Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
©2007 Cisco Systems, Inc. All rights reserved.
CCVP, the Cisco logo, and Welcome to the Human Network are trademarks of Cisco Systems, Inc.; Changing the Way We Work, Live, Play, and Learn is a service mark of
Cisco Systems,
Inc.; and Access Registrar, Aironet, Catalyst, CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, CCSP, Cisco, the Cisco Certified Internetwork Expert logo, Cisco IOS,
Cisco
Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Cisco Unity, Enterprise/Solver, EtherChannel, EtherFast, EtherSwitch, Fast Step, Follow Me
Browsing, FormShare, GigaDrive, HomeLink, Internet Quotient, IOS, iPhone, IP/TV, iQ Expertise, the iQ logo, iQ Net Readiness Scorecard, iQuick Study, LightStream, Linksys,
MeetingPlace, MGX, Networkers, Networking Academy, Network Registrar, PIX, ProConnect, ScriptShare, SMARTnet, StackWise, The Fastest Way to Increase Your Internet
Quotient, and TransPath are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries.
All other trademarks mentioned in this document or Website are the property of their respective owners. The use of the word partner does not imply a partnership relationship
between Cisco and any other company. (0711R)
![](/img.php?id=899518&img=bg3.png)
iii
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
CONTENTS
Preface vii
Audience i-vii
Purpose i-vii
Organization i-viii
Conventions i-viii
Related Publications i-ix
Obtaining Documentation, Obtaining Support, and Security Guidelines i-ix
CHAPTER
1Cisco Aironet 1000 Series Access Points 1-1
Channels and Maximum Power Levels 1-2
IEEE 802.11b/g (2.4-GHz Band) 1-2
IEEE 802.11a (5-GHz Band) 1-3
Special Country Restrictions 1-6
Changing the Lightweight Access Point Output Power 1-6
CHAPTER
2Cisco Aironet 1100 Series Access Points 2-9
Channels 2-10
AIR-LAP1121G IEEE 802.11g (2.4-GHz Band) 2-10
Maximum Power Levels 2-11
IEEE 802.11b (2.4-GHz Band) 2-11
IEEE 802.11g (2.4-GHz Band) 2-11
Changing the Lightweight Access Point Output Power 2-12
CHAPTER
3Cisco Aironet 1130 Series Access Points 3-1
IEEE 802.11b/g (2.4-GHz Band) 3-2
Channels and Maximum Power Levels 3-3
IEEE 802.11b/g (2.4-GHz Band) 3-3
IEEE 802.11a (5-GHz Band) 3-3
Special Country Restrictions 3-5
Changing the Lightweight Access Point Output Power 3-5
CHAPTER
4Cisco Aironet 1200 Series Access Points 4-1
Channels 4-2
![](/img.php?id=899518&img=bg4.png)
Contents
iv
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
IEEE 802.11g (2.4-GHz Band) 4-2
IEEE 802.11a (5-GHz Band) 4-2
Maximum Power Levels and Antenna Gains 4-4
IEEE 802.11g (2.4-GHz Band) 4-4
IEEE 802.11a (5-GHz Band) 4-5
Maximum Power Levels in Some Regulatory Domains with External Antennas 4-8
Special Country Restrictions 4-9
Power Conversion Table 4-9
Changing the Lightweight Access Point Output Power 4-10
CHAPTER
5Cisco Aironet 1240 Series Access Points 5-1
Channels and Maximum Power Levels 5-2
IEEE 802.11g (2.4-GHz Band) 5-2
IEEE 802.11g (2.4-GHz Band) 5-3
IEEE 802.11a (5-GHz Band) 5-4
Maximum Power Levels in Some Regulatory Domains with External Antennas 5-5
Special Country Restrictions 5-7
Changing the Lightweight Access Point Output Power 5-7
CHAPTER
6Cisco Aironet 1250 Series Lightweight
Access Points 6-1
Channels and Maximum Power Levels 6-2
2.4 GHz Band (Draft IEEE 802.11n Version 2.0) 6-2
5 GHz Band (Draft IEEE 802.11n Version 2.0) 6-7
Special Country Restrictions 6-17
Changing Lightweight Access Point Output Power 6-17
CHAPTER
7Cisco Aironet 1300 Series Access Points 7-1
Channels 7-2
IEEE 802.11g (2.4-GHz Band) 7-2
Maximum Power Levels and Antenna Gains 7-3
IEEE 802.11b/g (2.4-GHz Band) 7-3
Changing the Lightweight Access Point Output Power 7-4
Power Conversion Table 7-6
CHAPTER
8Cisco Aironet 1500 Series Mesh Access Points 8-1
Channels and Maximum Power Levels 8-2
IEEE 802.11b/g (2.4-GHz Band) 8-2
![](/img.php?id=899518&img=bg5.png)
Contents
v
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
IEEE 802.11a (5-GHz Band) 8-3
Antenna Settings 8-5
Maximum Power Levels Allowed in Some Regulatory Domains 8-5
Special Country Restrictions 8-7
Changing the Lightweight Access Point Output Power 8-8
CHAPTER
9Cisco Aironet 1520 Series Mesh Access Points 9-1
Channels and Maximum Power Levels 9-2
AIR-LAP1521G 9-2
IEEE 802.11b/g (2.4-GHz Band) 9-2
AIR-LAP1522AG 9-4
IEEE 802.11b/g (2.4-GHz Band) 9-4
IEEE 802.11a (5-GHz Band) 9-5
Minimum 5-GHz Radio Power Levels 9-12
Special Country Restrictions 9-13
Changing the Lightweight Access Point Output Power 9-14
![](/img.php?id=899518&img=bg6.png)
Contents
vi
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
![](/img.php?id=899518&img=bg7.png)
vii
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
Preface
Audience
This guide is for the networking professional who installs and manages Cisco Aironet access points and
bridges.
To use this guide with lightweight access points, you should have experience working with a Cisco
Wireless LAN Controller and be familiar with the concepts and terminology of wireless local area
networks.
Purpose
This guide provides the channel and maximum power settings you need to install your lightweight access
points and bridges in supported regulatory regions.
For hardware information about Cisco Aironet access points and bridges, refer to the product hardware
installation guides for your access points and bridges available from the Cisco.com at this URL:
http://www.cisco.com/en/US/products/hw/wireless/
The access point products are listed under the “Access Points” and “Outdoor Wireless” sections. Choose
the needed product, then click Install and Upgrade in the Support box.
For information about Cisco Wireless LAN Controllers, refer to the Cisco documentation sets available
under the “Wireless LAN Controllers” section. Choose the needed controller, then click on the
documentation type in the Support box.
![](/img.php?id=899518&img=bg8.png)
viii
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Preface
Organization
Organization
This guide is organized into these chapters:
Chapter 1, “Cisco Aironet 1000 Series Access Points,” lists the 1000 series lightweight access point
radio channels and the maximum power levels supported by the world’s regulatory domains.
Chapter 2, “Cisco Aironet 1100 Series Access Points,” lists the 1100 series lightweight access point
radio channels and the maximum power levels supported by the world’s regulatory domains.
Chapter 3, “Cisco Aironet 1130 Series Access Points,” lists the 1130 series lightweight access point
radio channels and the maximum power levels supported by the world’s regulatory domains.
Chapter 4, “Cisco Aironet 1200 Series Access Points,” lists the 1200 series lightweight access point
radio channels and the maximum power levels supported by the world’s regulatory domains.
Chapter 5, “Cisco Aironet 1240 Series Access Points,” lists the 1240 series lightweight access point
radio channels and the maximum power levels supported by the world’s regulatory domains.
Chapter 6, “Cisco Aironet 1250 Series Lightweight Access Points,” lists the 1250 series lightweight
access point radio channels and the maximum power levels supported by the world’s regulatory domains.
Chapter 7, “Cisco Aironet 1300 Series Access Points,” lists the 1300 series lightweight outdoor access
point/bridge radio channels and the maximum power levels supported by the world’s regulatory domains.
Chapter 8, “Cisco Aironet 1500 Series Mesh Access Points,” lists the 1500 series lightweight outdoor
mesh access point radio channels and the maximum power levels supported by the world’s regulatory
domains.
Chapter 9, “Cisco Aironet 1520 Series Mesh Access Points,” lists the 1520 series lightweight outdoor
mesh access point radio channels and the maximum power levels supported by the world’s regulatory
domains.
Conventions
This publication uses these conventions to convey instructions and information:
Interactive examples use these conventions:
• Terminal sessions and system displays are in screen font.
• Information you enter is in boldface screen font.
• Nonprinting characters, such as passwords or tabs, are in angle brackets (< >).
Notes, cautions, and timesavers use these conventions and symbols:
Tip Means the following will help you solve a problem. The tips information might not be troubleshooting
or even an action, but could be useful information.
Note Means reader take note. Notes contain helpful suggestions or references to materials not contained in
this manual.
![](/img.php?id=899518&img=bg9.png)
ix
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
Preface Related Publications
Caution Means reader be careful. In this situation, you might do something that could result equipment damage
or loss of data.
Related Publications
These documents provide information about the access points and bridges:
• Cisco Aironet 1000 Series Lightweight Access Point Hardware Installation Guide
• Cisco Aironet 1100 Series Access Point Hardware Installation Guide
• Cisco Aironet 1130AG Series Access Point Hardware Installation Guide
• Cisco Aironet 1200 Series Access Point Hardware Installation Guide
• Cisco Aironet 1240AG Series Access Point Hardware Installation Guide
• Cisco Aironet 1250 Series Access Point Hardware Installation Guide
• Cisco Aironet 1300 Series Access Point/Bridge Hardware Installation Guide
• Cisco Aironet 1500 Series Outdoor Mesh Access Point Hardware Installation Guide
• Cisco Aironet 1520 Series Outdoor Mesh Access Point Hardware Installation Guide
• Cisco IOS Software Configuration Guide for Cisco Aironet Access Points
• Cisco Wireless LAN Controller Configuration Guide
Click this link to browse to the Cisco Wireless documentation home page:
http://www.cisco.com/en/US/products/hw/wireless/
To browse to the access point and bridge documentation, click a product listed under “Access Points” or
“Outdoor Wireless.” The documentation is available from the Support box.
To browse to the Cisco Wireless LAN Controller documentation, click Cisco 4400 Series Wireless LAN
Controllers or Cisco 2100 Series Wireless LAN Controllers listed under “Wireless LAN Controllers.”
The documentation is available from the Support box.
Obtaining Documentation, Obtaining Support, and Security
Guidelines
For information on obtaining documentation, obtaining support, providing documentation feedback,
security guidelines, and also recommended aliases and general Cisco documents, see the monthly
What’s New in Cisco Product Documentation, which also lists all new and revised Cisco technical
documentation, at:
http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html
![](/img.php?id=899518&img=bga.png)
x
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Preface
Obtaining Documentation, Obtaining Support, and Security Guidelines
![](/img.php?id=899518&img=bgb.png)
CHAPTER
1-1
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
1
Cisco Aironet 1000 Series Access Points
This chapter lists the IEEE 802.11b/g (2.4-GHz) and the IEEE 802.11a (5-GHz) channels and maximum
power levels supported by the world’s regulatory domains for the Cisco Aironet 1000 Series Lightweight
Access Point. For additional product hardware information refer to the Cisco Aironet 1000 Series
Lightweight Access Point Hardware Installation Guide.
The following topic is covered in this appendix:
• Channels and Maximum Power Levels, page 1-2
![](/img.php?id=899518&img=bgc.png)
1-2
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 1 Cisco Aironet 1000 Series Access Points
Channels and Maximum Power Levels
Channels and Maximum Power Levels
IEEE 802.11b/g (2.4-GHz Band)
When shipped from the factory, the access points support the channels and maximum power levels listed
in Table 1-1 and Table 1-2 for their regulatory domain.
Note In Table 1-1 and Table 1-2, the operating data rates (in Mbps) are shown in the CCK and OFDM table
cells. For example: CCK 1-11 indicates CCK data rates of 1 to 11 Mbps.
.
Table 1-1 Channels and Maximum Conducted Power for the 802.11b/g Radio with Up to 6.5-dBi Antennas
Channel
ID
Center
Freq
(MHz)
Maximum Conducted Power Levels (dBm) in the Regulatory Domains
–A and –B –C –E
CCK
1-11 OFDM
9-24 OFDM
36 OFDM
48 OFDM
54 CCK
1-11 OFDM
9-24 OFDM
36 OFDM
48 OFDM
54 CCK
1-11 OFDM
9-24 OFDM
36 OFDM
48 OFDM
54
12412 20 17 17 17 17 14 14 14 14 14 14 14 14 14 14
22417 20 20 20 19 18 14 14 14 14 14 14 14 14 14 14
32422 20 20 20 19 18 14 14 14 14 14 14 14 14 14 14
42427 20 20 20 19 18 14 14 14 14 14 14 14 14 14 14
52432 20 20 20 19 18 14 14 14 14 14 14 14 14 14 14
62437 20 20 20 19 18 14 14 14 14 14 14 14 14 14 14
72442 20 20 20 19 18 14 14 14 14 14 14 14 14 14 14
82447 20 20 20 19 18 14 14 14 14 14 14 14 14 14 14
92452 20 20 20 19 18 14 14 14 14 14 14 14 14 14 14
10 2457 20 20 20 19 18 14 14 14 14 14 14 14 14 14 14
11 2462 20 17 17 17 17 14 14 14 14 14 14 14 14 14 14
12 2467 – – – 14 14 14 14 14 14 14 14 14 14
13 2472 – – – 14 14 14 14 14 14 14 14 14 14
14 2484 ––– ––––––––––
![](/img.php?id=899518&img=bgd.png)
1-3
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
Chapter 1 Cisco Aironet 1000 Series Access Points Channels and Maximum Power Levels
IEEE 802.11a (5-GHz Band)
When shipped from the factory, the outdoor access points support the channels and maximum power
levels listed in Table 1-3 and Table 1-4 for their regulatory domain.
