outputs
are mapped on the most significant. Attribute value is 4 bytes long (effective used bits depend
on the reader model).
0x6A
ConfigParameter: a value representing a configuration parameter. Attribute value is 4 bytes
long and can assume the following values:
0x00 = ReadCycle configuration
0x01 = Observed Threshold configuation
0x02 = Lost Threshold configuration
0x03 = Starting Q value (Valid values : 0 15 ). EPC C1GEN2 Protocol only.
0x04 = Session (Valid values : 0 3 ). EPC C1GEN2 protocol only.
0x05 = Target (Valid values : 0 1 ). EPC C1GEN2 protocol only.
0x06 = Selected (Valid values : 0 1 ). EPC C1GEN2 protocol only.
0x07 = Data Exchange Status B (Valid values : 0 1 ). ISO 18000-6B protocol only.
0x08 = Antenna dwell time during inventory (msec). A528 only.
0x09 = Inventory type (Valid values : 0 3 ). A528 only.
0x6B
ConfigValue: a value for the configuration parameter. Attribute value is 4 bytes long.
0x6C
NoOfTriggers: a value representing the number of triggers. Attribute value is 2 bytes long.
0x6D
NoOfChannels: a value representing the number of channels. Attribute value is 2 bytes long.
0x6E
EventMode: a value representing the event handling mode. Attribute value is 2 bytes long and
can assume the following values:
0x00 = ReadCycle mode
0x01 = Time Mode
0x02 = No Event Mode
0x6F
UpgradeType: a value representing the type of upgrade to perform. Attribute value is 2 bytes
long and can assume the following values:
0x01 = TFTP firmware upgrade.
0x70
UpgradeArgument: a value representing the argument for the requested upgrade. Attribute
value has a maximum length of 255 bytes.
For TFTP upgrade (code 0x01) the string has the form: ‘<tftpserverip>:<filename>’.
0x71
MemoryBank: a value representing the memory bank of a EPC Class 1 Generation 2 tag.
Attribute value is 2 bytes long and can assume the following values:
0x00 = Reserved Memory Bank
0x01 = EPC Memory Bank
0x02 = TID Memory Bank
0x03 = User Memory Bank
0x72
Payload: a value representing the payload parameter for the EPC Class 1 Gen 2 lock command
(see the EPC Gen2 specification for details). Attribute value is 4 bytes long.
0x73
G2Password: a value representing the Acess / Kill password parameter for the EPC Class 1 Gen 2
commands (see the EPC Gen2 specification for details). Attribute value is 4 bytes long.
0x74
G2NSI: a value representing the numbering system identifier for the EPC Class 1 Gen 2 tags’ id
(see the EPC Gen2 specification for details). Attribute value is 2 bytes long.
0x75
QParameter: a value representing the initial value for the Q parameter involved in the EPC Class
1 Gen 2 anticollision algorithm (see the EPC Gen2 specification for details). Attribute value is 2
bytes long.
0x76
ReaderInfo: a string indicating the model and the serial number of the reader.
CAEN UHF RFID Readers Communication Protocol - Technical Information Manual
11
Code
Description
0x77
RFRegulation: a value representing the RF regulation to use. Attribute value is 2 bytes long and
can assume the following values:
0x00 = ETSI EN 302 208
0x01 = ETSI EN 300 220
0x02 = FCC
0x03 = Malaysia
0x04 = Japan
0x05 = Korea
0x06 = Australia
0x07 = China
Note: not all the value are supported by all the readers. For the list of RF regulation supported
by each reader please refer to the reader’s user manual.
0x78
RFChannel: a value representing the RF channel to use. Attribute value is 2 bytes long and can
assume values in the range 0 … 9. Channels are referred to the ETSI EN 302 208 regulation.
0x7A
RSSI: a value representing the backscattered RF field strenght. Attribute value is 2 bytes long.
0x96
PowerSet: a value representing the RF power emitted during the communication with tags.
Attribute value is 4 bytes long. (used to set a new current value).
