Cisco Systems WRP501156 Dual Band Wireless Broadband Router User Manual
Cisco Systems Inc Dual Band Wireless Broadband Router
Contents
- 1. User Manual 1
- 2. User Manual 2
User Manual 2
REVIEW DRAFT - CISCO CONFIDENTIAL
Regulatory Compliance and Safety InformationCisco WRP500
Wireless-G Broadband Router with 2 Phone Ports
Information sur la réglementation de la conformité et de
sécuritéCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
First Published: December 15, 2014
Première publication: 15 Décembre 2014
Last Updated: December 19, 2014
Dernière mise à jour: 19 Décembre 2014
Cisco Systems, Inc.
www.cisco.com
Cisco has more than 200 offices worldwide. Addresses, phone numbers, and fax numbers are listed on the
Cisco website at www.cisco.com/go/offices.
Cisco possède plus de 200 bureaux dans le monde entier. Adresses, numéros de téléphone et numéros de fax
sont répertoriés sur le site Web de Cisco à l' www.cisco.com/go/offices.
RCSI Part Number: RCSI-0144
RCSI Numéro de pièce : RCSI-0144
CONTENTS
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2
Phone Ports 1
Gesetzliche Auflagen und SicherheitshinweiseCisco WRP500 Wireless-G Broadband Router with 2
Phone Ports 9
Cumplimiento de las normas e información de seguridadCisco WRP500 Wireless-G Broadband Router
with 2 Phone Ports 15
Säädösten noudattaminen ja turvallisuustiedotCisco WRP500 Wireless-G Broadband Router with 2
Phone Ports 23
Informations relatives à la conformité et à la sécuritéCisco WRP500 Wireless-G Broadband Router
with 2 Phone Ports 29
A szabályozásnak való megfelelésre és a biztonságra vonatkozó információkCisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports 37
Informazioni sulla conformità alle normative e sulla sicurezzaCisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports 43
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports 49
Informasjon om forskriftsmessig samsvar og sikkerhetCisco WRP500 Wireless-G Broadband Router
with 2 Phone Ports 55
Regelnaleving en veiligheidsinformatieCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports 61
Regulamentação de Conformidade e Informações de SegurançaCisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports 67
Cisco WRP500
Wireless-G Broadband Router with 2 Phone Ports 73
Information om överensstämmelse med regelverk och säkerhetskravCisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports 79
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports 85
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports 91
Cisco WRP500
Wireless-G Broadband Router with 2 Phone Ports 95
Informace o bezpenosti a dodrování pedpisCisco WRP500 Wireless-G Broadband Router with 2
Phone Ports 97
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
iii
Overholdelse af lovgivningen og sikkerhedsoplysningerCisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports 101
Cisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports 105
Eeskirjade järgimine ja ohutusteaveCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports 109
reglufylgni og öryggisupplýsingarCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports 111
reglamentinei atitikties ir saugos informacijaiCisco WRP500 Wireless-G Broadband Router with
2 Phone Ports 113
Atbilstba normatviem un informcija par drobuCisco WRP500 Wireless-G Broadband Router
with 2 Phone Ports 115
Konformità mar-Regolamenti u Informazzjoni Dwar is-SigurtàCisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports 117
Informacje o zgodnoci i bezpieczestwieCisco WRP500 Wireless-G Broadband Router with 2
Phone Ports 119
Informaii referitoare la siguran i conformitatea cu reglementrileCisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports 123
Dodriavanie predpisov a bezpenostné informácieCisco WRP500 Wireless-G Broadband Router
with 2 Phone Ports 125
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports 129
Informacije o skladnosti s predpisi in varnostiCisco WRP500 Wireless-G Broadband Router with
2 Phone Ports 133
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports Regulatory
Compliance 135
Usklaenost sa propisima i informacije o sigurnostiCisco WRP500 Wireless-G Broadband Router
with 2 Phone Ports 137
Cisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports 139
Conformidade regulamentar e informações de segurançaCisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports 143
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
iv
Contents
REVIEW DRAFT - CISCO CONFIDENTIAL
CHAPTER 1
Regulatory Compliance and Safety
InformationCisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports
Statement 19TN Power Warning, page 2
Statement 157VCCI Compliance for Class B Equipment, page 3
Statement 199Emergency Access Warning, page 3
Statement 287Declaration of Conformity to R&TTE Directive 1999/5/EC for the European Community,
Switzerland, Norway, Iceland and Liechtenstein, page 3
Statement 295Class B Warning for Korea, page 3
Statement 331Power Supply Installation Warning, page 3
Statement 353This Product Must be Connected, page 4
Statement 355Telephone Receivers Produce a Magnetic Field, page 4
Statement 361VoIP and Emergency Calling Services do not Function if Power Fails, page 4
Statement 378Read Wall-Mounting Instructions Before Installation, page 4
Statement 1003DC Power Disconnection, page 4
Statement 1004Installation Instructions, page 5
Statement 1005Circuit Breaker, page 5
Statement 1019Main Disconnecting Device, page 5
Statement 1021SELV Circuit, page 5
Statement 1030Equipment Installation, page 5
Statement 1040Product Disposal, page 5
Statement 1044Port Connections, page 6
Statement 1071Warning Definition, page 6
Statement 1072Shock Hazard from Interconnections, page 6
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
1
Statement 1073No User-Serviceable Parts, page 6
Statement 1074Comply with Local and National Electrical Codes, page 7
Statement 2018Class B Notice for FCC, page 7
Statement 2022Class B Notice for Canada, page 7
Statement 3015CS-03 Certification for Canada, page 7
Statement 4008Devices Operating in the 51505250 MHz Band, page 8
Statement 4009Devices Operating in the 5 GHz DFS Bands, page 8
Statement 4043Caution U-NII Devices are Restricted, page 8
Statement 4046Canada Health Code 6, page 8
This document uses the following conventions:
Means reader be careful. In this situation, you might perform an action that could result in equipment damage
or loss of data.
Caution
IMPORTANT SAFETY INSTRUCTIONS
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any
equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for
preventing accidents. Use the statement number provided at the end of each warning to locate its translation in
the translated safety warnings that accompanied this device.
SAVE THESE INSTRUCTIONS
Warning
Statements using this symbol are provided for additional information and to comply with regulatory and customer
requirements.
Warning
Statement 19TN Power Warning
The device is designed to work with TN power systems.
Warning
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
2
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 157VCCI Compliance for Class B Equipment
This is a Class B product based on the standard of the VCCI Council. If this is used near a radio or television receiver
in a domestic environment, it may cause radio interference. Install and use the equipment according to the
instruction manual. VCCI-B
Warning
Statement 199Emergency Access Warning
This equipment is not designed for making emergency telephony calls when the power fails. Alternative
arrangements should be made for access to emergency services. Access to emergency services can be affected
by any call-barring function of this equipment.
Warning
Statement 287Declaration of Conformity to R&TTE Directive
1999/5/EC for the European Community, Switzerland, Norway,
Iceland and Liechtenstein
This equipment is in compliance with the essential requirements and other relevant provisions of Directive
1999/5/EC.
Note
Statement 295Class B Warning for Korea
This is a Class B Device and is registered for EMC requirements for residential use. This device can be used not
only in residential areas but in all other areas.
Warning
Statement 331Power Supply Installation Warning
The power supply must be placed indoors.
Warning
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
3
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 353This Product Must be Connected
This product must be connected to a power-over-ethernet (PoE) IEEE802.3af compliant power source or an IEC60950
compliant limited power source.
Warning
Statement 355Telephone Receivers Produce a Magnetic Field
Telephone receivers produce a magnetic field that can attract small magnetic objects such as pins and staples.
To avoid the possibility of injury, do not place the handset where such objects may be picked up.
Warning
Statement 361VoIP and Emergency Calling Services do not
Function if Power Fails
Voice over IP (VoIP) service and the emergency calling service do not function if power fails or is disrupted. After
power is restored, you might have to reset or reconfigure equipment to regain access to VoIP and the emergency
calling service. In the USA, this emergency number is 911. You need to be aware of the emergency number in your
country.
Warning
Statement 378Read Wall-Mounting Instructions Before
Installation
Read the wall-mounting instructions carefully before beginning installation. Failure to use the correct hardware
or to follow the correct procedures could result in a hazardous situation to people and damage to the system.
Warning
Statement 1003DC Power Disconnection
Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Warning
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
4
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1004Installation Instructions
Read the installation instructions before connecting the system to the power source.
Warning
Statement 1005Circuit Breaker
This product relies on the building s installation for short-circuit (overcurrent) protection. Ensure that the protective
device is rated not greater than:
Warning
Statement 1019Main Disconnecting Device
The plug-socket combination must be accessible at all times, because it serves as the main disconnecting device.
Warning
Statement 1021SELV Circuit
To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to telephone-network voltage
(TNV) circuits. LAN ports contain SELV circuits, and WAN ports contain TNV circuits. Some LAN and WAN ports
both use RJ-45 connectors. Use caution when connecting cables.
Warning
Statement 1030Equipment Installation
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Warning
Statement 1040Product Disposal
Ultimate disposal of this product should be handled according to all national laws and regulations.
Warning
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
5
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1044Port Connections
For connections outside the building where the equipment is installed, the following ports must be connected
through an approved network termination unit with integral circuit protection.
Warning
Statement 1071Warning Definition
IMPORTANT SAFETY INSTRUCTIONS
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any
equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for
preventing accidents. Use the statement number provided at the end of each warning to locate its translation in
the translated safety warnings that accompanied this device.
SAVE THESE INSTRUCTIONS
Warning
Statement 1072Shock Hazard from Interconnections
Voltages that present a shock hazard may exist on Power over Ethernet (PoE) circuits if interconnections are made
using uninsulated exposed metal contacts, conductors, or terminals. Avoid using such interconnection methods,
unless the exposed metal parts are located within a restricted access location and users and service people who
are authorized within the restricted access location are made aware of the hazard. A restricted access area can
be accessed only through the use of a special tool, lock and key or other means of security.
Warning
Statement 1073No User-Serviceable Parts
No user-serviceable parts inside. Do not open.
Warning
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
6
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1074Comply with Local and National Electrical
Codes
Installation of the equipment must comply with local and national electrical codes.
Warning
Statement 2018Class B Notice for FCC
Modifying the equipment without Cisco?s authorization may result in the equipment no longer complying
with FCC requirements for Class B digital devices. In that event, your right to use the equipment may be
limited by FCC regulations, and you may be required to correct any interference to radio or television
communications at your own expense.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
?Reorient or relocate the receiving antenna.
?Increase the separation between the equipment and receiver.
?Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
?Consult the dealer or an experienced radio/TV technician for help.
Statement 2022Class B Notice for Canada
This Class B digital apparatus complies with Canadian ICES-003.
Statement 3015CS-03 Certification for Canada
This product meets the applicable Industry Canada technical specifications
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
7
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 4008Devices Operating in the 51505250 MHz Band
The band 5150-5250 MHz is only for indoor usage to reduce potential for harmful interference to co-channel
mobile satellite systems.
Statement 4009Devices Operating in the 5 GHz DFS Bands
Caution: high-power radars are allocated as primary users (meaning they have priority) of the bands 5250-5350
MHz and 5650-5850 MHz and these radars could cause interference and/or damage to LE-LAN devices
Caution
Statement 4043Caution U-NII Devices are Restricted
Within the 5.47 to 5.75 GHz band the U-NII devices are restricted to indoor operations to reduce any potential
for harmful interference to weather radar at this time. Further no operation in the 5600-5650MHz band is
allowed at this time.
Caution
Statement 4046Canada Health Code 6
The radio has been evaluated in accordance with RSS-102 addressing RF Exposure from radio frequency
devices and the product meets the requirements of Canada Health Code 6. To maintain compliance, the
minimum separation distance from the antenna to general bystander is 20cm.
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
8
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
KAPITEL 2
Gesetzliche Auflagen und
SicherheitshinweiseCisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports
Statement 19 TN-Stromsysteme, Seite 10
Statement 199Kontaktieren von Notfalldiensten, Seite 10
Statement 287Konformitätserklärung zur R & TTE-Richtlinie 1999/5/EG für die Europäische
Gemeinschaft, die Schweiz, Norwegen, Island und Liechtenstein, Seite 11
Statement 331Stromversorgungsinstallation, Seite 11
Statement 353Dieses Produkt muss an eine Stromquelle angeschlossen sein, Seite 11
Statement 355Telefonhörer erzeugen Magnetfeld, Seite 11
Statement 361VoIP- und Notrufdienste bei Stromausfall nicht nutzbar, Seite 12
Statement 378Anweisungen zur Installierung vor Wandmontage sorgfältig durchlesen, Seite 12
Statement 1003Trennen der Gleichstromverbindung, Seite 12
Statement 1004Installationsanweisungen, Seite 12
Statement 1005Leistungsschutzschalter, Seite 12
Statement 1019Primäre Ausschaltvorrichtung, Seite 13
Statement 1021Sicherheits-Kleinspannungs-Stromkreise (SELV-Stromkreis), Seite 13
Statement 1030Installation der Ausrüstung, Seite 13
Statement 1040Produktentsorgung, Seite 13
Statement 1044Anschlussverbindungen, Seite 13
Statement 1071Definition von Warnhinweisen, Seite 14
Statement 1072SStromschlaggefahr beim Herstellen von Verbindungen, Seite 14
Statement 1073Keine vom Benutzer zu wartenden Teile, Seite 14
Statement 1074Lokale und nationale Sicherheitsstandards für Elektroinstallationen, Seite 14
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
9
In dieser Veröffentlichung werden folgende Konventionen verwendet:
Bedeutet: Bitte vorsichtig sein. In dieser Situation kann eine Vorgehensweise möglicherweise zu Schäden an
den Geräten oder zu einem Datenverlust führen.
Vorsicht
WICHTIGE SICHERHEITSHINWEISE
Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich möglicherweise in einer Situation, in der es zu körperlichen
Verletzungen kommen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen
und den üblichen Verfahren zur Vorbeugung von Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung
angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen,
die zusammen mit diesem Gerät ausgeliefert wurden.
BEWAHREN SIE DIESE ANWEISUNGEN SICHER AUF.
Warnung
Anweisungen mit diesem Symbol sollen zusätzliche Informationen bieten und sind mit der Erfüllung bestimmter
Auflagen und Kundenanforderungen verbunden.
Warnung
Statement 19 TN-Stromsysteme
Das Gerät ist für die Verwendung mit TN-Stromsystemen ausgelegt.
Warnung
Statement 199Kontaktieren von Notfalldiensten
Dieses Gerät ist nicht geeignet für Notruftelefonate, wenn die Stromzufuhr ausfällt. Für das Kontaktieren von
Notfalldiensten sollten alternative Maßnahmen geplant werden. Das Kontaktieren von Notfalldiensten kann von
jeder der anrufsperrenden Funktionen dieses Gerätes beeinträchtigt werden.
Warnung
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
10
Gesetzliche Auflagen und SicherheitshinweiseCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 287Konformitätserklärung zur R & TTE-Richtlinie
1999/5/EG für die Europäische Gemeinschaft, die Schweiz,
Norwegen, Island und Liechtenstein
Dieses Gerät entspricht den grundlegenden Anforderungen und den weiteren entsprechenden Vorgaben der
Richtlinie 1999/5/EU.
Hinweis
Statement 331Stromversorgungsinstallation
Die Stromversorgungsquelle darf nicht im Freien aufgestellt werden.
Warnung
Statement 353Dieses Produkt muss an eine Stromquelle
angeschlossen sein
This product must be connected to a power-over-ethernet (PoE) IEEE802.3af compliant power source or an IEC60950
compliant limited power source.
Warnung
Statement 355Telefonhörer erzeugen Magnetfeld
Telephone receivers produce a magnetic field that can attract small magnetic objects such as pins and staples.
To avoid the possibility of injury, do not place the handset where such objects may be picked up.
Warnung
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
11
Gesetzliche Auflagen und SicherheitshinweiseCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 361VoIP- und Notrufdienste bei Stromausfall nicht
nutzbar
Voice over IP (VoIP) service and the emergency calling service do not function if power fails or is disrupted. After
power is restored, you might have to reset or reconfigure equipment to regain access to VoIP and the emergency
calling service. In the USA, this emergency number is 911. You need to be aware of the emergency number in your
country.
Warnung
Statement 378Anweisungen zur Installierung vor
Wandmontage sorgfältig durchlesen
Read the wall-mounting instructions carefully before beginning installation. Failure to use the correct hardware
or to follow the correct procedures could result in a hazardous situation to people and damage to the system.
Warnung
Statement 1003Trennen der Gleichstromverbindung
Vor Ausführung der folgenden Vorgänge ist sicherzustellen, daß die Gleichstromschaltung keinen Strom erhält.
Warnung
Statement 1004Installationsanweisungen
Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen.
Warnung
Statement 1005Leistungsschutzschalter
Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist.
Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als:
Warnung
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
12
Gesetzliche Auflagen und SicherheitshinweiseCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1019Primäre Ausschaltvorrichtung
Der Netzkabelanschluß am Gerät muß jederzeit zugänglich sein, weil er als primäre Ausschaltvorrichtung dient.
Warnung
Statement 1021Sicherheits-Kleinspannungs-Stromkreise
(SELV-Stromkreis)
Zur Vermeidung von Elektroschock die Sicherheits-Kleinspannungs-Stromkreise (SELV-Kreise) nicht an
Fernsprechnetzspannungs-Stromkreise (TNV-Kreise) anschließen. LAN-Ports enthalten SELV-Kreise, und WAN-Ports
enthalten TNV-Kreise. Einige LAN- und WAN-Ports verwenden auch RJ-45-Steckverbinder. Vorsicht beim
Anschließen von Kabeln.
Warnung
Statement 1030Installation der Ausrüstung
Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet
werden.