Note In Table 1-3 and Table 1-4, the operating data rates (in Mbps) are shown in the OFDM table cells. For
example: OFDM 9-24 indicates OFDM data rates of 9 to 24Mbps.
Note To obtain the most current maximum power levels for the EMEA (–E) regulatory domain, refer to the
EMEA (–E) regulatory document that shipped with your access point.
Table 1-2 Channels and Maximum Conducted Power for the 802.11b/g Radio with Up to 6.5-dBi Antennas
Maximum Conducted Power Levels (dBm) in the Regulatory Domains
Channel
ID
Center
Freq
(MHz)
–I –K –N –J –P
–U –R –S –T
All CCK and
OFDM CCK
1-11 OFDM
9-24 OFDM
36 OFDM
448 OFDM
54 All CCK and OFDM CCK
1-11 OFDM
9-24 OFDM
36 OFDM
448 OFDM
54
12412 14 14 20 17 17 17 17 17 17 14 14 20 17 17 17 17
22417 14 14 20 20 20 19 18 17 17 14 14 20 20 20 19 18
32422 14 14 20 20 20 19 18 17 17 14 14 20 20 20 19 18
42427 14 14 20 20 20 19 18 17 17 14 14 20 20 20 19 18
52432 14 14 20 20 20 19 18 17 17 14 14 20 20 20 19 18
62437 14 14 20 20 20 19 18 17 17 14 14 20 20 20 19 18
72442 14 14 20 20 20 19 18 17 17 14 14 20 20 20 19 18
82447 14 14 20 20 20 19 18 17 17 14 14 20 20 20 19 18
92452 14 14 20 20 20 19 18 17 17 14 14 20 20 20 19 18
10 2457 14 14 20 20 20 19 18 17 17 14 14 20 20 20 19 18
11 2462 14 14 20 17 17 17 17 17 17 14 14 20 17 17 17 17
12 2467 14 14 – – – – – 17 17 14 14 – – – – –
13 2472 14 14 – – – – – 17 17 14 14 – – – – –
14 2484 – – – – – – – 171
1. Channel 14 allowed for 802.11b data rates only.
171–141– – – – –
![](/img.php?id=899518&img=bge.png)
1-4
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 1 Cisco Aironet 1000 Series Access Points
Channels and Maximum Power Levels
,
Table 1-3 Channels and Maximum Conducted Power for IEEE 802.11a Radio with Up to 6-dBi Antennas
Channel
ID
Center
Freq
(MHz)
Maximum Conducted Power Levels (dBm) in the Regulatory Domains
–A –B –C –E
OFDM
9-24 OFDM
36 OFDM
48 OFDM
54 OFDM
9-24 OFDM
36 OFDM
48 OFDM
54 OFDM
9-36 OFDM
48 OFDM
54 OFDM
9-36 OFDM
48 OFDM
54
UNII-1 (5150-5350 MHz)
34 5170 ––––––––––––––
36 5180 15 15 15 15 15 15 15 15 –––14.5 14.5 14.5
38 5190 ––––––––––––––
40 5200 17 17 17 17 17 17 17 17 –––14.5 14.5 14.5
42 5210 ––––––––––––––
44 5220 17 17 17 17 17 17 17 17 –––14.5 14.5 14.5
46 5230 ––––––––––––––
48 5240 15 15 15 15 15 15 15 15 –––14.5 14.5 14.5
52 5260 20 20 18 17 –––––––14.51
1. Dynamic frequency selection (DFS) and transmit power control (TPC) are required (uniform spreading is not required for the –P and –U regulatory
domains).
14.5114.51
56 5280 20 20 18 ––––––––14.5114.5114.51
60 5300 20 20 18 ––––––––14.5114.5114.51
64 5320 17 17 17 17 –––––––14.5114.5114.51
5470 to 5725 MHz
100 5500 –––––––––––201181171
104 5520 –––––––––––201181171
108 5540 –––––––––––201181171
112 5560 –––––––––––201181171
116 5580 –––––––––––201181171
120 5600 –––––––––––201181171
124 5620 –––––––––––201181171
128 5640 –––––––––––201181171
132 5660 –––––––––––201181171
136 5680 –––––––––––201181171
140 5700 –––––––––––201181171
5725 to 5850 MHz
149 5745 20 19 18 16 20 19 18 16 19.5 18 16 –––
153 5765 20 19 18 16 20 19 18 16 19.5 18 16 –––
157 5785 20 19 18 16 20 19 18 16 19 18 16 –––
161 5805 20 19 18 16 20 19 18 16 19 18 16 –––
165 5825 20 19 18 16 20 19 18 16 ––––––
![](/img.php?id=899518&img=bgf.png)
1-5
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
Chapter 1 Cisco Aironet 1000 Series Access Points Channels and Maximum Power Levels
Table 1-4 Channels and Maximum Conducted Power for IEEE 802.11a Radio with Up to 6-dBi Antennas
Channel
ID
Center
Frequency
(MHz)
Maximum Conducted Power Levels (dBm) in the Regulatory Domains
–I –K –N –J –P –U –R –S –T
OFDM
All OFDM
All OFDM
9-24 OFDM
36 OFDM
48 OFDM
54 OFDM
All OFDM
All OFDM
All OFDM
All OFDM
All OFDM
9-484 OFDM
54
UNII-1 (5150-5350 MHz)
34 5170 – – – – – – 18 – – – – – –
36 5180 15 15 15 15 15 15 –15 15 –15 – –
38 5190 – – – – – – 18 – – – – – –
40 5200 15 15 17 17 17 17 –15 15 –15 – –
42 5210 – – – – – – 18 – – – – – –
44 5220 15 15 17 17 17 17 –15 15 –15 – –
46 5230 – – – – – – 18 – – – – – –
48 5240 15 15 15 15 15 15 –15 15 –15 – –
52 5260 15117120 20 18 17 –111
1. Dynamic frequency selection (DFS) and transmit power control (TPC) are required (uniform spreading is not required for the –P and –U
regulatory domains).
– – 141– –
56 5280 15117120 20 18 17 –111– – 14115 15
60 5300 15117120 20 18 17 –111– – 14115 15
64 5320 15117117 17 17 17 –111– – 14115 15
5470 to 5725 MHz
100 5500 –171–––––––– – ––
104 5520 –171–––––––– – ––
108 5540 –171–––––––– – ––
112 5560 –171–––––––– – ––
116 5580 –171–––––––– – ––
120 5600 –171–––––––– – ––
124 5620 –171–––––––– – ––
128 5640 – – – – – – – – – – – – –
132 5660 – – – – – – – – – – – – –
136 5680 – – – – – – – – – – – – –
140 5700 – – – – – – – – – – – – –
5725 to 5850 MHz
149 5745 –16 20 19 18 16 – – – – 16 17 16
153 5765 –16 20 19 18 16 – – – – 16 17 16
157 5785 –16 20 19 18 16 – – – – 16 17 16
161 5805 –16 20 19 18 16 – – – – 16 17 16
165 5825 – – – – – – – – – – – – –
![](/img.php?id=899518&img=bg10.png)
1-6
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 1 Cisco Aironet 1000 Series Access Points
Channels and Maximum Power Levels
Special Country Restrictions
Table 1-5 lists special restrictions for wireless operation in some countries.
Changing the Lightweight Access Point Output Power
This section provides instructions for changing the 1000 series lightweight access point output power.
The output power on the 1000 series lightweight access points can be changed only using a 2600 series
or 4400 series controller, the controllers on a Cisco Wireless Services Module (WiSM), or a Cisco
Wireless Control System (WCS).
Note Administrator privileges may be required in order to change access point settings.
Note Regulatory domains are set at the factory and cannot be changed by the user.
Note See the Cisco Wireless LAN Controller Configuration Guide for more details on how to to configure your
access point.
Follow these steps to change the access point’s output power to meet local regulations or special country
restrictions using a controller running software release 4.1.x or later:
Step 1 Open your Internet browser. You must use Microsoft Internet Explorer 6.0.2800 or later.
Step 2 Enter https://IP address (where IP address is the controller’s IP address) in the browser address line
and press Enter. A user login screen appears.
Step 3 Enter the username and password and press Enter. The controller’s summary page appears.
Note The username and password are case-sensitive.
Step 4 Click Wireless on the upper tabs of the screen. The All APs screen appears.
Table 1-5 Special Country Restrictions for Wireless Operation
Country Frequency
Band (GHz) Regulatory
Domain Special Limitation and Restrictions
Japan 5–J, –P, and –U Operation limited to indoor use only.
Mexico 2.4 –N End user must limit 2.4 GHz operation to 2450 to 2483.5 MHz and
36 dBm EIRP1.
1. EIRP (dBm) = maximum output power (dBm) + antenna gain (dBi)
Russian Federation 5–E End user must limit 5 GHz operation to 5150-5250 MHz and
5650 to 5725 MHz.
United States 5 –A and –B Operation limited to indoor use only from 5150-5250 MHz.
![](/img.php?id=899518&img=bg11.png)
1-7
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
Chapter 1 Cisco Aironet 1000 Series Access Points Channels and Maximum Power Levels
Step 5 On the left side of the screen under Access Points, click 802.11a Radios or 802.11b/g Radios and a list
of accociated access points appears.
Step 6 Choose the desired access point from the displayed list and click Configure from the drop down arrow.
The radio settings page appears.
Step 7 Scroll down to the Tx Power Level Assignment field, and click Custom.
Custom—indicates that the radio output power is manually controlled by the Tx Power Configuration
setting field.
Step 8 In the Tx Power Level field, select the appropriate power level setting (1 to 5).
Based on the operating channel, the regulatory domain, and the controller power level setting (1 to 5),
the actual transmit power at the access point can be reduced to comply with special regulatory or country
restrictions.
Note Table 1-1, Table 1-2, Table 1-3, and Table 1-4 lists the access point maximum output power
levels supported for its regultory domain when shipped from the factory.
Table 1-6 lists the controller power settings and the corresponding output power levels for two examples:
• 2.4 GHz (802.11b/g) operation:
–
Non-FCC (–N) regulatory domain
–
Channel 2 using 11 Mbps data rates
• 5 GHz (802.11a) operation:
–
Non-FCC (–N) regulatory domain
–
Channel 36 using 36 Mbps data rates
Step 9 Click Apply.
Table 1-6 Example of Output Power Levels
Controller
Tx Power Settings1
1. The Tx Power Level setting of 1 represents the maximum conducted power
setting for the access point. Each subsequent controller power level (such as
2, 3, 4, etc) represents approximately a 3-dBm reduction in transmit power
from the previous power level.
Radio Output Power
802.11b/g
(dBm) 802.11a (dBm)
1 (maximum) 202
2. The maximum output power level obtained from Table 1-2.
153
3. The maximum output power level obtained from Table 1-4.
217 12
314 9
411 6
5 8 3
![](/img.php?id=899518&img=bg12.png)
1-8
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 1 Cisco Aironet 1000 Series Access Points
Channels and Maximum Power Levels
Step 10 Close your Internet browser.
For additional configuration information, refer to the Cisco Wireless LAN Controller Configuration
Guide.
![](/img.php?id=899518&img=bg13.png)
CHAPTER
2-9
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
2
Cisco Aironet 1100 Series Access Points
This chapter lists the 1100 series lightweight (AIR-LAP1121G) access point IEEE 802.11b (2.4-GHz)
and IEEE 802.11g (2.4-GHz) channels and the maximum power levels supported by the world’s
regulatory domains. For additional product hardware information refer to the Cisco Aironet 1100 Series
Access Point Hardware Installation Guide.
The following topics are covered in this chapter:
• Channels, page 2-10
• Maximum Power Levels, page 2-11
• Changing the Lightweight Access Point Output Power, page 2-12
![](/img.php?id=899518&img=bg14.png)
2-10
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 2 Cisco Aironet 1100 Series Access Points
Channels
Channels
AIR-LAP1121G IEEE 802.11g (2.4-GHz Band)
The channel identifiers, channel center frequencies, and regulatory domains of each IEEE 802.11g
22-MHz-wide channel are shown in Table 2-2.