0xFB
SourceName: a string representing the name of the data source. Attribute value has a maximum
length of 30 bytes and can assume the following values:
“Source_0”, “Source_1”, “Source_2”, “Source_3”
Tab. 2.1: Attribute types
CAEN UHF RFID Readers Communication Protocol – Technical Information Manual
12
Command codes
Code
Description
Comp.
0x12
RawReadIDs: permits to get all the tag’s Ids that are under the RF field of the selected
source (Deprecated).
Parameters:
SourceNameIn: [in] the name of the source to use.
SourceNameOut: [out] the name of the source used.
ReadPointName: [out] the name of the readpoint.
TimeStamp: [out] the time at which the tags are detected.
TagIDLen: [out] the ID length of the tags detected.
ListOfIDs: [out] the list of Ids detected from the source.
ResultCode: [out] the result code.
Note: out parameters are repeated for each readpoint in the source.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
0x13
NewRawReadIDs: permits to get all the tag’s Ids that are under the RF field of the
selected source.
Parameters:
SourceNameIn: [in] the name of the source to use (optional).
Length: [in] Filter Mask Lenght (optional).
TagID: [in] the Filter Mask Value (optional).
TagAddress: [in] Filter Mask Start Address (optional)
Bitmask: [in] Inventory Flags. When set to 1 for each tag detected the RSSI value is
returned. Default value 0. (optional, A528 only).
For each tag detected the parameters returned by the command are:
SourceNameOut: [out] the name of the source used
ReadPointName: [out] the name of the readpoint.
TimeStamp: [out] the time at which the tags are detected.
TagType: *out+ the tag’s type.
TagIDLen: [out] the ID length of the tags detected.
TagID: *out+ the tag’s id.
RSSI: [out] the tag’s backscattered field strength (optional, A528 only)
ResultCode: [out] the result code.
Note: out parameters are repeated for each readpoint in the source.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x3F
AddReadTrigger: permits to add a trigger to a source.
Parameters:
SourceName: [in] the name of the source.
TriggerName: [in] the name of the trigger.
ResultCode: [out] the result code.
A928EU
A948EU
0x40
AddNotifyTrigger: permits to add a trigger to a notification channel.
Parameters:
ChannelName: [in] the name of the channel.
TriggerName: [in] the name of the trigger.
ResultCode: [out] the result code.
A928EU
A948EU
0x41
RemoveReadTrigger: permits to remove a trigger from a source.
Parameters:
SourceName: [in] the name of the source.
TriggerName: [in] the name of the trigger.
ResultCode: [out] the result code.
A928EU
A948EU
0x42
RemoveNotifyTrigger: permits to remove a trigger from a notification channel.
Parameters:
ChannelName: [in] the name of the channel.
TriggerName: [in] the name of the trigger.
ResultCode: [out] the result code.
A928EU
A948EU
CAEN UHF RFID Readers Communication Protocol - Technical Information Manual
13
Code
Description
Comp.
0x49
AllocateTrigger: permits to create a new trigger.
Parameters:
TriggerName: [in] the name of the trigger.
TriggerType: [in] the type of the trigger.
ResultCode: [out] the result code.
A928EU
A948EU
0x4A
DeallocateTrigger: permits to destroy an existing trigger.
Parameters:
TriggerName: [in] the name of the trigger.
ResultCode: [out] the result code.
A928EU
A948EU
0x53
AllocateChannel: permits to create a notification channel.
Parameters:
ChannelName: [in] the name of the channel.
ChannelAddress: [in] the address of the channel.
ResultCode: [out] the result code.
A928EU
A948EU
0x54
DeallocateChannel: permits to destroy a notification channel.
Parameters:
ChannelName: [in] the name of the channel.
ResultCode: [out] the result code.
A928EU
A948EU
0x5D
AddSourceToChannel: permits to add a source to a notification channel.
Parameters:
SourceName: [in] the name of the source.
ChannelName: [in] the name of the channel.
ResultCode: [out] the result code.
A928EU
A948EU
0x5E
RemoveSourceFromChannel: permits to remove a source from a notification channel.
Parameters:
SourceName: [in] the name of the source.
