Unified Services Router User Manual
149
Symptom: Router can obtain an IP address, but PC is unable to load Internet pages.
Recommended action:
1. Ask your ISP for the addresses of its designated Domain Name System (DNS) servers.
Configure your PC to recognize those addresses. For details, see your operating system
documentation.
2. On your PC, configure the router to be its TCP/IP gateway.
11.2 Date and time
Symptom: Date shown is January 1, 1970.
Possible cause: The router has not yet successfully reached a network time server
(NTS).
Recommended action:
1. If you have just configured the router, wait at least 5 minutes, select Administration >
Time Zone, and recheck the date and time.
2. Verify your Internet access settings.
Symptom: Time is off by one hour.
Possible cause: The router does not automatically adjust for Daylight Savings Time.
Recommended action:
1. Select Administration > Time Zone and view the current date and time settings.
2. Click to check or uncheck ―Automatically adjust for Daylight Savings Time‖, then click
Apply.
11.3 Pinging to Test LAN Connectivity
Most TCP/IP terminal devices and firewalls contain a ping utility that sends an ICMP
echo-request packet to the designated device. The DSR responds with an echo reply.
Troubleshooting a TCP/IP network is made very easy by using the ping utility in your
PC or workstation.
11.3.1 Testing the LAN path from your PC to your
router
1. From the PC‘s Windows toolbar, select Start > Run.
2. Type ping <IP_address> where <IP_address> is the router‘s IP address. Example: ping
192.168.10.1.
3. Click OK.
Unified Services Router User Manual
150
4. Observe the display:
If the path is working, you see this message sequence:
Pinging <IP address> with 32 bytes of data
Reply from <IP address>: bytes=32 time=NN ms TTL=xxx
If the path is not working, you see this message sequence:
Pinging <IP address> with 32 bytes of data
Request timed out
5. If the path is not working, Test the physical connections between PC and router
If the LAN port LED is off, go to the ―LED displays‖ section on page B-
1 and follow instructions for ―LAN or Internet port LEDs are not lit.‖
Verify that the corresponding link LEDs are lit for your network
interface card and for any hub ports that are connected to your
workstation and firewall.
6. If the path is still not up, test the network configuration:
Verify that the Ethernet card driver software and TCP/IP software are
installed and configured on the PC.
Verify that the IP address for the router and PC are correct and on the
same subnet.
11.3.2 Testing the LAN path from your PC to a remote
device
1. From the PC‘s Windows toolbar, select Start > Run.
2. Type ping -n 10 <IP_address> where -n 10 specifies a maximum of 10 tries and <IP
address> is the IP address of a remote device such as your ISP‘s DNS server. Example:
ping -n 10 10.1.1.1.
3. Click OK and then observe the display (see the previous procedure).
4. If the path is not working, do the following:
Check that the PC has the IP address of your firewall listed as the
default gateway. (If the IP configuration of your PC is assigned by
DHCP, this information is not visible in your PC‘s Network C ontrol
Panel.)
Unified Services Router User Manual
151
Verify that the network (subnet) address of your PC is different from the
network address of the remote device.
Verify that the cable or DSL modem is connected and functioning.
Ask your ISP if it assigned a hostname to your PC.
If yes, select Network Configuration > WAN Settings > Ethernet ISP
Settings and enter that hostname as the ISP account name.
Ask your ISP if it rejects the Ethernet MAC addresses of all but one of
your PCs.
Many broadband ISPs restrict access by allowing traffic from the MAC address of
only your broadband modem; but some ISPs additionally restrict access to the MAC
address of just a single PC connected to that modem. If this is the case, configure
your firewall to clone or spoof the MAC address from the authorized PC.
11.4 Restoring factory-default configuration
settings
To restore factory-default configuration settings, do either of the following:
1. Do you know the account password and IP address?
If yes, select Administration > Settings Backup & Upgrade and
click default.
If no, do the following:
On the rear panel of the router, press and hold the Reset button about 10 seconds,
until the test LED lights and then blinks.
Release the button and wait for the router to reboot.
2. If the router does not restart automatically; manually restart it to make the default settings
effective.
3. After a restore to factory defaults —whether initiated from the configuration interface or
the Reset button — the following settings apply:
LAN IP address: 192.168.10.1
Username: admin
Password: password
DHCP server on LAN: enabled
WAN port configuration: Get configuration via DHCP
Chapter 12. Credits
Microsoft, Windows are registered trademarks of Microsoft Corp.
Linux is a registered trademark of Linus Torvalds.
UNIX is a registered trademark of The Open Group.
Unified Services Router User Manual
154
Appendix A. Glossary
ARP
Address Resolution Protocol. Broadcast protocol for mapping IP addresses to MAC addresses.
CHAP
Challenge-Handshake Authentication Protocol. Protocol for authenticating users to an ISP.
DDNS
Dynamic DNS. System for updating domain names in real time. Allows a domain name to be
assigned to a device with a dynamic IP address.
DHCP
Dynamic Host Configuration Protocol. Protocol for allocating IP addresses dynamically so that
addresses can be reused when hosts no longer need them.
DNS
Domain Name System. Mechanism for translating H.323 IDs, URLs, or e-mail IDs into IP
addresses. Also used to assist in locating remote gatekeepers and to map IP addresses to
hostnames of administrative domains.
FQDN
Fully qualified domain name. Complete domain name, including the host portion. Example:
serverA.companyA.com.
FTP
File Transfer Protocol. Protocol for transferring files between network nodes.
HTTP
Hypertext Transfer Protocol. Protocol used by web browsers and web servers to transfer files.
IKE
Internet Key Exchange. Mode for securely exchanging encryption keys in ISAKMP as part of
building a VPN tunnel.
IPsec
IP security. Suite of protocols for securing VPN tunnels by authenticating or encrypting IP
packets in a data stream. IPsec operates in either transport mode (encrypts payload but not
packet headers) or tunnel mode (encrypts both payload and packet headers).
ISAKMP
Internet Key Exchange Security Protocol. Protocol for establishing security associations and
cryptographic keys on the Internet.
ISP
Internet service provider.
MAC Address
Media-access-control address. Unique physical-address identifier attached to a network
adapter.
MTU
Maximum transmission unit. Size, in bytes, of the largest packet that can be passed on. The
MTU for Ethernet is a 1500-byte packet.
NAT
Network Address Translation. Process of rewriting IP addresses as a packet passes through a
router or firewall. NAT enables multiple hosts on a LAN to access the Internet using the single
public IP address of the LAN’s gateway router.
NetBIOS
Microsoft Windows protocol for file sharing, printer sharing, messaging, authentication, and
name resolution.
NTP
Network Time Protocol. Protocol for synchronizing a router to a single clock on the network,
known as the clock master.
PAP
Password Authentication Protocol. Protocol for authenticating users to a remote access server
or ISP.
Unified Services Router User Manual
155
PPPoE
Point-to-Point Protocol over Ethernet. Protocol for connecting a network of hosts to an ISP
without the ISP having to manage the allocation of IP addresses.
PPTP
Point-to-Point Tunneling Protocol. Protocol for creation of VPNs for the secure transfer of data
from remote clients to private servers over the Internet.
RADIUS
Remote Authentication Dial-In User Service. Protocol for remote user authentication and
accounting. Provides centralized management of usernames and passwords.
RSA
Rivest-Shamir-Adleman. Public key encryption algorithm.
TCP
Transmission Control Protocol. Protocol for transmitting data over the Internet with guaranteed
reliability and in-order delivery.
UDP
User Data Protocol. Protocol for transmitting data over the Internet quickly but with no
guarantee of reliability or in-order delivery.
VPN
Virtual private network. Network that enables IP traffic to travel securely over a public TCP/IP
network by encrypting all traffic from one network to another. Uses tunneling to encrypt all
information at the IP level.
WINS
Windows Internet Name Service. Service for name resolution. Allows clients on different IP
subnets to dynamically resolve addresses, register themselves, and browse the network without
sending broadcasts.
XAUTH
IKE Extended Authentication. Method, based on the IKE protocol, for authenticating not just
devices (which IKE authenticates) but also users. User authentication is performed after device
authentication and before IPsec negotiation.
Appendix B. Factory Default Settings
Feature
Description
Default Setting
Device login
User login URL
http://192.168.10.1
User name (case sensitive)
admin
Login password (case sensitive)
admin
Internet
Connection
WAN MAC address
Use default address
WAN MTU size
1500
Port speed
Autosense
Local area network
(LAN)
IP address
192.168.10.1
IPv4 subnet mask
255.255.255.0
RIP direction
None
RIP version
Disabled
RIP authentication
Disabled
DHCP server
Enabled
DHCP starting IP address
192.168.10.2
DHCP ending IP address
192.168.10.100
Time zone
GMT
Time zone adjusted for Daylight Saving Time
Disabled
SNMP
Disabled
Remote management
Disabled
Firewall
Inbound communications from the Internet
Disabled (except traffic on port
80, the HTTP port)
Outbound communications to the Internet
Enabled (all)
Source MAC filtering
Disabled
Stealth mode
Enabled
Unified Services Router User Manual
158
Appendix C. Standard Services
Available for Port Forwarding
& Firewall Configuration
ANY
AIM
BGP
BOOTP_CLIENT
BOOTP_SERVER
CU-SEEME:UDP
CU-SEEME:TCP
DNS:UDP
DNS:TCP
FINGER
FTP
HTTP
HTTPS
ICMP-TYPE-3
ICMP-TYPE-4
ICMP-TYPE-5
ICMP-TYPE-6
ICMP-TYPE-7
ICMP-TYPE-8
ICMP-TYPE-9
ICMP-TYPE-10
ICMP-TYPE-11
ICMP-TYPE-13
ICQ
IMAP2
IMAP3
IRC
NEWS
NFS
NNTP
PING
POP3
PPTP
RCMD
REAL-AUDIO
REXEC
RLOGIN
RTELNET
RTSP:TCP
RTSP:UDP
SFTP
SMTP
SNMP:TCP
SNMP:UDP
SNMP-TRAPS:TCP
SNMP-TRAPS:UDP
SQL-NET
SSH:TCP
SSH:UDP
STRMWORKS
TACACS
TELNET
TFTP
VDOLIVE
Unified Services Router User Manual
159
Appendix D. Log Output Reference
Facility: System (Networking)
Log Message
Log Message
Severity
DBUpdate event: Table: %s opCode:%d
rowId:%d
BridgeConfig: too few arguments to
command %s
ERROR
networkIntable.txt not found
BridgeConfig: too few arguments to
command %s
ERROR
sqlite3QueryResGet failed
sqlite3QueryResGet failed.Query:%s
ERROR
Interface is already deleted in bridge
ddnsDisable failed
ERROR
removing %s from bridge %s... %s
sqlite3QueryResGet failed.Query:%s
ERROR
adding %s to bridge %s... %s
sqlite3QueryResGet failed.Query:%s
ERROR
stopping bridge...
ddnsDisable failed
ERROR
stopping bridge...
failed to call ddns enable
ERROR
stopping bridge...
ddnsDisable failed
ERROR
%s:DBUpdate event: Table: %s
opCode:%d rowId:%d
sqlite3QueryResGet failed.Query:%s
ERROR
Wan is not up
Error in executing DB update handler
ERROR
%s:DBUpdate event: Table: %s
opCode:%d rowId:%d
sqlite3QueryResGet failed.Query:%s
ERROR
doDNS:failed
Illegal invocation of ddnsView (%s)
ERROR
doDNS:failed
sqlite3QueryResGet failed.Query:%s
ERROR
doDNS:Result = FAILED
sqlite3QueryResGet failed.Query:%s
ERROR
doDNS:Result SUCCESS
ddns: SQL error: %s
ERROR
Write Old Entry: %s %s %s: to %s
Illegal operation interface got deleted
ERROR
Write New Entry: %s %s #%s : to %s
sqlite3QueryResGet failed.Query:%s
ERROR
Write Old Entry: %s %s %s: to %s
sqlite3QueryResGet failed.Query:%s
ERROR
Write New Entry: %s %s #%s : to %s
sqlite3QueryResGet failed.Query:%s
ERROR
ifStaticMgmtDBUpdateHandler: returning
with "
ddnsDisable failed
ERROR
nimfLinkStatusGet: buffer: \
ddns: SQL error: %s
ERROR
nimfLinkStatusGetErr: returning with
status: %d
Failed to call ddns enable
ERROR
nimfAdvOptSetWrap: current Mac
Option: %d
ddns: SQL error: %s
ERROR
nimfAdvOptSetWrap: current Port Speed
Option: %d
sqlite3QueryResGet failed.Query:%s
ERROR
nimfAdvOptSetWrap: current Mtu Option:
%d
Failed to call ddns enable
ERROR
nimfAdvOptSetWrap: looks like we are
reconnecting. "
ddns: SQL error: %s
ERROR
nimfAdvOptSetWrap: Mtu Size: %d
ddnsDisable failed
ERROR
nimfAdvOptSetWrap: NIMF table is %s
ddns: SQL error: %s
ERROR
nimfAdvOptSetWrap:WAN_MODE
TRIGGER
sqlite3QueryResGet failed.Query:%s
ERROR
nimfAdvOptSetWrap: MTU: %d
Failed to call ddns enable
ERROR
nimfAdvOptSetWrap: MacAddress: %s
ddns: SQL error: %s
ERROR
nimfAdvOptSetWrap: old Mtu Flag: %d
ddnsDisable failed
ERROR
Unified Services Router User Manual
160
nimfAdvOptSetWrap: user has changed
MTU option
ddns: SQL error: %s
ERROR
nimfAdvOptSetWrap: MTU: %d
sqlite3QueryResGet failed.Query:%s
ERROR
nimfAdvOptSetWrap: old MTU size: %d
sqlite3QueryResGet failed.Query:%s
ERROR
nimfAdvOptSetWrap: old Port Speed
Option: %d
ddnsDisable failed
ERROR
nimfAdvOptSetWrap: old Mac Address
Option: %d
ddns: SQL error: %s
ERROR
nimfAdvOptSetWrap: MacAddress: %s
sqlite3QueryResGet failed.Query:%s
ERROR
Setting LED [%d]:[%d] For %s
sqlite3QueryResGet failed.Query:%s
ERROR
l2tpEnable: command string: %s
ddnsDisable failed
ERROR
nimfAdvOptSetWrap: handling reboot
scenario
failed to call ddns enable
ERROR
nimfAdvOptSetWrap: INDICATOR = %d
ddns: SQL error: %s
ERROR
nimfAdvOptSetWrap: UpdateFlag: %d
ddnsDisable failed
ERROR
nimfAdvOptSetWrap: returning with
status: %s
sqlite3QueryResGet failed.Query:%s
ERROR
nimfGetUpdateMacFlag: MacTable Flag
is: %d
Error in executing DB update handler
ERROR
nimfMacGet: Mac Option changed
Failed to open the resolv.conf file.
Exiting./n
ERROR
nimfMacGet: Update Flag: %d
Could not write to the resolv.conf file.
Exiting.
ERROR
nimfMacGet: MacAddress: %s
Error opening the lanUptime File
ERROR
nimfMacGet: MacAddress: %s
Error Opening the lanUptime File.
ERROR
nimfMacGet: MacAddress: %s
failed to open %s
ERROR
nimfMacGet: MacAddress: %s
failed to open %s
ERROR
nimfMacGet: MacAddress: %s
failed to query networkInterface table
ERROR
nimfMacGet:Mac option Not changed \
failed to query networkInterface table
ERROR
nimfMacGet: MacAddress: %s
sqlite3QueryResGet failed.Query:%s
ERROR
nimfMacGet: MacAddress: %s
failed to enable IPv6 forwarding
ERROR
nimfMacGet: MacAddress: %s
failed to set capabilities on the "
ERROR
nimfMacGet: returning with status: %s
failed to enable IPv6 forwarding
ERROR
Now in enableing LanBridge function
failed to set capabilities on the "
ERROR
sucessfully executed the command %s
failed to disable IPv6 forwarding
ERROR
Now in disableing LanBridge function
failed to set capabilities on the "
ERROR
sucessfully executed the command %s
failed to open %s
ERROR
configPortTblHandler:Now we are in
Sqlite Update "
Could not create ISATAP Tunnel
ERROR
The Old Configuration of ConfiPort
was:%s
Could not destroy ISATAP Tunnel
ERROR
The New Configuration of ConfiPort
was:%s
Could not configure ISATAP Tunnel
ERROR
The user has deselected the
configurable port
Could not de-configure ISATAP
Tunnel
ERROR
failed query %s
nimfStatusUpdate: updating
NimfStatus failed
ERROR
failed query %s
nimfStatusUpdate: updating
NimfStatus failed
ERROR
failed query %s
nimfLinkStatusGet: determinig link's
status failed
ERROR
%s:DBUpdate event: Table: %s
opCode:%d rowId:%d
nimfLinkStatusGet: opening status file
failed
ERROR
Unified Services Router User Manual
161
%s:DBUpdate event: Table: %s
opCode:%d rowId:%d
Failed to commit
ERROR
%s:%d SIP ENABLE: %s
ifStatusDBUpdate: Failed to begin "
ERROR
sipTblHandler:failed to update ifStatic
%s: SQL error: %s
ERROR
sipTblHandler:failed to update Configport
%s: Failed to commit "
ERROR
%s:%d SIP DISABLE: %s
nimfNetIfaceTblHandler: unable to get
LedPinId
ERROR
%s:%d SIP SET CONF: %s
nimfNetIfaceTblHandler: unable to get
LedPinId
ERROR
Failed to open %s: %s
nimfNetIfaceTblHandler: unable to get
LedPinId
ERROR
Failed to start sipalg
%s: unable to kill dhclient
ERROR
Failed to stop sipalg
nimfAdvOptSetWrap: unable to get
current Mac Option
ERROR
Failed to get config info
nimfAdvOptSetWrap: unable to get
current Port "
ERROR
Network Mask: 0x%x
nimfAdvOptSetWrap: unable to get
current MTU Option
ERROR
RTP DSCP Value: 0x%x
nimfAdvOptSetWrap: error getting
Mac Address from "
ERROR
Need more arguments
nimfAdvOptSetWrap: unable to get
the MTU
ERROR
Invalid lanaddr
nimfAdvOptSetWrap: error setting
interface advanced "
ERROR
Invalid lanmask
nimfAdvOptSetWrap: error getting
MTU size
ERROR
Invalid option
nimfAdvOptSetWrap: unable to get
Mac Address
ERROR
Failed to set config info
nimfAdvOptSetWrap: error setting
interface advanced "
ERROR
Unknown option
nimfAdvOptSetWrap: failed to get old
connectiontype
ERROR
sshdTblHandler
nimfAdvOptSetWrap: old connection
type is: %s
ERROR
pPort: %s
nimfAdvOptSetWrap: failed to get old
MTU Option
ERROR
pProtocol: %s
nimfAdvOptSetWrap: error getting
MTU size
ERROR
pListerAddr: %s
nimfOldFieldValueGet: failed to get
old "
ERROR
pKeyBits: %s
nimfOldFieldValueGet: user has
changed MTU size
ERROR
pRootEnable: %s
nimfAdvOptSetWrap: failed to get old
Port Speed "
ERROR
pRsaEnable: %s
nimfAdvOptSetWrap: user has
changed Port Speed
ERROR
pDsaEnable: %s
nimfAdvOptSetWrap: failed to get old
Mac Address "
ERROR
pPassEnable: %s
nimfAdvOptSetWrap: user has
changed Mac Address "
ERROR
pEmptyPassEnable: %s
nimfAdvOptSetWrap: unable to get
Mac Address
ERROR
pSftpEnable: %s
nimfAdvOptSetWrap:Failed to RESET
the flag
ERROR
pScpEnable: %s
nimfAdvOptSetWrap: setting
advanced options failed
ERROR
pSshdEnable: %s
nimfAdvOptSetWrap: interface
advanced options applied
ERROR
Unified Services Router User Manual
162
pPrivSep: %s
nimfGetUpdateMacFlag: unable to get
Flag from MacTable
ERROR
%s:DBUpdate event: Table: %s
opCode:%d rowId:%d
nimfMacGet: Updating MAC address
failed
ERROR
Re-Starting sshd daemon....
sqlite3QueryResGet failed.Query:%s
ERROR
sshd re-started successfully.
error executing the command %s
ERROR
sshd stopped .
error executing the command %s
ERROR
failed query %s
error executing the command %s
ERROR
vlan disabled, not applying vlan
configuration..
disableLan function is failed to disable
ConfigPort"
ERROR
failed query %s
sqlite3QueryResGet failed.Query:%s
ERROR
failed query %s
sqlite3QueryResGet failed.Query:%s
ERROR
no ports present in this vlanId %d
Unable to Disable configurable port
from
ERROR
failed query %s
configPortTblHandler has failed
ERROR
vlan disabled, not applying vlan
configuration..
sqlite3QueryResGet failed.Query:%s
ERROR
disabling vlan
Error in executing DB update handler
ERROR
enabling vlan
sqlite3QueryResGet failed
ERROR
vlan disabled, not applying vlan
configuration..
Failed to execute switchConfig for
port\
ERROR
no ports present in this vlanId %d
Failed to execute switchConfig for
port enable
ERROR
failed query %s
Failed to execute ifconfig for port
enable
ERROR
vlan disabled, not applying vlan
configuration..
Failed to execute ethtool for\
ERROR
removing %s from bridge%s... %s
Failed to execute switchConfig for
port disable
ERROR
adding %s to bridge%d... %s
Failed to execute ifconfig for port
disable
ERROR
restarting bridge...
sqlite3QueryResGet failed
ERROR
[switchConfig] Ignoring event on port
number %d
sqlite3_mprintf failed
ERROR
restarting bridge...
sqlite3QueryResGet failed
ERROR
executing %s ... %s
Failed to execute switchConfig for
port mirroring
ERROR
removing %s from bridge%s... %s
Usage:%s <DB Name> <Entry
Name> <logFile> <subject>
ERROR
adding %s to bridge%d... %s
sqlite3QueryResGet failed
ERROR
[switchConfig] Ignoring event on %s
Could not get all the required
variables to email the Logs.
ERROR
restarting bridge...
runSmtpClient failed
ERROR
[switchConfig] Ignoring event on port
number %d
getaddrinfo returned %s
ERROR
[switchConfig] executing %s ... %s
file not found
ERROR
restarting bridge...
sqlite3QueryResGet failed.Query:%s
ERROR
UserName: %s
sqlite3QueryResGet failed.Query:%s
ERROR
Password: %s
sqlite3QueryResGet failed.Query:%s
ERROR
IspName: %s
No memory to allocate
ERROR
DialNumber: %s
Failed to Open SSHD Configuration
File
ERROR
Apn: %s
Ipaddress should be provided with
accessoption 1
ERROR
Unified Services Router User Manual
163
GetDnsFromIsp: %s
Subnetaddress should be provided
with accessoption 2
ERROR
IdleTimeOutFlag: %s
Failed to restart sshd
ERROR
IdleTimeOutValue: %d
unable to open the "
ERROR
AuthMetho: %d
sqlite3QueryResGet failed.Query:%s
ERROR
executing %s ... %s
Error in executing DB update handler
ERROR
removing %s from bridge%d... %s
Error in executing DB update handler
ERROR
adding %s to bridge%d... %s
unknown vlan state
ERROR
stopping bridge...
Failed to execute vlanConfig binary
for vlanId %d
ERROR
restarting bridge...
sqlite3_mprintf failed
ERROR
Could not configure 6to4 Tunnel
Interface
Access port can be present only in
single vlan
ERROR
Could not de-configure 6to4 Tunnel
Interface
Failed to execute vlanConfig binary
for vlanId %d
ERROR
failed to restart 6to4 tunnel interfaces
unknown vlan state
ERROR
BridgeConfig: too few arguments to
command %s
Failed to execute vlanConfig binary
for port number %d
ERROR
BridgeConfig: unsupported command %d
Failed to clear vlan for oldPVID %d
ERROR
BridgeConfig returned error=%d
Failed to execute vlanConfig binary
for port number %d
ERROR
sqlite3QueryResGet failed
Failed to clear vlan for %d
ERROR
Error in executing DB update handler
Failed to set vlan entry for vlan %d
ERROR
sqlite3QueryResGet failed
Failed to set vlan entries, while
enabling \
ERROR
Failed to remove vlan Interface for vlanId
\
sqlite3QueryResGet failed
ERROR
sqlite3QueryResGet failed
Failed to execute vlanConfig binary
for port number %d
ERROR
Invalid oidp passed
Failed to execute vlanConfig binary
for vlanId %d
ERROR
Invalid oidp passed
Failed to enable vlan
ERROR
Failed to get oid from the tree
Failed to disable vlan
ERROR
threegEnable: Input to wrapper %s
Failed to set vlanPort table entries,
while \
ERROR
threegEnable: spawning command %s
Failed to enable vlan
ERROR
threegMgmtHandler: query string: %s
unknown vlan state
ERROR
threegMgmtHandler: returning with
status: %s
Error in executing DB update handler
ERROR
adding to dhcprealy ifgroup failed
unknown vlan state
ERROR
adding to ipset fwDhcpRelay failed
Failed to execute vlanConfig binary
for vlanId %d
ERROR
Disabling Firewall Rule for DHCP Relay
Protocol
sqlite3_mprintf failed
ERROR
Enabling Firewall Rule for DHCP Relay
Protocol
Access port can be present only in
single vlan
ERROR
prerouting Firewall Rule add for Relay
failed
Failed to execute vlanConfig binary
for vlanId %d
ERROR
prerouting Firewall Rule add for Relay
failed
unknown vlan state
ERROR
%s: SQL get query: %s
Failed to execute vlanConfig binary
for port number %d
ERROR
%s: sqlite3QueryResGet failed
Failed to clear vlan for oldPVID %d
ERROR
%s: no result found
Failed to execute vlanConfig binary
for port number %d
ERROR
Unified Services Router User Manual
164
%s: buffer overflow
Failed to clear vlan for %d
ERROR
%s: value of %s in %s table is: %s
Failed to set vlan entry for vlan %d
ERROR
%s: returning with status: %s
Failed to set vlan entries, while
enabling \
ERROR
dnsResolverConfigure: addressFamily:
%d
Failed to execute vlanConfig binary
for port number %d
ERROR
dnsResolverConfigure: LogicalIfName:
%s
Failed to execute vlanConfig binary
for vlanId %d
ERROR
chap-secrets File found
Failed to enable vlan
ERROR
PID File for xl2tpd found
Failed to disable vlan
ERROR
pid: %d
Failed to set vlanPort table entries,
while \
ERROR
options.xl2tpd file found
Failed to enable vlan
ERROR
options.xl2tpd file not found
unknown vlan state
ERROR
Conf File for xl2tpd found
threegMgmtInit: unable to open the
database file %s
ERROR
xl2tpd.conf not found
threegConnEnable: failed to get the
WanMode
ERROR
Chap Secrets file found
threegEnable:spawning failed
ERROR
Chap Secrets file not found
threegDisable: unable to kill ppp
daemon
ERROR
%s:DBUpdate event: Table: %s
opCode:%d rowId:%d
threegMgmtHandler: Query: %s
ERROR
chap-secrets File found
threegMgmtHandler: error in
executing database update
ERROR
PID File for pptpd found
Error in executing DB update handler
ERROR
pid: %d
are we getting invoked twice ??