Note Mexico is included in the Americas (-A) regulatory domain; however, channels 1 through 8 are for
indoor use only while channels 9 through 11 can be used indoors and outdoors. Users are responsible for
ensuring that the channel set configuration is in compliance with the regulatory standards of Mexico.
Table 2-1 Channels for IEEE 802.11g
Channel
Identifier
Center
Frequency
(MHz)
Regulatory Domains
Americas (-A) EMEA (-E) Japan (-J)
CCK OFDM CCK OFDM CCK OFDM
12412 X X X X X X
22417 X X X X X X
32422 X X X X X X
42427 X X X X X X
52432 X X X X X X
62437 X X X X X X
72442 X X X X X X
82447 X X X X X X
92452 X X X X X X
10 2457 X X X X X X
11 2462 X X X X X X
12 2467 – – X X X X
13 2472 – – X X X X
14 2484 – – – – X –
![](/img.php?id=899518&img=bg15.png)
2-11
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
Chapter 2 Cisco Aironet 1100 Series Access Points Maximum Power Levels
Maximum Power Levels
IEEE 802.11b (2.4-GHz Band)
An improper combination of power level and antenna gain can result in equivalent isotropic radiated
power (EIRP) above the amount allowed per regulatory domain. Table 2-2 indicates the maximum power
levels allowed with the Cisco integrated antenna for each IEEE 802.11b regulatory domain.
IEEE 802.11g (2.4-GHz Band)
An improper combination of power level and antenna gain can result in equivalent isotropic radiated
power (EIRP) above the amount allowed per regulatory domain. Table 2-3 shows the maximum power
levels allowed with the Cisco integrated antenna for each IEEE 802.11g regulatory domain.
Table 2-2 Maximum Power Levels Per Antenna Gain for IEEE 802.11b
Regulatory Domain Antenna Gain (dBi) Maximum Power Level (mW)
Americas (-A)
(4 watts EIRP maximum) 2.2 100
EMEA (-E)
(100 mW EIRP maximum) 2.2 50
Japan (-J)
(10 mW/MHz EIRP maximum) 2.2 30
Table 2-3 Maximum Power Levels Per Antenna Gain for IEEE 802.11g
Regulatory Domain Antenna Gain (dBi)
Maximum Power Level (mW)
CCK OFDM
Americas (-A)
(4 watts EIRP maximum) 2.2 100 30
EMEA (-E)
(100 mW EIRP maximum) 2.2 50 30
Japan (-J)
(10 mW/MHz EIRP
maximum)
2.2 30 30
![](/img.php?id=899518&img=bg16.png)
2-12
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 2 Cisco Aironet 1100 Series Access Points
Changing the Lightweight Access Point Output Power
Changing the Lightweight Access Point Output Power
This section provides instructions for changing the 1100 series lightweight access point output power to
comply with the maximum power limits imposed by regulatory domains (see the “Maximum Power
Levels” section on page 2-11). Follow these instructions to change the output power settings using your
browser:
Note Administrator privileges may be required in order to change access point settings.
Note Regulatory domains are set at the factory and cannot be changed by the user.
The output power on the AIR-LAP1121G-x-K9 (where x is the regulatory domain) access points can be
changed only by using a Cisco wireless LAN controller (2600 series or 4400 series), the controllers on
a Cisco Wireless Services Module (WiSM), or using Cisco Wireless Control System (WCS).
Note See the Cisco Wireless LAN Controller Configuration Guide for more details on how to configure your
access point using the web-browser interface.
Follow these steps to change theAIR-LAP1121G-x-K9 (where x is the regulatory domain) access point’s
output power to meet local regulations using a controller:
Step 1 Open your Internet browser. You must use Microsoft Internet Explorer 6.0.2800 or a later release.
Step 2 Enter https://IP address (where IP address is the controller’s IP address) in the browser address line
and press Enter. A user login screen appears.
Step 3 Enter the username and password and press Enter. The controller’s summary page appears.
Note The username and password are case-sensitive.
Step 4 Click Wireless > 802.11b/g Radio and a list of associated access points appears.
Step 5 Choose the desired access point from the displayed list and click Configure. The radio settings page
appears.
Step 6 Scroll down to the Tx Power Level Assignment field, and click Custom. Custom indicates that the radio
output power is manually controlled by the Tx Power Configuration setting field.
Step 7 In the Tx Power Level field, select the appropriate power level setting (1 to 8).
![](/img.php?id=899518&img=bg17.png)
2-13
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
Chapter 2 Cisco Aironet 1100 Series Access Points Changing the Lightweight Access Point Output Power
Table 2-4 lists the controller power settings and the corresponding output power levels for this example:
• 2.4-GHz (802.11b/g) operation:
–
EMEA (–E) regulatory domain
Step 8 Click Apply.
Step 9 Close your Internet browser.
For additional configuration information, refer to the Cisco Wireless LAN Controller Configuration
Guide.
Table 2-4 Available Output Power Levels
Controller
Tx Power Settings1
1. The Tx Power Level setting of 1 represents the maximum conducted power setting
for the access point. Each subsequent power level (such as 2, 3, 4, etc.) represents
an approximate 3-dBm reduction in transmit power from the previous power level.
Radio Output Power
802.11b (mW) 802.11g (mW)
1 (maximum)2
2. See Table 2-3 for the maximum power levels in the –E regulatory domain.
50 30
225 15
312 8
4 6 4
5 3 2
6 2 1
7-1 –
8 –
![](/img.php?id=899518&img=bg18.png)
2-14
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 2 Cisco Aironet 1100 Series Access Points
Changing the Lightweight Access Point Output Power
![](/img.php?id=899518&img=bg19.png)
CHAPTER
3-1
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
3
Cisco Aironet 1130 Series Access Points
This chapter lists the 1130 series lightweight access point (models: AIR-LAP1131G-x-K9 and
AIR-LAP1131AG-x-K9) IEEE 802.11b/g (2.4-GHz) and the IEEE 802.11a (5-GHz) channels and
maximum power levels supported by the world’s regulatory domains. For additional product hardware
information refer to the Cisco Aironet 1130AG Series Access Point Hardware Installation Guide.
The following topics are covered in this chapter:
• Channels and Maximum Power Levels, page 3-3
• Special Country Restrictions, page 3-5
• Changing the Lightweight Access Point Output Power, page 3-5
![](/img.php?id=899518&img=bg1a.png)
3-2
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 3 Cisco Aironet 1130 Series Access Points
IEEE 802.11b/g (2.4-GHz Band)
When shipped from the factory, the AIR-LAP1131G-x-K9 (single radio) access points support the
channels and maximum power levels listed in Table 3-1 for their regulatory domain.
Note The B columns indicate IEEE 802.11b data rates and the G colums indicate IEEE 802.11g data rates.
.Table 3-1 Channels and Maximum Conducted Power for the 802.11g Radio ‘
with 3-dBi Integrated Antenna
Channel
Id
Center
Freq
(MHz)
Maximum Conducted Power Levels (dBm) in the
Regulatory Domains
–A –E–P
B G B G B G
12412 20 17 14 14 14 14
22417 20 17 14 14 14 14
32422 20 17 14 14 14 14
42427 20 17 14 14 14 14
52432 20 17 14 14 14 14
62437 20 17 14 14 14 14
72442 20 17 14 14 14 14
82447 20 17 14 14 14 14
92452 20 17 14 14 14 14
10 2457 20 17 14 14 14 14
11 2462 20 17 14 14 14 14
12 2467 – – 14 14 14 14
13 2472 – – 14 14 14 14
14 2484 – – – – 14 –
![](/img.php?id=899518&img=bg1b.png)
3-3
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
Chapter 3 Cisco Aironet 1130 Series Access Points Channels and Maximum Power Levels
Channels and Maximum Power Levels
IEEE 802.11b/g (2.4-GHz Band)
When shipped from the factory, the AIR-AP1131AG-x-K9 (dual radio) access points support the
channels and maximum power levels listed in Table 3-2 for their regulatory domain.
Note The B columns indicate IEEE 802.11b data rates and the G colums indicate IEEE 802.11g data rates .
.
IEEE 802.11a (5-GHz Band)
When shipped from the factory, the AIR-AP1131AG-x-K9 (dual radio) access points support the
channels and maximum power levels listed in Table 3-3 for their regulatory domain.
Table 3-2 Channels and Maximum Conducted Power for the 802.11b/g Radio with 3-dBi Integrated Antenna
Channel
Id
Center
Freq
(MHz)
Maximum Conducted Power Levels (dBm) in the Regulatory Domains
–A –C –E–I –J –K –N–P –S –T
BGBGBGBGBGBGBGBGBGBG
12412 20 17 14 14 14 14 14 14 14 14 14 14 20 17 14 14 14 14 20 17
22417 20 17 14 14 14 14 14 14 14 14 14 14 20 17 14 14 14 14 20 17
32422 20 17 14 14 14 14 14 14 14 14 14 14 20 17 14 14 14 14 20 17
42427 20 17 14 14 14 14 14 14 14 14 14 14 20 17 14 14 14 14 20 17
52432 20 17 14 14 14 14 14 14 14 14 14 14 20 17 14 14 14 14 20 17
62437 20 17 14 14 14 14 14 14 14 14 14 14 20 17 14 14 14 14 20 17
72442 20 17 14 14 14 14 14 14 14 14 14 14 20 17 14 14 14 14 20 17
82447 20 17 14 14 14 14 14 14 14 14 14 14 20 17 14 14 14 14 20 17
92452 20 17 14 14 14 14 14 14 14 14 14 14 20 17 14 14 14 14 20 17
10 2457 20 17 14 14 14 14 14 14 14 14 14 14 20 17 14 14 14 14 20 17
11 2462 20 17 14 14 14 14 14 14 14 14 14 14 20 17 14 14 14 14 20 17
12 2467 – – 14 14 14 14 14 14 14 14 14 14 – – 14 14 14 14 – –
13 2472 – – 14 14 14 14 14 14 14 14 14 14 – – 14 14 14 14 – –
14 2484 – – – – – – – – 14 –––––14 –––––
![](/img.php?id=899518&img=bg1c.png)
3-4
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 3 Cisco Aironet 1130 Series Access Points
Channels and Maximum Power Levels
Note Access points with FCC Certification Number (LDK102054) do not support dynamic frequency
selection (DFS) on channels 100 to 140 in the US, Canada, and the Philippines. The FCC Certification
Number (also called FCC ID number) is shown on the product label on the bottom of the unit. Only
access points with LDK102054E on the product label and running the 4.1.170.0 software release can
support DFS in the US, Canada, and the Philippines.
.
Table 3-3 Channels and Maximum Conducted Power for IEEE 802.11a Radio with 4.5-dBI Integrated Antenna
Channel
ID
Center
Freq
(MHz)
Maximum Conducted Power Levels (dBm) in the Regulatory Domains
–A –C –E –I –J –K –N –P –U –S –T
5150 to 5250 MHz
34 5170 – – – – 15 – – – – – –
36 5180 15 –17 17 –15 15 15 15 17 –
38 5190 – – – – 15 – – – – – –
40 5200 15 –17 17 –15 15 15 15 17 –
42 5210 – – – – 15 – – – – – –
44 5220 15 –17 17 –15 15 15 15 17 –
46 5230 – – – – 15 – – – – – –
48 5240 15 –17 17 –15 15 15 15 17 –
5250 to 5350 MHz
52 5260 17 –171
1. Frequencies require DFS (Uniform spreading not required for the –P and –U regulatory domains).
171–171171151–141–
56 5280 17 –171171–171171151–14115
60 5300 17 –171171–171171151–14115
64 5320 17 –171171–171171151–14115
5450 to 5725 MHz
100 5500 171–171– – 171– – – – 171
104 5520 171–171– – 171– – – – 171
108 5540 171–171– – 171– – – – 171
112 5560 171–171– – 171– – – – 171
116 5580 171–171– – 171– – – – 171
120 5600 – – 171– – 171– – – – 171
124 5620 – – 171– – 171– – – – 171
128 5640 – – 171– – – – – – – 171
132 5660 171–171– – – – – – – 171
136 5680 171–171– – – – – – – 171
140 5700 171–171– – – – – – – 171
5725 to 5850 MHz
149 5745 17 17 –––17 17 – – 17 17
153 5765 17 17 –––17 17 – – 17 17
157 5785 17 17 –––17 17 – – 17 17
161 5805 17 17 –––17 17 – – 17 17
165 5825 – – – – – – – – – – –
![](/img.php?id=899518&img=bg1d.png)
3-5
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
Chapter 3 Cisco Aironet 1130 Series Access Points Special Country Restrictions
Special Country Restrictions
Table 3-4 lists special restrictions for wireless operation in some countries.
Changing the Lightweight Access Point Output Power
This section provides instructions for changing the 1130AG series access point output power to comply
with the maximum power limits imposed by special regulatory and country restrictions (see the “Special
Country Restrictions” section on page 3-5). Follow these instructions to change the output power
settings using a controller and your browser:
Note Administrator privileges may be required in order to change access point settings.
