AT Commands Set SIM7500 SIM7600 Series Command Manual V1.10

User Manual:

Open the PDF directly: View PDF PDF.
Page Count: 335 [warning: Documents this large are best viewed by clicking the View PDF Link!]

SIM7500_SIM7600 Series_AT
Command Manual _V1.10
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
1
Document Title: SIM7500_SIM7600 Series_AT Command Manual
Version: 1.10
Date: 2018-10-08
Status: Release
Document ID: SIM7500_SIM7600 Series_AT Command Manual_V1.10
General Notes
SIMCom offers this information as a service to its customers, to support application and engineering efforts
that use the products designed by SIMCom. The information provided is based upon requirements
specifically provided to SIMCom by the customers. SIMCom has not undertaken any independent search
for additional relevant information, including any information that may be in the customer’s possession.
Furthermore, system validation of this product designed by SIMCom within a larger electronic system
remains the responsibility of the customer or the customer’s system integrator. All specifications supplied
herein are subject to change.
Copyright
This document contains proprietary technical information which is the property of SIMCom Limited.,
copying of this document and giving it to others and the using or communication of the contents thereof,
are forbidden without express authority. Offenders are liable to the payment of damages. All rights reserved
in the event of grant of a patent or the registration of a utility model or design. All specification supplied
herein are subject to change without notice at any time.
Copyright © Shanghai SIMCom Wireless Solutions Ltd. 2018
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
2
Version History
Version
Date
Chapter
What is new
V1.00 2016-07-08 New version
V1.01 2016-07-21 5.5 AT+CCUG Add note.
V1.01 2016-07-21 5.6 AT+CUSD Add note.
V1.01 2016-07-21 5.7 AT+CAOC Add note.
V1.01 2016-07-21 5.8 AT+CSSN Add note.
V1.01 2016-07-21 11.2 AT+STGI Add PDU format support
V1.01 2016-07-21 11.3 AT+STGR Add PDU format support
V1.01 2016-07-21 11.6 AT+STENV Add this command
V1.01 2016-07-21 11.7 AT+STSM Add this command
V1.02
2016-07-27
11.7 AT+STSM
Modify this command
V1.02 2016-07-27 5.13 AT+CNAOP Modify this command
V1.02 2016-07-27 5.18 AT+CTZU Modify this command
V1.02 2016-07-27 5.19 AT+CTZR Modify this command
V1.02 2016-07-27 5.16 AT+CPSI Modify this command
V1.02 2016-07-27 9.15 AT+CGAUTH Modify this command
V1.02 2016-07-27 Chapter 15 Delete the CSOCK* Command
V1.02 2016-07-27 3.21 AT&F Modify this command
V1.02 2016-07-28 6.25 AT+CACDBFN Modify this command
V1.02
2016-07-29
5.18 AT+CTZU
Modify this command
V1.02 2016-07-29 5.18 AT+CTZR Modify this command
V1.02 2016-07-29 6.24 AT+SIDET Modify this command
V1.02 2016-07-29 5.20 AT+NETMODE Modify this command,PIN->NO
V1.02 2016-07-29 12.5 AT+CGFUNC Modify this command
V1.02 2016-07-29 12.6 AT+CGDRT Modify this command
V.1.02 2016-07-29 12.7 AT+ C G GRTV Modify this command
V.1.02 2016-07-29 12.8 AT+ C G SETV Modify this command
V1.02 2016-07-29 5.15 AT+CPSI Modify this command
V1.02 2016-07-29 11.2 AT+STGI Modify this command
V1.02
2016-07-29
11.7 AT+STSM
Modify this command
V1.02 2016-07-29 Delete CSD function Delete CSD function
V1.02 2016-08-05 11.5
AT+STKFMT Set STK pdu
Modify this command
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
3
format
V1.02 2016-08-05 5.15
AT+CPSI Inquiring UE
system information
Modify 1xlte
V1.02 2016-08-05 9.11 AT+CGDATA Enter data state Modify cid
V1.02 2016-08-05 9.3 AT+CGACT
PDP context
activate or deactivate
Modify cid
V1.02 2016-08-05 7.9 AT+CNMI New m
essage
indications to TE
Modify default value
V1.02 2016-08-12 7.25 AT +CMGP Set
cdma/evdo
text mode parameters
Modify format
V1.02 2016-08-16 15.7 Common Channel Service
15.8 SSL Certificate & Ke
y
management
Modify these commands
V1.02 2016-08-16 6.29 AT+CTXVOL
6.30 AT+CTXMICGAIN
Add commands
V1.02 2016-08-17 11.7
AT+STSM Get STK Setup
Menu List with PDU Mode
Modify this command
V1.02 2016-08-17 5.14
AT+CNSDP Preferred service
domain selection
Delete this command
V1.02
2016-08-19
AT+CMGENREF
AT+CMSSEXM
AT+CSALPHA
Delete this command
V1.02 2016-08-26 15.1.6 AT+CPINGSTOP Modify this command
V1.02 2016-08-30 5.19 AT+NETMODE Modify this command
V1.02 2016-09-05 3.21 AT&F Modify this command
V1.02 2016-09-05 10.6 AT+CMTE Modify test command
V1.02 2016-09-05 15.7.3 AT+CCHOPEN
15.7.7 AT+CCHSET
15.7.8 AT+CCHADDR
Modify these commands
V1.02 2016-09-05 15.7.10
Unsolicited common
channel command <err> Codes
Add error code description
V1.02 2016-09-06 6.27 AT+CMICGAIN
6.28 AT+COUTGAIN
6.29 AT+CTXVOL
6.30 AT+CTXMICGAIN
Modify these commands
V1.02 2016-09-06 6.31 AT+CRXVOL
6.32 AT+CECH
6.33 AT+CECDT
6.34 AT+CECWB
Add these commands
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
4
6.35 AT+CNSN
6.36 AT+CNSLIM
6.37 AT+CFNSMOD
6.38 AT+CFNSIN
6.39 AT+CFNSLVL
V1.02 2016-09-06 12.6 AT+CGDRT
12.7 AT+CGSETV
12.8 AT+CGGETV
12.9 AT+CGISR
Modify these commands
V1.02 2016-09-07 9.15 AT+CGAUTH Modify read command and
test
command
V1.02 2016-09-09 5.11 AT + C NMP Modify this command
V1.02 2016-09-09 3.21 AT&F Modify this command
V1.02 2016-09-09 11.5 AT +STKFMT Modify this command
V1.02 2016-09-13 6.24 AT+SIDET Modify this command
V1.02 2016-09-13 4.23 AT+CUSBPIDSWITCH Add this command
V1.02 2016-09-14 6.22 AT+C SDVC Modify this command
V1.02 2016-09-18 6.40 AT+CECRX
6.41 AT+CNLPPG
6.42 AT+CNLPPL
Add these commands
V1.02 2016-09-19 7.2 AT+ C PMS Modify this command
V1.02 2016-09-21 10.6 AT+CMTE Modify this command
V1.02 2016-09-21 10.9 AT+ CUSBDELETEADB Delete this command
V1.02 2016-09-22 6.43 AT+CECM Add this command
V1.02 2016-09-22 15.7.6 AT+CCHRECV Modify this command
V1.02 2016-09-22 15.7.10
Unsolicited common
channel command <err> Codes
Modify the format
V1.02 2016-09-26 6.25 AT+CACDBFN Modify this command
V1.02 2016-09-27 15.2.10 AT+CIPFILTERSET Modify this command
V1.02 2016-09-28 3.33 AT+CIMI Modify this command
V1.02 2016-09-28 3.34 AT+CIMIM Add this command
V1.02 2016-09-28 7.13 AT+CMGS
7.15 AT+CMGW
7.20 AT+CMGSEX
Modify these commands
V1.02 2016-10-08 3.21 AT&F Modify this command
V1.02 2016-10-12 9.6 AT+CGTFT Modify this command
V1.02 2016-10-13 9.4 AT+CGDCONT Modify this command
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
5
V1.02
2016-10-13
16.8 AT+CGPSNMEA
Modify this command
V1.02 2016-10-17 9.3 AT+CGACT
9.7 AT+CGQREQ
9.8 AT+CGEQREQ
9.9 AT+CGQMIN
9.10 AT+CGEQMIN
9.11 AT+ CGDATA
9.12 AT+CGPADDR
9.15 AT+CGAUTH
15.1.12 AT+CDNSSRV
Modify these commands
V1.02 2016-10-18 7.2 AT+ C PMS Modify this command
V1.02 2016-10-19 3.21 AT&F Modify this command
V1.02 2016-10-20 9.8 AT+CGEQREQ
9.10 AT+CGEQMIN
Modify these commands
V1.02 2016-10-20 12.9 AT+CGISR Modify this command
V1.02 2016-10-24 5.13 AT+CNAOP Modify this command
V1.02 2016-10-24 3.21 AT&F Modify this command
V1.02 2016-10-28 16.20 AT+CGPSMODE Add this command
V1.02 2016-11-09 11.4 AT + STK Modify this command
V1.02 2016-11-04 6.22 AT+ C SDVC Modify this command
V1.02 2016-11-04 16.21 AT+ CBDS Add this command
V1.02 2016-11-04 15.3.9 AT+CFTPGET
15.3.11 AT+CFTPLIST
Modify these commands
V1.02 2016-11-04 15.3.15 AT+CFTPCACHERD Add this command
V1.02 2016-11-08 4.23 AT+CUSBPIDSWITCH Modify this command
V1.02 2016-11-10 3.21 AT&F Modify this command
V1.02 2016-11-10 9.3 AT+CGACT
9.11 AT + C G D ATA
Modify these commands
V1.02 2016-11-10 15.1.1 AT+CSOCKSETPN Modify this command
V1.03 2016-11-11 4.23 AT+CUSBPIDSWITCH Modify this command
V1.03 2016-11-17 16.21 AT+ C BDS Modify this command
V1.03 2016-11-17 16.15 AT+CGPSINFOCFG Modify this command
V1.03 2016-11-24 15.3.9 AT+CFTPGET
15.3.11 AT+CFTPLIST
15.3.15 AT+CFTPCACHERD
Modify these commands
V1.03 2016-11-24 15.7.3 AT+CCHOPEN
15.7.6 AT+CCHRECV
Modify these commands
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
6
V1.03
2016-12-12
9.3 AT+CGACT
Modify this command
V1.03 2016-12-21 9.4 AT+CGDCONT Modify this command
V1.03 2016-12-23 3.21 AT&F
5.11 AT + C NBP
5.14 AT+CPSI
Modify these commands
V1.03 2017-1-4 9.12 AT+CGPADDR Modify this command
V1.03 2017-1-11 16.10 AT+CGPSFTM Modify this command
V1.03 2017-1-12 5.14 AT+CPSI Modify this command
V1.04 2017-1-20 15.7.6 AT+CCHRECV Modify this command
V1.04 2017-2-9 6.26 AT+CPCMREG
6.43 AT+CECM
Modify these commands
V1.04 2017-2-9 15.7.6 AT+CCHRECV Modify this command
V1.04 2017-2-20 5.12 AT+ C NBP Modify this command
V1.04 2017-2-21 3.12 AT+ IPR
12.1 AT+IPREX
Modify these commands
V1.04 2017-3-8 3.21 AT&F Modify this command
V1.04 2017-3-28 17.24 AT+CLBS Add this command
V1.04 2017-4-13 17.9 AT+CGPSNEMARATE Add this command
V1.04 2017-4-14 15.5 HTTPS Add this chapter
V1.04 2017-4-19 17.25 AT+CLBSCFG Add this command
V1.04 2017-5-4 4.23 AT+CUSBPIDSWITCH Modify this command
V1.04 2017-5-11 17.26 AT+CASSISTLOC Add this command
V1.04 2017-5-17 16
AT Commands for Open/Close
Network
Add this chapter
V1.04 2017-5-24 18 Audio Application Commands Add this chapter
V1.04 2017-5-25 15.7 SMTP Delete this chapter
V1.04 2017-5-25 15.4 FTPS Add this chapter
V1.05 2017-6-19 15.6 HTTPS Modify HTTPS commands
V1.05 2017-7-3 16.4
Unsolicited CNETSTART/
CNETSTOP Codes
Add this command
V1.05 2017-7-3 17.24 AT+CLBS
17.25 AT+ CLBSCFG
Modify these commands
V1.05 2017-7-10 14.2 AT+CFTRANTX Modify this command
V1.05 2017-7-10 13 AT Commands for File System Modify the description
V1.05 2017-7-11 6.44 AT+CPCMFRM Add this command
V1.05 2017-7-14 15.8.9 AT+CCERTVERIFY Add this command
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
7
V1.05
2017-8-25
7.12 AT+CMGR
Modify this command
V1.05 2017-9-5 5.15 AT+CNSMOD Modify this command
V1.05 2017-9-5 5.14 AT+C PSI Modify this command
V1.06 2017-10-13 1.1 Scope Modify scope
V1.06 2017-10-13 17.24 AT+CLBS Modify this command
V1.07 2017-10-16 15.3.2 AT+CFTPMODE Modify this command
V1.07 2017-10-16 15.6.4 AT+CHTTPSCLSE Modify this command
V1.07 2017-11-3 7.9 AT+ CNMI Modify this command
V1.07 2017-11-7 12.2 AT+CFGRI Modify this command
V1.07 2017-11-13 17.25 AT+CLBS Modify this command
V1.07
2017-11-13
15.8 NTP
Add this chapter
V1.07 2017-11-13 17.23 AT+CGNSSINFO Add this command
V1.07 2017-12-14 4.23 AT+CUSBPIDSWITCH Modify this command
V1.07 2017-12-15 17.25 AT+CLBS Modify this command
V1.08 2017-12-18 17.8 AT+ CGPSNMEA Modify this command
V1.08 2017-12-18 17.24 AT+CGNSSMODE Add this command
V1.08 2018-1-10 17.26 AT+CLBS Modify this command
V1.08 2018-1-24 17.21 AT+CGPSMODE Delete this command
V1.08 2018-1-24 17.22 AT+CBDS Delete this command
V1.08 2018-1-24 15.8.2 Unsolicited NTP Codes Delete this command
V1.08
2018-2-8
15.10.1 AT+CCERTDOWN
Modify this command
V1.08 2018-2-9 15.8.1 AT+ C NTP Modify this command
V1.08 2018-2-28 13 AT Commands for File System Modify this chapter
V1.08 2018-3-2 15.10.1 AT+CCERTDOWN
15.10.2 AT+CCERTLIST
15.10.3 AT+CCERTDELE
Modify these commands
V1.08 2018-3-13 15.6.5 AT+CHTTPSSEND Modify this command
V1.08 2018-3-20 15.5.1 AT+CHTTPACT Modify this command
V1.08 2018-3-28 15.6.9
Unsolicited HTTPS command
<err> Codes
Modify this command
V1.08
2018-4-2
17.8 AT+CGPSNMEA
Modify this command
V1.08 2018-4-2 17.22 AT+CGNSSMODE Modify this command
V1.08 2018-4-2 15.6.5 AT+CHTTPSSEND Modify this command
V1.09 2018-4-17 6.45 AT+CPTONE Add this command
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
8
V1.09
2018-4-18
15.3.16 AT+CFTPSINGLEIP
Add this command
V1.09 2018-5-2 17.24 AT+ C LBS Modify this command
V1.09 2018-5-3 15.2.1 AT+CIPCCFG Modify this command
V1.09 2018-5-4 17.25 AT+CLBSCFG Modify this command
V1.09 2018-5-7 15.6.5 AT+CHTTPSSEND
15.6.5 AT+ C HTTPSRECV
Modify these commands
V1.09 2018-5-9 15.10.2 AT+CCERTLIST Modify this command
V1.09 2018-5-21 15.8.1 AT+CNTP Modify this command
V1.09 2018-5-31 4.23 AT+CUSBPIDSWITCH Modify this command
V1.09 2018-6-5 4.23 AT+CUSBPIDSWITCH Modify this command
V1.09 2018-7-10 15.2.10 AT+CIPFILTERSET Delete this command
V1.09 2018-7-11 15.8.1 AT+CNTP Modify this command
V1.09 2018-7-25 15.9 Common Channel Service
15.10
SSL Certificate & Key
Management
Add mbedtls
V1.09 2018-8-3 15.6.5 AT+ CHTTPSSEND
15.6.6 AT+ CHTTPSRECV
Modify these commands
V1.09 2018-8-3 15.9.9 AT+CCHMODE Add this command
V1.10 2018-8-16 4.23 AT+CUSBPIDSWITCH Modify this command
V1.10 2018-8-22 18.3 AT+CCMXSTOPWAV
18.5 AT+CCMXSTOP
Modify these commands
V1.10 2018-8-24 15.9 Common Channel Service
15.10
SSL Certificate & Key
Management
Delete these chapters
V1.10 2018-9-11 17.25 AT+CLBSCFG
17.26 AT+CASSISTLOC
Modify these commands
V1.10 2018-9-12 15.2 TCP/UDP
15.3 FTP
15.4 FTPS
15.5 HTTP
15.6 HTTPS
Delete these chapters
V1.10
2018-9-17
17.11 AT+CGPSFTM
17.13 AT+CGPSXE
17.16 AT+CGPSINFOCFG
Modify these commands
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
9
Contents
Version History ........................................................................................................................... 2
Contents ............................................................................................................................................ 9
1 Introduction.................................................................................................................................... 16
1.1 Scope .................................................................................................................................................... 16
1.2 References ............................................................................................................................................ 16
