User Guide

G9 / G9 PowerSet™

4**0$1%22.-LQGE $0

CONTENTS

1. INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2. CHARGING THE SCALA RIDER G9® . . . . . . . . . . . . . . . . . . . . . . . . . 4

3. CARDO COMMUNITY™ PLATFORM AND “ONE+8” INTERCOM . . .

4. GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

4.1 MOUNTING THE SCALA RIDER G9 ON YOUR HELMET . . . . . . . . 5

4.2 GENERAL FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

4.3 STATUS LIGHTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

4.4 AUDIO SOURCES AND PRIORITIES . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4.5 VOICE COMMAND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4.6 SETTINGS CUSTOMIZATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

4.7 VOICE MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

5. INTERCOM CONFIGURATION: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

5.1 “ONE+8” INTERCOM TOGGLING MODE . . . . . . . . . . . . . . . . . . . . . . 13

5.1a CONFIGURING YOUR G9 BUDDY NAME . . . . . . . . . . . . . . . . . . 13

5.1b HEARING YOUR ASSIGNED NAME . . . . . . . . . . . . . . . . . . . . . . . 13

5.1c PAIRING WITH A “ONE+8” INTERCOM BUDDY . . . . . . . . . . . . . 13

5.1d PAIRED DEVICE INDICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

5.2 INTERCOM CONFERENCE MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

5.2a TWO-WAY INTERCOM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

5.2b THREE-WAY INTERCOM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

5.2c FOUR-WAY INTERCOM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

5.3 CLICK-TO-LINK® INTERCOM MODE. . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

6. USING THE INTERCOM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

6.1. MAKING TWO-WAY INTERCOM CALLS . . . . . . . . . . . . . . . . . . . . . . . 17

6.2 MAKING THREE-WAY INTERCOM CALLS . . . . . . . . . . . . . . . . . . . . . 18

6.3 MAKING FOUR-WAY INTERCOM CALLS . . . . . . . . . . . . . . . . . . . . . .18

6.4 USING CLICK-TO-LINK INTERCOM . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

6.5 RECEIVING INTERCOM CALLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

6.6 BUSY SIGNAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

6.7 GROUP SIGNAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

6.8 VOICE CONNECT (VOX) SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . .19

7. PAIRING AND USING A MOBILE PHONE, GPS OR

MP3 PLAYER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

7.1. MOBILE PHONE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

7.1a PAIRING A MOBILE PHONE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

7.1b MAKING AND RECEIVING PHONE CALLS . . . . . . . . . . . . . . . . .20

7.1c HOT DIAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

7.2. PAIRING A GPS DEVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

7.3 MUSIC STREAMING VIA A2DP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

7.3a PAIRING TO AN A2DP MUSIC PLAYER . . . . . . . . . . . . . . . . . . . . 21

7.3b LISTENING TO MUSIC VIA A2DP . . . . . . . . . . . . . . . . . . . . . . . .22

7.4 CABLE-CONNECTED MP3 PLAYERS . . . . . . . . . . . . . . . . . . . . . . . . . .22

7.4a CONNECTING YOUR MUSIC PLAYER VIA THE AUX . . . . . . . .22

7.4b LISTENING TO MUSIC VIA THE AUX . . . . . . . . . . . . . . . . . . . . .22

8. FM RADIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

8.1 GENERAL FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

8.2 RADIO TUNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

8.3 AUTOMATIC RADIO TUNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

8.4 RDS (ALTERNATIVE FREQUENCIES) . . . . . . . . . . . . . . . . . . . . . . . . . .23

9. TROUBLESHOOTING CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . .24

10. SUPPORT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

11. NOTICES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

IMPORTANT:

This is version 1.1 of the User Manual. Please note, that our manual is

periodically updated on the Cardo website to include the very latest

features and functions of your new scala rider G9.

Please visit www.cardosystems.com/download/manuals to check

if the manual you are holding is the most updated version and to

download the manual in your preferred language.

scala rider® G9 / G9 PowerSetscala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

1. INTRODUCTION

Thank you for choosing the scala rider G9® Bluetooth®

communication and entertainment system for motorcycle helmets.

This manual will help you set up, congure and operate the

scala rider G9.

If you have purchased the G9 PowerSet™, your retail box contains

two factory-paired scala rider G9 units.

Among others, the scala rider G9 oers the following key features:

INTERCOM OPTIONS

• Intercom Conference mode between 2, 3 or 4 riders at a range of

up to 1 mile /1.6 km*

• Click-to-Link® Intercom: For spontaneous connection with other

scala rider G9 or G4 user nearby

• “One+8” Intercom Toggling with 8 additional buddies

MULTIPLE DEVICE CONNECTIVITY

•

Bluetooth Mobile phone / GPS device

• Wireless A2DP/ MP3 connectivity for stereo music (cable option

also provided)

ENTERTAINMENT OPTIONS

• Wireless music streaming via devices supporting Bluetooth Stereo

A2DP and AVRCP proles.

• MP3 Players (non-Bluetooth) via cable

• Built-in FM Radio with 6 station presets and automatic tuning

CARDO COMMUNITY™

• Download software upgrades, enhancements and new features

• Set up your “One+8” Intercom buddies

• Create, nd and join riding tours

• Customize your G9 settings

ADVANCED TECHNOLOGY

³Voice Command and VOX technology:

• Make / Receive mobile calls by voice command

• Make / Receive intercom calls by voice command

³AGC technology (Automatic Gain Control), allowing the

automatic adjustment of volume according to ambient noise

and driving speed. You can also control the volume level

manually. AGC sensitivity levels can be customized to suit

your personal preferences.

³VOX technology and Voice Command for safe and hands-

free operation of key functions. VOX sensitivity levels can be

customized to suit your personal preferences.

³PLC software (Packet Loss Concealment) for real-time

compensation of audio losses in challenging environments.

³Advanced software updates via any PC running Windows® XP™,

Vista™ or Windows 7.

³Spoken status announcements, so that you always know to

whom or to what device you are connected.

³Volume Per Mode: Volume is set and saved at dierent levels

for each audio source.

We wish you a great scala rider G9 experience and encourage you

to write us at support@cardosystems.com with any questions,

suggestions or comments you may have.

* Under tough environmental conditions (dense forest, narrow buildings, heavy

trac), intercom range will be reduced. Once conditions improve, the range will

increase again.

scala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

CONTENTS OF RETAIL BOX

NOTE: If you purchased the scala rider G9 PowerSet, your Retail

Box will include two sets of each component listed below.

G9 Audio Kit

Interchangeable

exible boom

(Corded mic also

provided)

Sliding

Panel

Two

speakers

MP3 Jack

(back)

Noise canceling

sealed omni

microphone

scala rider G9 Unit

Channel A Button

• Connect to Rider A

• MP3 Button

Channel B Button

• Connect to Rider B

• FM Radio Button

Voice Command

Button

“One+8” Intercom

• Charging

jack

• Software

download

port

Silicone Cover

Volume Down / Rewind button

Flip-up Antenna

Mobile phone button

Volume Up / Forward button

IMPORTANT:

The scala rider G9 has been certied as waterproof and dustproof (IP67).

