OEM regulatory notice
Calexico I (802.11b) Compliance Guidelines
Wireless Networking Division
Regulatory and Safety Notices
User Documentation Guidelines for OEMs and
Integrators
Calexico I (802.11b)
Note: Due to the evolving state of regulations and standards in the wireless LAN field
(IEEE 802.11 and similar), the information provided herein is subject to change. Intel
Corporation assumes no responsibility for errors or omissions in this document. Nor
does Intel make any commitment to update the information contained herein.
Created: 09/25/02
Last Updated: 01/24/03
Page 1 1/24/2003
Calexico I (802.11b) Compliance Guidelines
Revision History
Date Changes
09/25/02 Created document
10/03/02 Corrected errors in document, added 3 additional Mini PCI models,
genericized product references to refer to “LAN Mini PCI Adapters”
10/08/02 Added Annex II under 1999/5/EC for 2.4 GHz products (PS)
12/18/02 Added “Information for the OEM” page 1 and additional text for
OEM integrators page 4 (TL)
12/20/02 Added End Product Label: FCC ID “XXXXXXXX’ info.
01/20/03 Renamed document to emphasize “guidelines”; added “purpose of
document” text; removed dual-band product models and
information; added notified body numbers; updated information for
France, Belgium, and the Netherlands; deleted all country/regional
coverage for which information has not become available
(exceptions are FCC, Canada, Europe); added copyright,
disclaimer, and trademark information.
01/24/03 Added additional disclaimer text to emphasize provisional nature of
document.
Copyright © 2003, Intel Corporation. All rights reserved.
Disclaimer: If this pre-release document is supplied under the terms of a non-disclosure agreement with Intel Corporation, it
may not be copied or disclosed except in accordance with the terms of that agreement.
Intel Corporation assumes no responsibility for errors or omissions in this document. Nor does Intel make any commitment
to update the information contained herein.
Intel is a registered trademark of Intel Corporation. Other product and corporate names may be trademarks of other
companies and are used only for explanation and to the owners' benefit, without intent to infringe.
Page 2 1/24/2003
Calexico I (802.11b) Compliance Guidelines
Intel® PRO/Wireless LAN 2100 Mini PCI Adapters
Safety and Regulatory Notices
User Documentation Guidelines for OEMs and Integrators
Purpose of This Document
This document is provided for the information of original equipment manufacturers (OEMs), system
integrators, and others who manufacture and distribute systems or products that incorporate a version of
the Intel PRO/Wireless LAN 2100 (single-band) Mini PCI adapter. The purpose of the document is to
provide safety and regulatory information pertaining to the Intel products of reference and guidance as to
what information must be communicated by the OEM/integrator to the end user of the products. As new
approval information becomes available over the course of the worldwide approvals process, additional
guidelines will be developed as required.
Note: This document should not be distributed directly to end users of the Intel products of reference. The
format and content of the regulatory information supplied to the end user is the responsibility of the OEM
or integrator, and not of Intel.
The information in this document applies to the following products:
Single-band wireless LAN adapters (802.11b only)
Intel® PRO/Wireless LAN 2100 3B Mini PCI Adapter (model WM3B2100)
Intel® PRO/Wireless LAN 2100 3A Mini PCI Adapter (model WM3A2100)
Information for OEMs and Integrators
The following statement must be included with all versions of this document supplied to an OEM or
integrator, but should not be distributed to the end user.
• This device is intended for OEM integrators only.
• This device cannot be co-located with any other transmitter.
• Please refer to the full Grant of Equipment document for other restrictions.
This device is intended for OEM integrators only.
This device cannot be co-located with any other transmitter.
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna and users. For
laptop installations, the antenna must be installed to ensure that the proper spacing is maintained in the
event the users places the device in their lap during use (i.e. positioning of antennas must be placed in
the upper portion of the LCD panel only to ensure 20 cm will be maintained if the user places the device
in their lap for use) and
2) The transmitter module may not be co-located with any other transmitter or antenna.