1.3 Terms and abbreviations ....................................................................................................................... 16
1.4 Definitions and conventions ................................................................................................................. 17
2 AT Interface Synopsis .................................................................................................................... 19
2.1 Interface settings .................................................................................................................................. 19
2.2 AT command syntax ............................................................................................................................. 19
2.3 Information responses .......................................................................................................................... 20
3 AT Commands According V.25TER .............................................................................................. 21
3.1 A/ Repeat last command.................................................................................................................... 21
3.2 ATD Dial command .......................................................................................................................... 21
3.3 ATD><mem><n> Originate call from specified memory ................................................................. 23
3.4 ATD><n> Originate call from active memory (1)............................................................................. 24
3.5 ATD><str> Originate call from active memory (2) ........................................................................... 25
3.6 ATA Call answer ................................................................................................................................ 26
3.7 ATH Disconnect existing call ............................................................................................................ 27
3.8 ATS0 Automatic answer incoming call ............................................................................................. 27
3.9 +++ Switch from data mode to command mode ............................................................................... 28
3.10 ATO Switch from command mode to data mode .............................................................................. 29
3.11 ATI Display product identification information ................................................................................ 29
3.12 AT+IPR Set local baud rate temporarily ........................................................................................... 31
3.13 AT+ICF Set control character framing .............................................................................................. 32
3.14 AT+IFC Set local data flow control................................................................................................... 33
3.15 AT&C Set DCD function mode ......................................................................................................... 34
3.16 ATE Enable command echo .............................................................................................................. 35
3.17 AT&V Display current configuration ................................................................................................ 35
3.18 AT&D Set DTR function mode ......................................................................................................... 36
3.19 AT&S Set DSR function mode .......................................................................................................... 36
3.20 ATV Set result code format mode ..................................................................................................... 37
3.21 AT&F Set all current parameters to manufacturer defaults ............................................................... 38
3.22 ATQ Set Result Code Presentation Mode.......................................................................................... 39
3.23 ATX Set CONNECT Result Code Format ........................................................................................ 39
3.24 AT\V Set CONNECT Result Code Format About Protocol .............................................................. 40
3.25 AT&E Set CONNECT Result Code Format About Speed ................................................................ 41
3.26 AT&W Save the user setting to ME .................................................................................................. 42
3.27 ATZ Restore the user setting from ME .............................................................................................. 42
3.28 AT+CGMI Request manufacturer identification ............................................................................... 43
3.29 AT+CGMM Request model identification ........................................................................................ 44
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
10
3.30 AT+CGMR Request revision identification ...................................................................................... 44
3.31 AT+CGSN Request product serial number identification ................................................................. 45
3.32 AT+CSCS Select TE character set .................................................................................................... 46
3.33 AT+CIMI Request international mobile subscriber identity ............................................................. 47
3.34 AT+CIMIM Request another international mobile subscriber identity ............................................. 47
3.35 AT+GCAP Request overall capabilities ............................................................................................ 48
4 AT Commands for Status Control .................................................................................................. 50
4.1 AT+CFUN Set phone functionality ................................................................................................... 50
4.2 AT+CPIN Enter PIN .......................................................................................................................... 51
4.3 AT+CICCID Read ICCID from SIM card ......................................................................................... 52
4.4 AT+CSIM Generic SIM access ......................................................................................................... 53
4.5 AT+CRSM Restricted SIM access .................................................................................................... 54
4.6 AT+SPIC Times remain to input SIM PIN/PUK ............................................................................... 58
4.7 AT+CSPN Get service provider name from SIM .............................................................................. 59
4.8 AT+CSQ Query signal quality .......................................................................................................... 60
4.9 AT+AUTOCSQ Set CSQ report ........................................................................................................ 61
4.10 AT+CSQDELTA Set RSSI delta change threshold ............................................................................ 62
4.11 AT+CATR Configure URC destination interface .............................................................................. 63
4.12 AT+CPOF Power down the module .................................................................................................. 64
4.13 AT+CRESET Reset the module ........................................................................................................ 65
4.14 AT+CACM Accumulated call meter ................................................................................................. 65
4.15 AT+CAMM Accumulated call meter maximum ............................................................................... 66
4.16 AT+CPUC Price per unit and currency table ..................................................................................... 67
4.17 AT+CCLK Real time clock management .......................................................................................... 68
4.18 AT+CMEE Report mobile equipment error ...................................................................................... 69
4.19 AT+CPAS Phone activity status ........................................................................................................ 70
4.20 AT+SIMEI Set IMEI for the module ................................................................................................. 71
4.21 AT+SMEID Request Mobile Equipment Identifier ........................................................................... 72
4.22 AT+CSVM Voice Mail Subscriber number ....................................................................................... 73
4.23 AT+CUSBPIDSWITCH Change module’s PID................................................................................ 74
4.24 Indication of EONS .............................................................................................................................. 75
4.25 Indication of Voice Mail ....................................................................................................................... 76
5 AT Commands for Network ........................................................................................................... 77
5.1 AT+CREG Network registration ....................................................................................................... 77
5.2 AT+COPS Operator selection ........................................................................................................... 78
5.3 AT+CLCK Facility lock .................................................................................................................... 81
5.4 AT+CPWD Change password ........................................................................................................... 82
5.5 AT+CCUG Closed user group ........................................................................................................... 84
5.6 AT+CUSD Unstructured supplementary service data ....................................................................... 85
5.7 AT+CAOC Advice of charge ............................................................................................................ 86
5.8 AT+CSSN Supplementary service notifications ................................................................................ 87
5.9 AT+CPOL Preferred operator list ...................................................................................................... 89
5.10 AT+COPN Read operator names ...................................................................................................... 91
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
5.11 AT+CNMP Preferred mode selection ................................................................................................ 92
5.12 AT+CNBP Preferred band selection .................................................................................................. 93
5.13 AT+CNAOP Acquisitions order preference ...................................................................................... 96
5.14 AT+CPSI Inquiring UE system information ..................................................................................... 97
5.15 AT+CNSMOD Show network system mode ................................................................................... 101
5.16 AT+CEREG EPS network registration status .................................................................................. 102
5.17 AT+CTZU Automatic time and time zone update ........................................................................... 104
5.18 AT+CTZR Time and time zone reporting ....................................................................................... 105
5.19 AT+NETMODE WCDMA & TDSCDMA mode select .................................................................. 106
6 AT Commands for Call Control ................................................................................................... 108
6.1 AT+CVHU Voice hang up control .................................................................................................. 108
6.2 AT+CHUP Hang up call .................................................................................................................. 109
6.3 AT+CBST Select bearer service type .............................................................................................. 109
6.4 AT+CRLP Radio link protocol ......................................................................................................... 111
6.5 AT+CR Service reporting control ..................................................................................................... 112
6.6 AT+CRC Cellular result codes ......................................................................................................... 114
6.7 AT+CLCC List current calls ............................................................................................................. 115
6.8 AT+CEER Extended error report ..................................................................................................... 117