However, when in use, the silicon cover of the Charging Jack should

be kept tightly closed to prevent moisture from entering the unit.

Corded Microphone

Replacement Mic sponges*

Allen wrench Wall charger plug

Pre-moistened Towlettes $OFRKRO

3DG USB adapter cable

MP3 cable Velcro Pads

Carry pouch Glue plate

* The large microphone sponge is recommended for use with open helmets

2. CHARGING THE SCALA RIDER G9

Make sure that your scala rider G9 is fully charged for at least

4 hours before initial use.

1. Open the silicone cover protecting the Charging Jack.

2. Insert the USB cable into the Charging Jack.

3. Insert the other end of the USB cable into the wall charger or a

computer’s USB port.

4. While charging, the red LED turns on. When charging is

complete, the red LED will turn o.

scala rider® G9 / G9 PowerSetscala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

3. CARDO COMMUNITY ONLINE

PLATFORM AND “ONE+8” INTERCOM

The Cardo Community is one of the most remarkable and ground-

breaking features of the scala rider G9.

Visit http://community.cardosystems.com in order to get the

following features:

• “One+8” Intercom: The scala rider G9 allows Intercom toggling

with up to 8 other individual riders.

Connect your G9 and

your PC by inserting the

USB cable into the

computer’s USB port and

the other end into the

software download port

of the G9

• Download and install the latest

software upgrades

• Congure your own Buddy name

(alias) for the “One+8”

Intercom mode and

personalize the settings

of your G9 through

your PC*

• Find your friends and

add them to your “One+8” Buddy list

• Create and join tours and invite your

friends

To register, make sure to have your product serial number ready

which can be found on the white label on the back of the unit.

*System Requirements: Windows® XP™, Windows Vista™, or Windows 7

4. GETTING STARTED

4.1 MOUNTING THE SCALA RIDER G9 ON YOUR HELMET

Glue Plate

See “Using the Glue Plate”

on next page

Back Plate

See “Using the Back Plate” on

Glue the Audio Kit onto

your helmet when the

standard Back Plate method

cannot be used.

Method A Method B

The boom microphone can be used with

open, half, full face and modular helmets.

The corded microphone is for full face

helmets.

NOTE:

scala rider® G9 / G9 PowerSet scala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

➋

➌

➊

METHOD A: USING THE BACK PLATE

Push the back plate between the helmet’s

outer shell and inner padding

Adjust the clamp’s location so that the

microphone is located opposite

the center of your mouth.

Loosen both screws

Allen

Wrench

Back Plate

➊

➋

➍

$OFRKRO

3DG

METHOD B: USING THE GLUE PLATE

(This can only be done once!)

Tighten the screws

NOTE: Please read the entire section before proceeding. While we have no

reason to believe that the gluing option might negatively aect any helmet,

Cardo does not assume any responsibility to that eect, irrespective of its

nature and circumstances. The Glue Plate is oered as an option that you

may choose to use at your own risk and subject to renouncement of any

future claims.

Glue Plate Allen Wrench Pre-moistened

Towlette

Adjust the audio kit’s

location so that the

microphone is

located in front of

the center of your

mouth.

Remove the Back Plate by taking out both screws with the Allen Wrench.

scala rider® G9 / G9 PowerSetscala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

➌

➍

➎

➏ ➐

$OFRKRO

3DG

Fasten both screws tightly

Press here for

15 seconds

Peel o protective

backing sheet

Use the Alcohol Pad to

clean the exact spot

on the helmet

Allow the glue to dry

for 24 hours

$OFRKRO

3DG

PLACING THE SPEAKERS

Speaker velcro pad position

Audio Kit Velcro pads

Attach Velcro Pads to inside of Helmet

R L

Cross the long speaker wire

over the center of the helmet

to enhance FM radio reception.

Using two speakers inside the helmet may be prohibited in certain

jurisdictions. If this is the case, postion both speakers on one side

of the helmet.

For best clarity, place speakers directly opposite and close to the ears.

Helmets with deep recesses may require padding to bring the

speakers closer for ideal positioning.

scala rider® G9 / G9 PowerSet scala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

➋

➌

➊

➍

NOTE: The Corded Microphone can be used with Full face helmets

only (not Modular helmets).

Remove both screws

Remove the screw

CHANGING THE MICROPHONE TYPE

Removing

Allen wrench

Corded microphone Velcro Pad

➋

➌

➍

➊

Tighten the screw

Tighten the screws

CHANGING MICROPHONE TYPE (cont.)

Attaching

scala rider® G9 / G9 PowerSetscala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

➋➊

POSITIONING THE MICROPHONE

Boom Microphone

Corded Microphone

Velcro Pad

Adjust the Audio Kit’s location so that the

microphone is located opposite the

center of your mouth.

Attach Velcro to

inside front

of helmet

➌ ➍

➋➊

REPLACING THE CORDED MICROPHONE SPONGE

NOTE: A replacement corded microphone sponge is provided for

future use should you need it.

The wires to the microphone are delicate. Avoid touching them.

Pinch and pull

existing microphone

sponge

Remove protective

backing sheet from replacement

sponge

Carefully attach

the new sponge

to the microphone

Carefully remove

the existing sponge.

scala rider® G9 / G9 PowerSet scala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

ATTACHING AND REMOVING THE G9 FROM THE AUDIO KIT

push!

CLICK !

4.2 GENERAL FUNCTIONS

GENERAL FUNCTIONS

Power ON Press and hold the Mobile Button for 2 seconds

• Light: 3 BLUE ashes

• Sound: Ascending tone

Power OFF Press and hold the Mobile Button for 2 seconds

• Light: 3 RED ashes

• Sound: Descending tone

Volume

Adjust and set volume

of current audio source

Tap the Volume Up or Volume Down Button

Mute speakers Tap Volume Up and Volume Down buttons

simultaneously

Battery level

indicator Press and hold the Volume Up Button for 2 seconds

Light:

• BLUE = Full charge

• PURPLE = Half charge

• RED = Almost empty

4.3 STATUS LIGHTS

LED Indication Status

None scala rider G9 is OFF

1 BLUE ash every 3 seconds Standby mode

No active audio sources

2 BLUE ashes every 3

seconds

Active mode – Call in progress / music

or other audio source is ON

1 RED ash every 3 seconds Standby mode – Battery is low

2 RED ashes every 3 seconds Active mode – Battery is low

Solid RED Charging

scala rider® G9 / G9 PowerSetscala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

4.4 AUDIO SOURCES AND PRIORITIES

If two connected audio sources try to play audio simultaneously,

your scala rider G9 automatically determines which audio

source to play through the speakers based on the priority of the

connected devices.