As long as the 2 conditions above are met, further transmitter testing will not be required. However, the
OEM integrator is still responsible for testing their end-product for any additional compliance requirements
required with this module installed (for example, digital device emissions, PC peripheral requirements,
etc.).
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop
configurations or co-location with another transmitter), then the FCC authorization is no longer considered
valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator
will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate
FCC authorization.
Page 3 1/24/2003
End Product Labeling
Calexico I (802.11b) Compliance Guidelines
This transmitter module is authorized only for use in devices where the antenna may be installed such
that 20 cm may be maintained between the antenna and users (for example access points, routers,
wireless ASDL modems, certain laptop configurations, and similar equipment). The final end product
must be labeled in a visible area with the following: "Contains TX FCC ID: XXXXXXXXXXXXXXX," where
XXXXXXXXXXXXXXX is replaced by the FCC ID on the module being integrated.
RF Exposure Manual Information That Must be Included
The users manual for end users must include the following information in a prominent location
"IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for
this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and
must not be co-located or operating in conjunction with any other antenna or transmitter."
Additional Information That Must be Provided to OEM Integrators
The end user should NOT be provided any instructions on how to remove or install the device.
Information to Be Supplied to the End User by the OEM or Integrator
The following regulatory and safety notices must be published in documentation supplied to the end user
of the product or system incorporating an Intel® PRO/Wireless 2100 LAN Mini PCI Adapter in compliance
with local regulations.
USA and Canada Safety Requirements and Notices
The FCC with its action in ET Docket 96-8 for spread-spectrum and 93-62 is for human exposure to radio
frequency (RF) electromagnetic energy emitted by FCC certified equipment. The Intel PRO/Wireless LAN
Mini PCI Adapter products meet the Human Exposure limits found in OET Bulletin 65, 2001, and
ANSI/IEEE C95.1, 1992. Proper operation of this radio according to the instructions found in this manual
will result in exposure substantially below the FCC’s recommended limits.
The following safety precautions should be observed:
• Do not touch or move antenna while the unit is transmitting or receiving.
• Do not hold any component containing the radio such that the antenna is very close or touching any
exposed parts of the body, especially the face or eyes, while transmitting.
• Do not operate the radio or attempt to transmit data unless the antenna is connected; if not, the radio
may be damaged.
• Use in specific environments:
o The use of wireless devices in hazardous locations is limited by the constraints posed by the safety
directors of such environments.
o The use of wireless devices on airplanes is governed by the Federal Aviation Administration (FAA).
o The use of wireless devices in hospitals is restricted to the limits set forth by each hospital.
• Antenna use:
o In order to comply with FCC RF exposure limits, low gain integrated antennas should be located at
a minimum distance of 20 cm (8 inches) or more from the body of all persons.
o High-gain, wall-mount, or mast-mount antennas are designed to be professionally installed and
should be located at a minimum distance of 30 cm (12 inches) or more from the body of all persons.
Please contact your professional installer, VAR, or antenna manufacturer for proper installation
requirements.
Explosive Device Proximity Warning
Warning: Do not operate a portable transmitter (such as a wireless network device) near unshielded
blasting caps or in an explosive environment unless the device has been modified to be qualified for such
use.
Antenna Warning
Warning: To comply with the FCC and ANSI C95.1 RF exposure limits, it is recommended for Intel(R)
PRO/Wireless LAN Mini PCI Adapters installed in a desktop or portable computer, that the antenna for
this device be installed so as to provide a separation distance of al least 20 cm (8 inches) from all
persons and that the antenna must not be co-located or operating in conjunction with any other antenna
or radio transmitter. It is recommended that the user limit exposure time if the antenna is positioned closer
than 20 cm (8 inches).
Use On Aircraft Caution
Page 4 1/24/2003
Calexico I (802.11b) Compliance Guidelines
Caution: Regulations of the FCC and FAA prohibit airborne operation of radio-frequency wireless devices
because their signals could interfere with critical aircraft instruments.
Other Wireless Devices
Safety Notices for Other Devices in the Wireless Network: Refer to the documentation supplied with
wireless Ethernet adapters or other devices in the wireless network.
