Regulatory Information

Back to Contents
Regulatory Information: Intel(R)
PRO/Wireless Network Connection
User's Guide
Intel(R) PRO/Wireless 2200BG Network
Connection
Intel(R) PRO/Wireless 2915ABG Network
Connection
Intel(R) PRO/Wireless 2915ABG Network Connection
Information for the User
Regulatory Information
Intel(R) PRO/Wireless 2200BG Network Connection
Information for the User
Regulatory Information
Intel(R) PRO/Wireless 2915ABG Network
Connection
The information in this document applies to the following products:
Tri-mode wireless LAN adapters (802.11a/802.11b/802.11g )
Intel(R) PRO/Wireless 2915ABG Network Connection (model
WM3B2915ABG)
Intel(R) PRO/Wireless 2915ABG Network Connection (model
WM3A2915ABG)
NOTE:Due to the evolving state of regulations and standards in
the wireless LAN field (IEEE 802.11 and similar standards),
the information provided herein is subject to change. Intel
Corporation assumes no responsibility for errors or
omissions in this document. Nor does Intel make any
commitment to update the information contained herein.
Information for the user
Safety Notices
The FCC with its action in ET Docket 96-8 has adopted a safety
standard for human exposure to radio frequency (RF) electromagnetic
energy emitted by FCC certified equipment. The Intel(R)
PRO/Wireless 2915ABG Network Connection adapter meets the
Human Exposure limits found in OET Bulletin 65, 2001, and
ANSI/IEEE C95.1, 1992. Proper operation of this radio according to
the instructions found in this manual will result in exposure
substantially below the FCC’s recommended limits.
The following safety precautions should be observed:
Do not touch or move antenna while the unit is transmitting or
receiving.
Do not hold any component containing the radio such that the
antenna is very close or touching any exposed parts of the
body, especially the face or eyes, while transmitting.
Do not operate the radio or attempt to transmit data unless the
antenna is connected; if not, the radio may be damaged.
Use in specific environments:
The use of wireless devices in hazardous locations is
limited by the constraints posed by the safety directors of
such environments.
The use of wireless devices on airplanes is governed by
the Federal Aviation Administration (FAA).
The use of wireless devices in hospitals is restricted to the
limits set forth by each hospital.
Antenna use:
In order to comply with FCC RF exposure limits, low gain
integrated antennas should be located at a minimum
distance of 20 cm (8 inches) or more from the body of all
persons.
High-gain, wall-mount, or mast-mount antennas are
designed to be professionally installed and should be
located at a minimum distance of 30 cm (12 inches) or
more from the body of all persons. Please contact your
professional installer, VAR, or antenna manufacturer for
proper installation requirements.
Explosive Device Proximity Warning (see below)
Antenna Warning (see below)
Use on Aircraft Caution (see below)
Other Wireless Devices (see below)
Power Supply (Access Point) (see below)
Explosive Device Proximity Warning
Warning: Do not operate a portable transmitter (such as a
wireless network device) near unshielded blasting caps or in an
explosive environment unless the device has been modified to be
qualified for such use.
Antenna Warnings
Warning: To comply with the FCC and ANSI C95.1 RF exposure
limits, it is recommended for the Intel(R) PRO/Wireless 2915ABG
Network Connection adapter installed in a desktop or portable
computer, that the antenna for this device be installed so as to provide
a separation distance of al least 20 cm (8 inches) from all persons and
that the antenna must not be co-located or operating in conjunction
with any other antenna or radio transmitter. It is recommended that the
user limit exposure time if the antenna is positioned closer than 20 cm
(8 inches). This device has also been evaluated for and shown
compliant with the FCC RF exposure limits under portable exposure
conditions (antennas are within 20 cm of a persons body) when
installed in certain specific OEM configurations. Details of the
authorized configurations can be found at
http://www.fcc.gov/oet/fccid/help.html by entering the FCC ID number
on the device."
Use On Aircraft Caution
Caution: Regulations of the FCC and FAA prohibit airborne
operation of radio-frequency wireless devices because their signals
could interfere with critical aircraft instruments.
Other Wireless Devices
Safety Notices for Other Devices in the Wireless Network: Refer
to the documentation supplied with wireless Ethernet adapters or
other devices in the wireless network.
