Regulatory Information: Intel(R) PRO/Wireless LAN
3A Mini PCI Adapter User's Guide
Information For the User
Regulatory Information
Information for the user
Safety Notices
The FCC with its action in ET Docket 96-8 has adopted a safety standard for human exposure to
radio frequency (RF) electromagnetic energy emitted by FCC certified equipment. The Intel(R)
PRO/Wireless 2100 LAN 3A Mini PCI Adapter meets the Human Exposure limits found in OET
Bulletin 65, 2001, and ANSI/IEEE C95.1, 1992. Proper operation of this radio according to the
instructions found in this manual will result in exposure substantially below the FCC’s
recommended limits.
The following safety precautions should be observed:
• Do not touch or move antenna while the unit is transmitting or receiving.
• Do not hold any component containing the radio such that the antenna is very close or
touching any exposed parts of the body, especially the face or eyes, while transmitting.
• Do not operate the radio or attempt to transmit data unless the antenna is connected; if
not, the radio may be damaged.
• Use in specific environments:
o The use of wireless devices in hazardous locations is limited by the constraints
posed by the safety directors of such environments.
o The use of wireless devices on airplanes is governed by the Federal Aviation
Administration (FAA).
o The use of wireless devices in hospitals is restricted to the limits set forth by each
hospital.
• Antenna use:
o In order to comply with FCC RF exposure limits, low gain integrated antennas
should be located at a minimum distance of 2 cm or more from the body of all
persons.
o High-gain, wall-mount, or mast-mount antennas are designed to be
professionally installed and should be located at a minimum distance of 30 cm
(12 inches) or more from the body of all persons. Please contact your
professional installer, VAR, or antenna manufacturer for proper installation
requirements.
• Explosive Device Proximity Warning (see below)
• Antenna Warning (see below)
• Use on Aircraft Caution (see below)
• Other Wireless Devices (see below)
• Power Supply (Access Point) (see below)
Explosive Device Proximity Warning
Warning: Do not operate a portable transmitter (such as a wireless network device) near
unshielded blasting caps or in an explosive environment unless the device has been modified to
be qualified for such use.
Antenna Warnings
Warning: To comply with the FCC and ANSI C95.1 RF exposure limits, it is recommended
for the Intel(R) PRO/Wireless LAN 2100 3A Mini PCI Adapter installed in a desktop or portable
computer, that the antenna for this device be installed so as to provide a separation distance of al
least 2 cm from all persons and that the antenna must not be co-located or operating in
conjunction with any other antenna or radio transmitter. It is recommended that the user limit
exposure time if the antenna is positioned closer than 2 cm.
Warning: Intel(R) PRO/Wireless LAN products are not designed for use with high-gain
directional antennas. Use of such antennas with these products is illegal.
Use On Aircraft Caution
Caution: Regulations of the FCC and FAA prohibit airborne operation of radio-frequency
wireless devices because their signals could interfere with critical aircraft instruments.
Other Wireless Devices
Safety Notices for Other Devices in the Wireless Network: Refer to the documentation
supplied with wireless Ethernet adapters or other devices in the wireless network.
Local Restrictions on 802.11a and 802.11b Radio Usage
Caution: Due to the fact that the frequencies used by 802.11a and 802.11b wireless LAN
devices may not yet be harmonized in all countries, 802.11a and 802.11b products are designed
for use only in specific countries, and are not allowed to be operated in countries other than those
of designated use. As a user of these products, you are responsible for ensuring that the products
are used only in the countries for which they were intended and for verifying that they are
configured with the correct selection of frequency and channel for the country of use. Any
deviation from the permissible settings for the country of use is an infringement of national law
and may be punished as such.
For country-specific information, see the additional compliance information supplied with the
product.
Wireless interoperability
The Intel(R) PRO/Wireless 2100 LAN 3A Mini PCI adapter is designed to be interoperable with
any wireless LAN product that is based on direct sequence spread spectrum (DSSS) radio
technology and to comply with the following standards:
• IEEE Std. 802.1b-1999. Standard on Wireless LAN.
• Wireless Fidelity (WiFi) certification, as defined by the WECA (Wireless Ethernet
Compatibility Alliance).