Higher Priority 1. Mobile Phone audio or GPS instructions*

2. Intercom/”One+8”/Click-to-Link

3. A2DP (Stereo Bluetooth) audio

4. FM Radio (Built-in)

5. AUX (for corded connection i.e. Music Players)

*GPS instructions from Smartphone GPS Apps are

prioritized like A2DP audio

Lower Priority

For example:

• Incoming mobile phone calls interrupt ongoing intercom calls

• Incoming intercom calls will interrupt ongoing A2DP music

Click-to-Link, Intercom and “One+8” calls have the same priority:

Click-to-Link requests will not interrupt any type of Intercom call

in progress, and vice-versa.

4.5 VOICE COMMAND

The G9 allows you to perform certain actions by simply using your

voice. Using advanced Voice Recognition, you can control the G9

completely handsfree.

The default Voice Command language is English. Other languages

can be selected via the Cardo Community platform including

German, French, Italian and Spanish (see section 3).

Throughout this manual, features which are available via Voice

Command are marked with the

icon.

VOICE COMMAND TABLE:

1. In Standby Mode (no call in progress), tap the Voice Command

button or speak any word loudly to activate VOX

2. Speak a Voice Command from the table below:

Current Mode Desired Action Say this:

Standby / FM /

A2DP / AUX

“One+8” Intercom Call* <<G9 Buddy Name>>*

Intercom call with A or B “Call Intercom”

Standby Start A2DP “Music ON”

Turn on FM “Radio ON”

FM Turn o FM “Radio OFF”

A2DP Stop / Pause A2DP “Music OFF”

*see Section 5.1 for details

NOTE: Voice Command performance may vary based on

environmental conditions including driving speed, helmet type and

ambient noise.

For improved performance of the Voice Command feature, minimize

wind impact on the microphone by using the large microphone

sponge and closing the visor.

4.6 SETTINGS CUSTOMIZATION

Your G9 oers various customizable settings, allowing you to

personalize it according to your preferences. Among these

settings, you can:

• Enable/Disable Spoken Status Announcements, i.e.

informing you about the respective connectivity status, like

if you are in mobile phone or intercom mode, and conrm

changes of such modes. By default the feature is ON.

scala rider® G9 / G9 PowerSet scala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

• Set custom AGC and VOX sensitivity levels suited to your

specic riding style and conditions.

G9 settings can be customized in two ways:

• Via the Cardo Community platform at http://community.

cardosystems.com (requires Windows PC). See Section 3.

• Via the Voice Menu and the buttons on your G9 unit – see below.

4.7 VOICE MENU

The Voice menu is available in several languages.

1. While on standby, press and hold the Channel “A” button and

Channel “B” button simultaneously for 2 seconds while on

standby.

2. After entering the menu, follow the voice instructions in

English or choose your preferred language.

5. INTERCOM CONFIGURATION

The scala rider G9 allows Bike-to-Bike full duplex intercom

communication at a range of up to 1 mile / 1.6 km (subject to

terrain) with antenna open and within line of sight.

Open the antenna

for maximum range

Open the antenna

for maximum range

Pairing with another scala rider G9

To chat with another scala rider device via Intercom, rst pair the

scala rider G9 to the second device. Pairing is a one-time process.

Once paired, the scala rider G9 will automatically recognize the

second unit whenever it is within range.

NOTE: If you have purchased the G9 PowerSet, the retail package

contains two factory-paired units congured to communicate via

their Channel A buttons.

“

”

Intercom communication is possible using one of the three

Intercom modes:

Section

5.1

“One+8” Intercom

Toggling Mode

(scala rider G9 only)

2-way Intercom conversations

within a group of up to eight other

“One+8” Buddies

Section

5.2

Intercom Conference

Mode (all scala rider

models)*

Intercom Conferencing (2-way,

3-way and 4-way) (Channel “A”

and “B”)

Section

5.3

Click-to-Link

(scala rider G9 and G4

models)

1-on-1 spontaneous intercom

conversations with random

scala rider users near you who are

not already paired to your G9

* Intercom Conference calls available only on G4 and G9 models.

scala rider® G9 / G9 PowerSetscala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

Intercom Compatibility

Your scala rider G9 is compatible with all scala rider intercom

models for intercom calls. In addition, it is also compatible with

the Schuberth SRC-System™. Intercom range with other models is

limited to the distance of the device with the shorter range.

For instructions on how to pair and use your scala rider G9 with

other scala rider models, please visit

www.cardosystems.com/compatibility.

5.1 “ONE+8” INTERCOM TOGGLING MODE

Pair with up to 8 other G9 devices (“One+8” Buddies) and

connect with one at a time by pronouncing their name.

5.1a CONFIGURING YOUR G9 BUDDY NAME

“One+8” Intercom Toggling allows you to connect to a “One+8”

Buddy by simply saying the Buddy Name they assigned to their G9.

IMPORTANT! Before using “One+8” Intercom, you should assign

your G9 device(s) a Buddy Name, so that other “One+8” participants

can call you by this name.

If you change your G9 Buddy Name, you must Flash Pair again with

your “One+8” Buddies for their G9 to receive your new Buddy Name.

Visit the Cardo Community platform

http://community.cardosystems.com to assign your G9

device’s Buddy Name using your PC. See Section 3 for more

details.

Until you assign a Buddy Name to your G9, it will be known by

its generic “One+8” Buddy name, “scala rider”.

“One+8” Intercom Buddies will be able to connect to your G9 by

manually choosing your G9 from their “One+8” Intercom Buddy

List (see Section 6.1: Option 2: Manual Mode).

5.1b HEARING YOUR ASSIGNED NAME

To hear the name you have chosen for your G9:

1. Start with the G9 in Standby mode.

2. Simultaneously tap the Voice Command and Channel “B” buttons.

3. You will hear the Buddy name of your G9 through the speakers.

5.1c PAIRING WITH A “ONE+8” INTERCOM BUDDY

Flash-Pairing™

Use Flash-Pairing to add a new “One+8” Buddy within

seconds.

1. Remove both G9 units from their Audio Kits and check they

are in Standby Mode (slow single blue ashing).

2. Bump the two G9 units gently against each other and hold

them side by side.

CLICK !

3. If Flash-Pairing was successful, a purple light appears for

2 seconds.

NOTE: If your scala rider G9 already has a full list of 8 paired

“One+8” Intercom Buddies, pairing another buddy will replace the

buddy that you have not spoken to for the longest time.

scala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

Pairing Online – Cardo Community®

You can nd your friends and add them to your “One+8” Buddy

list via the Cardo Community website at:

http://community.cardosystems.com

5.1d PAIRED DEVICE INDICATION

Use the Paired Device indication to quickly see which G9 units

within a range of 60ft./20m are your “One+8” Intercom Buddies.