Local Restrictions on 802.11a and 802.11b Radio Usage
Caution: Due to the fact that the frequencies used by 802.11a and
802.11b wireless LAN devices may not yet be harmonized in all
countries, 802.11a and 802.11b products are designed for use only in
specific countries, and are not allowed to be operated in countries
other than those of designated use. As a user of these products, you
are responsible for ensuring that the products are used only in the
countries for which they were intended and for verifying that they are
configured with the correct selection of frequency and channel for the
country of use. The device transmit power control (TPC) interface is
part of the Intel(R) PROSet/Wireless software. Operational restrictions
for Equivalent Isotropic Radiated Power (EIRP) are provided by the
system manufacturer. Any deviation from the permissible power and
frequency settings for the country of use is an infringement of national
law and may be punished as such.
For country-specific information, see the additional compliance
information supplied with the product.
Wireless interoperability
The Intel(R) PRO/Wireless 2915ABG Network Connection adapter is
designed to be interoperable with other wireless LAN products that are
based on direct sequence spread spectrum (DSSS) radio technology
and to comply with the following standards:
IEEE Std. 802.1b-1999. Standard on Wireless LAN.
Wireless Fidelity (WiFi) certification, as defined by the WECA
(Wireless Ethernet Compatibility Alliance).
The Intel(R) PRO/Wireless 2915ABG Network Connection adapter
and your health
The Intel(R) PRO/Wireless 2915ABG Network Connection adapter,
like other radio devices, emits radio frequency electromagnetic
energy. The level of energy emitted by this device, however, is less
than the electromagnetic energy emitted by other wireless devices
such as mobile phones. The Intel(R) PRO/Wireless 2915ABG Network
Connection adapter wireless device operates within the guidelines
found in radio frequency safety standards and recommendations.
These standards and recommendations reflect the consensus of the
scientific community and result from deliberations of panels and
committees of scientists who continually review and interpret the
extensive research literature. In some situations or environments, the
use of the Intel(R) PRO/Wireless 2915ABG Network Connection
adapter wireless device may be restricted by the proprietor of the
building or responsible representatives of the applicable organization.
Examples of such situations include the following:
Using the Intel(R) PRO/Wireless 2915ABG Network Connection
adapter equipment on board airplanes, or
Using the Intel(R) PRO/Wireless 2915ABG Network Connection
adapter equipment in any other environment where the risk of
interference with other devices or services is perceived or
identified as being harmful
If you are uncertain of the policy that applies to the use of wireless
devices in a specific organization or environment (an airport, for
example), you are encouraged to ask for authorization to use the
Intel(R) PRO/Wireless 2915ABG Network Connection adapter
wireless device before you turn it on.
Regulatory information
Information for the OEMs and Integrators:
The following statement must be included with all versions of this
document supplied to an OEM or integrator, but should not be
distributed to the end user.
This device is intended for OEM integrators only.
This device cannot be co-located with any other transmitter.
Please refer to the full Grant of Equipment document for other
restrictions.
This device must be operated and used with a locally approved
AP.
Information To Be Supplied to the End User by the OEM or
Integrator
The following regulatory and safety notices must be published in
documentation supplied to the end user of the product or system
incorporating an Intel(R) PRO/Wireless 2915ABG Network Connection
in compliance with local regulations.
The Intel(R) PRO/Wireless 2915ABG Network Connection adapter
wireless network device must be installed and used in strict
accordance with the manufacturer's instructions as described in the
user documentation that comes with the product. For country-specific
approvals, see Radio approvals. Intel Corporation is not responsible
for any radio or television interference caused by unauthorized
modification of the devices included with the Intel(R) PRO/Wireless
2915ABG Network Connection adapter kit, or the substitution or
attachment of connecting cables and equipment other than that
specified by Intel Corporation. The correction of interference caused
by such unauthorized modification, substitution or attachment is the
responsibility of the user. Intel Corporation and its authorized resellers
or distributors are not liable for any damage or violation of government
regulations that may arise from the user failing to comply with these
guidelines.
Local Restriction of 802.11a and 802.11b Radio Usage
The following statement on local restrictions must be published as
part of the compliance documentation for all 802.11a and 802.11b
products.
Caution: Due to the fact that the frequencies used by 802.11a and
802.11b wireless LAN devices may not yet be harmonized in all
countries, 802.11a and 802.11b products are designed for use only in
specific countries, and are not allowed to be operated in countries
other than those of designated use. As a user of these products, you
are responsible for ensuring that the products are used only in the
countries for which they were intended and for verifying that they are
configured with the correct selection of frequency and channel for the
country of use. Any deviation from permissible settings and
restrictions in the country of use could be an infringement of national
law and may be punished as such.