USA Radio Frequency Interference Requirements
FCC Regulations Part 15 Declaration of Conformity (DoC)
Intel Corporation declares that the equipment described in this document is within the requirements of the
Code of Federal Regulations listed below:
Title 47 Part 15, Subpart B, Class B for a digital device.
This declaration is based upon the compliance of the Intel(R) PRO/Wireless LAN Mini PCI Adapters to the
above standards. Intel has determined that the models listed have been shown to comply with the
applicable technical standards if no unauthorized change is made in the equipment and if the equipment
is properly maintained and operated.
These units are identical to the units tested and found acceptable with the applicable standards. Records
maintained by Intel continue to reflect that units being produced under this Declaration of Conformity,
within the variation that can be expected due to quantity production and tested on a statistical basis,
continue to comply with the applicable technical standards.
FCC Rules and Regulations - Part 15
This device uses, generates and radiates radio frequency energy. The radio frequency energy produced
by this device is well below the maximum exposure allowed by the Federal Communications Commission
(FCC).
This device complies with the limits for a Class B digital device pursuant to Part 15 subpart C of the FCC
Rules and Regulations. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired
operation.
The FCC limits are designed to provide reasonable protection against harmful interference when the
equipment is installed and used in accordance with the instruction manual and operated in a commercial
environment. However, there is no guarantee that interference will not occur in a particular commercial
installation, or if operated in a residential area.
If harmful interference with radio or television reception occurs when the device is turned on, the user
must correct the situation at the user’s own expense. The user is encouraged to try one or more of the
following corrective measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that on which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION: The Part 15 radio device operates on a non-interference basis with other devices operating at
this frequency. Any changes or modification to said product not expressly approved by Intel could void the
user's authority to operate this device.
Canada
Canada Radio Frequency Interference Requirements
This Class B digital apparatus complies with Canadian ICES-003, Issue 2, and RSS-210, Issue 4 (Dec.
2000).
“To prevent radio interference to the licensed service, this device is intended to be operated indoors and
away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed
outdoors is subject to licensing.”
Cet appareil numérique de la classe B est conforme à la norme NMB-003, No. 2, et CNR-210, No. 4
(Dec. 2000).
« Pour empêcher que cet appareil cause du brouillage au service faisant l'objet d'une licence, il doit être
utilisé à l'intérieur et devrait être placé loin des fenêtres afin de fournir un écran de blindage maximal. Si
le matériel (ou son antenne d'émission) est installé à l'extérieur, il doit faire l'objet d'une licence. »
Page 5 1/24/2003
Calexico I (802.11b) Compliance Guidelines
European Union CE Marking and Compliance Notices
Products intended for sale within the European Union are marked with the Conformité Européene (CE)
Marking, which indicates compliance with the applicable Directives and European standards and
amendments identified below. This equipment also carries the Class 2 identifier.
Declaration of Conformity (Mini PCI Adapter)
[Declaration to be supplied]
Product Descriptions:
Intel® PRO/Wireless LAN 2100 3B Mini PCI Adapter (model WM3B2100)
Intel® PRO/Wireless LAN 2100 3A Mini PCI Adapter (model WM3A2100)
Warning: See 802.11b restrictions for specific countries or regions within countries under the heading
“European Economic Area Restrictions” below.
Translated Statements of Compliance
[English]
This product follows the provisions of the European Directive 1999/5/EC.
[Danish]
Dette produkt er i overensstemmelse med det europæiske direktiv 1999/5/EC
[Dutch]
Dit product is in navolging van de bepalingen van Europees Directief 1999/5/EC.
[Finnish]
Tämä tuote noudattaa EU-direktiivin 1999/5/EC määräyksiä.
[French]
Ce produit est conforme aux exigences de la Directive Européenne 1999/5/EC.
[German]
Dieses Produkt entspricht den Bestimmungen der Europäischen Richtlinie 1999/5/EC
[Greek]
Το προϊόν αυτό πληροί τις προβλέψεις της Ευρωπαϊκής Οδηγίας 1999/5/ΕC.