ERROR
PID File for pptpd interface found
could not open %s to append
ERROR
pid: %d
could not write nameserver %s to %s
ERROR
options.pptpd file found
could not write nameserver %s to %s
ERROR
options.pptpd file not found
could not open %s to truncate
ERROR
Conf File for pptpd found
dnsResolverConfigMgmtInit: unable
to open the "
ERROR
pptpd.conf not found
resolverConfigDBUpateHandler:
sqlite3QueryResGet "
ERROR
Chap Secrets file found
could not configure DNS resolver
ERROR
Chap Secrets file not found
dnsResolverConfigure: could not write
nameserver:%s,"
ERROR
%s:DBUpdate event: Table: %s
opCode:%d rowId:%d
unboundMgmt: unable to open the "
ERROR
chap-secrets File found
ioctl call Failed-could not update
active user Details
ERROR
pppoeMgmtTblHandler: MtuFlag: %d
sqlite3QueryResGet failed.Query:%s
ERROR
pppoeMgmtTblHandler: Mtu: %d
Can't kill xl2tpd
ERROR
pppoeMgmtTblHandler:
IdleTimeOutFlag: %d
xl2tpd restart failed
ERROR
pppoeMgmtTblHandler:
IdleTimeOutValue: %d
failed to get field value
ERROR
pppoeMgmtTblHandler: UserName: %s
failed to get field value
ERROR
pppoeMgmtTblHandler: Password: %s
sqlite3QueryResGet failed.Query:%s
ERROR
pppoeMgmtTblHandler: DNS specified:
%s
sqlite3QueryResGet failed.Query:%s
ERROR
pppoeMgmtTblHandler: Service: %s
unboundMgmt: unable to open the "
ERROR
pppoeMgmtTblHandler: StaticIp: %s
writing options.xl2tpd failed
ERROR
Unified Services Router User Manual
165
pppoeMgmtTblHandler: NetMask: %s
xl2tpdStop failed
ERROR
pppoeMgmtTblHandler: AuthOpt: %d
writing xl2tpd.conf failed
ERROR
pppoeMgmtTblHandler: Satus: %d
writing options.xl2tpd failed
ERROR
pppoeEnable: ppp dial string: %s
xl2tpdStop failed
ERROR
pppoeMgmtDBUpdateHandler: returning
with status: %s
xl2tpdStart failed
ERROR
pptpMgmtTblHandler: MtuFlag: %d
sqlite3QueryResGet failed.Query:%s
ERROR
pptpMgmtTblHandler: Mtu: %d
writing Chap-secrets/Pap-Secrets
failed
ERROR
pptpMgmtTblHandler: IdleTimeOutFlag:
%d
xl2tpdStop failed
ERROR
pptpMgmtTblHandler: IdleTimeOutValue:
%d
xl2tpdStart failed
ERROR
pptpMgmtTblHandler: GetDnsFromIsp:
%d
sqlite3QueryResGet failed.Query:%s
ERROR
pptpMgmtTblHandler: UserName: %s
writing Chap-secrets/Pap-Secrets
failed
ERROR
pptpMgmtTblHandler: Password: %s
xl2tpdStop failed
ERROR
pptpMgmtTblHandler: dynamic MyIp
configured
xl2tpdStart failed
ERROR
pptpMgmtTblHandler: MyIp: %s
sqlite3QueryResGet failed.Query:%s
ERROR
pptpMgmtTblHandler: ServerIp: %s
writing Chap-secrets/Pap-Secrets
failed
ERROR
pptpMgmtTblHandler: StaticIp: %s
Error in executing DB update handler
ERROR
pptpMgmtTblHandler: NetMask: %s
unboundMgmt: unable to open the "
ERROR
pptpMgmtTblHandler:
MppeEncryptSupport: %s
Can't kill pptpd
ERROR
pptpMgmtTblHandler: SplitTunnel: %s
pptpd restart failed
ERROR
pptpEnable: ppp dial string: %s
Can't kill pptpd
ERROR
pptpEnable: spawning command %s
failed to get field value
ERROR
PID File for dhcpc found
failed to get field value
ERROR
pid: %d
unboundMgmt: unable to open the "
ERROR
pptpMgmtDBUpdateHandler: query
string: %s
writing options.pptpd failed
ERROR
pptpMgmtDBUpdateHandler: returning
with status: %s
pptpdStop failed
ERROR
dhcpcReleaseLease: dhcpc release
command: %s
writing pptpd.conf failed
ERROR
dhcpcMgmtTblHandler: MtuFlag: %d
writing options.pptpd failed
ERROR
dhcpcMgmtTblHandler: Mtu: %d
pptpdStop failed
ERROR
DHCPv6 Server started successfully.
pptpdStart failed
ERROR
DHCPv6 Server stopped successfully
writing Chap-secrets/Pap-Secrets
failed
ERROR
DHCPv6 Client started successfully.
Error in executing DB update handler
ERROR
DHCPv6 Client stopped successfully.
pppStatsUpdate: unable to get default
MTU
ERROR
DHCPv6 Client Restart successful
pppoeMgmtInit: unable to open the
database file %s
ERROR
l2tpMgmtTblHandler: MtuFlag: %d
pppoeDisable: unable to kill ppp
daemon
ERROR
l2tpMgmtTblHandler: Mtu: %d
pppoeMultipleEnableDisable: pppoe
enable failed
ERROR
l2tpMgmtTblHandler: IspName: %s
pppoeMultipleEnableDisable: pppoe
disable failed
ERROR
Unified Services Router User Manual
166
l2tpMgmtTblHandler: UserName: %s
pppoeMgmtTblHandler: unable to get
current Mtu Option
ERROR
l2tpMgmtTblHandler: Password: %s
pppoeMgmtTblHandler: unable to get
the Mtu
ERROR
l2tpMgmtTblHandler: AccountName: %s
pppoeMgmtTblHandler: pppoe enable
failed
ERROR
l2tpMgmtTblHandler: DomainName: %s
pppoeMgmtDBUpdateHandler: failed
query: %s
ERROR
l2tpMgmtTblHandler: Secret: not
specified
pppoeMgmtDBUpdateHandler: error
in executing "
ERROR
l2tpMgmtTblHandler: Secret: %s
pptpMgmtInit: unable to open the
database file %s
ERROR
l2tpMgmtTblHandler: dynamic MyIp
configured
pptpEnable: error executing
command: %s
ERROR
l2tpMgmtTblHandler: MyIp: %s
pptpEnable: unable to resolve
address: %s
ERROR
l2tpMgmtTblHandler: ServerIp: %s
pptpEnable: inet_aton failed
ERROR
l2tpMgmtTblHandler: StaticIp: %s
pptpEnable: inet_aton failed
ERROR
l2tpMgmtTblHandler: NetMask: %s
pptpEnable:spawning failed
ERROR
l2tpMgmtTblHandler: SplitTunnel: %s
pptpDisable: unable to kill ppp
daemon
ERROR
needToStartHealthMonitor: returning with
status: %s
pptpMgmtTblHandler: unable to get
current MTU Option
ERROR
l2tpEnable: command string: %s
pptpMgmtTblHandler: unable to get
the Mtu
ERROR
l2tpEnable: command: %s
pptpMgmtTblHandler:
dbRecordValueGet failed for %s "
ERROR
l2tpEnable: command string: %s
pptpMgmtTblHandler: pptp enable
failed
ERROR
PID File for dhcpc found
pptpMgmtTblHandler: pptp disable
failed
ERROR
pid: %d
pptpMgmtDBUpdateHandler:
sqlite3QueryResGet "
ERROR
l2tpMgmtDBUpdateHandler: query string:
%s
pptpMgmtDBUpdateHandler: error in
executing "
ERROR
l2tpMgmtDBUpdateHandler: returning
with status: %s
Illegal invocation of dhcpConfig (%s)
ERROR
RADVD started successfully
dhcpLibInit: unable to open the
database file %s
ERROR
RADVD stopped successfully
sqlite3QueryResGet failed.Query:%s
ERROR
empty update. nRows=%d nCols=%d
dhcpcMgmtInit: unable to open the
database file %s
ERROR
Wan is not up or in load balencing mode
dhcpcReleaseLease: unable to
release lease
ERROR
threegMgmtHandler: no row found.
nRows = %d nCols = %d
dhcpcEnable: unable to kill dhclient
ERROR
pppoeMgmtDBUpdateHandler: empty
update.
dhcpcEnable: enabling dhcpc failed
on: %s
ERROR
dhcpcEnable: dhclient already running
on: %s
dhcpcDisable: unable to kill dhclient
ERROR
dhcpcDisable: deleted dhclient.leases
dhcpcDisable: delete failed for
dhclient.leases
ERROR
l2tpMgmtInit: unable to open the
database file %s
dhcpcDisable: failed to reset the ip
ERROR
l2tpEnable: unable to resolve address:
%s
dhcpcMgmtTblHandler: unable to get
current Mtu Option
ERROR
l2tpEnable: inet_aton failed
dhcpcMgmtTblHandler: unable to get
the Mtu
ERROR
Unified Services Router User Manual
167
The Enable Command is %s
dhcpcMgmtTblHandler: dhclient
enable failed
ERROR
l2tpEnable:Executing the Command
failed
dhcpcMgmtTblHandler: dhcpc release
failed
ERROR
l2tpDisable: command string: %s
dhcpcMgmtTblHandler: dhcpc disable
failed
ERROR
l2tpDisable: unable to stop l2tp session
dhcpcMgmtDBUpdateHandler: failed
query: %s
ERROR
l2tpMgmtTblHandler: unable to get
current MTU option
dhcpcMgmtDBUpdateHandler: error
in executing "
ERROR
l2tpMgmtTblHandler: unable to get the
Mtu
DHCPv6 Client start failed.
ERROR
l2tpMgmtTblHandler: dbRecordValueGet
failed for %s "
DHCPv6 Client stop failed.
ERROR
l2tpMgmtTblHandler: l2tpEnable failed
failed to create/open DHCPv6 client "
ERROR
l2tpMgmtTblHandler: disabling l2tp failed
failed to write DHCPv6 client
configuration file
ERROR
l2tpMgmtDBUpdateHandler:
sqlite3QueryResGet "
failed to restart DHCPv6 Client
ERROR
l2tpMgmtDBUpdateHandler: error in
executing
failed to create/open DHCPv6 Server
"
ERROR
Illegal invocation of tcpdumpConfig (%s)
Restoring old configuration..
ERROR
Failed to start tcpdump
DHCPv6 Server configuration update
failed
ERROR
Failed to stop tcpdump
DHCPv6 Server Restart failed
ERROR
Invalid tcpdumpEnable value
sqlite3QueryResGet failed.Query:%s
ERROR
Facility: System (VPN)
Log Message
Log Message
Severity
%d command not supported by eapAuth
PEAP key derive: ERROR
ERROR
pCtx NULL.
PEAP context is NULL: ERROR
ERROR
Current cert subject name= %s
Constructing P2 response: ERROR
ERROR
X509_STORE_CTX_get_ex_data failed.
innerEapRecv is NULL: ERROR
ERROR
Cannot get cipher, no session est.
Decrypting TLS data: ERROR
ERROR
%s:
SSL_ERROR_WANT_X509_LOOKUP
Wrong identity size: ERROR
ERROR
err code = (%d) in %s
Wrong size for extensions packet:
ERROR
ERROR
BIO_write: Error
innerEapRecv is NULL: ERROR.
ERROR
Decrypting: BIO reset failed
Inner EAP processing: ERROR
ERROR
Encrypting BIO reset: ERROR
TLS handshake: ERROR.
ERROR
BIO_read: Error
Sending P1 response: ERROR
ERROR
EAP state machine changed from %s to
%s.
Unexpected tlsGlueContinue return
value.
ERROR
EAP state machine changed from %s to
%s.
No more fragments in message.
ERROR
ERROR
Received EAP Packet with code %d
No phase 2 data or phase 2 data
buffer NULL: ERROR
ERROR
Response ID %d
Allocating memory for PEAP Phase 2
payload: ERROR
ERROR
Response Method %d
TLS encrypting response: ERROR
ERROR
Unified Services Router User Manual
168
Created EAP/PEAP context: OK
Setting message in fragment buffer:
ERROR
ERROR
Deleted EAP/PEAP context: OK
Allocating TLS read buffer is NULL:
ERROR
ERROR
Upper EAP sent us: decision = %d
method state = %d
Setting last fragment: ERROR
ERROR
P2 decision=(%d); methodState=(%d)
Getting message: ERROR
ERROR
Writing message to BIO: ERROR.
Processing PEAP message: ERROR
ERROR
Encrypted (%d) bytes for P2
Setting fragment: ERROR
ERROR
P2: sending fragment.
Creating receive buffer: ERROR
ERROR
P2: message size = %d
Setting first fragment: ERROR
ERROR
P2: sending unfragmented message.
Sending P1 response: ERROR
ERROR
P1: Sending fragment.
NULL request (or response) PDU or
NULL context: ERROR
ERROR
P1: Total TLS message size = (%d)
Expecting start packet, got something
else: ERROR
ERROR
P1: sending unfragmented message.
Protocol version mismatch: ERROR
ERROR
peapFragFirstProcess: TLS record size
to receive = (%d)
Processing PEAP message (from
frag): ERROR
ERROR
Setting version %d
Processing PEAP message: ERROR
ERROR
PEAP pkt rcvd: data len=(%d) flags=(%d)
version=(%d)
Processing PEAP message: ERROR
ERROR
Got PEAP/Start packet.
Indicated length not valid: ERROR
ERROR
Got first fragment
Did not get Acknowledged result:
ERROR
ERROR
Got fragment (n)
Cannot understand AVP value:
ERROR
ERROR
Got last fragment
eapExtResp is NULL: ERROR
ERROR
Got unfragmented message
eapWscCtxCreate:
EAPAUTH_MALLOC failed.
ERROR
Got frag ack.
eapWscProcess: umiIoctl req to WSC
failed, status = %d
ERROR
Ext AVP parsed: flags=(0x%x)
eapWscCheck: Invalid frame
ERROR
Mandatory bit not set: WARNING
eapWscBuildReq: Invalid state %d
ERROR
Ext AVP parsed: type=(%d)
eapWscProcessWscResp: Invalid data
recd pData = %p, dataLen"
ERROR
Ext AVP parsed: value=(%d)
Data received for invalid context,
dropping it
ERROR
Got PEAPv0 success!
eapWscProcessWscResp: Build
Request failed
ERROR
Got PEAPv0 failure!
eapWscProcessWscResp: Invalid
state %d
ERROR
pCtx NULL.
eapWscProcessWscResp: Message
processing failed 0x%X
ERROR
Authenticator response check: Error
eapWscProcessWscData: Invalid
notification recd %d
ERROR
Authenticator response check: Failed
unable to initialize MD5
ERROR
MS-CHAP2 Response AVP size = %u
MDString: adpDigestInit for md5 failed
ERROR
Created EAP/MS-CHAP2 context: OK.
EAPAUTH_MALLOC failed.
ERROR
pCtx NULL.
EAPAUTH_MALLOC failed.
ERROR
Deleted EAP/MS-CHAPv2 context: OK
NULL context created: Error
ERROR
Not authenticated yet.
NULL context received: Error
ERROR
Authenticator response invalid
Authenticator ident invalid.
ERROR
EAP-MS-CHAPv2 password changed.
Success request message invalid:
ERROR
Unified Services Router User Manual
169
Error
rcvd. opCode %d.
Plugin context is NULL
ERROR
pCtx NULL.
Deriving implicit challenge: Error
ERROR
TLS message len changed in the
fragment, ignoring.
Generating NT response: Error
ERROR
no data to send while fragment ack
received.
NULL in/out buffer: Error
ERROR
TLS handshake successful.
Incorrect vendor id.
ERROR
Created EAP/TTLS context: OK
Allocating memory for outBuff: ERROR
ERROR
Deleted EAP/TTLS context: OK
AVP code not recognized
ERROR
No more fragments in message. ERROR
EAPAUTH_MALLOC failed.
ERROR
Upper EAP sent us: method state = %d;
decision = %d
Converting password to unicode: Error
ERROR
P2: sending fragment.
Generating password hash: Error.
ERROR
P2 send unfragmented message.
Generating password hash hash:
Error.
ERROR
P1: sending fragment.
Generating master key: Error.
ERROR
P1: sending unfragmented message.
Generating first 16 bytes of session
key: Error.n
ERROR
\tTLSMsgLen = 0x%x
Generating second 16 bytes of session
key: Error.n
ERROR
Send req ptr = 0x%x; Send resp ptr =
0x%x
Converting password to unicode: Error
ERROR
P2 decision=(%d); methodState=(%d)
Constructing failure response: ERROR
ERROR
Default EAP: method state = %d;
decision = %d
Error checking authenticator response.
ERROR
TTLS pkt: data len=(%d) flags=(0x%x)
Error generating NT response.
ERROR
Got start
Username string more than 256 ASCII
characters: ERROR
ERROR
Got first fragment (n).
Invalid Value-Size.
ERROR
Got fragment (n).
Invalid MS-Length. Got (%d), expected
(%d)
ERROR
Got last fragment
Error constructing response.
ERROR
Got unfragmented message.
Got type (%d), expecting (%d)
ERROR
Got frag ack.
Cannot handle message; opCode =
%d
ERROR
Rcvd. AVP Code-%u: flags-0x%x: len-
%u: vendorId-%u: "
EAPAUTH_MALLOC failed.
ERROR
MOD EAP: method state from upper =
%d; decision = %d
tlsGlueCtxCreate failed.
ERROR
Got AVP len = %ul. Should be less than
16777215
client certificate must be set in the
profile.
ERROR
AVP length extract: Error
received tls message length too big.
ERROR
pFB is NULL
total frags len > initial total tls length.
ERROR
Requesting message before assembly
complete
total frags len > initial total tls length.
ERROR
pFB is NULL
total data rcvd(%d) doesnt match the
initial "
ERROR
pFB is NULL
couldnt write %d data to TLS buffer.
ERROR
Buffer cannot hold message: ERROR
invalid flags %s passed to
eapTlsBuildResp.
ERROR
pFB is NULL: Error
EAPAUTH_MALLOC failed.
ERROR
pFB is NULL
tlsGlueCtxCreate failed.
ERROR
TLS_FB* is NULL.
Context NULL: ERROR
ERROR
Unified Services Router User Manual
170
pFB->msgBuff is NULL.
Setting profile to glue layer: ERROR.
ERROR
Error calculating binary.
_eapCtxCreate failed.
ERROR
Error calculating binary.
%d authentication not enabled in the
system.
ERROR
adpDigestInit for SHA1 failed.
Initializing inner non-EAP auth plugin:
ERROR
ERROR
adpDigestInit for SHA1 failed.
TTLS key derive: ERROR
ERROR
E = %d
TTLS context from EAP plugin is
NULL: ERROR
ERROR
R = %d
Allocating memory for TTLS Phase 2
payload: ERROR
ERROR
Could not initialize des-ecb
TLS Encrypting response: ERROR
ERROR
adpDigestInit for MD4 failed.
Allocating TLS read buffer is NULL:
ERROR
ERROR
adpDigestInit for SHA1 failed.
Inner authentication (id: %d)
unhandled
ERROR
adpDigestInit for SHA1 failed.
innerEapRecv is NULL: ERROR.
ERROR
Error converting received auth reponse to
bin.
Decrypting TLS data: ERROR
ERROR
Gnerating challenge hash: Error
Processing Phase 2 method: Error
ERROR
Generating password hash: Error
Writing message to BIO: ERROR.
ERROR
Generating challenge response: Error
TLS handshake: ERROR.
ERROR
Conn cipher name=%s ver=%s: %s
Unexpected tlsGlueContinue return
value.
ERROR
Send req ptr = 0x%x; Send resp ptr =
0x%x
NULL request (or response) PDU or
NULL context
ERROR
Request ptr = 0x%x;
Protocol version mismatch: ERROR
ERROR
Response ptr = 0x%x
Creating receive buffer: ERROR
ERROR
Rcvd. AVP Code - %ul
Setting first fragment: ERROR
ERROR
Rcvd. AVP flags - 0x%02x
Setting fragment: ERROR
ERROR
Rcvd. AVP len - %ul
Setting last fragment: ERROR
ERROR
Rcvd. AVP vendor id - %ul
Getting message: ERROR
ERROR
\tCode = %d
Processing TTLS message: ERROR
ERROR
\tIdent = %d
Processing TTLS message: ERROR
ERROR
\tLen = %d
Processing TTLS message: ERROR
ERROR
\tType = %d
Decapsulating AVP: ERROR
ERROR
\tOpCode = %d
Processing EAP receive: Error
ERROR
\tMSID = %d
AVP code not EAP: Error
ERROR
\tmsLen = %d
Encapsulating AVP: ERROR
ERROR
\tvalSize = %d
profile %s doesnt exist.
ERROR
Frag Buffer bytes left = (%d)
profile %s is in use.
ERROR
Stripped username=(%s)
profile %s already exists.
ERROR
digestLen = %d.
EAPAUTH_MALLOC failed
ERROR
ClearText =
User not found.
ERROR
CipherText =
EAP-MD5 not enabled in system
configuration.
ERROR
digestLen = %d.
EAP-MSCHAPV2 not enabled in
system configuration.
ERROR
digestLen1 = %d.
EAP-TLS not enabled in system
configuration.
ERROR
digestLen2 = %d.
EAP-TTLS not enabled in system
configuration.
ERROR
Unified Services Router User Manual
171
password change is not allowed for this
user
EAP-PEAP not enabled in system
configuration.
ERROR
completed writing the policy
EAP-WSC not enabled in system
configuration.
ERROR
completed writing the SA
PAP not enabled in system
configuration.
ERROR
completed writing the proposal block
CHAP not enabled in system
configuration.
ERROR
cmdBuf: %s
MSCHAP not enabled in system
configuration.
ERROR
X509_DEBUG : Invalid Certificate for the
generated"
MSCHAPV2 not enabled in system
configuration.
ERROR
X590_ERROR : Failed to create File '%s'
PAP/Token not enabled in system
configuration.
ERROR
x509TblHandler
EAP-MD5 not enabled in system
configuration.
ERROR
pCertType: %s
EAP-MSCHAPV2 not enabled in
system config.
ERROR
pRowQueryStr: %s
EAP-TLS not enabled in system
configuration.
ERROR
x509SelfCertTblHandler
EAP-TTLS and EAP-PEAP are not
valid as inner"
ERROR
pRowQueryStr: %s
invalid innerAuth %d.
ERROR
%s:DBUpdate event: Table: %s
opCode:%d rowId:%d
profile %s doesnt exist.
ERROR
umiRegister failed
Re-assembling fragments incorrect
size
ERROR
eapAuthHandler: Invalid data received
Error creating cipher context.
ERROR
EAPAUTH_MALLOC failed.
Error initializing cipher context.
ERROR
malloc failed.
Error creating digest context.
ERROR
BIO_new_mem_buf failed.
Error initializing digest context.
ERROR
malloc failed.
Error initializing DES in Klite
ERROR
BIO_new_mem_buf failed.
Error initializing MD4 in Klite
ERROR
SSL_CTX_new (TLSv1_client_method)
failed.
Error initializing RC4 in Klite
ERROR
unable to set user configured CIPHER
list %s
Error initializing SHA in Klite
ERROR
Certificate verification failed.
Error cleaning cipher context.
ERROR
Server name match failed. Got (%s)
expected "
Error destroying cipher context.
ERROR
SSL_CTX_use_certificate_file (cert,
PEM) failed.
Error cleaning digest context.
ERROR
SSL_CTX_use_PrivateKey_file failed.
Error destroying digest context.
ERROR
private key does not match public key
Error stripping domain name.
ERROR
SSL_CTX_load_verify_locations failed
Error cleaning digest context.
ERROR
SSL_new failed.
Error cleaning digest context.
ERROR
Both SSL_VERIFY_PEER and
SSL_VERIFY_NONE set: Error
Challenge not present in failure
packet.
ERROR
EAPAUTH_MALLOC failed.
Wrong challenge length.
ERROR
EAPAUTH_MALLOC failed.
Incorrect password change version
value.
ERROR
eapTimerCreate failed.
Error generating password hash.
ERROR
eapCtxDelete:pCtx == NULL
Error generating password hash.
ERROR
eapRole != EAP_ROLE_PEER or
EAP_ROLE_AUTHENTICATOR
Error encrypting password hash with
block
ERROR
Unified Services Router User Manual
172
pEapCtx == NULL or pPDU == NULL.
Could not initialize des-ecb
ERROR
received EAP pdu bigger than
EAP_MTU_SIZE.
Error cleaning cipher context.
ERROR
received EAP pdu bigger than
EAP_MTU_SIZE.
Error cleaning cipher context.
ERROR
state machine is in invalid state.
Error cleaning digest context.
ERROR
unable to create method context.
Error cleaning digest context.
ERROR
method ctxCreate failed.
adpDigestInit for SHA1 failed.
ERROR
method profile set failed.
X509_ERROR : .Query:%s
ERROR
state machine is in invalid state.
X509_ERROR : Invalid Certificate for
the "
ERROR
Only StandAlone authenticator supported
currently.
invalid x509 certificate
ERROR
state machine is in invalid state.
Couldn't get the x509 cert hash
ERROR
BuildReq operation failed
Memory allocation failed
ERROR
No method ops defined for current
method
FileName too lengthy
ERROR
Process operation failed
Couldn't execute command
ERROR
state machine is in invalid state.
Memory allocation failed
ERROR
Packet length mismatch %d, %d
Memory allocation failed
ERROR
eapAuthTypeToType: Invalid
eapAuthType %d
invalid certificate data
ERROR
eapTypeToAuthType: Invalid eapType
%d
.Query:%s
ERROR
unable to create method context.
.Query:%s
ERROR
method ctxCreate failed.