FCC Radio Frequency Interference Requirements
This device is restricted to indoor use due to its operation in the 5.15
to 5.25 GHz frequency range. FCC requires this product to be used
indoors for the frequency range 5.15 to 5.25 GHz to reduce the
potential for harmful interference to co-channel Mobile Satellite
systems. High power radars are allocated as primary users of the 5.25
to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can
cause interference with and /or damage this device.
This device is intended for OEM integrators only.
This device cannot be co-located with any other transmitter.
USA—Federal Communications Commission (FCC)
This device complies with Part 15 of the FCC Rules. Operation of the
device is subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference that may cause
undesired operation.
NOTE:The radiated output power of the Intel(R) PRO/Wireless
2915ABG Network Connection adapter wireless network
device is far below the FCC radio frequency exposure
limits. Nevertheless, the Intel(R) PRO/Wireless LAN
wireless network device should be used in such a manner
that the potential for human contact during normal operation
is minimized. To avoid the possibility of exceeding the FCC
radio frequency exposure limits, you should keep a distance
of at least
20 cm between you (or any other person in the vicinity) and
the antenna that is built into the computer.
This device has also been evaluated for and shown compliant with the
FCC RF exposure limits under portable exposure conditions
(antennas are within 20 cm of a persons body) when installed in
certain specific OEM configurations. Details of the authorized
configurations can be found at
http://www.fcc.gov/oet/fccid/help.html by entering the FCC ID number
on the device."
Caution: This device is restricted to indoor use due to its operation
in the 5.15 to 5.25 GHz frequency range. FCC requires this product to
be used indoors for frequency range 5.15 to 5.25 GHz to reduce the
potential for harmful interference to co-channel Mobile Satellite
systems. High power radars are allocated as primary users of the 5.25
to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can
cause interference with and/or damage this device.
Interference statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy. If the
equipment is not installed and used in accordance with the
instructions, the equipment may cause harmful interference to radio
communications. There is no guarantee, however, that such
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception (which
can be determined by turning the equipment off and on), the user is
encouraged to try to correct the interference by taking one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the distance between the equipment and the receiver.
Connect the equipment to an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
NOTE:The Intel(R) PRO/Wireless 2915ABG Network Connection
adapter wireless network device must be installed and used
in strict accordance with the manufacturer's instructions as
described in the user documentation that comes with the
product. Any other installation or use will violate FCC Part
15 regulations.
Canada—Industry Canada (IC)
This device complies with RSS210 of Industry Canada.
This Class B digital apparatus complies with Canadian ICES-003,
Issue 2, and RSS-210, No 4 (Dec 2000) and No 5 (Nov 2001).
Cet appariel numérique de la classe B est conforme à la norme NMB-
003, No. 2, et CNR-210, No 4 (Dec 2000) et No 5 (Nov 2001)..
"To prevent radio interference to the licensed service, this device is
intended to be operated indoors and away from windows to provide
maximum shielding. Equipment (or its transmit antenna) that is
installed outdoors is subject to licensing."
« Pour empêcher que cet appareil cause du brouillage au service
faisant l'objet d'une licence, il doit être utilisé a l'intérieur et devrait être
placé loin des fenêtres afinde fournir un écran de blindage maximal. Si
le matériel (ou son antenne d'émission) est installé à l'extérieur, il doit
faire l'objet d'une licence. »
Europe Frequency Bands
2.400 - 2.4835 GHz (Europe ETSI)
5.15 - 5.35 GHz and 5.47-5.725 GHz (Europe ETSI)
5.15-5.25 can be used outdoors and all other 5 GHz supported must
be indoors
Low band 5.25 - 5.35 GHz is for indoor use only
5.47 - 5.725 GHz is not allowed in Austria, France and Switzerland
Declaration of Conformity
This equipment complies with the essential requirements of the
European Union directive 1999/5/EC.
English
Hereby, Intel(R) Corporation, declares
that this Intel(R) PRO/Wireless
2915ABG Network Connection is in
compliance with the essential
requirements and other relevant
provisions of Directive 1999/5/EC.
Finnish
Intel(R) Corporation vakuuttaa täten että
Intel(R) PRO/Wireless 2915ABG
Network Connection tyyppinen laite on
direktiivin 1999/5/EY oleellisten
vaatimusten ja sitä koskevien direktiivin
muiden ehtojen mukainen.