Note Regulatory domains are set at the factory and cannot be changed by the user.
Caution To meet regulatory restrictions, the access point and the external antenna must be professionally
installed. The network administration or other IT professional responsible for installing and configuring the
unit is a suitable professional installer. Following installation, access to the unit should be password
protected by the network administrator to maintain regulatory compliance.
The output power on the access points can be changed only using a Cisco wireless LAN controller (2600
series or 4400 series), the controllers on a Cisco Wireless Services Module (WiSM), or using Cisco
Wireless Control System (WCS).
Note See the Cisco Wireless LAN Controller Configuration Guide for more details on how to to configure your
access point using the web-browser interface.
Follow these steps to change the access point’s output power to meet local regulations using a controller:
Step 1 Open your Internet browser. You must use Microsoft Internet Explorer 6.0.2800 or a later release.
Step 2 Enter https://IP address (where IP address is the controller’s IP address) in the browser address line and
press Enter. A user login screen appears.
Table 3-4 Special Country Restrictions for Wireless Operation
Country Frequency
Band (GHz) Regulatory
Domain Special Limitation and Restrictions
Mexico 2.4 –N End user must limit 2.4 GHz operation to 2450 to 2483.5 MHz and 36
dBm EIRP1.
1. EIRP (dBm) = maximum output power (dBm) + antenna gain (dBi)
Russian Federation 5–E End user must limit 5 GHz operation to 5650 to 5725 MHz.
United States 5 –A Operation limited to indoor use only from 5150-5250 MHz.
![](/img.php?id=899518&img=bg1e.png)
3-6
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 3 Cisco Aironet 1130 Series Access Points
Changing the Lightweight Access Point Output Power
Step 3 Enter the username and password and press Enter. The controller’s summary page appears.
Note The username and password are case-sensitive.
Step 4 Click Wireless > 802.11a Radios or 802.11b/g Radios and a list of associated access points displays.
Step 5 Choose the desired access point from the displayed list and click Configure. The radio settings page
displays.
Step 6 Scroll down to the Tx Power Level Assignment field, and click Custom.
Custom indicates that the radio output power is manually controlled by the Tx Power Configuration
setting field.
Step 7 In the Tx Power Level field, select the appropriate power level setting (1 to 8).
Based on the operating channel, the regulatory domain, and the controller power level setting (1 to 8),
the actual transmit power at the access point can be reduced to comply with special regulatory or country
restrictions.
Table 3-5 lists the controller power settings and the corresponding output power levels for these two
examples:
• 2.4 GHz (802.11b/g) operation:
–
American regulatory domain and channel 2 using 11 Mbps data rates
• 5 GHz (802.11a) operation:
–
American regulatory domain and channel 149 using 36 Mbps data rates
Step 8 Click Apply.
Table 3-5 Example of Output Power Levels
Controller
Tx Power Settings1
1. The Tx Power Level setting of 1 represents the maximum conducted power setting for
the access point. Each subsequent controller power level (such as 2, 3, 4, etc) represents
approximately a 3-dBm reduction in transmit power from the previous power level.
Radio Output Power
802.11b/g (dBm) 802.11a (dBm)
1 (maximum) 202
2. The maximum output power level obtained from Table 3-2.
173
3. The maximum output power level obtained from Table 3-3.
217 14
314 11
411 8
5 8 5
6 5 2
7 2 -1
8-1 –
![](/img.php?id=899518&img=bg1f.png)
3-7
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
Chapter 3 Cisco Aironet 1130 Series Access Points Changing the Lightweight Access Point Output Power
Step 9 Close your Internet browser.
For additional configuration information, refer to the Cisco Wireless LAN Controller Configuration
Guide.
![](/img.php?id=899518&img=bg20.png)
3-8
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 3 Cisco Aironet 1130 Series Access Points
Changing the Lightweight Access Point Output Power
![](/img.php?id=899518&img=bg21.png)
CHAPTER
4-1
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
4
Cisco Aironet 1200 Series Access Points
This section lists the 1200 series lightweight access point (models: AIR-LAP1231G and
AIR-LAP1232AG) IEEE 802.11g (2.4-GHz) and IEEE 802.11a (5-GHz) channels, maximum power
levels, and antenna gains supported by the world’s regulatory domains. For additional product hardware
information refer to the Cisco Aironet 1200 Series Access Point Hardware Installation Guide.
The following topics are covered in this section:
• Channels, page 4-2
• Maximum Power Levels and Antenna Gains, page 4-4
• Power Conversion Table, page 4-9
• Changing the Lightweight Access Point Output Power, page 4-10
![](/img.php?id=899518&img=bg22.png)
4-2
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 4 Cisco Aironet 1200 Series Access Points
Channels
Channels
IEEE 802.11g (2.4-GHz Band)
The channel identifiers, channel center frequencies, and regulatory domains of each IEEE 802.11g
22-MHz-wide channel are shown in Table 4-1.
Note Mexico is included in the Americas (–A) regulatory domain; however, channels 1 through 8 are for
indoor use only while channels 9 through 11 can be used indoors and outdoors. Users are responsible for
ensuring that the channel set configuration is in compliance with the regulatory standards of Mexico.
IEEE 802.11a (5-GHz Band)
The channel identifiers, channel center frequencies, and regulatory domains of each IEEE 802.11a
20-MHz-wide channel are shown in Table 4-2.
Table 4-1 Channels for IEEE 802.11g
Channel
Identifier
Center
Frequency
(MHz)
Regulatory Domains
–A –E–J
CCK OFDM CCK OFDM CCK OFDM
12412 X X X X X X
22417 X X X X X X
32422 X X X X X X
42427 X X X X X X
52432 X X X X X X
62437 X X X X X X
72442 X X X X X X
82447 X X X X X X
92452 X X X X X X
10 2457 X X X X X X
11 2462 X X X X X X
12 2467 – – X X X X
13 2472 – – X X X X
14 2484 – – – – X –
![](/img.php?id=899518&img=bg23.png)
4-3
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
Chapter 4 Cisco Aironet 1200 Series Access Points Channels
..
Table 4-2 Channels for IEEE 802.11a for the RM21A and RM22A Radio Modules
Channel
ID
Center
Frequency
(MHz)
Regulatory Domains
–A –C –E–I –J –K –N–P –U –S–T
5150 to 5250 MHz
34 5170 – – – – X – – – – – –
36 5180 X – X X – X X X X X –
38 5190 – – – – X – – – – – –
40 5200 X – X X – X X X X X –
42 5210 – – – – X – – – – – –
44 5220 X – X X – X X X X X –
46 5230 – – – – X – – – – – –
48 5240 X – X X X X X X X –
5250 to 5350 MHz
52 5260 X – X X – X X X – X –
56 5280 X – X X – X X X – X X
60 5300 X – X X – X X X – X X
64 5320 X – X X – X X X – X X
5470 to 5725 MHz
100 5500 –– X – – X – – – – –
104 5520 –– X – – X – – – – –
108 5540 –– X – – X – – – – –
112 5560 –– X – – X – – – – –
116 5580 –– X – – X – – – – –
120 5600 –– X – – X – – – – –
124 5620 –– X – – X – – – – –
128 5640 –– X – – – – – – – –
132 5660 –– X – – – – – – – –
136 5680 –– X – – – – – – – –
140 5700 –– X – – – – – – – –
5725 to 5850 MHz
149 5745 X X – – – X X – – X X
153 5765 X X – – – X X – – X X
157 5785 X X – – – X X – – X X
161 5805 X X – – – X X – – X X
165 5825 – – – – – – – – – – –
![](/img.php?id=899518&img=bg24.png)
4-4
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 4 Cisco Aironet 1200 Series Access Points
Maximum Power Levels and Antenna Gains
Maximum Power Levels and Antenna Gains
IEEE 802.11g (2.4-GHz Band)
An improper combination of power level and antenna gain can result in equivalent isotropic radiated
power (EIRP) above the amount allowed per regulatory domain. Table 4-3 indicates the maximum power
levels and antenna gains allowed for each IEEE 802.11g regulatory domain.
Table 4-3 Maximum Power Levels Per Antenna Gain for IEEE 802.11g
Regulatory Domain Antenna Gain (dBi)
Maximum Power Level (mW)
CCK Modulation OFDM Modulation
–A
(4 W EIRP maximum) 2.2 100 30
5100 30
6 100 30
6.5 100 30
8.5 100 30
10 100 30
–E
(100 mW EIRP maximum) 2.2 50 30
530 10
630 10
6.5 20 10
8.5 10 5
10 10 5
–I
(100 mW EIRP maximum) 2.2 50 30
530 10
630 10
6.5 20 10
8.5 10 5
10 10 5
–J
(10 mW/MHz EIRP
maximum)
2.2 30 30
530 30
6 30 30
6.5 30 30
8.5 – –
10 – –
![](/img.php?id=899518&img=bg25.png)
4-5
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
Chapter 4 Cisco Aironet 1200 Series Access Points Maximum Power Levels and Antenna Gains
IEEE 802.11a (5-GHz Band)
When shipped from the factory, the RM21A radio modules (with the 5-dBi integrated antenna) support
the channels and maximum power levels listed in Table 4-4 for their regulatory domain.
.
Table 4-4 Maximum Power for RM21A Radio Module with 5-dBi Integrated Antenna
Channel
ID
Center
Frequency
(MHz)
Regulatory Domains
–A –C –E–I –J –K –N–P –U –S–T
5150 to 5250 MHz
34 5170 – – – – 15 – – – –– –
36 5180 15 –17 17 –15 15 15 15 17 –
38 5190 – – – – 15 – – – –– –
40 5200 15 –17 17 –15 15 15 15 17 –
42 5210 – – – – 15 – – – –– –
44 5220 15 –17 17 –15 15 15 15 17 –
46 5230 – – – – 14 – – – –– –
48 5240 15 –17 17 –15 15 15 15 17 –
5250 to 5350 MHz
52 5260 171
1. Frequencies require DFS (Uniform spreading not required for –P and –U regulatory domains).
–171171–171171141–141–
56 5280 171–171171–171171141–14115
60 5300 171–171171–171171141–14115
64 5320 171–171171–1712 171141–14115
5470 to 5725 MHz
100 5500 171–171– – 171– – – – –
104 5520 171–171– – 171– – – – –
108 5540 171–171– – 171– – – – –
112 5560 171–171– – 171– – – – –
116 5580 171–171– – 171– – – – –
120 5600 – – 171– – 171– – – – –
124 5620 – – 171– – 171– – – – –
128 5640 – – 171– – – – – – – –
132 5660 171–171– – – – – – – –
136 5680 171–171– – – – – – – –
140 5700 171–171– – – – – – – –
5725 to 5850 MHz
149 5745 17 17 ––– 17 17 ––17 17
153 5765 17 17 ––– 17 17 ––17 17
157 5785 17 17 ––– 17 17 ––17 17
161 5805 17 17 ––– 17 17 ––17 17
165 5825 – – – – – – – – –– –
![](/img.php?id=899518&img=bg26.png)
4-6
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 4 Cisco Aironet 1200 Series Access Points
Maximum Power Levels and Antenna Gains
When shipped from the factory, the RM21A radio modules (with the 9-dBi integrated antenna) support
the channels and maximum power levels listed in Table 4-5 for their regulatory domain.
..
Table 4-5 Maximum Power for RM21A Radio Module with 9-dBi Integrated Antenna
Channel
ID
Center
Frequency
(MHz)
Regulatory Domains
–A –C –E –I –J –K –N–P –U –S–T
5150 to 5250 MHz
34 5170 – – – – 11 – – – – – –
36 5180 11 –14 14 –15 11 11 11 14 –
38 5190 – – – – 11 – – – – – –
40 5200 11 –14 14 –15 11 11 11 14 –
42 5210 – – – – 11 – – – – – –
44 5220 11 –14 14 –15 11 11 11 14 –
46 5230 – – – – 11 – – – – – –
48 5240 11 –14 14 –15 11 11 11 14 –
5250 to 5350 MHz
52 5260 171
1. Frequencies require DFS (Uniform spreading not required for the –P and –U regulatory domains).
–141141–17117181–111–
56 5280 171–141141–17117181–11111
60 5300 171–141141–17117181–11111
64 5320 111–141141–17117181–11111
5470 to 5725 MHz
100 5500 171–171– – 171– – – – –
104 5520 171–171– – 171– – – – –
108 5540 171–171– – 171– – – – –
112 5560 171–171– – 171– – – – –
116 5580 171–171– – 171– – – – –
120 5600 – – 171– – 171– – – – –
124 5620 – – 171– – 171– – – – –
128 5640 – – 171– – – – – – – –
132 5660 171–171– – – – – – – –
136 5680 171–171– – – – – – – –
140 5700 171–171– – – – – – – –
5725 to 5850 MHz
149 5745 17 17 –––17 17 – – 17 17
153 5765 17 17 –––17 17 – – 17 17
157 5785 14 17 –––17 14 – – 17 14
161 5805 11 17 –––17 11 – – 17 11
165 5825 – – – – – – – – – – –
![](/img.php?id=899518&img=bg27.png)
4-7
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
Chapter 4 Cisco Aironet 1200 Series Access Points Maximum Power Levels and Antenna Gains
When shipped from the factory, the RM22A radio modules support the channels and maximum power
levels listed in Table 4-6 for their regulatory domain.