The Intel(R) PRO/Wireless 2100 LAN 3A Mini PCI adapter and your health
The Intel(R) PRO/Wireless 2100 LAN 3A Mini PCI adapter, like other radio devices, emits radio
frequency electromagnetic energy. The level of energy emitted by this device, however, is less
than the electromagnetic energy emitted by other wireless devices such as mobile phones. The
Intel(R) PRO/Wireless 2100 LAN 3A Mini PCI adapter wireless device operates within the
guidelines found in radio frequency safety standards and recommendations. These standards
and recommendations reflect the consensus of the scientific community and result from
deliberations of panels and committees of scientists who continually review and interpret the
extensive research literature. In some situations or environments, the use of the Intel(R)
PRO/Wireless 2100 LAN 3A Mini PCI adapter wireless device may be restricted by the proprietor
of the building or responsible representatives of the applicable organization. Examples of such
situations include the following:
• Using the Intel(R) PRO/Wireless 2100 LAN 3A Mini PCI adapter equipment on board
airplanes, or
• Using the Intel(R) PRO/Wireless 2100 LAN 3A Mini PCI adapter equipment in any other
environment where the risk of interference with other devices or services is perceived or
identified as being harmful.
If you are uncertain of the policy that applies to the use of wireless devices in a specific
organization or environment (an airport, for example), you are encouraged to ask for authorization
to use the Intel(R) PRO/Wireless 2100 LAN 3A Mini PCI adapter wireless device before you turn
it on.
Regulatory information
This device is intended for OEM integrators only.
This device cannot be co-located with any other transmitter.
Information for the OEM Integrators: Please refer to the full Grant of equipment document
for other restrictions.
The Intel(R) PRO/Wireless 2100 LAN 3A Mini PCI adapter wireless network device must be
installed and used in strict accordance with the manufacturer's instructions as described in the
user documentation that comes with the product. For country-specific approvals, see Radio
approvals. Dell Computer Corporation is not responsible for any radio or television interference
caused by unauthorized modification of the devices included with the Intel(R) PRO/Wireless 2100
LAN 3A Mini PCI adapter kit, or the substitution or attachment of connecting cables and
equipment other than that specified by Dell Computer Corporation. The correction of interference
caused by such unauthorized modification, substitution or attachment is the responsibility of the
user. Dell Computer Corporation and its authorized resellers or distributors are not liable for any
damage or violation of government regulations that may arise from the user failing to comply with
these guidelines.
NOTE—Your Intel(R) PRO/Wireless 2100 LAN 3A Mini PCI adapter
transmits less than 100 mW, but more than 10 mW.
USA—Federal Communications Commission (FCC)
This device complies with Part 15 of the FCC Rules. Operation of the device is
subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference that may cause undesired
operation.
NOTE—The radiated output power of the Intel(R) PRO/Wireless 2100 LAN 3A Mini PCI adapter
wireless network device is far below the FCC radio frequency exposure limits. Nevertheless, the
Intel(R) PRO/Wireless LAN wireless network device should be used in such a manner that the
potential for human contact during normal operation is minimized. To avoid the possibility of
exceeding the FCC radio frequency exposure limits, you should keep a distance of at least 2 cm
between you (or any other person in the vicinity) and the antenna that is built into the computer.
To determine the location of the antenna within your computer, check the information posted on
the general Dell support site at support.dell.com.
Interference statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy. If the equipment is not installed and used in accordance with
the instructions, the equipment may cause harmful interference to radio
communications. There is no guarantee, however, that such interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception (which can be determined by
turning the equipment off and on), the user is encouraged to try to correct the
interference by taking one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
NOTE—The Intel(R) PRO/Wireless 2100 LAN 3A Mini PCI adapter wireless network device
must be installed and used in strict accordance with the manufacturer's instructions as described
in the user documentation that comes with the product. Any other installation or use will violate
FCC Part 15 regulations and may void the operator’s right to operate the equipment.
Canada—Industry Canada (IC)
This device complies with RSS210 of Industry Canada.
Europe—EU Declaration of Conformity
This equipment complies with the essential requirements of the European
Union directive 1999/5/EC.