[Icelandic]
Þessi vara stenst reglugerð Evrópska Efnahags Bandalagsins númer 1999/5/EC
[Italian]
Questo prodotto è conforme alla Direttiva Europea 1999/5/EC.
[Norwegian]
Dette produktet er i henhold til bestemmelsene i det europeiske direktivet 1999/5/EC.
[Portuguese]
Este produto cumpre com as normas da Diretiva Européia 1999/5/EC.
[Spanish]
Este producto cumple con las normas del Directivo Europeo 1999/5/EC.
[Swedish]
Denna produkt har tillverkats i enlighet med EG-direktiv 1999/5/EC.
European Economic Area Restrictions
Local Restriction of 802.11b Radio Usage
[Note to integrator: The following statements on local restrictions must be published in all end-user
documentation provided with the system or product incorporating the Intel PRO/Wireless 2100 Wireless
LAN (802.11b) product.]
Caution: Due to the fact that the frequencies used by 802.11b wireless LAN devices may not yet be
harmonized in all countries, 802.11b products are designed for use only in specific countries or regions,
and are not allowed to be operated in countries or regions other than those of designated use. As a user
of these products, you are responsible for ensuring that the products are used only in the countries or
regions for which they were intended and for verifying that they are configured with the correct selection
of frequency and channel for the country or region of use. Any deviation from permissible settings and
Page 6 1/24/2003
Calexico I (802.11b) Compliance Guidelines
restrictions in the country or region of use could be an infringement of local law and may be punished as
such.
The European variant is intended for use throughout the European Economic Area. However,
authorization for use is further restricted in particular countries or regions within countries, as follows:
Local Restrictions on 802.11b Radio Usage
General
European standards dictate maximum radiated transmit power of 100mW effective isotropic radiated
power (EIRP) and the frequency range 2400 – 2483.5 MHz.
Belgium and the Netherlands
In Belgium and the Netherlands, the product may not be used outdoors. See the instructions below under
the heading “How to Turn Off the Wireless LAN Radio.”
France
Note: At the time of publication of this document, operation of Intel® PRO/Wireless 2100 LAN Mini PCI
Adapters in France was restricted to indoor use only and was allowable in only 38 specific regional
“départements” due to local restrictions on transmission power and frequencies. The 38 departments in
which the Intel adapter can currently be used are listed below. Since it is likely that additional permitted
departments will be added to the list at regular intervals, visit the website of the French Authority for
Regulation of Telecommunications (ART) for updated information, in French at http://www.art-
telecom.fr/ or in English at http//www.art-telecom.fr/eng/
Departments in Which the Intel Wireless LAN Mini PCI Adapter Can Be Used (Indoors Only)
The Intel® PRO/Wireless 2100 LAN Mini PCI Adapter can currently be used indoors only in the following
38 departments of mainland France.
01 Ain Orientales 36 Indre 66 Pyrénées
02 Aisne 37 Indre et Loire 67 Bas Rhin
03 Allier 41 Loir et Cher 68 Haut Rhin
05 Hautes Alpes 42 Loire 70 Haute Saône
08 Ardennes 45 Loiret 71 Saône et Loire
09 Ariège 50 Manche 75 Paris
11 Aude 55 Meuse 82 Tarn et Garonne
12 Aveyron 58 Nièvre 84 Vaucluse
16 Charente 59 Nord 88 Vosges
24 Dordogne 60 Oise 89 Yonne
25 Doubs 61 Orne 90 Territoire de Belfort
26 Drôme 63 Puy du Dôme 94 Val de Marne
32 Gers 64 Pyrénées Atlantique
Departments in Which the Intel Wireless LAN Mini PCI Adapter Cannot Be Used
The Intel® PRO/Wireless 2100 LAN Mini PCI Adapter cannot currently be used in any departments of
mainland France other than the 38 listed above. See the heading “How to Turn Off the Wireless LAN
Radio” for the procedures to be followed when operating your computer device or system in departments
not listed above.