Memory allocation failed
ERROR
Invalid condition, methodState = %d,
respMethod = %d
X509_ERROR : Failed to validate the
certficate "
ERROR
A EAP Ctx map already exists
Memory allocation failed
ERROR
eapTimerCreate: Currently unsupported
for Peer role
.Query:%s
ERROR
eapTimerStart: Currently unsupported for
Peer role
Invalid Sign Key Length : %d
ERROR
eapTimerDestroy: Currently unsupported
for Peer role
Invalid Hash Alg : %d
ERROR
eapTimerCancel: Currently unsupported
for Peer role
Invalid Sign Alg : %d
ERROR
eapTimerHandler: Currently unsupported
for Peer role
No Memory Available
ERROR
pCtx is NULL: ERROR
Certificate Request Failed
ERROR
tlsGlueCtxCreate failed
File Open Failed
ERROR
eapVars is NULL
File is Empty
ERROR
Context NULL: ERROR
Memory Allocation Failed
ERROR
Initializing inner EAP auth: ERROR
File Open Failed
ERROR
pCtx is NULL: ERROR
File is Empty
ERROR
Memory Allocation Failed
Error in executing DB update handler
ERROR
Facility: System (Admin)
Log Message
Severity
Log Message
Severity
Usage:%s <DBFile>
unable to register to UMI
ERROR
Unified Services Router User Manual
173
Could not open database: %s
sqlite3QueryResGet failed
ERROR
CPU LOG File not found
radSendtoServer: socket: %s
ERROR
MEM LOG File not found
radSendtoServer: bind() Failed: %s:
%s
ERROR
cpuMemUsageDBUpdateHandler:
update query: %s
radRecvfromServer: recvfrom() Failed:
%s
ERROR
Printing the whole list after inserting
radRecvfromServer: Packet too small
from %s:%d: %s
ERROR
%s at %d(minute) %d(hour)
%d(dayOfMonth) %d(month)"
radCheckMsgAuth: Invalid Message-
Authenticator length in"
ERROR
adpCmdExec exited with return code=%d
radDictLoad: couldn't open dictionary
%s: %s
ERROR
%s op=%d row=%d
radBuildAndSendReq: Invalid Request
Code %d
ERROR
sqlite3_mprintf failed
radPairAssign: bad attribute value
length
ERROR
sqlite3QueryResGet failed: query=%s
radPairAssign: unknown attribute type
%d
ERROR
Printing the whole list after delete
radPairNew: unknown attribute %d
ERROR
%s at %d(minute) %d(hour)
%d(dayOfMonth) %d(month)"
radPairGen: Attribute(%d) has invalid
length
ERROR
Printing the whole list after inserting
radPairValue: unknown attribute type
%d
ERROR
%s at %d(minute) %d(hour)
%d(dayOfMonth) %d(month)"
radPairValueLen: unknown attribute
type %d
ERROR
email logs: No logging events enabled
radPairLocate: Attribute(%d) has
invalid length
ERROR
%s
radPairUnpackDefault: Unknown-
Attribute[%d]:
ERROR
Mail sent and the Database is reset.
radConfigure: can't open %s: %s
ERROR
Disabled syslog server
radConfigure: %s: line %d: bogus
format: %s
ERROR
Event logs are full, sending logs to email
radConfAssert: No AuthServer
Specified
ERROR
Email logs sending failed
radConfAssert: No Default Timeout
Specified
ERROR
Packing attribute: %s
radConfAssert: No Default Retry
Count Specified
ERROR
Server found: %s, secret: %s
radExtractMppeKey: Invalid MS-
MPPE-Key Length
ERROR
Packed Auth. Reqest: code:%d, id:%d,
len:%d
radVendorMessage: Invalid Length in
Vendor Message
ERROR
Sending Packet to %x:%d ....
radVendorMessage: Unknown Vendor
ID received:%d
ERROR
Receiving Reply Packet....
radVendorAttrGet: Invalid Length in
Vendor Message
ERROR
Verified Reply Packet Integrity
radVendorAttrGet: Unknown Vendor
ID:%d
ERROR
Generated Reply Attribute-Value pairs
radVendorMessagePack: Unknown
Vendor ID:%d
ERROR
Verified Message-Authenticator
radGetIPByName: couldn't resolve
hostname: %s
ERROR
Unloaded RADIUS Dictionary
radGetHostIP: couldn't get hostname
ERROR
Adding Dictionary Attribute %s
radGetHostIP: couldn't get host IP
address
ERROR
Adding Dictionary Value %s
radius dictionary loading failed
ERROR
Loaded Dictionary %s
Failed to set default timeout value
ERROR
Unified Services Router User Manual
174
Adding Dictionary Attribute '%s'
Failed to set default retries value
ERROR
Adding Dictionary Value %s
ERROR: incomplete DB update
information.
ERROR
Receiving attribute: %s
old values result does not contain 2
rows
ERROR
Processing attribute: %s
sqlite3QueryResGet failed
ERROR
Processing attribute: %s
empty update. nRows=%d nCols=%d
ERROR
Processing attribute: %s
Error in executing DB update handler
ERROR
Processing attribute: %s
sqlite3QueryResGet failed
ERROR
radConfGet: "
Invalid SQLITE operation code - %d
ERROR
Added Server %s:%d with "
sqlite3QueryResGet failed
ERROR
Added Server %s:%d with "
empty result. nRows=%d nCols=%d
ERROR
Default Timeout Set to %d
sqlite3QueryResGet failed
ERROR
Default Retry Count Set to %d
empty result. nRows=%d nCols=%d
ERROR
%s - %s : %d
RADIUS Accounting Exchange Failed
ERROR
Deleting Server %s:%d with "
Unable to set debug for radAcct.
ERROR
Adding RowId:%d to Server %s:%d with "
Unable to set debug level for radAcct.
ERROR
rowIds: %d - %d
ERROR: option value not specified
ERROR
Deleting Server %s:%d with "
ERROR: option value not specified
ERROR
RADIUS Deconfigured
Unable to initialize radius
ERROR
Found Option %s on line %d of file %s
radEapMsgQueueAdd: Invalid EAP
packet length(%d)
ERROR
Setting Option %s with value %s
radEapRecvTask: invalid EAP
code:%d
ERROR
RADIUS Configured
radEapRecvTask: Packet length
mismatch %d, %d
ERROR
%d : Server %s:%d with "
No attributes received in Access-
Challenge message
ERROR
DBUpdate event: Table: %s opCode:%d
rowId:%d
No State Attribute in Access-
Challenge message
ERROR
Host IP address: %s
radEapRecvTask: "
ERROR
Adding Packet for existing cookie:%p
failed to initialize UMI
ERROR
Adding Packet and cookie:%p
umiRegister failed. errno=%d
ERROR
Releasing Packet and cookie:%p
Invalid arguments to ioctl handler
ERROR
Releasing Packet with cookie:%p
radEapSendRtn: Invalid Arguments
ERROR
Received EAP-Identity from Pnac: %s
radEapSendRtn: failed to allocate
buffer
ERROR
Filling User-Name: %s
umiIoctl failed
ERROR
Filling State:
failed to initialize EAP message queue
ERROR
Filling EAP-Message:
Unable to set debug for radEap.
ERROR
Filling Service-Type: %d
Unable to set debug level for radEap.
ERROR
Filling Framed-MTU: %d
ERROR: option value not specified
ERROR
Received Access-Challenge from Server
ERROR: option value not specified
ERROR
Sending Reply EAP Packet to Pnac
could not initialize MGMT framework
ERROR
Error sending packet to Pnac
Unable to initialize radius
ERROR
RADIUS Authentication Failed; "
Unable to set debug for radEap.
ERROR
RADIUS Authentication Successful; "
Unable to set debug level for radEap.
ERROR
Got Packet with cookie:%p
ERROR: option value not specified
ERROR
Next DNS Retry after 1 min
Unable to initialize radius
ERROR
Next Synchronization after"
Invalid username or password
ERROR
Unified Services Router User Manual
175
Next Synchronization after"
Unable to set debug for radAuth.
ERROR
Next Synchronization after %d \
Unable to set debug level for radAuth.
ERROR
Primary is not available, "
ERROR: option value not specified
ERROR
Secondary is not available, "
Unable to initialize radius
ERROR
Invalid value for use default servers, "
Invalid username, challenge or
response
ERROR
No server is configured, "
Unable to set debug for radAuth.
ERROR
Backing off for %d seconds
Unable to set debug level for radAuth.
ERROR
Requesting time from %s
ERROR: option value not specified
ERROR
Synchronized time with %s
Unable to initialize radius
ERROR
Received KOD packet from %s
Invalid username or password
ERROR
No suitable server found %s
usage : %s <DB fileName>
ERROR
Received Invalid Length packet from %s
ntpd : umi initialization failed
ERROR
Received Invalid Version packet from %s
ntpd : ntpInit failed
ERROR
Received Invalid Mode packet from %s
ntpd : ntpMgmtInit failed
ERROR
Request Timed out from %s
There was an error while getting the
timeZoneChangeScript."
ERROR
Looking Up %s
unexpected reply from %d cmd=%d !
ERROR
Timezone difference :%d
cmd %d not supported. caller %d
ERROR
Could not open file: %s
default reached
ERROR
Could not read data from file
Unable to initialize ntpControl
ERROR
ntpTblHandler
ntpMgmt : Couldn't open database %s
ERROR
status: %d
ERROR : incomplete DB update
information
ERROR
tz: %d
empty update. nRows=%d nCols=%d
ERROR
DayLightsaving: %d
Error in executing DB update handler
ERROR
pNtpControl-
>ServerNames[PRIMARY_SERVER]:
%s
requestNtpTime: Invalid addr
ERROR
pNtpControl-
>ServerNames[SECONDARY_SERVER]
: %s
failed to take lock for compId: %d
ERROR
DS: %d
failed to convert ioctl args to buffer
for"
ERROR
pPriServ %s
request timeout dst(%d) <-- src(%d)
ERROR
pSecServ %s
failed to take lock for compId: %d
ERROR
Making request from %d --> %d
umiIoctlArgsToBuf: failed to allocate
memory
ERROR
sent request dst(%d) <-- src(%d) using
option %d
umiRecvFrom: could not allocate
memory
ERROR
received request too small!(%d bytes)
adpMalloc failed
ERROR
Received a UMI request from %d
context with ID: %d already registered
ERROR
sent a reply src(%d) ---> dst(%d)
Failed to allocate memory for creating
UMI context
ERROR
umiRegister (%x,%x,%x,%x)
Failed to create recvSem for UMI
context
ERROR
srcId=%d(%s) --> destId=%d(%s)
cmd=%d inLen=%d outLen=%d
Failed to create mutex locks for UMI
context
ERROR
waiting for reply...Giving Up
Failed to create mutex recvQLock for
UMI context
ERROR
No request in the list after semTake
Invalid arguments to umiIoctl
ERROR
reply timeout
could not find the destination context
ERROR
Unified Services Router User Manual
176
timeout after semTake
memPartAlloc for %d size failed
ERROR
srcId=%d(%s) <-- destId=%d(%s)
cmd=%d
memPartAlloc for %d size failed
ERROR
Un-registerting component with Id %d
No Handler registered for this UMI
context
ERROR
failed to send ioctl request: dst(%d) <---
src(%d)
Couldn't find component with ID
(%d),"
ERROR
processed a reply dst(%d) <-- src(%d)
id=%d handler=%x
ERROR
request with no result option dst(%d) <--
src(%d)
Received NULL buffer in
umiBufToIoctlArgs()
ERROR
cmd = %s
usbMgmtInit: unable to open the
database file %s
ERROR
cmdstring is %s %s:%d
call to printConfig failed
ERROR
Calling printerConfig binary ...
Failed to Disable Network Storage"
ERROR
Calling unmount for USB ...
Some error occurred while removing
device
ERROR
Calling mount for USB ...
Some error occurred while removing
device
ERROR
usbdevice is %d %s:%d
Sqlite update failed
ERROR
Query string: %s
Failed to enable printer properly
ERROR
sqlite3QueryResGet failed.Query:%s
Failed to mount device on system
ERROR
%s: 1. usb is already disconnected for
old usb type. "
Failed to enable network storage
device"
ERROR
%s: 2.call disable for new usb type !
Failed to mount device on system
ERROR
%s: 3. usb is already disconnected for
old usb type. "
Sqlite update failed
ERROR
%s: 4. Disabled old usb type . Now "
USB1 Touch failed
ERROR
usbdevice is %d %s:%d
USB2 Touch failed
ERROR
USB: failed to begin transaction: %s
Sqlite update failed
ERROR
USB: SQL error: %s pSetString = %s
Failed query: %s
ERROR
USB: failed to commit transaction: %s
Failed to execute usb database
update handler
ERROR
USB: updated table: %s
Usage:%s <DBFile> <opType>
<tblName> <rowId>
ERROR
USB: returning with status: %s
Illegal invocation of snmpConfig (%s)
ERROR
%s:DBUpdate event: Table: %s
opCode:%d rowId:%d
Invalid Community Access Type
ERROR
executing %s status =%d
Invalid User Access Type
ERROR
executing %s
Invalid Security Level
ERROR
%s returned status=%d
Invalid Authentication Algorithm
ERROR
%s returned status=%d
Invalid Privacy Algorithm
ERROR
snmpd.conf not found
Invalid Argument
ERROR
[SNMP_DEBUG] : Fwrite Successful
Failed to allocate memory for
engineID
ERROR
[SNMP_DEBUG] : Fwrite failed
[SNMP_DEBUG]: Failed to get host
address
ERROR
radPairGen: received unknown attribute
%d of length %d
[SNMP_DEBUG] : FOPEN failed
ERROR
radPairGen: %s has unknown type
sqlite3QueryResGet failed.Query:%s
ERROR
radPairLocate: unknown attribute %ld of
length %d
sqlite3QueryResGet failed.Query:%s
ERROR
radPairLocate: %s has unknown type
Invalid Security Level
ERROR
Illegal invocation of cpuMemUsage (%s)
Invalid Authentication Algorithm
ERROR
Unified Services Router User Manual
177
cpuMemUsageDBUpdateHandler: SQL
error: %s
Invalid Privacy Algorithm
ERROR
unable to open the DB file %s
Failed to Get Host Address
ERROR
umiInit failed
Invalid version
ERROR
unable to register to UMI
snmp v3 Trap Configuration Failed
ERROR
Error Reading from the Database.
sqlite3QueryResGet failed query:%s
ERROR
short DB update event request!
sqlite3QueryResGet failed.Query:%s
ERROR
Error in executing DB update handler
Failed to Open Snmp Configuration
File
ERROR
adpListNodeRemove : Returned with an
error
Failed to write access control entries
ERROR
command too long. Try increasing "
Failed to write snmpv3 users entries
ERROR
failed to allocate memory for
CRON_NODE
Failed to write snmp trap entries
ERROR
sqlite3QueryResGet failed
Failed to write system entries.
ERROR
There was an error while reading the
schedules.
Failed to restart snmp
ERROR
unable to register to UMI
%s failed with status
ERROR
short DB update event request!
Error in executing DB update handler
ERROR
malloc(DB_UPDATE_NODE) failed
%s: Unable to open file: %s
ERROR
short ifDev event request!
RADVD start failed
ERROR
sqlite3_mprintf failed
RADVD stop failed
ERROR
no component id matching %s
failed to create/open RADVD
configuration file %s
ERROR
umiIoctl (%s,
UMI_CMD_DB_UPDATE(%d)) failed.
Restoring old configuration..
ERROR
sqlite3_mprintf failed
failed to write/update RADVD
configuration file
ERROR
sqlite3_mprintf failed
upnpDisableFunc failed
ERROR
no component id matching %s
upnpEnableFunc failed
ERROR
umiIoctl (%s,
UMI_CMD_IFDEV_EVENT(%d)) failed.
sqlite3QueryResGet failed.Query:%s
ERROR
klogctl(9) failed
Error in executing DB update handler
ERROR
malloc failed for %d bytes
unable to open the DB file %s
ERROR
klogctl(4) failed
umiInit failed
ERROR
emailLogs: Invalid Number of
Arguments!! Exiting.
unable to register to UMI
ERROR
sqlite3QueryResGet failed
short DB update event request!
ERROR
Could not execute the smtpClient.
short ifDev event request!
ERROR
Error while cleaning the
database.Exiting. %s
sqlite3_mprintf failed
ERROR
%s failed. status=%d
ERROR
Facility: System (Firewall)
Log Message
Severity
Log Message
Severity
Enabling rule for protocol binding.
DEBUG
Disable all NAT rules.
DEBUG
Disabling rule for protocol binding.
DEBUG
Enable all NAT rules.
DEBUG
Enabling Remote SNMP on WAN.
DEBUG
Enabling NAT URL filter rules.
DEBUG
Disabling Remote SNMP on WAN
DEBUG
Restarting all NAT rules.
DEBUG
Unified Services Router User Manual
178
wan traffic counters are restared
DEBUG
Deleting schedule based firewall rules.
DEBUG
Traffic limit has been reached
DEBUG
Deleting schedule based firewall rules
from DB.
DEBUG
Traffic meter monthly limit has been
changed to %d.
DEBUG
Update schedule based firewall rules in
DB.
DEBUG
Enabling traffic meter for only dowload.
DEBUG
Restart schedule based firewall rules.
DEBUG
Enabling traffic meter for both directions.
DEBUG
inter vlan routing enabled
DEBUG
Enabling traffic meter with no limit.
DEBUG
inter vlan routing disabled
DEBUG
Email alert in traffic meter disabled.
DEBUG
Disabling Content Filter for %d
DEBUG
Email alert in traffic meter enabled.
DEBUG
Enabling Content Filter for %d
DEBUG
Traffic Meter:Monthly limit %d MB has
been "
DEBUG
./src/firewall/linux/user/firewalld.c:59:#u
ndef ADP_DEBUG2
DEBUG
Traffic Metering: Adding rule to drop all
traffic
DEBUG
./src/firewall/linux/user/firewalld.c:61:#d
efine ADP_DEBUG2 printf
DEBUG
Traffic Metering: %sabling Email traffic
DEBUG
Enabling Source MAC Filtering
DEBUG
Disabling attack checks for IPv6 rules.
DEBUG
Disabling Source MAC Filtering
DEBUG
Enabling attack checks for IPv6 rules.
DEBUG
Adding MAC Filter Policy for Block &
Permit Rest
DEBUG
Configuring one to one NAT settings with
%s private start IP "
DEBUG
Adding MAC Filter Policy for Permit &
Block Rest
DEBUG
Deleting forward one to one NAT having
setting %s private start"
DEBUG
Restarting Source MAC Address Policy
DEBUG
Disabling attack check for Block ping to
WAN interface.
DEBUG
Disabling Firewall Rule for DHCP Relay
Protocol
DEBUG
Disabling attack check for Stealth mode
for tcp
DEBUG
Enabling Firewall Rule for DHCP Relay
Protocol
DEBUG
Disabling attack check for Stealth mode
for udp
DEBUG
prerouting Firewall Rule add for Relay
failed
DEBUG
Disabling attack check for TCP Flood.
DEBUG
prerouting Firewall Rule add for Relay
failed
DEBUG
Disabling attack check for UDP Flood.
DEBUG
Deleting MAC Filter Policy for Address
%s
DEBUG
Disabling attack check for IPsec.
DEBUG
Adding MAC Filter Policy for Address
%s
DEBUG
Disabling attack check for PPTP.
DEBUG
Disabling Firewall Rules for DMZ host
DEBUG
Disabling attack check for L2TP.
DEBUG
Enabling Firewall Rules for DMZ host
DEBUG
Disabling attack check for UDP Flood.
DEBUG
Disabling Firewall Rules for Spill Over
Load Balancing
DEBUG
Disabling attack check for IPsec.
DEBUG
Disabling Firewall Rules for Load
Balancing
DEBUG
Disabling attack check for PPTP.
DEBUG
Enabling Firewall Rules for Load
Balancing
DEBUG
Disabling attack check for L2TP.
DEBUG
Enabling Firewall Rules for Spill Over
Load Balancing
DEBUG
Enabling attack check for Block ping to
WAN "
DEBUG
Enabling Firewall Rules for Auto
Failover
DEBUG
Enabling attack check for Stealth Mode
for tcp.
DEBUG
Enabling Firewall Rules for Load
Balancing .
DEBUG
Enabling attack check for Stealth Mode
for udp.
DEBUG
Enabling Firewall Rules for Spill Over
Load Balancing .
DEBUG
Enabling attack check for TCP Flood.
DEBUG
Enabling Firewall Rules for Auto
Failover
DEBUG
Enabling attack check for UDP Flood.
DEBUG
Deleting BlockSites Keyword \
DEBUG
Enabling attack check for IPsec.
DEBUG
Enabling BlockSites Keyword \
DEBUG
Enabling attack check for PPTP.
DEBUG
Disabling BlockSites Keyword \
DEBUG
Unified Services Router User Manual
179
Enabling attack check for L2TP.
DEBUG
Updating BlockSites Keyword from \
DEBUG
Enabling attack check for UDP Flood.
DEBUG
Inserting BlockSites Keyword \
DEBUG
Enabling attack check for IPsec.
DEBUG
Deleting Trusted Domain \
DEBUG
Enabling attack check for PPTP.
DEBUG
Adding Trusted Domain \
DEBUG
Enabling attack check for L2TP.
DEBUG
Restarting Schedule Based Firewall
Rules
DEBUG
Enabling DoS attack check with %d
SyncFlood detect rate, "
DEBUG
Enabling Remote SNMP
DEBUG
Disabling DoS attack check having %d
SyncFlood detect rate,"
DEBUG
Disabling Remote SNMP
DEBUG
Enabling ICSA Notification Item for ICMP
notification.
DEBUG
Enabling Remote SNMP
DEBUG
Enabling ICSA Notification Item for
Fragmented Packets.
DEBUG
Disabling DOS Attacks
DEBUG
Enabling ICSA Notification Item for Multi
cast Packets.
DEBUG
Enabling DOS Attacks
DEBUG
Disabling ICSA Notification Item for
ICMP notification.
DEBUG
Enabling DOS Attacks
DEBUG
Disabling ICSA Notification Item for
Fragmented Packets.
DEBUG
Restarting Firewall [%d]:[%d] For %s
DEBUG
Disabling ICSA Notification Item for Multi
cast Packets.
DEBUG
restartStatus = %d for LogicalIfName =
%s
DEBUG
Adding IP/MAC binding rule for %s MAC
address "
DEBUG
Deleting Lan Group %s
DEBUG
Deleting IP/MAC binding rule for %s
MAC "
DEBUG
Adding Lan Group %s
DEBUG
./src/firewall/linux/user/firewalld.c:60:#un
def ADP_DEBUG
DEBUG
Deleting lan host %s from group %s
DEBUG
./src/firewall/linux/user/firewalld.c:62:#def
ine ADP_DEBUG printf
DEBUG
Adding lan host %s from group %s
DEBUG
Restarting traffic meter with %d mins,
%d hours, "
DEBUG
Disabling Firewall Rule for IGMP
Protocol
DEBUG
Updating traffic meter with %d mins, %d
hours, "
DEBUG
Enabling Firewall Rule for IGMP
Protocol
DEBUG
Deleting traffic meter.
DEBUG
Deleting IP/MAC Bind Rule for MAC
address %s and IP "
DEBUG
Disabling block traffic for traffic meter.
DEBUG
Adding IP/MAC Bind Rule for MAC
address %s and IP
DEBUG
Enabling traffic meter.
DEBUG
Deleting Protocol Bind Rule for Service
%s
DEBUG
Adding lan group %s.
DEBUG
Deleting Protocol Bind Rule for Service
%s
DEBUG
Deleting lan group %s.
DEBUG
Deleting Protocol Bind Rule for Service
%s
DEBUG
Renaming lan group from %s to %s.
DEBUG
Adding Protocol Bind Rule for Service
%s
DEBUG
Deleting host %s from %s group.
DEBUG
%s Session Settings
DEBUG
Adding host %s to %s group.
DEBUG
Restarting IPv6 Firewall Rules...
DEBUG
Enabling Keyword blocking for %s
keyword.
DEBUG
Deleting Port Trigger Rule for
%d:%d:%d:%d:%d
DEBUG
Disabling keyword Blocking for %s
keyword .
DEBUG
Deleting Port Trigger Rule for
%d:%d:%d:%d:%d
DEBUG
Deleting trusted domain with keyword
%s.
DEBUG
Enabling Port Trigger Rule for
%d:%d:%d:%d:%d
DEBUG
Adding %s keyword to trusted domain.
DEBUG
Disabling Port Trigger Rule for
%d:%d:%d:%d:%d
DEBUG
Enabling Management Access from
DEBUG
Enabling Port Trigger Rule for
DEBUG
Unified Services Router User Manual
180
Internet on port %d
%d:%d:%d:%d:%d
Enabling remote access management
for IP address range"
DEBUG
Disabling Port Trigger Rule for
%d:%d:%d:%d:%d
DEBUG
Enabling remote access management to
only this PC.
DEBUG
Adding Port Trigger Rule for
%d:%d:%d:%d:%d
DEBUG
Disabling Management Access from
Internet on port %d
DEBUG
Enabling Content Filter
DEBUG
Disabling remote access management
for IP address range"
DEBUG
Disabling Content Filter
DEBUG
Disabling remote access management
only to this PC.
DEBUG
Enabling Content Filter
DEBUG
MAC Filtering %sabled for BLOCK and
PERMIT REST.
DEBUG
Setting NAT mode for pLogicalIfName
= %s
DEBUG
MAC Filtering %sabled for PERMIT and
BLOCK REST.
DEBUG
Enabling DROP for INPUT
DEBUG
Enabling Content Filtering.
DEBUG
Enabling DROP for FORWARD
DEBUG
Disabling Content Filtering.
DEBUG
Enabling NAT based Firewall Rules
DEBUG
Deleting rule, port triggering for protocol
TCP.
DEBUG
Setting transparent mode for
pLogicalIfName \
DEBUG
Deleting rule, port triggering for protocol
UDP.
DEBUG
Enabling Accept for INPUT
DEBUG
Deleting rule, port triggering for protocol
TCP.
DEBUG
Enabling Accept for FORWARD
DEBUG
Deleting rule, port triggering for protocol
UDP.
DEBUG
Setting Routing mode for
pLogicalIfName \
DEBUG
Enabling rule, port triggering for protocol
TCP.
DEBUG
Enabling DROP for INPUT
DEBUG
Enabling rule, port triggering for protocol
UDP.
DEBUG
Enabling DROP for FORWARD
DEBUG
Enabling rule, port triggering for protocol
TCP.
DEBUG
Disabling NAT based Firewall Rules
DEBUG
Enabling rule, port triggering for protocol
UDP.
DEBUG
Enabling Firewall Rules for URL
Filtering & "
DEBUG
Enabling DNS proxy.
DEBUG
Adding Firewall Rule for RIP Protocol
DEBUG
Restarting DNS proxy.
DEBUG
Restarting Schedule Based Firewall
Rules
DEBUG
checking DNS proxy for Secure zone.
DEBUG
enabling IPS checks between %s and
%s zones.
DEBUG
checking DNS proxy for Public zone.
DEBUG
disabling IPS checks between %s and
%s zones.
DEBUG
Enabling Block traffic from %s zone.
DEBUG
Stopping IPS...%s
DEBUG
Configuring firewall session settings for "
DEBUG
IPS started.
DEBUG
Disabling DMZ
DEBUG
Route already exists
DEBUG
Disabling WAN-DMZ rules .
DEBUG
Route addition failed: Network
Unreachable
DEBUG
Enabling WAN DMZ rules .
DEBUG
Route addition failed: Network is down
DEBUG
Restarting DMZ rule having %s address
with %s address.
DEBUG
Route addition failed
DEBUG
Enabling LAN DHCP relay.