ChannelName: [in] the name of the channel.
ResultCode: [out] the result code.
A928EU
A948EU
0x5F
AddReadPointToSource: permits to add a readpoint to a source.
Parameters:
SourceName: [in] the name of the source.
ReadPointName: [in] the name of the readpoint.
ResultCode: [out] the result code.
A928EU
A948EU
A528
R1230CB
R1260I
0x60
RemoveReadPointFromSource: permits to remove a readpoint from a source.
Parameters:
SourceName: [in] the name of the source.
ReadPointName: [in] the name of the readpoint.
ResultCode: [out] the result code.
A928EU
A948EU
A528
R1230CB
R1260I
0x64
SetPower: permits to set the RF power level.
Parameters:
PowerSet: [in] the power level to set.
ResultCode: [out] the result code.
A928EU
A948EU
A949EU
A528
A828AEU
R1230CB
R1260I
0x6E
ReadTagData: permits to read data from the tag memory.
Parameters:
SourceName: [in] the name of the source to use.
TagIDLen: [in] the ID length of the tag.
TagID: [in] the ID of the tag.
TagAddress: [in] the address from which read the data.
Length: [in] the number of bytes to read.
TagValue: [out] the data read from the tag memory.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
R1230CB
R1260I
CAEN UHF RFID Readers Communication Protocol – Technical Information Manual
14
Code
Description
Comp.
0x6F
WriteTagData: permits to write data to the tag memory.
Parameters:
SourceName: [in] the name of the source to use.
TagIDLen: [in] the ID length of the tag.
TagID: [in] the ID of the tag.
TagAddress: [in] the address where to write the data.
Length: [in] the number of bytes to write.
TagValue: [in] the data to write to the tag memory.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
R1230CB
R1260I
0x70
LockTag: permits to lock data into the tag memory.
Parameters:
SourceName: [in] the name of the source to use.
TagIDLen: [in] the ID length of the tag.
TagID: [in] the ID of the tag.
TagAddress: [in] the address where to write the data.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
R1230CB
R1260I
0x71
RESERVED
0x72
SetBitRate: permits to set the BitRate to use.
Parameters:
BitRate: [in] the BitRate to set.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x73
GetPower: permits to get the current RF power level.
Parameters:
PowerGet: [out] the current power level.
ResultCode: [out] the result code.
A928EU
A948EU
A949EU
A528
R1230CB
R1260I
0x74
SetProtocol: permits to set the protocol to use.
Parameters:
Protocol: [in] the protocol to use.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x75
RESERVED
0x76
CheckReadPointStatus: permits to check the quality of the antenna connection.
Parameters:
ReadPointName: [in] the name of the readpoint.
ReadPointStatus: [out] the quality of the connection.
ResultCode: [out] the result code.
A928EU
A948EU
A949EU
0x77
CheckSourceInChannel: permits to verify if a source is assigned to a notify channel.
Parameters:
SourceName: [in] the name of the source.
ChannelName: [in] the name of the channel.
Value: [out] a Boolean value meaning the belonging to the source.
ResultCode: [out] the result code.
A928EU
A948EU
CAEN UHF RFID Readers Communication Protocol - Technical Information Manual
15
Code
Description
Comp.
0x78
CheckReadPointInSource: permits to verify if a readpoint belongs to a givens source.
Parameters:
ReadPointName: [in] the name of the readpoint.
SourceName: [in] the name of the source.
Value: [out] a Boolean value meaning the belonging to the source.
ResultCode: [out] the result code.
A928EU
A948EU
A949EU
A528
R1230CB
R1260I
0x79
GetProtocol: permits to get the protocol in use.
Parameters:
Protocol: [out] the protocol in use.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x7A
SetNetwork: permits to set up the network configuration.
Parameters:
IPAddress: [in] the IP address to set.
IPNetMask: [in] the IP netmask to set.
IPGateway: [in] the IP gateway to set.
ResultCode: [out] the result code.
A928EU
A948EU
0x7B
SetDESB: permits to enable or disable the “Data Exchange Status Bit” handling during
the anti-collision algorithm when ISO 18000-6b air protocol is in use.