Dutch Hierbij verklaart Intel(R) Corporation dat
het toestel Intel(R) PRO/Wireless
2915ABG Network Connection in
overeenstemming is met de essentiële
eisen en de andere relevante bepalingen
van richtlijn 1999/5/EG
Bij deze verklaart Intel(R) Corporation
dat deze Intel(R) PRO/Wireless
2915ABG Network Connection voldoet
aan de essentiële eisen en aan de
overige relevante bepalingen van
Richtlijn 1999/5/EC.
French Par la présente Intel(R) Corporation
déclare que l'appareil Intel(R)
PRO/Wireless 2915ABG Network
Connection est conforme aux exigences
essentielles et aux autres dispositions
pertinentes de la directive 1999/5/CE
Par la présente, Intel(R) Corporation
déclare que ce Intel(R) PRO/Wireless
2915ABG Network Connection est
conforme aux exigences essentielles et
aux autres dispositions de la directive
1999/5/CE qui lui sont applicables
Swedish Härmed intygar Intel(R) Corporation att
denna Intel(R) PRO/Wireless 2915ABG
Network Connection står I
överensstämmelse med de väsentliga
egenskapskrav och övriga relevanta
bestämmelser som framgår av direktiv
1999/5/EG.
Danish
Undertegnede Intel(R) Corporation
erklærer herved, at følgende udstyr
Intel(R) PRO/Wireless 2915ABG
Network Connection overholder de
væsentlige krav og øvrige relevante krav
i direktiv 1999/5/EF
German Hiermit erklärt Intel(R) Corporation, dass
sich dieser/diese/dieses Intel(R)
PRO/Wireless 2915ABG Network
Connection in Übereinstimmung mit den
grundlegenden Anforderungen und den
anderen relevanten Vorschriften der
Richtlinie 1999/5/EG befindet". (BMWi)
Hiermit erklärt Intel(R) Corporation die
Übereinstimmung des Gerätes Intel(R)
PRO/Wireless 2915ABG Network
Connection mit den grundlegenden
Anforderungen und den anderen
relevanten Festlegungen der Richtlinie
1999/5/EG. (Wien)
Greek ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Intel(R) Corporation
∆ΗΛΩΝΕΙ ΟΤΙ Intel(R) PRO/Wireless
2915ABG Network Connection ΣΥΜΜΟ
ΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩ∆ΕΙΣ ΑΠΑ
ΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ∆Ι
ΑΤΑΞΕΙΣ ΤΗΣ Ο∆ΗΓΙΑΣ 1999/5/ΕΚ
Italian Con la presente Intel(R) Corporation
dichiara che questo Intel(R)
PRO/Wireless 2915ABG Network
Connection è conforme ai requisiti
essenziali ed alle altre disposizioni
pertinenti stabilite dalla direttiva
1999/5/CE
Spanish Por medio de la presente Intel(R)
Corporation declara que el Intel(R)
PRO/Wireless 2915ABG Network
Connection cumple con los requisitos
esenciales y cualesquiera otras
disposiciones aplicables o exigibles de
la Directiva 1999/5/CE
Portuguese Intel(R) Corporation declara que este
Intel(R) PRO/Wireless 2915ABG
Network Connection está conforme com
os requisitos essenciais e outras
disposições da Directiva 1999/5/CE.
Malti Hawnhekk, Intel(R) Corporation,
jiddikjara li dan Intel(R) PRO/Wireless
2915ABG Network Connection
jikkonforma mal-•ti•ijiet essenzjali u ma
provvedimenti o•rajn relevanti li hemm
fid-Dirrettiva 1999/5/EC
New Member States requirements of Declaration of Conformity
Estonian
Käesolevaga kinnitab Intel(R)
Corporation seadme Intel(R)
PRO/Wireless 2915ABG
Network Connection vastavust
direktiivi 1999/5/EÜ
põhinõuetele ja nimetatud
direktiivist tulenevatele teistele
asjakohastele sätetele.
Hungary
Alulírott, Intel(R) Corporation
nyilatkozom, hogy a Intel(R)
PRO/Wireless 2915ABG
Network Connection megfelel
a vonatkozó alapvetõ
követelményeknek és az
1999/5/EC irányelv egyéb
elõírásainak
Slovak
Intel(R) Corporation týmto
vyhlasuje, že Intel(R)
PRO/Wireless 2915ABG
Network Connection sp••a
základné požiadavky a všetky
príslušné ustanovenia
Smernice 1999/5/ES.