6.9 AT+CCWA Call waiting ................................................................................................................... 118
6.10 AT+C HLD Call related supplementary services .............................................................................. 119
6.11 AT+CCFC Call forwarding number and conditions ........................................................................ 121
6.12 AT+CLIP Calling line identification presentation ........................................................................... 122
6.13 AT+CLIR Calling line identification restriction .............................................................................. 124
6.14 AT+COLP Connected line identification presentation .................................................................... 125
6.15 AT+VTS DTMF and tone generation .............................................................................................. 127
6.16 AT+VTD Tone duration .................................................................................................................. 128
6.17 AT+CSTA Select type of address .................................................................................................... 129
6.18 AT+CMOD Call mode .................................................................................................................... 130
6.19 AT+VMUTE Speaker mute control ................................................................................................ 131
6.20 AT+CMUT Microphone mute control ............................................................................................. 132
6.21 AT+MORING Enable or disable report MO ring URC................................................................... 132
6.22 AT+CSDVC Switch voice channel device ...................................................................................... 133
6.23 AT+CLVL Loudspeaker volume level ............................................................................................. 134
6.24 AT+SIDET Set sidetone .................................................................................................................. 135
6.25 AT+CACDBFN Change default ACDB filename ........................................................................... 136
6.26 AT+CPCMREG USB audio control ................................................................................................ 137
6.27 AT+CMICGAIN Adjust mic gain ................................................................................................... 138
6.28 AT+COUTGAIN Adjust out gain ................................................................................................... 139
6.29 AT+CTXVOL Adjust TX voice mic volume .................................................................................. 139
6.30 AT+CTXMICGAIN Adjust TX voice mic gain .............................................................................. 140
6.31 AT+CRXVOL Adjust RX voice output speaker volume ................................................................. 141
6.32 AT+CECH Inhibit far-end echo ....................................................................................................... 142
6.33 AT+CECDT Inhibit echo during doubletalk ................................................................................... 143
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
12
6.34 AT+CECWB Inhibit echo in the high band ..................................................................................... 144
6.35 AT+CNSN MIC NOISE suppression .............................................................................................. 145
6.36 AT+CNSLIM MIC NOISE suppression .......................................................................................... 145
6.37 AT+CFNSMOD Adjust parameter fnsMode of RX_VOICE_FNS ................................................. 146
6.38 AT+CFNSIN Adjust parameter fnsInputGain of RX_VOICE_FNS ............................................... 147
6.39 AT+CFNSLVL Adjust parameter fnsTargetNS of RX_VOICE_FNS ............................................. 148
6.40 AT+CECRX Enable or disable VOICE_MOD_ENABLE .............................................................. 149
6.41 AT+CNLPPG Modify the NLPP_gain in DSP ................................................................................ 150
6.42 AT+CNLPPL Modify the NLPP_limit in DSP ................................................................................ 150
6.43 AT+CECM Adjust echo canceller ................................................................................................... 151
6.44 AT+CPCMFRM Set usb audio sample rate to 16k bit .................................................................... 152
6.45 AT+CPTONE Play tone .................................................................................................................. 153
7 AT Commands for SMS ............................................................................................................... 155
7.1 AT+C SMS Select message service .................................................................................................. 155
7.2 AT+CPMS Preferred message storage ............................................................................................ 156
7.3 AT+CMGF Select SMS message format ......................................................................................... 158
7.4 AT+CSCA SMS service centre address ........................................................................................... 159
7.5 AT+CSCB Select cell broadcast message indication....................................................................... 160
7.6 AT+CSMP Set text mode parameters .............................................................................................. 161
7.7 AT+CSDH Show text mode parameters .......................................................................................... 162
7.8 AT+CNMA New message acknowledgement to ME/TA ................................................................ 163
7.9 AT+CNMI New message indications to TE .................................................................................... 164
7.10 AT+CGSMS Select service for MO SMS messages ....................................................................... 166
7.11 AT+CMGL List SMS messages from preferred store ..................................................................... 167
7.12 AT+CMGR Read message .............................................................................................................. 171
7.13 AT+CMGS Send message ............................................................................................................... 175
7.14 AT+CMSS Send message from storage .......................................................................................... 176
7.15 AT+CMGW Write message to memory .......................................................................................... 177
7.16 AT+CMGD Delete message ............................................................................................................ 179
7.17 AT+CMGMT Change message status ............................................................................................. 180
7.18 AT+CMVP Set message valid period .............................................................................................. 181
7.19 AT+CMGRD Read and delete message .......................................................................................... 182
7.20 AT+CMGSEX Send message .......................................................................................................... 183
7.21 AT+CMSSEX Send multi messages from storage .......................................................................... 184
7.22 AT+CMGP Set cdma/evdo text mode parameters ........................................................................... 185
8 AT Commands for Phonebook ..................................................................................................... 187
8.1 AT+CPBS Select phonebook memory storage ................................................................................ 187
8.2 AT+CPBR Read phonebook entries ................................................................................................ 188
8.3 AT+CPBF Find phonebook entries ................................................................................................. 190
8.4 AT+CPBW Write phonebook entry ................................................................................................. 191
8.5 AT+CNUM Subscriber number ....................................................................................................... 192
9 AT Commands for GPRS ............................................................................................................. 194
9.1 AT+CGREG GPRS network registration status .............................................................................. 194
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
13
9.2 AT+CGATT Packet domain attach or detach .................................................................................. 195
9.3 AT+CGACT PDP context activate or deactivate ............................................................................. 196
9.4 AT+CGDCONT Define PDP context .............................................................................................. 197
9.5 AT+CGDSCONT Define Secondary PDP Context ......................................................................... 199
9.6 AT+CGTFT Traffic Flow Template ................................................................................................ 202
9.7 AT+CGQREQ Quality of service profile (requested) ..................................................................... 205
9.8 AT+CGEQREQ 3G quality of service profile (requested) .............................................................. 207
9.9 AT+CGQMIN Quality of service profile (minimum acceptable) .................................................... 212
9.10 AT+CGEQMIN 3G quality of service profile (minimum acceptable) ............................................ 215
9.11 AT+CGDATA Enter data state ......................................................................................................... 219
9.12 AT+CGPADDR Show PDP address ................................................................................................ 220
9.13 AT+CGCLASS GPRS mobile station class .................................................................................. 222
9.14 AT+CGEREP GPRS event reporting .............................................................................................. 223
9.15 AT+CGAUTH Set type of authentication for PDP-IP connections of GPRS .................................. 225
10 Hardware Related Commands ................................................................................................. 227
10.1 AT+CVALARM Low and high voltage Alarm ................................................................................ 227
10.2 AT+CVAUXS Set state of the pin named VREG_AUX1 ............................................................... 228
10.3 AT+CVAUXV Set voltage value of the pin named VREG_AUX1 ................................................. 229
10.4 AT+CADC Read ADC value ........................................................................................................... 230
10.5 AT+CADC2 Read ADC2 value ....................................................................................................... 230
10.6 AT+CMTE Control the module whether power shutdown when the module’s temperature upon the
critical temperature ......................................................................................................................................... 231
10.7 AT+CPMVT Low and high voltage Power Off ............................................................................... 233
10.8 AT+CDELTA Set the module go to recovery mode ........................................................................ 234
10.9 AT+CRIIC Read values from register of IIC device ....................................................................... 234
10.10 AT+CWIIC Write values to register of IIC device .......................................................................... 235
10.11 AT+CBC Read the voltage value of the power supply .................................................................... 236
10.12 AT+CPMUTEMP Read the temperature of the module .................................................................. 236
11 AT Commands for SIM Application Toolkit ............................................................................ 238
11.1 AT+STIN SAT Indication ................................................................................................................ 238
11.2 AT+STGI Get SAT information ...................................................................................................... 239
11.3 AT +S TG R SAT re sp o nd .................................................................................................................. 242
11.4 AT+STK STK switch ...................................................................................................................... 243