Parameters:
DESBEnable: [in] enable/disable value.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
0x7C
GetFirmwareRelease: permits to get the firmware revision.
Parameters:
FWRelease: [in] the firmware release.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x7D
GetDESB: permits to get the current setting of the “Data Exchange Status Bit” handling.
Parameters:
DESBStatus: [in] enabled/disabled value.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
0x7E
ProgramID: permits to program the ID in the EPC Class 1 Gen 1 tags.
Parameters:
SourceName: [in] the name of the source.
TagIDLen: [in] the ID length of the tag.
TagID: [in] the ID of the tag.
EPCPWD: [in] the EPC password to set.
Lock: [in] a Boolean value; TRUE = lock the ID. FALSE = do not lock.
ResultCode: [out] the result code.
A928EU
A948EU
0x7F
KillTag: permits to kill a EPC Class 1 Gen 1 tag.
Parameters:
SourceName: [in] the name of the source.
TagIDLen: [in] the ID length of the tag.
TagID: [in] the ID of the tag.
EPCPWD: [in] the EPC password.
ResultCode: [out] the result code.
A928EU
A948EU
CAEN UHF RFID Readers Communication Protocol – Technical Information Manual
16
Code
Description
Comp.
0x80
RFOnOff: permits to start/stop the generation of a continuous wave. Used only for test
and measurements purposes.
Parameters:
RFOnOff: [in] = 0 stop; != 0 start
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x81
GetBitRate: permits to get the BitRate in use.
Parameters:
BitRate: [out] the BitRate in.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x82
BlockWriteTag: permits to write data to the tag memory. This function uses the
ISO18000-6b Write4Byte command to speed up the writing of large amount of data at
one time.
Parameters:
SourceName: [in] the name of the source to use.
TagIDLen: [in] the ID length of the tag.
TagID: [in] the ID of the tag.
TagAddress: [in] the address where to write the data.
Length: [in] the number of bytes to write.
TagValue: [in] the data to write to the tag memory.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
0x83
SetRS232: permits to modify the settings of the serial port.
Parameters:
Baudrate: [in] the baud rate value.
Databits: [in] the data bits setting.
Stopbits: [in] the stop bits setting.
Parity: [in] the parity setting.
Flowctrl: [in] the flow control setting.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x84
SetDateTime: permits to modify date and time.
Parameters:
Datetime: [in] the date and time to set up.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
0x85
GroupSelectUnselect: permits to execute the tag selection commands defined by the
ISO18000-6B protocol.
Parameters:
SourceName: [in, optional] the name of the source to use.
Operation: [in] the tag selection operation.
Bytemask: [in] the byte mask as defined by the protocol.
TagAddress: [in] the address where to compare the data.
TagValue: [in] the data to compare with the tag memory.
TagID: [out] the ID of the tag.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
CAEN UHF RFID Readers Communication Protocol - Technical Information Manual
17
Code
Description
Comp.
0x86
GetIO: permits to read the current status of the I/O lines.
Parameters:
IORegister: [out] the status of the I/O lines.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x87
SetIO: permits to set the level of the output lines.
Parameters:
IORegister: [in] the value to set to the output lines.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x88
SetIODirection: permits to define the direction of the I/O lines.
(0 = input; 1 = output)
Parameters:
IORegister: [in] the direction to set to the I/O lines.
ResultCode: [out] the result code.
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x89
GetIODirection: permits to read the current status of the I/O lines. (0 = input; 1 =
output)
Parameters:
IORegister: [out] the direction of the I/O lines.
ResultCode: [out] the result code.
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x8A
SetSourceConfig: permits to set a configure parameter for a logical source.
Parameters:
SourceName: [in] the name of the source to configure.
ConfigParameter: [in] the code of the parameter.
ConfigValue: [in] the value for the parameter.
ResultCode: [out] the result code.
A928EU
A948EU
A528
R1230CB
R1260I
0x8B
GetSourceConfig: permits to read a configure parameter for a logical source.