Czech
Intel(R) Corporation tímto
prohlašuje, že tento Intel(R)
PRO/Wireless 2915ABG
Network Connection je ve
shod• se základními
požadavky a dalšími
p•íslušnými ustanoveními sm
•rnice 1999/5/ES."
Slovenia
Šiuo Intel(R) Corporation
deklaruoja, kad šis Intel(R)
PRO/Wireless 2915ABG
Network Connection atitinka
esminius reikalavimus ir kitas
1999/5/EB Direktyvos
nuostatas.
Latvian
Ar šo Intel(R) Corporation
deklar•, ka Intel(R)
PRO/Wireless 2915ABG
Network Connection atbilst
Direkt•vas 1999/5/EK b•tiskaj
•m pras•b•m un citiem ar to
saist•tajiem noteikumiem
Lithuanian
Intel(R) Corporation
deklaruoja, kad Intel(R)
Pro/Wireless 2915ABG
Network Connectionatitinka
1999/5/EC
Direktyvos esminius
reikalavimus ir kitas
nuostatas".
Polish
Niniejszym, Intel(R)
Corporation, deklaruj•, •e
Intel(R) PRO/Wireless
2915ABG Network
Connection spe•nia
wymagania zasadnicze oraz
stosowne postanowienia
zawarte
Dyrektywie 1999/5/EC.
France
For Metropolitan departments
2.400 - 2.4835 GHz for indoor use
2.400 -2.454 GHz (channels 1 to 7) for outdoor use
Some areas of France have a restricted frequency band. The worst
case maximum authorized power indoors is:
10 mW for the entire 2.4 GHz band (2400 MHz–2483.5 MHz)
100 mW for frequencies between 2446.5 MHz and 2483.5 MHz
(Note: Channels 10 through 13 inclusive operate in the band
2446.6 MHz to 2483.5 MHz)
There are few possibilities for outdoor use: On private property or on
the private property of public persons, use is subject to a preliminary
authorization procedure by the Ministry of Defense, with maximum
authorized power of 100 mW in the 2446.5–2483.5 MHz band. Use
outdoors on public property is not permitted. In the departments listed
below, for the entire 2.4 GHz band:
Maximum authorized power indoors is 100 mW
Maximum authorized power outdoors is 10 mW
There is partial restriction of the 2.4 GHz band for outdoor/indoor in
part of the 2.4 GHz band, according to the OEM Regulatory and
Safety Notice Guidelines of CX2 2200BG (see page 12, concerning
France).
Departments in which the use of the 2400–2483.5 MHz band is
permitted with an EIRP of less than 100 mW indoors and less than 10
mW outdoors:
01Ain Orientales36Indre 66Pyrénées
02Aisne 37Indre et Loire 67Bas Rhin
03Allier 41Loir et Cher 68Haut Rhin
05Hautes Alpes 42Loire 70Haute Saône
08Ardennes 45Loiret 71Saône et Loire
09Ariège 50Manche 75Paris
11Aude 55Meuse 82Tarn et Garonne
12Aveyron 58Nièvre 84Vaucluse
16Charente 59Nord 88Vosges
24Dordogne 60Oise 89Yonne
25Doubs 61Orne 90Territoire de Belfort
26Drôme 63Puy du Dôme 94Val de Marne
32Gers 64Pyrénées Atlantique
This requirement is likely to change over time, allowing the use your
Network Connection card in more areas within France. Please check
with ART for the latest information (www.art-telecom.co.fr)
For Guadeloupe, Martinique, St Pierre et Miquelon, Mayotte:
2.400 - 2.4835 GHz for indoor and outdoor use.
For Reunion, Guyane:
2.400 - 2.4835 GHz for indoor use.
2.420 - 2.4835 GHz for outdoor use (channels 5 to 13)
NOTE:Your Intel(R) PRO/Wireless 2915ABG Network Connection
adapter transmits less than 100 mW, but more than 10 mW.
Italia
A license is required for indoor use. Outdoor use is prohibited.
NOTE:E' necessaria la concessione ministeriale anche per l'uso
interno. Verificare con i rivenditori la procedura da seguire.
L'uso per installazione in esterni non e' permessa.