Warnung
Statement 1040Produktentsorgung
Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen.
Warnung
Statement 1044Anschlussverbindungen
Für Verbindungen außerhalb des Gebäudes, in dem das Gerät installiert ist, müssen die folgenden Anschlüsse
über eine zulässige Netzabschlusseinheit mit integralem Leitungsschutz verbunden werden. cs-1044-1
Warnung
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
13
Gesetzliche Auflagen und SicherheitshinweiseCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1071Definition von Warnhinweisen
WICHTIGE SICHERHEITSHINWEISE
Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich möglicherweise in einer Situation, in der es zu körperlichen
Verletzungen kommen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen
und den üblichen Verfahren zur Vorbeugung von Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung
angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen,
die zusammen mit diesem Gerät ausgeliefert wurden.
BEWAHREN SIE DIESE ANWEISUNGEN SICHER AUF.
Warnung
Statement 1072SStromschlaggefahr beim Herstellen von
Verbindungen
Bei Power-over-Ethernet-(PoE-)Schaltkreisen besteht u.U. Stromschlaggefahr, wenn Verbindungen unter
Verwendung nicht isolierter, freiliegender Metallkontakte, Leiter oder Anschlussklemmen hergestellt werden.
Vermeiden Sie das Herstellen solcher Verbindungen, es sei denn, die freiliegenden Metallteile befinden sich an
Orten mit beschränktem Zugang, und Personen, die Zugang dazu haben, sind ausdrücklich über diese Gefahr
informiert worden. Ein Ort mit beschränktem Zugang ist nur mit Hilfe eines speziellen Werkzeugs, Schloss und
Schlüssels oder anderen Sicherheitseinrichtungen zugänglich.
Warnung
Statement 1073Keine vom Benutzer zu wartenden Teile
Enthält keine Teile, die vom Benutzer gewartet werden müssen. Bitte nicht öffnen.
Warnung
Statement 1074Lokale und nationale Sicherheitsstandards
für Elektroinstallationen
Die Installation der Geräte muss den Sicherheitsstandards entsprechen.
Warnung
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
14
Gesetzliche Auflagen und SicherheitshinweiseCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
CAPÍTULO 3
Cumplimiento de las normas e información de
seguridadCisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports
Statement 19 Advertencia sobre alimentación de TN, página 16
Statement 199Advertencia sobre acceso de emergencia, página 16
Statement 287Declaración de conformidad de R & TTE 1999/5/CE de la Comunidad Europea, Suiza,
Noruega, Islandia y Liechtenstein, página 17
Statement 331Advertencia sobre la instalación de la fuente de alimentación, página 17
Statement 353Se debe conectar este producto, página 17
Statement 355Los receptores telefónicos generan un campo magnético, página 17
Statement 361Los servicios de llamada de emergencia y voz sobre IP (VoIP) no funcionan si se
produce un fallo en la alimentación, página 18
Statement 378Lea las instrucciones de montaje en pared antes de la instalación, página 18
Statement 1003Desconexión de la alimentación de CC, página 18
Statement 1004Instrucciones de instalación, página 18
Statement 1005Disyuntor, página 19
Statement 1019Dispositivo de desconexión principal, página 19
Statement 1021SELV Circuito, página 19
Statement 1030Instalación del equipo, página 19
Statement 1040Desecho de productos, página 19
Statement 1044Conexiones de puertos, página 20
Statement 1071Definición de advertencia, página 20
Statement 1072Peligro de descarga de las interconexiones, página 20
Statement 1073El usuario no puede reparar ninguna pieza, página 20
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
15
Statement 1074Cumple con los códigos eléctricos nacionales y regionales, página 21
En este documento se utilizan las siguientes convenciones:
Significa que el lector debe tener precaución. En esta situación, es posible que realice alguna acción que
provoque daños en el equipo o la pérdida de datos.
Precaución
INSTRUCCIONES DE SEGURIDAD IMPORTANTES
Este símbolo de advertencia indica peligro. Puede sufrir lesiones físicas. Antes de manipular cualquier equipo,
debe ser consciente de los peligros que entraña la corriente eléctrica y familiarizarse con los procedimientos
estándar de prevención de accidentes. Utilice el número de advertencia que aparece al final de cada una para
localizar su traducción en las advertencias de seguridad que acompañan a este dispositivo.
GUARDE ESTAS INSTRUCCIONES
Advertencia
Las declaraciones que utilizan este símbolo se incluyen para aportar información adicional y cumplir con los
requisitos legales y de los clientes.
Advertencia
Statement 19 Advertencia sobre alimentación de TN
El equipo está diseñado para trabajar con sistemas de alimentación tipo TN.
Advertencia
Statement 199Advertencia sobre acceso de emergencia
Este equipo no está diseñado para efectuar llamadas telefónicas de emergencia en caso de que falle la alimentación.
Se deberán tomar medidas alternativas para acceder a servicios de emergencia. El acceso a servicios de
emergencia puede verse afectado por cualquier función de bloqueo de lamadas que pueda tener este equipo.
Advertencia
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
16
Cumplimiento de las normas e información de seguridadCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 287Declaración de conformidad de R & TTE
1999/5/CE de la Comunidad Europea, Suiza, Noruega, Islandia
y Liechtenstein
Este equipo cumple con los requisitos esenciales asi como con otras disposiciones de la Directiva 1999/5/CE.Nota
Statement 331Advertencia sobre la instalación de la fuente
de alimentación
El suministro de energía debe estar ubicado en un lugar cubierto y no al aire libre.
Advertencia
Statement 353Se debe conectar este producto
Debe conectar este producto a una fuente de alimentación en Ethernet (PoE) conforme con el estándar IEEE 802.3af,
o a una fuente limitada conforme con el estándar IEC60950.
Advertencia
Statement 355Los receptores telefónicos generan un campo
magnético
Los receptores telefónicos producen un campo magnético que puede atraer objetos pequeños, como alfileres o
grapas. Para evitar posibles lesiones, no coloque el aparato cerca de objetos de este tipo.
Advertencia
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
17
Cumplimiento de las normas e información de seguridadCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 361Los servicios de llamada de emergencia y voz
sobre IP (VoIP) no funcionan si se produce un fallo en la
alimentación
El servicio de voz sobre IP (VoIP) y el de llamadas de emergencia no funcionan si se interrumpe el suministro de
energía. Tras recuperar el suministro es posible que deba que restablecer o volver a configurar el equipo para
tener acceso a los servicios de VoIP y de llamadas de emergencia. En Estados Unidos el número de emergencia
es el 911. Asegúrese de obtener el número de emergencia en su país.
Advertencia
Statement 378Lea las instrucciones de montaje en pared
antes de la instalación
Lea atentamente las instrucciones que se encuentran en la pared antes de comenzar con la instalación. Si no
utiliza el hardware correcto o no sigue los procedimientos correctos se podría producir una situación peligrosa
para las personas y daños al sistema.
Advertencia
Statement 1003Desconexión de la alimentación de CC
Antes de proceder con los siguientes pasos, comprobar que la alimentación del circuito de corriente continua
(CC) esté cortada (OFF).
Advertencia
Statement 1004Instrucciones de instalación
Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación..
Advertencia
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
18
Cumplimiento de las normas e información de seguridadCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1005Disyuntor
Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio. Asegúrese de
que el dispositivo de protección no sea superior a:
Advertencia
Statement 1019 Dispositivo de desconexión principal
El conjunto de clavija y toma ha de encontrarse siempre accesible ya que hace las veces de dispositivo de
desconexión principal.
Advertencia
Statement 1021SELV Circuito
Para evitar una descarga eléctrica , no conecte los circuitos de seguridad muy baja tensión ( SELV ) a los circuitos
de voltaje de red telefónica (TNV).Los puertos LAN contienen circuitos SELV y los puertos WAN contienen circuitos
VRT. Algunos puertos LAN y WAN utilizan conectores RJ-45.Tenga cuidado al conectar los cables.
Advertencia
Statement 1030Instalación del equipo
Solamente el personal calificado debe instalar, reemplazar o utilizar este equipo.
Advertencia
Statement 1040Desecho de productos
Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales.
Advertencia
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
19
Cumplimiento de las normas e información de seguridadCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1044Conexiones de puertos
Para realizar conexiones en el exterior del edificio en el que esté instalado el equipo, deberá conectar los puertos
especificados a continuación a una unidad terminal de red aprobada que cuente con protección de circuitos
integrales.cs-1044-1
Advertencia
Statement 1071Definición de advertencia
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
Este símbolo de aviso indica peligro. Existe riesgo para su integridad física. Antes de manipular cualquier equipo,
considere los riesgos de la corriente eléctrica y familiarícese con los procedimientos estándar de prevención de
accidentes. Al final de cada advertencia encontrará el número que le ayudará a encontrar el texto traducido en
el apartado de traducciones que acompaña a este dispositivo.
GUARDE ESTAS INSTRUCCIONES
Advertencia
Statement 1072Peligro de descarga de las interconexiones
Puede haber voltajes con riesgo de shock en circuitos de alimentación sobre el cableado Ethernet (PoE), si para
las interconexiones se utilizan contactos, conductores o terminales metálicos descubiertos. Evite tales métodos
de interconexión, a menos que las partes metálicas descubiertas se encuentren en un lugar de acceso restringido
y tanto los usuarios como el personal de servicios en dicho lugar sean conscientes de la existencia de tal riesgo.
Sólo se puede tener acceso a una zona de acceso restringido mediante el uso de una herramienta especial, un
candado y una llave u otros medios de seguridad.
Advertencia
Statement 1073El usuario no puede reparar ninguna pieza
No contiene partes que puedan ser arregladas por el usuario. No abrir.
Advertencia
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
20
Cumplimiento de las normas e información de seguridadCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1074Cumple con los códigos eléctricos nacionales
y regionales
La instalación del equipo debe cumplir con las normativas de electricidad locales y nacionales.
Advertencia
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
21
Cumplimiento de las normas e información de seguridadCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
22
Cumplimiento de las normas e información de seguridadCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
LUKU 4
Säädösten noudattaminen ja
turvallisuustiedotCisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports
Statement 19 TN-virtajärjestelmää koskeva varoitus, sivu 24
Statement 199Hätäpalvelujen käyttöä koskeva varoitus, sivu 24
Statement 287Vaatimustenmukaisuusvakuutus R & TTE-direktiivin 1999/5/EY Euroopan yhteisön,
Sveitsi, Norja, Islanti ja Liechtenstein, sivu 25
Statement 331Virtalähteen asentamista koskeva varoitus, sivu 25
Statement 353Tämä tuote on kytkettävä, sivu 25
Statement 355Puhelinvastaanottimien ympärille muodostuu magneettikenttä, sivu 25
Statement 361VoIP- ja hätäpuhelupalvelut eivät toimi, jos virta katkeaa, sivu 26
Statement 378Lue seinäkiinnitysohjeet ennen asentamista, sivu 26
Statement 1003Tasavirtasyötön katkaisu, sivu 26
Statement 1004Asennusohjeet, sivu 26
Statement 1005Piirikatkaisin, sivu 26
Statement 1019Pääkatkaisumekanismi, sivu 27
Statement 1021SELV-piiri, sivu 27
Statement 1030Laitteen asentaminen, sivu 27
Statement 1040Tuotteen hävittäminen, sivu 27
Statement 1044Porttien kytkeminen, sivu 27
Statement 1071Varoitukset, sivu 28
Statement 1072Sähköiskuvaara sisäisistä kytkennöistä, sivu 28
Statement 1073Ei käyttäjän huollettavia osia, sivu 28
Statement 1074Noudata paikallisia ja kansallisia sähköturvallisuusmääräyksiä, sivu 28
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
23
Tässä asiakirjassa käytetään seuraavia käytäntöjä:
Tarkoittaa, että lukijan on oltava huolellinen. Tässä tilanteessa saatat tehdä jotakin, joka voi aiheuttaa laitteen
vaurioitumisen tai tietojen katoamisen.
Huomio
TÄRKEITÄ TURVALLISUUSOHJEITA
Tämä varoitussymboli tarkoittaa vaaraa. Olet tilanteessa, josta voi aiheutua henkilövahinko. Ennen kuin käytät
mitään laitteita, sinun on oltava selvillä sähkövirtapiireihin liittyvistä vaaroista ja onnettomuuksien ehkäisyn
peruskäytännöistä. Käytä kunkin varoituksen jäljessä olevaa lausunnon numeroa sen käännöksen etsimiseen
käännetyistä turvallisuusvaroituksista, jotka toimitettiin tämän laitteen mukana.
SÄÄSTÄ NÄMÄ OHJEET
Varoitus
Tällä symbolilla varustetut lausunnot sisältävät lisätietoja, jotka helpottavat säädösten ja asiakasvaatimusten
noudattamista.
Varoitus
Statement 19 TN-virtajärjestelmää koskeva varoitus
Koje on suunniteltu toimimaan TN-sähkövoimajärjestelmien yhteydessä.
Varoitus
Statement 199Hätäpalvelujen käyttöä koskeva varoitus
Tätä laitetta ei voi käyttää hätäpuheluihin, jos sähkövirta on katkennut. Käytettävissä täytyy olla vaihtoehtoinen
järjestelmä yhteyden saamiseksi hälytyskeskukseen. Hälytyskeskusyhteyden estymiseen voi vaikuttaa mikä
tahansa tämän laitteiston soitonestotoiminto.
Varoitus
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
24
Säädösten noudattaminen ja turvallisuustiedotCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 287Vaatimustenmukaisuusvakuutus R &
TTE-direktiivin 1999/5/EY Euroopan yhteisön, Sveitsi, Norja,
Islanti ja Liechtenstein
Tämä laite täyttää direktiivin 1999/5/EY olennaiset vaatimukset ja on siinä asetettujen muiden laitetta koskevien
määräysten mukainen.
Huomautus
Statement 331Virtalähteen asentamista koskeva varoitus
Tehonlähde on sijoitettava sisätiloihin.
Varoitus
Statement 353Tämä tuote on kytkettävä
Tämä tuote on liitettävä PoE (power-over-ethernet) IEEE 802.3af -yhteensopivaan virtalähteeseen tai
IEC60950-yhteensopivaan rajoitettuun virtalähteeseen.
Varoitus
Statement 355Puhelinvastaanottimien ympärille muodostuu
magneettikenttä
Puhelimen ympärille muodostuu magneettikenttä, joka vetää puoleensa pieniä magneettisia esineitä, kuten niittejä
ja klemmareita. Aseta kuuloke aina paikkaan, jossa kyseisiä esineitä ei ole. Näin vältät loukkaamasta itseäsi.
Varoitus
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
25
Säädösten noudattaminen ja turvallisuustiedotCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 361VoIP- ja hätäpuhelupalvelut eivät toimi, jos
virta katkeaa
Voice over IP (VoIP) -palvelu ja hätäpuhelupalvelu eivät toimi, jos virta katkeaa tai sen syötössä esiintyy häiriöitä.
Kun virransyöttö on taas normaali, sinun täytyy mahdollisesti asettaa tai määrittää laitteisto uudelleen, jotta voisit
jälleen käyttää VoIP-palvelua ja hätäpuhelupalvelua. Yhdysvalloissa hätänumero on 911. Selvitä, mikä on omassa
kotimaassasi käytössä oleva hätänumero.
Varoitus
Statement 378Lue seinäkiinnitysohjeet ennen asentamista
Lue seinäkiinnitysohjeet huolellisesti läpi ennen työn aloitusta. Mikäli kiinnityksessä ei käytetä oikeanlaisia
työkaluja tai ohjeita ei noudateta tarkasti, järjestelmä saattaa aiheuttaa vaaratilanteen tai se voi vaurioitua.
Varoitus
Statement 1003Tasavirtasyötön katkaisu
Varmista, että tasavirtapiirissä ei ole virtaa ennen seuraavien toimenpiteiden suorittamista.
Varoitus
Statement 1004Asennusohjeet
Lue asennusohjeet ennen järjestelmän yhdistämistä virtalähteeseen.
Varoitus
Statement 1005Piirikatkaisin
Tämä tuote on riippuvainen rakennukseen asennetusta oikosulkusuojauksesta (ylivirtasuojauksesta). Varmista,
että suojalaitteen mitoitus ei ole yli:
Varoitus
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
26
Säädösten noudattaminen ja turvallisuustiedotCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1019Pääkatkaisumekanismi
Pistoke/liitinkohta toimii pääkatkaisumekanismina. Pääsy siihen on pidettävä aina esteettömänä.
Varoitus
Statement 1021SELV-piiri
Jotta vältyt sähköiskulta, älä kytke pienjännitteisiä SELV-suojapiirejä puhelinverkkojännitettä (TNV) käyttäviin
virtapiireihin. LAN-portit sisältävät SELV-piirejä ja WAN-portit puhelinverkkojännitettä käyttäviä piirejä. Osa sekä
LAN- että WAN-porteista käyttää RJ-45-liittimiä. Ole varovainen kytkiessäsi kaapeleita.
Varoitus
Statement 1030Laitteen asentaminen
Tämän laitteen saa asentaa, vaihtaa tai huoltaa ainoastaan koulutettu ja laitteen tunteva henkilökunta.
Varoitus
Statement 1040Tuotteen hävittäminen
Tämä tuote on hävitettävä kansallisten lakien ja määräysten mukaisesti.
Varoitus
Statement 1044Porttien kytkeminen
Asennuksen sisältävän rakennuksen ulkopuolisia liitäntöjä varten seuraavat portit on kytkettävä hyväksytyn verkon
päätelaitteen kautta ja virtapiirin on oltava kiinteästi suojattu.cs-1044-1
Varoitus
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
27
Säädösten noudattaminen ja turvallisuustiedotCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1071Varoitukset
TÄRKEITÄ TURVALLISUUSOHJEITA
Tämä varoitusmerkki merkitsee vaaraa. Tilanne voi aiheuttaa ruumiillisia vammoja. Ennen kuin käsittelet laitteistoa,
huomioi sähköpiirien käsittelemiseen liittyvät riskit ja tutustu onnettomuuksien yleisiin ehkäisytapoihin.