11.5 AT+STKFMT Set STK pdu format ................................................................................................. 244
11.6 AT+STENV Original STK PDU Envelope Command .................................................................... 245
11.7 AT+STSM Get STK Setup Menu List with PDU Mode ................................................................. 246
12 AT Commands for Hardware ................................................................................................... 247
12.1 AT+IPREX Set local baud rate permanently ................................................................................... 247
12.2 AT+CFGRI Indicate RI when using URC ....................................................................................... 248
12.3 AT+CSCLK Control UART Sleep ..................................................................................................... 249
12.4 AT+CMUX Enable the multiplexer over the UART ....................................................................... 250
12.5 AT+CGFUNC Enable/disable the function for the special GPIO ...................................................... 251
12.6 AT+CGDRT Set the direction of specified GPIO ............................................................................ 253
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
14
12.7 AT+CGSETV Set the value of specified GPIO ............................................................................... 254
12.8 AT+CGGETV Get the value of specified GPIO.............................................................................. 254
12.9 AT+CGISR Set GPIO interrupt trigger condition ........................................................................... 255
13 AT Commands for File System ................................................................................................ 257
13.1 AT+FSCD Select directory as current directory .............................................................................. 257
13.2 AT+FSMKDIR Make new directory in current directory ............................................................... 258
13.3 AT+FSRMDIR Delete directory in current directory ...................................................................... 259
13.4 AT+FSLS List directories/files in current directory ........................................................................ 260
13.5 AT+FSDEL Delete file in current directory .................................................................................... 261
13.6 AT+FSRENAME Rename file in current directory ........................................................................ 262
13.7 AT+FSATTRI Request file attributes .............................................................................................. 263
13.8 AT+FSMEM Check the size of available memory .......................................................................... 264
13.9 AT+FSLOCA Select storage place .................................................................................................. 264
13.10 AT+FSCOPY Copy an appointed file ............................................................................................. 265
14 AT Commands for File Transmission ...................................................................................... 268
14.1 AT+CFTRANRX Transfer a file to EFS ......................................................................................... 268
14.2 AT+CFTRANTX Transfer a file from EFS to host ......................................................................... 269
15 AT Commands for Internet Service ......................................................................................... 271
15.1 PDP .................................................................................................................................................... 271
15.1.1 AT+CSOCKSETPN Set active PDP context’s profile number ................................................................ 271
15.1.2 AT+CIPDNSSET Set DNS query parameters .......................................................................................... 272
15.1.3 AT+CDNSGIP Query the IP address of given domain name ................................................................... 273
15.1.4 AT+CDNSGHNAME Query the domain name of given IP address ........................................................ 274
15.1.5 AT+CPING Ping destination address ....................................................................................................... 275
15.1.6 AT+CPINGSTOP Stop an ongoing ping session ..................................................................................... 277
15.1.7 AT+CTCPFIN Configure TCP FIN ......................................................................................................... 278
15.1.8 AT+CTCPKA Conigure TCP heartbeat ................................................................................................... 279
15.1.9 AT+CTEUTP Set unknown incoming TCP packet echo .......................................................................... 280
15.1.10 AT+CUPURE Set UDP port unreachable ICMP echo ............................................................................. 281
15.1.11 AT+CINICMPALLOW Preferred ICMP filter ......................................................................................... 282
15.1.12 AT+CDNSSRV Get dns server ip address ............................................................................................... 283
15.2 HTP .................................................................................................................................................... 284
15.2.1 AT+CHTPSERV Set HTP server info ...................................................................................................... 284
15.2.2 AT+CHTPUPDATE Updating date time using HTP protocol ................................................................. 286
15.2.3 Unsolicited HTP Codes .............................................................................................................................. 287
15.3 NTP .................................................................................................................................................... 287
15.3.1 AT+CNTP Update system time ............................................................................................................... 287
15.3.2 Unsolicited NTP Codes .............................................................................................................................. 288
16 AT Commands for Open/Close Network ................................................................................. 289
16.1 AT+CNETSTART Open network .................................................................................................... 289
16.2 AT+CNETSTOP Close network ...................................................................................................... 290
16.3 AT+CNETIPADDR Inquire PDP address ....................................................................................... 291
16.4 Unsolicited Open/Close network command <err> Codes .................................................................. 291
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
15
17 AT Commands for GPS ........................................................................................................... 293
17.1 AT+CGPS Start/Stop GPS session .................................................................................................. 293
17.2 AT+CGPSINFO Get GPS fixed position information ..................................................................... 294
17.3 AT+CGPSCOLD Cold start GPS .................................................................................................... 296
17.4 AT+CGPSHOT Hot start GPS......................................................................................................... 296
17.5 AT+CGPSURL Set AGPS default server URL ............................................................................... 297
17.6 AT+CGPSSSL Set AGPS transport security ................................................................................... 298
17.7 AT+CGPSAUTO Start GPS automatic ........................................................................................... 298
17.8 AT+CGPSNMEA Configure NMEA sentence type ........................................................................ 299
17.9 AT+CGPSNEMARATE Set NMEA output rate ........................................................................... 300
17.10 AT+CGPSMD Configure AGPS MO method ................................................................................. 301
17.11 AT+CGPSFTM Start GPS test mode .............................................................................................. 302
17.12 AT+CGPSDEL Delete the GPS information ................................................................................... 303
17.13 AT+CGPSXE Enable/Disable GPS XTRA function ....................................................................... 304
17.14 AT+CGPSXD Download XTRA assistant file ................................................................................ 305
17.15 AT+CGPSXDAUTO Download XTRA assistant file automatically ............................................... 306
17.16 AT+CGPSINFOCFG Report GPS NMEA-0183 sentence .............................................................. 306
17.17 AT+CGPSPMD Configure positioning mode ................................................................................. 308
17.18 AT+CGPSMSB Configure based mode switch to standalone ......................................................... 309
17.19 AT+CGPSHOR Configure positioning desired accuracy ................................................................ 310
17.20 AT+CGPSNOTIFY LCS respond positioning request ..................................................................... 311
17.21 AT+CGNSSINFO Get GNSS fixed position information ............................................................... 312
17.22 AT+CGNSSMODE Configure GNSS support mode ...................................................................... 314
17.23 Unsolicited XTRA download Codes .................................................................................................. 315
17.24 AT+CLBS Base station location ...................................................................................................... 315
17.25 AT+CLBSCFG Base station location configure .............................................................................. 318
17.26 AT+CASSISTLOC Base station location of LTE/CDMA1x mode ................................................. 319
18 Audio Application Commands ................................................................................................. 321
18.1 AT+CREC record wav audio file .................................................................................................. 321
18.2 AT+CCMXPLAYWAV Play wav audio file .................................................................................. 322
18.3 AT+CCMXSTOPWAV Stop playing wav audio file ..................................................................... 323
18.4 AT+CCMXPLAY Play audio file .................................................................................................... 323
18.5 AT+CCMXSTOP Stop playing audio file ....................................................................................... 324
19 Appendixes .............................................................................................................................. 325
19.1 Verbose code and numeric code ......................................................................................................... 325
19.2 Response string of AT+CEER ............................................................................................................ 325
19.3 Summary of CME ERROR codes ...................................................................................................... 329
19.4 Summary of CMS ERROR codes ...................................................................................................... 332
1 Introduction
1.1 Scope
The present document describes the AT Command Set for the SIMCom Module:
SIM7500 series, SIM7600 series.
More information about the SIMCom Module which includes the Software Version information can be
retrieved by the command AT I . In this document, a short description, the syntax, the possible setting values
and responses, and some examples of AT commands are presented.
Prior to using the Module, please read this document and the Version History to know the difference from
the previous document.
In order to implement communication successfully between Customer Application and the Module, it is
recommended to use the AT commands in this document, but not to use some commands which are not
included in this document.
1.2 References
The present document is based on the following standards:
[1] ETSI GSM 01.04: Abbreviations and acronyms.
[2] 3GPP TS 27.005: Use of Data Terminal Equipment – Data Circuit terminating Equipment (DTE –
DCE) interface for Short Message Service (SMS) and Cell Broadcast Service (CBS).
[3] 3GPP TS 27.007: AT command set for User Equipment (UE).