DEBUG
Failed to add rule in iptables
DEBUG
OneToOneNat configured successfully
DEBUG
Failed to delete rule from iptables
DEBUG
OneToOneNat configuration failed
DEBUG
fwLBSpillOverConfigure: Something
going wrong here
ERROR
Deleting scheduled IPv6 rules.
DEBUG
fwLBSpillOverConfigure: unable to get
interfaceName
ERROR
delete from FirewallRules6 where
ScheduleName = '%s'.
DEBUG
fwLBSpillOverConfigure: Could not set
PREROUTING rules
ERROR
Unified Services Router User Manual
181
Update FirewallRules6 where
ScheduleName = '%s' to New "
DEBUG
fwLBSpillOverConfigure: Could not set
POSTROUTING rules
ERROR
Dns proxy Restart failed
DEBUG
fwLBSpillOverConfigure: Something
going wrong Here
ERROR
deleting interface to ifgroup failed
DEBUG
fwL2TPGenericRules.c: unable to open
the database file "
ERROR
adding interface to ifgroup failed
DEBUG
fwL2TPGenericRules.c: inet_aton failed
ERROR
deleting interface pVirtIface %s from
ifgroup %d"
DEBUG
fwPPTPGenericRules.c: unable to
open the database file "
ERROR
adding interface pVirtIface %s to ifgroup
%d failed
DEBUG
fwPPTPGenericRules.c: inet_aton
failed
ERROR
Deleting IP address %s.
DEBUG
DNS proxy firewall rule add failed for
%s
ERROR
Adding new IP address %s.
DEBUG
deleting interface %s from ifgroup %d
failed
ERROR
Updating old IP address %s to new IP
address %s.
DEBUG
adding interface %s to ifgroup %d
failed
ERROR
Restarting Firewall For %s Address
Update from %s:%s
DEBUG
nimfBridgeTblHandler: unable to get
interfaceName
ERROR
Disabling Firewall Rule for MSS packet
marking
DEBUG
nimfBridgeTblHandler: \
ERROR
Enabling Firewall Rule for MSS packet
marking
DEBUG
nimfBridgeTblHandler: unable to get \
ERROR
Enabling packet marking rule for %s
IDLE timer
DEBUG
Failed to %s traffic from %s to %s to
IPS.
ERROR
Deleted firewall rule %s for service %s
with action %s
DEBUG
Failed to %s traffic from %s to %s to
IPS.
ERROR
%s firewall rule %s for service %s with
action %s
DEBUG
failed to start IPS service.
ERROR
Added firewall rule %s for service %s
with action %s
DEBUG
Timeout in waiting for IPS service to
start.
ERROR
Deleting inbound(WAN-LAN) firewall
rule.
DEBUG
Usage:%s <DBFile> <opType>
<tblName> <rowId> "
ERROR
Deleting inbound(WAN-DMZ) firewall
rule.
DEBUG
xlr8NatConfig: illegal invocation of (%s)
ERROR
RIPng disabled.
DEBUG
Illegal invocation of [%s]
ERROR
RIPng enabled.
DEBUG
xlr8NatMgmtTblHandler: failed query:
%s
ERROR
Disable IPv6 firewall rule.
DEBUG
Could not open file: %s
ERROR
Enable IPv6 firewall rule.
DEBUG
Rip Error Command Too Long
ERROR
Deleting IGMP proxy rule.
DEBUG
No authentication for Ripv1
ERROR
Enable IGMP proxy rule.
DEBUG
Invalid Rip Direction
ERROR
Restarting IGMP rule.
DEBUG
Invalid Rip Version
ERROR
Traffic meter enabled with no limit type.
DEBUG
Invalid Password for 1st Key
ERROR
Traffic meter enabled for only download.
DEBUG
Invalid Time for 1st Key
ERROR
Traffic meter enabled for both directions.
DEBUG
Invalid Password for 2nd Key
ERROR
Deleted firewall rule %s for service %s
with action %s
DEBUG
Invalid Time for 2nd Key
ERROR
%s firewall rule %s for service %s with
action %s
DEBUG
Invalid First KeyId
ERROR
Added firewall rule %s for service %s
with action %s
DEBUG
Invalid Second KeyId
ERROR
Enabling Inter VLAN routing.
DEBUG
Invalid Authentication Type
ERROR
Updating inter VLAN routing status.
DEBUG
ripDisable failed
ERROR
Deleting inter VLAN routing.
DEBUG
ripEnable failed
ERROR
Unified Services Router User Manual
182
Facility: Local0 (Wireless)
Log Message
Severity
Log Message
Severity
(node=%s) setting %s to val = %d
sqlite3QueryResGet failed
ERROR
Custom wireless event: '%s'
sqlite3QueryResGet failed
ERROR
Wireless event: cmd=0x%x len=%d
VAP(%s) set beacon interval failed
ERROR
New Rogue AP
(%02x:%02x:%02x:%02x:%02x:%02x)
detected
VAP(%s) set DTIM interval failed
ERROR
WPS session in progress, ignoring
enrolle assoc request
VAP(%s) set RTS Threshold failed
ERROR
ran query %s
VAP(%s) set Fragmentation Threshold
failed
ERROR
DBUpdate event: Table: %s opCode:%d
rowId:%d
VAP(%s) set Protection Mode failed
ERROR
%sing VAPs using profile %s
VAP(%s) set Tx Power failed
ERROR
%sing VAP %s
WDS Profile %s not found
ERROR
ran query %s
Failed to initalize WPS on %s
ERROR
%sing VAP instance %s
failed to get profile %s
ERROR
VAP(%s) set Short Preamble failed
could not initialize MGMT framework
ERROR
VAP(%s) set Short Retry failed
could not initialize MGMT framework
ERROR
VAP(%s) set Long Retry failed
dot11VapBssidUpdt SQL error: %s
ERROR
Decrypting context with key %s
sqlite3QueryResGet failed.Query:%s
ERROR
Unknown IAPP command %d received.
KDOT11_GET_PARAM(IEEE80211_I
OC_CHANNEL) failed
ERROR
unexpected reply from %d cmd=%d !
Failed to get the channel setting for %s
ERROR
unexpected reply from %d cmd=%d !
sqlite3QueryResGet failed.Query:%s
ERROR
Recvied DOT11_EAPOL_KEYMSG
sqlite3QueryResGet failed.Query:%s
ERROR
shutting down AP:%s
profile %s not found
ERROR
APCtx Found
sqlite3QueryResGet failed.Query:%s
ERROR
APCtx Not-Found
Interface name and policy must be
specified
ERROR
node not found *:*:*:%x:%x:%x
Interface name and policy must be
specified
ERROR
error installing unicast key for %s
invalid ACL type %d
ERROR
cmd =%d i_type =%d i_val=%d
interface name not specified
ERROR
join event for new node %s
interface name not specified
ERROR
wpa/rsn IE id %d/%d not supported
Invalid interface - %s specified
ERROR
wpa IE id %d not supported
buffer length not specified
ERROR
leave event for node %s
Invalid length(%d) specified
ERROR
NodeFree request for node : %s
failed created iappdLock
ERROR
installing key to index %d
failed to create cipher contexts.
ERROR
iReq.i_val : %d
unable to register to UMI
ERROR
pIfName : %s
iappSockInit() failed
ERROR
iReq.i_val : %d
iappInit got error, unregistering it with
UMI
ERROR
setting mode: %d
umiIoctl(UMI_COMP_UDOT11,%d,%d
) failed
ERROR
Global counter wrapped, re-generating...
umiIoctl(UMI_COMP_KDOT11,%d,%d
) failed
ERROR
Unified Services Router User Manual
183
Got
PNAC_EVENT_PREAUTH_SUCCESS
event for : %s
UDP failed, received Length is %d
ERROR
event for non-existent node %s
umiIoctl(UMI_COMP_KDOT11,
ERROR
PNAC_EVENT_EAPOL_START event
received
umiIoctl(UMI_COMP_UDOT11,%d,%d
) \
ERROR
PNAC_EVENT_EAPOL_LOGOFF event
received
umiIoctl(UMI_COMP_KDOT11,%d,%d
) \
ERROR
PNAC_EVENT_REAUTH event received
No IAPP Node found for req id %d
ERROR
PNAC_EVENT_AUTH_SUCCESS event
received
umiIoctl(UMI_COMP_UDOT11,%d,%d
) \
ERROR
PNAC_EVENT_PORT_STATUS_CHAN
GED event received
umiIoctl(UMI_COMP_KDOT11,%d,%d
) \
ERROR
unsupported event %d from PNAC
umiIoctl(UMI_COMP_UDOT11,%d,%d
) failed
ERROR
event for non-existent node %s. Create
new node.
UDP socket is not created
ERROR
Add new node to DOT11 Node list
UDP send failed
ERROR
Update dot11STA database
IAPP: socket (SOCK_STREAM) failed.
ERROR
Add PMKSA to the list
IAPP: TCP connect failed to %s.
ERROR
eapolRecvAuthKeyMsg: received key
message
cmd %d not supported.sender=%d
ERROR
node not found
umiIoctl(UMI_COMP_KDOT11,%d,%d
) failed
ERROR
eapolRecvKeyMsg: replay counter not
incremented
IAPP-CACHE-NOTIFY-REQUEST
send to
ERROR
eapolRecvKeyMsg: replay counter is not
same
./src/dot11/iapp/iappLib.c:1314:
ADP_ERROR (
ERROR
processing pairwise key message 2
BSSID value passed is NULL
ERROR
RSN IE matching: OK
reserved requestId is passed
ERROR
processing pairwise key message 4
interface name is NULL
ERROR
processing group key message 2
IP address value passed is NULL
ERROR
processing key request message from
client
opening receive UDP socket failed
ERROR
WPA version %2x %2x not supported
enabling broadcast for UDP socket
failed
ERROR
(%s) group cipher %2x doesn't match
opening receive TCP socket for new
AP failed
ERROR
(%s)Pairwise cipher %s not supported
./src/dot11/iapp/iappLib.c:1784:
ADP_ERROR(
ERROR
(%s) authentication method %d not
supported
./src/dot11/iapp/iappLib.c:1794:
ADP_ERROR(
ERROR
%s:Auth method=%s pairwise cipher=%s
IE size=%d
./src/dot11/iapp/iappLib.c:1803:
ADP_ERROR(
ERROR
WPA version %2x %2x not supported
failed created dot11dLock.
ERROR
Unable to obtain IE of type %d
failed initialize profile library.
ERROR
PTK state changed from %s to %s
failed to create cipher contexts.
ERROR
using PMKSA from cache
unable to register to UMI
ERROR
PTK GK state changed from %s to %s
could not create MIB tree
ERROR
GK state changed from %s to %s
unable to register to PNAC
ERROR
Sending PTK Msg1
Max registration attempts by DOT11 to
PNAC exceeded
ERROR
Sending PTK Msg3
Creation of EAP WPS Profile Failed
ERROR
Sending GTK Msg1
umiIoctl(UMI_COMP_IAPP,%d ) failed
ERROR
Unified Services Router User Manual
184
sending EAPOL pdu to PNAC...
DOT11_RX_EAPOL_KEYMSG:
unknown ifname %s
ERROR
creating pnac authenticator with values
%d %d - %s
cmd %d not supported.sender=%d
ERROR
Profile %s does not exist
inteface name passed is NULL
ERROR
IAPP initialized.
BSSID passed is NULL
ERROR
Encrypting context key=%s for
inteface name passed is NULL
ERROR
could not find access point context for
%s
unable to allocate memory for
DOT11_CTX
ERROR
join event for existing node %s
unable to install wme mapping on %s
ERROR
failed to send
PNAC_FORCE_AUTHORIZED "
unable to get %s mac address
ERROR
failed to send PNAC_AUTHORIZED "
Failed to set %s SSID
ERROR
failed to send
PNAC_VAR_KEY_AVAILABLE (TRUE) "
Failed to set SSID broadcast status
ERROR
failed to send PNAC_VAR_KEY_TX_EN
(TRUE) "
Failed to set PreAuth mode
ERROR
failed to send PNAC_VAR_KEY_TX_EN
(FALSE) "
unable to install key
ERROR
failed to send
PNAC_FORCE_AUTHORIZED "
KDOT11_SET_PARAM:IEEE80211_I
OC_AUTHMODE failed
ERROR
failed to send PNAC_AUTHORIZED "
KDOT11_SET_PARAM:IEEE80211_I
OC_PRIVACY failed
ERROR
mic verification: OK
wpaInit failed
ERROR
pnacIfConfig: Invalid supplicant"
dot11InstallProfile: unable to get
interface index
ERROR
Failed to process user request
adpHmacInit(%s) failed
ERROR
Failed to process user request - %s(%d)
interface %s not found
ERROR
pnacIfConfigUmiIoctl: umiIoctl failed
AP not found on %s
ERROR
pnacIfConfigUmiIoctl: usrPnac returned
%d
keyLen > PNAC_KEY_MAX_SIZE
ERROR
pnacIfConfigUmiIoctl: usrPnac returned
%d
Invalid profile name passed
ERROR
pnacIfConfigUmiIoctl: usrPnac returned
%d
Creation of WPS EAP Profile failed
ERROR
pnacKernNotifier: invalid PAE
configuration "
unsupported command %d
ERROR
From pnacEapDemoAuthRecv:
unsupported response "
device %s not found
ERROR
From pnacEapDemoAuthRecv: invalid
codes received
unsupported command %d
ERROR
From pnacRadXlateDemoRecv: received
unknown "
dot11NodeAlloc failed
ERROR
From pnacRadXlateDemoRecv: invalid
codes received
Getting WPA IE failed for %s
ERROR
Error from pnacRadXlateDemoRecv:
malloc failed
Getting WPS IE failed for %s
ERROR
From pnacRadXlateRadPktHandle:
received a non-supported"
Failed initialize authenticator for node
%s
ERROR
Only md5 authentication scheme
currently supported. "
Failed to get the system up time while
adding node %s
ERROR
Message from authenticator:
error creating PNAC port for node %s
ERROR
from pnacPDUXmit: bufsize = %d,
pktType = %d,"
dot11NodeAlloc failed
ERROR
pnacPDUXmit: sending eap packet. code
= %d, "
Invalid arguments.
ERROR
Unified Services Router User Manual
185
pnacRecvRtn: no corresponding pnac
port pae found
umiIoctl(UMI_COMP_IAPP,%d) failed
ERROR
sending unicast key
Invalid IE.
ERROR
sending broadcast key
umiIoctl(UMI_COMP_KDOT11_VAP,
%d ) failed
ERROR
from pnacAuthPAEDisconnected: calling
pnacTxCannedFail
umiIoctl(UMI_COMP_KDOT11,%d
,%d) failed
ERROR
from pnacAuthPAEForceUnauth: calling
pnacTxCannedFail
KDOT11_SET_PARAM:IEEE80211_I
OC_WME_CWMIN failed
ERROR
state changed from %s to %s
KDOT11_SET_PARAM:IEEE80211_I
OC_WME_CWMAX failed
ERROR
PNAC user comp id not set. dropping
event %d
KDOT11_SET_PARAM:IEEE80211_I
OC_WME_AIFS failed
ERROR
sending event %d to %d
KDOT11_SET_PARAM:80211_IOC_
WME_TXOPLIMIT failed
ERROR
requesting keys informantion from %d
KDOT11_SET_PARAM:IEEE80211_I
OC_WME_ACM failed
ERROR
pnacUmiPortPaeParamSet: error in
getting port pae
KDOT11_SET_PARAM:IEEE80211_I
OC_WME failed
ERROR
pnacUmiPortPaeParamSet: invalid
param - %d
invalid group cipher %d
ERROR
pnacRecvASInfoMessage: Skey of length
%d set
KDOT11_SET_PARAM:IEEE80211_I
OC_MCASTCIPHER failed
ERROR
pnacRecvASInfoMessage: reAuthPeriod
set to: %d
KDOT11_SET_PARAM:IEEE80211_I
OC_MCASTKEYLEN failed
ERROR
pnacRecvASInfoMessage: suppTimeout
set to: %d
KDOT11_SET_PARAM:IEEE80211_I
OC_UCASTCIPHERS failed
ERROR
PORT SUCCESSFULLY DESTROYED
KDOT11_SET_PARAM:IEEE80211_I
OC_KEYMGTALGS failed
ERROR
creating physical port for %s
KDOT11_SET_PARAM:IEEE80211_I
OC_WPA failed
ERROR
pnacAuthInit: using defualt
pnacAuthParams
unknow cipher type = %d
ERROR
pnacSuppInit: using defualt
pnacSuppParams
umiIoctl(UMI_COMP_IAPP,%d) failed
ERROR
Error from
pnacCombinedStMachTriggerFunc: "
invalid media value=%d
ERROR
Error from
pnacCombinedStMachTriggerFunc: "
invalid mediaOpt value=%d
ERROR
Error from
pnacCombinedStMachTriggerFunc: "
invalid mode value=%d
ERROR
Error from
pnacCombinedStMachTriggerFunc: "
dot11PnacIfCreate failed
ERROR
Error from
pnacCombinedStMachTriggerFunc: "
wpaPRF failed
ERROR
Error from
pnacCombinedStMachTriggerFunc: "
Error generating global key counter
ERROR
Error from
pnacCombinedStMachTriggerFunc: "
wpaCalcMic: unsupported key
descriptor version
ERROR
Error from
pnacCombinedStMachTriggerFunc: "
integrity failed. need to stop all stations
"
ERROR
Error from
pnacCombinedStMachTriggerFunc: "
couldn't find AP context for %s
interface
ERROR
received a pdu on %s
dot11Malloc failed
ERROR
pnacRecvMapi: protoType: %04x
pPhyPort->authToASSendRtn:%p
dot11Malloc failed
ERROR
port not found
eapolRecvKeyMsg: unknown
descType =%d
ERROR
Unified Services Router User Manual
186
from pnacRecvMapi: pkt body len = %d,
pktType = %d
eapolRecvKeyMsg: invalid descriptor
version
ERROR
from pnacPDUProcess: received
PNAC_EAP_PACKET
eapolRecvKeyMsg: incorrect
descriptor version
ERROR
from pnacPDUProcess: currentId = %d
eapolRecvKeyMsg: Ack must not be
set
ERROR
from pnacPDUProcess: code = %d,
identifier = %d, "
eapolRecvKeyMsg: MIC bit must be
set
ERROR
from pnacPDUProcess: setting rxResp
true
wpaAuthRecvPTKMsg2: unexpected
packet received
ERROR
from pnacPDUProcess: code = %d,
identifier = %d, "
wpaAuthRecvPTKMsg2: mic check
failed
ERROR
from pnacPDUProcess: received "
wpaAuthRecvPTKMsg2: rsn ie
mismatch
ERROR
from pnacPDUProcess: received "
wpaAuthRecvPTKMsg4: unexpected
packet received
ERROR
from pnacPDUProcess: received
PNAC_EAPOL_KEY_PACKET
wpaAuthRecvPTKMsg4:
keyDataLength not zero
ERROR
doing pnacTxCannedFail
wpaAuthRecvPTKMsg4: mic check
failed
ERROR
doing pnacTxCannedSuccess
wpaAuthRecvGTKMsg2: unexpected
packet received
ERROR
doing pnacTxReqId
secureBit not set in GTK Msg2
ERROR
doing pnacTxReq
wpaAuthRecvGTKMsg2:
keyDataLength not zero
ERROR
doing pnacTxStart
wpaAuthRecvGTKMsg2: mic check
failed
ERROR
doing pnacTxLogoff
wpaAuthRecvKeyReq: unexpected
packet received
ERROR
doing pnacTxRspId: 1st cond
wpaAuthRecvKeyReq: keyDataLength
not zero
ERROR
doing pnacTxRspId: entering 2nd cond
wpaAuthRecvKeyReq: mic check
failed
ERROR
from pnacTxRspId: code = %d, identifier
= %d, length = %d, "
invalid OUI %x %x %x
ERROR
doing pnacTxRspId: 2nd cond
(%s) invalid OUI %x %x %x
ERROR
doing pnacTxRspAuth: 1st cond
[%s:%d] Cipher in WPA IE : %x
ERROR
doing pnacTxRspAuth: 2nd cond
(%s) invalid OUI %x %x %x
ERROR
message for unknown port PAE
short WPA IE (length = %d) received
ERROR
from pnacACToSuppRecvRtn: calling
pnacEapPktRecord
PTK state machine in unknown state.
ERROR
from pnacEapPktRecord: code = %d,
identifier = %d, "
dot11InstallKeys failed
ERROR
from pnacEapPktRecord: received
success pkt
group state machine entered into
WPA_AUTH_GTK_INIT
ERROR
from pnacEapPktRecord: received failure
pkt
dot11Malloc failed
ERROR
from pnacEapPktRecord: received
request pkt
dot11Malloc failed
ERROR
unknown EAP-code %d
dot11Malloc failed
ERROR
Authenticator[%d]:
aesWrap failed
ERROR
Auth PAE state = %s
unknown key descriptor version %d
ERROR
Auth Reauth state = %s
dot11Malloc failed
ERROR
Back auth state = %s
could not initialize AES128ECB
ERROR
Supplicant[%d]:
could not initialize AES-128-ECB
ERROR
Supp Pae state = %s
MD5 initialization failed
ERROR
Unified Services Router User Manual
187
from pnacBackAuthFail: calling
pnacTxCannedFail
RC4 framework initialization failed
ERROR
%s returned ERROR
PNAC framework initialization failed
ERROR
pnacUmiIoctlHandler: cmd: %s(%d)
ERROR: option value not specified
ERROR
%s not configured for 802.1x
ERROR: -u can be used only with -s
ERROR
could not process PDU received from the
wire
ERROR: user-name not specified
ERROR
pnacPDUForward: failed to foward the
received PDU
failed to enable debug
ERROR
Creating PHY port with AUTH backend :
%s SendRtn: %p RecvRtn:%p
[%s]: failed to convert string to MAC "
ERROR
pnacUmiAuthConfig: %s not configured
for 802.1x
failed to initialize UMI
ERROR
pnacSuppRegisterUserInfo: not a valid
AC
pnacPhyPortParamSet:invalid
arguments
ERROR
pnacIfConfig: autoAuth Enabled
pnacPhyPortParamSet:Failed to
create socket
ERROR
pnacSendRtn: no pnac port pae found for
"
Error from pnacPhyPortParamSet:%s-
device invalid
ERROR
sending portStatus: %s[%d] to dot11
Error from pnacPhyPortParamSet:%s-
Getting MAC address "
ERROR
pnacRecvASInfoMessage: Rkey of
length %d set
pnacPhyPortParamSet:Failed to add
802.1X multicast "
ERROR
ASSendRtn: %p ASToAuthRecv: %p
pnacIsInterfaceUp: failed to create a
raw socket
ERROR
adpRand failed:unable to generate
random unicast key
pnacIsInterfaceUp: failed to get
interface flags
ERROR
using group key as unicast key
failed to allocate buffer
ERROR
Integrity check failed more than once in
last 60 secs.
UMI initialization failed
ERROR
MIC failed twice in last 60 secs, taking
countermeasures
UMI initialization failed
ERROR
Failed to set dot11 port status
Error from pnacEapDemoAuthLibInit:
malloc failed
ERROR
PTK state machine in NO_STATE.
Error from pnacEapDemoAuthRecv:
received null EAP pkt
ERROR
PTK state machine in NO_STATE!!
Error from pnacEapDemoAuthRecv:
send "
ERROR
PMKSA refcount not 1
Error from pnacRadXlateASAdd:
cannot open socket
ERROR
IV verification failednknown subtype>
Error from pnacRadXlateDemoRecv:
received null EAP pkt
ERROR
pnacIfConfig: overwriting previous
interface "
From pnacRadXlateDemoRecv: send "
ERROR
pnacIfConfig: overwriting previous "
Error from pnacRadXlateDemoRecv:
radius "
ERROR
pnacIfConfig: overwriting previous
username"
Error from pnacRadXlateDemoRecv:
radius "
ERROR
pnacIfConfig: overwriting previous
password"
Error from
pnacRadXlateRadIdRespSend: send
to failed
ERROR
%s: Failed to set port status
Error from
pnacRadXlateRadNonIdRespSend:
send to failed
ERROR
%s: Failed to notify event to dot11
Error from
pnacRadXlateRadRecvProc: recvfrom
failed
ERROR
pnacLibDeinit: Failed to destroy the
From
ERROR
Unified Services Router User Manual
188
phyPort:%s
pnacRadXlateRadPktIntegrityChk: no
corresponding "
pnacPortPaeDeconfig:kpnacPortPaeDec
onfig failed
Error from
pnacRadXlateRadPktIntegrityChk: no
message "
ERROR
pnacPortPaeDeconfig:kpnacPortPaeDec
onfig failed
Error from
pnacRadXlateRadPktIntegrityChk: "
ERROR
pnacBackAuthSuccess: failed to notify
the destination "
From
pnacRadXlateRadChalPktHandle: no
encapsulated eap "
ERROR
could not initialize MGMT framework
Error from
pnacRadXlateRadChalPktHandle:
malloc for eap "
ERROR
umiInit failed
Error from
pnacEapDemoSuppUserInfoRegister:
invalid "
ERROR
iappInit failed
Error from pnacEapDemoSuppRecv:
received null EAP pkt
ERROR
could not initialize IAPP MGMT.
Error from pnacEapDemoSuppRecv:
send ptr to pnac supplicant"
ERROR
dot11Malloc failed
From pnacEapDemoSuppRecv: user
info not entered yet
ERROR
buffer length not specified
Error from pnacEapDemoSuppRecv:
couldn't "
ERROR
Invalid length(%d) specified
MDString: adpDigestInit for md5 failed
ERROR
Failed to get information about
authorized AP list.
pnacUmiInit: UMI initialization failed
ERROR
Recd IE data for non-existent AP %s
could not start PNAC task
ERROR
Recd IE data for wrong AP %s
invalid aruments
ERROR
Received Invalid IE data from WSC
pnacIfNameToIndex failed
ERROR
Recd IE data for non-existent AP %s
pnacPhyPortParamSet: device invalid
%s%d
ERROR
Recd WSC Start command without
interface name
pnacPhyPortParamSet: EIOCGADDR
ioctl failed
ERROR
Recd WSC start for non-existent AP %s
pnacPhyPortParamSet: multicast addr
add ioctl failed
ERROR
Recd WSC start for wrong AP %s
pnacPhyPortParamUnset: multicast
addr del ioctl failed
ERROR
Unable to send
WSC_WLAN_CMD_PORT to WSC
pnacPDUXmit: Invalid arguments
ERROR
Failed to get the ap context for %s
pnacPDUXmit: failed to get M_BLK_ID
ERROR
WPS can only be applied to WPA/WPA2
security profiles
from pnacIsInterfaceUp: device %s%d
invalid
ERROR
wpsEnable: running wsccmd failed
pnacRecvRtn: dropping received
packet as port is"
ERROR
Failed to get the ap context for %s
pnacSendRtn: Invalid arguments
ERROR
WPS conf. under non WPA/WPA2
security setting
pnacSendRtn: no physical port
corresponding to"
ERROR
Failed to reset the Beacon Frame IE in
the driver
pnacSendRtn: dropping packet as
port"
ERROR
Failed to reset the Beacon Frame IE in
the driver
pnacAuthBuildRC4KeyDesc:
adpEncryptInit(RC4) failed
ERROR
WPS method cannot be NULL
pnacAuthBuildRC4KeyDesc:
adpCipherContextCtrl"
ERROR
PIN value length should be a multiple of
4 !!
pnacDot11UserSet: incorrect buffer
length
ERROR
Failed to initiate PIN based association,
PIN = %s
PNAC user component id not set.
