Chungear Co CE10307 Ceiling fan remote Controller (Transmitter) User Manual
Chungear Industrial Co Ltd Ceiling fan remote Controller (Transmitter)
User Manual
DC POWER CEILING FAN REMOTE CONTROL MANUAL
LEARNING PROCESS
NOTE:This unit is to be used for the control of DC power ceiling fan and in an AC110/120V 60Hz power
supply only.
Step: 1 Open the remote battery cover and
install
CR2032*2pcs Lithium batteries.
Step: 2. Within 30 seconds of turning the Receivers
AC
power ON. use a ball pen to press and hold the Set key
about
5 seconds.Once the receiver has detected the frequency,
the
receiver will make sound, Bi Bi, twice. This will indicate
the
receiver has learned the frequency that was
previously
selected on the transmitter.
Note: After the AC power is on, do not press any other button on the transmitter before setting learning. Doing so will
cause the procedure to fail.
After completing the steps above, you should be able to operate the ceiling fan and light. If the fan is not responding
to the transmitter, please turn the power off to the receiver. And repeat step 2.
LIGHT FUNCTION SELECT SWITCH
If installed energy light onto ceiling fan, please slide the
dip
switch
,light
function
select switch, to “O” position. If installed tungsten light onto ceiling fan,
please
slide the “light function select switch” to “D” position.
FUCNCTIONS OF WALL REMOTE CONTROL
LED for show fan or light’s function setting
FAN key : press and turn fan off
: fan speed control key
press the key or key each time for change fan speed
light control key:
ON/OFF- Press and release immediately to turn on or off dwon light.
DIMMER-Press or and hold to dim or brighten light to the desired level
and
release.
(Tungsten only and light function select switch on dimmer position.)
1hr：Setting up that the ceiling fan will turn off after 1 hour automatically
3hr：Setting up that the ceiling fan will turn off after 3 hours automatically
6hr：Setting up that the ceiling fan will turn off after 6 hours automatically
Home Shield – Press and hold the buttons for 3 seconds. Fan will be off and the light will
randomly turn on and off while you are away home.
TR205A
: Walk Away Light Delay – Tap once ‐the light and fan turn off after 1 minute automatically.
Press the key for set fan speed for making natural wind.
Press the key for forward airflow of ceiling fan
Touch icon for reverse airflow of ceiling fan.
To assure continued FCC compliance:
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
--Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult
the dealer or an experienced radio/TV technician for help.
CAUTION:
Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to
operate the equipment.
FCC ID：
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