Turvallisuusvaroitusten käännökset löytyvät laitteen mukana toimitettujen käännettyjen turvallisuusvaroitusten
joukosta varoitusten lopussa näkyvien lausuntonumeroiden avulla.
SÄILYTÄ NÄMÄ OHJEET
Varoitus
Statement 1072Sähköiskuvaara sisäisistä kytkennöistä
Sisäisissä Ethernet (PoE) -virtapiireissä voi olla sähköiskun vaaran aiheuttavia jännitteitä, jos kytkentöihin
käytetään eristämättömiä paljaita metalliliittimiä tai -johtimia. Vältä tällaisia kytkentöjä, elleivät paljaat metalliosat
ole rajatussa paikassa. Ilmoita valtuutetuille käyttäjille ja huoltohenkilöille vaarasta. Rajattuun alueeseen pääsee
käsiksi ainoastaan erityistyökalua, lukkoa ja avainta tai muuta turvallista menetelmää käyttämällä.
Varoitus
Statement 1073Ei käyttäjän huollettavia osia
Ei sisällä käyttäjän huollettavissa olevia osia. Älä avaa.
Varoitus
Statement 1074Noudata paikallisia ja kansallisia
sähköturvallisuusmääräyksiä
Laitteisto tulee asentaa paikallisten ja kansallisten sähkömääräysten mukaisesti.
Varoitus
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
28
Säädösten noudattaminen ja turvallisuustiedotCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
CHAPITRE 5
Informations relatives à la conformité et à la
sécuritéCisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports
Déclaration 19Mise en garde relative à l'alimentation TN, page 30
Déclaration 287déclaration de conformité à la directive R&TTE 1999/5/CE pour la Communauté
européenne, la Suisse, la Norvège, l'Islande et le Liechtenstein, page 30
Déclaration 331Mise en garde relative à l'installation du bloc d'alimentation :, page 31
Déclaration 353Ce produit doit être connecté, page 31
Déclaration 355Les récepteurs téléphoniques produisent un champ magnétique, page 31
Déclaration 361Les services VoIP et d'appel d'urgence ne fonctionnent pas en cas de panne de courant,
page 31
Déclaration 378Avant l'installation, lisez les instructions relatives au montage mural, page 32
Déclaration 1003Déconnexion de l'alimentation c.c., page 32
Déclaration 1004Consignes d'installation, page 32
Déclaration 1005disjoncteur, page 32
Déclaration 1019Dispositif de déconnexion principal, page 32
Déclaration 1030Installation de l'équipement, page 33
Déclaration 1040Mise au rebut du produit, page 33
Déclaration 1044Connexions de port, page 33
Déclaration 1071Définition des mises en garde, page 33
Déclaration 1072Risque d'électrocution en raison d'interconnexions, page 34
Déclaration 1073Aucune pièce réparable ni remplaçable par l'utilisateur, page 34
Déclaration 1074Conformité avec les codes électriques locaux et nationaux, page 34
Déclaration 2022Notification relative aux appareils de Classe B (Canada), page 34
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
29
Déclaration 3015CS-03 Certification pour le Canada, page 35
Sont utilisées dans le présent document les conventions suivantes :
Invite le lecteur à être prudent. Dans cette situation, vous risquez de provoquer l'endommagement de
l'équipement ou la perte de données.
Avertissement
CONSIGNES DE SÉCURITÉ IMPORTANTES
Ce symbole de mise en garde signale un danger. Vous risquez des blessures ou des dommages corporels. Avant
de travailler sur un équipement, prenez en compte les risques associés aux circuits électriques et familiarisez-vous
avec les procédures usuelles visant à éviter les accidents. Utilisez le numéro indiqué après chaque consigne de
sécurité pour pouvoir retrouver sa traduction parmi les consignes de sécurité relatives à cet appareil.
CONSERVEZ CES INSTRUCTIONS
Attention
Les déclarations accompagnées de ce symbole constituent un supplément d'information. Elles sont présentées
conformément à la réglementation et pour satisfaire aux exigences commerciales.
Attention
Déclaration 19Mise en garde relative à l'alimentation TN
Ce dispositif a été conçu pour fonctionner avec des systèmes d'alimentation TN.
Attention
Déclaration 287déclaration de conformité à la directive
R&TTE 1999/5/CE pour la Communauté européenne, la Suisse,
la Norvège, l'Islande et le Liechtenstein
Cet appareil est conforme aux exigences essentielles et aux autres dispositions pertinentes de la Directive
1999/5/EC.
Remarque
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
30
Informations relatives à la conformité et à la sécuritéCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Déclaration 331Mise en garde relative à l'installation du bloc
d'alimentation :
Le bloc dalimentation électrique doit être placé à lintérieur.
Attention
Déclaration 353Ce produit doit être connecté
Ce produit doit être connecté à une source électrique PoE (Power over Ethernet) conforme à la norme IEEE 802.3af
ou à une source électrique limitée conforme à la norme IEC60950.
Attention
Déclaration 355Les récepteurs téléphoniques produisent un
champ magnétique
Les combinés téléphoniques produisent un champ magnétique susceptible d'attirer de petits objets magnétiques
tels que des épingles ou des agrafes. Pour éviter tout risque de blessure, ne placez pas le combiné à un endroit
où de tels objets peuvent se trouver.
Attention
Déclaration 361Les services VoIP et d'appel d'urgence ne
fonctionnent pas en cas de panne de courant
Le service Voice over IP (VoIP) et le service dappels durgence ne fonctionnent pas en cas de panne de courant.
Une fois que le courant est rétabli, vous devrez peut-être réinitialiser ou reconfigurer le système pour accéder de
nouveau au service VoIP et à celui des appels durgence. Aux États-Unis, le numéro des services durgence est
le 911. Vous devez connaître le numéro dappel d'urgence en vigueur dans votre pays.
Attention
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
31
Informations relatives à la conformité et à la sécuritéCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Déclaration 378Avant l'installation, lisez les instructions
relatives au montage mural
Lisez les instructions de montage murale avec attention avant de commencer l'installation. Ne pas utiliser le
matériel correct ou ne pas suivre les procédures correctes pourrait donner résultat a une situation dangereuse
pour les utilisateurs et endommager le système.
Attention
Déclaration 1003Déconnexion de l'alimentation c.c.
Avant de pratiquer l'une quelconque des procédures ci-dessous, vérifier que le circuit en courant continu n'est
plus sous tension.
Attention
Déclaration 1004Consignes d'installation
Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation.
Attention
Déclaration 1005disjoncteur
Un système de protection contre les courts-circuits (surintensité) doit être installé dans le bâtiment. Assurez-vous
que l'intensité nominale du dispositif de protection n'est pas supérieure à :
Attention
Déclaration 1019Dispositif de déconnexion principal
La combinaison de prise de courant doit être accessible à tout moment parce qu'elle fait office de système principal
de déconnexion. .
Attention
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
32
Informations relatives à la conformité et à la sécuritéCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Déclaration 1030Installation de l'équipement
Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à
des personnels qualifiés et expérimentés.
Attention
Déclaration 1040Mise au rebut du produit
La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect
de l'environnement. Renseignez-vous auprès de l'organisme compétent.
Attention
Déclaration 1044Connexions de port
Pour les connexions extérieures au bâtiment équipé, les ports suivants doivent être connectés à un point approuvé
de terminaison de réseau, avec protection complète du circuit. cs-1044-1
Attention
Déclaration 1071Définition des mises en garde
IMPORTANTES INFORMATIONS DE SÉCURITÉ
Ce symbole d'avertissement indique un danger. Vous vous trouvez dans une situation pouvant entraîner des
blessures ou des dommages corporels. Avant de travailler sur un équipement, soyez conscient des dangers liés
aux circuits électriques et familiarisez-vous avec les procédures couramment utilisées pour éviter les accidents.
Pour prendre connaissance des traductions des avertissements figurant dans les consignes de sécurité traduites
qui accompagnent cet appareil, référez-vous au numéro de l'instruction situé à la fin de chaque avertissement.
CONSERVEZ CES INFORMATIONS
Attention
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
33
Informations relatives à la conformité et à la sécuritéCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Déclaration 1072Risque d'électrocution en raison
d'interconnexions
Les tensions existant sur les alimentations utilisant la technologie PoE (Power over Ethernet) peuvent constituer
un risque d'électrocution si les interconnexions sont effectuées en utilisant des terminaux, conducteurs ou contacts
métalliques exposés non isolés. Évitez d'utiliser de telles méthodes d'interconnexion à moins que les pièces
métalliques exposées ne se trouvent dans un emplacement d'accès restreint et que les utilisateurs et les
responsables du service autorisés dans cet emplacement d'accès restreint ne soient conscients du danger. Une
zone d'accès restreint peut être accédée uniquement à l'aide d'une clé, d'un outil et d'un verrou spécial, ou d'autres
moyens de sécurité.
Attention
Déclaration 1073Aucune pièce réparable ni remplaçable par
l'utilisateur
Aucune pièce se trouvant à l'intérieur ne peut être réparée ou remplacée par l'utilisateur. Ne pas ouvrir.
Attention
Déclaration 1074Conformité avec les codes électriques
locaux et nationaux
L'équipement doit être installé conformément aux normes électriques nationales et locales
Attention
Déclaration 2022Notification relative aux appareils de
Classe B (Canada)
Cet appareil numérique de classe B est conforme à la norme ICES-003 du Canada.Remarque
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
34
Informations relatives à la conformité et à la sécuritéCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Déclaration 3015CS-03 Certification pour le Canada
Le présent materiel est conforme aux specifications techniques applicables d'Industrie Canada.
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
35
Informations relatives à la conformité et à la sécuritéCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
36
Informations relatives à la conformité et à la sécuritéCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
FEJEZET 6
A szabályozásnak való megfelelésre és a
biztonságra vonatkozó információkCisco
WRP500 Wireless-G Broadband Router with 2
Phone Ports
Statement 19TN tápellátási figyelmeztetés, oldal 38
Statement 287Nyilatkozat az R & TTE 1999/5/EK irányelv az Európai Közösség, Svájc, Norvégia,
Izland és Liechtenstein, oldal 38
Statement 331Tápegység beszerelésével kapcsolatos figyelmeztetés, oldal 39
Statement 353A termék elírt csatlakoztatása, oldal 39
Statement 355Telephone Receivers Produce a Magnetic Field, oldal 39
Statement 361A VoIP és a vészhívási funkció nem mködik áramkimaradás esetén, oldal 39
Statement 378Read Wall-Mounting Instructions Before Installation, oldal 40
Statement 1003Egyenáramú tápellátás megszakítása, oldal 40
Statement 1004Üzembe helyezési útmutató, oldal 40
Statement 1005Áramköri megszakító, oldal 40
Statement 1019Fmegszakító eszköz, oldal 40
Statement 1021SELV áramkör, oldal 41
Statement 1030Berendezés üzembe helyezése, oldal 41
Statement 1040Hulladékkezelés, oldal 41
Statement 1044Portkapcsolatok, oldal 41
Statement 1072Shock Hazard from Interconnections, oldal 41
Statement 1073A készülékben nincsenek a felhasználó által javítható alkatrészek, oldal 42
Statement 1074A helyi és az országos elektrotechnikai elírások betartása, oldal 42
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
37
Ez a dokumentum a következjelölési rendszert használja:
Jelentése: figyeljen a következkre. Az érintett helyzetekben elfordulhat, hogy bizonyos mveletek
végrehajtása esetén károsodhat a berendezés, vagy adatok veszhetnek el.
Felhívás
FONTOS BIZTONSÁGI ELÍRÁSOK
Ez a figyelmeztet szimbólum veszélyt jelez. Az adott helyzet személyi sérüléshez vezethet. Mieltt bármely
berendezésen munkát végezne, legyen figyelemmel az elektromos áramkörök okozta kockázatokra, és ismerkedjen
meg a szokásos balesetvédelmi eljárásokkal. Az egyes figyelmeztetések végén szerepl figyelmeztetésazonosító
segítségével megtalálhatja az adott figyelmeztetés fordítását az eszközhöz mellékelt magyar nyelv biztonsági
figyelmeztetések között.
RIZZE MEG EZEKET AZ UTASÍTÁSOKAT
Figyelmeztetés
Az ezzel a szimbólummal jelölt figyelmeztetések további információt nyújtanak, illetve a törvényi és fogyasztói
követelményeknek való megfelelés érdekében kerültek feltüntetésre.
Figyelmeztetés
Statement 19TN tápellátási figyelmeztetés
Az eszköz kialakítása a TN tápellátási rendszerekkel való használatot támogatja.
Figyelmeztetés
Statement 287Nyilatkozat az R & TTE 1999/5/EK irányelv az
Európai Közösség, Svájc, Norvégia, Izland és Liechtenstein
Ez a készülék teljesíti az alapvetkövetelményeket és más 1999/5/EK irányelvben meghatározott vonatkozó
rendelkezéseket.
Megjegyzés
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
38
A szabályozásnak való megfelelésre és a biztonságra vonatkozó információkCisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 331Tápegység beszerelésével kapcsolatos
figyelmeztetés
A tápegységet kizárólag beltérben szabad elhelyezni.
Figyelmeztetés
Statement 353A termék elírt csatlakoztatása
Ezt a terméket PoE (power-over-ethernet) rendszer, IEEE802.3af szabvány szerinti tápellátáshoz vagy IEC60950
szabvány szerinti teljesítményhatárolós tápellátáshoz kell csatlakoztatni.
Figyelmeztetés
Statement 355Telephone Receivers Produce a Magnetic Field
Telephone receivers produce a magnetic field that can attract small magnetic objects such as pins and staples.
Személyi sérülés kockázatának csökkentése érdekében ne tegye a készüléket olyan helyre, ahol ilyen tárgyakat
vonzhat magához.
Figyelmeztetés
Statement 361A VoIP és a vészhívási funkció nem mködik
áramkimaradás esetén
A VoIP (Voice over IP) szolgáltatás, illetve a vészhívási funkció nem mködik a tápellátás kimaradása vagy
megsznése esetén. Elfordulhat, hogy a tápellátás helyreállítása után újra kell indítani vagy újra kell konfigurálni
a berendezést a VoIP szolgáltatás és a vészhívási funkció újbóli eléréséhez. Az Egyesült Államokban ez a vészhívó
szám a 911. Ismernie kell az Ön országában használatos vészhívó számot.
Figyelmeztetés
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
39
A szabályozásnak való megfelelésre és a biztonságra vonatkozó információkCisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 378Read Wall-Mounting Instructions Before
Installation
Read the wall-mounting instructions carefully before beginning installation. Ha nem a megfelel hardverelemeket
használja, illetve nem a megfelel eljárás szerint halad, az magában hordozza személyi sérülés, illetve a rendszer
károsodásának kockázatát.
Figyelmeztetés
Statement 1003Egyenáramú tápellátás megszakítása
Mieltt a következ eljárások bármelyikét végrehajtaná, gyzdjön meg arról, hogy az egyenáramú áramkör nincs
feszültség alatt.
Figyelmeztetés
Statement 1004Üzembe helyezési útmutató
Mieltt áramforráshoz csatlakoztatná a rendszert, olvassa el az üzembe helyezési útmutatót.
Figyelmeztetés
Statement 1005Áramköri megszakító
A termék védelmi rendszerének része az épület kábelezésébe épített, rövidzárlat (túláram) elleni védelem is.
Gondoskodjon róla, hogy a készüléket véd eszköz legfeljebb ___ A áramersségre legyen méretezve.
Figyelmeztetés
Statement 1019Fmegszakító eszköz
A dugaszolóaljzat és a dugasz együttesének mindig hozzáférhetnek kell lennie, mivel ez szolgál fmegszakítóként.
Figyelmeztetés
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
40
A szabályozásnak való megfelelésre és a biztonságra vonatkozó információkCisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1021SELV áramkör
Áramütés elkerülése érdekében ne csatlakoztasson biztonságos törpefeszültség (SELV) áramköröket telefonhálózati
feszültség (TNV) áramkörökhöz. A LAN-portok SELV áramköröket, a WAN-portok TNV áramköröket tartalmaznak.
Bizonyos LAN- és WAN-portok egyaránt RJ-45 csatlakozókkal vannak felszerelve. Kábelek csatlakoztatásakor
legyen körültekint.
Figyelmeztetés
Statement 1030Berendezés üzembe helyezése
A berendezést csak szakképzett személy helyezheti üzembe, cserélheti ki és javíthatja.
Figyelmeztetés
Statement 1040Hulladékkezelés
Életciklusának végén a terméket a hatályos nemzeti hulladékkezelési törvények és szabályozások betartásával
kell elhelyezni.
Figyelmeztetés
Statement 1044Portkapcsolatok
A készülék helyéül szolgáló épületen kívüli csatlakozásokhoz az alábbi portokat beépített áramköri védelmet
tartalmazó, engedélyezett hálózati végpontokon keresztül kell csatlakoztatni. cs-1044-1
Figyelmeztetés
Statement 1072Shock Hazard from Interconnections
Voltages that present a shock hazard may exist on Power over Ethernet (PoE) circuits if interconnections are made
using uninsulated exposed metal contacts, conductors, or terminals. Kerülje az ilyen csatolási megoldások
alkalmazását, hacsak nincsenek a szabad fémrészek elzárt területen, továbbá a hozzáférésre jogosult
felhasználóknak és szervizszakembereknek tisztában kell lenniük a veszélyhelyzettel. Az elzárt terület kizárólag
speciális eszköz, illetve zár és kulcs birtokában, vagy egyéb biztonsági megoldáson keresztül elérhet térrész.