[4] WAP -224-WTP-20010710-a
[5] WAP -230-WSP-20010705-a
[6] WAP -209-MMSEncapsulation-20010601-a
1.3 Terms and abbreviations
For the purposes of the present document, the following abbreviations apply:
AT ATtention; the two-character abbreviation is used to start a command line to be sent
from TE/DTE to TA/DCE
DCE Data Communication Equipment; Data Circuit terminating Equipment
DCS Digital Cellular Network
DTE Data Terminal Equipment
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
17
DTMF Dual Tone Multi–Frequency
EDGE Enhanced Data GSM Environment
EGPRS Enhanced General Packet Radio Service
GPIO General–Purpose Input/Output
GPRS General Packet Radio Service
GSM Global System for Mobile communications
HSDPA High Speed Downlink Packet Access
HSUPA High Speed Uplink Packet Access
I2C Inter–Integrated Circuit
IMEI International Mobile station Equipment Identity
IMSI International Mobile Subscriber Identity
ME Mobile Equipment
MO Mobile–Originated
MS Mobile Station
MT Mobile–Terminated; Mobile Termination
PCS Personal Communication System
PDU Protocol Data Unit
PIN Personal Identification Number
PUK Personal Unlock Key
SIM Subscriber Identity Module
SMS Short Message Service
SMS–SC Short Message Service – Service Center
TA Terminal Adaptor; e.g. a data card (equal to DCE)
TE Terminal Equipment; e.g. a computer (equal to DTE)
UE User Equipment
UMTS Universal Mobile Telecommunications System
USIM Universal Subscriber Identity Module
WCDMA Wideband Code Division Multiple Access
FTP File Transfer Protocol
HTTP Hyper Text Transfer Protocol
RTC Real Time Clock
URC Unsolicited Result Code
1.4 Definitions and conventions
1. For the purposes of the present document, the following syntactical definitions apply:
<CR> Carriage return character.
<LF> Linefeed character.
<…> Name enclosed in angle brackets is a syntactical element. Brackets themselves do not
appear in the command line.
[…] Optional subparameter of AT command or an optional part of TA information response
is enclosed in square brackets. Brackets themselves do not appear in the command line.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
18
If subparameter is not given, its value equals to its previous value or the recommended
default value.
underline Underlined defined subparameter value is the recommended default setting or factory
setting.
2. Document conventions:
♦ Display the examples of AT commands with Italic format.
♦ Not display blank-line between command line and responses or inside the responses.
♦ Generally, the characters <CR> and <LF> are intentionally omitted throughout this document.
♦ If command response is ERROR, not list the ERROR response inside command syntax.
NOTE: AT commands and responses in figures may be not following above conventions.
3. Special marks for commands or parameters:
SIM PIN – Is the command PIN protected?
YES – AT command can be used only when SIM PIN is READY.
NO – AT command can be used when SIM card is absent or SIM PIN validation is
pending.
References – Where is the derivation of command?
3GPP TS 27.007 – 3GPP Technical Specification 127 007.
V.25ter – ITU–T Recommendation V.25ter.
Vendor – This command is supported by SIMCom.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
19
2 AT Interface Synopsis
2.1 Interface settings
Between Customer Application and the Module, standardized RS–232 interface is used for the
communication, and default values for the interface settings as following:
115200bps, 8 bit data, no parity, 1 bit stop, no data stream control.
2.2 AT command syntax
The prefix “AT ” or “at” (no case sensitive) must be included at the beginning of each command line
(except A/ and +++), and the character <CR> is used to finish a command line so as to issue the command
line to the Module. It is recommended that a command line only includes a command.
When Customer Application issues a series of AT commands on separate command lines, leave a pause
between the preceding and the following command until information responses or result codes are retrieved
by Customer Application, for example, “OK” is appeared. This advice avoids too many AT commands are
issued at a time without waiting for a response for each command.
In the present document, AT commands are divided into three categories: Basic Command, S Parameter
Command, and Extended Command.
1. Basic Command
The format of Basic Command is “AT<x><n>” or “AT&<x><n>”, “<x>” is the command name, and “<n>”
is/are the parameter(s) for the basic command, and optional. An example of Basic Command is “AT E <n>”,
which informs the TA/DCE whether received characters should be echoed back to the TE/DTE according to
the value of “<n>”; “<n>” is optional and a default value will be used if omitted.
2. S Parameter Command
The format of S Parameter Command is “ATS <n>=<m>”, “<n>” is the index of the S–register to set, and
“<m>” is the value to assign to it. “<m>” is optional; in this case, the format is “ATS<n>”, and then a
default value is assigned.
3. Extended Command
The Extended Command has several formats, as following table list:
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
20
Table 2-1: Types of Extended Command
Command Type Syntax Comments
Test Command
AT+<NAME>=?
Test the existence of the command; give some
information about the command subparameters.
Read Command AT+<NAME>? Check the current values of subparameters.
Write Command AT+<NAME>=<…> Set user-definable subparameter values.
Execution Command AT+<NAME> Read non-variable subparameters determined by
internal processes.
NOTE: The character “+” between the prefix “AT” and command name may be replaced by other
character. For example, using “#” or “$”instead of “+”.
2.3 Information responses
If the commands included in the command line are supported by the Module and the subparameters are
correct if presented, some information responses will be retrieved by from the Module. Otherwise, the
Module will report “ERROR” or “+CME ERROR” or “+CMS ERROR” to Customer Application.
Information responses start and end with <CR><LF>, i.e. the format of information responses is
“<CR><LF><response><CR><LF>”. Inside information responses, there may be one or more <CR><LF>.
Throughout this document, only the responses are presented, and <CR><LF> are intentionally omitted.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
21
3 AT Commands According V.25TER
3.1 A/ Repeat last command
Description
This command is used for implement previous AT command repeatedly (except A/), and the return
value depends on the last AT command. If A/ is issued to the Module firstly after power on, the
response “OK” is only returned.
SIM PIN References
NO
V.25ter
Syntax
Execution Command Responses
A/ The response the last AT command return
Examples
AT+GCAP
+GCAP:+CGSM,+FCLASS,+DS
OK
A/
+GCAP:+CGSM,+FCLASS,+DS
OK
3.2 ATD Dial command
Description
This command is used to list characters that may be used in a dialling string for making a call or
controlling supplementary services.
NOTE:
1. Support several “P” or “p” in the DTMF string but the valid auto-sending DTMF after characters
“P” or “p” should not be more than 29.
2.
Auto-sending DTMF after character “P” or “p” should be ASCII character in the set 0-9, *, #.
SIM PIN References
NO V25.ter
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
22
Syntax
Execution Commands Responses
ATD<n>[<mgsm>][;] Originate a voice call successfully:
OK
VOICE CALL: BEGIN
Originate a data call successfully:
CONNECT [<text>]
Originate a call unsuccessfully during command execution:
ERROR
Originate a call unsuccessfully for failed connection recovery:
NO CARRIER
Originate a call unsuccessfully for error related to the MT:
+CME ERROR: <err>
Defined values
<n>
String of dialing digits and optionally V.25ter modifiers dialing digits:
0 1 2 3 4 5 6 7 8 9 * # + A B C
Following V.25ter modifiers are ignored:
, T P ! W @
<mgsm>
String of GSM modifiers:
I Activates CLIR (disables presentation of own phone number to called party)
i Deactivates CLIR (enables presentation of own phone number to called party)
G Activate Closed User Group explicit invocation for this call only
g Deactivate Closed User Group explicit invocation for this call only
<;>
The termination character ";" is mandatory to set up voice calls. It must not be used for data and fax
calls.
<text>
CONNECT result code string; the string formats please refer ATX/AT \V/AT&E command.
<err>
Service failure result code string; the string formats please refer +CME ERROR result code and
AT+CMEE command.
Examples
ATD10086;
OK
VOICE CALL:BEGIN
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
23
3.3 ATD><mem><n> Originate call from specified memory
Description
This command is used to originate a call using specified memory and index number.
SIM PIN References
NO V.25ter
Syntax
Execution Commands Responses
ATD><mem><n>[;] Originate a voice call successfully:
OK
VOICE CALL: BEGIN
Originate a data call successfully:
CONNECT [<text>]
Originate a call unsuccessfully during command execution:
ERROR
Originate a call unsuccessfully for failed connection recovery:
NO CARRIER
Originate a call unsuccessfully for error related to the MT:
+CME ERROR: <err>
Defined values
<mem>
Phonebook storage: (For detailed description of storages see AT+CPBS)
"DC" ME dialed calls list
"MC" ME missed (unanswered received) calls list
"RC" ME received calls list
"SM" SIM phonebook
"ME" UE phonebook
"FD" SIM fixed dialing phonebook
"ON" MSISDN list
"LD" Last number dialed phonebook
"EN" Emergency numbers
<n>
Integer type memory location in the range of locations available in the selected memory, i.e. the
index returned by AT+CPBR.
<;>
The termination character ";" is mandatory to set up voice calls. It must not be used for data and fax
calls.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
24
<text>
CONNECT result code string; the string formats please refer ATX/AT\V/AT&E command.
<err>
Service failure result code string; the string formats please refer +CME ERROR result code and
AT+CMEE command.
Examples
ATD>SM3;
OK
VOICE CALL: BEGIN
3.4 ATD><n> Originate call from active memory (1)
Description
This command is used to originate a call to specified number.
SIM PIN References
NO
V.25ter
Syntax
Execution Commands Responses
ATD><n>[;] Originate a voice call successfully:
OK
VOICE CALL: BEGIN
Originate a data call successfully:
CONNECT [<text>]
Originate a call unsuccessfully during command execution:
ERROR
Originate a call unsuccessfully for failed connection recovery:
NO CARRIER
Originate a call unsuccessfully for error related to the MT:
+CME ERROR: <err>
Defined values
<n>
Integer type memory location in the range of locations available in the selected memory, i.e. the
index number returned by AT+CPBR.
<;>
The termination character ";" is mandatory to set up voice calls. It must not be used for data and fax
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
25
calls.
<text>
CONNECT result code string; the string formats please refer ATX/AT\V/AT&E command.
<err>
Service failure result code string; the string formats please refer +CME ERROR result code and
AT+CMEE command.
Examples
ATD>2;
OK
VOICE CALL: BEGIN
3.5 ATD><str> Originate call from active memory (2)
Description
This command is used to originate a call to specified number.
