Compoka Electronic Technology KBJ-151N BT SPORTS BEHIND NECK HEADPHONE User Manual KBJ 151N
Shenzhen Compoka Electronic Technology Co., Ltd BT SPORTS BEHIND NECK HEADPHONE KBJ 151N
User manual
User's Manual
KBJ-151N
Stereo Headset
立体声蓝牙耳机
使用说明书
Bluetooth 4.0
USB charging port
Switch on: Press 3 seconds to switch on, the blue indicator
will be in(voice prompts in English）. Press 2.5 seconds, it
enters into pairing mode, the red and blue indicators take
turns to flash.(voice prompts in English）; power will switch
off automatically after 5 minutes no devices to connect .
In music mode, press it 1 time to pause, and press it
again to play. (when phone call comes, the music will
be off. When phone call is off, the music will continue.
Short press “volume increase”key for 1 time to increase
volume with one point, long press to increase volume all
the time. The voice prompts will appear when the volume
up to the maximum.
Short press “volume Decrease”key for 1 time to decrease
volume with one point, long press to decrease volume all
the time (the “Du
,
Du ” warning sound will appear when the
volume up to the minimum).
10:30 90%
KBJ-151N
蓝牙
现为可被发现状态
设备
已连接
ON/OFF
蓝牙通用
0201 03 04
Thank you for selecting our latest Bluetooth headset, please
read this User's Manual carefully before you operate this
headset, and please save this Manual for further reference.
Before operating, please read all the Safety notice to make sure
the safe and appropriate use.
Safety Notice:
Please observe the rules of the Country or Region which you
are in while driving.
Do not disassemble or modify the headset at any reason,
otherwise, It may damage or burn the headset.
If there is any quality problem, please send the headset to
authorized service center for repairing.
Please keep the equipment along with all the accessories out
of the reach of children and pets. It will cause suffocation and
serious injury.
Do not put the device under the environment which the
temperature is too low or too high ( Below 0℃ or over 45℃).
Extreme temperatures will cause the device deformation,
reduce the charging capacity and shorten the working life.
Please do not wet the device, for the liquid can cause serious
damage to the device. Please do not touch the device by wet
hands. It is out of the maintenance range for the damage
caused by water.
Please avoid closing to the eyes of children and pets when
using the flash indicator of the device.
Please do not operate the device in thunderstorm weather.
It will damage your hearing if you listen with high
volume for a long time. It is recommended that
only use the lowest volume which is necessary
for speaking and listening to music.
1. Guide
■ Headset introduction
※ Contents: Bluetooth Headset, USB Charging Cable,
User's Manual
USB Charging Cable:
2.Instruction
■ Key Function
Power
switch
Previous
song
Next Song
Volume
Increase
Volume
Decrease
Play
Pause
■ How to connect with two Bluetooth mobile phones:
3. Battery power of bluetooth headset displayed on Iphone
※ After connected with Iphone, the battery power of the
headset will be displayed on the phone.
Press “function key” to receive phone call, press it
again to end the phone call.
Press the key by twice continuously to re-dial the last
phone number.
Press the key for 2 seconds to reject the phone call.
In the Music Mode, press it to play previous song.
In the Music Mode, press it to play next song.
90%
Headband
Silicone Sheath
Silicone ear buds
Ear arm (horn base)
LED indicator
Microphone
Automatic reset volume switch
Automatically reset previous song
Next song switch
Music play/pause
8
10 11
9
6
10
11
8
7
9
3
2
45
1
Power switch/Pairing
Receive/Hang up phone call
Re-dial the last phone No
Receive
Hang up
phone call
Switch off: Press 3 seconds to switch off, the red indicator
flashes one time mean the device is switched off (voice
prompts in English）
1) Turn on the bluetooth function of mobile phone 1.
2) Press " " of bluetooth headset for 4~5 seconds, bluetooth
switch on and enters into pairing mode, the red and blue
indicators take turns to flash, make connection with phone 1
(English voice prompts)
3) Press " " for 3 seconds to switch off the headset(voice
prompts), and phone 1 is disconnected, meanwhile turn off
the bluetooth function of phone 1.
4) Return on the bluetooth headset, and make it enter into
pairing mode, blue and red indicator take turns to flash
(voice prompts)
5) Turn on the bluetooth function of phone 2, and search the
device KBJ-151N from the device list, and make connection
6) Turn off the headset bluetooth, and turn on again. And turn
on the bluetooth function of both phones.The headset will
make connection with two mobile phones automatically
www.compoka.com
立体声蓝牙耳机
Bluetooth 4.0
Stereo Headset
06 07 0805
7.Project Specification and Instruction
- Bluetooth Version : V4.0
- Supported devices: Bluetooth mobile phones,
Bluetooth speakers Bluetooth PC and other Bluetooth
devices
- Maximum work range: 33 Feet (10 Meters)
- Standby time: 80 Hours
- Music play/Talk time: 3 Hours
- Charging time: 2 Hours
- Charging Voltage: DC 5V
- Work Voltage: 3.7V
- Sensitivity: 105±3dB
- Frequency Response: 20Hz~20KHz
※ The actual time may vary from mobile phone types and
functions.
Use both hands to pick to wear the headset:
4.Bluetooth Indicator Status
Red indicator is on all the time
when charging; Blue indicator is
on instead when charged full
Charging
Work Status Indicator Light Status Remark
Switch on Blue indicator flash 2 times
Switch off Red indicator flash 1 time
Connection
Phone call
Play Music
Battery low
warning
5.Headset Charging
6.Wearing Style
Pairing Mode Red and blue indicators take
turns to flash
Voice Prompts
Voice Prompts
Voice Prompts
Voice Prompts
Voice Prompts
(1) Put the headset on your head, rotate to the back of your
head (see Pic 1)
(2) Put the earhook on both of your ears (see Pic 2)
(3) Put the speaker into ears and adjust to the comfortable
position (see Pic 3). After wearing well, the headset
backside should be "suspended" above the neck.
According to personal comfort demand, can adjust the
headset up or down appropriately
Pic 1 Pic 2 Pic 3
※ If the speaker shut down without battery during the phone,
when call, it will switch to mobile phone automatically.
※ Press Function Key “ ” 2 seconds to reject the call.
This headset is equipped with built-in non-detachable and
rechargeable battery.
Please make sure that the battery is charged full for the first
time use.
■ Connect the charger to the charging port.
■ Insert the charger into the standard power outlet.
During the charging, indicator will turn to Red. If without
charging, please plug out the travel charger first, then
connect it again.
■ After full charging, red indicator will be off. Please plug out
the travel charger from the power outlet and headset.
■ It will reduce the battery performance after long time /
repeatable charge and dis-charge.
■ And it is normal phenomenon for all the rechargeable battery.
Please do not dial or receive phone call during charging, and
please plug out the charger from the headset, then receive
the phone call. When the battery is low, the headset will
appear the prompt and the red indicator will flash.
Blue indicator will flash
Blue indicator will flash
Blue indicator will flash
Red indicator will flash every
60 second
(the voice prompts “Bluetooth is connected” will appear
2 times in English) .
※ When the headset is connected with two mobile phones,
some functions of the mobile phones cannot work
normally.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