Japan Frequency Bands
2.400 - 2.497 GHz (Japan)
5.15 to 5.25 (offset Japanese channels) active scan
High Band Frequencies
5.725 to 5.825 active scan
Radio approvals
To determine whether you are allowed to use your wireless network
device in a specific country, please check to see if the radio type
number that is printed on the identification label of your device is listed
in the manufacture OEM Regulatory Guidance document.
Underwriters Laboratories Inc. (UL) Regulatory Warning
For use in (or with) UL Listed personal computers or compatible.
Back to Top
Back to Contents
Regulatory Information: Intel(R) PRO/Wireless
2200BG Network Connection
Information for the User
Regulatory Information
Information for the user
Safety Notices
The FCC with its action in ET Docket 96-8 has adopted a safety
standard for human exposure to radio frequency (RF) electromagnetic
energy emitted by FCC certified equipment. The Intel(R)
PRO/Wireless 2200BG Network Connection meets the Human
Exposure limits found in OET Bulletin 65, 2001, and ANSI/IEEE
C95.1, 1992. Proper operation of this radio according to the
instructions found in this manual will result in exposure substantially
below the FCC’s recommended limits.
The following safety precautions should be observed:
Do not touch or move antenna while the unit is transmitting or
receiving.
Do not hold any component containing the radio such that the
antenna is very close or touching any exposed parts of the
body, especially the face or eyes, while transmitting.
Do not operate the radio or attempt to transmit data unless the
antenna is connected; if not, the radio may be damaged.
Use in specific environments:
The use of wireless devices in hazardous locations is
limited by the constraints posed by the safety directors of
such environments.
The use of wireless devices on airplanes is governed by
the Federal Aviation Administration (FAA).
The use of wireless devices in hospitals is restricted to the
limits set forth by each hospital.
Explosive Device Proximity Warning (see below)
Antenna Warning (see below)
Use on Aircraft Caution (see below)
Other Wireless Devices (see below)
Power Supply (Access Point) (see below)
Explosive Device Proximity Warning
Warning: Do not operate a portable transmitter (such as a
wireless network device) near unshielded blasting caps or in an
explosive environment unless the device has been modified to be
qualified for such use.
Antenna Warnings
Warning: To comply with the FCC and ANSI C95.1 RF exposure
limits, it is recommended for the Intel(R) PRO/Wireless 2200BG
Network Connection installed in a desktop or portable computer, that
the antenna for this device be installed so as to provide a separation
distance of al least 20 cm (8 inches) from all persons and that the
antenna must not be co-located or operating in conjunction with any
other antenna or radio transmitter. It is recommended that the user
limit exposure time if the antenna is positioned closer than 20 cm (8
inches).
Warning: The Intel(R) PRO/Wireless 2200BG Network
Connection product is not designed for use with high-gain directional
antennas. Use of such antennas with these products is illegal.
Use On Aircraft Caution
Caution: Regulations of the FCC and FAA prohibit airborne
operation of radio-frequency wireless devices because their signals
could interfere with critical aircraft instruments.
Local Restrictions on 802.11b Radio Usage
Caution: Due to the fact that the frequency used by 802.11b
wireless LAN devices may not yet be harmonized in all countries,
802.11b products are designed for use only in specific countries, and
are not allowed to be operated in countries other than those of
designated use. As a user of these products, you are responsible for
ensuring that the products are used only in the countries for which
they were intended and for verifying that they are configured with the
correct selection of frequency and channel for the country of use. Any
deviation from the permissible settings for the country of use is an
infringement of national law and may be punished as such.
For country-specific information, see the additional compliance
information supplied with the product.
Wireless interoperability
The Intel(R) PRO/Wireless 2200BG Network Connection adapter is
designed to be interoperable with any wireless LAN product that is
based on direct sequence spread spectrum (DSSS) radio technology
and to comply with the following standards:
IEEE Std. 802.11b-1999. Standard on Wireless LAN.
IEEE Std. 802.11g compliant. Standard on Wireless LAN.
Wireless Fidelity (WiFi(R)) certification, as defined by the WECA
(Wireless Ethernet Compatibility Alliance).
The Intel(R) PRO/Wireless LAN 2200 3A Mini PCI adapter and
your health
The Intel(R) PRO/Wireless 2200BG Network Connection adapter, like
other radio devices, emits radio frequency electromagnetic energy.
The level of energy emitted by this device, however, is less than the
electromagnetic energy emitted by other wireless devices such as
mobile phones. The Intel(R) PRO/Wireless 2200BG Network
Connection adapter wireless device operates within the guidelines
found in radio frequency safety standards and recommendations.