Parameters:
SourceName: [in] the name of the source to configure.
ConfigParameter: [in] the code of the parameter.
ConfigValue: [out] the value for the parameter.
ResultCode: [out] the result code.
A928EU
A948EU
A528
R1230CB
R1260I
0x8C
GetTriggers: permits to read the names of the allocated triggers.
Parameters:
NoOfTriggers: [out] the number of allocated triggers.
ListOfTriggerNames: [in] a list containing the names of the allocated triggers.
ResultCode: [out] the result code.
A928EU
A948EU
0x8D
GetChannels: permits to read the names of the allocated notification channels.
Parameters:
NoOfChannels: [out] the number of allocated channels.
ListOfChannelNames: [in] a list containing the names of the allocated channels.
ResultCode: [out] the result code.
A928EU
A948EU
CAEN UHF RFID Readers Communication Protocol – Technical Information Manual
18
Code
Description
Comp.
0x8E
CheckSourceInTrigger: permits to verify if the specified logical source is associated to
the specified trigger.
Parameters:
SourceName: [in] the name of the source.
TriggerName: [in] the name of the trigger.
Boolean: [out] 0 if they are associated, ≠0 if not.
ResultCode: [out] the result code.
A928EU
A948EU
0x8F
CheckTriggerInChannel: permits to verify if the specified trigger is associated to the
specified channel.
Parameters:
ChannelName: [in] the name of the source.
TriggerName: [in] the name of the trigger.
Boolean: [out] 0 if they are associated, ≠0 if not.
ResultCode: [out] the result code.
A928EU
A948EU
0x90
CheckChannelInTrigger: permits to verify if the specified channel is associated to the
specified trigger.
Parameters:
ChannelName: [in] the name of the source.
TriggerName: [in] the name of the trigger.
Boolean: [out] 0 if they are associated, ≠0 if not.
ResultCode: [out] the result code.
A928EU
A948EU
0x91
SetEventMode: permits to set the event generation mode for the reader notification
channels.
Parameters:
EventMode: [in] the event mode.
ResultCode: [out] the result code.
A928EU
A948EU
0x92
GetEventMode: permits to read the event generation mode for the reader notification
channels.
Parameters:
EventMode: [out] the event mode.
ResultCode: [out] the result code.
A928EU
A948EU
0x93
FirmwareUpgrade: permits to upgrade the reader firmware.
Parameters:
UpgradeType: [in] the type of the upgrade.
UpgradeArg: [in] the argument needed by the upgrade procedure.
ResultCode: [out] the result code.
A928EU
A948EU
0x94
E119ProgramID: permits to write the EPC into a EPC1.19 tag.
Parameters:
SourceName: [in] the name of the source to use.
TagID: [in] the old EPC of the tag.
TagValue: [in] the EPC to write into the tag memory.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
0x95
G2ProgramID: permits to write the EPC in a Class 1 Gen 2 tag.
Parameters:
SourceName: [in] the name of the source to use.
TagIDLen: [in] the ID length of the tag (must be an even number).
TagID: [in] the EPC to write into the tag memory.
G2NSI: [in] the EPC numbering system.
G2Password: [in] the EPC Access password (optional).
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
CAEN UHF RFID Readers Communication Protocol - Technical Information Manual
19
Code
Description
Comp.
0x96
G2Read: permits to read data from anyone of the Gen2 tag memory banks.
Parameters:
SourceName: [in, optional] the name of the source to use.
TagIDLen: [in] the ID length of the tag.
TagID: [in] the ID of the tag.
MemoryBank: [in] the memory bank.
TagAddress: [in] the address where to read the data.
Length: [in] the number of bytes to read (must be an even number).
TagValue: [out] the data read from the tag memory.
G2Password: [in] the EPC Access password (optional).
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x97
G2Write: permits to write data into anyone of the Gen2 tag memory banks.
Parameters:
SourceName: [in, optional] the name of the source to use.
TagIDLen: [in] the ID length of the tag.
TagID: [in] the ID of the tag.
MemoryBank: [in] the memory bank.