Figyelmeztetés
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
41
A szabályozásnak való megfelelésre és a biztonságra vonatkozó információkCisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1073A készülékben nincsenek a felhasználó által
javítható alkatrészek
A készülékben nincsenek a felhasználó által javítható alkatrészek. Ne nyissa fel.
Figyelmeztetés
Statement 1074A helyi és az országos elektrotechnikai
elírások betartása
A berendezés üzembe helyezése során be kell tartani a helyi és az adott országban érvényes elektromos elírásokat.
Figyelmeztetés
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
42
A szabályozásnak való megfelelésre és a biztonságra vonatkozó információkCisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
CAPITOLO 7
Informazioni sulla conformità alle normative e
sulla sicurezzaCisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports
Statement 19 Avviso alimentazione di TN, pagina 44
Statement 199Avviso accesso di emergenza, pagina 44
Statement 287Dichiarazione di Conformità R & TTE 1999/5/CE per la Comunità europea, Svizzera,
Norvegia, Islanda e Liechtenstein, pagina 45
Statement 331Avviso installazione alimentatore, pagina 45
Statement 353È necessario collegare il prodotto, pagina 45
Statement 355I ricevitori telefonici creano un campo magnetico, pagina 45
Statement 361I servizi VoIP e di chiamata di emergenza non funzionano in caso di problemi di
alimentazione, pagina 46
Statement 378Leggere le istruzioni del montaggio a parete prima di eseguire l'installazione, pagina
46
Statement 1003Disconnessione alimentazione CC, pagina 46
Statement 1004Istruzioni di installazione, pagina 46
Statement 1005Interruttore automatico, pagina 46
Statement 1019Disconnessione dispositivo da alimentazione, pagina 47
Statement 1021SELV Circuit, pagina 47
Statement 1030Installazione apparecchiatura, pagina 47
Statement 1040Smaltimento del prodotto, pagina 47
Statement 1044Port Connections, pagina 47
Statement 1071Definizione avviso, pagina 48
Statement 1072Pericolo di scossa dalle interconnessioni, pagina 48
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
43
Statement 1073Non sono presenti parti soggette a manutenzione da parte dell'utente, pagina 48
Statement 1074Conforme allo standard NFPA 70 e relative versioni regionali, pagina 48
In questo documento vengono adottate le seguenti convenzioni:
Invita il lettore a prestare attenzione. In questa situazione si rischia di eseguire un'operazione che potrebbe
danneggiare l'apparecchiatura o comportare la perdita di dati.
Attenzione
ISTRUZIONI IMPORTANTI SULLA SICUREZZA
Questo simbolo di avvertenza indica un pericolo. La situazione potrebbe causare infortuni alle persone. Prima di
utilizzare qualsiasi apparecchiatura, occorre essere al corrente dei pericoli relativi ai circuiti elettrici e conoscere
le procedure standard per la prevenzione di incidenti. Utilizzare il numero presente alla fine di ciascuna avvertenza
per individuare le traduzioni delle avvertenze fornite con il dispositivo.
CONSERVARE QUESTE ISTRUZIONI
Allerta
Le dichiarazioni contenenti questo simbolo hanno lo scopo di fornire ulteriori informazioni e sono conformi ai
requisiti normativi e dei clienti.
Allerta
Statement 19 Avviso alimentazione di TN
Il dispositivo è stato progettato per luso con sistemi di alimentazione TN.
Allerta
Statement 199Avviso accesso di emergenza
Questo apparecchio non è predisposto per effettuare chiamate demergenza nel caso dimancanza di alimentazione
di corrente. È necessario pertanto predisporre misure alternative per consentire laccesso ai servizi di emergenza.
Tale accesso può essere inoltre influenzato dalle funzioni di blocco presenti sullapparechio stesso.
Allerta
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
44
Informazioni sulla conformità alle normative e sulla sicurezzaCisco WRP500 Wireless-G Broadband Router with 2
Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 287Dichiarazione di Conformità R & TTE 1999/5/CE
per la Comunità europea, Svizzera, Norvegia, Islanda e
Liechtenstein
Questo apparato é conforme ai requisiti essenziali ed agli altri principi sanciti dalla Direttiva 1999/5/CE.Nota
Statement 331Avviso installazione alimentatore
Lalimentatore deve essere posto in un luogo interno.
Allerta
Statement 353È necessario collegare il prodotto
Questo prodotto deve essere connesso a una fonte di alimentazione di tipo PoE (power-over-ethernet) conforme
a IEEE 802.3af o a una fonte di alimentazione conforme a IEC60950.
Allerta
Statement 355I ricevitori telefonici creano un campo
magnetico
I ricevitori telefonici producono un campo magnetico in grado di attrarre piccoli oggetti magnetici quali spilli e
punti metallici. Per evitare danni personali, non posizionare il ricevitore accanto a tali oggetti.
Allerta
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
45
Informazioni sulla conformità alle normative e sulla sicurezzaCisco WRP500 Wireless-G Broadband Router with 2
Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 361I servizi VoIP e di chiamata di emergenza non
funzionano in caso di problemi di alimentazione
Il servizio Voice over IP (VoIP) e il servizio per le chiamate di emergenza non funzionano in caso di interruzione
dell'alimentazione. Ristabilita l'alimentazione, potrebbe essere necessario reimpostare o riconfigurare l'attrezzatura
per ottenere nuovamente l'accesso al servizio VoIP e al servizio per le chiamate di emergenza. Negli Stati Uniti,
il numero di emergenza è 911. Si consiglia di individuare il numero di emergenza del proprio Paese.
Allerta
Statement 378Leggere le istruzioni del montaggio a parete
prima di eseguire l'installazione
Leggere attentamente le istruzioni per il montaggio al muro prima di iniziare l'installazione. Un errato uso del
corretto hardware o il mancato rispetto delle corrette procedure potrebbe avere come conseguenza una situazione
di pericolo per le persone e danni al sistema.
Allerta
Statement 1003Disconnessione alimentazione CC
Prima di svolgere una qualsiasi delle procedure seguenti, verificare che il circuito CC non sia alimentato.
Allerta
Statement 1004Istruzioni di installazione
Consultare le istruzioni di installazione prima di collegare il sistema all'alimentatore.
Allerta
Statement 1005Interruttore automatico
Questo prodotto dipende dall'impianto dell'edificio per quanto riguarda la protezione contro cortocircuiti
(sovracorrente). Assicurarsi che il dispositivo di protezione non abbia un rating superiore a:
Allerta
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
46
Informazioni sulla conformità alle normative e sulla sicurezzaCisco WRP500 Wireless-G Broadband Router with 2
Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1019Disconnessione dispositivo da alimentazione
Il gruppo spina-presa deve essere sempre accessibile, poiché viene utilizzato come dispositivo di scollegamento
principale.
Allerta
Statement 1021SELV Circuit
Per evitare scosse, non collegare circuiti a bassa tensione di sicurezza (SELV) a circuiti telefonici (TNV). Le porte
LAN includono circuiti SELV, mentre le porte WAN includono circuiti TNV. In alcuni casi sia le porte LAN che
WAN utilizzano connettori RJ-45. Fare quindi attenzione quando si collegano questi cavi.</cf>
Allerta
Statement 1030Installazione apparecchiatura
Questo apparato può essere installato, sostituito o mantenuto unicamente da un personale competente.
Allerta
Statement 1040Smaltimento del prodotto
Lo smaltimento di questo prodotto deve essere eseguito secondo le leggi e regolazioni locali.
Allerta
Statement 1044Port Connections
Per le connessioni al di fuori dell'edificio in cui l'attrezzatura è installata le seguenti porte devono essere connesse
mediante una unità terminazione di rete approvata con protezione integrale dei circuiti: cs-1044-1
Allerta
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
47
Informazioni sulla conformità alle normative e sulla sicurezzaCisco WRP500 Wireless-G Broadband Router with 2
Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1071Definizione avviso
IMPORTANTI ISTRUZIONI SULLA SICUREZZA
Questo simbolo di avvertenza indica un pericolo. La situazione potrebbe causare infortuni alle persone. Prima di
intervenire su qualsiasi apparecchiatura, occorre essere al corrente dei pericoli relativi ai circuiti elettrici e
conoscere le procedure standard per la prevenzione di incidenti. Utilizzare il numero di istruzione presente alla
fine di ciascuna avvertenza per individuare le traduzioni delle avvertenze riportate in questo documento.
CONSERVARE QUESTE ISTRUZIONI
Allerta
Statement 1072Pericolo di scossa dalle interconnessioni
Nei circuiti con alimentazione via Ethernet (PoE) possono verificarsi pericoli di scosse elettriche se si creano
connessioni con contatti metallici, conduttori o terminali scoperti. Evitare di utilizzare i metodi di connessione
sopraelencati a meno che le parti metalliche esposte non si trovino in una zona riservata e gli utenti e il personale
di assistenza, che sono autorizzati ad accedere nella suddetta zona, siano stati messi al corrente del pericolo. È
possibile accedere alla zona riservata solamente utilizzando gli appositi elementi di sicurezza.
Allerta
Statement 1073Non sono presenti parti soggette a
manutenzione da parte dell'utente
Non contiene parti riparabili dall'utente. Non aprire.
Allerta
Statement 1074Conforme allo standard NFPA 70 e relative
versioni regionali
Conforme allo standard NFPA 70 e relative versioni regionali
Allerta
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
48
Informazioni sulla conformità alle normative e sulla sicurezzaCisco WRP500 Wireless-G Broadband Router with 2
Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
8
Cisco WRP500
Wireless-G Broadband Router with 2 Phone Ports
Statement 19TN , 50
Statement 157 B VCCI , 50
Statement 331, 50
Statement 353, 51
Statement 355Telephone Receivers Produce a Magnetic Field, 51
Statement 361VoIP , 51
Statement 371AC, 51
Statement 378, 52
Statement 391（ARIB-STD）, 52
Statement 1003DC , 52
1004：, 52
Statement 1005, 53
Statement 1019, 53
Statement 1021LAN, 53
1030, 53
Statement 1040, 53
Statement 1044, 53
Statement 1072Shock Hazard from Interconnections, 54
Statement 1073, 54
1074：, 54
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
49
Statement 19TN
TN
Statement 157 B VCCI
VCCI B
VCCI-B
Statement 331
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
50
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 353
Power over Ethernet（PoE; ）IEEE 802.3af
IEC60950
Statement 355Telephone Receivers Produce a Magnetic Field
Telephone receivers produce a magnetic field that can attract small magnetic objects such as pins and staples.
Statement 361VoIP
Voice over IP（VoIP）
VoIP
911
Statement 371AC
AC
（PSE）UL（ULCSA
）
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
51
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 378
Statement 391
（ARIB-STD）
（）（
）（）
（）
URL
http://www.cisco.com/jp/
Statement 1003DC
DC
1004：
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
52
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1005
（）
:
Statement 1019
Statement 1021LAN
5.2/5.3GHzLAN
1030
Statement 1040
Statement 1044
cs-1044-1
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
53
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1072Shock Hazard from Interconnections
Voltages that present a shock hazard may exist on Power over Ethernet (PoE) circuits if interconnections are made
using uninsulated exposed metal contacts, conductors, or terminals.
Statement 1073
1074：
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
54
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
KAPITTEL 9
Informasjon om forskriftsmessig samsvar og
sikkerhetCisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports
Statement 19 TN Strøm Advarsel, side 56
Statement 199Nødtilgang - advarsel, side 56
Statement 287Erklæring av samsvar med R&TTE direktivet 1999/5/EC for den Europeiske Union,
Sveits, Norge, Island og Liechtenstein, side 57
Statement 331Installasjon av strømforsyningsenhet - advarsel, side 57
Statement 353Dette produktet må være tilkoblet, side 57
Statement 355Telefonrøret skaper et magnetfelt, side 57
Statement 361Tjenestene Voice over IP (VoIP) og nødanrop fungerer ikke ved strømbrudd, side 57
Statement 378Les instruksjonene for veggmontering før installasjon, side 58
Statement 1003Frakobling av likestrøm, side 58
Statement 1004Installasjonsinstrukser, side 58
Statement 1005Overbelastningsbryter, side 58
Statement 1019Hovedfrakoblingsenhet, side 58
Statement 1021SELV Circuit, side 59
Statement 1030Installasjon av utstyr, side 59
Statement 1040Produktkassering, side 59
Statement 1044Porttilkoblinger, side 59
Statement 1071Advarselsdefinisjon, side 59
Statement 1072Støtfare fra sammenkoblinger, side 60
Statement 1073Ingen deler kan repareres av brukeren, side 60
Statement 1074Samsvar med lokale og nasjonale elektrisitetsforskrifter, side 60
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
55
Dette dokumentet bruker følgende konvensjoner:
Betyr leser vær forsiktig. I denne situasjonen, kan du utføre en handling som kan føre til skade på utstyret
eller tap av data.
Forsiktig
VIKTIGE SIKKERHETSINSTRUKSER
Dette varselsymbolet betyr fare. Du befinner deg i en situasjon som kan forårsake personskade. Før du jobber med
utstyr, må du gjøre deg kjent med de farer elektriske strømkretser kan medføre, samt sikkerhetsrutiner som
forebygger ulykker. Bruk erklæringsnummeret på slutten av hver advarsel for å finne oversettelsen i de oversatte
sikkerhetsvarslingene vedlagt dette utstyret.
TA VARE PÅ DISSE INSTRUKSJONENE
Advarsel
Uttalelser som bruker dette symbolet er gitt for ytterligere informasjon og for å overholde regelverk og krav fra
kunder.
Advarsel
Statement 19 TN Strøm Advarsel
Utstyret er utfomet til bruk med TN-strømsystemer.
Advarsel
Statement 199Nødtilgang - advarsel
Dette utstyret har ingen funksjon for nødtjenester når strømmen er brutt. En bør utarbeide alternative ordninger
hvis man må ha tilgang til nødtjenester. Tilgangen til nødtjenester kan bli påvirket av alle samtalesperrende
funksjoner i dette utstyret.
Advarsel
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
56
Informasjon om forskriftsmessig samsvar og sikkerhetCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 287 Erklæring av samsvar med R&TTE direktivet
1999/5/EC for den Europeiske Union, Sveits, Norge, Island og
Liechtenstein
Dette utstyret er i samsvar med de grunnleggende krav og andre relevante bestemmelser i EU-direktiv
1999/5/EF.
Merk
Statement 331Installasjon av strømforsyningsenhet - advarsel
Strømkilden skal være plassert innendørs.
Advarsel
Statement 353Dette produktet må være tilkoblet
Dette produktet må være koblet til en Power-over-Ethernet (PoE) IEEE 802.3af-kompatibel strømkilde eller en
IEC60950-kompatibel begrenset strømkilde.
Advarsel
Statement 355Telefonrøret skaper et magnetfelt
Håndsettet lager et magnetfelt som kan tiltrekke seg små magnetiske objekter som nåler og stifter. For å unngå
skade bør du ikke plassere håndsettet der det finnes slike objekter.
Advarsel
Statement 361Tjenestene Voice over IP (VoIP) og nødanrop
fungerer ikke ved strømbrudd
Tjenesten Voice over IP (VoIP) og nødanropstjenesten fungerer ikke ved strømbrudd. Etter at strømmen har kommet
tilbake, må du kanskje nullstille eller konfigurere utstyret på nytt for å få tilgang til VoIP og nødanropstjenesten.
I USA er dette nødnummeret 911. Du må vite hva nødnummeret er i ditt land.
Advarsel
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
57
Informasjon om forskriftsmessig samsvar og sikkerhetCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 378Les instruksjonene for veggmontering før
installasjon
Les nøye gjennom instruksene om veggmontering før du begynner monteringen. Dersom man ikke bruker riktig
maskinvare eller ikke følger riktig framgangsmåte kan det resultere i risiko for personskader og skade på systemet.
Advarsel
Statement 1003Frakobling av likestrøm
Før noen av disse prosedyrene utføres, kontroller at strømmen er frakoblet likestrømkretsen.
Advarsel
Statement 1004Installasjonsinstrukser
Les installasjonsinstruksjonene før systemet kobles til strømkilden.
Advarsel
Statement 1005Overbelastningsbryter
Dette produktet er avhengig av bygningens installasjon for beskyttelse mot kortslutning (overstrøm). Kontroller at
vernenheten ikke er rangert høyere enn:
cs-1005-1
Advarsel
Statement 1019Hovedfrakoblingsenhet
Kombinasjonen støpsel/uttak må alltid være tilgjengelig ettersom den fungerer som hovedfrakoplingsenhet
Advarsel
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
58
Informasjon om forskriftsmessig samsvar og sikkerhetCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1021SELV Circuit
For å unngå elektrisk sjokk, må du ikke koble spenningskretser med ekstra lav spenning (SELV) til spenningskretser
i telefonnettverk (TNV). LAN-porter inneholder SELV-kretser, og WAN-porter inneholder TNV-kretser. Enkelte LAN-
og WAN-porter bruker begge RJ-45-tilkoblinger. Vær varsom når du setter inn kabler.</cf>
Advarsel
Statement 1030Installasjon av utstyr
Bare opplært og kvalifisert personell skal foreta installasjoner, utskiftninger eller service på dette utstyret.
Advarsel
Statement 1040Produktkassering
Endelig kassering av dette produktet skal være i henhold til alle relevante nasjonale lover og bestemmelser.
Advarsel
Statement 1044Porttilkoblinger
For tilkoblinger utenfor bygningen der utstyret er montert, må følgende åpninger tilkobles gjennom en godkjent
nettverksterminal med integrert kretsbeskyttelse.cs-1044-1
Advarsel
Statement 1071Advarselsdefinisjon
VIKTIGE SIKKERHETSINSTRUKSJONER
Dette advarselssymbolet betyr fare. Du er i en situasjon som kan føre til skade på person. Før du begynner å arbeide
med noe av utstyret, må du være oppmerksom på farene forbundet med elektriske kretser, og kjenne til
standardprosedyrer for å forhindre ulykker. Bruk nummeret i slutten av hver advarsel for å finne oversettelsen i
de oversatte sikkerhetsadvarslene som fulgte med denne enheten.