Cet équipement est conforme aux principales caractéristiques définies dans la
Directive européenne RTTE 1999/5/CE.
Die Geräte erfüllen die grundlegenden Anforderungen der RTTE-Richtlinie
1999/5/EG.
Questa apparecchiatura è conforme ai requisiti essenziali della Direttiva
Europea R&TTE 1999/5/CE.
Este equipo cumple los requisitos principales de la Directiva 1999/5/CE de la
UE, "Equipos de Terminales de Radio y Telecomunicaciones".
Este equipamento cumpre os requisitos essenciais da Directiva 1999/5/CE do
Parlamento Europeu e do Conselho (Directiva RTT).
O exoplismos autos plhroi tis basikes apaits ths koinotikhs odhgias EU R&TTE
1999/5/E.
Deze apparatuur voldoet aan de noodzakelijke vereisten van EU-richtlijn
betreffende radioapparatuur en telecommunicatie-eindapparatuur 1999/5/EG.
Dette udstyr opfylder de Væsentlige krav i EU's direktiv 1999/5/EC om Radio-
og teleterminaludstyr.
Dette utstyret er i overensstemmelse med hovedkravene i R&TTE-direktivet
(1999/5/EC) fra EU.
Utrustningen uppfyller kraven för EU-direktivet 1999/5/EC om ansluten
teleutrustning och ömsesidigt erkännande av utrustningens överensstämmelse
(R&TTE).
Tämä laite vastaa EU:n radio- ja telepäätelaitedirektiivin (EU R&TTE
Directive 1999/5/EC) vaatimuksia.
France
Some areas of France have a restricted frequency band. The worst case
maximum authorized power indoors is:
10 mW for the entire 2.4 GHz band (2400 MHz–2483.5 MHz)
100 mW for frequencies between 2446.5 MHz and 2483.5 MHz (NOTE—
Channels 10 through 13 inclusive operate in the band 2446.6 MHz to 2483.5
MHz)
There are few possibilities for outdoor use: On private property or on the
private property of public persons, use is subject to a preliminary authorization
procedure by the Ministry of Defence, with maximum authorized power of 100
mW in the 2446.5–2483.5 MHz band. Use outdoors on public property is not
permitted.
In the departments listed below, for the entire 2.4 GHz band:
• Maximum authorized power indoors is 100 mW
• Maximum authorized power outdoors is 10 mW
Departments in which the use of the 2400–2483.5 MHz band is permitted with
an EIRP of less than 100 mW indoors and less than 10 mW outdoors:
01 Ain Orientales 36 Indre 66 Pyrénées
02 Aisne 37 Indre et Loire 67 Bas Rhin
03 Allier 41 Loir et Cher 68 Haut Rhin
05 Hautes Alpes 42 Loire 70 Haute Saône
08 Ardennes 45 Loiret 71 Saône et Loire
09 Ariège 50 Manche 75 Paris
11 Aude 55 Meuse 82 Tarn et Garonne
12 Aveyron 58 Nièvre 84 Vaucluse
16 Charente 59 Nord 88 Vosges
24 Dordogne 60 Oise 89 Yonne
25 Doubs 61 Orne 90 Territoire de Belfort
26 Drôme 63 Puy du Dôme 94 Val de Marne
32 Gers 64 Pyrénées Atlantique
This requirement is likely to change over time, allowing to use your wireless
LAN card in more areas within France. Please check with ART for the latest
information (www.art-telecom.fr)
NOTE—Your Intel(R) PRO/Wireless 2100 LAN 3A Mini PCI adapter
transmits less than 100 mW, but more than 10 mW.
Italia A license is required for indoor use. Outdoor use is prohibited.
E' necessaria la concessione ministeriale anche per l'uso interno. Verificare con i
rivenditori la procedura da seguire. L'uso per installazione in esterni non e'
permessa.
Radio approvals
To determine whether you are allowed to use your wireless network device in a
specific country, please check to see if the radio type number that is printed on
the identification label of your device is listed on the radio approval list posted
on the general Dell support site at support.dell.com.
Please read all restrictions and disclaimers.
Back to Contents Page