.
Table 4-6 Maximum Power for the RM22A Radio Module with Up To 9.5-dBi External Antennas
Channel
ID
Center
Frequency
(MHz)
Regulatory Domains
–A –C –E1
1. For the –E and –I regulatory domains, see the “Maximum Power Levels in Some Regulatory Domains with External Antennas” section on page 4-8.
–I1–J –K,2
2. In South Korea, the AIR-RM22A-N-K9 is approved only with antenna gains of 6 dBi or less.
–N3
3. In Australia and New Zealand, the AIR-RM22A-N-K9 is approved only with antenna gains of 6 dBi or less.
–P –U –S–T
5150 to 5250 MHz
34 5170 – – – – 11 – – – – – –
36 5180 11 –17 17 –15 11 11 11 14 –
38 5190 – – – – 11 – – – – – –
40 5200 11 –17 17 –15 11 11 11 14 –
42 5210 – – – – 11 – – – – – –
44 5220 11 –17 17 –15 11 11 11 14 –
46 5230 – – – – 11 – – – – – –
48 5240 11 –17 17 –15 11 11 11 14 –
5250 to 5350 MHz
52 5260 174
4. Frequencies require DFS (Uniform spreading not required for the –P and –U regulatory domains).
–174174–17417484–114–
56 5280 174–174174–17417484–11411
60 5300 174–174174–17417484–11411
64 5320 114–174174–17411484–11411
5470 to 5725 MHz
100 5500 174–174– – 174– – – – –
104 5520 174–174– – 174– – – – –
108 5540 174–174– – 174– – – – –
112 5560 174–174– – 174– – – – –
116 5580 174–174– – 174– – – – –
120 5600 – – 174– – 174– – – – –
124 5620 – – 174– – 174– – – – –
128 5640 – – 174– – – – – – – –
132 5660 174–174– – – – – – – –
136 5680 174–174– – – – – – – –
140 5700 174–174– – – – – – – –
5725 to 5850 MHz
149 5745 17 17 –––17 17 – – 17 17
153 5765 17 17 –––17 17 – – 17 17
157 5785 14 17 –––17 14 – – 17 14
161 5805 11 17 –––17 11 – – 17 11
165 5825 – – – – – – – – – – –
![](/img.php?id=899518&img=bg28.png)
4-8
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 4 Cisco Aironet 1200 Series Access Points
Maximum Power Levels and Antenna Gains
Maximum Power Levels in Some Regulatory Domains with External Antennas
Caution To avoid exceeding maximum conducted power levels in the EMEA (-E) and Israel (–I) regulatory
domains when using an external antenna, you must manually set the access point output power level as
shown in Table 4-7. The Israel (–I) regulator domain does not support channels 100 to 140.
Note For the latest EMEA (-E) regulatory domain information, refer to the EU Directive 1999/5/EC
Compliance Information document that ships with this product.
.
Table 4-7 RM22A Radio Module Maximum Power with External Antennas in the (–E) and (–I) Regulatory Domains
Channel
Identifier Center
Frequency (MHz) Maximum Power Levels (dBm)
4-dBi Antenna 5-dBi Antenna 6-dBi Antenna 7-dBi Antenna 9.5-dBi Antenna
5150 to 5250 MHz
34 5170 –––––
36 5180 17 17 15 15 11
38 5190 –––––
40 5200 17 17 15 15 11
42 5210 –––––
44 5220 17 17 15 15 11
46 5230 –––––
48 5240 17 17 15 15 11
5250 to 5350 MHz
52 5260 17 17 15 15 11
56 5280 17 17 15 15 11
60 5300 17 17 15 15 11
64 5320 17 17 15 15 11
5470 to 5725 MHz
100 5500 17 17 17 17 17
104 5520 17 17 17 17 17
108 5540 17 17 17 17 17
112 5560 17 17 17 17 17
116 5580 17 17 17 17 17
120 5600 17 17 17 17 17
124 5620 17 17 17 17 17
128 5640 17 17 17 17 17
132 5660 17 17 17 17 17
136 5680 17 17 17 17 17
140 5700 17 17 17 17 17
5725 to 5850 MHz
149 5745 –––––
153 5765 –––––
157 5785 –––––
161 5805 –––––
165 5825 –––––
![](/img.php?id=899518&img=bg29.png)
4-9
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
Chapter 4 Cisco Aironet 1200 Series Access Points Power Conversion Table
Special Country Restrictions
Table 4-8 lists special restrictions for wireless operation in some countries.
Power Conversion Table
You can use Table 4-9 to convert power values from dBm to mW or from mW to dBm.
Table 4-8 Special Country Restrictions for Wireless Operation
Country Frequency
Band (GHz) Regulatory
Domain Special Limitation and Restrictions
Australia and
New Zealand 5–N 2.4 and 5 GHz external antenna gain limited to 6 dBi. or less
South Korea 2.4 and 5 –K 2.4 and 5 GHz external antenna gain limited to 6 dBi or less.
Mexico 2.4 –N End user must limit 2.4 GHz operation to 2450 to 2483.5 MHz and
36 dBm EIRP1.
1. EIRP (dBm) = maximum output power (dBm) + antenna gain (dBi)
Russian Federation 5 –E End user must limit 5 GHz operation to 5150 to 5350 and
5650 to 5725 MHz.
United States 2.4 –A Operation limited to indoor use only from 5150-5250 MHz.
Table 4-9 Power Conversion Table
mW dBm mW dBm
200 23 15 12
150 22 12 11
125 21 10 10
100 20 8 9
80 19 6 8
60 18 5 7
50 17 4 6
40 16 3 5
30 15 2 2
25 14 1–1
20 13 –
![](/img.php?id=899518&img=bg2a.png)
4-10
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 4 Cisco Aironet 1200 Series Access Points
Changing the Lightweight Access Point Output Power
Changing the Lightweight Access Point Output Power
This section provides instructions for changing the 1200 series access point output power to comply with
the maximum power limits imposed by special regulatory and country restrictions (see the“Maximum
Power Levels in Some Regulatory Domains with External Antennas” section on page 4-8 and the
“Special Country Restrictions” section on page 4-9). Follow these instructions to change the output
power settings using a controller and your browser:
Note Administrator privileges may be required in order to change access point settings.
Note Regulatory domains are set at the factory and cannot be changed by the user.
Caution To meet regulatory restrictions, the access point and the external antenna must be professionally
installed. The network administration or other IT professional responsible for installing and configuring the
unit is a suitable professional installer. Following installation, access to the unit should be password
protected by the network administrator to maintain regulatory compliance.
The output power on the access points can be changed only using a Cisco wireless LAN controller (2600
series or 4400 series), the controllers on a Cisco Wireless Services Module (WiSM), or using Cisco
Wireless Control System (WCS).
Note See the Cisco Wireless LAN Controller Configuration Guide for more details on how to to configure your
access point using the web-browser interface.
Follow these steps to change the access point’s output power to meet local regulations using a controller:
Step 1 Open your Internet browser. You must use Microsoft Internet Explorer 6.0.2800 or a later release.
Step 2 Enter https://IP address (where IP address is the controller’s IP address) in the browser address line and
press Enter. A user login screen appears.
Step 3 Enter the username and password and press Enter. The controller’s summary page appears.
Note The username and password are case-sensitive.
Step 4 Click Wireless > 802.11a Radios or 802.11b/g Radios and a list of associated access points appears.
Step 5 Choose the desired access point from the displayed list and click Configure. The radio settings page
appears.
Step 6 Scroll down to the Tx Power Level Assignment field, and click Custom.
Custom indicates that the radio output power is manually controlled by the Tx Power Configuration
setting field.
![](/img.php?id=899518&img=bg2b.png)
4-11
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
Chapter 4 Cisco Aironet 1200 Series Access Points Changing the Lightweight Access Point Output Power
Step 7 In the Tx Power Level field, select the appropriate power level setting (1 to 8).
Based on the operating channel, the regulatory domain, and the controller power level setting (1 to 8),
the actual transmit power at the access point can be reduced to comply with special regulatory or country
restrictions.
Table 4-10 lists the controller power settings and the corresponding output power levels for these two
examples:
• 2.4-GHz (802.11b/g) operation:
–
(–E) regulatory domain and channel 2 using 11-Mbps data rates
–
6-dBi external antenna
• 5-GHz (802.11a) operation:
–
(–E) regulatory domain and channel 52 using 36-Mbps data rates
–
RM22A with 6-dBi external antenna
• For 802.11b (CCK) and 802.11g (OFDM) data rates (see Table 4-3 and Table 4-10), the manual
controller Tx Power Level setting is 3.
• For only 802.11b (CCK) data rates (see Table 4-3 and Table 4-10), the manual controller Tx Power
Level setting is 2.
• For 802.11a (see Table 4-7 and Table 4-10), the manual controller Tx Power Level setting is 2.
Step 8 Click Apply.
Step 9 Close your Internet browser.
For additional configuration information, refer to the Cisco Wireless LAN Controller Configuration
Guide.
Table 4-10 Example of Output Power Levels
Controller
Tx Power Settings1
1. The Tx Power Level setting of 1 represents the maximum conducted power setting for the access point. Each
subsequent controller power level (such as 2, 3, 4, etc.) represents approximately a 3-dBm reduction in transmit
power from the previous power level.
Radio Output Power
802.11b (mW) 802.11g (mW) 802.11a (dBm)
1 (maximum) 50 2
2. The maximum output power levels obtained from Table 4-3 and the values converted using Table 4-9.
30217 3
3. The maximum output power level of 17 dBi obtained from Table 4-6.
225 15 14
312 811
46 4 8
53 2 5
62 1 2
71 –-1
8 – – –
![](/img.php?id=899518&img=bg2c.png)
4-12
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 4 Cisco Aironet 1200 Series Access Points
Changing the Lightweight Access Point Output Power
![](/img.php?id=899518&img=bg2d.png)
CHAPTER
5-1
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
5
Cisco Aironet 1240 Series Access Points
This chapter lists the 1240 series lightweight access point (models: AIR-LAP1242AG-x-K9 and
AIR-LAP1242G-x-K9) IEEE 802.11b/g (2.4-GHz) and the IEEE 802.11a (5-GHz) channels and
maximum power levels supported by the world’s regulatory domains. For additional product hardware
information refer to the Cisco Aironet 1240AG Series Access Point Hardware Installation Guide.
The following topics are covered in this chapter:
• Channels and Maximum Power Levels, page 5-2
• Special Country Restrictions, page 5-7
• Changing the Lightweight Access Point Output Power, page 5-7
![](/img.php?id=899518&img=bg2e.png)
5-2
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 5 Cisco Aironet 1240 Series Access Points
Channels and Maximum Power Levels
Channels and Maximum Power Levels
IEEE 802.11g (2.4-GHz Band)
When shipped from the factory, the AIR-AP1242G-x-K9 (single radio) access points support the
channels and maximum power levels listed in Table 5-1 for their regulatory domain.
Note Table 5-1 lists the power levels shipped from the factory. The B columns indicate IEEE 802.11b data
rates and the G columns indicate IEEE 802.11g data rates . In the –C, –E, –I, –K, and –S regulatory
domains, you must manually adjust power levels depending upon the antenna being used (see Table 5-4).
.
Table 5-1 Channels and Maximum Conducted Power for the 802.11g Radio with up to 10-dBi External Antennas
Channel
Id
Center
Frequency
(MHz)
Maximum Conducted Power Levels (dBm)
in the Regulatory Domains
–A –J –P
BGBGBG
12412 20 17 14 14 14 14
22417 20 17 14 14 14 14
32422 20 17 14 14 14 14
42427 20 17 14 14 14 14
52432 20 17 14 14 14 14
62437 20 17 14 14 14 14
72442 20 17 14 14 14 14
82447 20 17 14 14 14 14
92452 20 17 14 14 14 14
10 2457 20 17 14 14 14 14
11 2462 20 17 14 14 14 14
12 2467 – – 14 14 14 14
13 2472 – – 14 14 14 14
14 2484 – – 14 –14 –
![](/img.php?id=899518&img=bg2f.png)
5-3
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
Chapter 5 Cisco Aironet 1240 Series Access Points Channels and Maximum Power Levels
IEEE 802.11g (2.4-GHz Band)
When shipped from the factory, the AIR-LAP1242AG-x-K9 (dual radio) access points support the
channels and maximum power levels listed in Table 5-1 for their regulatory domain.
Note Table 5-2 lists the power levels shipped from the factory. The B columns indicate IEEE 802.11b data
rates and the G columns indicate IEEE 802.11g data rates. In the –C, –E, –I, –K, and –S regulatory
domains, you must manually adjust power levels depending upon the antenna being used (see Table 5-4).