ERROR
Unified Services Router User Manual
189
Failed to initiate PBC based enrolle
association
pnacKeyInfoGet:failed to allocate
buffer
ERROR
Invalid association mode. (Allowed
modes : PIN/PBC)
PNAC user comp id not set. dropping
EAPOL key pkt
ERROR
wpsEnable: running wsccmd failed
pnacUmiPortPaeParamSet: invalid
buffer received
ERROR
Failed to send QUIT command to WSC
from DOT11
Error from pnacRecvASInfoMessage: "
ERROR
Failed to clear off the WPS process
pnacRecvASInfoMessage: "
ERROR
missing profile name
pnacRecvASInfoMessage: Bad info
length
ERROR
A profile exists with the same name
Error from pnacLibInit: malloc failed
ERROR
Error in allocating memory for profile
could not create phy ports lock
ERROR
missing profile name
could not create nodes ports lock
ERROR
missing profile name
port exists for iface - %s
ERROR
Profile name and interface name must be
specified
pnacPhyPortCreate failed
ERROR
Profile %s does not exist
kpnacPhyPortCreate failed
ERROR
Could not set profile %s on the interface
%s
invalid argument
ERROR
missing profile name
pnacAuthConfig: maxAuth limit
reached
ERROR
Profile %s does not exist
pnacAuthConfig: malloc failed
ERROR
Profile %s does not exist
Error from pnacAuthConfig: pAsArg
cannot be NULL
ERROR
SSID should not be longer than %d
Error from pnacAuthConfig: receive
routine hook "
ERROR
Profile %s does not exist
pnacAuthConfig: pnacAuthInit failed
ERROR
Profile %s does not exist
kpnacPortPaeConfig failed
ERROR
Profile %s does not exist
Invalid arguments
ERROR
Profile %s does not exist
Error from pnacSuppConfig: malloc
failed
ERROR
Profile %s does not exist
Error from pnacSuppConfig: receive
routine hook "
ERROR
Profile %s does not exist
Error from pnacSuppConfig:
pnacSuppInit failed
ERROR
SSID not set. SSID is needed to
generate password hash
kpnacPortPaeConfig failed
ERROR
Password string too big
pnacAuthDeconfig failed: pPortPae
NULL
ERROR
dot11Malloc failed
Error from pnacPhyPortDestroy: port
not configured
ERROR
Profile %s does not exist
pnacPhyPortDestroy: Failed to
deconfigure port
ERROR
Hex string should only have %d hex
chars
pnacPhyPortParamUnset FAILED
ERROR
dot11Malloc failed
Error from pnacPhyPortCreate: malloc
failed
ERROR
Profile %s does not exist
Error from pnacPhyPortCreate:
pnacPhyPortParamSet"
ERROR
invalid key index %d. key index should
be 0-3.
error from pnacPhyPortCreate: malloc
failed
ERROR
wepKey length incorrect
Error from pnacAuthInit:
pnacPortTimersInit failed
ERROR
Profile %s does not exist
Error from pnacAuthInit:
pnacAuthPAEInit failed
ERROR
Unified Services Router User Manual
190
Invalid Cipher type %d
Error from pnacAuthInit:
pnacAuthKeyTxInit failed
ERROR
Profile supports WEP stas,Group cipher
must be WEP
Error from pnacAuthInit:
pnacReauthTimerInit failed
ERROR
Profile %s does not exist
Error from pnacAuthInit:
pnacBackAuthInit failed
ERROR
Profile %s does not exist
Error from pnacAuthInit: pnacCtrlDirInit
failed
ERROR
Profile %s does not exist
Error from pnacAuthInit:
pnacKeyRecvInit failed
ERROR
invalid pairwise cipher type %d
Error from pnacSuppInit: malloc failed
ERROR
Cipher %s is already in the list.
Error from pnacSuppInit:
pnacPortTimersInit failed
ERROR
Profile %s does not exist
Error from pnacSuppInit:
pnacKeyRecvInit failed
ERROR
Invalid Cipher type %d
Error from pnacSuppInit:
pnacSuppKeyTxInit failed
ERROR
Cipher %s not found in the list.
Error from pnacSuppInit:
pnacSuppPAEInit failed
ERROR
Profile %s does not exist
Error from pnacRecvRtn: invalid
arguments
ERROR
Profile %s does not exist
Error from pnacRecvMapi:
unsupported PDU received
ERROR
Auth method %s is already in the list
suppToACSendRtn returned not OK!
ERROR
Profile %s does not exist
Error from pnacBasicPktCreate: malloc
failed
ERROR
Auth method %s not found in the list.
Error from pnacEAPPktCreate: basic
pkt create failed
ERROR
Profile %s does not exist
Error from pnacTxCannedFail: eap pkt
create failed
ERROR
Profile %s does not exist
Error from pnacTxCannedSuccess:
eap pkt create failed
ERROR
Profile %s does not exist
Error from pnacTxReqId: eap pkt
create failed
ERROR
invalid type value %d. supported values
are 1,2,3,4
Error from pnacTxReq: eap pkt create
failed
ERROR
Profile %s does not exist
Error from pnacSendRespToServer:
malloc failed
ERROR
invalid type value %d. supported values
are 1,2,3,4
Error from pnacSendRespToServer:
no AS configured
ERROR
Profile %s does not exist
Error from pnacTxStart: basic pkt
create failed
ERROR
invalid type value %d. supported values
are 1,2,3,4
Error from pnacTxStart: basic pkt
create failed
ERROR
Profile %s does not exist
Error from pnacTxRspId: eap pkt
create failed
ERROR
invalid type value %d. supported values
are 1,2,3,4
Error from pnacTxRspAuth: eap pkt
create failed
ERROR
Profile %s does not exist
Error from pnacEapPktRecord: EAP
packet too"
ERROR
invalid type value %d. supported values
are 1,2,3,4
Error from pnacEapPktRecord: "
ERROR
Profile %s does not exist
from pnacBackAuthTimeout: calling
pnacTxCannedFail
ERROR
ERROR: incomplete DB update
information.
hmac_md5: adpHmacContextCreate
failed
ERROR
old values result does not contain 2 rows
hmac_md5:adpHmacInit failed
ERROR
sqlite3QueryResGet failed
pnacUmiIoctlHandler: invalid cmd: %d
ERROR
Unified Services Router User Manual
191
Error in executing DB update handler
pnacEapRadAuthSend: Invalid
arguments
ERROR
sqlite3QueryResGet failed
pnacEapRadAuthSend: failed to
allocate inbuffer
ERROR
ERROR: incomplete DB update
information.
pnacXmit : umiIoctl failed[%d]
ERROR
old values result does not contain 2 rows
pnacPDUForward: Invalid input
ERROR
sqlite3QueryResGet failed
pnacPDUForward: error in getting port
pae information
ERROR
Error in executing DB update handler
pnacPDUForward: error allocating
memory
ERROR
sqlite3QueryResGet failed.Query:%s
pnacUmiIfMacAddrChange: %s not
configured for 802.1x
ERROR
sqlite3QueryResGet failed.Query:%s
pnacUmiIfMacAddrChange: could not
process PDU received"
ERROR
sqlite3QueryResGet failed.Query:%s
pnacUmiPhyPortConfig: Invalid config
data
ERROR
sqlite3QueryResGet failed.Query:%s
pnacUmiPhyPortConfig: Invalid
backend name specified
ERROR
startStopVap failed to stop %s
pnacUmiPhyPortConfig: could not
create PNAC physical"
ERROR
Invalid SQLITE operation code - %d
pnacUmiAuthConfig: Invalid config
data
ERROR
./src/dot11/mgmt/dot11Mgmt.c:1177:
ADP_ERROR (
pnacUmiAuthConfig: Invalid backend
name specified
ERROR
only delete event expected on
dot11RogueAP.
unable to create new EAP context.
ERROR
sqlite3QueryResGet failed
unable to apply %s profile on the EAP
context.
ERROR
unhandled database operation %d
pnacUmiAuthConfig: could not
configure PNAC PAE "
ERROR
sqlite3QueryResGet failed
pnacUmiSuppConfig: Invalid config
data
ERROR
failed to configure WPS on %s
pnacUmiSuppConfig: Invalid backend
name specified
ERROR
sqlite3QueryResGet failed
pnacUmiSuppConfig: %s not
configured for 802.1x
ERROR
sqlite3QueryResGet failed
pnacUmiSuppConfig: could not PNAC
port Access"
ERROR
sqlite3QueryResGet failed
pnacUmiSuppConfig: Failed to register
user information
ERROR
sqlite3QueryResGet failed
pnacPortByMacDeconfig: port not
found
ERROR
sqlite3QueryResGet failed
pnacPortByMacDeconfig: port not
found
ERROR
no VAP rows returned. expected one
pnacUmiIfDown: Invalid config data
ERROR
multiple VAP rows returned. expected
one
pnacUmiIfDown: Invalid config data
ERROR
sqlite3QueryResGet failed
Error from pnacPortDeconfig: port not
configured
ERROR
invalid query result. ncols=%d nrows=%d
pnacUmiIfDown: could not de-
configure port
ERROR
%s:VAP(%s) create failed
pnacUmiPhyPortDestroy: Invalid
config data
ERROR
sqlite3QueryResGet failed
pnacUmiPhyPortDestroy: Invalid
config data
ERROR
invalid query result. ncols=%d nrows=%d
pnacUmiPhyPortDestroy: Failed to
destroy the port
ERROR
Unified Services Router User Manual
192
Invalid config data
ERROR
Facility: Kernel
Log Message
Severity
Log Message
Severity
DNAT: multiple ranges no longer
supported
DEBUG
%s: %s%s:%d -> %s:%d %s,
DEBUG
DNAT: Target size %u wrong for %u
ranges,
DEBUG
%s: %s%s:%d %s,
DEBUG
DNAT: wrong table %s, tablename
DEBUG
%s: Failed to add WDS MAC: %s, dev-
>name,
DEBUG
DNAT: hook mask 0x%x bad,
hook_mask
DEBUG
%s: Device already has WDS mac
address attached,
DEBUG
%s%d: resetting MPPC/MPPE
compressor,
DEBUG
%s: Added WDS MAC: %s, dev-
>name,
DEBUG
%s%d: wrong offset value: %d,
DEBUG
%s: WDS MAC address %s is not
known by this interface,
DEBUG
%s%d: wrong length of match value:
%d,
DEBUG
[madwifi] %s() : Not enough space.,
__FUNCTION__
DEBUG
%s%d: too big offset value: %d,
DEBUG
Returning to chan %d, ieeeChan
DEBUG
%s%d: cannot decode offset value,
DEBUG
WEP
DEBUG
%s%d: wrong length code: 0x%X,
DEBUG
AES
DEBUG
%s%d: short packet (len=%d),
__FUNCTION__,
DEBUG
AES_CCM
DEBUG
%s%d: bad sequence number: %d,
expected: %d,
DEBUG
CKIP
DEBUG
%s%d: bad sequence number: %d,
expected: %d,
DEBUG
TKIP
DEBUG
PPPIOCDETACH file->f_count=%d,
DEBUG
%s: cannot map channel to mode; freq
%u flags 0x%x,
DEBUG
PPP: outbound frame not passed
DEBUG
%s: %s, vap->iv_dev->name, buf
DEBUG
PPP: VJ decompression error
DEBUG
%s: [%s] %s, vap->iv_dev->name,
DEBUG
PPP: inbound frame not passed
DEBUG
%s: [%s] %s, vap->iv_dev->name,
ether_sprintf(mac), buf
DEBUG
PPP: reconstructed packet
DEBUG
[%s:%s] discard %s frame, %s, vap-
>iv_dev->name,
DEBUG
PPP: no memory for
DEBUG
[%s:%s] discard frame, %s, vap-
>iv_dev->name,
DEBUG
missed pkts %u..%u,
DEBUG
[%s:%s] discard %s information
element, %s,
DEBUG
%s%d: resetting MPPC/MPPE
compressor,
DEBUG
[%s:%s] discard information element,
%s,
DEBUG
%s%d: wrong offset value: %d,
DEBUG
[%s:%s] discard %s frame, %s, vap-
>iv_dev->name,
DEBUG
%s%d: wrong length of match value:
%d,
DEBUG
[%s:%s] discard frame, %s, vap-
>iv_dev->name,
DEBUG
%s%d: too big offset value: %d,
DEBUG
ifmedia_add: null ifm
DEBUG
%s%d: cannot decode offset value,
DEBUG
Adding entry for
DEBUG
%s%d: wrong length code: 0x%X,
DEBUG
ifmedia_set: no match for 0x%x/0x%x,
DEBUG
%s%d: short packet (len=%d),
__FUNCTION__,
DEBUG
ifmedia_set: target
DEBUG
%s%d: bad sequence number: %d,
expected: %d,
DEBUG
ifmedia_set: setting to
DEBUG
Unified Services Router User Manual
193
%s%d: bad sequence number: %d,
expected: %d,
DEBUG
ifmedia_ioctl: no media found for 0x%x,
DEBUG
PPPIOCDETACH file->f_count=%d,
DEBUG
ifmedia_ioctl: switching %s to , dev-
>name
DEBUG
PPP: outbound frame not passed
DEBUG
ifmedia_match: multiple match for
DEBUG
PPP: VJ decompression error
DEBUG
<unknown type>
DEBUG
PPP: inbound frame not passed
DEBUG
desc->ifmt_string
DEBUG
PPP: reconstructed packet
DEBUG
mode %s, desc->ifmt_string
DEBUG
PPP: no memory for
DEBUG
<unknown subtype>
DEBUG
missed pkts %u..%u,
DEBUG
%s, desc->ifmt_string
DEBUG
%s: INC_USE_COUNT, now %d,
__FUNCTION__, mod_use_count \
DEBUG
%s%s, seen_option++ ? , : ,
DEBUG
%s: DEC_USE_COUNT, now %d,
__FUNCTION__, mod_use_count \
DEBUG
%s%s, seen_option++ ? , : ,
DEBUG
PPPOL2TP %s: _fmt,
DEBUG
%s, seen_option ? > :
DEBUG
PPPOL2TP: --> %s, __FUNCTION__)
DEBUG
%s: %s, dev->name, buf
DEBUG
PPPOL2TP: <-- %s, __FUNCTION__)
DEBUG
%s: no memory for sysctl table!,
__func__
DEBUG
%s: recv: , tunnel->name
DEBUG
%s: no memory for VAP name!,
__func__
DEBUG
%s: xmit:, session->name
DEBUG
%s: failed to register sysctls!, vap-
>iv_dev->name
DEBUG
%s: xmit:, session->name
DEBUG
%s: no memory for new proc entry
(%s)!, __func__,
DEBUG
%s: module use_count is %d,
__FUNCTION__, mod_use_count
DEBUG
%s: 0x%p len %u, tag, p, len
DEBUG
PPPOL2TP %s: _fmt,
DEBUG
%03d:, i
DEBUG
PPPOL2TP: --> %s, __FUNCTION__)
DEBUG
%02x, ((u_int8_t *)p)[i]
DEBUG
PPPOL2TP: <-- %s, __FUNCTION__)
DEBUG
first difference at byte %u, i
DEBUG
%s: recv: , tunnel->name
DEBUG
%s: , t->name
DEBUG
%s: xmit:, session->name
DEBUG
FAIL: ieee80211_crypto_newkey failed
DEBUG
%s: xmit:, session->name
DEBUG
FAIL: ieee80211_crypto_setkey failed
DEBUG
PPPOL2TP %s: _fmt,
DEBUG
FAIL: unable to allocate skbuff
DEBUG
PPPOL2TP: --> %s, __FUNCTION__)
DEBUG
FAIL: wep decap failed
DEBUG
PPPOL2TP: <-- %s, __FUNCTION__)
DEBUG
FAIL: decap botch; length mismatch
DEBUG
%s: recv: , tunnel->name
DEBUG
FAIL: decap botch; data does not
compare
DEBUG
%s: xmit:, session->name
DEBUG
FAIL: wep encap failed
DEBUG
%s: xmit:, session->name
DEBUG
FAIL: encap data length mismatch
DEBUG
IRQ 31 is triggered
DEBUG
FAIL: encrypt data does not compare
DEBUG
[%s:%d] , __func__, __LINE__\
DEBUG
PASS
DEBUG
\t[R%s %#0x %#0x 0x%08x%08x],
(status == ERROR ? # : ), page, addr,
(uint32_t)(*pValue >> 32),
(uint32_t)(*pValue & 0xffffffff)
DEBUG
%u of %u 802.11i WEP test vectors
passed, pass, total
DEBUG
\t[W%s %#0x %#0x 0x%08x%08x],
(status == ERROR ? # : ), page, addr,
(uint32_t)(value >> 32), (uint32_t)(value
& 0xffffffff)
DEBUG
%s: 0x%p len %u, tag, p, len
DEBUG
%s: mac_add
%02X:%02X:%02X:%02X:%02X:%02X,
dev->name, addr[0], addr[1], addr[2],
addr[3], addr[4], addr[5]
DEBUG
%03d:, i
DEBUG
Unified Services Router User Manual
194
%s: mac_del
%02X:%02X:%02X:%02X:%02X:%02X,
dev->name, addr[0], addr[1], addr[2],
addr[3], addr[4], addr[5]
DEBUG
%02x, ((u_int8_t *)p)[i]
DEBUG
%s: mac_kick
%02X:%02X:%02X:%02X:%02X:%02X,
dev->name, addr[0], addr[1], addr[2],
addr[3], addr[4], addr[5]
DEBUG
first difference at byte %u, i
DEBUG
%s: mac_undefined
%02X:%02X:%02X:%02X:%02X:%02X,
dev->name, addr[0], addr[1], addr[2],
addr[3], addr[4], addr[5]
DEBUG
%s: , t->name
DEBUG
%s: addr_add
%02X:%02X:%02X:%02X:%02X:%02X,
dev->name, addr[0], addr[1], addr[2],
addr[3], addr[4], addr[5]
DEBUG
FAIL: ieee80211_crypto_newkey failed
DEBUG
%s: addr_del
%02X:%02X:%02X:%02X:%02X:%02X,
dev->name, addr[0], addr[1], addr[2],
addr[3], addr[4], addr[5]
DEBUG
FAIL: ieee80211_crypto_setkey failed
DEBUG
%s: mac_undefined
%02X:%02X:%02X:%02X:%02X:%02X,
dev->name, addr[0], addr[1], addr[2],
addr[3], addr[4], addr[5]
DEBUG
FAIL: unable to allocate skbuff
DEBUG
%s: set_float %d;%d,
DEBUG
FAIL: ccmp encap failed
DEBUG
IRQ 32 is triggered
DEBUG
FAIL: encap data length mismatch
DEBUG
ip_finish_output2: No header cache and
no neighbour!
DEBUG
FAIL: encrypt data does not compare
DEBUG
a guy asks for address mask. Who is it?
DEBUG
FAIL: ccmp decap failed
DEBUG
icmp v4 hw csum failure)
DEBUG
FAIL: decap botch; length mismatch
DEBUG
expire>> %u %d %d %d, expire,
DEBUG
FAIL: decap botch; data does not
compare
DEBUG
expire++ %u %d %d %d, expire,
DEBUG
PASS
DEBUG
rt_cache @%02x: %u.%u.%u.%u, hash,
DEBUG
%u of %u 802.11i AES-CCMP test
vectors passed, pass, total
DEBUG
rt_bind_peer(0) @%p,
NET_CALLER(iph)
DEBUG
%s: 0x%p len %u, tag, p, len
DEBUG
ip_rt_advice: redirect to
DEBUG
%03d:, i
DEBUG
ip_rt_bug: %u.%u.%u.%u ->
%u.%u.%u.%u, %s,
DEBUG
%02x, ((u_int8_t *)p)[i]
DEBUG
udp cork app bug 2)
DEBUG
first difference at byte %u, i
DEBUG
udp cork app bug 3)
DEBUG
ieee80211_crypto_newkey failed
DEBUG
udp v4 hw csum failure.)
DEBUG
ieee80211_crypto_setkey failed
DEBUG
UDP: short packet: From
%u.%u.%u.%u:%u %d/%d to
%u.%u.%u.%u:%u,
DEBUG
unable to allocate skbuff
DEBUG
UDP: bad checksum. From
%d.%d.%d.%d:%d to
%d.%d.%d.%d:%d ulen %d,
DEBUG
tkip enmic failed
DEBUG
%s: lookup policy [list] found=%s,
DEBUG
enmic botch; length mismatch
DEBUG
%s: called: [output START],
__FUNCTION__
DEBUG
enmic botch
DEBUG
%s: flow dst=%s, __FUNCTION__,
XFRMSTRADDR(fl->fl4_dst, family)
DEBUG
tkip encap failed
DEBUG
%s: flow src=%s, __FUNCTION__,
XFRMSTRADDR(fl->fl4_src, family)
DEBUG
encrypt phase1 botch
DEBUG
Unified Services Router User Manual
195
%s: flow dst=%s, __FUNCTION__,
XFRMSTRADDR(fl->fl6_dst, family)
DEBUG
encrypt data length mismatch
DEBUG
%s: flow src=%s, __FUNCTION__,
XFRMSTRADDR(fl->fl6_src, family)
DEBUG
encrypt data does not compare
DEBUG
a guy asks for address mask. Who is it?
DEBUG
tkip decap failed
DEBUG
icmp v4 hw csum failure)
DEBUG
decrypt phase1 botch
DEBUG
expire>> %u %d %d %d, expire,
DEBUG
decrypt data does not compare
DEBUG
expire++ %u %d %d %d, expire,
DEBUG
decap botch; length mismatch
DEBUG
rt_cache @%02x: %u.%u.%u.%u, hash,
DEBUG
decap botch; data does not compare
DEBUG
rt_bind_peer(0) @%p,
NET_CALLER(iph)
DEBUG
tkip demic failed
DEBUG
ip_rt_advice: redirect to
DEBUG
802.11i TKIP test vectors passed
DEBUG
ip_rt_bug: %u.%u.%u.%u ->
%u.%u.%u.%u, %s,
DEBUG
%s, buf
DEBUG
UDP: short packet: From
%u.%u.%u.%u:%u %d/%d to
%u.%u.%u.%u:%u,
DEBUG
Atheros HAL assertion failure: %s: line
%u: %s,
DEBUG
UDP: bad checksum. From
%d.%d.%d.%d:%d to
%d.%d.%d.%d:%d ulen %d,
DEBUG
ath_hal: logging to %s %s,
ath_hal_logfile,
DEBUG
a guy asks for address mask. Who is it?
DEBUG
ath_hal: logging disabled
DEBUG
fib_add_ifaddr: bug: prim == NULL
DEBUG
%s%s, sep, ath_hal_buildopts[i]
DEBUG
fib_del_ifaddr: bug: prim == NULL
DEBUG
ath_pci: No devices found, driver not
installed.
DEBUG
expire>> %u %d %d %d, expire,
DEBUG
_fmt, __VA_ARGS__
DEBUG
expire++ %u %d %d %d, expire,
DEBUG
%s: Warning, using only %u entries in
%u key cache,
DEBUG
rt_cache @%02x: %u.%u.%u.%u, hash,
DEBUG
%s: TX99 support enabled, dev->name
DEBUG
rt_bind_peer(0) @%p,
DEBUG
%s:grppoll Buf allocation failed
,__func__
DEBUG
ip_rt_advice: redirect to
DEBUG
%s: %s: unable to start recv logic,
DEBUG
ip_rt_bug: %u.%u.%u.%u ->
%u.%u.%u.%u, %s,
DEBUG
%s: %s: unable to start recv logic,
DEBUG
%s: lookup policy [list] found=%s,
DEBUG
%s: no skbuff, __func__
DEBUG
%s: called: [output START],
__FUNCTION__
DEBUG
%s: hardware error; resetting, dev-
>name
DEBUG
%s: flow dst=%s, __FUNCTION__,
XFRMSTRADDR(fl->fl4_dst, family)
DEBUG
%s: rx FIFO overrun; resetting, dev-
>name
DEBUG
%s: flow src=%s, __FUNCTION__,
XFRMSTRADDR(fl->fl4_src, family)
DEBUG
%s: unable to reset hardware: '%s'
(HAL status %u)
DEBUG
%s: flow dst=%s, __FUNCTION__,
XFRMSTRADDR(fl->fl6_dst, family)
DEBUG
%s: unable to start recv logic, dev-
>name
DEBUG
%s: flow src=%s, __FUNCTION__,
XFRMSTRADDR(fl->fl6_src, family)
DEBUG
%s: %s: unable to reset hardware: '%s'
(HAL status %u),
DEBUG
a guy asks for address mask. Who is it?
DEBUG
%s: %s: unable to start recv logic,
DEBUG
icmp v4 hw csum failure)
DEBUG
ath_mgtstart: discard, no xmit buf
DEBUG
expire>> %u %d %d %d, expire,
DEBUG
%s: [%02u] %-7s , tag, ix, ciphers[hk-
>kv_type]
DEBUG
expire++ %u %d %d %d, expire,
DEBUG
%02x, hk->kv_val[i]
DEBUG
rt_cache @%02x: %u.%u.%u.%u, hash,
DEBUG
mac %s, ether_sprintf(mac)
DEBUG
rt_bind_peer(0) @%p,
NET_CALLER(iph)
DEBUG
%s , sc->sc_splitmic ? mic : rxmic
DEBUG
ip_rt_advice: redirect to
DEBUG
%02x, hk->kv_mic[i]
DEBUG
Unified Services Router User Manual
196
ip_rt_bug: %u.%u.%u.%u ->
%u.%u.%u.%u, %s,
DEBUG
txmic
DEBUG
UDP: short packet: From
%u.%u.%u.%u:%u %d/%d to
%u.%u.%u.%u:%u,
DEBUG
%02x, hk->kv_txmic[i]
DEBUG
UDP: bad checksum. From
%d.%d.%d.%d:%d to
%d.%d.%d.%d:%d ulen %d,
DEBUG
%s: unable to update h/w beacon
queue parameters,
DEBUG
REJECT: ECHOREPLY no longer
supported.
DEBUG
%s: stuck beacon; resetting (bmiss
count %u),
DEBUG
ipt_rpc: only valid for PRE_ROUTING,
FORWARD, POST_ROUTING,
LOCAL_IN and/or LOCAL_OUT targets.
DEBUG
move data from NORMAL to XR
DEBUG
ip_nat_init: can't setup rules.
DEBUG
moved %d buffers from NORMAL to
XR, index
DEBUG
ip_nat_init: can't register in hook.
DEBUG
move buffers from XR to NORMAL
DEBUG
ip_nat_init: can't register out hook.
