Compoka Electronic Technology KBJ-225N FOLDABLE BLUETOOTH HEADPHONE User Manual KBJ 225N
Shenzhen Compoka Electronic Technology Co., Ltd FOLDABLE BLUETOOTH HEADPHONE KBJ 225N
User manual
0201 03 04
Thank you for selecting our latest Bluetooth headphone, please
read this User's Manual carefully before you operate this
headphone, and please save this Manual for further reference.
Before operating, please read all the Safety notice to make sure
the safe and appropriate use.
Safety Notice:
Please observe the rules of the Country or Region which you
are in while driving.
Do not disassemble or modify the
headphone
at any reason,
otherwise, It may damage or burn the
headphone
.
If there is any quality problem, please send the
headphone
to
authorized service center for repairing.
Please keep the equipment along with all the accessories out
of the reach of children and pets. It will cause suffocation and
serious injury.
Do not put the device under the environment which the
temperature is too low or too high ( Below 0℃ or over 45℃).
Extreme temperatures will cause the device deformation,
reduce the charging capacity and shorten the working life.
Please do not wet the device, for the liquid can cause serious
damage to the device. Please do not touch the device by wet
hands. It is out of the maintenance range for the damage
caused by water.
Please avoid closing to the eyes of children and pets when
using the flash indicator of the device.
Please do not operate the device in thunderstorm weather.
It will damage your hearing if you listen with high
volume for a long time. It is recommended that
only use the lowest volume which is necessary
for speaking and listening to music.
1. Guide
■ Heaphone introduction 2.Instruction
■ Key Function
User's Manual
KBJ-225N
立体声蓝牙耳机
使用说明书
Bluetooth 4.0
Stereo Headphone
■ How to connect with two Bluetooth mobile phones:
Play/Pause
Receive
Hang up phone call
Re-dial the last
phone No
Previous song
Volume Increase
Next Song
Volume Decrease
head pad
Ear cushion
D3.5mm Plug port
Foldable
Microphone
USB Charging Port
Power switch
Pairing
LED indicator
※ Contents: Bluetooth Headphone, USB Charging Cable,
3.5mm Audio Cable, User’s Manual
USB Charging Cable:
3.5mm Audio Cable:
Switch on : Press 2 seconds to switch on , the Blue
indicator will be in (It will appear voice prompts in
English). Press 2 seconds again to enter into pairing
mode, meanwhile the red and blue indicators take
turns to flash. It will turn off automatically when no
device to connect in 5 mins ) .
Switch off : Press 4 seconds to switch off , the Red
indicator flashes one time means the device is
switched off.
Press “Function Key” to receive phone call, press it
again to end the phone call.
Press the key by twice continuously to re-dial the last
phone number.
Press the key for 2 seconds to reject the phone call.
In Music Mode, press it for 1 time to pause, and press
it again to play. (when phone call comes, the music will
be off. When phone call is off, the music will continue)
In Music Mode, press it to play previous song.
In Music Mode, press it to play next song.
Long press to increase volume all
the time. The voice prompts will appear when the volume
up to Maximum.
Previous song
Next Song
Volume Increase
Volume Decrease
Play/Pause
Receive
Hang up phone call
Re-dial the last
phone No
Power switch
Pairing
Long press to decrease volume all the time.
■ Voice Prompt Function
Battery low warning
Bluetooth is turned on
Bluetooth enter pairing mode
Volume max
Bluetooth is turned off
VOICE PROMPT STATUS
When you turn the headphone off
When you turn the headphone on
When entering into paring mode
When you connect the second mobile phone
When the volume up to the maximum
When you connect the first mobile phone
Bluetooth is connected
Bluetooth is connected
Battery low
(1) Turn on the bluetooth function of mobile phone 1.
(2) Press the” ” for 4 seconds of the bluetooth headset, switch
on and enter into pairing mode, blue and red indicators take
turns to flash, make connection with phone 1
(3) press the ” ” again for 2.5 seconds, the red and blue
indicators take turns to flash and searching connections
automatically; meanwhile, phone 1 is disconnected.
(4) Turn on the bluetooth function of the mobile phone 2 and
search KBJ-225N from the list, make connection.(Input the
password 0000 if needed and the connection will be made)
(5) Turn off the bluetooth headset and return on, the headset
will connect with both mobile phones automatically. The
voice “Bluetooth is connected, bluetooth is connected” will
appear in English.
www.compoka.com
立体声蓝牙耳机
Bluetooth 4.0
Stereo Headphone
06 07 0805
7.Project Specification and Instruction
- Bluetooth Version : V4.0
- Supported devices: Bluetooth mobile phones, Bluetooth
speakers Bluetooth PC and other Bluetooth devices
- Maximum work range: 33 Feet (10 Meters)
- Standby time: 100 Hours
- Talk time: 12 Hours
- Music play: 10 Hours
- Charging time: 3 Hours
- Charging Voltage: DC 5V
- Work Voltage: 3.7V
- Sensitivity: 100±3dB
- Frequency Response: 20Hz~20KHz
※ The actual time may vary from mobile phone types and
functions.
3. Battery power of bluetooth headphone
displayed on Iphone
※ After connected with Iphone, the battery power of the
headphone will be displayed on the phone.
4.Bluetooth Indicator Status
5.Headphone Charging
This headphone is equipped with built-in non-detachable and
rechargeable battery.
Please make sure that the battery is charged full for the first
time use.
■ Connect the charger to the charging port.
※ When the headphone is connected with two mobile
phones, some functions of the mobile phones cannot
work normally.
10:30 90%
KBJ-101N
蓝牙
现为可被发现状态
设备
已连接
ON/OFF
蓝牙通用 90%
6．Audio cable connection
■ Insert the charger into the standard power outlet.
During the charging, indicator will turn to Red. If without
charging, please plug out the travel charger first, then
connect it again.
■ After full charging, red indicator will be off. Please plug out
the travel charger from the power outlet and headset.
■ It will reduce the battery performance after long time /
repeatable charge and dis-charge.
■ And it is normal phenomenon for all the rechargeable battery.
Please do not dial or receive phone call during charging, and
please plug out the charger from the headset, then receive
the phone call. When the battery is low, the headset will
appear the prompt and the red indicator will flash.
Line Insert 3.5mm audio cable into speaker 3.5mm plug port,
the other part into audio output device(MP3/PC), then you can
enjoy music. When the bluetooth speaker is on, the bluetooth
function will be preffered although insert audio cable.
Red indicator will flash 1 time
every 60 seconds
Charging
Work Status Indicator Light Status Remark
Switch on Blue indicator flash 2 times
Switch off Red indicator flash 1 time
Connection Blue indicator will flash 1 time
every 6 seconds
Phone call Blue indicator will flash 1 time
every 6 seconds
Blue indicator will flash 1 time
every 6 seconds
Play Music
Battery low
warning
Pairing Red and blue indicators take
turns to flash
Voice Prompts
Voice Prompts
Voice Prompts
Voice Prompts
Voice Prompts
Red indicator is on all the time
when charging; Blue indicator is
on instead when charged full
※ If the headphone shut down without battery during the
phone calls, it will switch to mobile phone automatically.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