TagAddress: [in] the address where to write the data.
Length: [in] the number of bytes to write (must be an even number).
TagValue: [in] the data to write to the tag memory.
G2Password: [in] the EPC Access password (optional).
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x98
G2Lock: permits to execute the tag lock command defined by the EPC Class 1 Gen 2
protocol.
Parameters:
SourceName: [in, optional] the name of the source to use.
TagIDLen: [in] the ID length of the tag.
TagID: [in] the ID of the tag.
G2Payload: [in] the lock payload.
G2Password: [in] the EPC Access password (optional).
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x99
G2Kill: permits to execute the tag kill command defined by the EPC Class 1 Gen 2
protocol.
Parameters:
SourceName: [in, optional] the name of the source to use.
TagIDLen: [in] the ID length of the tag.
TagID: [in] the ID of the tag.
G2Password: [in] the kill password.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x9A
G2Query: permits to execute the tag query command defined by the EPC Class 1 Gen 2
protocol. If a tag is in the field result code is ERROR_SUCCESS (0x00) else result code is
ERROR_TAGNOTPRESENT (0xCA).
Parameters:
SourceName: [in] the name of the source to use.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x9B
G2SetQ: permits to change the initial value of the Q parameter used in the Gen2
anticollision algorithm.
Parameters:
QParameter: [in] the value of the Q parameter.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
CAEN UHF RFID Readers Communication Protocol – Technical Information Manual
20
Code
Description
Comp.
0x9C
G2GetQ: permits to read the initial value of the Q parameter used in the Gen2
anticollision algorithm.
Parameters:
QParameter: [out] the value of the Q parameter.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x9D
G2QueryAck: permits to execute the tag query and ack command defined by the EPC
Class 1 Gen 2 protocol. If a tag is in the field result code is ERROR_SUCCESS (0x00) and
the command returns the EPC code stored in the tag else the result code is
ERROR_TAGNOTPRESENT (0xCA).
Parameters:
SourceName: [in] the name of the source to use.
TagID: [out] the ID of the tag.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x9E
GetReaderInfo: permits to read some information about the reader itself.
Parameters:
ReaderInfo: [out] a string with information about the reader.
ResultCode: [out] the result code.
A928EU
A948EU
A828EU
A828AEU
A829EU
A949EU
A528
R1230CB
R1260I
0x9F
SetLBTMode: permits to enable or disable the Listen Before Talk capability on ETSI EN
302 208 compatible readers.
Parameters:
Boolean: [in] 0 to disable LBT and ≠0 to enable LBT.
ResultCode: [out] the result code.
A948EU
A949EU
A528
R1230CB
R1260I
0xA0
GetLBTMode: permits to read the current setting for the Listen Before Talk capability
on ETSI EN 302 208 compatible readers.
Parameters:
Boolean: [out] 0 if LBT is disabled, ≠0 if LBT is enabled.
ResultCode: [out] the result code.
A948EU
A949EU
A528
R1230CB
R1260I
0xA1
SetRFRegulation: permits to change the RF regulation used by the reader.
Parameters:
RFRegulation: [in] the desired RF regulation.
ResultCode: [out] the result code.
A948EU
A949EU
A528
R1230CB
R1260I
0xA2
GetRFRegulation: permits to read the RF regulation used by the reader.
Parameters:
RFRegulation: [out] the desired RF regulation.
ResultCode: [out] the result code.
A948EU
A949EU
A528
R1230CB
R1260I
0xA3
SetRFChannel: permits to set the RF channel where the reader emits the RF field.
Parameters:
RFChannel: [in] the RF channel.
ResultCode: [out] the result code.
A948EU
A949EU
A528
R1230CB
R1260I
0xA4
GetRFChannel: permits to read the RF channel currently in use.
Parameters:
RFChannel: [out] the RF channel.
ResultCode: [out] the result code.