DEBUG
moved %d buffers from XR to
NORMAL, count
DEBUG
ip_nat_init: can't register adjust in hook.
DEBUG
%s:%d %s, __FILE__, __LINE__,
__func__
DEBUG
ip_nat_init: can't register adjust out
hook.
DEBUG
%s:%d %s, __FILE__, __LINE__,
__func__
DEBUG
ip_nat_init: can't register local out hook.
DEBUG
%s: no buffer (%s), dev->name,
__func__
DEBUG
ip_nat_init: can't register local in hook.
DEBUG
%s: no skbuff (%s), dev->name,
__func__
DEBUG
ipt_hook: happy cracking.
DEBUG
%s: HAL qnum %u out of range, max
%u!,
DEBUG
ip_conntrack: can't register pre-routing
defrag hook.
DEBUG
grppoll_start: grppoll Buf allocation
failed
DEBUG
ip_conntrack: can't register local_out
defrag hook.
DEBUG
%s: HAL qnum %u out of range, max
%u!,
DEBUG
ip_conntrack: can't register pre-routing
hook.
DEBUG
%s: AC %u out of range, max %u!,
DEBUG
ip_conntrack: can't register local out
hook.
DEBUG
%s: unable to update hardware queue
DEBUG
ip_conntrack: can't register local in
helper hook.
DEBUG
%s: bogus frame type 0x%x (%s), dev-
>name,
DEBUG
ip_conntrack: can't register postrouting
helper hook.
DEBUG
ath_stoprecv: rx queue 0x%x, link %p,
DEBUG
ip_conntrack: can't register post-routing
hook.
DEBUG
%s: %s: unable to reset channel %u
(%u MHz)
DEBUG
ip_conntrack: can't register local in
hook.
DEBUG
%s: %s: unable to restart recv logic,
DEBUG
ip_conntrack: can't register to sysctl.
DEBUG
%s: unable to allocate channel table,
dev->name
DEBUG
ip_conntrack_rtsp v
IP_NF_RTSP_VERSION loading
DEBUG
%s: unable to allocate channel table,
dev->name
DEBUG
ip_conntrack_rtsp: max_outstanding
must be a positive integer
DEBUG
%s: unable to collect channel list from
HAL;
DEBUG
ip_conntrack_rtsp: setup_timeout must
be a positive integer
DEBUG
R (%p %llx) %08x %08x %08x %08x
%08x %08x %c,
DEBUG
ip_conntrack_rtsp: ERROR registering
port %d, ports[i]
DEBUG
T (%p %llx) %08x %08x %08x %08x
%08x %08x %08x %08x %c,
DEBUG
ip_nat_rtsp v IP_NF_RTSP_VERSION
loading
DEBUG
%s: no memory for sysctl table!,
__func__
DEBUG
%s: Sorry! Cannot find this match
option., __FILE__
DEBUG
%s: no memory for device name
storage!, __func__
DEBUG
Unified Services Router User Manual
197
ipt_time loading
DEBUG
%s: failed to register sysctls!, sc-
>sc_dev->name
DEBUG
ipt_time unloaded
DEBUG
%s: mac %d.%d phy %d.%d, dev-
>name,
DEBUG
ip_conntrack_irc: max_dcc_channels
must be a positive integer
DEBUG
5 GHz radio %d.%d 2 GHz radio
%d.%d,
DEBUG
ip_conntrack_irc: ERROR registering
port %d,
DEBUG
radio %d.%d, ah->ah_analog5GhzRev
>> 4,
DEBUG
ip_nat_h323:
ip_nat_mangle_tcp_packet
DEBUG
radio %d.%d, ah->ah_analog5GhzRev
>> 4,
DEBUG
ip_nat_h323:
ip_nat_mangle_udp_packet
DEBUG
%s: Use hw queue %u for %s traffic,
DEBUG
ip_nat_h323: out of expectations
DEBUG
%s: Use hw queue %u for CAB traffic,
dev->name,
DEBUG
ip_nat_h323: out of RTP ports
DEBUG
%s: Use hw queue %u for beacons,
dev->name,
DEBUG
ip_nat_h323: out of TCP ports
DEBUG
Could not find Board Configuration
Data
DEBUG
ip_nat_q931: out of TCP ports
DEBUG
Could not find Radio Configuration
data
DEBUG
ip_nat_ras: out of TCP ports
DEBUG
ath_ahb: No devices found, driver not
installed.
DEBUG
ip_nat_q931: out of TCP ports
DEBUG
_fmt, __VA_ARGS__
DEBUG
ip_conntrack_core: Frag of proto %u.,
DEBUG
_fmt, __VA_ARGS__
DEBUG
Broadcast packet!
DEBUG
xlr8NatIpFinishOutput: Err.. skb2 ==
NULL !
DEBUG
Should bcast: %u.%u.%u.%u-
>%u.%u.%u.%u (sk=%p, ptype=%u),
DEBUG
xlr8NatSoftCtxEnqueue: Calling
xlr8NatIpFinishOutput () .., status
DEBUG
ip_conntrack version %s (%u buckets,
%d max)
DEBUG
xlr8NatSoftCtxEnqueue:
xlr8NatIpFinishOutput () returned [%d],
status
DEBUG
ERROR registering port %d,
DEBUG
icmpExceptionHandler: Exception!
DEBUG
netfilter PSD loaded - (c) astaro AG
DEBUG
fragExceptionHandler: Exception!
DEBUG
netfilter PSD unloaded - (c) astaro AG
DEBUG
algExceptionHandler: Exception!
DEBUG
%s , SELF
DEBUG
dnsExceptionHandler: Exception!
DEBUG
%s , LAN
DEBUG
IPsecExceptionHandler: Exception!
DEBUG
%s , WAN
DEBUG
ESP Packet Src:%x Dest:%x Sport:%d
dport:%d secure:%d spi:%d isr:%p,
DEBUG
TRUNCATED
DEBUG
xlr8NatConntrackPreHook: We found
the valid context,
DEBUG
SRC=%u.%u.%u.%u
DST=%u.%u.%u.%u ,
DEBUG
xlr8NatConntrackPreHook: Not a
secured packet.
DEBUG
LEN=%u TOS=0x%02X
PREC=0x%02X TTL=%u ID=%u ,
DEBUG
xlr8NatConntrackPreHook: isr=[%p],
pIsr
DEBUG
FRAG:%u , ntohs(ih->frag_off) &
IP_OFFSET
DEBUG
xlr8NatConntrackPreHook:
secure=[%d], secure
DEBUG
TRUNCATED
DEBUG
Context found for ESP %p,pFlowEntry-
>post.pIsr[0]
DEBUG
PROTO=TCP
DEBUG
xlr8NatConntrackPreHook: New
connection.
DEBUG
INCOMPLETE [%u bytes] ,
DEBUG
xlr8NatConntrackPostHook:
postSecure=[%d] postIsr=[%p %p],
DEBUG
SPT=%u DPT=%u ,
DEBUG
proto %d spi %d <-------> proto %d spi
%d,pPktInfo->proto,pPktInfo->spi,
DEBUG
SEQ=%u ACK=%u ,
DEBUG
IPSEC_INF Clock skew detected
DEBUG
Unified Services Router User Manual
198
WINDOW=%u , ntohs(th->window)
DEBUG
IPSEC_ERR [%s:%d]: Max (%d) No of
SA Limit reached,
DEBUG
RES=0x%02x ,
(u8)(ntohl(tcp_flag_word(th) &
TCP_RESERVED_BITS) >> 22)
DEBUG
IPSEC_ERR [%s:%d]: Max (%d) No of
SA Limit reached,
DEBUG
URGP=%u , ntohs(th->urg_ptr)
DEBUG
IPSEC_ERR [%s:%d]: time(secs): %u
DEBUG
TRUNCATED
DEBUG
ERROR: Failed to add entry to IPsec
sa table
DEBUG
%02X, op[i]
DEBUG
ERROR: Failed to add entry to IPsec
sa table
DEBUG
PROTO=UDP
DEBUG
ERROR: Failed to add entry to IPsec
sa table
DEBUG
INCOMPLETE [%u bytes] ,
DEBUG
ERROR: Failed to add entry to IPsec
sa table
DEBUG
SPT=%u DPT=%u LEN=%u ,
DEBUG
ERROR: Failed to add entry to IPsec
sa table
DEBUG
SPT=%u DPT=%u LEN=%u ,
DEBUG
ERROR: Failed to add entry to IPsec
sa table
DEBUG
PROTO=ICMP
DEBUG
unknown oid '%s', varName
DEBUG
INCOMPLETE [%u bytes] ,
DEBUG
could not find oid pointer for '%s',
varName
DEBUG
TYPE=%u CODE=%u , ich->type, ich-
>code
DEBUG
unRegistering IPsecMib .....
DEBUG
INCOMPLETE [%u bytes] ,
DEBUG
ERROR: Failed to add entry to IPsec
sa table
DEBUG
ID=%u SEQ=%u ,
DEBUG
ERROR: Failed to add entry to IPsec
sa table
DEBUG
PARAMETER=%u ,
DEBUG
ERROR: Failed to add entry to IPsec
sa table
DEBUG
GATEWAY=%u.%u.%u.%u ,
DEBUG
ERROR: Failed to add entry to IPsec
sa table
DEBUG
MTU=%u , ntohs(ich->un.frag.mtu)
DEBUG
ERROR: Failed to add entry to IPsec
sa table
DEBUG
PROTO=AH
DEBUG
ERROR: Failed to add entry to IPsec
sa table
DEBUG
INCOMPLETE [%u bytes] ,
DEBUG
unknown oid '%s', varName
DEBUG
SPI=0x%x , ntohl(ah->spi)
DEBUG
could not find oid pointer for '%s',
varName
DEBUG
PROTO=ESP
DEBUG
unRegistering IPsecMib .....
DEBUG
INCOMPLETE [%u bytes] ,
DEBUG
. %u.%u.%u.%u, NIPQUAD(trt-
>rt_dst)
DEBUG
SPI=0x%x , ntohl(eh->spi)
DEBUG
%02x, *p
DEBUG
PROTO=%u , ih->protocol
DEBUG
. %u.%u.%u.%u, NIPQUAD(trt-
>rt_dst)
DEBUG
UID=%u , skb->sk->sk_socket->file-
>f_uid
DEBUG
%02x, *p
DEBUG
<%d>%sIN=%s OUT=%s , loginfo-
>u.log.level,
DEBUG
. %u.%u.%u.%u, NIPQUAD(trt-
>rt_dst)
DEBUG
level_string
DEBUG
%02x, *p
DEBUG
%sIN=%s OUT=%s ,
DEBUG
. %u.%u.%u.%u, NIPQUAD(trt-
>rt_dst)
DEBUG
%s , prefix == NULL ? loginfo->prefix :
prefix
DEBUG
%02x, *p
DEBUG
IN=
DEBUG
unable to register vIPsec kernel comp
to UMI
DEBUG
OUT=
DEBUG
unregistering VIPSECK from UMI ....
DEBUG
PHYSIN=%s , physindev->name
DEBUG
in vIPsecKIoctlHandler cmd - %d, cmd
DEBUG
Unified Services Router User Manual
199
PHYSOUT=%s , physoutdev->name
DEBUG
%s: Error. DST Refcount value less
than 1 (%d),
DEBUG
MAC=
DEBUG
for %s DEVICE refcnt: %d ,pDst-
>dev->name,
DEBUG
%02x%c, *p,
DEBUG
%s: Got Null m:%p *m:%p sa:%p
*sa:%p,__func__,ppBufMgr,
DEBUG
NAT: no longer support implicit source
local NAT
DEBUG
%s Got Deleted SA:%p
state:%d,__func__,pIPsecInfo,pIPsecIn
fo->state
DEBUG
NAT: packet src %u.%u.%u.%u -> dst
%u.%u.%u.%u,
DEBUG
%s: %s: fmt, __FILE__,
__FUNCTION__ , ## args)
INFO
SNAT: multiple ranges no longer
supported
DEBUG
%s: %s: fmt, __FILE__,
__FUNCTION__ , ## args)
INFO
format,##args)
DEBUG
ipt_TIME: format, ## args)
INFO
version
DEBUG
IPT_ACCOUNT_NAME : checkentry()
wrong parameters (not equals existing
table parameters).
INFO
offset_before=%d, offset_after=%d,
correction_pos=%u, x->offset_before, x-
>offset_after, x->correction_pos
DEBUG
IPT_ACCOUNT_NAME : checkentry()
too big netmask.
INFO
ip_ct_h323:
DEBUG
IPT_ACCOUNT_NAME : checkentry()
failed to allocate %zu for new table
%s., sizeof(struct t_ipt_account_table),
info->name
INFO
ip_ct_h323: incomplete TPKT
(fragmented?)
DEBUG
IPT_ACCOUNT_NAME : checkentry()
wrong network/netmask.
INFO
ip_ct_h245: decoding error: %s,
DEBUG
account: Wrong netmask given by
netmask parameter (%i). Valid is 32 to
0., netmask
INFO
ip_ct_h245: packet dropped
DEBUG
IPT_ACCOUNT_NAME : checkentry()
failed to create procfs entry.
INFO
ip_ct_q931: decoding error: %s,
DEBUG
IPT_ACCOUNT_NAME : checkentry()
failed to register match.
INFO
ip_ct_q931: packet dropped
DEBUG
failed to create procfs entry .
INFO
ip_ct_ras: decoding error: %s,
DEBUG
MPPE/MPPC encryption/compression
module registered
INFO
ip_ct_ras: packet dropped
DEBUG
MPPE/MPPC encryption/compression
module unregistered
INFO
ERROR registering port %d,
DEBUG
PPP generic driver version
PPP_VERSION
INFO
ERROR registering port %d,
DEBUG
MPPE/MPPC encryption/compression
module registered
INFO
ipt_connlimit [%d]:
src=%u.%u.%u.%u:%d
dst=%u.%u.%u.%u:%d %s,
DEBUG
MPPE/MPPC encryption/compression
module unregistered
INFO
ipt_connlimit [%d]:
src=%u.%u.%u.%u:%d
dst=%u.%u.%u.%u:%d new,
DEBUG
PPP generic driver version
PPP_VERSION
INFO
ipt_connlimit: Oops: invalid ct state ?
DEBUG
PPPoL2TP kernel driver, %s,
INFO
ipt_connlimit: Hmm, kmalloc failed :-(
DEBUG
PPPoL2TP kernel driver, %s,
INFO
ipt_connlimit: src=%u.%u.%u.%u
mask=%u.%u.%u.%u
DEBUG
PPPoL2TP kernel driver, %s,
INFO
_lvl PPPOL2TP: _fmt, ##args
DEBUG
failed to create procfs entry .
INFO
%02X, ptr[length]
DEBUG
proc dir not created ..
INFO
%02X, ((unsigned char *) m-
DEBUG
Initialzing Product Data modules
INFO
Unified Services Router User Manual
200
>msg_iov[i].iov_base)[j]
%02X, skb->data[i]
DEBUG
De initializing by \
INFO
_lvl PPPOL2TP: _fmt, ##args
DEBUG
kernel UMI module loaded
INFO
%02X, ptr[length]
DEBUG
kernel UMI module unloaded
INFO
%02X, ((unsigned char *) m-
>msg_iov[i].iov_base)[j]
DEBUG
Loading bridge module
INFO
%02X, skb->data[i]
DEBUG
Unloading bridge module
INFO
_lvl PPPOL2TP: _fmt, ##args
DEBUG
unsupported command %d, cmd
INFO
%02X, ptr[length]
DEBUG
Loading ifDev module
INFO
%02X, ((unsigned char *) m-
>msg_iov[i].iov_base)[j]
DEBUG
Unloading ifDev module
INFO
%02X, skb->data[i]
DEBUG
ERROR#%d in alloc_chrdev_region,
result
INFO
KERN_EMERG THE value read is
%d,value*/
DEBUG
ERROR#%d in cdev_add, result
INFO
KERN_EMERG Factory Reset button is
pressed
DEBUG
using bcm switch %s, bcmswitch
INFO
KERN_EMERG Returing error in INTR
registration
DEBUG
privlegedID %d wanporttNo: %d,
privlegedID,wanportNo
INFO
KERN_EMERG Initialzing Factory
defaults modules
DEBUG
Loading mii
INFO
Failed to allocate memory for
pSipListNode
DEBUG
Unloading mii
INFO
SIPALG: Memeory allocation failed for
pSipNodeEntryTbl
DEBUG
%s: Version 0.1
INFO
pkt-err %s, pktInfo.error
DEBUG
%s: driver unloaded, dev_info
INFO
pkt-err %s, pktInfo.error
DEBUG
wlan: %s backend registered, be-
>iab_name
INFO
pkt-err %s, pktInfo.error
DEBUG
wlan: %s backend unregistered,
INFO
%s Len=%d, msg, len
DEBUG
wlan: %s acl policy registered, iac-
>iac_name
INFO
%02x , ((uint8_t *) ptr)[i]
DEBUG
wlan: %s acl policy unregistered, iac-
>iac_name
INFO
End
DEBUG
%s, tmpbuf
INFO
CVM_MOD_EXP_BASE MISMATCH
cmd=%x base=%x, cmd,
DEBUG
VLAN2
INFO
op->sizeofptr = %ld, op->sizeofptr
DEBUG
VLAN3
INFO
opcode cmd = %x, cmd
DEBUG
VLAN4 <%d %d>,
INFO
modexp opcode received
DEBUG
%s: %s, dev_info, version
INFO
Memory Allocation failed
DEBUG
%s: driver unloaded, dev_info
INFO
modexpcrt opcode received
DEBUG
%s, buf
INFO
kmalloc failed
DEBUG
%s: %s (, dev_info, ath_hal_version
INFO
kmalloc failed
DEBUG
%s: driver unloaded, dev_info
INFO
kmalloc failed
DEBUG
%s: %s: mem=0x%lx, irq=%d
hw_base=0x%p,
INFO
kmalloc failed
DEBUG
%s: %s, dev_info, version
INFO
kmalloc Failed
DEBUG
%s: driver unloaded, dev_info
INFO
kmalloc failed
DEBUG
%s: %s: mem=0x%lx, irq=%d,
INFO
unknown cyrpto ioctl cmd received %x,
cmd
DEBUG
%s: %s: mem=0x%lx, irq=%d,
INFO
register_chrdev returned ZERO
DEBUG
%s: %s, dev_info, version
INFO
const char *descr, krb5_keyblock *k) {
DEBUG
%s: driver unloaded, dev_info
INFO
F password, &pdata
DEBUG
%s, buf
INFO
Unified Services Router User Manual
201
test key, key
DEBUG
%s: %s (, dev_info, ath_hal_version
INFO
pre-hashed key, key
DEBUG
%s: driver unloaded, dev_info
INFO
const char *descr, krb5_keyblock *k) {
DEBUG
%s: driver unloaded, dev_info
INFO
AES 128-bit key, &key
DEBUG
%s: Version 2.0.0
INFO
const char *descr, krb5_keyblock *k) {
DEBUG
%s: driver unloaded, dev_info
INFO
test key, key
DEBUG
%s: driver unloaded, dev_info
INFO
pre-hashed key, key
DEBUG
wlan: %s backend registered, be-
>iab_name
INFO
const char *descr, krb5_keyblock *k) {
DEBUG
wlan: %s backend unregistered,
INFO
128-bit AES key,&dk
DEBUG
wlan: %s acl policy registered, iac-
>iac_name
INFO
256-bit AES key, &dk
DEBUG
wlan: %s acl policy unregistered, iac-
>iac_name
INFO
WARNING:
DEBUG
%s: %s, dev_info, version
INFO
bwMonMultipathNxtHopSelect::
checking rates
DEBUG
%s: driver unloaded, dev_info
INFO
hop :%d dev:%s usableBwLimit = %d
currBwShare = %d lastHopSelected =
%d weightedHopPrefer = %d ,
DEBUG
%s: %s (, dev_info, ath_hal_version
INFO
1. selecting hop: %d lastHopSelected =
%d , selHop, lastHopSelected
DEBUG
%s: driver unloaded, dev_info
INFO
4. hop :%d dev:%s usableBwLimit = %d
currBwShare = %d lastHopSelected =
%d weightedHopPrefer = %d ,
DEBUG
%s: %s: mem=0x%lx, irq=%d,
INFO
2. selecting hop: %d lastHopSelected =
%d , selHop, lastHopSelected
DEBUG
%s: %s, dev_info, version
INFO
3. selecting hop: %d lastHopSelected =
%d , selHop, lastHopSelected
DEBUG
%s: driver unloaded, dev_info
INFO
bwMonitor multipath selection enabled
DEBUG
ath_pci: switching rfkill capability %s,
INFO
bwMonitor multipath selection disabled
DEBUG
Unknown autocreate mode: %s,
INFO
weightedHopPrefer set to %d
,weightedHopPrefer
DEBUG
%s: %s: mem=0x%lx, irq=%d,
INFO
bwMonitor sysctl registration failed
DEBUG
%s: %s, dev_info, version
INFO
bwMonitor sysctl registered
DEBUG
%s: driver unloaded, dev_info
INFO
bwMonitor sysctl not registered
DEBUG
%s: %s, dev_info, version
INFO
Unregistered bwMonitor sysctl
DEBUG
%s: unloaded, dev_info
INFO
CONFIG_SYSCTL enabled ...
DEBUG
%s: %s, dev_info, version
INFO
Initialized bandwidth monitor ...
DEBUG
%s: unloaded, dev_info
INFO
Removed bandwidth monitor ...
DEBUG
%s: %s, dev_info, version
INFO
Oops.. AES_GCM_encrypt failed
(keylen:%u),key->cvm_keylen
DEBUG
%s: unloaded, dev_info
INFO
Oops.. AES_GCM_decrypt failed
(keylen:%u),key->cvm_keylen
DEBUG
failed to create procfs entry .
INFO
%s, msg
DEBUG
ICMP: %u.%u.%u.%u:
INFO
%02x%s, data[i],
DEBUG
ICMP: %u.%u.%u.%u: Source
INFO
Failed to set AES encrypt key
DEBUG
Wrong address mask %u.%u.%u.%u
from
INFO
Failed to set AES encrypt key
DEBUG
Redirect from %u.%u.%u.%u on %s
about
INFO
AES %s Encrypt Test Duration: %d:%d,
hard ? Hard : Soft,
DEBUG
IP: routing cache hash table of %u
buckets, %ldKbytes,
INFO
Failed to set AES encrypt key
DEBUG
source route option %u.%u.%u.%u ->
%u.%u.%u.%u,
INFO
Unified Services Router User Manual
202
Failed to set AES encrypt key
DEBUG
ICMP: %u.%u.%u.%u:
INFO
AES %s Decrypt Test Duration: %d:%d,
hard ? Hard : Soft,
DEBUG
ICMP: %u.%u.%u.%u: Source
INFO
Failed to set AES encrypt key
DEBUG
Wrong address mask %u.%u.%u.%u
from
INFO
Failed to set AES encrypt key
DEBUG
Redirect from %u.%u.%u.%u on %s
about
INFO
Failed to set AES encrypt key
DEBUG
IP: routing cache hash table of %u
buckets, %ldKbytes,
INFO
Failed to set AES encrypt key
DEBUG
source route option %u.%u.%u.%u ->
%u.%u.%u.%u,
INFO
Failed to set DES encrypt key[%d], i
DEBUG
Wrong address mask %u.%u.%u.%u
from
INFO
Failed to set DES decrypt key[%d], i
DEBUG
Redirect from %u.%u.%u.%u on %s
about
INFO
Failed to set DES encrypt key[%d], i
DEBUG
source route option
INFO
Failed to set DES decrypt key[%d], i
DEBUG
ICMP: %u.%u.%u.%u:
INFO
Failed to set DES encrypt key
DEBUG
ICMP: %u.%u.%u.%u: Source
INFO
Failed to set DES decrypt key
DEBUG
Wrong address mask %u.%u.%u.%u
from
INFO
Failed to set DES encrypt key
DEBUG
Redirect from %u.%u.%u.%u on %s
about
INFO
Failed to set DES decrypt key
DEBUG
IP: routing cache hash table of %u
buckets, %ldKbytes,
INFO
AES Software Test:
DEBUG
source route option %u.%u.%u.%u ->
%u.%u.%u.%u,
INFO
AES Software Test %s, aesSoftTest(0)
? Failed : Passed
DEBUG
IPsec: device unregistering: %s, dev-
>name
INFO
AES Hardware Test:
DEBUG
IPsec: device down: %s, dev->name
INFO
AES Hardware Test %s,
aesHardTest(0) ? Failed : Passed
DEBUG
mark: only supports 32bit mark
WARNIN
G
3DES Software Test:
DEBUG
ipt_time: invalid argument
WARNIN
G
3DES Software Test %s,
des3SoftTest(0) ? Failed : Passed
DEBUG
ipt_time: IPT_DAY didn't matched
WARNIN
G
3DES Hardware Test:
DEBUG
./Logs_kernel.txt:45:KERN_WARNING
WARNIN
G
3DES Hardware Test %s,
des3HardTest(0) ? Failed : Passed
DEBUG
./Logs_kernel.txt:59:KERN_WARNING
WARNIN
G
DES Software Test:
DEBUG
ipt_LOG: not logging via system
console
WARNIN
G
DES Software Test %s, desSoftTest(0)
? Failed : Passed
DEBUG
%s: wrong options length: %u, fname,
opt_len
WARNIN
G
DES Hardware Test:
DEBUG
%s: options rejected: o[0]=%02x,
o[1]=%02x,
WARNIN
G
DES Hardware Test %s,
desHardTest(0) ? Failed : Passed
DEBUG
%s: wrong options length: %u,
WARNIN
G
SHA Software Test:
DEBUG
%s: options rejected: o[0]=%02x,
o[1]=%02x,
WARNIN
G
SHA Software Test %s, shaSoftTest(0)
? Failed : Passed
DEBUG
%s: don't know what to do: o[5]=%02x,
WARNIN
G
SHA Hardware Test:
DEBUG
%s: wrong options length: %u, fname,
opt_len
WARNIN
G
SHA Hardware Test %s,
shaHardTest(0) ? Failed : Passed
DEBUG
%s: options rejected: o[0]=%02x,
o[1]=%02x,
WARNIN
G
MD5 Software Test:
DEBUG
%s: wrong options length: %u,
WARNIN
G
Unified Services Router User Manual
203
MD5 Software Test %s, md5SoftTest(0)
? Failed : Passed
DEBUG
%s: options rejected: o[0]=%02x,
o[1]=%02x,
WARNIN
G
MD5 Hardware Test:
DEBUG
%s: don't know what to do: o[5]=%02x,
WARNIN
G
MD5 Hardware Test %s,
md5HardTest(0) ? Failed : Passed
DEBUG
*** New port %d ***, ntohs(expinfo-
>natport)
WARNIN
G
AES Software Test: %d iterations, iter
DEBUG
** skb len %d, dlen %d,(*pskb)->len,
WARNIN
G
AES Software Test Duration: %d:%d,
DEBUG
********** Non linear skb
WARNIN
G
AES Hardware Test: %d iterations, iter
DEBUG
End of sdp %p, nexthdr
WARNIN
G
AES Hardware Test Duration: %d:%d,
DEBUG
%s: unknown pairwise cipher %d,
WARNIN
G
3DES Software Test: %d iterations, iter
DEBUG
%s: unknown group cipher %d,
WARNIN
G
3DES Software Test Duration: %d:%d,
DEBUG
%s: unknown SIOCSIWAUTH flag %d,
WARNIN
G
3DES Hardware Test: %d iterations, iter
DEBUG
%s: unknown SIOCGIWAUTH flag %d,
WARNIN
G
3DES Hardware Test Duration: %d:%d,
DEBUG
%s: unknown algorithm %d,
WARNIN
G
DES Software Test: %d iterations, iter
DEBUG
%s: key size %d is too large,
WARNIN
G
DES Software Test Duration: %d:%d,
DEBUG
try_module_get failed \
WARNIN
G
DES Hardware Test: %d iterations, iter
DEBUG
%s: request_irq failed, dev->name
WARNIN
G
DES Hardware Test Duration: %d:%d,
DEBUG
try_module_get failed
WARNIN
G
SHA Software Test: %d iterations, iter
DEBUG
try_module_get failed \
WARNIN
G
SHA Software Test Duration: %d:%d,
DEBUG
%s: unknown pairwise cipher %d,
WARNIN
G
SHA Hardware Test: %d iterations, iter
DEBUG
%s: unknown group cipher %d,
WARNIN
G
SHA Hardware Test Duration: %d:%d,
DEBUG
%s: unknown SIOCSIWAUTH flag %d,
WARNIN
G
MD5 Software Test: %d iterations, iter
DEBUG
%s: unknown SIOCGIWAUTH flag %d,
WARNIN
G
MD5 Software Test Duration: %d:%d,
DEBUG
%s: unknown algorithm %d,
WARNIN
G
MD5 Hardware Test: %d iterations, iter
DEBUG
%s: key size %d is too large,
WARNIN
G
MD5 Hardware Test Duration: %d:%d,
DEBUG
unable to load %s,
scan_modnames[mode]
WARNIN
G
./pnac/src/pnac/linux/kernel/xcalibur.c:2
09:#define DEBUG_PRINTK printk
DEBUG
Failed to mkdir /proc/net/madwifi
WARNIN
G
bcmDeviceInit: registration failed
DEBUG
try_module_get failed
WARNIN
G
bcmDeviceInit: pCdev Add failed
DEBUG
%s: request_irq failed, dev->name
WARNIN
G
REG Size == 8 Bit
DEBUG
too many virtual ap's (already got %d),
sc->sc_nvaps
WARNIN
G
Value = %x ::: At Page = %x : Addr =
%x
DEBUG
%s: request_irq failed, dev->name
WARNIN
G
REG Size == 16 Bit
DEBUG
rix %u (%u) bad ratekbps %u mode
%u,
WARNIN
G
Unified Services Router User Manual
204
Value = %x ::: At Page = %x : Addr =
%x
DEBUG
cix %u (%u) bad ratekbps %u mode
%u,
WARNIN
G
REG Size == 32 Bit
DEBUG
%s: no rates for %s?,
WARNIN
G
Value = %x ::: At Page = %x : Addr =
%x
DEBUG
no rates yet! mode %u, sc-
>sc_curmode
WARNIN
G
REG Size == 64 Bit
DEBUG
%u.%u.%u.%u sent an invalid ICMP
WARNIN
G
REG Size is not in 8/16/32/64
DEBUG
dst cache overflow
WARNIN
G
Written Value = %x ::: At Page = %x :
Addr = %x
DEBUG
Neighbour table overflow.