SIM PIN References
NO V.25ter
Syntax
Execution Commands Responses
ATD><str>[;] Originate a voice call successfully:
OK
VOICE CALL: BEGIN
Originate a data call successfully:
CONNECT [<text>]
Originate a call unsuccessfully during command execution:
ERROR
Originate a call unsuccessfully for failed connection recovery:
NO CARRIER
Originate a call unsuccessfully for error related to the MT:
+CME ERROR: <err>
Defined values
<str>
String type value, which should equal to an alphanumeric field in at least one phone book entry in
the searched memories. <str> formatted as current TE character set specified by AT+CSCS.<str>
must be double quoted.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
26
<;>
The termination character ";" is mandatory to set up voice calls. It must not be used for data and fax
calls.
<text>
CONNECT result code string; the string formats please refer ATX/AT\V/AT&E command.
<err>
Service failure result code string; the string formats please refer +CME ERROR result code and
AT+CMEE command.
Examples
ATD>”Kobe”;
OK
VOICE CALL: BEGIN
3.6 ATA Call answer
Description
This command is used to make remote station to go off-hook, e.g. answer an incoming call. If there
is no an incoming call and entering this command to TA, it will be return “NO CARRIER” to TA.
SIM PIN References
YES V.25ter
Syntax
Execution Commands Responses
ATA For voice call:
OK
VOICE CALL: BEGIN
For data call, and TA switches to data mode:
CONNECT
No connection or no incoming call:
NO CARRIER
Examples
ATA
VOICE CALL: BEGIN
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
27
3.7 ATH Disconnect existing call
Description
This command is used to disconnect existing call. Before using ATH command to hang up a voice
call, it must set AT+CVHU=0. Otherwise, ATH command will be ignored and “OK” response is
given only.
This command is also used to disconnect PS data call, and in this case it doesn’t depend on the
value of AT+CVHU.
SIM PIN References
NO V.25ter
Syntax
Execution Command Responses
ATH If AT+CVHU=0:
VOICE CALL: END: <time>
OK
OK
Defined values
<time>
Voice call connection time:
Format – HHMMSS (HH: hour, MM: minute, SS: second)
Examples
AT+CVHU=0
OK
ATH
VOICE CALL:END:000017
OK
3.8 ATS0 Automatic answer incoming call
Description
The S-parameter command controls the
automatic answering feature of the Module. If set to 000,
automatic answering is disabled, otherwise it causes the Module to answer when the incoming call
indication (RING) has occurred the number of times indicated by the specified value; and the
setting will not be stored upon power-off, i.e. the default value will be restored after restart.
SIM PIN References
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
28
YES V.25ter
Syntax
Read Command Responses
ATS0? <n>
OK
ERROR
Write Command
Responses
ATS0=<n> OK
ERROR
Defined values
<n>
000
Automatic answering mode is disable. (default value when power-on)
001–255 Enable automatic answering on the ring number specified.
NOTE: 1.The S-parameter command is effective on voice call and data call.
2.If <n> is set too high, the remote party may han
g up before the call can be answered
automatically.
Examples
ATS0?
000
OK
ATS0=003
OK
3.9 +++ Switch from data mode to command mode
Description
This command is only available during a connecting PS data call. The +++ c
haracter sequence
causes the TA to cancel the data flow over the AT interface and switch to Command Mode. This
allows to enter AT commands while maintaining the data connection to the remote device.
NOTE: To prevent the +++ escape sequence from being misinterpreted as data, it must be preceded
and followed by a pause of at least 1000 milliseconds, and the interval between two ‘+’ character
can’t exceed 900 milliseconds.
SIM PIN References
YES
V.25ter
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
29
Syntax
Execution Command Responses
+++
OK
Examples
+++
OK
3.10 ATO Switch from command mode to data mode
Description
ATO is the corresponding command to the +++ escape sequence. When there is a PS data call
connected and the TA is in Command Mode, ATO
causes the TA to resume the data and takes back
to Data Mode.
SIM PIN References
YES V.25ter
Syntax
Execution Command Responses
ATO TA/DCE switches to Data Mode from Command Mode:
CONNECT [<baud rate>]
If connection is not successfully resumed:
NO CARRIER
ERROR
Examples
ATO
CONNECT 115200
3.11 ATI Display product identification information
Description
This command is used to request the product information, which consists of manufacturer
i
dentification, model identification, revision identification, International Mobile station Equipment
Identity (IMEI) and overall capabilities of the product.
SIM PIN References
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
30
NO V.25ter
Syntax
Execution Command Responses
ATI Manufacturer: <manufacturer>
Model: <model>
Revision: <revision>
IMEI: <sn>
+GCAP: list of <name>s
OK
Defined values
<manufacturer>
The identification of manufacturer.
<model>
The identification of model.
<revision>
The revision identification of firmware.
<sn>
Serial number identification, which consists of a single line containing IMEI (International Mobile
station Equipment Identity) number.
<name>
List of additional capabilities:
+CGSM GSM function is supported
+FCLASS FAX function is supported
+DS Data compression is supported
+ES Synchronous data mode is supported.
+CIS707-A CDMA data service command set
+CIS-856 EVDO data service command set
+MS Mobile Specific command set
Examples
ATI
Manufacturer: SIMCOM INCORPORATED
Model: SIMCOM_SIM7600C
Revision: SIM7600C _V1.0
IMEI: 351602000330570
+GCAP: +CGSM,+FCLASS,+DS
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
31
OK
3.12 AT+IPR Set local baud rate temporarily
Description
This command sets the baud rate of module’s serial interface temporarily, after reboot the baud rate
is set to value of IPREX.if set to 0,then support autobaud at now,and the value of the IPR will be
changed to current baudrate when the autobaud is successful.
SIM PIN References
NO V.25ter
Syntax
Test Command Responses
AT+IPR=? +IPR: (list of supported<speed>s)
OK
Read Command
Responses
AT+IPR? +IPR: <speed>
OK
Write Command Responses
AT+IPR=<speed>
OK
ERROR
Execution Command Responses
AT+IPR Set default value 115200:
OK
Defined values
<speed>
Baud rate per second:
0, 300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200, 230400, 460800,921600,
3000000,3200000,3686400
Examples
AT+IPR?
+IPR: 115200
OK
AT+IPR=?
+IPR:(0,300,600,1200,2400,4800,9600,19200,38400,57600,115200,230400,460800,921600,
3000000,3200000,3686400)
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
32
AT+IPR=115200
OK
AT+IPR=0
OK
3.13 AT+ICF Set control character framing
Description
This command sets character framing which contains data bit, stop bit and parity bit.
SIM PIN References
NO Vendor
Syntax
Test Command
Responses
AT+ICF=? +ICF: (list of supported<format>s), (list of supported<parity>s)
OK
Read Command Responses
AT+ICF? +ICF: <format>,<parity>
OK
Write Command Responses
AT+ICF=
<format>[,<parity>]
OK
ERROR
Execution Command
Responses
AT+ICF Set default value:
OK
Defined values
<format>
1 – data bit 8, stop bit 2
2 – data bit 8, parity bit 1,stop bit 1
3 – data bit 8, stop bit 1
4 – data bit 7, stop bit 2
5 – data bit 7, parity bit 1,stop bit 1
6 – data bit 7, stop bit 1
<parity>
0 – Odd
1 – Even
2 – mark
3 – none
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
33
Examples
AT+ICF?
+ICF: 3,3
OK
AT+ICF=?
+ICF: (1-6),(0-3)
OK
AT+ICF=3,3
OK
3.14 AT+IFC Set local data flow control
Description
The command sets the flow control mode of the module.
SIM PIN References
NO V.25ter
Syntax
Test Command Responses
AT+IFC=? +IFC: (list of supported<DCE>s), (list of supported<DTE>s)
OK
ERROR
Read Command Responses
AT+IFC? +IFC: <DCE>,<DTE>
OK
ERROR
Write Command Responses
AT+IFC=<DCE>[,<DTE>] OK
ERROR
Execution Command Responses
AT+IFC Set default value:
OK
ERROR
Defined values
<DCE>
0 – none (default)
2 – RTS hardware flow control
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
34
<DTE>
0 – none (default)
2 – CTS hardware flow control
Examples
AT+IFC?
+IFC: 0,0
OK
AT+IFC=?
+IFC: (0,2),(0,2)
OK
AT+IFC=2,2
OK
3.15 AT&C Set DCD function mode
Description
This command determines how the state of DCD PIN relates to the detection of received line signal
from the distant end.
SIM PIN References
NO V.25ter
Syntax
Execution Command Responses
AT&C[<value>] OK
ERROR
Defined values
<value>
0 DCD line shall always be on.
1 DCD line shall be on only when data carrier signal is present.
2 Setting winks(briefly transitions off,then back on)the DCD line when data calls end.
Examples
AT&C1
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
35
3.16 ATE Enable command echo
Description
This command sets whether or not the TA echoes characters.
SIM PIN References
NO V.25ter
Syntax
Execution Command
Responses
ATE[<value>] OK
ERROR
Defined values
<value>
0 – Echo mode off
1 – Echo mode on
Examples
ATE1
OK
3.17 AT&V Display current configuration
Description
This command returns some of the base configuration parameters settings.
SIM PIN References
YES V.25ter
Syntax
Execution Command Responses
AT&V <TEXT>
OK
ERROR
Defined values
<TEXT>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
36
All relative configuration information.
Examples
AT&V
&C: 0; &D: 2; &F: 0; E: 1; L: 0; M: 0; Q: 0; V: 1; X: 0; Z: 0; S0: 0;
S3: 13; S4: 10; S5: 8; S6: 2; S7: 50; S8: 2; S9: 6; S10: 14; S11: 95;
+FCLASS: 0; +ICF: 3,3; +IFC: 2,2; +IPR: 115200; +DR: 0; +DS: 0,0,2048,6;
+WS46: 12; +CBST: 0,0,1;
……
OK
3.18 AT&D Set DTR function mode
Description
This command determines how the TA responds when DTR PIN is changed from the ON t
o the OFF condition during data mode.
SIM PIN References
NO V.25ter
Syntax
Execution Command Responses
AT&D[<value>]
OK
ERROR
Defined values
<value>
0 TA ignores status on DTR.
1 ON->OFF on DTR: Change to Command mode with remaining the connected call
2 ON->OFF on DTR: Disconnect call, change to Command mode.During state DTR =
OFF is auto-answer off.
Examples
AT&D1
OK
3.19 AT&S Set DSR function mode
Description
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
37
The command determines how the state of DSR pin works.