Page 7 1/24/2003
Calexico I (802.11b) Compliance Guidelines
Maximum EIRP for use of 802.11b wireless LAN cards in the mainland departments of France not
shown in the table above (see the ART website at www.art-telecom.fr for information on the
French overseas territories)
Frequency Ranges (MHz) Indoors Outdoors
2400 – 2446.5 10 mW Not permitted
2446.5 – 2483.5 100 mW 100 mW on private
property with Ministry
of Defense approval
[Note to integrator: In the documentation provided to the end user, the OEM or integrator must specify
the maximum EIRP of the system (including antenna) so that the user can compare the EIRP of the
system to the limits stated in the table above.]
How to turn off the wireless LAN radio
Note: Turning the wireless LAN radio off is not the same as disabling the wireless LAN card. It is not
necessary to disable the card to meet the regulatory requirements.
While operating the computer or system incorporating the Intel® PRO/Wireless 2100 LAN Mini PCI in
those French departments that do not allow use of the wireless LAN equipment, the user of the
equipment must turn off the wireless LAN radio in order to comply with local regulations. Instructions on
how to do this are provided in this document under the heading “How to Turn Off the Wireless LAN
Radio.”
[Note to integrator: The following instructions must be published in all end-user documentation provided
with the system or product incorporating the Intel PRO/Wireless 2100 Wireless LAN (802.11b) products.
The instructions be matched to the features of the computer or system to which they below.]
How to turn off the WLAN radio using software
If Intel® PROSet is installed
[Note to integrator: If Intel PROSet utility software is installed on the system or computer incorporating
the Intel® PRO/Wireless 2100 LAN Mini PCI Adapter, the OEM or integrator must supply the end user
with OS-appropriate instructions on how use Intel PROSet to turn off the Intel wireless LAN card in
restricted countries or regions, either as part of the documentation containing wireless LAN regulatory
guidelines or by referral to system documentation containing the required instructions. The procedure for
turning off the wireless LAN radio in restricted regions must be described clearly step by step so that the
end user can easily comply with the regulatory requirements. See an outline of the procedure below.]
To turn off the wireless LAN radio using Intel PROSet:
1. Right-click the Intel(R) PRO/Wireless card icon in the system tray
2. Select the active Intel adapter and click Switch Radio Off.
You can also turn off the radio on the General tab of the Intel PROSet screen, by selecting Off next to
Switch radio.
If Intel PROSet is not installed
[Note to integrator: If Intel PROSet configuration software is not installed on the system or computer
incorporating the Intel® PRO/Wireless 2100 LAN Mini PCI Adapter, the OEM or integrator must supply
the end user with OS-appropriate instructions on how to use the Control Panel to turn off the Intel
wireless LAN radio in restricted countries or regions, either as part of the documentation containing
wireless LAN regulatory guidelines or by referral to system documentation containing the required
instructions. The procedure for turning off the wireless LAN radio in restricted regions must be described
clearly step by step so that the end user can easily comply with the regulatory requirements. See an
outline of the procedure below.]
To turn off the wireless LAN radio using the Control Panel:
1. Access the Control Panel and double-click the System icon.
Page 8 1/24/2003
Calexico I (802.11b) Compliance Guidelines
Page 9 1/24/2003
2. Go to Device Manager under Hardware and expand the list of Network Adapters.
3. Double-click the Intel PRO/Wireless Mini PCI LAN Adapter and select the Advanced tab.
4. On the Advanced tab, check the Wireless device off (radio off) check box, and click OK.
How to turn off the WLAN radio using a hardware switch (if supplied)
[Note to integrator: If the system or computer incorporating the Intel® PRO/Wireless 2100 LAN Mini PCI
Adapter has an external hardware switch that can be used to manually turn the wireless LAN card off and
on, the OEM or integrator must supply the end user with instructions on how to use this switch, either as
part of the documentation containing wireless LAN regulatory guidelines or by referral to system
documentation containing the required instructions. The procedure for manually turning off the wireless
LAN radio in restricted regions must be described clearly step by step so that the end user can easily
comply with local regulatory requirements.]