WARNIN
G
bcm_ioctl :Unknown Ioctl Case :
DEBUG
host %u.%u.%u.%u/if%d ignores
WARNIN
G
=========Register Dump for Port
Number # %d=========,port
DEBUG
martian destination %u.%u.%u.%u
from
WARNIN
G
%s : Read Status=%s
data=%#x,regName[j],
DEBUG
martian source %u.%u.%u.%u from
WARNIN
G
%s : Read Status=%s
data=%#x,regName[j],
DEBUG
ll header:
WARNIN
G
powerDeviceInit: device registration
failed
DEBUG
%u.%u.%u.%u sent an invalid ICMP
WARNIN
G
powerDeviceInit: adding device failed
DEBUG
dst cache overflow
WARNIN
G
%s: Error: Big jump in pn number.
TID=%d, from %x %x to %x %x.
DEBUG
Neighbour table overflow.
WARNIN
G
%s: The MIC is corrupted. Drop this
frame., __func__
DEBUG
host %u.%u.%u.%u/if%d ignores
WARNIN
G
%s: The MIC is OK. Still use this frame
and update PN., __func__
DEBUG
martian destination %u.%u.%u.%u
from
WARNIN
G
ADDBA send failed: recipient is not a
11n node
DEBUG
martian source %u.%u.%u.%u from
WARNIN
G
Cannot Set Rate: %x, value
DEBUG
ll header:
WARNIN
G
Getting Rate Series: %x,vap-
>iv_fixed_rate.series
DEBUG
%u.%u.%u.%u sent an invalid ICMP
WARNIN
G
Getting Retry Series: %x,vap-
>iv_fixed_rate.retries
DEBUG
dst cache overflow
WARNIN
G
IC Name: %s,ic->ic_dev->name
DEBUG
Neighbour table overflow.
WARNIN
G
usage: rtparams rt_idx <0|1> per
<0..100> probe_intval <0..100>
DEBUG
host %u.%u.%u.%u/if%d ignores
WARNIN
G
usage: acparams ac <0|3> RTS <0|1>
aggr scaling <0..4> min mbps <0..250>
DEBUG
martian source %u.%u.%u.%u from
WARNIN
G
usage: hbrparams ac <2> enable <0|1>
per_low <0..50>
DEBUG
ll header:
WARNIN
G
%s(): ADDBA mode is AUTO, __func__
DEBUG
martian destination %u.%u.%u.%u
from
WARNIN
G
%s(): Invalid TID value, __func__
DEBUG
%u.%u.%u.%u sent an invalid ICMP
WARNIN
G
%s(): ADDBA mode is AUTO, __func__
DEBUG
dst cache overflow
WARNIN
G
%s(): Invalid TID value, __func__
DEBUG
Neighbour table overflow.
WARNIN
G
%s(): Invalid TID value, __func__
DEBUG
host %u.%u.%u.%u/if%d ignores
WARNIN
G
Addba status IDLE
DEBUG
martian destination %u.%u.%u.%u
WARNIN
Unified Services Router User Manual
205
from
G
%s(): ADDBA mode is AUTO, __func__
DEBUG
martian source %u.%u.%u.%u from
WARNIN
G
%s(): Invalid TID value, __func__
DEBUG
ll header:
WARNIN
G
Error in ADD- no node available
DEBUG
Unable to create ip_set_list
ERROR
%s(): Channel capabilities do not match,
chan flags 0x%x,
DEBUG
Unable to create ip_set_hash
ERROR
%s: cannot map channel to mode; freq
%u flags 0x%x,
DEBUG
ip_conntrack_in: Frag of proto %u
(hook=%u),
ERROR
ic_get_currentCountry not initialized yet
DEBUG
Unable to register netfilter socket
option
ERROR
Country ie is %c%c%c,
DEBUG
Unable to create ip_conntrack_hash
ERROR
%s: wrong state transition from %d to
%d,
DEBUG
Unable to create ip_conntrack slab
cache
ERROR
%s: wrong state transition from %d to
%d,
DEBUG
Unable to create ip_expect slab cache
ERROR
%s: wrong state transition from %d to
%d,
DEBUG
Unable to create ip_set_iptreeb slab
cache
ERROR
%s: wrong state transition from %d to
%d,
DEBUG
Unable to create ip_set_iptreed slab
cache
ERROR
%s: wrong state transition from %d to
%d,
DEBUG
%s: cannot allocate space for
%scompressor, fname,
ERROR
%s: wrong state transition from %d to
%d,
DEBUG
%s: cannot allocate space for MPPC
history,
ERROR
ieee80211_deliver_l2uf: no buf available
DEBUG
%s: cannot allocate space for MPPC
history,
ERROR
%s: %s, vap->iv_dev->name, buf /*
NB: no */
DEBUG
%s: cannot load ARC4 module, fname
ERROR
%s: [%s] %s, vap->iv_dev->name,
DEBUG
%s: cannot load SHA1 module, fname
ERROR
%s: [%s] %s, vap->iv_dev->name,
ether_sprintf(mac), buf
DEBUG
%s: CryptoAPI SHA1 digest size too
small, fname
ERROR
[%s:%s] discard %s frame, %s, vap-
>iv_dev->name,
DEBUG
%s: cannot allocate space for SHA1
digest, fname
ERROR
[%s:%s] discard frame, %s, vap-
>iv_dev->name,
DEBUG
%s%d: trying to write outside history
ERROR
[%s:%s] discard %s information
element, %s,
DEBUG
%s%d: trying to write outside history
ERROR
[%s:%s] discard information element,
%s,
DEBUG
%s%d: trying to write outside history
ERROR
[%s:%s] discard %s frame, %s, vap-
>iv_dev->name,
DEBUG
%s%d: too big uncompressed packet:
%d,
ERROR
[%s:%s] discard frame, %s, vap-
>iv_dev->name,
DEBUG
%s%d: encryption negotiated but not
an
ERROR
HBR list
dumpNode\tAddress\t\t\tState\tTrigger\t
Block
DEBUG
%s%d: error - not an MPPC or MPPE
frame
ERROR
Nodes
informationAddress\t\t\tBlock\t\tDroped
VI frames
DEBUG
Kernel doesn't provide ARC4 and/or
SHA1 algorithms
ERROR
%d\t
%2.2x:%2.2x:%2.2x:%2.2x:%2.2x:%2.2
x\t%s\t%s\t%s,
DEBUG
PPP: not interface or channel??
ERROR
%2.2x:%2.2x:%2.2x:%2.2x:%2.2x:%2.2
x\t%s\t\t%d,
DEBUG
PPP: no memory (VJ compressor)
ERROR
[%d]\tFunction\t%s, j, ni-
>node_trace[i].funcp
DEBUG
failed to register PPP device (%d), err
ERROR
Unified Services Router User Manual
206
[%d]\tMacAddr\t%s, j,
DEBUG
PPP: no memory (VJ comp pkt)
ERROR
[%d]\tDescp\t\t%s, j, ni-
>node_trace[i].descp
DEBUG
PPP: no memory (comp pkt)
ERROR
[%d]\tValue\t\t%llu(0x%llx), j, ni-
>node_trace[i].value,
DEBUG
ppp: compressor dropped pkt
ERROR
ifmedia_add: null ifm
DEBUG
PPP: no memory (fragment)
ERROR
Adding entry for
DEBUG
PPP: VJ uncompressed error
ERROR
ifmedia_set: no match for 0x%x/0x%x,
DEBUG
ppp_decompress_frame: no memory
ERROR
ifmedia_set: target
DEBUG
ppp_mp_reconstruct bad seq %u <
%u,
ERROR
ifmedia_set: setting to
DEBUG
PPP: couldn't register device %s (%d),
ERROR
ifmedia_ioctl: switching %s to , dev-
>name
DEBUG
ppp: destroying ppp struct %p but
dead=%d
ERROR
ifmedia_match: multiple match for
DEBUG
ppp: destroying undead channel %p !,
ERROR
<unknown type>
DEBUG
PPP: removing module but units
remain!
ERROR
desc->ifmt_string
DEBUG
PPP: failed to unregister PPP device
ERROR
mode %s, desc->ifmt_string
DEBUG
%s: cannot allocate space for
%scompressor, fname,
ERROR
<unknown subtype>
DEBUG
%s: cannot allocate space for MPPC
history,
ERROR
%s, desc->ifmt_string
DEBUG
%s: cannot allocate space for MPPC
history,
ERROR
%s%s, seen_option++ ? , : ,
DEBUG
%s: cannot load ARC4 module, fname
ERROR
%s%s, seen_option++ ? , : ,
DEBUG
%s: cannot load SHA1 module, fname
ERROR
%s, seen_option ? > :
DEBUG
%s: CryptoAPI SHA1 digest size too
small, fname
ERROR
%s: %s, dev->name, buf
DEBUG
%s: cannot allocate space for SHA1
digest, fname
ERROR
%s: no memory for sysctl table!,
__func__
DEBUG
%s%d: trying to write outside history
ERROR
%s: failed to register sysctls!, vap-
>iv_dev->name
DEBUG
%s%d: trying to write outside history
ERROR
Atheros HAL assertion failure: %s: line
%u: %s,
DEBUG
%s%d: trying to write outside history
ERROR
ath_hal: logging to %s %s,
ath_hal_logfile,
DEBUG
%s%d: too big uncompressed packet:
%d,
ERROR
ath_hal: logging disabled
DEBUG
%s%d: encryption negotiated but not
an
ERROR
%s%s, sep, ath_hal_buildopts[i]
DEBUG
%s%d: error - not an MPPC or MPPE
frame
ERROR
ath_pci: No devices found, driver not
installed.
DEBUG
Kernel doesn't provide ARC4 and/or
SHA1 algorithms
ERROR
---:%d pri:%d qd:%u ad:%u sd:%u
tot:%u amp:%d %02x:%02x:%02x,
DEBUG
PPP: not interface or channel??
ERROR
SC Pushbutton Notify on %s::%s,dev-
>name,vap->iv_dev->name
DEBUG
PPP: no memory (VJ compressor)
ERROR
Could not find Board Configuration Data
DEBUG
failed to register PPP device (%d), err
ERROR
Could not find Radio Configuration data
DEBUG
PPP: no memory (comp pkt)
ERROR
%s: No device, __func__
DEBUG
ppp: compressor dropped pkt
ERROR
ath_ahb: No devices found, driver not
installed.
DEBUG
PPP: no memory (VJ comp pkt)
ERROR
PKTLOG_TAG %s:proc_dointvec failed,
__FUNCTION__
DEBUG
PPP: no memory (comp pkt)
ERROR
PKTLOG_TAG %s:proc_dointvec failed,
DEBUG
PPP: no memory (fragment)
ERROR
Unified Services Router User Manual
207
__FUNCTION__
%s: failed to register sysctls!,
proc_name
DEBUG
PPP: VJ uncompressed error
ERROR
PKTLOG_TAG %s: proc_mkdir failed,
__FUNCTION__
DEBUG
ppp_decompress_frame: no memory
ERROR
PKTLOG_TAG %s: pktlog_attach failed
for %s,
DEBUG
ppp_mp_reconstruct bad seq %u <
%u,
ERROR
PKTLOG_TAG %s:allocation failed for
pl_info, __FUNCTION__
DEBUG
PPP: couldn't register device %s (%d),
ERROR
PKTLOG_TAG %s:allocation failed for
pl_info, __FUNCTION__
DEBUG
ppp: destroying ppp struct %p but
dead=%d
ERROR
PKTLOG_TAG %s: create_proc_entry
failed for %s,
DEBUG
ppp: destroying undead channel %p !,
ERROR
PKTLOG_TAG %s: sysctl register failed
for %s,
DEBUG
PPP: removing module but units
remain!
ERROR
PKTLOG_TAG %s: page fault out of
range, __FUNCTION__
DEBUG
PPP: failed to unregister PPP device
ERROR
PKTLOG_TAG %s: page fault out of
range, __FUNCTION__
DEBUG
JBD: bad block at offset %u,
ERROR
PKTLOG_TAG %s: Log buffer
unavailable, __FUNCTION__
DEBUG
JBD: corrupted journal superblock
ERROR
PKTLOG_TAG
DEBUG
JBD: bad block at offset %u,
ERROR
Logging should be disabled before
changing bufer size
DEBUG
JBD: Failed to read block at offset %u,
ERROR
%s:allocation failed for pl_info, __func__
DEBUG
JBD: error %d scanning journal, err
ERROR
%s: Unable to allocate buffer, __func__
DEBUG
JBD: IO error %d recovering block
ERROR
%s:allocation failed for pl_info, __func__
DEBUG
./Logs_kernel.txt:303:KERN_ERR
ERROR
%s: Unable to allocate buffer, __func__
DEBUG
./Logs_kernel.txt:304:KERN_ERR
ERROR
Atheros HAL assertion failure: %s: line
%u: %s,
DEBUG
JBD: recovery pass %d ended at
ERROR
ath_hal: logging to %s %s,
ath_hal_logfile,
DEBUG
%s: %s:%d: BAD SESSION MAGIC \
ERROR
ath_hal: logging disabled
DEBUG
%s: %s:%d: BAD TUNNEL MAGIC \
ERROR
%s%s, sep, ath_hal_buildopts[i]
DEBUG
msg->msg_namelen wrong, %d, msg-
>msg_namelen
ERROR
failed to allocate rx descriptors: %d,
error
DEBUG
addr family wrong: %d, usin-
>sin_family
ERROR
ath_stoprecv: rx queue %p, link %p,
DEBUG
udp addr=%x/%hu, usin-
>sin_addr.s_addr, usin->sin_port
ERROR
no mpdu (%s), __func__
DEBUG
%s: %s:%d: BAD TUNNEL MAGIC
ERROR
Reset rx chain mask. Do internal reset.
(%s), __func__
DEBUG
%s: %s:%d: BAD TUNNEL MAGIC
ERROR
OS_CANCEL_TIMER failed!!
DEBUG
socki_lookup: socket file changed!
ERROR
%s: unable to allocate channel table,
__func__
DEBUG
%s: %s:%d: BAD TUNNEL MAGIC
ERROR
%s: unable to collect channel list from
hal;
DEBUG
%s: %s:%d: BAD SESSION MAGIC \
ERROR
%s: cannot map channel to mode; freq
%u flags 0x%x,
DEBUG
%s: %s:%d: BAD TUNNEL MAGIC \
ERROR
%s: unable to reset channel %u
(%uMhz)
DEBUG
msg->msg_namelen wrong, %d, msg-
>msg_namelen
ERROR
%s: unable to restart recv logic,
DEBUG
addr family wrong: %d, usin-
>sin_family
ERROR
%s: start DFS WAIT period on channel
%d, __func__,sc->sc_curchan.channel
DEBUG
udp addr=%x/%hu, usin-
>sin_addr.s_addr, usin->sin_port
ERROR
Unified Services Router User Manual
208
%s: cancel DFS WAIT period on
channel %d, __func__, sc-
>sc_curchan.channel
DEBUG
%s: %s:%d: BAD TUNNEL MAGIC
ERROR
Non-DFS channel, cancelling previous
DFS wait timer channel %d, sc-
>sc_curchan.channel
DEBUG
%s: %s:%d: BAD TUNNEL MAGIC
ERROR
%s: unable to reset hardware; hal status
%u
DEBUG
socki_lookup: socket file changed!
ERROR
%s: unable to start recv logic, __func__
DEBUG
%s: %s:%d: BAD TUNNEL MAGIC
ERROR
%s: unable to start recv logic, __func__
DEBUG
%s: %s:%d: BAD SESSION MAGIC \
ERROR
%s: unable to reset hardware; hal status
%u,
DEBUG
%s: %s:%d: BAD TUNNEL MAGIC \
ERROR
hardware error; reseting
DEBUG
msg->msg_namelen wrong, %d, msg-
>msg_namelen
ERROR
rx FIFO overrun; reseting
DEBUG
addr family wrong: %d, usin-
>sin_family
ERROR
%s: During Wow Sleep and got BMISS,
__func__
DEBUG
udp addr=%x/%hu, usin-
>sin_addr.s_addr, usin->sin_port
ERROR
AC\tRTS \tAggr Scaling\tMin
Rate(Kbps)\tHBR \tPER LOW
THRESHOLD
DEBUG
%s: %s:%d: BAD TUNNEL MAGIC
ERROR
BE\t%s\t\t%d\t%6d\t\t%s\t%d,
DEBUG
%s: %s:%d: BAD TUNNEL MAGIC
ERROR
BK\t%s\t\t%d\t%6d\t\t%s\t%d,
DEBUG
socki_lookup: socket file changed!
ERROR
VI\t%s\t\t%d\t%6d\t\t%s\t%d,
DEBUG
%s: %s:%d: BAD TUNNEL MAGIC
ERROR
VO\t%s\t\t%d\t%6d\t\t%s\t%d,
DEBUG
rebootHook: null function pointer
ERROR
--%d,%p,%lu:0x%x 0x%x 0x%p 0x%x
0x%x 0x%x 0x%x,
DEBUG
Bad ioctl command
ERROR
bb state: 0x%08x 0x%08x, bbstate(sc,
4ul), bbstate(sc, 5ul)
DEBUG
fResetMod: Failed to configure gpio pin
ERROR
%08x %08x %08x %08x %08x %08x
%08x %08x%08x %08x %08x %08x,
DEBUG
fResetMod: Failed to register interrupt
handler
ERROR
noise floor: (%d, %d) (%d, %d) (%d,
%d),
DEBUG
registering char device failed
ERROR
%p: %08x %08x %08x %08x %08x
%08x %08x %08x %08x %08x %08x
%08x,
DEBUG
unregistering char device failed
ERROR
--%d,%p,%lu:0x%x 0x%x 0x%p 0x%x
0x%x 0x%x 0x%x,
DEBUG
proc entry delete failed
ERROR
%08x %08x %08x %08x %08x %08x
%08x %08x%08x %08x %08x %08x,
DEBUG
proc entry initialization failed
ERROR
%s: unable to allocate device object.,
__func__
DEBUG
testCompHandler: received %s from
%d, (char *)pInBuf,
ERROR
%s: unable to attach hardware; HAL
status %u,
DEBUG
UMI proto registration failed %d,ret
ERROR
%s: HAL ABI msmatch;
DEBUG
AF_UMI registration failed %d,ret
ERROR
%s: Warning, using only %u entries in
%u key cache,
DEBUG
umi initialization failed %d,ret
ERROR
unable to setup a beacon xmit queue!
DEBUG
kernel UMI registration failed!
ERROR
unable to setup CAB xmit queue!
DEBUG
./Logs_kernel.txt:447:KERN_ERR
ERROR
unable to setup xmit queue for BE
traffic!
DEBUG
ERROR msm not found properly %d,
len %d, msm,
ERROR
%s DFS attach failed, __func__
DEBUG
ModExp returned Error
ERROR
%s: Invalid interface id = %u, __func__,
if_id
DEBUG
ModExp returned Error
ERROR
%s:grppoll Buf allocation failed
DEBUG
%s: 0x%p len %u, tag, p, (unsigned
ERROR
Unified Services Router User Manual
209
,__func__
int)len
%s: unable to start recv logic,
DEBUG
%03d:, i
ERROR
%s: Invalid interface id = %u, __func__,
if_id
DEBUG
%02x, ((unsigned char *)p)[i]
ERROR
%s: unable to allocate channel table,
__func__
DEBUG
mic check failed
ERROR
%s: Tx Antenna Switch. Do internal
reset., __func__
DEBUG
%s: 0x%p len %u, tag, p, (unsigned
int)len
ERROR
Radar found on channel %d (%d MHz),
DEBUG
%03d:, i
ERROR
End of DFS wait period
DEBUG
%02x, ((unsigned char *)p)[i]
ERROR
%s error allocating beacon, __func__
DEBUG
mic check failed
ERROR
failed to allocate UAPSD QoS NULL tx
descriptors: %d, error
DEBUG
[%s] Wrong parameters, __func__
ERROR
failed to allocate UAPSD QoS NULL
wbuf
DEBUG
[%s] Wrong Key length, __func__
ERROR
%s: unable to allocate channel table,
__func__
DEBUG
[%s] Wrong parameters, __func__
ERROR
%s: unable to update h/w beacon queue
parameters,
DEBUG
[%s] Wrong Key length, __func__
ERROR
ALREADY ACTIVATED
DEBUG
[%s] Wrong parameters, __func__
ERROR
%s: missed %u consecutive beacons,
DEBUG
[%s] Wrong Key length, __func__
ERROR
%s: busy times: rx_clear=%d,
rx_frame=%d, tx_frame=%d, __func__,
rx_clear, rx_frame, tx_frame
DEBUG
[%s] Wrong parameters, __func__
ERROR
%s: unable to obtain busy times,
__func__
DEBUG
[%s] Wrong Key length, __func__
ERROR
%s: beacon is officially stuck,
DEBUG
[%s]: Wrong parameters, __func__
ERROR
Busy environment detected
DEBUG
[%s] Wrong Key Length %d, __func__,
des_key_len
ERROR
Inteference detected
DEBUG
[%s] Wrong parameters %d, __func__,
des_key_len
ERROR
rx_clear=%d, rx_frame=%d,
tx_frame=%d,
DEBUG
[%s] Wrong Key Length %d, __func__,
des_key_len
ERROR
%s: resume beacon xmit after %u
misses,
DEBUG
[%s] Wrong parameters, __func__
ERROR
%s: stuck beacon; resetting (bmiss
count %u),
DEBUG
[%s] Wrong Key Length, __func__
ERROR
EMPTY QUEUE
DEBUG
[%s] Wrong parameters, __func__
ERROR
SWRInfo: seqno %d isswRetry %d
retryCnt %d,wh ? (*(u_int16_t *)&wh-
>i_seq[0]) >> 4 : 0, bf->bf_isswretry,bf-
>bf_swretries
DEBUG
[%s] Wrong Key Length, __func__
ERROR
Buffer #%08X --> Next#%08X
Prev#%08X Last#%08X,bf,
TAILQ_NEXT(bf,bf_list),
DEBUG
[%s] Wrong parameters, __func__
ERROR
Stas#%08X flag#%08X
Node#%08X, bf->bf_status, bf-
>bf_flags, bf->bf_node
DEBUG
[%s] Wrong parameters, __func__
ERROR
Descr #%08X --> Next#%08X
Data#%08X Ctl0#%08X Ctl1#%08X, bf-
>bf_daddr, ds->ds_link, ds->ds_data,
ds->ds_ctl0, ds->ds_ctl1
DEBUG
[%s] Wrong parameters, __func__
ERROR
Ctl2#%08X Ctl3#%08X
Sta0#%08X Sta1#%08X,ds->ds_hw[0],
ds->ds_hw[1], lastds->ds_hw[2], lastds-
>ds_hw[3]
DEBUG
[%s] Wrong parameters, __func__
ERROR
Error entering wow mode
DEBUG
device name=%s not found, pReq-
ERROR
Unified Services Router User Manual
210
>ifName
Wakingup due to wow signal
DEBUG
unable to register KIFDEV to UMI
ERROR
%s, wowStatus = 0x%x, __func__,
wowStatus
DEBUG
ERROR: %s: Timeout at page %#0x
addr %#0x
ERROR
Pattern added already
DEBUG
ERROR: %s: Timeout at page %#0x
addr %#0x
ERROR
Error : All the %d pattern are in use.