1. Press and hold the Voice Command button for 5 seconds.

2. If your G9 and another nearby G9 are paired as “One+8”

Buddies, both your Purple lights will turn on for 2 seconds.

3. If they aren’t paired as “One+8” Buddies, pair them in seconds

using Flash-Pairing (see Section 5.1c).

5.2 INTERCOM CONFERENCE MODE

Start multi-party conversations using the Channel A and B buttons

on your G9. This mode is suitable for 2, 3 or 4-way calls.

Pairing between scala rider G9s can be done either via Flash-

Pairing (see below) or by manually pairing the Channel A and B

buttons as described in the following sections.

INTERCOM CHANNELS AND PAIRING LED INDICATION

INTERCOM

CHANNEL

PAIRING / CONNECTION

BUTTON

PAIRING MODE LED

INDICATORS

Channel “A” Channel “A” BUTTON Rapid RED ashing

Channel “B” Channel “B” BUTTON Rapid BLUE ashing

5.2a TWOWAY INTERCOM

If you have purchased the G9 PowerSet, both units are factory-

paired and congured to communicate via their respective

Channel “A” Buttons. If for any reason you have to pair them again,

OR if you purchased a single scala rider G9 and wish to pair with

a second unit to make Intercom calls, proceed as follows:

METHOD 1: Flash-Pairing with Channel A and B

buttons

1. Remove two G9 units from the Audio Kits and verify they are

in Standby Mode (slow single blue ashing).

2. Tap the Channel button (“A” or “B”) on the rst G9 unit and the

purple light begins ashing.

3. Tap the Channel button (“A” or “B”) on the second G9 unit and

the purple light begins ashing.

NOTE: Selecting a Channel that is already in use will override the

existing paired device on that Channel with the newly-paired device.

4. Within 5 seconds of tapping a Channel button, bump the two

G9 units gently against each other and hold them side by side.

CLICK !

5. If Flash-Pairing was successful, a purple light appears for 2 seconds.

scala rider® G9 / G9 PowerSetscala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

 METHOD 2: Manual Pairing with Channel A / B buttons

1. Check that both G9s are ON and in Standby mode (single BLUE

ash every 3 seconds).

2. Choose a channel to pair the G9 unit (Channel “A” or “B”).

NOTE: Selecting a Channel that is already in use will override the

existing paired device on that Channel with the newly paired device.

3. Press and hold the chosen Channel Button (“A” or “B”) on the

rst G9 for at least 5 seconds until the BLUE or RED LED begins

ashing rapidly, indicating it is in Intercom Pairing mode (see

Table in section 5.2).

4. Immediately repeat Steps 2-3 for the second G9 unit. Both units

will now be in Intercom Pairing mode.

5. After a few seconds, both G9s will show a solid light for

2 seconds, indicating that they are paired, connected and

ready to use.

NOTE: If Pairing is not completed within two minutes, the G9 will

return to Standby mode.

5.2b THREEWAY INTERCOM

If you purchased the scala rider G9 PowerSet, both units are

factory-paired and congured to communicate via their respective

Channel “A” Buttons. To pair a third scala rider G9 use Channel “B”.

To set up three-way intercom conference mode proceed as

follows:

Use Channel “B”

Use Channel “A”

Rider 2 Rider 3

Rider 1

Rider “1” is paired to Rider “2” and also to Rider “3”.

PAIRING THREE SCALA RIDER G9 UNITS

1. Rider 1 pairs their device to Rider 2 using Channel “A” as

described in section 5.2a.

2. Rider 1 pairs their device to Rider 3 using Channel “B” as

described in section 5.2a.

The Three-Way Conference Intercom Pairing is now complete

and ready to use.

IMPORTANT: Three-Way Conference Mode Considerations

During a 3-Way Intercom Conference call with 2 other participants,

Rider 1 will not be able to receive mobile phone calls or GPS

navigation instructions as long as the call is in progress.

scala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

5.2c FOURWAY INTERCOM

To set up four-way intercom conference mode proceed as

follows:

In this conguration the two passengers (numbered 2 and 4) are

each using two Bluetooth connections:

Passenger 2 is paired to Rider 1 and to Passenger 4

Passenger 4 is paired to Rider 3 and to Passenger 2

PAIRING FOUR SCALA RIDER G9 UNITS

1. Pair Rider 1 to Passenger 2 using Channel “A” (see section 5.2a).

2. Pair Rider 3 to Passenger 4 using Channel “A” (see section 5.2a).

3. Pair Passenger 2 to Passenger 4 using Channel “B” (see

section 5.2a).

The Four-Way Pairing is complete and ready to use.

IMPORTANT: Four-Way Conference Mode Considerations

During a 4-Way Intercom call, the two passengers who maintain two

active connections simultaneously will not be able to receive mobile

phone calls or GPS instructions as long as the conference call is in

progress.

5.3 CLICKTOLINK INTERCOM MODE

Click-to-Link is a spontaneous, “social” feature of your G9.

Use Click-to-Link to instantly initiate 1-on-1 intercom calls

with other scala rider users near you, without those users

already being paired to you. Think of it as a private Bike-to-Bike

channel that you can set up on-the-go with other scala rider G9 or

G4 users that you see along the way.

The Click-to-Link feature can be disabled on your G9 eectively blocking

any attempt by a third party to send a Click-to-Link request to you.

ENABLE/DISABLE CLICKTOLINK

The feature can be turned on or o via the Voice Menu (see

Section 4.7)

NOTE: By default, Click-to-Link is DISABLED.

scala rider® G9 / G9 PowerSetscala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

6. USING THE INTERCOM

6.1 MAKING 2WAY INTERCOM CALLS

There are two ways to start an intercom call with devices that are

paired to your scala rider G9.

OPTION 1: Voice Connect (VOX) Intercom Call

Use this for either “One+8” Intercom or 2-way Intercom

Calls (Channel “A” or “B”)

1. Speak any word loudly into the microphone to open the

Intercom channel.

2. When you hear the Voice Command tone, say:

• the name of a ”One+8” Intercom Buddy i.e. “John Smith”

• or say “Call Intercom” to start an intercom call with Rider A

and / or Rider B (subject to who is present)

NOTE: VOX Intercom call with only Rider A or Rider B will end

automatically after 30 seconds of silence.

OPTION 2: Manual Mode

Channel A button

Connect to Rider A

Voice Command button

“One+8“ Intercom

Channel B button

Connect to Rider B

Use this to start an Intercom call with either:

• ”RIDER A” – tap Channel A button

• ”RIDER B” – tap Channel B button

• “One+8” Intercom Buddy – See table below

To end a call tap the respective button again.

“One+8” Intercom

SAY THE NAME:

CHOOSE THE NAME (from your Buddy List):

a. Tap the Voice

Command

button

b. Speak the

name of

the “One+8”

Intercom

Buddy

a. Press and hold the Voice Command button

for 2 seconds

b. The G9 plays the names of all pre-paired

“One+8” Intercom buddies.

c. Once you hear the name of the Buddy

you wish to call, tap the Voice Command

button or speak any word loudly into the

microphone.