These standards and recommendations reflect the consensus of the
scientific community and result from deliberations of panels and
committees of scientists who continually review and interpret the
extensive research literature. In some situations or environments, the
use of the Intel(R) PRO/Wireless 2200BG Network Connection
adapter wireless device may be restricted by the proprietor of the
building or responsible representatives of the applicable organization.
Examples of such situations include the following:
Using the Intel(R) PRO/Wireless 2200BG Network Connection
adapter equipment on board airplanes, or
Using the Intel(R) PRO/Wireless 2200BG Network Connection
adapter equipment in any other environment where the risk of
interference with other devices or services is perceived or
identified as being harmful.
If you are uncertain of the policy that applies to the use of wireless
devices in a specific organization or environment (an airport, for
example), you are encouraged to ask for authorization to use the
Intel(R) PRO/Wireless 2200BG Network Connection adapter wireless
device before you turn it on.
Regulatory information
The Intel(R) PRO/Wireless 2200BG Network Connection adapter
wireless network device must be installed and used in strict
accordance with the manufacturer's instructions as described in the
user documentation that comes with the product. For country-specific
approvals, see Radio approvals. Dell Inc. is not responsible for any
radio or television interference caused by unauthorized modification of
the devices included with the Intel(R) PRO/Wireless 2200BG Network
Connection adapter kit, or the substitution or attachment of connecting
cables and equipment other than that specified by Dell Inc. The
correction of interference caused by such unauthorized modification,
substitution or attachment is the responsibility of the user. Dell inc.
and its authorized resellers or distributors are not liable for any
damage or violation of government regulations that may arise from the
user failing to comply with these guidelines.
NOTE:Your Intel(R) PRO/Wireless 2200BG Network Connection
adapter transmits less than 100 mW, but more than 10 mW.
USA—Federal Communications Commission (FCC)
This device complies with Part 15 of the FCC Rules. Operation of the
device is subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference that may cause
undesired operation.
NOTE:The radiated output power of the Intel(R) PRO/Wireless
2200BG Network Connection adapter wireless network
device is far below the FCC radio frequency exposure
limits. Nevertheless, the Intel(R) PRO/Wireless 2200BG
Network Connection device should be used in such a
manner that the potential for human contact during normal
operation is minimized. To avoid the possibility of
exceeding the FCC radio frequency exposure limits, you
should keep a distance of at least 20 cm between you (or
any other person in the vicinity) and the antenna that is built
into the computer. To determine the location of the antenna
within your computer, check the information posted on the
general Dell support site at http://www.support.dell.com/.
Interference statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy. If the
equipment is not installed and used in accordance with the
instructions, the equipment may cause harmful interference to radio
communications. There is no guarantee, however, that such
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception (which
can be determined by turning the equipment off and on), the user is
encouraged to try to correct the interference by taking one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the distance between the equipment and the receiver.
Connect the equipment to an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
NOTE:The Intel(R) PRO/Wireless 2200BG Network Connection
adapter wireless network device must be installed and used
in strict accordance with the manufacturer's instructions as
described in the user documentation that comes with the
product. Any other installation or use will violate FCC Part
15 regulations.
U.S. Frequency Bands
2.400 - 2.473 GHz
Canada—Industry Canada (IC)
This Class B digital apparatus complies with Canadian ICES-003,
Issue 2, and RSS-210, Issue 4 (Dec. 2000).
Cet appariel numérique de la classe B est conforme à la norme NMB-
003, No. 2, et CNR-210, No 4 (Dec 2000).
"To prevent radio interference to the licensed service, this device is
intended to be operated indoors and away from windows to provide
maximum shielding. Equipment (or its trasmit antenna) that is installed
outdoors is subject to licensing."
« Pour empêcher que cet appareil cause du brouillage au service
faisant l'objet d'une licence, il doit être utilisé a l'intérieur et devrait être
placé loin des fenêtres afinde fournir un écran de blindage maximal. Si
le matériel (ou son antenne d'émission) est installé à l'extérieur, il doit
faire l'objet d'une licence. »
Europe—EU Declaration of Conformity
Europe Frequency Bands
2.400 - 2.4835 GHz (Europe ETSI)
This equipment complies with the essential requirements of the
European Union directive 1999/5/EC.