SIM PIN References
YES V.25ter
Syntax
Execution Command Responses
AT&S<value>
OK
ERROR
Defined values
<value>
0 DSR line shall always be on.
1 DSR line shall be on only when DTE and DCE are connected.
Examples
AT&S0
OK
3.20 ATV Set result code format mode
Description
This parameter setting determines the contents of the header and trailer transmitted with result
codes and information responses.
NOTE: In case of using This command without parameter <value> will be set to 0.
SIM PIN References
No
V.25ter
Syntax
Write Command Responses
ATV[<value>] If <value> =0
0
If <value> =1
OK
Defined values
<value>
0 Information response: <text><CR><LF>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
38
Short result code format: <numeric code><CR>
1 Information response: <CR><LF><text><CR><LF>
Long result code format: <CR><LF><verbose code><CR><LF>
Examples
ATV1
OK
3.21 AT&F Set all current parameters to manufacturer defaults
Description
This command is used to set all current parameters to the manufacturer defined profile.
NOTE:List of parameters reset to manufacturer default can be found in defined values, factory
default settings restorable with AT&F[<value>].
Every ongoing or incoming call will be terminated.
SIM PIN References
NO V.250
Syntax
Execution Command Responses
AT&F[<value>] OK
Defined values
<value>
0 — Set some temporary TA parameters to manufacturer defaults. The setting after power on or reset is
same as value 0.
default values
TA parameters VA L U E
AT+C AT R 0
AT+CNMP 2
AT+CNAOP ① 7,9,4,2,5,3,11
AT+CTZU 0
AT+CVAUXV 2850
① The default value of no CDMA/EVDO version is 7,9,5,3,11,2,4
Examples
AT&F
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
39
OK
3.22 ATQ Set Result Code Presentation Mode
Description
Specify whet
her the TA transmits any result code to the TE or not. Text information transmitted in
response is not affected by this setting
SIM PIN References
YES 3GPP TS 27.005
Syntax
Write Command Responses
ATQ<n> If <n>=0:
OK
If <n>=1:
No Responses
Execution Command Responses
ATQ
Set default value:0
OK
No Responses
Defined values
<n>
0 – DCE transmits result code
1 – DCE not transmits result code
Examples
ATQ0
OK
3.23 ATX Set CONNECT Result Code Format
Description
This parameter setting determines wheth
er the TA transmits unsolicited result codes or not. The
unsolicited result codes are
<CONNECT><SPEED><COMMUNICATION PROTOCOL>[<TEXT>]
SIM PIN References
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
40
YES 3GPP TS 27.005
Syntax
Write Command Responses
ATX<VALUE>
OK
ERROR
Execution Command
Responses
ATX Set default value:1
OK
ERROR
Defined values
<value>
0 – CONNECT result code returned
1,2,3,4 – May be transmits extern result codes according to AT&E and AT\V settings. Refer to
AT&E.
Examples
ATX1
OK
3.24 AT\V Set CONNECT Result Code Format About Protocol
Description
This parameter setting determines wh
ether report the communication protocol. If PS call, it also
determines wether report APN, uplink rate, downlink rate.
SIM PIN References
YES 3GPP TS 27.005
Syntax
Write Command
Responses
AT\V<value> OK
ERROR
Execution Command Responses
AT\V Set default value: 0
OK
ERROR
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
41
Defined values
<value>
0 – Don’t report
1 –
Report communication protocol. And report APN, uplink rate, downlink rate if PS call.
Refer to AT&E. The maybe
communication protocol report include
“NONE”,”PPPoverUD”,”AV32K”,”AV64K”,”PACKET”. And APN in string format while
uplink rate and downlink rate in integer format with kb unit.
Examples
AT\V0
OK
3.25 AT&E Set CONNECT Result Code Format About Speed
Description
This parameter setting determines to report Serial connection rate or Wireless connection speed. It
is valid only ATX above 0.
SIM PIN References
YES 3GPP TS 27.005
Syntax
Write Command Responses
AT&E<value> OK
ERROR
Execution Command Responses
AT&E Set default value: 1
OK
Defined values
<value>
0 – Wireless connection speed in integer format.
1 – Serial connection rate in integer format. Such as: “115200”
Examples
AT&E0
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
42
3.26 AT&W Save the user setting to ME
Description
This command will save the user settings to ME
which set by ATE, ATQ, ATV, ATX, AT&C AT&D,
AT&S, AT \V, AT+IFC and ATS0.
SIM PIN References
YES
3GPP TS 27.005
Syntax
Write Command Responses
AT&W<value> OK
ERROR
Execution Command Responses
AT&W
Set default value: 0
OK
ERROR
Defined values
<value>
0 – Save
Examples
AT&W0
OK
3.27 ATZ Restore the user setting from ME
Description
This command will restore the user setting from ME which set by ATE, ATQ, ATV, ATX, AT&C
AT&D, AT&S, AT\Q , AT \V, and ATS0.
SIM PIN References
YES 3GPP TS 27.005
Syntax
Write Command Responses
ATZ<value> OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
43
ERROR
Execution Command Responses
ATZ Set default value: 0
OK
ERROR
Defined values
<value>
0 – Restore
Examples
ATZ0
OK
3.28 AT+CGMI Request manufacturer identification
Description
This command is used to request
the manufacturer identification text, which is intended to permit
the user of the Module to identify the manufacturer.
SIM PIN References
NO 3GPP TS 27.007
Syntax
Test Command Responses
AT+CGMI=?
OK
Execution Command Responses
AT+CGMI
<manufacturer>
OK
Defined values
<manufacturer>
The identification of manufacturer.
Examples
AT+CGMI
SIMCOM INCORPORATED
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
44
3.29 AT+CGMM Request model identification
Description
This command is used to requests model identification text, which is intended to permit the user of
the Module to identify the specific model.
SIM PIN References
NO
3GPP TS 27.007
Syntax
Test Command Responses
AT+CGMM=? OK
Execution Command Responses
AT+CGMM <model>
OK
Defined values
<model>
The identification of model.
Examples
AT+CGMM
SIMCOM_SIM7600C
OK
3.30 AT+CGMR Request revision identification
Description
This command is used to
request product firmware revision identification text, which is intended to
permit the user of the Module to identify the version.
SIM PIN References
NO 3GPP TS 27.007
Syntax
Test Command Responses
AT+CGMR=? OK
Execution Command
Responses
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
45
AT+CGMR +CGMR: <revision>
OK
Defined values
<revision>
The revision identification of firmware.
Examples
AT+CGMR
+CGMR: LE11B01SIM7600C
OK
3.31 AT+CGSN Request product serial number identification
Description
This command requests product serial number
identification text, which is intended to permit the
user of the Module to identify the individual ME to which it is connected to.
SIM PIN References
NO 3GPP TS 27.007
Syntax
Test Command Responses
AT+CGSN=? OK
Execution Command Responses
AT+CGSN <sn>
OK
Defined values
<sn>
Serial number identification, which consists of a single line containing the IMEI (International
Mobile station Equipment Identity) number of the MT.
If in CDMA/EVDO mode ,it will show ESN(Electronic Serial Number)
Examples
AT+CGSN
351602000330570
OK
AT+CGSN (CDMA/EVDO mode)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
46
0x8059D1F6
OK
3.32 AT+CSCS Select TE character set
Description
Write command informs TA which character set <chest>
is used by the TE. TA is then able to
convert character strings correctly between TE and MT character sets.
Read command shows current setting and test command displays conversion schemes implemented
in the TA.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CSCS=? +CSCS: (list of supported <chset>s)
OK
Read Command Responses
AT+CSCS? +CSCS: <chset>
OK
Write Command
Responses
AT+CSCS=<chset> OK
ERROR
Execution Command Responses
AT+CSCS
Set subparameters as default value:
OK
Defined values
<chest>
Character set, the definition as following:
“IRA” International reference alphabet.
“GSM” GSM default alphabet; this setting causes easily software flow control (XON
/XOFF) problems.
“UCS2” 16-bit universal multiple-octet coded character set; UCS2 character strings are
converted to hexadecimal numbers from 0000 to FFFF.
Examples
AT+CSCS=”IRA”
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
47
OK
AT+CSCS?
+CSCS:”IRA”
OK
3.33 AT+CIMI Request international mobile subscriber identity
Description
Execution command causes the TA to return <IMSI>, which is intended to permit the TE to identify
the individual SIM card which is attached to MT.
NOTE: If USIM card contains two apps, like China Telecom 4G card, one RUIM/CSIM app, and
another USIM ap
p; so there are two IMSI in it; AT+CIMI will return the RUIM/CSIM IMSI;
AT+CIMIM will return the USIM IMSI;
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CIMI=? OK
ERROR
Execution Command Responses
AT+CIMI <IMSI>
OK
ERROR
Defined values
<IMSI>
International Mobile Subscriber Identity (string, without double quotes).
Examples
AT+CIMI
460010222028133
OK
3.34 AT+CIMIM Request another international mobile subscriber identity
Description
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
48
Execution command causes the TA to return <IMSI>, which is intended to permit the TE to identify
the individual SIM card which is attached to MT.
NOTE: If USIM card contains two apps, like China Telecom 4G card, one RUIM/CSIM app, and
another USIM app; so there are two IMSI in it; AT+CIMIM will return the USIM IMSI; AT+CIMI
will return the RUIM/CSIM IMSI;
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CIMIM=? OK
ERROR
Execution Command
Responses
AT+CIMIM <IMSI>
OK
ERROR
Defined values
<IMSI>
International Mobile Subscriber Identity (string, without double quotes).
Examples
AT+CIMIM
460110222028133
OK
3.35 AT+GCAP Request overall capabilities
Description
Execution command causes the TA reports a list of additional capabilities.
SIM PIN References
YES V.25ter
Syntax
Test Command Responses
AT+GCAP=? OK
ERROR
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
49
Execution Command
Responses
AT+GCAP +GCAP: (list of <name>s)
OK
ERROR
Defined values
<name>
List of additional capabilities.
+CGSM GSM function is supported
+FCLASS FAX function is supported
+DS Data compression is supported
+ES Synchronous data mode is supported.
