Antenna Kitting Info
SureCall Force-5 Packages
Force-5 - Antenna Kitting Information
Table 1. Force-5
Component
Product
Number
(Description)
Gain/Loss
Notes
LTE-A
LTE-V
800
MHz
1900
MHz
1700 MHz\
2100 MHz
Outdoor
Antennas*
CM288W 3 dBi 3 dBi 3 dBi 4 dBi 4 dBi\4 dBi
CM288W-L 5 dBi 5 dBi 6 dBi 8 dBi 8 dBi\8 dBi
CM230W 10 dBi 10 dBi 10 dBi 10 dBi 10 dBi\10 dBi
CM248W 7 dBi 7 dBi 7 dBi 10 dBi 10 dBi\10 dBi
Outdoor
Cable*
CM400-
65NN
(65 feet)
3.74 dB 3.74 dB 3.89 dB 5.43 dB 5.11 dB\5.75 dB 65 feet or
longer
Indoor
Antennas*
CM248W 7 dBi 7 dBi 7 dBi 10 dBi 10 dBi\10 dBi
CM222W 3 dBi 3 dBi 3 dBi 6 dBi 6 dBi\6 dBi
Indoor Cable* CM400-
40NN
(40 feet)
2.53dB 2.53dB 2.63dB 3.57dB 3.36 dB\3.77 dB 40 feet or
longer
* All equivalent antennas and cables are suitable for use with the Force-5 booster.
Table 2. Dual Indoor Antenna Kit
Component
Product Number (Description)
Quantity
Notes
Outdoor Antennas* CM230W 1 pcs
CM248W
1 pcs
Outdoor Cable* CM400-65NN (65 feet) 1 pcs 65 feet or longer
Indoor Cable* CM400-20NN (20 feet) 1 pcs 20 feet or longer
Splitter CM-WS-2 1 pcs
Cable After Splitting* CM400-40NN (40 feet) 2 pcs 40 feet or longer
Indoor Antenna* CM248W 2 pcs
* All equivalent antennas and cables are suitable for use with the Force-5 booster.
Table 3. Four Indoor Antenna Kit
Component
Product Number ( Description)
Quantity
Notes
Outdoor Antennas*
CM230W
1 pcs
CM248W 1 pcs
Outdoor Cable*
CM400-65NN (65 feet)
1 pcs
65 feet or longer
Indoor Cable* CM400-20NN (20 feet) 1 pcs 20 feet or longer
Splitter
CM-WS-4
1 pcs
Cable After Splitting CM400-40NN (40 feet) 4 pcs 40 feet or longer
Indoor Antenna* CM248W 4 pcs
* All equivalent antennas and cables are suitable for use with the Force-5 booster.