TA VARE PÅ DISSE INSTRUKSJONENE
Advarsel
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
59
Informasjon om forskriftsmessig samsvar og sikkerhetCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1072Støtfare fra sammenkoblinger
I strømkretser med PoE (Power over Ethernet) kan det være spenninger som kan utgjøre støtfare hvis det blir
foretatt sammenkoblinger med uisolerte, eksponerte kontakter, ledere eller terminaler av metall. Unngå å bruke
slike sammenkoblingsmetoder med mindre de eksponerte metalldelene er i et område med begrenset tilgang, og
brukere og servicepersonell som har tilgang til det begrensede området, blir gjort oppmerksom på faren. Et område
med begrenset tilgang kan bare åpnes ved hjelp av spesialverktøy, nøkkel eller andre sikkerhetstiltak.
Advarsel
Statement 1073Ingen deler kan repareres av brukeren
Inneholder ingen deler som kan repareres av brukeren. Må ikke åpnes.
Advarsel
Statement 1074Samsvar med lokale og nasjonale
elektrisitetsforskrifter
Installasjon av utstyret må samsvare med lokale og nasjonale elektrisitetsforskrifter.
Advarsel
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
60
Informasjon om forskriftsmessig samsvar og sikkerhetCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
HOOFDSTUK 10
Regelnaleving en veiligheidsinformatieCisco
WRP500 Wireless-G Broadband Router with 2
Phone Ports
Statement 19 Waarschuwing: TN-voeding, pagina 62
Statement 199Waarschuwing: noodtoegang, pagina 62
Statement 287Verklaring van conformiteit met R & TTE-richtlijn 1999/5/EG van de Europese
Gemeenschap, Zwitserland, Noorwegen, IJsland en Liechtenstein, pagina 63
Statement 331Waarschuwing: installatie van voeding, pagina 63
Statement 353Dit product moet worden aangesloten, pagina 63
Statement 355Telefoonontvangers produceren een magnetisch veld, pagina 63
Statement 361Geen VoIP- en noodoproepen mogelijk bij stroomuitval, pagina 64
Statement 378Lees wandmontage-instructies voorafgaande aan installatie, pagina 64
Statement 1003Loskoppeling DC-voeding, pagina 64
Statement 1004Installatie-instructies, pagina 64
Statement 1005Circuitonderbreker, pagina 64
Statement 1019Hoofdmechanisme voor verbreking van de aansluiting, pagina 65
Statement 1021SELV-circuit, pagina 65
Statement 1030Installatie van apparatuur, pagina 65
Statement 1040Definitieve verwijdering van product, pagina 65
Statement 1044Poortaansluitingen, pagina 65
Statement 1071Waarschuwingsdefinitie, pagina 66
Statement 1072Schokgevaar van aansluitingen, pagina 66
Statement 1073Geen onderdelen waarop de gebruiker onderhoud kan uitvoeren, pagina 66
Statement 1074Volg plaatselijk en landelijk geldende regelgeving voor elektrische , pagina 66
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
61
In deze publicatie worden de volgende conventies gebruikt:
Betekent lezer: wees voorzichtig. In deze situatie kunt u handelingen uitvoeren die schade aan de apparatuur
of het verlies van gegevens tot gevolg kunnen hebben.
Voorzichtig
BELANGRIJKE VEILIGHEIDSINSTRUCTIES
Dit waarschuwingssymbool betekent gevaar. Deze situatie kan leiden tot lichamelijk letsel. Voordat u met apparatuur
gaat werken, dient u op de hoogte te zijn van de gevaren van elektrische circuits en van de standaard
veiligheidsmaatregelen voor het voorkomen van ongevallen. Gebruik het nummer van de verklaring, dat u aan het
einde van elke waarschuwing vindt, om de vertaling ervan op te zoeken in de vertaalde veiligheidswaarschuwingen
die bij dit apparaat zijn geleverd.
BEWAAR DEZE INSTRUCTIES
Waarschuwing
Verklaringen met dit symbool worden verstrekt als aanvullende informatie en om aan de regelgevende voorschriften
en de eisen van de klant te voldoen.
Waarschuwing
Statement 19 Waarschuwing: TN-voeding
Het apparaat is ontworpen om te functioneren met TN energiesystemen.
Waarschuwing
Statement 199Waarschuwing: noodtoegang
Deze apparatuur is niet bedoeld voor noodtelefoongesprekken bij stroomstoringen. Voor telefoondiensten in
noodsituaties moet u andere maatregelen treffen. Eventuele blokkeringsfuncties van deze apparatuur kunnen van
invloed zijn op de bereikbaarheid van deze telefoondiensten.
Waarschuwing
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
62
Regelnaleving en veiligheidsinformatieCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 287Verklaring van conformiteit met R &
TTE-richtlijn 1999/5/EG van de Europese Gemeenschap,
Zwitserland, Noorwegen, IJsland en Liechtenstein
Dit apparaat voldoet aan de essentiele eisen en andere van toepassing zijnde bepalingen van de Richtlijn
1999/5/EC.
Opmerking
Statement 331Waarschuwing: installatie van voeding
De stroomtoevoer moet binnen worden geplaatst.
Waarschuwing
Statement 353Dit product moet worden aangesloten
Dit product moet worden verbonden met een stroomvoorziening die compatibel is met PoE (power-over-ethernet)
IEEE 802.3af of een beperkte stroomvoorziening die compatibel is met IEC60950.
Waarschuwing
Statement 355Telefoonontvangers produceren een
magnetisch veld
Telefoonontvangers produceren een magnetisch veld dat kleine magnetische objecten, zoals spelden of nietjes,
kan aantrekken. Leg de hoorn niet ergens neer waar zich dergelijke objecten kunnen bevinden, om verwondingen
te voorkomen.
Waarschuwing
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
63
Regelnaleving en veiligheidsinformatieCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 361Geen VoIP- en noodoproepen mogelijk bij
stroomuitval
Voice over IP (VoIP)-service en de service voor noodoproepen werken niet indien er een stroomstoring is. Nadat
de stroomtoevoer is hersteld, dient u wellicht de configuratie van uw apparatuur opnieuw in te stellen om opnieuw
toegang te krijgen tot VoIP en de noodoproepen. In de VS is het nummer voor noodoproepen 911. U dient u zelf op
de hoogte te stellen van het nummer voor noodoproepen in uw land.
Waarschuwing
Statement 378Lees wandmontage-instructies voorafgaande
aan installatie
Lees de wandbevestigingsinstructies aandachtig door voordat u met de installatie begint. Het niet gebruiken van
de juiste hardware of het opvolgen van de juiste procedures kan resulteren in een gevaarlijke situatie voor mensen
en schade aan het systeem.
Waarschuwing
Statement 1003Loskoppeling DC-voeding
Voordat u een van de onderstaande procedures uitvoert, dient u te controleren of de stroom naar het gelijkstroom
circuit uitgeschakeld is.
Waarschuwing
Statement 1004Installatie-instructies
Raadpleeg de installatie-instructies voordat u het systeem op de voedingsbron aansluit.
Waarschuwing
Statement 1005Circuitonderbreker
Dit product is afhankelijk van de installatie in het gebouw voor bescherming tegen kortsluiting. Zorg ervoor dat
de bescherming de volgende waarden niet overschrijdt:
Waarschuwing
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
64
Regelnaleving en veiligheidsinformatieCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1019Hoofdmechanisme voor verbreking van de
aansluiting
De combinatie van de stekker en het elektrisch contactpunt moet te allen tijde toegankelijk zijn omdat deze het
hoofdmechanisme vormt voor verbreking van de aansluiting.
Waarschuwing
Statement 1021SELV-circuit
Om elektrische schokken te vermijden, mogen veiligheidscircuits met extra lage spanning(genaamd SELV = Safety
Extra-Low Voltage) niet met telefoonnetwerkspanning (TNV) circuits verbonden worden. LAN (Lokaal netwerk)
poorten bevatten SELV circuits en WAN (Regionaal netwerk) poorten bevatten TNV circuits. Sommige LAN en
WAN poorten gebruiken allebei RJ-45 connectors. Ga voorzichtig te werk wanneer u kabels verbindt.
Waarschuwing
Statement 1030Installatie van apparatuur
Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door bevoegdgeschoold personeel.
Waarschuwing
Statement 1040Definitieve verwijdering van product
Het uiteindelijke wegruimen van dit product dient te geschieden in overeenstemming met alle nationale wetten
en reglementen.
Waarschuwing
Statement 1044Poortaansluitingen
Voor aansluitingen buiten het gebouw waar de apparatuur wordt geïnstalleerd, dienen de volgende poorten
aangesloten te worden via een goedgekeurde netwerkafsluiteenheid met integrale circuitbescherming.cs-1044-1
Waarschuwing
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
65
Regelnaleving en veiligheidsinformatieCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1071Waarschuwingsdefinitie
BELANGRIJKE VEILIGHEIDSINSTRUCTIES
Dit waarschuwingssymbool betekent gevaar. U verkeert in een situatie die lichamelijk letsel kanveroorzaken.
Voordat u aan enige apparatuur gaat werken, dient u zich bewust te zijn van de bij elektrische schakelingen
betrokken risico's en dient u op de hoogte te zijn van de standaardpraktijken om ongelukken te voorkomen. Gebruik
het nummer van de verklaring onderaan de waarschuwing als u een vertaling van de waarschuwing die bij het
apparaat wordt geleverd, wilt raadplegen.
BEWAAR DEZE INSTRUCTIES
Waarschuwing
Statement 1072Schokgevaar van aansluitingen
Voltages kunnen elektrische schokken veroorzaken in PoE (Power over Ethernet)-circuits als er verbindingen
worden gemaakt met blootliggende metalen contactpunten, geleiders of aansluitingspunten die niet zijn geïsoleerd.
Gebruik dit type verbinding niet tenzij de blootliggende metalen onderdelen zich bevinden op een locatie met
beperkte toegang en de gebruikers en onderhoudstechnici die toegang tot deze locatie hebben, op het gevaar
worden gewezen. De locatie met beperkte toegang kan alleen worden geopend met speciaal gereedschap, slot
en sleutel of een andere beveiligingsmethode.
Waarschuwing
Statement 1073Geen onderdelen waarop de gebruiker
onderhoud kan uitvoeren
Er zijn geen door de gebruiker te vervangen onderdelen. Niet openen.
Waarschuwing
Statement 1074Volg plaatselijk en landelijk geldende
regelgeving voor elektrische
Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
Waarschuwing
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
66
Regelnaleving en veiligheidsinformatieCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
CAPÍTULO 11
Regulamentação de Conformidade e Informações
de SegurançaCisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports
Statement 19 Aviso de energia TN, página 68
Statement 199Aviso de acesso em caso de emergência, página 68
Statement 287Declaração de Conformidade para R & TTE 1999/5/CE para a Comunidade Europeia,
Suíça, Noruega, Islândia e Liechtenstein, página 69
Statement 331Aviso de instalação da fonte de alimentação, página 69
Statement 353Este produto tem de estar ligado, página 69
Statement 355Os auscultadores telefónicos geram um campo magnético, página 69
Statement 361Os serviços VoIP e de chamada de emergência não funcionam se ocorrer uma falha de
energia, página 70
Statement 378Leia as instruções de montagem na parede antes de proceder à instalação, página 70
Statement 1003Desconexão da alimentação CC, página 70
Statement 1004Instruções de instalação, página 70
Statement 1005Disjuntor, página 70
Statement 1019Dispositivo de desconexão principal, página 71
Statement 1021Circuito SELV, página 71
Statement 1030Instalação do equipamento, página 71
Statement 1040Eliminação do produto, página 71
Statement 1044Ligações da porta, página 71
Statement 1071Definição de aviso, página 72
Statement 1072Risco de choque resultante de interligações, página 72
Statement 1073Não existem peças passíveis de assistência por parte do utilizador, página 72
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
67
Statement 1074Em conformidade aos códigos elétricos locais e nacionais, página 72
Neste documento são utilizadas as seguintes convenções:
Quer dizer atenção leitor. Desta forma, poderá efectuar uma acção que cause danos no equipemento or perda
de dados.
Atenção
INSTRUÇÕES DE SEGURANÇA IMPORTANTES
Este símbolo de aviso significa perigo. Está numa situação que poderá causar lesão corporal. Antes de trabalhar
em qualquer equipamento, tenha em atenção os perigos inerentes aos circuitos eléctricos e familiarize-se com
as práticas padrão para prevenção de acidentes. Utilize o número de declaração fornecido no final de cada aviso
para localizar a respectiva tradução, nos avisos de segurança traduzidos que acompanham este dispositivo.
GUARDE ESTAS INSTRUÇÕES
Aviso
As declarações que utilizam este símbolo são fornecidas como informação adicional e para cumprimento dos
requisitos regulamentares.
Aviso
Statement 19 Aviso de energia TN
O dispositivo foi criado para operar com sistemas de corrente TN.
Aviso
Statement 199Aviso de acesso em caso de emergência
Este equipamento não foi concebido para estabelecer chamadas telefónicas de emergência quando faltar a
energia. Devem tomar-se medidas alternativas para aceder a serviços de emergência. O acesso aos serviços de
emergência pode ser afectado por qualquer função de barramento de chamadas aplicada a este equipamento.
Aviso
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
68
Regulamentação de Conformidade e Informações de SegurançaCisco WRP500 Wireless-G Broadband Router with 2
Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 287Declaração de Conformidade para R & TTE
1999/5/CE para a Comunidade Europeia, Suíça, Noruega, Islândia
e Liechtenstein
Este equipamento está em conformidade com os requisitos essenciais e outras provisões relevantes da Directiva
1999/5/EC.
Nota
Statement 331Aviso de instalação da fonte de alimentação
A fonte de alimentação deve ser instalada no interior.
Aviso
Statement 353Este produto tem de estar ligado
Este produto tem de estar ligado a uma fonte de alimentação compatível com a norma IEEE 802.3af, também
conhecida pela sigla Power over Ethernet (PoE), ou a uma fonte de alimentação limitada compatível com a norma
IEC60950.
Aviso
Statement 355Os auscultadores telefónicos geram um campo
magnético
Os auscultadores telefónicos produzem um campo magnético que pode atrair pequenos objectos magnéticos como
por exemplo alfinetes e agrafos. Para evitar eventuais ferimentos, não coloque o auscultador próximo deste tipo
de objectos.
Aviso
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
69
Regulamentação de Conformidade e Informações de SegurançaCisco WRP500 Wireless-G Broadband Router with 2
Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 361Os serviços VoIP e de chamada de emergência
não funcionam se ocorrer uma falha de energia
O serviço Voice over IP (VoIP) e o serviço de chamadas de emergência não funcionam se houver um corte de
energia. Depois do fornecimento de energia ser restabelecido, poderá ser necessário reiniciar ou reconfigurar o
equipamento para voltar a utilizar os serviços VoIP ou chamadas de emergência. Nos EUA, o número de emergência
é o 911. É importante que saiba qual o número de emergência no seu país.
Aviso
Statement 378Leia as instruções de montagem na parede
antes de proceder à instalação
Leia com cuidado as instruções de montagem na parede antes de iniciar a instalação. Falha em usar o hardware
correto ou em seguir os procedimentos corretos pode resultar numa situação de risco para as pessoas e danos
ao sistema.
Aviso
Statement 1003Desconexão da alimentação CC
Antes de executar um dos seguintes procedimentos, certifique-se que desligou a fonte de alimentação de energia
do circuito de corrente contínua.
Aviso
Statement 1004Instruções de instalação
Leia as instruções de instalação antes de ligar o sistema à fonte de energia.
Aviso
Statement 1005Disjuntor
Este produto depende das instalações existentes para proteção contra curto-circuito (sobrecarga). Assegure-se
de que o fusível ou disjuntor não seja superior a:
Aviso
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
70
Regulamentação de Conformidade e Informações de SegurançaCisco WRP500 Wireless-G Broadband Router with 2
Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1019Dispositivo de desconexão principal
A combinação ficha-tomada deverá ser sempre acessível, porque funciona como interruptor principal.
Aviso
Statement 1021Circuito SELV
Para evitar choques eléctricos, não conecte os circuitos de segurança de baixa tensão (SELV) aos circuitos de
tensão de rede telefónica (TNV). As portas LAN contêm circuitos SELV e as portas WAN contêm circuitos TNV.
Algumas portas LAN e WAN usam conectores RJ-45. Tenha o devido cuidado ao conectar os cabos.
Aviso
Statement 1030Instalação do equipamento
Apenas pessoal treinado e qualificado deve ser autorizado a instalar, substituir ou fazer a revisão deste equipamento.
Aviso
Statement 1040Eliminação do produto
Deitar fora este produto em conformidade com todas as leis e regulamentos nacionais.
Aviso
Statement 1044Ligações da porta
Para ligações fora do edifício onde o equipamento está instalado, é necessário ligar as seguintes portas através
de uma unidade de terminal de rede aprovada com protecção de circuito integral.
Aviso
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
71
Regulamentação de Conformidade e Informações de SegurançaCisco WRP500 Wireless-G Broadband Router with 2
Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1071Definição de aviso
INSTRUÇÕES IMPORTANTES DE SEGURANÇA
Este símbolo de aviso significa perigo. Você está em uma situação que poderá ser causadora de lesões corporais.
Antes de iniciar a utilização de qualquer equipamento, tenha conhecimento dos perigos envolvidos no manuseio
de circuitos elétricos e familiarize-se com as práticas habituais de prevenção de acidentes. Utilize o número da
instrução fornecido ao final de cada aviso para localizar sua tradução nos avisos de segurança traduzidos que
acompanham este dispositivo.
