Digital Device LL500H 15 inch LCD Monitor User Manual UserManual
Digital Device Inc. 15 inch LCD Monitor UserManual
users manual
Digital Device, Inc.
User’s Manual
1.Setup for Operation
Once the circuit has been connected, a setup procedure for optimal operation is required some time.
The following instructions are likely to form the basis of the finished product operation manual.
l PC Settings
The PC needs to be set to an appropriate graphics mode that has the same resolution with the LCD panel
to have clear screen image. And the vertical refresh rate should be set to one of 56-75Hz, non-interlaced.
l LCD Display System Settings
The OSD(On Screen Display) provides certain functions to have clear image and others.
This board supports 4 buttons OSD operation as a standard. The control functions defined on OSD
operation are as below.
1) Functions on OSD Menu
OSD Menu Descriptions
Auto Adjustment Auto Geometry & Auto Color Balance
Auto Geometry Automatically adjust the Horizontal position, Vertical position, Horizontal
size, and Phase. In order to have good Auto Adjustment operation, You
would better have full screen Window’s background or characters on the
screen prior to proceeding this function.
Auto Color Balance Auto adjust the color balance of the screen
Horizontal Position Adjust the horizontal position of the screen’s image.
Vertical Position Adjust the Vertical position of the screen’s image.
Horizontal Size Adjust the horizontal size of the screen’s image.
Phase Adjust the focus of the screen’s image.
Brightness Adjust the brightness of the screen.
Contrast Adjust the contrast of the screen.
Color Temperature, Red, Green & Blue
Language Select one of the five language(English, French, German, Italian, Spanish)
Advanced Factory Preset, Sharpness, DOS/GFX, OSD Horizontal / Vertical Position
Cancel Ignore current changes and keep the pervious data.
Digital Device, Inc.
2) Hotkey Function Definition
OSD KEY Functions
DOWN Brightness control
UP Contrast control
SEL Auto Geometry Adjustment
2.Applicable Graphic Mode
The microprocessor measure the H-sync, V-sync and V-sync/H-sync polarity for RGB inputs, and uses
this timing information to control all of the display operation to get the proper image on a screen.
This board can detect all VESA standard Graphic modes shown on the table below and provide more
clear and stable image on a screen.
Horizontal Timing Vertical TimingPixel
Freq. Sync
Polar Freq Total Active Sync
Polar Freq Total Active
Spec
Mode
MHz KHz Pixel Pixel Hz Line Line
640x350
@70Hz 25.144 P31.430 800 640 N70.000 449 350
640x480
@70Hz 28.287 N31.430 800 640 P70.000 449 400
720x400
@70Hz 28.287 N31.430 900 720 P70.000 449 400
640x480
@60Hz 25.175 N31.469 800 640 N59.940 525 480
640x480
@72Hz 31.500 N37.861 832 640 N72.809 520 480
640x480
@75 31.500 N37.500 840 640 N75.000 500 480
800x600
@56Hz 36.000 P35.156 1024 800 P56.250 625 600
800x600
@60Hz 40.000 P37.879 1056 800 P60.317 628 600
800x600
@72Hz 50.000 P48.077 1040 800 P72.188 666 600
800x600
@75Hz 49.500 P46.875 1056 800 P75.000 625 600
1024x768
@60Hz 65.000 N48.363 1344 1024 N60.005 806 768
1024x768
@70Hz 75.000 N56.476 1328 1024 N70.070 806 768
1024x768
@75Hz 78.750 P60.023 1312 1024 P75.030 800 768