To cancel “One+8” Buddy List playback:

Press and hold the Voice Command button for

2 seconds.

NOTE: Voice Command performance may vary based on

environmental conditions including driving speed, helmet type

and ambient noise.

For improved performance of the Voice Command feature,

minimize the wind impact on the microphone by using the large

microphone sponge and closing the visor.

scala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

6.2 MAKING 3WAY INTERCOM CALLS

To start an Intercom Conference Call with Channel “A” and “B”:

OPTION 1: Voice Connect VOX

1. Speak any word loudly into the microphone to open the

Intercom channel.

2. When you hear the Voice Command tone, say: “Call Intercom”

to make an intercom call with Rider A and Rider B.

 OPTION 2: Manual Mode

1. Add Channel “A”: Tap the Channel “A” Button

2. Add Channel “B”: Tap the Channel “B” Button

If you are already in an Intercom Call with Rider A or B, you can add

another rider (A or B) by tapping the respective button, or another

rider can join the intercom call in the same way.

To end Intercom Call press the respective Channel “A” or “B” Button.

NOTE: 3 and 4-way intercom calls can only be made using Channel

“A” and Channel “B”.

6.3 MAKING 4WAY INTERCOM CALLS

Once you have successfully paired the four G9s as described in

5.2c. proceed as follows:

1. Make sure all four G9s are in Standby mode.

2. Passenger 2 should tap Button “B” to initiate an Intercom call

with Passenger 4. Wait until audio is heard on both G9s.

3. Rider 1 should tap Button “A” to initiate an Intercom call with

Passenger 2.

4. Rider 3 should tap Button “A” to initiate an Intercom call with

Passenger 4.

Now the 4-way Intercom conference mode is established.

6.4 USING CLICKTOLINK INTERCOM

If you want to… Perform this action:

Make

Click-to-Link

calls

Start a Click-to-Link call

request

(search lasts up to 10

seconds)

Double tap the Channel“A”

Button

End a Click-to-Link call /

Cancel a Click-to-Link call

request

Tap the Channel “A” Button

Receive

Click-to-Link

calls

Accept a Click-to-Link call When hearing the

Click-to-Link ringtone:

Tap the Channel “A” Button

or Speak any word loudly

to answer by VOX

Reject a Click-to-Link call While hearing the

Click-to-Link ringtone:

Remain silent until the ring

tone stops

If other scala rider users are nearby, your next Click-to-Link call

may randomly connect to any of them.

scala rider® G9 / G9 PowerSetscala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

6.5 RECEIVING INTERCOM CALLS

• If another paired scala rider G9 tries calling you via Intercom,

the call will begin almost instantly.

• If you receive a “One+8” intercom call from someone who is not

in your Buddy list, you will hear a ringtone.

Tap the Channel “A” button to accept the Intercom call, or

remain silent until the ringtone stops to reject the call.

6.6 BUSY SIGNAL

When attempting to establish an Intercom call with another device

that is already busy, a busy signal will be heard. The G9 is busy

while on a phone call, intercom call with Channels “A” and “B”,

“One+8” intercom call or Click-to-Link call.

6.7 GROUP SIGNAL

Send an instant message to all paired G9s within a range of

up to 350 m / 1,150 ft. The recipients will hear a “Signal!”

voice announcement. To reach a maximum number of riders, the

message is automatically forwarded to all paired G9s within the

recipient’s range. In this manner the total range is extended to up

to 1 km / 3,280 ft.

Activating the Group Signal: Double tap the Voice Command

button to send a Group Signal at any time.

NOTE: The transfer of wireless signals is subject to multiple external

factors. Therefore, users may use but should not rely on the Group

Signal for emergency purposes.

6.8 VOICE CONNECT VOX SETTINGS

The G9 oers VOX technology for safe and hands-free

operation of some key functions.

The VOX feature can be customized to adjust its sensitivity level.

VOX activation for Intercom calls can also be disabled completely.

You can choose between ‘Regular’ (default), ‘Low’ and ‘High’ VOX

sensitivity. If you experience diculties starting a conversation

using VOX, change the setting to ‘High’ via the Cardo Community

website or directly on your G9 via the Voice Menu (see Section 4.6).

ENABLE/DISABLE VOX

Press and hold Volume Up and Down buttons simultaneously for

2 seconds.

Feedback:

• Enable: Blue ash for 2 seconds

• Disable: Red ash for 2 seconds

For incoming calls, just pronounce loudly any word (e.g. “hello”).

To reject an incoming call, remain silent for about 15 seconds.

scala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

7. PAIRING AND USING A MOBILE PHONE,

GPS OR MP3 PLAYER

To connect your scala rider G9 to a Bluetooth device you must

rst pair them. Pairing is a one-time process. Once paired, the

Bluetooth device and the scala rider G9 will automatically

recognize each other whenever they are within range (10m / 33ft).

Your scala rider G9 oers Multiple Device Connectivity (“MDC”) :

³ Intercom with up to 10 other scala rider G9 units (Rider A,

Rider B, and “One+8” Buddies)

³ Bluetooth Mobile Phone / GPS device

³ Bluetooth A2DP Music Player

7.1 MOBILE PHONE

• Make and receive calls

• Listen to Music via A2DP (with compatible phones)

7.1a PAIRING A MOBILE PHONE

If using both a Bluetooth GPS and Mobile Phone, pair the mobile

phone to the GPS device. See Section 7.2

1. Turn on your mobile phone and make sure the Bluetooth

function is activated.

2. Verify that the scala rider G9 is turned ON and in Standby

mode. (single BLUE ash every 3 seconds).

3. Press and hold the Mobile Button for at least 6 seconds. The

G9 will rst ash RED. Continue to hold the button until the

RED and BLUE lights begin rapidly alternating.

4. Search for Bluetooth devices on your phone by following the

phone’s instructions. Consult your phone’s User Manual for

more information.

5. After a few seconds the phone will list “scala rider G9” as a

discovered device. Select “scala rider G9” from the list.

6. If prompted for a PIN or Passkey, enter 0000 (four zeros).

7. The phone will conrm that pairing has succeeded and the

scala rider G9 will begin ashing slowly in BLUE.

NOTES:

• If Pairing is not completed within 2 minutes, the scala rider G9 will

return to Standby mode.

• Not all Bluetooth mobile phones can broadcast Bluetooth Stereo

music (A2DP), even if the phone has an MP3 player function. Consult

your mobile phone’s User Manual for more information.

• After pairing, you may need to tap the Mobile Button to connect the

scala rider G9 to the phone.