GUARDE ESTAS INSTRUÇÕES
Aviso
Statement 1072Risco de choque resultante de interligações
Pode haver voltagens que representam perigo de choque em circuitos PoE (Power over Ethernet) se as interconexões
forem feitas utilizando-se terminais, condutores ou contatos de metal exposto e sem isolamento. Evite utilizar tais
métodos de interconexão a não ser que as partes de metal expostas estejam em um local de acesso restrito e os
usuários e o pessoal de serviço com acesso autorizado a este local restrito estejam cientes do perigo. Uma área
de acesso restrito só pode ser acessada com o uso de uma ferramenta, fechadura e chave especial ou de outros
meios de segurança.
Aviso
Statement 1073Não existem peças passíveis de assistência
por parte do utilizador
Sem peças sujeitas a manutenção pelo utilizador. Não abrir
Aviso
Statement 1074Em conformidade aos códigos elétricos locais
e nacionais
A instalação do equipamento tem de estar em conformidade com os códigos eléctricos locais e nacionais.
Aviso
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
72
Regulamentação de Conformidade e Informações de SegurançaCisco WRP500 Wireless-G Broadband Router with 2
Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
12
Cisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports
Statement 19 !
, 74
Statement 331! , 74
Statement 353 , 74
Statement 355Telephone Receivers Produce a Magnetic Field, 75
Statement 361 VoIP
, 75
Statement 378 ,
75
Statement 1003 , 75
Statement 1004 , 76
Statement 1005, 76
Statement 1021 , 76
Statement 1030 , 76
Statement 1040 , 76
Statement 1044 , 77
Statement 1072 , 77
Statement 1073, ,, 77
Statement 1074
, 77
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
73
:
, . ,
, .
!
. ,
. ,
, ,
.
, .
, ,
.
Statement 19 !
.
Statement 331!
.
Statement 353
,
thernet (PoE) IEEE802.3af, ,
IEC60950.
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
74
Cisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 355Telephone Receivers Produce a Magnetic Field
Telephone receivers produce a magnetic field that can attract small magnetic objects such as pins and staples.
, .
Statement 361 VoIP
IP- (VoIP) .
VoIP .
911. .
Statement 378
.
.
Statement 1003
,
.
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
75
Cisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1004
.
Statement 1005
(). ,
Statement 1021
() . LAN ,
WAN . LAN WAN
RJ-45. , .
Statement 1030
,
.
Statement 1040
.
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
76
Cisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1044
, ,
.cs-1044-1
Statement 1072
thernet (PoE),
, .
, , ,
,
, , .
,
.
Statement 1073, ,
, . .
Statement 1074
.
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
77
Cisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
78
Cisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
KAPITEL 13
Information om överensstämmelse med regelverk
och säkerhetskravCisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports
Statement 19 Varning TN-ström, sida 80
Statement 199Varning Nödåtkomst, sida 80
Statement 287Försäkran om överensstämmelse med R & TTE-direktivet 1999/5/EG för Europeiska
gemenskapen, Schweiz, Norge, Island och Liechtenstein, sida 81
Statement 331Varning Installation av nätaggregat, sida 81
Statement 353Denna produkt måste anslutas , sida 81
Statement 355Telefonlurar avger magnetfält, sida 81
Statement 361VoIP- och nödsamtalstjänster fungerar inte om strömmen bryts, sida 81
Statement 378Läs anvisningar för väggmontering före installation , sida 82
Statement 1003Frånkoppling av likström, sida 82
Statement 1004Installationsanvisningar, sida 82
Statement 1005Säkring, sida 82
Statement 1019Huvudfrånkopplingsenhet, sida 82
Statement 1021SELV-krets, sida 83
Statement 1030Installation av utrustning, sida 83
Statement 1040Produktåtervinning, sida 83
Statement 1044Portanslutningar, sida 83
Statement 1071Varningsdefinition, sida 83
Statement 1072Risk för elektriska stötar från mellananslutningar, sida 84
Statement 1073Inga delar som användaren kan utföra service på, sida 84
Statement 1074Följ lokala och nationella elbestämmelser, sida 84
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
79
I dokumentet används följande konventioner:
Betyder var aktsam. I denna situation kanske du gör något som kan leda till att utrustningen skadas eller till
dataförlust.
Försiktighet
VIKTIGA SÄKERHETSINSTRUKTIONER
Den här varningssymbolen indikerar fara. Det finns risk för kroppsskador. Innan du börjar arbeta med utrustningen
måste du vara medveten om riskerna med elektriska kretsar och känna till de normala förfarandena för att förhindra
olyckor. Använd numret som finns angivet vid varje varning för att hitta den översatta varningen bland de översatta
säkerhetsvarningarna som medföljde enheten.
SPARA DE HÄR INSTRUKTIONERNA
Varning
Innehåll med denna symbolen är för ytterligare information och för efterlevnad av regelverk och kundkrav.
Varning
Statement 19 Varning TN-ström
Enheten är konstruerad för användning tillsammans med elkraftssystem av TN-typ.
Varning
Statement 199Varning Nödåtkomst
Denna utrustning är inte utformad för telefonsamtal i nödläge när strömmen bryts. Andra arrangemang måste göras
för att kunna nå nödtjänster. Åtkomst till nödtjänster kan påverkas av alla samtalsspärrningsfunktioner i denna
utrustning.
Varning
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
80
Information om överensstämmelse med regelverk och säkerhetskravCisco WRP500 Wireless-G Broadband Router with
2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 287Försäkran om överensstämmelse med R &
TTE-direktivet 1999/5/EG för Europeiska gemenskapen, Schweiz,
Norge, Island och Liechtenstein
Denna utrustning är i överensstämmelse med de väsentliga kraven och andra relevanta bestämmelser i Direktiv
1999/5/EC.
OBS!
Statement 331Varning Installation av nätaggregat
Strömkällan måste vara placerad inomhus.
Varning
Statement 353Denna produkt måste anslutas
Denna produkt måste vara ansluten till en PoE IEEE 802.3af-kompatibel strömkälla eller en IEC60950-kompatibel
begränsad strömkälla.
Varning
Statement 355Telefonlurar avger magnetfält
Telefonmottagare genererar magnetfält som kan dra till sig små magnetiska föremål, t.ex. nålar och häftklamrar.
Undvik att lägga luren i närheten av sådana föremål.
Varning
Statement 361VoIP- och nödsamtalstjänster fungerar inte om
strömmen bryts
Tjänsten Voice over IP (VoIP) och larmnummertjänsten fungerar inte vid strömavbrott. Efter att strömmen kommit
tillbaka måste du kanske återställa eller konfigurera om utrustningen för att få strömmen kommit tillbaka måste
du kanske återställa eller konfigurera om utrustningen för att få larmnummer som gäller i ditt land.
Varning
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
81
Information om överensstämmelse med regelverk och säkerhetskravCisco WRP500 Wireless-G Broadband Router with
2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 378Läs anvisningar för väggmontering före
installation
Läs väggmonteringsintruktionerna noga innan du påbörjar installationen. Försummelse av att inte använda rätt
hårdvara eller att inte föjla korrekt tillvägagångsätt kan resultera i en riskabel situation för människor och kan
skada systemet.
Varning
Statement 1003Frånkoppling av likström
Innan du utför någon av följande procedurer måste du kontrollera att strömförsörjningen till likströmskretsen är
bruten.
Varning
Statement 1004Installationsanvisningar
Läs installationsanvisningarna innan du kopplar systemet till strömförsörjningsenheten.
Varning
Statement 1005Säkring
Denna produkt är beroende av i byggnaden installerat kortslutningsskydd (överströmsskydd). Kontrollera att
skyddsanordningen inte har högre märkvärde än:
Varning
Statement 1019Huvudfrånkopplingsenhet
Man måste alltid kunna komma åt stickproppen i uttaget, eftersom denna koppling utgör den huvudsakliga
frånkopplingsanordningen.
Varning
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
82
Information om överensstämmelse med regelverk och säkerhetskravCisco WRP500 Wireless-G Broadband Router with
2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1021SELV-krets
För att undvika elektriska stötar, koppla inte säkerhetskretsar med extra låg spänning (SELV-kretsar) till kretsar
med telefonnätspänning (TNV-kretsar). LAN-portar innehåller SELV-kretsar och WAN-portar innehåller TNV-kretsar.
Vissa LAN- och WAN-portar är försedda med RJ-45-kontakter. Iaktta försiktighet vid anslutning av kablar.
Varning
Statement 1030Installation av utrustning
Endast utbildad och kvalificerad personal bör få tillåtelse att installera, byta ut eller reparera denna utrustning.
Varning
Statement 1040Produktåtervinning
Vid deponering hanteras produkten enligt gällande lagar och bestämmelser.
Varning
Statement 1044Portanslutningar
För alla anslutningar utanför byggnaden där utrustningen har installerats gäller att följande portar måste anslutas
genom en godkänd nätverksavslutningsenhet med integrerat kretsskydd.
Varning
Statement 1071Varningsdefinition
VIKTIGA SÄKERHETSANVISNINGAR
Denna varningssignal signalerar fara. Du befinner dig i en situation som kan leda till personskada. Innan du utför
arbete på någon utrustning måste du vara medveten om farorna med elkretsar och känna till vanliga förfaranden
för att förebygga olyckor. Använd det nummer som finns i slutet av varje varning för att hitta dess översättning i
de översatta säkerhetsvarningar som medföljer denna anordning.
SPARA DESSA ANVISNINGAR
Varning
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
83
Information om överensstämmelse med regelverk och säkerhetskravCisco WRP500 Wireless-G Broadband Router with
2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1072Risk för elektriska stötar från
mellananslutningar
Det kan finnas spänningar på PoE-kretsarna (Power over Ethernet) som utgör risk för stötar om sammankopplingarna
görs med ej isolerade, exponerade kontakter, ledare och/eller terminaler av metall. Undvik att använda sådana
sammankopplingsmetoder, såvida inte de exponerade metalldelarna finns i en plats med begränsad åtkomst.
Användare och servicepersonal som tillåts inom platsen med begränsad åtkomst måste vara medvetna om risken.
Ett begränsat område kan bara nås med ett speciellt verktyg eller lås, en speciell nyckel eller någon annan
säkerhetsmetod.
Varning
Statement 1073Inga delar som användaren kan utföra service
på
Det finns inga delar som användare kan utföra service på. Öppna inte.
Varning
Statement 1074Följ lokala och nationella elbestämmelser
Installation av utrustningen måste ske i enlighet med gällande elinstallationsföreskrifter
Varning
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
84
Information om överensstämmelse med regelverk och säkerhetskravCisco WRP500 Wireless-G Broadband Router with
2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
14
Cisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports
Statement 19TN ,86
Statement 331,86
Statement 353,86
Statement 355Telephone Receivers Produce a Magnetic Field, 86
Statement 361，VoIP ,87
Statement 378,87
Statement 1003,87
Statement 1004,87
Statement 1005,87
Statement 1019,88
Statement 1021SELV ,88
Statement 1030,88
Statement 1040,88
Statement 1044,88
Statement 1072Shock Hazard from Interconnections, 89
Statement 1073,89
Statement 1074,89
：
，
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
85
，
，
，
Statement 19TN
TN
Statement 331
Statement 353
IEEE802.3af (PoE) IEC60950
Statement 355Telephone Receivers Produce a Magnetic Field
Telephone receivers produce a magnetic field that can attract small magnetic objects such as pins and staples.
，
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
86
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 361，VoIP
，IP (VoIP) ，
VoIP ， 911
Statement 378
Statement 1003
，
Statement 1004
，
Statement 1005
（） ：
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
87
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1019
，
Statement 1021SELV
， (SELV) (TNV) LAN SELV
，WAN TNV LAN WAN RJ-45
Statement 1030
Statement 1040
Statement 1044
，
cs-1044-1
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
88
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1072Shock Hazard from Interconnections
Voltages that present a shock hazard may exist on Power over Ethernet (PoE) circuits if interconnections are made
using uninsulated exposed metal contacts, conductors, or terminals. ，
，
Statement 1073
Statement 1074
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
89
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
90
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
15
Cisco WRP500
Wireless-G Broadband Router with 2 Phone Ports
Statement 19TN ,92
Statement 1004,92
Statement 1019,92
Statement 1021SELV ,92
Statement 1030,92
Statement 1040,92
Statement 1071,93
Statement 1074,93
：
，
，， ，
，
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
91
Statement 19TN
TN
Statement 1004
，
Statement 1019
，
Statement 1021SELV
， (SELV) (TNV) SELV
， TNV RJ-45
Statement 1030
Statement 1040
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
92
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1071
，
，， ，
Statement 1074
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
93
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
94
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
16
Cisco WRP500
Wireless-G Broadband Router with 2 Phone Ports
Statement 287 R & TTE 1999/5/O
,,, ,. 96
:
. , ,
.
. ,
. ,
,
. ,
, ,
.
.
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
95
Statement 287 R & TTE
1999/5/O ,
, ,
1999/5/.
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
96
Cisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
KAPITOLA 17
Informace o bezpenosti a dodrování
pedpisCisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports
Statement 287Prohláení o shods R & TTE 1999/5/EC pro Evropské spoleenství, výcarsko,
Norsko, Island a Lichtentejnsko, strana 98
Statement 1003Odpojení od stejnosmrného proudu, strana 98
Statement 1004Pokyny k instalaci, strana 98
Statement 1019Hlavní odpojovací zaízení, strana 99
Statement 1030Instalace zaízení, strana 99
Statement 1040Likvidace produktu, strana 99
Statement 1044Pipojení pomocí port, strana 99
Statement 1071Popis varování, strana 99
Statement 1073ádné díly, na kterých by mohl provádt údrbu uivatel, strana 100
Statement 1074Soulad s vnitrostátními a místními pedpisy pro elektrická zaízení, strana 100
V tomto dokumentu se pouívají následující konvence:
Znamená vyaduje opatrnost tenáe. V této situaci byste mohli provést krok, který zpsobí pokození zaízení
i ztrátu dat.
Upozornní
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
97
DLEITÉ BEZPENOSTNÍ POKYNY
Tento varovný symbol znamená nebezpeí. Nacházíte se v situaci, kdy by mohlo dojít ke zranní osob. Ne zanete
pracovat s jakýmkoli zaízením, uvdomte si rizika spojená s elektrickými obvody a seznamte se se standardními
postupy, jak zabránit nehodám. Podle ísla sdlení uvedeného na konci kadého varování vyhledejte jeho peklad
v peloených bezpenostních upozornních dodaných se zaízením.
TYTO POKYNY USCHOVEJTE
Varování
Sdlení, která obsahují tento symbol, jsou uvádna za úelem poskytnutí dalích informací a splnní pedpis a
poadavk zákazník.
Varování
Statement 287Prohláení o shod s R & TTE 1999/5/EC pro
Evropské spoleenství, výcarsko, Norsko, Island a
Lichtentejnsko
Toto zaízení je v souladu se základními poadavky a ostatními odpovídajícími ustanoveními Smrnice
1999/5/EC.
Poznámka
Statement 1003Odpojení od stejnosmrného proudu
Ne zanete s libovolným z následujících postup, ujistte se, e je okruh stejnosmrného proudu odpojen od
napájení.
Varování
Statement 1004Pokyny k instalaci
Ped pipojením systému ke zdroji napájení si pette pokyny k instalaci.
Varování
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
98
Informace o bezpenosti a dodrování pedpisCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1019Hlavní odpojovací zaízení
Zástrka se zásuvkou musí být vdy pístupné, protoe se jedná o hlavní odpojovací zaízení.
Varování
Statement 1030Instalace zaízení
Instalaci, výmnu i servis tohoto zaízení by mli provádt pouze vykolení a kvalifikovaní pracovníci.
Varování
Statement 1040Likvidace produktu
Konená likvidace produktu musí probhnout v souladu s vnitrostátními pedpisy a smrnicemi.
Varování
Statement 1044Pipojení pomocí port
Pokud se chcete k zaízení pipojit mimo budovu, ve které bylo nainstalováno, pipojte následující porty k jednotce
NTU s ochranou obvod. cs-1044-1
Varování
Statement 1071Popis varování
DLEITÉ BEZPENOSTNÍ POKYNY
Tento varovný symbol pedstavuje nebezpeí. Nacházíte se v situaci, kdy by mohlo dojít ke zranní osob. Ne
zanete pracovat s jakýmkoli zaízením, uvdomte si rizika spojená s elektrickými obvody a seznamte se se
standardními postupy, jak zabránit nehodám. Podle ísla sdlení uvedeného na konci kadého varování vyhledejte
jeho peklad v peloených bezpenostních upozornních dodaných se zaízením.
TYTO POKYNY USCHOVEJTE
Varování
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
99
Informace o bezpenosti a dodrování pedpisCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1073ádné díly, na kterých by mohl provádt
údrbu uivatel
Uvnit zaízení se nenachází ádné díly, na kterých by mohl provádt údrbu uivatel. Neotevírejte.
Varování
Statement 1074Soulad s vnitrostátními a místními pedpisy
pro elektrická zaízení
Instalace zaízení musí probhnout v souladu s vnitrostátními a místními pedpisy pro elektrická zaízení.
Varování
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
100
Informace o bezpenosti a dodrování pedpisCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
KAPITEL 18
Overholdelse af lovgivningen og
sikkerhedsoplysningerCisco WRP500
Wireless-G Broadband Router with 2 Phone Ports
Statement 287Overensstemmelseserklæring til R & TTE-direktivet 1999/5/EF for Det Europæiske
Fællesskab, Schweiz, Norge, Island og Liechtenstein, side 102
Statement 1003DC strømafbrydelse, side 102
Statement 1030 Udstyr Installation, side 102
Statement 1040 Produkt Bortskaffelse, side 102
Statement 1071Definition på advarsel, side 103
Statement 1073Ingen brugerservicerbare dele, side 103
Denne vejledning anvender følgende konventioner:
Betyder, at læseren skal være forsigtig. I denne situation kan du gøre noget, som kunne medføre skade på
udstyret eller tab af data.