A948EU
A949EU
A528
R1230CB
R1260I
0xFFFF
RESERVED
Tab. 2.2: Command codes
CAEN UHF RFID Readers Communication Protocol - Technical Information Manual
21
3 ASYNCHRONOUS
NOTIFICATION:
PROTOCOL SPECIFICATION
CAEN UHF RFID Readers Communication Protocol – Technical Information Manual
22
The notification channels are implemented only with sockets.
All the messages notifications are composed by a header and a body. In all cases the body of the message is a list of
attribute-value pairs. The first AVP of the body is fixed and called NotifyMessage.
All the packets for notification channel share the same header format of other packet as described at § 3.
The first AVP (NotifyMessage) is followed by a list of AVPs, the number of which depends on how many tags should be
notified. Each AVP has the same format of the AVP described in § 3.
The NotifyMessage has the following fixed format:
1 2 3
0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1
+-------------------------------+------------------------------+
| RESERVED | 8 |
+-------------------------------+------------------------------+
| CommandName | ReportBuffer |
+-------------------------------+------------------------------+
After the NotifyMessage AVP we can receive:
a) a list of AVPs (as described in table 3) followed by an AVP with ‘Attribute Type’ ResultCode
b) a single AVP called KillMessage with the following fixed format:
1 2 3
0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1
+-------------------------------+------------------------------+
| RESERVED | 8 |
+-------------------------------+------------------------------+
| KillCommand | KillCommand |
+-------------------------------+------------------------------+
Description
TimeStamp: the timestamp of the notification
TagIDLen: the ID length of the tag.
TagID: the ID of the tag.
SourceName: the name of the source to use.
EventType: the type of the notified event
Tab. 3.1: Attribute types: Notification AVP List.
CAEN UHF RFID Readers Communication Protocol - Technical Information Manual
23
4 DEFAULT CONFIGURATION
CAEN UHF RFID Readers Communication Protocol – Technical Information Manual
24
CAEN A928EUEU and A948EUEU UHF RFID Reader protocol has various configuration parameters; in the following table
are summarized the default values.
Parameter
Default value
IP Address
192.168.0.125
IP Netmask
255.255.255.0
IP Gateway
192.168.0.1
Sources
“Source_0”, “Source_1”, “Source_2”, “Source_3”
Readpoints
“Ant0”, “Ant1”, “Ant2”, “Ant3”
Baud Rate
115200
Data Bits
8
Stop Bits
1
Parity
None
Flow Control
None
Tab. 4.1: A928EUEU and A948EUEU Configuration parameters default values
The default composition of sources for A928EUEU and A948EUEU reader is the following:
Source
Readpoints
Source_0
Ant0
Source_1
Ant1
Source_2
Ant2
Source_3
Ant3
Tab. 4.2: A928EUEU and A948EUEU Default composition of sources
CAEN A828EU A828AEUEU, A829EUEU, A946EUEU and A949EUEU UHF RFID Reader protocol has various configuration
parameters; in the following table are summarized the default values.
Parameter
Default value
Sources
“Source_0”
Readpoints
“Ant0”
Baud Rate
115200
Data Bits
8
Stop Bits
1
Parity
None
Flow Control
None
Tab. 4.3: A828EU A828AEUEU, A829EUEU, A946EUEU and A949EUEU Configuration parameters default values
The default composition of sources for the A828EU A828AEUEU, A829EUEU, A946EUEU and A949EUEU reader is the
following:
Source
Readpoints
Source_0
Ant0
Tab. 4.4: A828EU A828AEUEU, A829EUEU, A946EUEU and A949EUEU Default composition of sources
5 EXAMPLES
CAEN UHF RFID Readers Communication Protocol – Technical Information Manual
26
Set Protocol Command
Action: Set Reader Protocol to EPC C1G2
Result: Reader select EPC C1G2 protocol.