7.1b MAKING AND RECEIVING PHONE CALLS

BASIC FUNCTIONS

Answer a call Tap the Mobile Button or speak any word

loudly to answer by VOX

Reject a call Remain silent for 15 seconds, or press and

hold the Mobile Button for 2 seconds

End a call Tap the Mobile Button

Voice Dial* (if supported

by mobile phone)

Tap the Mobile Button and follow the

prompt from the mobile

Redial* Tap the Mobile Button twice

INTERCOM CONFERENCE MODE

Add/Remove Channel

“A” to/from a call

Tap the Channel “A” button while on a

phone call

Add/Remove Channel

“B” to/from a call

Tap the Channel “B” button while on a

phone call

*This feature is not available during intercom or mobile calls

scala rider® G9 / G9 PowerSetscala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

7.1c HOT DIAL

Call a pre-programmed phone number automatically at the push

of a button.

1. Congure your G9’s Hot Dial number via the Cardo Community

at http://community.cardosystems.com. See Section 3 for

more details.

2. To call your Hot Dial number, tap the Channel “A” and Channel

“B” buttons simultaneously.

7.2 PAIRING A GPS DEVICE

• Receive GPS navigation instructions

NOTES:

• Not all Bluetooth GPS devices allow connections to Bluetooth

audio devices. Please consult your GPS User Manual for more

information.

• If Pairing is not completed within 2 minutes, the scala rider G9 will

return to Standby mode.

1. Turn on your GPS.

2. Verify that your G9 is turned ON and in Standby mode (single

BLUE ash every 3 seconds).

3. Press and hold the Volume Up Button for at least 5 seconds,

until the PURPLE light begins ashing rapidly.

4. Search for Bluetooth device on the GPS device by following the

instructions in the GPS User Manual.

5. Once your GPS lists the scala rider G9 as a discovered device,

select it.

6. If prompted for a PIN or Passkey, enter 0000 (four zeros).

7. Your GPS will conrm that pairing has succeeded and the

scala rider G9 will begin ashing slowly in BLUE.

IMPORTANT: If you wish to use a mobile phone and GPS device with

the scala rider G9, pair the mobile phone directly to the GPS device.

7.3 MUSIC STREAMING VIA A2DP

7.3a PAIRING TO AN A2DP MUSIC PLAYER

• Listen to Stereo Music via A2DP (non-mobile phone

device)

NOTE: The scala rider G9 can also receive audio via the enclosed

cable from non-Bluetooth MP3 Players or audio sources as

described in section 7.4.

1. Turn on the Music Player and make sure that Bluetooth

function is activated.

2. Verify that the scala rider G9 is turned ON and in Standby

mode (single BLUE ash every 3 seconds).

3. Press and hold the Mobile Button for at least 6 seconds. The G9

will rst ash RED. Continue to hold the button until the RED

and BLUE lights begin rapidly alternating.

4. Search for Bluetooth device on the Music Player by following

the device’s instructions.

5. Once your Music Player lists the “scala rider G9” as a

discovered device, select it.

6. If prompted for a PIN or Passkey, enter 0000 (four zeros).

7. The Music Player may conrm that pairing has succeeded, and

the scala rider G9 will begin ashing slowly in BLUE.

scala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

NOTE: If Pairing is not completed within two minutes, the

scala rider G9 will return to Standby mode.

7.3b LISTENING TO MUSIC VIA A2DP

BASIC FUNCTIONS Available only on AVRCP compatible Bluetooth

audio sources

Play Press and hold the MP3 Button for 2 seconds

Pause/Stop Press and hold the MP3 Button for 2 seconds

Forward Press and hold the Volume Up Button for 2 seconds

Rewind* Press and hold the Volume Down Button for 2 seconds

*With some phones you may need to repeat this action

SWITCHING BETWEEN A2DP AUDIO SOURCES

If a Music Player is paired, the scala rider G9 will use it as the

default A2DP audio source.

1. Stop the music playback from the current device.

2. Start music playback from the other device.

7.4 CABLECONNECTED MP3 PLAYERS

7.4a CONNECTING YOUR MUSIC PLAYER VIA THE AUX

The AUX Line-in Port is used to connect a non-Bluetooth audio

source with a 3.5 mm–⁄” stereo jack using the enclosed cable.

AUX Line-in Port

1. Verify that the scala rider G9 is turned ON and in Standby

mode (single BLUE ash every 3 seconds).

2. Connect the MP3 cable to the Music Player’s jack and insert

the other end of the cable into the AUX Line-in Port.

7.4b LISTENING TO MUSIC VIA THE AUX

To listen to music from a cable-connected device, operate the

Music Player using its buttons as usual (FF/REW/ PLAY/PAUSE).

8. FM RADIO

Your scala rider G9 includes a built-in FM radio with a 6

Preset memory and RDS (Radio Data System).

8.1 GENERAL FUNCTIONS

Turn on Radio Press and hold the Channel “B” button for 2 seconds

Turn o Radio Press and hold the Channel “B” button for 2 seconds

Preset stations can be saved via the Cardo Community platform

online conguration tool or directly from your G9 device.

1. Turn on the Radio.

scala rider® G9 / G9 PowerSetscala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

2. Select a Preset number you wish to set (Preset 1 – 6) by

tapping the Channel “B” button until the desired Preset is

heard.

3. Find an FM station to save using Seek or Scan (see 8.2 RADIO

TUNING).

8.2 RADIO TUNING

Seek and Save: (Find the next FM station)

1. Press and hold the Volume Up or Volume Down Button for

2 seconds.

• Pressing Volume Up searches upwards (higher frequency) for

a station

• Pressing Volume Down searches downwards (lower

frequency) for a station

2. Tap the Channel “B” button within 20 seconds of nding the

FM station to save it as the current Preset.

Scan and Save: Scan through FM stations

1. Press and hold the Volume Up button for 5 seconds. The G9

will search upwards (higher frequency) for a station. When a

station is found, it can be heard for a few seconds.

2. To stop the scan on this station: Tap the Volume Up Button.

3. Tap the Channel “B” button within 20 seconds of nding the

FM station to save it as the current Preset.

4. To continue scan: Wait for the next station to be found.

NOTE: During Scan, tap the Channel “B” button to Fast Save the

current FM station as the current Preset

8.3 AUTOMATIC RADIO TUNING

This feature makes nding new stations fast and easy by automatically

creating a temporary list of 6 “on-the-go” radio stations.

1. Turn on the Radio.

2. Press and hold the Volume Down button for 5 seconds.

3. Your G9 will search upwards (higher frequency) from the

current station and store the next 6 FM stations it discovers as

“on the go” stations.

4. If desired, repeat from Step 2 to store the next 6 FM stations as

“on the go” stations.

NOTE: These 6 temporary “on the go” stations cannot be saved

and do not replace the FM Presets you may have saved.

Turning o your G9 will clear the Automatic Radio Tuning stations

and restore the FM Presets.