Cannot add a new pattern ,
MAX_NUM_PATTERN
DEBUG
Invalid IOCTL %#08x, cmd
ERROR
Pattern added to entry %d ,i
DEBUG
%s: unable to register device, dev-
>name
ERROR
Remove wake up pattern
DEBUG
ath_pci: 32-bit DMA not available
ERROR
mask = %p pat = %p
,maskBytes,patternBytes
DEBUG
ath_pci: cannot reserve PCI memory
region
ERROR
mask = %x pat = %x
,(u_int32_t)maskBytes,
(u_int32_t)patternBytes
DEBUG
ath_pci: cannot remap PCI memory
region) ;
ERROR
Pattern Removed from entry %d ,i
DEBUG
ath_pci: no memory for device state
ERROR
Error : Pattern not found
DEBUG
%s: unable to register device, dev-
>name
ERROR
PPM STATE ILLEGAL %x %x,
forcePpmStateCur, afp->forceState
DEBUG
ath_dev_probe: no memory for device
state
ERROR
FORCE_PPM %4d %6.6x %8.8x %8.8x
%8.8x %3.3x %4.4x,
DEBUG
%s: no memory for device state,
__func__
ERROR
failed to allocate tx descriptors: %d,
error
DEBUG
kernel MIBCTL registration failed!
ERROR
failed to allocate beacon descripotrs:
%d, error
DEBUG
Bad ioctl command
ERROR
failed to allocate UAPSD descripotrs:
%d, error
DEBUG
WpsMod: Failed to configure gpio pin
ERROR
hal qnum %u out of range, max %u!,
DEBUG
WpsMod: Failed to register interrupt
handler
ERROR
HAL AC %u out of range, max %zu!,
DEBUG
registering char device failed
ERROR
HAL AC %u out of range, max %zu!,
DEBUG
unregistering char device failed
ERROR
%s: unable to update hardware queue
%u!,
DEBUG
%s:%d - ERROR: non-NULL node
pointer in %p, %p<%s>!
ERROR
Multicast Q:
DEBUG
%s:%d - ERROR: non-NULL node
pointer in %p, %p<%s>!
ERROR
%p , buf
DEBUG
can't alloc name %s, name
ERROR
buf flags - 0x%08x --------- , buf-
>bf_flags
DEBUG
%s: unable to register device, dev-
>name
ERROR
buf status - 0x%08x, buf->bf_status
DEBUG
failed to automatically load module:
%s; \
ERROR
# frames in aggr - %d, length of
aggregate - %d, length of frame - %d,
sequence number - %d, tidno - %d,
DEBUG
Unable to load needed module: %s; no
support for \
ERROR
isdata: %d isaggr: %d isampdu: %d ht:
%d isretried: %d isxretried: %d
shpreamble: %d isbar: %d ispspoll: %d
aggrburst: %d calcairtime: %d
qosnulleosp: %d,
DEBUG
Module \%s\ is not known, buf
ERROR
%p: 0x%08x 0x%08x 0x%08x 0x%08x
0x%08x 0x%08x 0x%08x 0x%08x
0x%08x 0x%08x,
DEBUG
Error loading module \%s\, buf
ERROR
0x%08x 0x%08x 0x%08x 0x%08x
0x%08x 0x%08x 0x%08x 0x%08x
DEBUG
Module \%s\ failed to initialize, buf
ERROR
Unified Services Router User Manual
211
0x%08x 0x%08x,
0x%08x 0x%08x 0x%08x 0x%08x,
DEBUG
ath_pci: 32-bit DMA not available
ERROR
sc_txq[%d] : , i
DEBUG
ath_pci: cannot reserve PCI memory
region
ERROR
tid %p pause %d : , tid, tid->paused
DEBUG
ath_pci: cannot remap PCI memory
region) ;
ERROR
%d: %p , j, tid->tx_buf[j]
DEBUG
ath_pci: no memory for device state
ERROR
%p , buf
DEBUG
%s: unable to attach hardware: '%s'
(HAL status %u),
ERROR
axq_q:
DEBUG
%s: HAL ABI mismatch;
ERROR
%s: unable to reset hardware; hal status
%u, __func__, status
DEBUG
%s: failed to allocate descriptors: %d,
ERROR
****ASSERTION HIT****
DEBUG
%s: unable to setup a beacon xmit
queue!,
ERROR
MacAddr=%s,
DEBUG
%s: unable to setup CAB xmit queue!,
ERROR
TxBufIdx=%d, i
DEBUG
%s: unable to setup xmit queue for %s
traffic!,
ERROR
Tid=%d, tidno
DEBUG
%s: unable to register device, dev-
>name
ERROR
AthBuf=%p, tid->tx_buf[i]
DEBUG
%s: autocreation of VAP failed: %d,
ERROR
%s: unable to reset hardware; hal status
%u,
DEBUG
ath_dev_probe: no memory for device
state
ERROR
%s: unable to reset hardware; hal status
%u,
DEBUG
kdot11RogueAPEnable called with
NULL argument.
ERROR
%s: unable to start recv logic,
DEBUG
kdot11RogueAPEnable: can not add
more interfaces
ERROR
_fmt, __VA_ARGS__ \
DEBUG
kdot11RogueAPGetState called with
NULL argument.
ERROR
sample_pri=%d is a multiple of
refpri=%d, sample_pri, refpri
DEBUG
kdot11RogueAPDisable called with
NULL argument.
ERROR
===========ft-
>ft_numfilters=%u===========, ft-
>ft_numfilters
DEBUG
%s: SKB does not exist.,
__FUNCTION__
ERROR
filter[%d] filterID = %d
rf_numpulses=%u; rf->rf_minpri=%u; rf-
>rf_maxpri=%u; rf->rf_threshold=%u; rf-
>rf_filterlen=%u; rf->rf_mindur=%u; rf-
>rf_maxdur=%u,j, rf->rf_pulseid,
DEBUG
%s: recvd invalid skb
ERROR
NOL
DEBUG
unable to register KIFDEV to UMI
ERROR
WARNING!!! 10 minute CAC period as
channel is a weather radar channel
DEBUG
The system is going to factory
defaults........!!!
CRITICAL
%s disable detects, __func__
DEBUG
%s, msg
CRITICAL
%s enable detects, __func__
DEBUG
%02x, *(data + i)
CRITICAL
%s disable FFT val=0x%x , __func__,
val
DEBUG
Inside crypt_open in driver ######
CRITICAL
%s enable FFT val=0x%x , __func__,
val
DEBUG
Inside crypt_release in driver ######
CRITICAL
%s debug level now = 0x%x , __func__,
dfs_debug_level
DEBUG
Inside crypt_init module in driver
@@@@@@@@
CRITICAL
RateTable:%d, maxvalidrate:%d,
ratemax:%d, pRc->rateTableSize,k,pRc-
>rateMaxPhy
DEBUG
Inside crypt_cleanup module in driver
@@@@@@@@
CRITICAL
%s: txRate value of 0x%x is bad.,
__FUNCTION__, txRate
DEBUG
SKB is null : %p ,skb
CRITICAL
Valid Rate Table:-
DEBUG
DST is null : %p ,dst
CRITICAL
Unified Services Router User Manual
212
Index:%d, value:%d, code:%x, rate:%d,
flag:%x, i, (int)validRateIndex[i],
DEBUG
DEV is null %p %p ,dev,dst
CRITICAL
RateTable:%d, maxvalidrate:%d,
ratemax:%d, pRc->rateTableSize,k,pRc-
>rateMaxPhy
DEBUG
Packet is Fragmented %d,pBufMgr-
>len
CRITICAL
Can't allocate memory for ath_vap.
DEBUG
Marked the packet proto:%d sip:%x
dip:%x sport:%d dport:%d
spi:%d,isr:%p:%p %p
CRITICAL
Unable to add an interface for ath_dev.
DEBUG
SAV CHECK FAILED IN
DECRYPTION
CRITICAL
%s: [%02u] %-7s , tag, ix, ciphers[hk-
>kv_type]
DEBUG
FAST PATH Breaks on BUF CHECK
CRITICAL
%02x, hk->kv_val[i]
DEBUG
FAST PATH Breaks on DST CHECK
CRITICAL
mac %02x-%02x-%02x-%02x-%02x-
%02x, mac[0], mac[1], mac[2], mac[3],
mac[4], mac[5]
DEBUG
FAST PATH Breaks on MTU %d %d
%d,bufMgrLen(pBufMgr),mtu,dst_mtu(
pDst->path)
CRITICAL
mac 00-00-00-00-00-00
DEBUG
FAST PATH Breaks on MAX PACKET
%d
%d,bufMgrLen(pBufMgr),IP_MAX_PA
CKET
CRITICAL
%02x, hk->kv_mic[i]
DEBUG
SAV CHECK FAILED IN
ENCRYPTION
CRITICAL
txmic
DEBUG
Match Found proto %d spi
%d,pPktInfo->proto,pFlowEntry-
>pre.spi
CRITICAL
%02x, hk->kv_txmic[i]
DEBUG
PRE: proto: %u srcip:%u.%u.%u.%u
sport :%u dstip: %u.%u.%u.%u dport:
%u,
CRITICAL
Cannot support setting tx and rx keys
individually
DEBUG
POST: proto: %u srcip:%u.%u.%u.%u
sport :%u dstip: %u.%u.%u.%u dport:
%u,
CRITICAL
bogus frame type 0x%x (%s),
DEBUG
Clearing the ISR %p,p
CRITICAL
ERROR: ieee80211_encap ret NULL
DEBUG
PROTO:%d %u.%u.%u.%u---
>%u.%u.%u.%u,
CRITICAL
ERROR: ath_amsdu_attach not called
DEBUG
ESP-DONE: %p %p,sav,m
CRITICAL
%s: no memory for cwm attach,
__func__
DEBUG
ESP-BAD: %p %p,sav,m
CRITICAL
%s: error - acw NULL. Possible attach
failure, __func__
DEBUG
Bug in ip_route_input_slow().
CRITICAL
%s: unable to abort tx dma, __func__
DEBUG
Bug in ip_route_input_slow().
CRITICAL
%s: no memory for ff attach, __func__
DEBUG
Bug in ip_route_input \
CRITICAL
Failed to initiate PBC based enrolle
association
DEBUG
Bug in ip_route_input_slow().
CRITICAL
KERN_EMERG Returing error in INTR
registration
DEBUG
AH: Assigning the secure flags for sav
:%p,sav
CRITICAL
KERN_EMERG Initialzing Wps module
DEBUG
ESP: Assigning the secure flags for
sav :%p skb:%p src:%x
dst:%x,sav,skb,ip->ip_src.s_addr,ip-
>ip_dst.s_addr
CRITICAL
%s:%d %s, __FILE__, __LINE__,
__func__
DEBUG
%s Buffer %d mtu %d path mtu %d
header %d trailer
%d,__func__,bufMgrLen(pBufMgr),mtu
,dst_mtu(pDst->path),pDst-
>header_len,pDst->trailer_len
CRITICAL
Unified Services Router User Manual
213
Appendix E. RJ-45 Pin-outs
Signal
RJ-45
Cable
Adapter
Signal
RJ-45 PIN
DB-9 PIN
CTS
NC
NC
NC
DTR
NC
NC
NC
TxD
6
3
RxD
GND
5
5
GND
GND
4
5
GND
RxD
3
2
TxD
DSR
NC
NC
NC
RTS
NC
NC
NC
Unified Services Router User Manual
214
Appendix F. Product Statement
1. DSR-1000N
Federal Communications Commission (FCC) Compliance Notice: Radio Frequency Notice
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 20 centimeters between the
radiator and your body.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference that may cause
undesired operation.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
The antennas used for this transmitter must be installed to provide a spectrum distance of at least 20cm
from all persons and must not be co-located or operating in conjunction with any other antenna or
transmitter.
This transmitter is restricted to indoor use in the 5150MHz to 5250MHz frequency range.
Non-modification Statement
Use only the integral antenna supplied by the manufacturer when operating this device. Unauthorized
antennas, modifications, or attachments could damage the TI Navigator access point and violate FCC
regulations. Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
Canadian Department of Communications Industry Canada (IC) Notice
This Class B digital apparatus complies with Canadian ICES-003 and RSS-210. Cet appareil numérique de
la classe B est conforme à la norme NMB-003 et CNR-210 du Canada.
ndustry Canada Statement
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two
conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference that may cause
undesired operation.
Unified Services Router User Manual
215
IMPORTANT NOTE: Radiation Exposure Statement
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. End
users must follow the specific operating instructions for satisfying RF exposure compliance. To maintain
compliance with IC RF exposure compliance requirements, please follow operation instruction as
documented in this manual.
This transmitter is restricted to indoor use in the 5150MHz to 5250MHz frequency range.
Europe – EU Declaration of Conformity
This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The following
test methods have been applied in order to prove presumption of conformity with the essential requirements
of the R&TTE Directive 1999/5/EC:
- EN 60950-1: 2006+A11:2009
Safety of information technology equipment
- EN 300 328 V1.7.1 (2006-10)
Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband transmission systems; Data
transmission equipment operating in the 2,4 GHz ISM band and using wide band modulation techniques;
Harmonized EN covering essential requirements under article 3.2 of the R&TTE Directive
- EN 301 893-1 V1.5.1 (2008-12)
Broadband Radio Access Networks (BRAN); 5 GHz high performance RLAN; Harmonized EN covering
essential requirements of article 3.2 of the R&TTE Directive
- EN 301 489-17 V1.3.2 (2008-04) and EN 301 489-1 V1.8.1 (2008-04)
Electromagnetic compatibility and Radio spectrum Matters (ERM); Electro Magnetic Compatibility (EMC)
standard for radio equipment and services; Part 17: Specific conditions for 2,4 GHz wideband transmission
systems and 5 GHz high performance RLAN equipment
This device is a 2.4 GHz wideband transmission system (transceiver), intended for use in all EU member
states and EFTA countries under the following conditions and/or with the following restrictions:
- In Italy the end-user should apply for a license at the national spectrum authorities in order to obtain
authorization to use the device for setting up outdoor radio links and/or for supplying public access to
telecommunications and/or network services.
- This device may not be used for setting up outdoor radio links in France and in some areas the RF output
power may be limited to 10 mW EIRP in the frequency range of 2454 – 2483.5 MHz. For detailed
information the enduser should contact the national spectrum authority in France.
This device is a 5 GHz wideband transmission system (transceiver), intended for use in all EU member
states and EFTA countries under the following conditions and/or with the following restrictions:
- This device may only be used indoors in the frequency bands 5150 – 5250 MHz.
- In France and Luxembourg a limited implementation of the frequency bands 5150 – 5250 MHz and 5250 –
5350 MHz. In Luxermbourg it is not allowed to make use of the frequency band 5470 – 5725 MHz. End-
users are encouraged to contact the national spectrum authorities in France and Luxembourg in order to
obtain the latest information about any restrictions in the 5 GHz frequency band(s).
Unified Services Router User Manual
216
Česky
[Czech]
[D-Link Corporation] tímto prohlašuje, že tento [DSR-1000N] je ve shodě se základními
požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES.
Dansk
[Danish]
Undertegnede [D-Link Corporation] erklærer herved, at følgende udstyr [DSR-1000N]
overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
Deutsch
[German]
Hiermit erklärt [D-Link Corporation], dass sich das Gerät [DSR-1000N] in
Übereinstimmung mit den grundlegenden Anforderungen und den übrigen einschlägigen
Bestimmungen der Richtlinie 1999/5/EG befindet.
Eesti
[Estonian]
Käesolevaga kinnitab [D-Link Corporation] seadme [DSR-1000N] vastavust direktiivi
1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele
sätetele.
English
Hereby, [D-Link Corporation], declares that this [DSR-1000N] is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
Español
[Spanish]
Por medio de la presente [D-Link Corporation] declara que el [DSR-1000N] cumple con
los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la
Directiva 1999/5/CE.
Ελληνική
[Greek]
ΜΕ ΣΗΝ ΠΑΡΟΤ΢Α [D-Link Corporation] ΔΗΛΩΝΕΙ ΟΣΙ [DSR-1000N]
΢ΤΜΜΟΡΦΩΝΕΣΑΙ ΠΡΟ΢ ΣΙ΢ ΟΤ΢ΙΩΔΕΙ΢ ΑΠΑΙΣΗ΢ΕΙ΢ ΚΑΙ ΣΙ΢ ΛΟΙΠΕ΢ ΢ΥΕΣΙΚΕ΢
ΔΙΑΣΑΞΕΙ΢ ΣΗ΢ ΟΔΗΓΙΑ΢ 1999/5/ΕΚ.
Français
[French]
Par la présente [D-Link Corporation] déclare que l'appareil [DSR-1000N] est conforme
aux exigences essentielles et aux autres dispositions pertinentes de la directive
1999/5/CE.
Italiano
[Italian]
Con la presente [D-Link Corporation] dichiara che questo [DSR-1000N] è conforme ai
requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
Latviski
[Latvian]
Ar šo [D-Link Corporation] deklarē, ka [DSR-1000N] atbilst Direktīvas 1999/5/EK
būtiskajām prasībām un citiem ar to saistītajiem noteikumiem.
Lietuvių
[Lithuanian]
Šiuo [D-Link Corporation] deklaruoja, kad šis [DSR-1000N] atitinka esminius reikalavimus
ir kitas 1999/5/EB Direktyvos nuostatas.
Nederlands
[Dutch]
Hierbij verklaart [D-Link Corporation] dat het toestel [DSR-1000N] in overeenstemming is
met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG.
Malti
[Maltese]
Hawnhekk, [D-Link Corporation], jiddikjara li dan [DSR-1000N] jikkonforma mal-ħtiġijiet
essenzjali u ma provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC.
Magyar
[Hungarian]
Alulírott, [D-Link Corporation] nyilatkozom, hogy a [DSR-1000N] megfelel a vonatkozó
alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
Polski
[Polish]
Niniejszym [D-Link Corporation] oświadcza, że [DSR-1000N] jest zgodny z zasadniczymi
wymogami oraz pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC.
Unified Services Router User Manual
217
Português
[Portuguese]
[D-Link Corporation] declara que este [DSR-1000N]está conforme com os requisitos
essenciais e outras disposições da Directiva 1999/5/CE.
Slovensko
[Slovenian]
[D-Link Corporation] izjavlja, da je ta [DSR-1000N] v skladu z bistvenimi zahtevami in
ostalimi relevantnimi določili direktive 1999/5/ES.
Slovensky
[Slovak]
[D-Link Corporation] týmto vyhlasuje, že [DSR-1000N] spĺňa základné požiadavky a
všetky príslušné ustanovenia Smernice 1999/5/ES.
Suomi
[Finnish]
[D-Link Corporation] vakuuttaa täten että [DSR-1000N] tyyppinen laite on direktiivin
1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.
Svenska
[Swedish]
Härmed intygar [D-Link Corporation] att denna [DSR-1000N] står I överensstämmelse
med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av
direktiv 1999/5/EG.
Unified Services Router User Manual
218
2.DSR-500N
Federal Communications Commission (FCC) Compliance Notice: Radio Frequency Notice
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 20 centimeters between the
radiator and your body.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference that may cause
undesired operation.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
The antennas used for this transmitter must be installed to provide a spectrum distance of at least 20cm
from all persons and must not be co-located or operating in conjunction with any other antenna or
transmitter.
This transmitter is restricted to indoor use in the 5150MHz to 5250MHz frequency range.
Non-modification Statement
Use only the integral antenna supplied by the manufacturer when operating this device. Unauthorized
antennas, modifications, or attachments could damage the TI Navigator access point and violate FCC
regulations. Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
Canadian Department of Communications Industry Canada (IC) Notice
This Class B digital apparatus complies with Canadian ICES-003 and RSS-210. Cet appareil numérique de
la classe B est conforme à la norme NMB-003 et CNR-210 du Canada.
Industry Canada Statement
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two
conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference that may cause
undesired operation.
IMPORTANT NOTE: Radiation Exposure Statement
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment.
End users must follow the specific operating instructions for satisfying RF exposure compliance.
To maintain compliance with IC RF exposure compliance requirements, please follow operation instruction
as documented in this manual.
Unified Services Router User Manual
219
Europe – EU Declaration of Conformity
This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The following
test methods have been applied in order to prove presumption of conformity with the essential requirements
of the R&TTE Directive 1999/5/EC:
- EN 60950-1: 2006+A11:2009
Safety of information technology equipment
- EN 300 328 V1.7.1 (2006-10)
Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband transmission systems; Data
transmission equipment operating in the 2,4 GHz ISM band and using wide band modulation techniques;
Harmonized EN covering essential requirements under article 3.2 of the R&TTE Directive
- EN 301 489-17 V1.3.2 (2008-04) and EN 301 489-1 V1.8.1 (2008-04)
Electromagnetic compatibility and Radio spectrum Matters (ERM); Electro Magnetic Compatibility (EMC)
standard for radio equipment and services; Part 17: Specific conditions for 2,4 GHz wideband transmission
systems and 5 GHz high performance RLAN equipment
This device is a 2.4 GHz wideband transmission system (transceiver), intended for use in all EU member
states and EFTA countries under the following conditions and/or with the following restrictions:
- In Italy the end-user should apply for a license at the national spectrum authorities in order to obtain authorization
to use the device for setting up outdoor radio links and/or for supplying public access to telecommunications and/or
network services.
- This device may not be used for setting up outdoor radio links in France and in some areas the RF output
power may be limited to 10 mW EIRP in the frequency range of 2454 – 2483.5 MHz. For detailed information the
enduser should contact the national spectrum authority in France.
Unified Services Router User Manual
220
Česky
[Czech]
[D-Link Corporation] tímto prohlašuje, že tento [DSR-500N] je ve shodě se základními
požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES.
Dansk
[Danish]
Undertegnede [D-Link Corporation] erklærer herved, at følgende udstyr [DSR-500N]
overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
Deutsch
[German]
Hiermit erklärt [D-Link Corporation], dass sich das Gerät [DSR-500N] in Übereinstimmung
mit den grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der
Richtlinie 1999/5/EG befindet.
Eesti
[Estonian]
Käesolevaga kinnitab [D-Link Corporation] seadme [DSR-500N] vastavust direktiivi
1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele
sätetele.
English
Hereby, [D-Link Corporation], declares that this [DSR-500N] is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
Español
[Spanish]
Por medio de la presente [D-Link Corporation] declara que el [DSR-500N] cumple con los
requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la
Directiva 1999/5/CE.
Ελληνική
[Greek]
ΜΕ ΣΗΝ ΠΑΡΟΤ΢Α [D-Link Corporation] ΔΗΛΩΝΕΙ ΟΣΙ [DSR-500N] ΢ΤΜΜΟΡΦΩΝΕΣΑΙ
ΠΡΟ΢ ΣΙ΢ ΟΤ΢ΙΩΔΕΙ΢ ΑΠΑΙΣΗ΢ΕΙ΢ ΚΑΙ ΣΙ΢ ΛΟΙΠΕ΢ ΢ΥΕΣΙΚΕ΢ ΔΙΑΣΑΞΕΙ΢ ΣΗ΢
ΟΔΗΓΙΑ΢ 1999/5/ΕΚ.
Français
[French]
Par la présente [D-Link Corporation] déclare que l'appareil [DSR-500N] est conforme aux
exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE.
Italiano
[Italian]
Con la presente [D-Link Corporation] dichiara che questo [DSR-500N] è conforme ai
requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
Latviski
[Latvian]
Ar šo [D-Link Corporation] deklarē, ka [DSR-500N] atbilst Direktīvas 1999/5/EK
būtiskajām prasībām un citiem ar to saistītajiem noteikumiem.
Lietuvių
[Lithuanian]
Šiuo [D-Link Corporation] deklaruoja, kad šis [DSR-500N] atitinka esminius reikalavimus
ir kitas 1999/5/EB Direktyvos nuostatas.
Nederlands
[Dutch]
Hierbij verklaart [D-Link Corporation] dat het toestel [DSR-500N] in overeenstemming is
met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG.
Malti
[Maltese]
Hawnhekk, [D-Link Corporation], jiddikjara li dan [DSR-500N] jikkonforma mal-ħtiġijiet
essenzjali u ma provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC.
Magyar
[Hungarian]
Alulírott, [D-Link Corporation] nyilatkozom, hogy a [DSR-500N] megfelel a vonatkozó
alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
Polski
[Polish]
Niniejszym [D-Link Corporation] oświadcza, że [DSR-500N] jest zgodny z zasadniczymi
wymogami oraz pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC.
Unified Services Router User Manual
221
Português
[Portuguese]
[D-Link Corporation] declara que este [DSR-500N]está conforme com os requisitos
essenciais e outras disposições da Directiva 1999/5/CE.
Slovensko
[Slovenian]
[D-Link Corporation] izjavlja, da je ta [DSR-500N] v skladu z bistvenimi zahtevami in
ostalimi relevantnimi določili direktive 1999/5/ES.
Slovensky
[Slovak]
[D-Link Corporation] týmto vyhlasuje, že [DSR-500N] spĺňa základné požiadavky a
všetky príslušné ustanovenia Smernice 1999/5/ES.
Suomi
[Finnish]
[D-Link Corporation] vakuuttaa täten että [DSR-500N] tyyppinen laite on direktiivin
1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.
Svenska
[Swedish]
Härmed intygar [D-Link Corporation] att denna [DSR-500N] står I överensstämmelse
med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av
direktiv 1999/5/EG.
Unified Services Router User Manual
222
3.DSR-250N
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution:
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
RSS-GEN 7.1.2:
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and
maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference
to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power
(e.i.r.p.) is not more than that necessary for successful communication.
RSS-GEN 7.1.3
You are cautioned that changes or modifications not expressly approved by the party responsible for 
compliance could void your authority to operate the equipment.
FCC RF Radiation Exposure Statement:
1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 
2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. 
This equipment should be installed and operated with a minimum distance of 20 centimeters between the 
radiator and your body.
This radio transmitter (identify the device by certification number, or model number if Category II) has been 
approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain and 
required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain 
greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the 
following two conditions: (1) this device may not cause interference, and (2) this device must accept any 
interference, including interference that may cause undesired operation of the device.
Unified Services Router User Manual
223
Regulatory statement (R&TTE)
European standards dictate maximum radiated transmit power of 100mW EIRP and frequency range 2.400-
2.4835GHz; In France, the equipment must be restricted to the 2.4465-2.4835GHz frequency range and
must be restricted to indoor use.
Operation of this device is subjected to the following National regulations and may be prohibited to use if
certain restriction should be applied.
D=0.020m is the minimum safety distance between the EUT and human body when the E-Field strength is
61V/m.
Is herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation
of the Laws of the Member States relating to Electromagnetic Compatibility (2004/108/EC), Low-voltage
Directive (2006/95/EC), the procedures given in European Council Directive 99/5/EC and 2004/104/EC.
The equipment was passed. The test was performed according to the following European standards:
EN 300 328 V.1.7.1
EN 301 489-1 V.1. 8.1 / EN 301 489-17 V.2.1.1
EN 62311
EN 60950-1

Navigation menu