Cet équipement est conforme aux principales exigences essentielles
définies dans la Directive européenne RTTE 1999/5/CE.
Die Geräte erfüllen die grundlegenden Anforderungen der RTTE-
Richtlinie 1999/5/EG.
Questa apparecchiatura è conforme ai requisiti essenziali della
Direttiva Europea R&TTE 1999/5/CE.
Este equipo cumple los requisitos principales de la Directiva
1999/5/CE de la UE, "Equipos de Terminales de Radio y
Telecomunicaciones".
Este equipamento cumpre os requisitos essenciais da Directiva
1999/5/CE do Parlamento Europeu e do Conselho (Directiva RTT).
O exoplismos autos plhroi tis basikes apaits ths koinotikhs odhgias EU
R&TTE 1999/5/E.
Deze apparatuur voldoet aan de noodzakelijke vereisten van EU-
richtlijn betreffende radioapparatuur en telecommunicatie-
eindapparatuur 1999/5/EG.
Dette udstyr opfylder de Væsentlige krav i EU's direktiv 1999/5/EC om
Radio- og teleterminaludstyr.
Dette utstyret er i overensstemmelse med hovedkravene i R&TTE-
direktivet (1999/5/EC) fra EU.
Utrustningen uppfyller kraven för EU-direktivet 1999/5/EC om ansluten
teleutrustning och ömsesidigt erkännande av utrustningens
överensstämmelse (R&TTE).
Tämä laite vastaa EU:n radio- ja telepäätelaitedirektiivin (EU R&TTE
Directive 1999/5/EC) vaatimuksia.
France
Some areas of France have a restricted frequency band. The worst
case maximum authorized power indoors is:
10 mW for the entire 2.4 GHz band (2400 MHz–2483.5 MHz)
100 mW for frequencies between 2446.5 MHz and 2483.5 MHz
(Note:Channels 10 through 13 inclusive operate in the band
2446.6 MHz to 2483.5 MHz)
There are few possibilities for outdoor use: On private property or on
the private property of public persons, use is subject to a preliminary
authorization procedure by the Ministry of Defense, with maximum
authorized power of 100 mW in the 2446.5–2483.5 MHz band. Use
outdoors on public property is not permitted. In the departments listed
below, for the entire 2.4 GHz band:
Maximum authorized power indoors is 100 mW
Maximum authorized power outdoors is 10 mW
Departments in which the use of the 2400–2483.5 MHz band is
permitted with an EIRP of less than 100 mW indoors and less than 10
mW outdoors:
01 Ain Orientales 36 Indre 66 Pyrénées
02 Aisne 37 Indre et Loire 67 Bas Rhin
03 Allier 41 Loir et Cher 68 Haut Rhin
05 Hautes Alpes 42 Loire 70 Haute Saône
08 Ardennes 45 Loiret 71 Saône et Loire
09 Ariège 50 Manche 75 Paris
11 Aude 55 Meuse 82 Tarn et Garonne
12 Aveyron 58 Nièvre 84 Vaucluse
16 Charente 59 Nord 88 Vosges
24 Dordogne 60 Oise 89 Yonne
25 Doubs 61 Orne 90 Territoire de
Belfort
26 Drôme 63 Puy du Dôme 94 Val de Marne
32 Gers 64 Pyrénées
Atlantique
This requirement is likely to change over time, allowing the use your
wireless LAN card in more areas within France. Please check with
ART for the latest information (http://www.telecom.co.fr/)
Belgique
Dans le cas d'une utilisation privée, à l'extérieur d'un bâtiment, au-
dessus d'un espace public, aucun enregistrement n'est nécessaire
pour une distance de moins de 300m. Pour une distance supérieure à
300m un enregistrement auprès de l'IBPT est requise. Pour les
enregistrements et licences, veuillez contacter l'IBPT.
Italia
For use in private premises: no restriction outdoor or indoor, 2.400 -
2.4835 Ghz
For use in public premises: no restriction outdoor or indoor, 2.400 -
2.4835 Ghz, but a general authorization has to be requested to the
ministry of Post and telecommunications.
Japan Frequency Bands
2.400 - 2.497 GHz (Japan)
Radio approvals
To determine whether you are allowed to use your wireless network
device in a specific country, please check to see if the radio type
number that is printed on the identification label of your device is listed
on the radio approval list posted on the general Dell support site at
http://www.support.dell.com/.
Back to Top
Back to Contents

Navigation menu