8.4 RDS ALTERNATIVE FREQUENCIES

This feature allows your G9 to automatically re-tune to the

strongest frequency available for the FM station you are listening

to when the rst signal becomes too weak.

Toggle RDS On/O

(Default: O)

1. Turn on Radio.

2. Press and hold Volume Up and Volume Down buttons

simultaneously for 2 seconds.

scala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

9. TROUBLESHOOTING CONNECTIONS

RESET PAIRING

To delete your paired devices (not including “One+8” pairings):

1. Verify that your G9 is turned ON and in Standby mode (single

BLUE ash every 3 seconds).

2. Press and hold the Mobile Button for at least 6 seconds. The G9

will rst ash RED. Continue to hold the button until the RED

and BLUE lights begin rapidly alternating.

3. Press and hold the Volume Up Button for 2 seconds.

4. The PURPLE light will ash 5 times and then the

scala rider G9 will turn OFF, indicating that the Reset was

successfully completed.

10. SUPPORT

For additional information please visit our website at

www.cardosystems.com

FAQ: www.cardosystems.com/support/faq

or contact us at: support@cardosystems.com

Phone: USA and Canada: 1-800-488-0363

International: +49 89 450 36819

IMPORTANT

MULTINATIONAL ELECTRONIC COMMERCE COMPANIES AND ONLINE AUCTION WEBSITES ARE NOT

AUTHORIZED TO SELL CARDO PRODUCTS AND PURCHASES FROM SUCH SITES ARE AT YOUR OWN

RISK. TO RECEIVE WARRANTY OR CUSTOMER SERVICE, YOU MUST SUBMIT ORIGINAL RECEIPTS

FROM AUTHORIZED CARDO DEALERS.

PRODUCTS THAT WERE IMPORTED FROM NORTH AMERICA MUST ALSO BE SERVICED IN THE USA.

11. NOTICES

Federal Communications Commission (FCC) Statement

15.21

You are cautioned that changes or modications not expressly approved by the part responsible

for compliance could void the user’s authority to operate the equipment.

15.105(b)

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment

o and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

Operation is subject to the following two conditions:

1) this device may not cause interference and

2) this device must accept any interference, including interference that may cause undesired

operation of the device.

FCC RF Radiation Exposure Statement:

This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment.

End users must follow the specic operating instructions for satisfying RF exposure compliance. The

antenna used for this transmitter must not transmit simultaneously with any other antenna or

transmitter, except in accordance with FCC/IC multi-transmitter product procedures.

scala rider® G9 / G9 PowerSetscala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

Industry Canada (IC)

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to

the following two conditions:

1) this device may not cause interference and

2) this device must accept any interference, including interference that may cause undesired

operation of the device.

IC RF Radiation Exposure Statement:

This equipment complies with the RSS-102 exemption from routine RF exposure evaluation for use

in an uncontrolled environment.

European CE Notice

Your Cardo product (the “Product”) is in conformity with the following essential requirements

of Council Directive 1999/5/EC (referred to as R&TTE Directive): Articles 3.1a, 3.1.b and 3.2. The

Product is manufactured in accordance with Annex II of the above directive.

Declaration of Conformity (DOC)

The Product is compliant with and adopts the Bluetooth® Specication 2.1 and has successfully

passed all interoperability tests that are specied in the Bluetooth® specication. However,

interoperability between the device and other Bluetooth®-enabled products is not guaranteed.

The contents of this User Guide, including all text, illustrations and drawings are the exclusive

intellectual property of Cardo Systems, Inc. (the “Company”) and are protected by copyright

laws. They are not in the public domain. Any partial or total reproduction, translation and or

dissemination, without the prior written authorization by the Company are strictly prohibited.

Any rights not expressly granted herein are reserved.

IMPORTANT SAFETY AND WARRANTY INFORMATION –

WAIVER AND GENERAL RELEASE

WARNING:

Cardo Systems Inc., (“Cardo” or the “Company”) noties you that your complete and undivided

attention is required when using a communication device (the “Product”) while riding. Failure to

avoid potentially hazardous situations could result in accident resulting in serious injury or death.

Cardo advises you to take all necessary precautions and remain alert to the trac, weather and all

road conditions. It is best to stop away from trac prior to activating or deactivating the Product

or initiating or receiving any calls.

Do not perform pairing, linking or similar operations while riding. All publications are intended to

address technical capabilities and should not be construed as encouraging the operation of Cardo’s

Products in any manner that is unsafe or prohibited by law.

Exercise all due caution while using this Product and obey all applicable trac laws. Always ride

and use the Product in a safe manner. Do not become distracted by the Product while riding on a

vehicle. When riding, always consider road, trac, terrain and other conditions to maximize safety.

Do not operate the Product if it becomes unsafe to do so.

In some regions or states, the use of mobile communications systems is prohibited or restricted.

Check all laws and regulations that apply to your region before using the Product and be

mindful that compliance with all laws and regulations is the user’s responsibility. Use the

Product in motion only where and in the manner that such devices are permitted by applicable

law. The Product should not be used in contravention of local, state or federal laws and

regulations. Please check federal, state and local laws and regulations before using your Cardo

Product.

No part of the body should come in contact with the antenna during operation of the equipment.

Use Product only where safe, and avoid usage at gas stations, fuel depots or around explosives. Use

with hearing aids and medical devices only after consulting a physician or specialist. Make sure to

install and mount the Product in a stable manner.

HEALTH WARNINGS:

Hearing Loss

Audio devices can cause hearing loss. Employ care and avoid exposure to excessive volume

levels that may damage or impair hearing or lead to hearing loss. Permanent hearing loss

may occur if Products are used at high volume for prolonged periods of time.

RF Signals

Most electronic equipment is shielded from RF signals. However, certain electronic

equipment may not be shielded against the RF signals emanating from your wireless

equipment.

Pacemakers

The Health Industry Manufacturers Association recommends that a minimum separation of about

six inches (or 16 cm) to be maintained between a mobile phone or wireless device and a pacemaker

to avoid potential interference with the pacemaker. Be sure not to interfere with the functionality

of personal medical devices.

scala rider® G9 / G9 PowerSet scala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

Hearing Aids

Some devices may interfere with certain hearing aids. In the event of such interference, you should

consult your hearing aid manufacturer to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device and/ or your

physician to determine if it is adequately shielded from interference caused by external RF energy.

Your physician may be able to assist you in obtaining this information.

LIMITED WARRANTY

Subject to the applicable laws and regulations in your jurisdiction, your Product is covered by a

Two-Year Limited product warranty from the date of original purchase. Please retain the retail

sales receipt and your registration data for proof of purchase.

Subject to the aforementioned, Cardo hereby represents that this Product is warranted to be

free from defects in materials or workmanship (proof of purchase and registration required).