Advarsel
VIGTIGE SIKKERHEDSINSTRUKTIONER
Dette advarselssymbol betyder fare. Du befinder dig i en situation, som kunne medføre personskade. Inden du
arbejder med nogen form for udstyr, skal du være opmærksom på de farer, der kan opstå ved arbejde med elektriske
kredsløb, og være bekendt med standardpraksisserne for forebyggelse af ulykker. Brug det erklæringsnummer,
der angives ved slutningen af hver advarsel, til at finde dens oversættelse i de oversatte sikkerhedsadvarsler, som
fulgte med enheden.
GEM DENNE VEJLEDNING
Advarsel
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
101
Erklæringer med dette symbol er angivet for give yderlige oplysninger og for at overholde lovmæssige krav og
kundekrav.
Advarsel
Statement 287Overensstemmelseserklæring til R &
TTE-direktivet 1999/5/EF for Det Europæiske Fællesskab,
Schweiz, Norge, Island og Liechtenstein
Dette udstyr er i overensstemmelse med de væsentlige krav og andre relevante bestemmelser i Direktiv
1999/5/EF.
Bemærk
Statement 1003 DC strømafbrydelse
Før du udfører nogen af følgende procedurer, skal du sikre dig, at der ikke er strøm til jævnstrømskredsløbet.
Advarsel
Statement 1030 Udstyr Installation
Kun uddannede personer må installere, udskifte komponenter i eller servicere dette udstyr.
Advarsel
Statement 1040 Produkt Bortskaffelse
Endelig bortskaffelse af dette produkt skal ske i henhold til gældende love og regler.
Advarsel
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
102
Overholdelse af lovgivningen og sikkerhedsoplysningerCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1071Definition på advarsel
VIGTIG SIKKERHEDSVEJLEDNING
Dette advarselssymbol betyder fare. Du befinder dig i en situation, som kunne medføre personskade. Inden du
arbejder med nogen form for udstyr, skal du være opmærksom på de farer, der kan opstå ved arbejde med elektriske
kredsløb, og være bekendt med standardpraksisserne for forebyggelse af ulykker. Brug det erklæringsnummer,
der angives ved slutningen af hver advarsel, til at finde dens oversættelse i de oversatte sikkerhedsadvarsler, som
fulgte med enheden.
GEM DENNE VEJLEDNING
Advarsel
Statement 1073Ingen brugerservicerbare dele
Ingen brugerservicerbare dele indeni. Må ikke åbnes.
Advarsel
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
103
Overholdelse af lovgivningen og sikkerhedsoplysningerCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
104
Overholdelse af lovgivningen og sikkerhedsoplysningerCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
19
Cisco WRP500
Wireless-G Broadband Router with 2 Phone Ports
Statement 287 R & TTE 1999/5/K
, , , , 106
Statement 1003 DC , 106
Statement 1004 , 106
Statement 1030 , 107
Statement 1040 , 107
Statement 1071 , 107
Statement 1073 , 107
Statement 1074
, 108
:
. ,
.
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
105
.
. ,
.
.
.
Statement 287 R &
TTE 1999/5/K , ,
,
µ µµ µ
1999/5/EC.
Statement 1003 DC
,
DC .
Statement 1004
, .
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
106
Cisco WRP500 Wireless-G Broadband Router with
2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1030
,
.
Statement 1040
.
Statement 1071
.
. ,
.
.
Statement 1073
. .
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
107
Cisco WRP500 Wireless-G Broadband Router with
2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1074
.
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
108
Cisco WRP500 Wireless-G Broadband Router with
2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
PEATÜKK 20
Eeskirjade järgimine ja ohutusteaveCisco
WRP500 Wireless-G Broadband Router with 2
Phone Ports
Statement 287Vastavusdeklaratsiooni R & TTE direktiivi 1999/5/EÜ, et Euroopa Ühendus, veits,
Norra, Island ja Liechtenstein, lehekülg 110
Selles dokumendis on kasutatud järgmisi tingmärke:
See manitseb lugejat ettevaatusele. Selles olukorras võib teatud tegutsemine kahjustada seadmeid või põhjustada
andmete kadumist.
Ettevaatust
TÄHTSAD OHUTUSEESKIRJAD
See ohusümbol tähistab ohtu. Olete olukorras, kus on kehavigastuste oht. Enne töö alustamist seadmetega olge
teadlik elektrisüsteemiga seotud ohtudest ja tutvuge töötamistavadega, et hoida ära õnnetusi. Iga hoiatuse järel
oleva numbri järgi leiate selle seletuse seadmega kaasas olevate ohutusnõuete tõlkest.
HOIDKE NEED JUHISED ALLES
Hoiatus
Seda sümbolit sisaldavad laused on täiendavaks teabeks ning vastavad eeskirjadele ja kliendi nõuetele.
Hoiatus
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
109
Statement 287Vastavusdeklaratsiooni R & TTE direktiivi
1999/5/EÜ, et Euroopa Ühendus, veits, Norra, Island ja
Liechtenstein
See seade vastab direktiivi 1999/5/EÜ olulistele nõuetele ja teistele asjakohastele sätetele.Märkus
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
110
Eeskirjade järgimine ja ohutusteaveCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
KAFLI 21
reglufylgni og öryggisupplýsingarCisco
WRP500 Wireless-G Broadband Router with 2
Phone Ports
Statement 287Samræmisyfirlýsing til R & TTE tilskipun 1999/5/EB um Evrópubandalagsins, Sviss,
Noregi, Íslandi og Liechtenstein, síða 112
Í þessu skjali eru notaðar eftirfarandi merkingar:
Merkir að lesandi skuli fara varlega. Í slíkum tilfellum gætirðu gert eitthvað sem kann að valda því að búnaður
skemmist eða gögn glatist.
Varúð
MIKILVÆGAR ÖRYGGISLEIÐBEININGAR
Þetta viðvörunarmerki merkir hættu. Þessar aðstæður gætu valdið líkamstjóni. Áður en þú byrjar að vinna með
hvers kyns búnað skaltu gera þér ljósar hætturnar sem tengjast rafrásum og kunna skil á hefðbundnum aðferðum
til að koma í veg fyrir slys. Notaðu númer yfirlýsingarinnar í lok hverrar viðvörunar til að finna þýðingu á henni í
þýddum viðvörunum sem fylgdu með þessu tæki.
GEYMDU ÞESSAR LEIÐBEININGAR
Viðvörun
Yfirlýsingar sem nota þetta tákn eru látnar fylgja til að veita viðbótarupplýsingar og til að uppfylla kröfur stjórnvalda
og viðskiptavina.
Viðvörun
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
111
Statement 287Samræmisyfirlýsing til R & TTE tilskipun
1999/5/EB um Evrópubandalagsins, Sviss, Noregi, Íslandi og
Liechtenstein
Þetta tæki er samkvæmt grunnkröfum og öðrum viðeigandi ákvæðum Tilskipunar 1999/5/EC.Athugið
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
112
reglufylgni og öryggisupplýsingarCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
SKYRIUS 22
reglamentinei atitikties ir saugos
informacijaiCisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports
Statement 287Atitikties deklaracija R & TTE direktyvos 1999/5/EB dl Europos bendrijos, veicarijos,
Norvegijos, Islandijos ir Lichtenteino, puslapis 114
iame dokumente naudojami tokie sutartiniai enklai:
Tai reikia, kad skaitytojas turi bti atsargus. ioje situacijoje galite atlikti veiksm, dl kurio bus sugadinta
ranga arba prarasti duomenys.
spjimas
SVARBIOS SAUGOS INSTRUKCIJOS
is perspjimo simbolis nurodo pavoj. Esamoje situacijoje galimas kno sualojimas. Prie dirbant su bet kokia
ranga, atsivelkite pavojus, susijusius su elektros grandine, ir susipainkite su standartine nelaiming vyki
prevencijos praktika. Naudodami pareikimo numer, pateikt kiekvieno perspjimo pabaigoje, susiraskite vertim
iverstuose saugumo perspjimuose, kurie buvo pridti prie io prietaiso.
ISAUGOKITE IAS INSTRUKCIJAS
Perspjimas
iuo simboliu paymti pareikimai pateikiami papildomai informacijai ir siekiant utikrinti reglamentini ir
kliento reikalavim laikymosi.
Perspjimas
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
113
Statement 287Atitikties deklaracija R & TTE direktyvos
1999/5/EB dl Europos bendrijos, veicarijos, Norvegijos,
Islandijos ir Lichtenteino
is renginys tenkina 1999/5/EB Direktyvos esminius reikalavimus ir kitas ios direktyvos nuostatas.
Pastaba
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
114
reglamentinei atitikties ir saugos informacijaiCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
NODAA 23
Atbilstba normatviem un informcija par
drobuCisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports
Statement 287Atbilstbas deklarcija, lai R & TTE Direktvas 1999/5/EK par Eiropas Kopienu, veici,
Norviju, slandi un Lihtenteinu, lappuse 116
ajdokumentizmantoti di apzmjumi:
Norda, ka lastjam jbt uzmangam. ajsitucijvar gadties, ka jsu darbbu rezulttvar tikt bojta
aparatra vai zaudti dati.
Uzmanbu
SVARGI DROBAS NORDJUMI
is brdinjuma simbols norda uz bstambu. Js esat situcij, kur iespjams gt traumas. Pirms skat lietot
aparatru, jums japzins ar elektriskm shmm saisttie riski un japgst standarta paskumi nelaimes gadjumu
novranai. Izmantojiet aiz katra brdinjuma nordto nordjuma numuru, lai atrastu nordjuma tulkojumu
s ierces komplekt iekautajos drobas brdinjumu tulkojumos.
SAGLABJIET OS NORDJUMUS
Brdinjums
Nordjumi ar o simbolu sniedz papildinformciju, un tie ir paredzti, lai nodrointu atbilstbu normatvajm un
klientu prasbm.
Brdinjums
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
115
Statement 287Atbilstbas deklarcija, lai R & TTE Direktvas
1999/5/EK par Eiropas Kopienu, veici, Norviju, slandi un
Lihtenteinu
iekrta atbilst Direktvas 1999/5/EK btiskajm prasbm un citiem ar to saisttajiem noteikumiem.
Piezme
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
116
Atbilstba normatviem un informcija par drobuCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
KAPITLU 24
Konformità mar-Regolamenti u Informazzjoni
Dwar is-SigurtàCisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports
Statement 287Dikjarazzjoni ta 'Konformità gall-R & TTE 1999/5/KE gall-Komunità Ewropea,
l-Ivizzera, in-Norveja, l-Ilanda u l-Liechtenstein, pana 118
Dan id-dokument jagmel uu mill-konvenzjonijiet li ejjin:
Ifisser qarrej oqgod attent. Fdin is-sitwazzjoni, jistajkun inti twettaq azzjoni li tistatirriulta fi sara
lit-tagmir jew ftelf tadejta.
Attenzjoni
STRUZZJONIJIET IMPORTANTI DWAR IS-SIGURTÀ
Dan is-sinjal ta twissija jfisser periklu. Inti tinsab fsitwazzjoni li tista tikkawa korriment. Qabel ma tadem fuq
kwalunkwe tagmir, kun konxju/a dwar il-perikli assojati ma irkwiti elettrii, u ffamiljarizza ruek mal-prattiki
standard gall-prevenzjoni tal-inidenti. Ua n-numru tad-dikjarazzjoni pprovdut fl-aar ta kull twissija biex
issib it-traduzzjoni tagha fit-twissijiet tas-sigurtà tradotti li ew ipprovduti ma dan l-apparat.
OMM DAWN L-ISTRUZZJONIJIET
Twissija
Dikjarazzjonijiet li juaw dan is-simbolu huma pprovduti bala informazzjoni addizzjonali, u sabiex ikun hemm
konformità mar-rekwiiti regolatorji u mar-rekwiiti tal-klijent.
Twissija
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
117
Statement 287Dikjarazzjoni ta 'Konformità gall-R & TTE
1999/5/KE gall-Komunità Ewropea, l-Ivizzera, in-Norveja,
l-Ilanda u l-Liechtenstein
Dan l-apparat huwa konformi mal-tiiet essenzjali u l-provedimenti l-ora rilevanti tad-Direttiva 1999/5/EC.
Nota
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
118
Konformità mar-Regolamenti u Informazzjoni Dwar is-SigurtàCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
ROZDZIA25
Informacje o zgodnoci i
bezpieczestwieCisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports
Statement 287Deklaracja zgodnoci z R & TTE 1999/5/WE w odniesieniu do Wspólnoty Europejskiej,
Szwajcarii Norwegia, Islandia i Liechtenstein, strona 120
Statement 1003Odczenie zasilania prdem staym, strona 120
Statement 1004Instrukcje dotyczce instalacji, strona 120
Statement 1019Gówne urzdzenie rozczajce, strona 121
Statement 1030Instalacja sprztu, strona 121
Statement 1040Utylizacja produktu, strona 121
Statement 1044Poczenia portów, strona 121
Statement 1071Definicja ostrzeenia, strona 121
Statement 1073Brak czci serwisowanych przez uytkownika, strona 122
Statement 1074Wymóg przestrzegania miejscowego i krajowego kodeksu elektrycznego, strona 122
W podrczniku zastosowano nastpujce konwencje:
Oznacza, enaley zachowaostrono. Wskazuje sytuacj, w której uytkownik moe wykonaczynno
skutkujcuszkodzeniem sprztu lub utratdanych.
Przestroga
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
119
WANE INSTRUKCJE DOTYCZCE BEZPIECZESTWA
Ten symbol ostrzegawczy oznacza zagroenie. Znajdujesz si w sytuacji, w której naraony jeste na odniesienie
obrae cielesnych. Obsugujc jakiekolwiek urzdzenie, naley zdawa sobie spraw z grocego ryzyka
poraenia prdem oraz zapozna si z podstawowymi zasadami zapobiegania wypadkom. Posugujc si numerem
umieszczonym na kocu kadego ostrzeenia, naley odnale jego tumaczenie w przetumaczonym spisie
ostrzee dotyczcych bezpieczestwa doczonym to tego urzdzenia.
INSTRUKCJE NALEY ZACHOWA
Ostrzeenie
Zdania, przy których znajduje si ten symbol, stanowi dodatkow informacj pozwalajc na zachowanie
zgodnoci z wymaganiami stawianymi przez prawo oraz przez klienta.
Ostrzeenie
Statement 287Deklaracja zgodnoci z R & TTE 1999/5/WE w
odniesieniu do Wspólnoty Europejskiej, Szwajcarii Norwegia,
Islandia i Liechtenstein
Urzdzenie jest zgodne z ogólnymi wymaganiami oraz szczególnymi warunkami okrelonymi Dyrektyw
UE: 1999/5/EC.
Uwaga
Statement 1003Odczenie zasilania prdem staym
Przed wykonaniem którejkolwiek z poniszych procedur, naley upewni si, e obwód prdu staego zosta
odczony od róda zasilania.
Ostrzeenie
Statement 1004Instrukcje dotyczce instalacji
Przed podczeniem systemu do róda zasilania, naley zapozna si z instrukcjami dotyczcymi instalacji.
Ostrzeenie
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
120
Informacje o zgodnoci i bezpieczestwieCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1019Gówne urzdzenie rozczajce
Gniazdo sieciowe, do którego jest podczona wtyczka musi by dostpne przez cay czas, poniewa suy jako
gówne urzdzenie rozczajce.
Ostrzeenie
Statement 1030Instalacja sprztu
Tylko odpowiednio przeszkolony i wykwalifikowany personel moe przeprowadza instalacj, wymian lub
konserwacj niniejszego sprztu.
Ostrzeenie
Statement 1040Utylizacja produktu
Ostateczna utylizacja produktu musi odbywa si zgodnie z wszelkimi obowizujcymi przepisami krajowymi.
Ostrzeenie
Statement 1044Poczenia portów
W przypadku pocze wykonywanych na zewntrz budynku w miejscach, w których instalowany jest sprzt,
ponisze porty naley podczy przy uyciu zatwierdzonego zakoczenia sieciowego wyposaonego w
zintegrowane zabezpieczenie obwodu. cs-1044-1
Ostrzeenie
Statement 1071Definicja ostrzeenia
IWANE INSTRUKCJE DOTYCZCE BEZPIECZESTWA
Ten symbol ostrzegawczy oznacza niebezpieczestwo. Znajdujesz si w sytuacji, w której naraony jeste na
odniesienie obrae cielesnych. Obsugujc jakiekolwiek urzdzenie, naley zdawa sobie spraw z grocego
ryzyka poraenia prdem oraz zapozna si z podstawowymi zasadami zapobiegania wypadkom. Posugujc si
numerem umieszczonym na kocu kadego ostrzeenia, naley odnale jego tumaczenie w spisie ostrzee
dotyczcych bezpieczestwa doczonym to tego urzdzenia.
NALEY ZACHOWA NINIEJSZ INSTRUKCJ.
Ostrzeenie
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
121
Informacje o zgodnoci i bezpieczestwieCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1073Brak czci serwisowanych przez
uytkownika
Urzdzenie nie zawiera czci serwisowanych przez uytkownika. Nie otwiera.
Ostrzeenie
Statement 1074Wymóg przestrzegania miejscowego i
krajowego kodeksu elektrycznego
Instalacja sprztu musi odbywa si w sposób zgodny z miejscowym i krajowym kodeksem elektrycznym.