.
Table 5-2 Channels and Maximum Conducted Power for the 802.11b/g Radio with up to 10-dBi External Antennas
Channel
Id
Center
Freq
(MHz)
Maximum Conducted Power Levels (dBm) in the Regulatory Domains
–A –C –E–I –J –K –N–P –S –T
BGBGBGBGBGBGBGBGBGBG
12412 20 17 17 17 17 17 17 17 14 14 17 17 20 17 14 14 17 17 20 17
22417 20 17 17 17 17 17 17 17 14 14 17 17 20 17 14 14 17 17 20 17
32422 20 17 17 17 17 17 17 17 14 14 17 17 20 17 14 14 17 17 20 17
42427 20 17 17 17 17 17 17 17 14 14 17 17 20 17 14 14 17 17 20 17
52432 20 17 17 17 17 17 17 17 14 14 17 17 20 17 14 14 17 17 20 17
62437 20 17 17 17 17 17 17 17 14 14 17 17 20 17 14 14 17 17 20 17
72442 20 17 17 17 17 17 17 17 14 14 17 17 20 17 14 14 17 17 20 17
82447 20 17 17 17 17 17 17 17 14 14 17 17 20 17 14 14 17 17 20 17
92452 20 17 17 17 17 17 17 17 14 14 17 17 20 17 14 14 17 17 20 17
10 2457 20 17 17 17 17 17 17 17 14 14 17 17 20 17 14 14 17 17 20 17
11 2462 20 17 17 17 17 17 17 17 14 14 17 17 20 17 14 14 17 17 20 17
12 2467 – – 17 17 17 17 17 17 14 14 17 17 – – 14 14 17 17 – –
13 2472 – – 17 17 17 17 17 17 14 14 17 17 – – 14 14 17 17 – –
14 2484 – – – – – – – – 14 –––––14 –––––
![](/img.php?id=899518&img=bg30.png)
5-4
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 5 Cisco Aironet 1240 Series Access Points
Channels and Maximum Power Levels
IEEE 802.11a (5-GHz Band)
When shipped from the factory, the AIR-LAP1242AG-x-K9 (dual radio) access points support the
channels and maximum power levels listed in Table 5-3 for their regulatory domain.
Note Table 5-3 lists the power levels shipped from the factory. In the –E and –I regulatory domains, you must
manually adjust power levels depending upon the antenna being used (see Table 5-5).
.
Table 5-3 Channels and Maximum Conducted Power for IEEE 802.11a Radio with up to 9.5-dBI External Antennas
Channel
ID
Center
Freq
(MHz)
Maximum Conducted Power Levels (dBm) in the Regulatory Domains
–A –C –E –I –J –K –N –P –U –S –T
5150 to 5250 MHz
34 5170 – – – – 11 – – – – – –
36 5180 11 –17 17 –15 11 11 11 14 –
38 5190 – – – – 11 – – – – – –
40 5200 11 –17 17 –15 11 11 11 14 –
42 5210 – – – – 11 – – – – – –
44 5220 11 –17 17 –15 11 11 11 14 –
46 5230 – – – – 11 – – – – – –
48 5240 11 –17 17 –15 11 11 11 14 –
5250 to 5350 MHz
52 5260 17 –171
1. Frequencies require DFS (Uniform spreading not required for the –P and –U regulatory domains).
171–17117181–111–
56 5280 17 –171171–17117181–11111
60 5300 17 –171171–17117181–11111
64 5320 11 –171171–17111181–11111
5450 to 5725 MHz
100 5500 171–171– – 171– – – – 171
104 5520 171–171– – 171– – – – 171
108 5540 171–171– – 171– – – – 171
112 5560 171–171– – 171– – – – 171
116 5580 171–171– – 171– – – – 171
120 5600 – – 171– – 171– – – – 171
124 5620 – – 171– – 171– – – – 171
128 5640 – – 171– – – – – – – 171
132 5660 171–171– – – – – – – 171
136 5680 171–171– – – – – – – 171
140 5700 171–171– – – – – – – 171
5725 to 5850 MHz
149 5745 17 17 ––– 17 17 – – 17 17
153 5765 17 17 ––– 17 17 – – 17 17
157 5785 14 17 ––– 17 14 – – 17 14
161 5805 11 17 ––– 17 11 – – 17 11
165 5825 – – – – – – – – – – –
![](/img.php?id=899518&img=bg31.png)
5-5
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
Chapter 5 Cisco Aironet 1240 Series Access Points Channels and Maximum Power Levels
Maximum Power Levels in Some Regulatory Domains with External Antennas
Caution To avoid exceeding maximum conducted power levels in the China (–C), EMEA (-E), South Korea (–K),
Israel (–I), and Singapore (–S) regulatory domains when using an 802.11b/g radio with 2.2- to 10-dBi
external antennas, you must manually set the access point output power level as shown in Table 5-4.
Table 5-4 Maximum Power Levels for the 802.11b/g Radio in the (–C), (–E), (–K), (–I), and (–S) Regulatory Domains
Channel
Identifier
Center
Frequency
(MHz)
Maximum Power Levels (dBm)
2.2 dBi
Antenna 5.2 dBi
Antenna 6.0 dBi
Antenna 6.5dBi
Antenna 9.0 dBi
Antenna 10 dBi
Antenna
12412 17 14 14 11 11 8
22417 17 14 14 11 11 8
32422 17 14 14 11 11 8
42427 17 14 14 11 11 8
52432 17 14 14 11 11 8
62437 17 14 14 11 11 8
72442 17 14 14 11 11 8
82447 17 14 14 11 11 8
92452 17 14 14 11 11 8
10 2457 17 14 14 11 11 8
11 2462 17 14 14 11 11 8
12 2467 17 14 14 11 11 8
13 2472 17 14 14 11 11 8
14 2484 ––––––
![](/img.php?id=899518&img=bg32.png)
5-6
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 5 Cisco Aironet 1240 Series Access Points
Channels and Maximum Power Levels
Caution To avoid exceeding maximum conducted power levels in the EMEA (-E) and Israel (–I) regulatory
domains when using a IEEE 802.11a radio with 6.0- to 9.5-dBi external 5-MHz antennas, you must
manually set the access point output power level as shown in Table 5-5.
Table 5-5 Maximum Power Levels for IEEE 802.11a Radio in the EMEA(–E) and Israel (–I) Regulatory Domains
Channel
Identifier
Center
Frequency
(MHz)
Maximum Power Levels (dBm)
3.5 dBi Antenna 4.5 dBi Antenna 6.0 dBi Antenna 7.0 dBi Antenna 9.5 dBi Antenna
UNII-1 (5150-5250 MHz)
34 5170 –––––
36 5180 17 17 15 15 11
38 5190 –––––
40 5200 17 17 15 15 11
42 5210 –––––
44 5220 17 17 15 15 11
46 5230 –––––
48 5240 17 17 15 15 11
5250 to 5350 MHz
52 5260 17 17 15 15 11
56 5280 17 17 15 15 11
60 5300 17 17 15 15 11
64 5320 17 17 15 15 11
5470 to 5725 MHz
100 5500 17 17 17 17 17
104 5520 17 17 17 17 17
108 5540 17 17 17 17 17
112 5560 17 17 17 17 17
116 5580 17 17 17 17 17
120 5600 17 17 17 17 17
124 5620 17 17 17 17 17
128 5640 17 17 17 17 17
132 5660 17 17 17 17 17
136 5680 17 17 17 17 17
140 5700 17 17 17 17 17
5725 to 5850 MHz
149 5745 –––––
153 5765 –––––
157 5785 –––––
161 5805 –––––
165 5825 –––––
![](/img.php?id=899518&img=bg33.png)
5-7
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
Chapter 5 Cisco Aironet 1240 Series Access Points Special Country Restrictions
Special Country Restrictions
Table 5-6 lists special restrictions for wireless operation in some countries.
Changing the Lightweight Access Point Output Power
This section provides instructions for changing the 1240 series access point output power to comply with
the maximum power limits imposed by special regulatory and country restrictions (see the “Special
Country Restrictions” section on page 5-7). Follow these instructions to change the output power
settings using a controller and your browser:
Note Administrator privileges may be required in order to change access point settings.
Note Regulatory domains are set at the factory and cannot be changed by the user.
Caution To meet regulatory restrictions, the access point and the external antenna must be professionally
installed. The network administration or other IT professional responsible for installing and configuring the
unit is a suitable professional installer. Following installation, access to the unit should be
password-protected by the network administrator to maintain regulatory compliance.
The output power on the access points can be changed only using a Cisco controllers (such as the 2600
series or 4400 series), the controllers on a Cisco Wireless Services Module (WiSM), or using Cisco
Wireless Control System (WCS).
Note See the Cisco Wireless LAN Controller Configuration Guide for more details on how to to configure your
access point using the web-browser interface.
Table 5-6 Special Country Restrictions for Wireless Operation
Country Frequency
Bands (GHz) Regulatory
Domain Special Limitation and Restrictions
Japan 5–J, –P, and –U Operation limited to indoor only.
South Korea 2.4 and 5 –K Maximum antenna gain limited to 6 dBi.
Mexico 2.4 –N End user must limit 2.4 GHz operation to 2450 to 2483.5 MHz and
36 dBm EIRP1.
1. EIRP (dBm) = Maximum output power (dBm) + antenna gain (dBi)
Russian Federation 5–E End user must limit 5 GHz operation to 5150-5350 and
5650 to 5725 MHz.
United States 5 –A Indoor use only from 5150-5250 MHz.
![](/img.php?id=899518&img=bg34.png)
5-8
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 5 Cisco Aironet 1240 Series Access Points
Changing the Lightweight Access Point Output Power
Follow these steps to change the access point’s output power to meet local regulations using a controller:
Step 1 Open your Internet browser. You must use Microsoft Internet Explorer 6.0.2800 or a later release.
Step 2 Enter https://IP address (where IP address is the controller’s IP address) in the browser address line
and press Enter. A user login screen appears.
Step 3 Enter the username and password and press Enter. The controller’s summary page appears.
Note The username and password are case-sensitive.
Step 4 Click Wireless > 802.11a Radios or 802.11b/g Radios and a list of associated access points displays.
Step 5 Choose the desired access point and click Configure. The radio settings page appears.
Step 6 Scroll down to the Tx Power Level Assignment field, and click Custom.
Custom indicates that the radio output power is manually controlled by the Tx Power Configuration
setting field.
Step 7 In the Tx Power Level field, select the appropriate power level setting (1 to 8).
Based on the operating channel, the regulatory domain, and the controller power level setting (1 to 8),
the actual transmit power at the access point can be reduced to comply with special regulatory or country
restrictions.
Table 5-7 lists the controller power settings and the corresponding output power levels for these two
examples:
• 2.4 GHz (802.11b/g) operation in –E regulatory domain:
–
Channel 2 using 11-Mbps data rates with 6-dBi external antenna
• 5 GHz (802.11a) operation:
–
Channel 52 with 6-dBi external antenna
Table 5-7 Example of Output Power Levels
Controller
Tx Power Settings1
1. The Tx Power Level setting of 1 represents the maximum conducted power setting for the
access point. Each subsequent controller power level (such as 2, 3, 4, etc.) represents
approximately a 3-dBm reduction in transmit power from the previous power level.
Radio Output Power
802.11b/g (dBm) 802.11a (dBm)
1 (maximum) 172
2. The maximum output power levels obtained from Table 5-2 and Table 5-3.
172
214 14
311 11
4 8 8
5 5 5
6 2 2
7-1 -1
8 – –
![](/img.php?id=899518&img=bg35.png)
5-9
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-07
Chapter 5 Cisco Aironet 1240 Series Access Points Changing the Lightweight Access Point Output Power
• For 802.11b/g (see Table 5-4 and Table 5-7), the manual controller Tx Power Level setting is 2.
• For 802.11a (see Table 5-5 and Table 5-7), the manual controller Tx Power Level setting is 2.
Step 8 Click Apply.
Step 9 Close your Internet browser.
![](/img.php?id=899518&img=bg36.png)
5-10
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-07
Chapter 5 Cisco Aironet 1240 Series Access Points
Changing the Lightweight Access Point Output Power
![](/img.php?id=899518&img=bg37.png)
CHAPTER
6-1
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-06
6
Cisco Aironet 1250 Series Lightweight
Access Points
This section lists the 1250 series lightweight access points (model: AIR-LAP1251) 2.4-GHz and 5-GHz
( draft IEEE 802.11n version 2.0) radio channels and maximum power levels supported by the world’s
regulatory domains. The following topics are covered in this section:
• Channels and Maximum Power Levels, page 6-2
• Special Country Restrictions, page 6-17
• Changing Lightweight Access Point Output Power, page 6-17
![](/img.php?id=899518&img=bg38.png)
6-2
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-06
Chapter 6 Cisco Aironet 1250 Series Lightweight Access Points
Channels and Maximum Power Levels
Channels and Maximum Power Levels
Note The access point has been designed to operate with the antennas listed in the product hardware
installation guide and having a maximum gain of 10 dBi for 2.4 GHz and 6 dBi for 5 GHz. Antennas not
included in this list or having a higher gain are strictly prohibited for use with the access point. The
required antenna impedance is 50 ohms.