Within the subject period, Cardo will, at its sole option, repair or replace any components that

fail in normal use. Such repairs or replacements will be made at no charge to the customer

for parts or labor, provided that the customer shall be responsible for any shipping cost. This

warranty does not cover failures due to abuse, misuse, accident or unauthorized alteration or

repairs.

This Product is intended to be used only as a communication and entertainment device and should

not be used in any location or jurisdiction where its use is prohibited.

The warranties and remedies contained herein are exclusive and in lieu of all other

warranties express, implied or statutory, including any liability arising under any warranty of

merchantibility or tness for a particular purpose, statutory or otherwise that Cardo specically

disclaims. This warranty gives you specic legal rights which may vary from state to state or

from jurisdiction to jurisdiction. Cardo makes no other warranties express or implied beyond

those stated specically herein. This warranty is extended by Cardo solely to the original

purchaser and is not assignable or transferable to others. Cardo assumes no obligation or

liability for additions or modications to this warranty unless made in writing and signed by an

ocer of the company.

Batteries are warranted only if the battery capacity falls below 50% of rated capacity or if the

battery develops leakage.

IMPORTANT: Do not store your Product without charging it from time to time for periods in

excess of six months, as this may cause irreversible damage to the capacity of your

battery. Your warranty will not cover such events.

This warranty also becomes void if:

a. any of the seals on the case or battery are broken or Product or battery show signs of tampering,

b. the battery is used in equipment other than the equipment for which it was intended.

c. the Product is used in contravention of its intended purpose

d. the Product was purchased from online auctions

Cardo assumes no responsibility resulting from the use of non-Cardo components or products in

conjunction with its Products, and specically the use of third party chargers or Bluetooth® devices.

Furthermore, Cardo is not responsible for any damage to any part of the Product resulting from the

use of ancillary equipment not furnished by Cardo which is attached to or used in connection with

the Product.

Not covered by the warranty:

1. Defects or damage resulting from the use of this Product in other than its normal and customary

manner.

2. Defects or damage from misuse, accident or neglect.

3. Defects caused by improper operation, maintenance, installation, adjustment or modication of

any kind (incl. long-term storage without periodic charging of the battery).

4. Products opened, disassembled or repaired by non-authorized parties.

5. Defects or damage due to exposure to excessive temperatures, adverse weather conditions,

external impacts or spills of food or liquid.

6. All plastic surfaces and all other externally exposed parts that are scratched or damaged after

purchase.

Disclaimer of Warranty

Cardo disclaims all express and implied warranties with regard to the enclosed device,

including without limitation any implied warranties of merchantability, tness for a particular

purpose, and non-infringement. The device and its accessories are provided “as is” and “as

available” without warranty of any kind beyond those assumed in the enclosed manual.

LIMITATION OF LIABILITY

In no event shall Cardo be liable for any incidental, special, indirect, punitive, exemplary or

consequential damages, whether resulting from the use, misuse, or inability to use this product

or from defects in the product, or for any damages whatsoever resulting from the use of the

product, whether based on breach of contract, tort (including negligence), product liability

or otherwise even if advised of the possibility of such damages. You acknowledge and agree

that the limitations set forth above are fundamental elements of this agreement to which you

consent and without which the product would not be provided to you absent such limitations.

Some states do not allow certain exclusions of incidental or consequential damages, so the

above limitations may not apply to you.

scala rider® G9 / G9 PowerSetscala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

Cardo retains the exclusive right to repair or replace (with a new or newly-refurbished replacement

Product) the device or software or give a refund of the purchase price at its sole discretion. SUCH REMEDY

SHALL BE YOUR SOLE AND EXCLUSIVE REMEDY FOR ANY BREACH OF WARRANTY.

Warranty Service

To obtain warranty service, your Product must be registered. Register online at:

www.cardosystems.com/registration. Please present the Product, along with your registration

number, bill of sale (receipt) at any authorized Service Center or at the store from which you have

purchased the Product.

To obtain warranty service, contact Cardo’s product support and obtain an RMA tracking number,

or contact your local Cardo authorized dealer. Ship securely with a copy of the original sales receipt

which is required as proof of purchase for warranty repairs. The RMA tracking number should be

written on the outside of the package. Send the Product freight charges prepaid, to the Cardo

address as directed by Cardo.

Online Auction Purchases: Online auction conrmations are not accepted for warranty verication.

To obtain warranty service, an original or copy of the sales receipt from the original retailer is

required. Cardo will not replace missing components from online auction sites.

Other manufacturers: Cardo is not responsible for and expressly disclaims any responsibility for

how Cardo Products are used or misused arising out of use with products, services or information

of other vendors.

WAIVER AND GENERAL RELEASE

By using the Product, you will waive substantial legal rights including the right to sue. Please read

the following carefully before using the Product.

By using the Product, you are irrevocably releasing, indemnifying from any liability, loss, claim

and expense (including attorneys fees) and holding Cardo harmless for any bodily injuries, harm or

death as well as losses or damages in goods, to any vehicles including your own, or to any property

or asset that belong to you or to third parties, any of which may result from using the Product

under any circumstances or conditions and irrespective of jurisdiction.

1. You, your heirs, legal representatives, successors or assigns, hereby voluntarily and forever release,

discharge, indemnify and hold harmless Cardo from any and all litigation, claims, debts, demands,

actions and liability which may arise, directly or indirectly, from using the Product for any distress,

pain, suering, discomfort, loss, injury, death, damages to or in respect to any person or property

however caused, WHETHER ARISING FROM THE NEGLIGENCE OR OTHERWISE, and which may hereafter

accrue to you on some future date as a result of said use, to the fullest extent permitted by law.

2. You fully understand and assume the risks in using the Product, including risk of negligent acts or

omissions by others. All risks for operating the Product are assumed solely by the user of the Product.

3. You conrm that you are physically capable to use the Product and that you have no medical

conditions or needs that may infringe upon your abilities to do so in a safe manner. You further

conrm that you will not consume any alcohol that may aect your alertness or any mind-altering

substance, and will not carry, use or consume these substances before or during the use of the Product.

4. You fully acknowledge our warnings and understand that:

(a) risks exist in using the Product while in trac, including but not limited to injury or illness,

strains, fractures, partial and/or total paralysis, death or other ailments that could cause

serious disability;

(b) these risks may be caused by the negligence of the manufacturers or its agents or any third

party involved in the Product;

You hereby assume all risks and dangers and all responsibility for any losses and/or damages, whether

caused in whole or in part by the negligence or other conduct of others, including Cardo.

5. By using the Product, you conrm that you have read this release of liability and fully

understand and accept its terms and conditions.

www.cardosystems.com

scala rider® G9 / G9 PowerSet scala rider® G9 / G9 PowerSet

4**0$1%22.-LQGE $0

Cardo Systems ER14 Bluetooth headset User Manual QG G9 EN

Cardo Systems, Inc. Bluetooth headset QG G9 EN

manual

Navigation menu

Namespaces

Views

Navigation