Command sent:
0x8001 (Fixed)
0x0000 (Message ID)
0x00005358 (Vendor ID = CAEN SpA)
0x001C (Message Length)
0x0000 (Reserved)
0x0008 (AVP Length)
0x0001 (AVP Type = CommandName)
0x0074 (AVP Value = SetProtocol)
0x0000 (Reserved)
0x000A (AVP Length)
0x0054 (AVP Type = Protocol)
0x00000003 (AVP Value = EPC C1G2)
Response received:
0x0001 (Fixed)
0x0000 (Message ID)
0x00005358 (Vendor ID = CAEN SpA)
0x001A (Overall Message Length)
0x0000 (Reserved)
0x0008 (AVP Length)
0x0001 (AVP Type = CommandName)
0x0074 (AVP Value = NewRawReadIDs)
0x0000 (Reserved)
0x0008 (AVP Length)
0x0002 (AVP Type = ResultCode)
0x0000 (AVP Value = Success)
CAEN UHF RFID Readers Communication Protocol - Technical Information Manual
27
Inventory Command
Action: Execute an inventory cycle on the logical source Source0
Result: Two EPCC1G2 tags are returned as being inventory by the reader on Ant0.
Tag1 Id = 010203040506070809101112131415161718191920 (160 bit)
Tag2 Id = 300833B2DDD9014035050000 (96 bit)
Command sent:
0x8001 (Fixed)
0x0000 (Message ID)
0x00005358 (Vendor ID = CAEN SpA)
0x0021 (Message Length)
0x0000 (Reserved)
0x0008 (AVP Length)
0x0001 (AVP Type = CommandName)
0x0013 (AVP Value = NewRawReadIDs)
0x0000 (Reserved)
0x000F (AVP Length)
0x00FB (AVP Type = SourceName)
0x536F757263655F3000 (AVP Value = “Source_0”)
Response received:
0x0001 (Fixed)
0x0000 (Message ID)
0x00005358 (Vendor ID = CAEN SpA)
0x00B6 (Overall Message Length)
0x0000 (Reserved)
0x0008 (AVP Length)
0x0001 (AVP Type = CommandName)
0x0013 (AVP Value = NewRawReadIDs)
0x0000 (Reserved)
0x000F (AVP Length)
0x00FB (AVP Type = SourceName)
0x536F757263655F3000 (AVP Value = “Source_0”)
0x0000 (Reserved)
0x000B (AVP Length)
0x0022 (AVP Type = ReadPointName)
416E743000 (AVP Value = “Ant0”)
0x0000 (Reserved)
0x000E (AVP Length)
0x0010 (AVP Type = TimeStamp)
0x00000578 (AVP Value = Thu Jan 1 01:23:20 1970)
0x00000000 (AVP Value)
0x0000 (Reserved)
0x0008 (AVP Length)
0x0012 (AVP Type = TagType)
0x0003 (AVP Value = EPCC1G2)
0x0000 (Reserved)
0x0008 (AVP Length)
0x000F (AVP Type = TagIDLen)
0x0014 (AVP Value = 160 bit)
0x0000 (Reserved)
0x001A (AVP Length)
0x0011 (AVP Type = TagID)
0x010203040506070809101112131415161718191920
0x0000 (Reserved)
0x000F (AVP Length)
0x00FB (AVP Type = SourceName)
CAEN UHF RFID Readers Communication Protocol – Technical Information Manual
28
0x536F757263655F3000 (AVP Value)
0x0000 (Reserved)
0x000B (AVP Length)
0x0022 (AVP Type = ReadPointName)
0x416E743000 (AVP Value = “Ant0”)
0x0000 (Reserved)
0x000E (AVP Length)
0x0010 (AVP Type = TimeStamp)
0x00000578 (AVP Value = Thu Jan 1 01:23:20 1970)
0x00000000 (AVP Value)
0x0000 (Reserved)
0x0008 (AVP Length)
0x0012 (AVP Type = TagType)
0x0003 (AVP Value = EPCC1G2)
0x0000 (Reserved)
0x0008 (AVP Length)
0x000F (AVP Type = TagIDLen)
0x000C (AVP Value = 96 bit)
0x0000 (Reserved)
0x0012 (AVP Length)
0x0011 (AVP Type = TagID)
0x300833B2DDD9014035050000
0x0000 (Reserved)
0x0008 (AVP Length)
0x0002 (AVP Type = ResultCode)
0x0000 (AVP Value = Success)