Note To reduce potential radio interference to other users, the antenna type and its gain should be chosen so
that the equivalent isotropically radiated power (e.i.r.p.) is not more than required for successful
communication.
2.4 GHz Band (Draft IEEE 802.11n Version 2.0)
An improper combination of power level and antenna gain can result in equivalent isotropic radiated
power (EIRP) above the amount allowed per regulatory domain. Table 6-1 indicates the channel
identifiers, channel center frequencies, and maximum power levels for each channel allowed by the
–A regulatory domain for a 2.4-GHz radio with up to 10-dBi antennas.
Table 6-1 Channels and Maximum Conducted Power in the –A Regulatory Domain with up to
10-dBi Antennas
Maximum Conducted Power Levels (dBm) in the –A Regulatory Domain for the 2.4-GHz Radio with up to 10-dBi
Antennas
Freq
(MHz)
Center
Channel
802.11b
Single Antenna
1 to 11 Mbps
802.11g
Single Antenna
6 to 54 Mbps
HT-20 MHz
Dual Antennas
M0 to M151
1. M0 to M15 corresponds to the Modulaton and Coding Schemes (MCS0 to MCS15). The MCS settings determine the number
of spatial streams, the modulation, the coding rate, and the data rate values.
HT-40 MHz
Dual Antennas
M0 to M151
20
MHz 40
MHz Tx A Tx B Total
Power Tx A Tx B Total
Power Tx A Tx B Total
Power Tx A Tx B Total
Power
2412 1 3 20 OFF 20 17 OFF 17 17 17 20 14 14 17
2417 2 4 20 OFF 20 17 OFF 17 17 17 20 14 14 17
2422 3 5 20 OFF 20 17 OFF 17 17 17 20 14 14 17
2427 4 6 20 OFF 20 17 OFF 17 17 17 20 14 14 17
2432 53, 7 20 OFF 20 17 OFF 17 17 17 20 14 14 17
2437 64, 8 23 OFF 23 20 OFF 20 17 17 20 17 17 20
2442 75, 9 20 OFF 20 17 OFF 17 17 17 20 14 14 17
2447 86, 10 20 OFF 20 17 OFF 17 17 17 20 14 14 17
2452 97, 11 20 OFF 20 17 OFF 17 17 17 20 14 14 17
2457 10 820 OFF 20 17 OFF 17 17 17 20 14 14 17
2462 11 920 OFF 20 17 OFF 17 17 17 20 14 14 17
2467 – – – – – – – – – – – – – –
2472 – – – – – – – – – – – – – –
2484 – – – – – – – – – – – – – –
![](/img.php?id=899518&img=bg39.png)
6-3
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-06
Chapter 6 Cisco Aironet 1250 Series Lightweight Access Points Channels and Maximum Power Levels
Table 6-2 indicates the channel identifiers, channel center frequencies, and maximum power levels for
each channel allowed by the –E regulatory domain for a 2.4-GHz radio with up to 3-dBi antennas.
Table 6-2 Channels and Maximum Conducted Power for –E Regulatory Domain with up to 3-dBi Antennas
Maximum Conducted Power Levels (dBm) in the –E Regulatory Domain for the 2.4-GHz Radio with up to 3-dBi
Anetnnas
Freq
(MHz)
Center
Channel
802.11b
Single Antenna
1 to 11 Mbps
802.11g
Single Antenna
6 to 54 Mbps
HT-20 MHz
Dual Antennas
M0 to M151
1. M0 to M15 corresponds to the Modulaton and Coding Schemes (MCS0 to MCS15). The MCS settings determine the number
of spatial streams, the modulation, the coding rate, and the data rate values.
HT-40 MHz
Dual Antennas
M0 to M151
20
MHz 40
MHz Tx
ATx
BTotal
Power Tx
ATx
BTotal
Power Tx
ATx
BTotal
Power Tx
ATx
BTotal
Power
2412 1 3 17 OFF 17 17 OFF 17 14 14 17 14 14 17
2417 2 4 17 OFF 17 17 OFF 17 14 14 17 14 14 17
2422 3 5 17 OFF 17 17 OFF 17 14 14 17 14 14 17
2427 4 6 17 OFF 17 17 OFF 17 14 14 17 14 14 17
2432 53, 7 17 OFF 17 17 OFF 17 14 14 17 14 14 17
2437 64, 8 17 OFF 17 17 OFF 17 14 14 17 14 14 17
2442 75, 9 17 OFF 17 17 OFF 17 14 14 17 14 14 17
2447 86, 10 17 OFF 17 17 OFF 17 14 14 17 14 14 17
2452 97, 11 17 OFF 17 17 OFF 17 14 14 17 14 14 17
2457 10 817 OFF 17 17 OFF 17 14 14 17 14 14 17
2462 11 917 OFF 17 17 OFF 17 14 14 17 14 14 17
2467 12 10 17 OFF 17 17 OFF 17 14 14 17 14 14 17
2472 13 11 17 OFF 17 17 OFF 17 14 14 17 14 14 17
2484 – – – – – – – – – – – – – –
![](/img.php?id=899518&img=bg3a.png)
6-4
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-06
Chapter 6 Cisco Aironet 1250 Series Lightweight Access Points
Channels and Maximum Power Levels
Table 6-3 indicates the channel identifiers, channel center frequencies, and maximum power levels for
each channel allowed by the –E regulatory domain for a 2.4-GHz radio with up to 6-dBi antennas.
Table 6-3 Channels and Maximum Conducted Power in the –E Regulatory Domain with up to
6-dBi Antennas
Maximum Conducted Power Levels (dBm) in the –E Regulatory Domain for the 2.4-GHz Radio with up to 6-dBi
Antennas
Freq
(MHz)
Center
Channel
802.11b
Single Antenna
1 to 11 Mbps
802.11g
Single Antenna
6 to 54 Mbps
HT-20 MHz
Dual Antennas
M0 to M151
1. M0 to M15 corresponds to the Modulaton and Coding Schemes (MCS0 to MCS15). The MCS settings determine the number
of spatial streams, the modulation, the coding rate, and the data rate values.
HT-40 MHz
Dual Antennas
M0 to M151
20
MHz 40
MHz Tx
ATx
BTotal
Power Tx
ATx
BTotal
Power Tx
ATx
BTotal
Power Tx
ATx
BTotal
Power
2412 1 3 14 OFF 14 14 OFF 14 11 11 14 11 11 14
2417 2 4 14 OFF 14 14 OFF 14 11 11 14 11 11 14
2422 3 5 14 OFF 14 14 OFF 14 11 11 14 11 11 14
2427 4 6 14 OFF 14 14 OFF 14 11 11 14 11 11 14
2432 53, 7 14 OFF 14 14 OFF 14 11 11 14 11 11 14
2437 64, 8 14 OFF 14 14 OFF 14 11 11 14 11 11 14
2442 75, 9 14 OFF 14 14 OFF 14 11 11 14 11 11 14
2447 86, 10 14 OFF 14 14 OFF 14 11 11 14 11 11 14
2452 97, 11 14 OFF 14 14 OFF 14 11 11 14 11 11 14
2457 10 814 OFF 14 14 OFF 14 11 11 14 11 11 14
2462 11 914 OFF 14 14 OFF 14 11 11 14 11 11 14
2467 12 10 14 OFF 14 14 OFF 14 11 11 14 11 11 14
2472 13 11 14 OFF 14 14 OFF 14 11 11 14 11 11 14
2484 – – – – – – – – – – – – – –
![](/img.php?id=899518&img=bg3b.png)
6-5
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-06
Chapter 6 Cisco Aironet 1250 Series Lightweight Access Points Channels and Maximum Power Levels
Table 6-4 indicates the channel identifiers, channel center frequencies, and maximum power levels for
each channel allowed by the –E regulatory domain for a 2.4-GHz radio with up to 9-dBi antennas.
Table 6-4 Channels and Maximum Conducted Power in the –E Regulatory Domain with up to
9-dBi Antennas
Maximum Conducted Power Levels (dBm) in the –E Regulatory Domain for the 2.4-GHz Radio with up to 9-dBi
Antennas
Freq
(MHz)
Center
Channel
802.11b
Single Antenna
1 to 11 Mbps
802.11g
Single Antenna
6 to 54 Mbps
HT-20 MHz
Dual Antennas
M0 to M151
1. M0 to M15 corresponds to the Modulaton and Coding Schemes (MCS0 to MCS15). The MCS settings determine the
number of spatial streams, the modulation, the coding rate, and the data rate values.
HT-40 MHz
Dual Antennas
M0 to M151
20
MHz 40
MHz Tx
ATx
BTotal
Power Tx
ATx
BTotal
Power Tx
ATx
BTotal
Power Tx
ATx
BTotal
Power
2412 1 3 11 OFF 11 11 OFF 11 8 8 11 8 8 11
2417 2 4 11 OFF 11 11 OFF 11 8 8 11 8 8 11
2422 3 5 11 OFF 11 11 OFF 11 8 8 11 8 8 11
2427 4 6 11 OFF 11 11 OFF 11 8 8 11 8 8 11
2432 53, 7 11 OFF 11 11 OFF 11 8 8 11 8 8 11
2437 64, 8 11 OFF 11 11 OFF 11 8 8 11 8 8 11
2442 75, 9 11 OFF 11 11 OFF 11 8 8 11 8 8 11
2447 86, 10 11 OFF 11 11 OFF 11 8 8 11 8 8 11
2452 97, 11 11 OFF 11 11 OFF 11 8 8 11 8 8 11
2457 10 811 OFF 11 11 OFF 11 8 8 11 8 8 11
2462 11 911 OFF 11 11 OFF 11 8 8 11 8 8 11
2467 12 10 11 OFF 11 11 OFF 11 8 8 11 8 8 11
2472 13 11 11 OFF 11 11 OFF 11 8 8 11 8 8 11
2484 – – – – – – – – – – – – – –
![](/img.php?id=899518&img=bg3c.png)
6-6
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-06
Chapter 6 Cisco Aironet 1250 Series Lightweight Access Points
Channels and Maximum Power Levels
Table 6-5 indicates the channel identifiers, channel center frequencies, and maximum power levels for
each channel allowed by the –E regulatory domain for a 2.4-GHz radio with up to 10-dBi antennas.
Table 6-5 Channels and Maximum Conducted Power in the –E Regulatory Domain with up to
10-dBi Antennas
Maximum Conducted Power Levels (dBm) in the –E Regulatory Domain for the 2.4-GHz Radio with up to 10-dBi
Anetnnas
Freq
(MHz)
Center
Channel
802.11b
Single Antenna
1 to 11 Mbps
802.11g
Single Antenna
6 to 54 Mbps
HT-20 MHz
Dual Antennas
M0 to M151
1. M0 to M15 corresponds to the Modulaton and Coding Schemes (MCS0 to MCS15). The MCS settings determine the number
of spatial streams, the modulation, the coding rate, and the data rate values.
HT-40 MHz
Dual Antennas
M0 to M151
20
MHz 40
MHz Tx
ATx
BTotal
Power Tx
ATx
BTotal
Power Tx
ATx
BTotal
Power Tx
ATx
BTotal
Power
2412 1 3 8 OFF 8 8 OFF 8 5 5 8 5 5 8
2417 2 4 8 OFF 8 8 OFF 8 5 5 8 5 5 8
2422 3 5 8 OFF 8 8 OFF 8 5 5 8 5 5 8
2427 4 6 8 OFF 8 8 OFF 8 5 5 8 5 5 8
2432 53, 7 8OFF 8 8 OFF 8 5 5 8 5 5 8
2437 64, 8 8OFF 8 8 OFF 8 5 5 8 5 5 8
2442 75, 9 8OFF 8 8 OFF 8 5 5 8 5 5 8
2447 86, 10 8OFF 8 8 OFF 8 5 5 8 5 5 8
2452 97, 11 8OFF 8 8 OFF 8 5 5 8 5 5 8
2457 10 8 8 OFF 8 8 OFF 8 5 5 8 5 5 8
2462 11 9 8 OFF 8 8 OFF 8 5 5 8 5 5 8
2467 12 10 8OFF 8 8 OFF 8 5 5 8 5 5 8
2472 13 11 8OFF 8 8 OFF 8 5 5 8 5 5 8
2484 – – – – – – – – – – – – – –
![](/img.php?id=899518&img=bg3d.png)
6-7
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-06
Chapter 6 Cisco Aironet 1250 Series Lightweight Access Points Channels and Maximum Power Levels
Table 6-6 indicates the channel identifiers, channel center frequencies, and maximum power levels for
each channel allowed by the –P regulatory domain for a 2.4-GHz radio with up to 10-dBi antennas.
5 GHz Band (Draft IEEE 802.11n Version 2.0)
An improper combination of power level and antenna gain can result in equivalent isotropic radiated
power (EIRP) above the amount allowed per regulatory domain.
