Cadco Systems PAP2400 Power Access Point User Manual Installation Front
Cadco Systems Inc Power Access Point Installation Front
Installation Guide
CADCO SYSTEMS
DUAL RADIO HOT SPOT
& SERVER
START GUIDEQUICK
Inventory
1.
- 5 ft. Mast Pipe
- 4 Clamps
- Bag of Bolts
- Access Point
- Ethernet
- RS232
- Power
- Server
- AC Adapter
Note: Verify that all equipment has been recieved and is of the correct type.
Installation
2.
Step 1. Make sure you have all of
the appropriate tools, wrench &
socket and screwdriver.
Step 2. Position one set of clamps
around the center satellite pole.
Partially screw in eight of the bolts.
Leave space to slide in the adjacent
pole.
Step 4. Align the Access Point so that
the top of the box is even with the top
of the satellite. Fasten the box to the
top of the pole with the small clamp and
remaining bolts.
Step 3. Slide the adjacent pole between
the clamps. Fasten the bolts. Position the
second set of clamps around both
poles and fasten the remaining bolts.
Server Setup
3.
Molex Connector
To Linkstar RCST
RS232
Ethernet
Truck
Stop
Line of Site
to the Roadway
Line of Site
to the Parking Area
4. Hot Spot & Server Positioning
This product intentionally uses RF enerergy and has been evaluated for RF exposure at a distance of 20 cm (8 inches). The antenna used
with this product must be mounted to maintain a separation distance of 20cm to all persons. Operation at a separation distance less than
20 cm (8 inches) from the radiating element to nearby persons will expose nearby persons to RF levels that exceed the FCC rules for RF
exposure and will violate FCC rules and regulations.
THIS EQUIPMENT COMPLIES WITH PART 15 OF THE FCC RULES.
ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED
BY THE MANUFACTURER COULD VOID THE USER'S AUTHORITY TO
OPERATE THE EQUIPMENT.
WARNING
CADCO
SYSTEMS
2363 Merritt Dr.
Garland, TX 75041
Phone: (972) 271-3651
Toll Free: (800) 877-2288
Fax: (972) 271-3654
