Compoka Electronic Technology KBJ-229N Bluetooth headphone User Manual KBJ 229N
Shenzhen Compoka Electronic Technology Co., Ltd Bluetooth headphone KBJ 229N
15_KBJ-229N UserMan.pdf
01 02 03 04
Thank you for selecting our latest Bluetooth headphone, please
read this User's Manual carefully before you operate this
headphone, and please save this Manual for further reference.
Before operating, please read all the Safety notice to make sure
the safe and appropriate use.
Safety Notice:
Please observe the rules of the Country or Region which you
are in while driving.
Do not disassemble or modify the
headphone
at any reason,
otherwise, It may damage or burn the
headphone
.
If there is any quality problem, please send the
headphone
to
authorized service center for repairing.
Please keep the equipment along with all the accessories out
of the reach of children and pets. It will cause suffocation and
serious injury.
Do not put the device under the environment which the
temperature is too low or too high ( Below 0ņ or over 45ņ).
Extreme temperatures will cause the device deformation,
reduce the charging capacity and shorten the working life.
Please do not wet the device, for the liquid can cause serious
damage to the device. Please do not touch the device by wet
hands. It is out of the maintenance range for the damage
caused by water.
Please avoid closing to the eyes of children and pets when
using the flash indicator of the device.
Please do not operate the device in thunderstorm weather.
It will damage your hearing if you listen with high
volume for a long time. It is recommended that
only use the lowest volume which is necessary
for speaking and listening to music.
1. Guide
2.Instruction
User's Manual
KBJ-229N
Bluetooth 4.0
Stereo Headphone
How to connect with two Bluetooth mobile phones:
Play/Pause /Receive
Re-dial the last
phone No
Next Song
Volume Increase
Previous song
Volume Decrease
Ear cushion D3.5mm Plug port
Microphone
USB Charging Port
Power switch
Pairing
LED indicator
※
3.5mm Audio Cable, User’s Manual
USB Charging Cable:
3.5mm Audio Cable:
Switch on : Press 2 seconds to switch on , the Blue
indicator will be in (It will appear voice prompts in
English). Press 2 seconds again to enter into pairing
mode, meanwhile the red and blue indicators take
turns to flash. It will turn off automatically when no
device to connect in 5 mins ) .
Switch off : Press 4 seconds to switch off , the Red
indicator flashes one time means the device is
switched off.
again to end the phone call.
Press the key by twice continuously to re-dial the last
phone number.
Press the key for 2 seconds to reject the phone call.
In Music Mode, press it for 1 time to pause, and press
it again to play. (when phone call comes, the music will
be off. When phone call is off, the music will continue)
In Music Mode, press it to play previous song.
In Music Mode, press it to play next song.
Long press to increase volume all
the time. The voice prompts will appear when the volume
up to Maximum.
Previous song
Next Song
Volume Increase
Volume Decrease
Play/Pause
Receive
Re-dial the last
phone No
Power switch
Pairing
Long press to decrease volume all the time.
Battery low warning
Bluetooth is turned on
Bluetooth enter pairing mode
Volume max
Bluetooth is turned off
VOICE PROMPT STATUS
When you turn the headphone off
When you turn the headphone on
When entering into paring mode
When you connect the second mobile phone
When the volume up to the maximum
When you connect the first mobile phone
Bluetooth is connected
Bluetooth is connected
Battery low
(1) Turn on the bluetooth function of mobile phone 1.
switch on and enter into pairing mode, blue and red indicators
take turns to flash, make connection with phone 1.
indicators take turns to flash and searching connections
automatically; meanwhile, phone 1 is disconnected.
(4) Turn on the bluetooth function of the mobile phone 2 and
password 0000 if needed and the connection will be made)
(5) Turn off the bluetooth headphone and return on, the
headphone will connect with both mobile phones automatically.
will appear in English.
Extendable
Bluetooth 4.0
Stereo Headphone
0605 07 08
7.Project Specification and Instruction
- Bluetooth Version : 4.0 (CSR8635)
- Supported devices: Bluetooth mobile phones, Bluetooth
speakers Bluetooth PC and other Bluetooth devices
- Charging Voltage: DC 5V
- Work Voltage: 3.7V
- Sensitivity: 97±3dB
- Battery Capacity:300mAh
- Frequency Response: 2.402~2.480GHz
※ The actual time may vary from mobile phone types and
functions.
3. Battery power of bluetooth headphone
displayed on Iphone
※ After connected with Iphone, the battery power bar of
the headphone will be displayed on the phone.
4.Bluetooth Indicator Status
This headphone is equipped with built-in non-detachable and
rechargeable battery.
Please make sure that the battery is charged full for the first
time use.
※ When the headphone is connected with two mobile phones,
some functions of the mobile phones cannot work normally.
6．Audio cable connection
During the charging, indicator will turn to Red. If without
charging, please plug out the travel charger first, then
connect it again.
the travel charger from the power outlet and headphone.
repeatable charge and dis-charge.
Please do not dial or receive phone call during charging, and
please plug out the charger from the headphone, then receive
the phone call. When the battery is low, the headphone will
appear the prompt and the red indicator will flash.
Line Insert 3.5mm audio cable into headphone 3.5mm plug
port, the other part into audio output device(MP3/PC), then
you can enjoy music. When the bluetooth headphone is on,
the bluetooth function will be preffered although insert audio
cable.
Red indicator will flash 1 time
every 60 seconds
Charging
Work Status Indicator Light Status Remark
Switch on Blue indicator flash 3 times
Switch off Red indicator flash 1 time
Connection Blue indicator will flash 1 time
every 6 seconds
Phone call Blue indicator will flash 1 time
every 6 seconds
Blue indicator will flash 1 time
every 6 seconds
Play Music
Battery low
warning
Pairing Red and blue indicators take
turns to flash
Voice Prompts
Voice Prompts
Voice Prompts
Voice Prompts
Voice Prompts
Red indicator is on all the time
when charging
※ If the headphone shut down without battery during the
phone calls, it will switch to mobile phone automatically.
10:30
KBJ-229N
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Thisdevicecomplieswithpart15oftheFCCrules.Operationissubjecttothefollowingtwo
conditions:
(1)thisdevicemaynotcauseharmfulinterference,and
(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycause
undesiredoperation.
Changesormodificationstothisunitnotexpresslyapprovedbythepartyresponsiblefor
compliancecouldvoidtheuser'sauthoritytooperatetheequipment.