Table 6-6 Channels and Maximum Conducted Power in the –P Regulatory Domain with up to
10-dBi Antennas
Maximum Conducted Power Levels (dBm) in the –P Regulatory Domain for the 2.4 GHz Radio with up to 10 dBi
Antennas
Freq
(MHz)
Center
Channel
802.11b
Single Antenna
1 to 11 Mbps
802.11g
Single Antenna
6 to 54 Mbps
HT-20 MHz
Dual Antennas
M0 to M151
1. M0 to M15 corresponds to the Modulaton and Coding Schemes (MCS0 to MCS15). The MCS settings determine the number
of spatial streams, the modulation, the coding rate, and the data rate values.
HT-40 MHz
Dual Antennas
M0 to M151
20
MHz 40
MHz
Tx
ATx
BTotal
Powe
r
Tx
ATx
BTotal
Power Tx
ATx
BTotal
Power Tx
ATx
BTotal
Power
2412 1 3 14 OFF 14 17 OFF 17 14 14 17 14 14 17
2417 2 4 14 OFF 14 17 OFF 17 14 14 17 14 14 17
2422 3 5 14 OFF 14 17 OFF 17 14 14 17 14 14 17
2427 4 6 14 OFF 14 17 OFF 17 14 14 17 14 14 17
2432 53, 7 14 OFF 14 17 OFF 17 14 14 17 14 14 17
2437 64, 8 14 OFF 14 17 OFF 17 14 14 17 14 14 17
2442 75, 9 14 OFF 14 17 OFF 17 14 14 17 14 14 17
2447 86, 10 14 OFF 14 17 OFF 17 14 14 17 14 14 17
2452 97, 11 14 OFF 14 17 OFF 17 14 14 17 14 14 17
2457 10 814 OFF 14 17 OFF 17 14 14 17 14 14 17
2462 11 914 OFF 14 17 OFF 17 14 14 17 14 14 17
2467 12 10 14 OFF 14 17 OFF 17 14 14 17 14 14 17
2472 13 11 14 OFF 14 17 OFF 17 14 14 17 14 14 17
2484 14 – – – – – – – – – – – – –
![](/img.php?id=899518&img=bg3e.png)
6-8
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-06
Chapter 6 Cisco Aironet 1250 Series Lightweight Access Points
Channels and Maximum Power Levels
Table 6-7 indicates the channel identifiers, channel center frequencies, and maximum power levels for
each channel allowed by the –A regulatory domain for a 5-GHz radio with up to 6-dBi antennas.
Table 6-7 Channels and Maximum Conducted Power in the –A Regulatory Domain with up to
6-dBi Antennas
Maximum Conducted Power Levels (dBm) in the –A Regulatory Domain for the 5-GHz Radio with up to 6-dBi
Antennas
Channel
ID Freq
(MHz)
802.11a
Single Antenna
6 to 54 Mbps
HT-20 MHz
Dual Antennas
M0 to M151
1. M0 to M15 corresponds to the Modulaton and Coding Schemes (MCS0 to MCS15). The MCS settings determine the number
of spatial streams, the modulation, the coding rate, and the data rate values.
Duplicate
(2x20 MHz)
Single Antennas
6 Mbps
HT-40 MHz
Dual Antennas
M0 to M151
Tx
ATx
BTotal
Power Tx
ATx
BTotal
Power Tx
A––Tx
ATx
BTotal
Power
5150-5250 MHz
36 5180 14 OFF 14 11 11 14 11 – – 11 11 14
40 5200 14 OFF 14 11 11 14 11 – – 11 11 14
44 5220 14 OFF 14 11 11 14 11 – – 11 11 14
48 5240 14 OFF 14 11 11 14 11 – – 11 11 14
5250 to 5350 MHz
52 5260 17 OFF 17 17 17 20 17 – – 17 17 20
56 5280 17 OFF 17 17 17 20 17 – – 17 17 20
60 5300 17 OFF 17 17 17 20 11 – – 11 11 14
64 5320 17 OFF 17 17 17 20 11 – – 11 11 14
5470 to 5725 MHz
100 5500 17 OFF 17 17 17 20 14 – – 14 14 17
104 5520 17 OFF 17 17 17 20 14 – – 14 14 17
108 5540 17 OFF 17 17 17 20 17 – – 17 17 20
112 5560 17 OFF 17 17 17 20 17 – – 17 17 20
116 5580 17 OFF 17 17 17 20 – – – – – –
120 5600 – – – – – – – – – – – –
124 5620 – – – – – – – – – – – –
128 5640 – – – – – – – – – – – –
132 5660 17 OFF 17 17 17 20 17 – – 17 17 20
136 5680 17 OFF 17 17 17 20 17 – – 17 17 20
140 5700 17 OFF 17 17 17 20 – – – – – –
5725 to 5850 MHz
149 5745 17 OFF 17 17 17 20 17 – – 17 17 20
153 5765 17 OFF 17 17 17 20 17 – – 17 17 20
157 5785 17 OFF 17 17 17 20 17 – – 17 17 20
161 5805 17 OFF 17 17 17 20 17 – – 17 17 20
165 5825 17 OFF 17 17 17 20 – – – – – –
![](/img.php?id=899518&img=bg3f.png)
6-9
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-06
Chapter 6 Cisco Aironet 1250 Series Lightweight Access Points Channels and Maximum Power Levels
Table 6-8 indicates the channel identifiers, channel center frequencies, and maximum power levels for
each channel allowed by the –C regulatory domain for a 5-GHz radio with up to 6-dBi antennas.
Table 6-8 Channels and Maximum Conducted Power in the –C Regulatory Domain with up to
6-dBi Antennas
Maximum Conducted Power Levels (dBm) in the –C Regulatory Domain for a 5-GHz Radio with up to 6-dBi
Antennas
Channel
ID Freq
(MHz)
802.11a
Single Antenna
6 to 54 Mbps
HT-20 MHz
Dual Antennas
M0 to M151
1. M0 to M15 corresponds to the Modulaton and Coding Schemes (MCS0 to MCS15). The MCS settings determine the
number of spatial streams, the modulation, the coding rate, and the data rate values.
Duplicate
(2x20 MHz)
Dual Antennas
6 Mbps
HT-40 MHz
Dual Antennas
M0 to M151
Tx
ATx
BTotal
Power Tx
ATx
BTotal
Power Tx
A––Tx
ATx
BTotal
Power
UNII-1 (5150-5250 MHz)
36 5180 ––––––––––––
40 5200 ––––––––––––
44 5220 ––––––––––––
48 5240 ––––––––––––
5250 to 5350 MHz
52 5260 ––––––––––––
56 5280 ––––––––––––
60 5300 ––––––––––––
64 5320 ––––––––––––
5470 to 5725 MHz
100 5500 ––––––––––––
104 5520 ––––––––––––
108 5540 ––––––––––––
112 5560 ––––––––––––
116 5580 ––––––––––––
120 5600 ––––––––––––
124 5620 ––––––––––––
128 5640 ––––––––––––
132 5660 ––––––––––––
136 5680 ––––––––––––
140 5700 ––––––––––––
5725 to 5850 MHz
149 5745 17 OFF 17 17 17 20 17 – – 17 17 20
153 5765 17 OFF 17 17 17 20 17 – – 17 17 20
157 5785 17 OFF 17 17 17 20 17 – – 17 17 20
161 5805 17 OFF 17 17 17 20 17 – – 17 17 20
165 5825 17 OFF 17 17 17 20 – – – – – –
![](/img.php?id=899518&img=bg40.png)
6-10
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points OL-11321-06
Chapter 6 Cisco Aironet 1250 Series Lightweight Access Points
Channels and Maximum Power Levels
Table 6-9 indicates the channel identifiers, channel center frequencies, and maximum power levels for
each channel allowed by the –E regulatory domain for a 5-GHz radio with up to 6-dBi antennas.
Table 6-9 Channels and Maximum Conducted Power in the –E Regulatory Domain with
up to 6-dBi Antennas
Maximum Conducted Power Levels (dBm) in the –E Regulatory Domain for the 5-GHz Radio with up to 6-dBi
Antennas
Channel
ID Freq
(MHz)
802.11a
Single Antenna
6 to 54 Mbps
HT-20 MHz
Dual Antennas
M0 to M151
1. M0 to M15 corresponds to the Modulaton and Coding Schemes (MCS0 to MCS15). The MCS settings determine the
number of spatial streams, the modulation, the coding rate, and the data rate values.
Duplicate
(2x20 MHz)
Dual Antennas
6 Mbps
HT-40 MHz
Dual Antennas
M0 to M151
Tx
ATx
BTotal
Power Tx
ATx
BTotal
Power Tx
A––Tx
ATx
BTotal
Power
UNII-1 (5150-5250 MHz)
36 5180 17 OFF 17 14 14 17 14 – – 14 14 17
40 5200 17 OFF 17 14 14 17 14 – – 14 14 17
44 5220 17 OFF 17 14 14 17 14 – – 14 14 17
48 5240 17 OFF 17 14 14 17 14 – – 14 14 17
5250 to 5350 MHz
52 5260 17 OFF 17 14 14 17 14 – – 14 14 17
56 5280 17 OFF 17 14 14 17 14 – – 14 14 17
60 5300 17 OFF 17 14 14 17 14 – – 14 14 17
64 5320 17 OFF 17 14 14 17 14 – – 14 14 17
5470 to 5725 MHz
100 5500 17 OFF 17 17 17 20 17 – – 17 17 20
104 5520 17 OFF 17 17 17 20 17 – – 17 17 20
108 5540 17 OFF 17 17 17 20 17 – – 17 17 20
112 5560 17 OFF 17 17 17 20 17 – – 17 17 20
116 5580 17 OFF 17 17 17 20 17 – – 17 17 20
120 5600 17 OFF 17 17 17 20 17 – – 17 17 20
124 5620 17 OFF 17 17 17 20 17 – – 17 17 20
128 5640 17 OFF 17 17 17 20 17 – – 17 17 20
132 5660 17 OFF 17 17 17 20 17 – – 17 17 20
136 5680 17 OFF 17 17 17 20 17 – – 17 17 20
140 5700 17 OFF 17 17 17 20 – –
5725 to 5850 MHz
149 5745 – – – – – – – – – – – –
153 5765 – – – – – – – – – – – –
157 5785 – – – – – – – – – – – –
161 5805 – – – – – – – – – – – –
165 5825 – – – – – – – – – – – –
![](/img.php?id=899518&img=bg41.png)
6-11
Channels and Maximum Power Settings for Cisco Aironet Lightweight Access Points
OL-11321-06
Chapter 6 Cisco Aironet 1250 Series Lightweight Access Points Channels and Maximum Power Levels
Table 6-10 indicates the channel identifiers, channel center frequencies, and maximum power levels for
each channel allowed by the –I regulatory domain for a 5-GHz radio with up to 6-dBi antenna.s
Table 6-10 Channels and Maximum Conducted Power in the –I Regulatory Domain with up to
6-dBi Antennas
Maximum Conducted Power Levels (dBm) in the –I Regulatory Domain for a 5-GHz Radio with up to 6-dBi
Antennas
Channel
ID Freq
(MHz)
802.11a
Single Antenna
6 to 54 Mbps
HT-20 MHz
Dual Antennas
M0 to M151
1. M0 to M15 corresponds to the Modulaton and Coding Schemes (MCS0 to MCS15). The MCS settings determine the
number of spatial streams, the modulation, the coding rate, and the data rate values.
Duplicate
(2x20 MHz)
Dual Antennas
6 Mbps
HT-40 MHz
Dual Antennas
M0 to M151
Tx
ATx
BTotal
Power Tx
ATx
BTotal
Power Tx
A––Tx
ATx
BTotal
Power
UNII-1 (5150-5250 MHz)
36 5180 17 OFF 17 14 14 17 14 – – 14 14 17
40 5200 17 OFF 17 14 14 17 14 – – 14 14 17
44 5220 17 OFF 17 14 14 17 14 – – 14 14 17
48 5240 17 OFF 17 14 14 17 14 – – 14 14 17
5250 to 5350 MHz
52 5260 17 OFF 17 14 14 17 14 – – 14 14 17
56 5280 17 OFF 17 14 14 17 14 – – 14 14 17
60 5300 17 OFF 17 14 14 17 14 – – 14 14 17
64 5320 17 OFF 17 14 14 17 14 – – 14 14 17
5470 to 5725 MHz
100 5500 ––––––––––––
104 5520 ––––––––––––
108 5540 ––––––––––––
112 5560 ––––––––––––
116 5580 ––––––––––––
120 5600 ––––––––––––
124 5620 ––––––––––––
128 5640 ––––––––––––
132 5660 ––––––––––––
136 5680 ––––––––––––
140 5700 ––––––––––––
5725 to 5850 MHz
149 5745 ––––––––––––
153 5765 ––––––––––––
157 5785 ––––––––––––
161 5805 ––––––––––––
165 5825 ––––––––––––
