Users Manual
USER’S MANUAL
OTT STB V3 N9090
Power on/Standby
Information
Go to Home page
Functions depend on
specific applications
Move cursor
Up/Down/Left/Right
Pause/Resume playing
Channel switch +/-
Confirm to selection
Back to previous menu
or exit from operation
Volume adjust +/-
Display EPG
REMOTE CONTROL
Note: The keys mentioned in the manual refer to RCU keys except for special explanations.
Please operate according to key instructions on screen.
Trouble Shooting FAST INSTALLATION GUIDE
DISPLAY on front panel is off
Power adapter is disconnected. Make sure power adapter is plugged
into a proper power socket.
No sound and no picture
The receiver is in standby mode. Press key to switch it to operation
mode.
No sound
1. Audio cable is disconnected or incorrectly connected. Connect
audio cable correctly.
2. The receiver is in mute mode. Press key to restore sound.
3. Volume is set to minimum. Increase volume to a proper level.
No picture
Video cable is disconnected or incorrectly connected. Connect video
cable correctly.
RCU doesn’t work
1. No enough power in batteries. Replace the batteries.
2. RCU is not aimed at the receiver. Aim RCU at the receiver.
Program cannot be played
1. Please check and make sure the network connection is normal.
2. Please make sure the program is authorized.
Please refer to following figure and instructions to connect
Ethernet, TV and other devices
TV set and STB are connected the HDMI cable (Included).
If the TV hasn’t HDMI input you can connect the analogue
cable (3 in 1, Optional).
Connect the STB to the power adapter in accessories.
Turn on the TV
Select the correct input source (HDMI input or analogue input)
that corresponding output of the STB by TV remote control.
Turn on the STB follow the instructions to enjoy the LEBARA
video service.
Set up the connection of the STB to the modem, either through
Wi-Fi or Ethernet cable.
1
2
3
4
5
6
Note: To ensure a better service, recommending to set up the connection
through the Ethernet cable.
12
Resolution
Specifications
Input Voltage
Power adapter
Output Voltage
Output Current
Power Consumption
1080p/1080i/720p/480i/480p
100-240V~ 50/60Hz
1.5A
7.5W max
Size
Physical Characteristics
Weight
100mmX100mmX23mm
255g
Wi-Fi module
Wireless connectivity:
IEEE 802.11a/b/g/n compliant,
Operating Temperature -10°C~+40°C
Storage Temperature -40°C~+60°C
Storage Humidity ≤93%
Hereby, Shenzhen Coship Electronics Co., Ltd declares that the radio equipment type
N9090 is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
www.coship.com
Output power: <15dBm@11a, < 18dBm@11b,
< 17dBm@11g, < 17dBm@11n.
support 20MHz,40MHz bandwidth
bandwidth in 2.4GHz.
in 5GHz, and 20MHz,40MHz
5V
N9090
Read following items carefully before operating this receiver.
Good ventilation (leave space not less than 10cm around this receiver)
Installation:
No heat source
(burning candle, radiator, heater, fireplace, amplifier, etc)
Suitable temperature
Against humidity (especially bathroom, kitchen, etc )
No direct sunlight
Low vibration
Do not cover vents of this receiver with newspaper, table cloth, curtain,
etc.
Precautions:
Don’t put heavy objects on this receiver.
Do not let liquid and spray flow into this device to avoid serious damage
Power socket should be available near the receiver and well grounded.
Power Socket and Power Adapter
Do not insert or pull out power adapter with wet hands to avoid electric
shock or fire.
Do not use damaged power adapter, which must be replaced to avoid
risk of fire or electric shock.
Only use accessories specified by the manufacturer, as other
unsupported accessories may cause damage to the receiver.
Accessory
Don’t unplug or insert audio and video cables when this receiver is on.
Maintenance
Unplug this receiver from power socket before changing connections
between this unit and other related equipment.
To avoid the risk of lightning strike, unplug power adapter of the
receiver from power socket in lightning storm.
Unplug power adapter from power socket when the unit is not used for
a long time or damaged accidentally.
Turn off this unit first, after 1 to 2 hours turn it on when move this
To avoid the risk of fire or electric shock, don’t expose this receiver to
rain, splashing and don’t put object with liquid on this unit.
Unplug power adapter of this receiver from power socket before
cleaning.
Chipset: 28nm, 1.5G Cortex-A7 Quad core with Neon
Main Features
HEVC (H.265) / H.264 / MPEG-4 1080P/30p HW decoder
HD+HD simultaneous video stream HW decode
Maili450 MP4 Quad core
OpenGL ES 1.1/2.0 3D graphic accelerator capable
OpenVG1.1 vector graphics accelerator
OS: Android 4.4 KitKat
Flash: 4GB eMMC flash
Memory: 1GB DDR3
Wi-Fi: 2.4G/5G Dual band (802.11a/b/g/n,Antena 2X2)
HDMI 1.4 with HDCP 1.4, support HDMI CEC, Support 3D video format
DRM: Encrypted HLS
Batteries should be installed in accordance with the polarity markings
(+/-) on battery compartment.
RCU Battery
Replace batteries if there is no enough power and dispose battery
waste properly for environmental protection
Remove batteries if RCU is not used for a long time.
Install the receiver in a place with:
The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modifications to this equipment. Such
modificationscould void the user’s authority to operate the equipment.
RF Exposure Information and Statement
NOTE:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help
This device and its antenna(s) must not be co-located or operating
in conjunction with any other antenna or transmitter.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
This equipment complies with FCC/IC radiation exposure limits set
Radiation Exposure Statement
This device is restricted to indoor use where operated in the European
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy
However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television
receiver from a cold environment to a hot environment or vice versa.
Community using frequency in 5150MHz ~ 5350MHz to reduce the
potential for interference
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
reception, which can be determined by turning the equipment off and
more of the following measures:
on, the user is encouraged to try to correct the interference by one or
forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20cm between the
radiator & your body.
This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired
operation.
est susceptible d'en compromettre le fonctionnement.
accepter tout brouillage radioélectrique subi, même si le brouillage
pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
est autorisée aux deux conditions suivantes : (1) l'appareil ne doit
applicables aux appareils radio exempts de licence. L'exploitation
Le présent appareil est conforme aux CNR d'Industrie Canada
must accept any interference received, including interference that
(1) this device may not cause harmful interference,and (2) this device
Industry Canada. Operation is subject to the following two conditions:
may cause undesired operation.
This device complies with part 15 of the FCC rules and RSS-247of