Ostrzeenie
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
122
Informacje o zgodnoci i bezpieczestwieCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
CAPITOLUL 26
Informaii referitoare la siguran i
conformitatea cu reglementrileCisco WRP500
Wireless-G Broadband Router with 2 Phone Ports
Statement 287Declaraia de conformitate cu R & TTE Directiva 1999/5/CE pentru Comunitatea
European, Elveia, Norvegia, Islanda i Liechtenstein, pagina 124
În acest document sunt utilizate urmtoarele convenii:
Înseamnccititorul trebuie sacorde atenie acestor informaii. În aceastsituaie, este vorba de aciuni
care ar putea cauza deteriorarea echipamentului sau pierderea datelor.
Atenie
INSTRUCIUNI IMPORTANTE PENTRU SIGURAN
Acest simbol de avertisment marcheaz o situaie periculoas. V aflai într-o situaie care ar putea cauza vtmri
corporale. Înainte de a utiliza orice echipament, trebuie s fii contient de pericolele implicate de circuitele
electrice i s fii familiarizat cu practicile standard de prevenire a accidentelor. Utilizai numrul de la finalul
fiecrui avertisment pentru a localiza traducerea avertismentului respectiv în documentele traduse care însoesc
acest dispozitiv.
PSTRAI ACESTE INSTRUCIUNI
Avertisment
Declaraiile care utilizeaz acest simbol sunt furnizate pentru informaii suplimentare i pentru a respecta cerinele
de reglementare i ale clientului.
Avertisment
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
123
Statement 287Declaraia de conformitate cu R & TTE Directiva
1999/5/CE pentru Comunitatea European, Elveia, Norvegia,
Islanda i Liechtenstein
Acest echipament este in conformitate cu cerintele esentiale si cu alte prevederi relevante ale Directivei
1999/5/EC.
Not
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
124
Informaii referitoare la siguran i conformitatea cu reglementrileCisco WRP500 Wireless-G Broadband Router
with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
KAPITOLA 27
Dodriavanie predpisov a bezpenostné
informácieCisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports
Statement 287Declaraia de conformitate cu R & TTE Directiva 1999/5/CE pentru Comunitatea
European, Elveia, Norvegia, Islanda i Liechtenstein, strana 126
Statement 1003Odpojenie jednosmerného prúdu, strana 126
Statement 1004Pokyny na intaláciu, strana 126
Statement 1019Sieové odpojovacie zariadenie, strana 126
Statement 1030Intalácia zariadenia, strana 127
Statement 1040Likvidácia výrobku, strana 127
Statement 1044Pripojenia portov, strana 127
Statement 1071Definícia upozornenia, strana 127
Statement 1073iadne súasti, ktorých servis môe vykonávapouívate, strana 127
Statement 1074Dodriavajte tátne a miestne elektrotechnické normy, strana 128
Tento dokument vyuíva nasledujúce dohody:
Preítajte si pozorne. V tejto situácii by mohlo vae konanie spôsobipokodenie vybavenia alebo stratu
údajov.
Pozor
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
125
DÔLEITÉ BEZPENOSTNÉ POKYNY
Tento varovný symbol znamená nebezpeenstvo. Ste v situácii, ktorá by mohla vies k telesnému poraneniu. Pred
prácou na ktoromkovek zariadení si uvedomte riziká v súvislosti s elektrickými obvodmi a oboznámte sa so
tandardnými postupmi predchádzania nehodám. Preklad kadého upozornenia nájdete v preloených
bezpenostných upozorneniach dodávaných s týmto zariadením poda ísla vyhlásenia, ktoré sa nachádza na konci
kadého upozornenia.
TIETO POKYNY SI ULOTE.
Varovanie
Vyhlásenia s týmto symbolom obsahujú doplujúce informácie a sú v súlade s regulanými poiadavkami a
poiadavkami zákazníkov.
Varovanie
Statement 287Declaraia de conformitate cu R & TTE Directiva
1999/5/CE pentru Comunitatea European, Elveia, Norvegia,
Islanda i Liechtenstein
Toto zariadenie je v zhode so základnými poiadavkami a inými príslunými nariadeniami direktív: 1999/5/EC.
Poznámka
Statement 1003Odpojenie jednosmerného prúdu
Pred vykonaním ktorejkovek z nasledujúcich inností sa presvedte, e jednosmerný obvod je odpojený.
Varovanie
Statement 1004Pokyny na intaláciu
Pred pripojením systému k zdroju elektrickej energie si preítajte pokyny na intaláciu.
Varovanie
Statement 1019Sieové odpojovacie zariadenie
Spojenie zástrky so zásuvkou musí by vdy dostupné, pretoe slúi ako hlavné odpojovacie zariadenie.
Varovanie
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
126
Dodriavanie predpisov a bezpenostné informácieCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1030Intalácia zariadenia
Intalova a vymiea zariadenie alebo vykonáva jeho servis smú len vykolení a kvalifikovaní pracovníci.
Varovanie
Statement 1040Likvidácia výrobku
Konená likvidácia tohto výrobku by sa mala vykonáva poda vetkých tátnych právnych predpisov.
Varovanie
Statement 1044Pripojenia portov
V prípade pripojení mimo budovy, v ktorej je zariadenie naintalované, musia by nasledujúce porty pripojené
prostredníctvom schváleného sieového zakonenia s ucelenou ochranou obvodu. cs-1044-1
Varovanie
Statement 1071Definícia upozornenia
DÔLEITÉ BEZPENOSTNÉ POKYNY
Tento výstraný symbol znamená nebezpeenstvo. Ste v situácii, ktorá by mohla vies k telesnému poraneniu.
Pred prácou na ktoromkovek zariadení si uvedomte riziká v súvislosti s elektrickými obvodmi a oboznámte sa so
tandardnými postupmi predchádzania nehodám. Preklad kadého upozornenia nájdete v preloených
bezpenostných upozorneniach dodávaných s týmto zariadením poda ísla vyhlásenia, ktoré sa nachádza na konci
kadého upozornenia.
TIETO POKYNY SI ODLOTE
Varovanie
Statement 1073iadne súasti, ktorých servis mô e vykonáva
pouívate
Vnútri nie sú iadne súasti, ktorých servis môe vykonáva pouívate. Neotvárajte.
Varovanie
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
127
Dodriavanie predpisov a bezpenostné informácieCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1074Dodriavajte tátne a miestne
elektrotechnické normy
Intalácia zariadenia musí by v súlade s miestnymi a tátnymi elektrotechnickými normami.
Varovanie
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
128
Dodriavanie predpisov a bezpenostné informácieCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
28
Cisco WRP500
Wireless-G Broadband Router with 2 Phone Ports
Statement 295 B, 130
Statement 1003DC , 130
Statement 1004 , 130
Statement 1019 , 130
Statement 1030 , 130
Statement 1040 , 131
Statement 1044 , 131
Statement 1071 , 131
Statement 1073 , 131
Statement 1074 , 131
.
. ,
.
. .
.
.
.
!
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
129
.
!
Statement 295 B
B EMC .
.
!
Statement 1003DC
DC .
!
Statement 1004
.
!
Statement 1019
- .
!
Statement 1030
.
!
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
130
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1040
.
!
Statement 1044
. cs-1044-1
!
Statement 1071
. .
.
.
!
Statement 1073
. .
!
Statement 1074
.
!
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
131
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
132
Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
POGLAVJE 29
Informacije o skladnosti s predpisi in
varnostiCisco WRP500 Wireless-G Broadband
Router with 2 Phone Ports
Statement 331Opozorilo za namestitev napajalnika, stran 134
Statement 1019Glavna prekinitvena naprava, stran 134
Statement 1030Namestitev opreme, stran 134
Statement 1040Odmetavanje izdelka, stran 134
Statement 1044Povezave vrat, stran 134
Statement 1074Upotevajte lokalne in nacionalne elektrine predpise, stran 134
V tem dokumentu se uporabljajo naslednji dogovori:
Pomeni, naj bo bralec previden. V teh okoliinah lahko izvedete dejanje, ki bi lahko imelo za posledico
pokodbe opreme ali izgubo podatkov.
Pozor
POMEMBNE VARNOSTNE INFORMACIJE
Ta znak opozarja na nevarnost. Ste v okoliinah, ki bi lahko povzroile telesne pokodbe. Pred deli na kakrni
koli opremi upotevajte nevarnosti elektrinih vezij in se seznanite s standardnimi postopki za prepreevanje
nesre. S tevilko izjave, navedeno na koncu vsakega opozorila, poiite prevod v prevedenih varnostnih opozorilih,
ki ste jih dobili s to napravo.
SHRANITE TA NAVODILA
Opozorilo
Izjave, ki uporabljajo ta znak, so navedene za dodatne informacije ter skladnost s predpisi in zahtevami strank.
Opozorilo
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
133
Statement 331Opozorilo za namestitev napajalnika
Napajalnik mora biti nameen znotraj.
Opozorilo
Statement 1019Glavna prekinitvena naprava
Kombinacija vtia in vtinice mora biti vedno dostopna, ker deluje kot glavna prekinitvena naprava.
Opozorilo
Statement 1030Namestitev opreme
To opremo lahko namea, zamenjuje ali servisira samo pooblaeno osebje.
Opozorilo
Statement 1040Odmetavanje izdelka
Izdelek zavrzite skladno z vsemi nacionalnimi predpisi in zakonodajo.
Opozorilo
Statement 1044Povezave vrat
Za povezave zunaj zgradbe, kjer je nameena oprema, je treba naslednja vrata prikljuiti prek odobrene
zakljuitvene enote z vgrajeno zaito tokokroga:
Opozorilo
Statement 1074Upotevajte lokalne in nacionalne elektrine
predpise
Namestitev opreme mora biti skladna z vsemi lokalnimi in nacionalnimi elektrinimi predpisi.
Opozorilo
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
134
Informacije o skladnosti s predpisi in varnostiCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
30
Cisco WRP500 Wireless-G Broadband Router
Regulatory with 2 Phone Ports
Compliance
136 , Statement 1003
136 , Statement 1030
136 , Statement 1040
136 , Statement 1071
136 , Statement 1073
:
.
.
. .
.
.
.
Cisco WRP500 Wireless-G Broadband Router with 2 Phone PortsRegulatory Compliance and Safety Information
135
Statement 1003
.DC
Statement 1030
.
Statement 1040
.
Statement 1071
. .
.
.
Statement 1073
.
Cisco WRP500 Wireless-G Broadband Router with 2 PhoneRegulatory Compliance and Safety Information
Ports
136
Regulatory Compliance Cisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
POGLAVLJE 31
Usklaenost sa propisima i informacije o
sigurnostiCisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports
Statement 1003Iskljuenje napajanja istosmjernog napona, stranica 138
Statement 1030Instaliranje opreme, stranica 138
Statement 1040Odlaganje proizvoda, stranica 138
Statement 1071Definicija upozorenja, stranica 138
Statement 1073Nema dijelova koje moe servisirati korisnik, stranica 138
U izdanju se koriste sljedee konvencije:
Napomena znai da itatelj mora biti oprezan. U toj situaciji moete uiniti neto to moe otetiti opremu
ili prouzroiti gubitak podataka.
Oprez
VANE SIGURNOSNE UPUTE
Ovaj simbol upozorenja oznaava opasnost. Nalazite se u situaciji koja moe prouzroiti ozljedu. Prije poetka
rada s bilo kojom opremom morate biti svjesni moguih opasnosti povezanih s elektrinim instalacijama te poznavati
standardne postupke sprjeavanja nesrea. Odgovarajui prijevod meu prevedenim sigurnosnim upozorenjima,
koja ste dobili s ovim ureajem, potraite pomou broja izjave na kraju svakog upozorenja.
SPREMITE OVE UPUTE
Upozorenje
Izjave s ovim simbolom slue za dodatne informacije i zadovoljenje propisa i zahtjeva kupaca.
Upozorenje
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
137
Statement 1003Iskljuenje napajanja istosmjernog napona
Prije provoenja sljedeih postupaka pobrinite se da je napajanje iskljueno iz kruga istosmjerne struje.
Upozorenje
Statement 1030Instaliranje opreme
Ovu opremu smije instalirati, mijenjati i servisirati samo osposobljeno i kvalificirano osoblje.
Upozorenje
Statement 1040Odlaganje proizvoda
Konano odlaganje ovog proizvoda treba obaviti u skladu s nacionalnim zakonima i propisima.
Upozorenje
Statement 1071Definicija upozorenja
VANE SIGURNOSNE UPUTE
Ovaj simbol upozorenja oznaava opasnost. Nalazite se u situaciji koja moe prouzroiti ozljedu. Prije poetka
rada s bilo kojom opremom morate biti svjesni moguih opasnosti povezanih s elektrinim instalacijama te poznavati
standardne postupke sprjeavanja nesrea. Odgovarajui prijevod meu prevedenim sigurnosnim upozorenjima,
koja ste dobili s ovim ureajem, potraite pomou broja izjave na kraju svakog upozorenja.
SPREMITE OVE UPUTE
Upozorenje
Statement 1073Nema dijelova koje moe servisirati korisnik
Unutar jedinice nema dijelova koje moe servisirati korisnik. Ne otvarajte.
Upozorenje
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
138
Usklaenost sa propisima i informacije o sigurnostiCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
32
Cisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports
Statement 1003 , 140
Statement 1030 , 140
Statement 1040 , 140
Statement 1071 , 140
Statement 1073 ,
141
:
. ,
.
.
. ,
.
.
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
139
.
Statement 1003
,
.
Statement 1030
,
.
Statement 1040
.
Statement 1071
.
. ,
.
.
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
140
Cisco WRP500 Wireless-G Broadband Router with 2
Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1073
. .
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
141
Cisco WRP500 Wireless-G Broadband Router with 2
Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
142
Cisco WRP500 Wireless-G Broadband Router with 2
Phone Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
CAPÍTULO 33
Conformidade regulamentar e informações de
segurançaCisco WRP500 Wireless-G
Broadband Router with 2 Phone Ports
Statement 1003 DC Power Disconnection, página 144
Statement 1004Instruções para instalação, página 144
Statement 1019Principal dispositivo de desconexão, página 144
Statement 1030 Equipment Installation, página 144
Statement 1040 Product Disposal, página 144
Statement 1044Conexões de portas, página 145
Statement 1071Definição de aviso, página 145
Statement 1073Nenhuma peça que possa ser reparada pelo usuário , página 145
Statement 1074Conformidade com as normas elétricas locais e nacionais , página 145
Este documento utiliza as seguintes convenções:
Significa que o leitor deve tomar cuidado. Nesta situação, você pode fazer algo que cause danos ao equipamento
ou perda de dados.
Cuidado
INSTRUÇÕES DE SEGURANÇA IMPORTANTES
Este símbolo de alerta significa perigo. Esta situação pode causar ferimentos. Antes de trabalhar com um
equipamento, conheça os perigos relacionados aos circuitos elétricos e os procedimentos normalmente utilizados
para evitar acidentes. Utilize o número da instrução disponibilizado no fim de cada aviso para localizar a respectiva
tradução dos avisos de segurança que acompanham este dispositivo.
GUARDE ESTAS INSTRUÇÕES
Aviso
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
143
Instruções com este símbolo indicam informações adicionais e conformidade com a regulamentação e necessidades
do cliente.
Aviso
Statement 1003 DC Power Disconnection
Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Aviso
Statement 1004Instruções para instalação
Leia as instruções para instalação antes de conectar o sistema à fonte de energia.
Aviso
Statement 1019Principal dispositivo de desconexão
A tomada deve estar acessível a qualquer momento, uma vez que é o principal dispositivo de desconexão.
Aviso
Statement 1030 Equipment Installation
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Aviso
Statement 1040 Product Disposal
Ultimate disposal of this product should be handled according to all national laws and regulations.
Aviso
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
144
Conformidade regulamentar e informações de segurançaCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Statement 1044Conexões de portas
Para ligações fora do edifício onde o equipamento está instalado, é necessário ligar as seguintes portas através
de uma unidade de terminal de rede aprovada com proteção de circuito integral.
Aviso
Statement 1071Definição de aviso
INSTRUÇÕES DE SEGURANÇA IMPORTANTES
Esse símbolo de aviso significa perigo. A situação apresentada pode provocar lesões. Antes de trabalhar com um
equipamento, saiba quais os perigos relacionados aos circuitos elétricos e familiarize-se com os procedimentos
normalmente utilizados para evitar os acidentes. Utilize o número de declaração fornecido no fim de cada aviso
para localizar a respectiva tradução nos avisos de segurança traduzidos que acompanham este dispositivo.
GUARDE ESSAS INSTRUÇÕES
Aviso
Statement 1073Nenhuma peça que possa ser reparada pelo
usuário
Não existem peças no interior que possam ser reparadas pelo usuário. Não abra.
Aviso
Statement 1074Conformidade com as normas elétricas locais
e nacionais
A instalação do equipamento deve estar em conformidade com as normas elétricas locais e nacionais.
Aviso
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
145
Conformidade regulamentar e informações de segurançaCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
146
Conformidade regulamentar e informações de segurançaCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
REVIEW DRAFT - CISCO CONFIDENTIAL
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco
trademarks, go to this URL: http://www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their respective
owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (1110R)
©2014 Cisco Systems, Inc. All rights reserved.
____________________________________________________________________________________________________________________________________________________________________
Cisco et le logo Cisco sont des marques ou des marques déposées de Cisco et/ou de ses filiales aux États-Unis et dans d'autres pays. Pour afficher la liste
des marques Cisco, rendez-vous à l'adresse : http://www.cisco.com/go/trademarks. Les autres marques mentionnées sont la propriété de
leurs détenteurs respectifs. L'utilisation du mot "partenaire" n'implique aucune relation de partenariat entre Cisco et toute autre entreprise. (1110R)
©2014 Cisco Systems, Inc. Tous droits réservés.
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone Ports
147
REVIEW DRAFT - CISCO CONFIDENTIAL
Regulatory Compliance and Safety InformationCisco WRP500 Wireless-G Broadband Router with 2 Phone
Ports
148
REVIEW DRAFT - CISCO CONFIDENTIAL