+CIS707-A CDMA data service command set
+CIS-856 EVDO data service command set
+MS Mobile Specific command set
Examples
AT+GCAP
+GCAP:+CGSM,+FCLASS,+DS
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
50
4 AT Commands for Status Control
4.1 AT+CFUN Set phone functionality
Description
This command is used to select the level of functionality <fun>
in the ME. Level "full
functionality" is where the highest level of power is drawn. "Minimum functionality
" is where
minimum power is drawn. Level of functionality between these may also be specified by
manufacturers. When supported by manufacturers, ME resetting with <rst>
parameter may be
utilized.
NOTE: AT+CFUN=6 must be used after setting AT+CFUN=7. If mod
ule in offline mode, must
execute AT+CFUN=6 or restart module to online mode.
SIM PIN References
NO 3GPP TS 27.007
Syntax
Test Command Responses
AT+CFUN=? +CFUN: (list of supported <fun>s), (list of supported <rst>s)
OK
ERROR
+CME ERROR: <err>
Read Command Responses
AT+CFUN? +CFUN: <fun>
OK
ERROR
+CME ERROR: <err>
Write Command
Responses
AT+CFUN=<fun>[,<rst>] OK
ERROR
+CME ERROR: <err>
Defined values
<fun>
0 – minimum functionality
1 – full functionality, online mode
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
51
4 – disable phone both transmit and receive RF circuits
5 – Factory Test Mode
6 – Reset
7 – Offline Mode
<rst>
0 – do not reset the ME before setting it to <fun> power level
1 – reset the ME before setting it to <fun> power level. This value only takes effect when
<fun> equals 1.
Examples
AT+CFUN?
+CFUN: 1
OK
AT+CFUN=0
OK
4.2 AT+CPIN Enter PIN
Description
This command is used to
send the ME a password which is necessary before it can be operated
(SIM PIN, SIM PUK, PH-SIM PIN, etc.). If the PIN is to be e
ntered twice, the TA shall
automatically repeat the PIN. If no PIN request is pending, no action is taken towards MT and an
error message, +CME ERROR, is returned to TE.
If the PIN required is SIM PUK or SIM PUK2, the second pin is required. This second pin,
<newpin>, is used to replace the old pin in the SIM.
SIM PIN References
NO 3GPP TS 27.007
Syntax
Test Command Responses
AT+CPIN=?
OK
Read Command Responses
AT+CPIN? +CPIN: <code>
OK
ERROR
+CME ERROR: <err>
Write Command Responses
AT+CPIN=<pin>[,<newpin>
]
OK
ERROR
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
52
+CME ERROR: <err>
Defined values
<pin>
String type values.
<newpin>
String type values.
<code>
Values reserved by the present document:
READY – ME is not pending for any password
SIM PIN – ME is waiting SIM PIN to be given
SIM PUK – ME is waiting SIM PUK to be given
PH-SIM PIN – ME is waiting phone-to-SIM card password to be given
SIM PIN2 – ME is waiting SIM PIN2 to be given
SIM PUK2 – ME is waiting SIM PUK2 to be given
PH-NET PIN – ME is waiting network personalization password to be given
Examples
AT+CPIN?
+CPIN: SIM PUK2
OK
4.3 AT+CICCID Read ICCID from SIM card
Description
This command is used to Read the ICCID from SIM card
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CICCID=? OK
Execution Command Responses
AT+CICCID +ICCID: <ICCID>
OK
ERROR
+CME ERROR: <err>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
53
Defined values
<ICCID>
Integrate circuit card identity, a standard ICCID is a 20-digit serial number of the SIM card
,
it presents the publish state, network co
de, publish area, publish date, publish manufacture and
press serial number of the SIM card.
Examples
AT+CICCID
+ICCID: 898600700907A6019125
OK
4.4 AT+CSIM Generic SIM access
Description
This command is used to control the SIM card directly.
Compared to restricted SIM access command AT+CRSM, AT+CSIM allows the ME to take more
control over the SIM interface.
For SIM–ME interface please refer 3GPP TS 11.11.
NOTE
：
The SIM Application Toolkit functionality is not supported by AT+CSIM. Therefore the
following SIM commands can not be used: TERMINAL PROFILE, ENVELOPE,
FETCH and TEMINAL RESPONSE.
SIM PIN References
NO
3GPP TS 27.007
Syntax
Test Command Responses
AT+CSIM=? OK
Write Command Responses
AT+CSIM=<length>,<com
mand>
+CSIM: <length>, <response>
OK
ERROR
+CME ERROR: <err>
Defined values
<length>
Interger type; length of characters that are sent to TE in <command> or <response>
<command>
Command passed from MT to SIM card.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
54
<response>
Response to the command passed from SIM card to MT.
Examples
AT+CSIM=?
OK
4.5 AT+CRSM Restricted SIM access
Description
By using AT+CRSM instead of Generic SIM Access AT+CSIM
, TE application has easier but
more limited access to the SIM database.
Write command transmits to the MT the SIM <command> and its required parameters. MT handles
internally all SIM-MT interface locking and file selection routines. As response to the command,
MT sends the actual SIM information parameters and response data. MT error result code +CME
ERROR
may be returned when the command cannot be passed to the SIM, but failure in the
execution of the command in the SIM is reported in <sw1> and <sw2> parameters.
SIM PIN References
NO 3GPP TS 27.007
Syntax
Test Command Responses
AT+CRSM=?
OK
Write Command Responses
AT+CRSM=<command>[,<f
ileID>[,<p1>,<p2>, <p3>
[,<data>]]]
+CRSM: <sw1>,<sw2>[,<response>]
OK
ERROR
+CME ERROR: <err>
Defined values
<command>
Command passed on by the MT to the SIM:
176 – READ BINARY
178 – READ RECORD
192 – GET RESPONSE
214 – UPDATE BINARY
220 – UPDATE RECORD
242 – STATUS
203 – RETRIEVE DATA
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
55
219 – SET DATA
<fileID>
Identifier for an elementary data file on SIM, if used by <command>.
The following list the fileID hex value, user needs to convet them to decimal.
EFs under MF
0x2FE2 ICCID
0x2F05 Extended Language Preferences
0x2F00 EF DIR
0x2F06 Access Rule Reference
EFs under USIM ADF
0x6F05 Language Indication
0x6F07 IMSI
0x6F08 Ciphering and Integrity keys
0x6F09 C and I keys for pkt switched domain
0x6F60 User controlled PLMN selector w/Acc Tech
0x6F30 User controlled PLMN selector
0x6F31 HPLMN search period
0x6F37 ACM maximum value
0x6F38 USIM Service table
0x6F39 Accumulated Call meter
0x6F3E Group Identifier Level
0x6F3F Group Identifier Level 2
0x6F46 Service Provider Name
0x6F41 Price Per Unit and Currency table
0x6F45 Cell Bcast Msg identifier selection
0x6F78 Access control class
0x6F7B Forbidden PLMNs
0x6F7E Location information
0x6FAD Administrative data
0x6F48 Cell Bcast msg id for data download
0x6FB7 Emergency call codes
0x6F50 Cell bcast msg id range selection
0x6F73 Packet switched location information
0x6F3B Fixed dialling numbers
0x6F3C Short messages
0x6F40 MSISDN
0x6F42 SMS parameters
0x6F43 SMS Status
0x6F49 Service dialling numbers
0x6F4B Extension 2
0x6F4C Extension 3
0x6F47 SMS reports
0x6F80 Incoming call information
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
56
0x6F81 Outgoing call information
0x6F82 Incoming call timer
0x6F83 Outgoing call timer
0x6F4E Extension 5
0x6F4F Capability Config Parameters 2
0x6FB5 Enh Multi Level Precedence and Pri
0x6FB6 Automatic answer for eMLPP service
0x6FC2 Group identity
0x6FC3 Key for hidden phonebook entries
0x6F4D Barred dialling numbers
0x6F55 Extension 4
0x6F58 Comparison Method information
0x6F56 Enabled services table
0x6F57 Access Point Name Control List
0x6F2C De-personalization Control Keys
0x6F32 Co-operative network list
0x6F5B Hyperframe number
0x6F5C Maximum value of Hyperframe number
0x6F61 OPLMN selector with access tech
0x6F5D OPLMN selector
0x6F62 HPLMN selector with access technology
0x6F06 Access Rule reference
0x6F65 RPLMN last used access tech
0x6FC4 Network Parameters
0x6F11 CPHS: Voice Mail Waiting Indicator
0x6F12, CPHS: Service String Table
0x6F13 CPHS: Call Forwarding Flag
0x6F14 CPHS: Operator Name String
0x6F15 CPHS: Customer Service Profile
0x6F16 CPHS: CPHS Information
0x6F17 CPHS: Mailbox Number
0x6FC5 PLMN Network Name
0x6FC6 Operator PLMN List
0x6F9F Dynamic Flags Status
0x6F92 Dynamic2 Flag Setting
0x6F98 Customer Service Profile Line2
0x6F9B EF PARAMS - Welcome Message
0x4F30 Phone book reference file
0x4F22 Phone book synchronization center
0x4F23 Change counter
0x4F24 Previous Unique Identifier
0x4F20 GSM ciphering key Kc
0x4F52 GPRS ciphering key
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
57
0x4F63 CPBCCH information
0x4F64 Investigation scan
0x4F40 MExE Service table
0x4F41 Operator Root Public Key
0x4F42 Administrator Root Public Key
0x4F43 Third party Root public key
0x6FC7 Mail Box Dialing Number
0x6FC8 Extension 6
0x6FC9 Mailbox Identifier
0x6FCA Message Waiting Indication Status
0x6FCD Service Provider Display Information
0x6FD2 UIM_USIM_SPT_TABLE
0x6FD9 Equivalent HPLMN
0x6FCB Call Forwarding Indicator Status
0x6FD6 GBA Bootstrapping parameters
0x6FDA GBA NAF List
0x6FD7 MBMS Service Key
0x6FD8 MBMS User Key
0x6FCE MMS Notification
0x6FD0 MMS Issuer connectivity parameters
0x6FD1 MMS User Preferences
0x6FD2 MMS User connectivity parameters
0x6FCF Extension 8
0x5031 Object Directory File
0x5032 Token Information File
0x5033 Unused space Information File
EFs under Telecom DF
0x6F3A Abbreviated Dialing Numbers
0x6F3B Fixed dialling numbers
0x6F3C Short messages
0x6F3D Capability Configuration Parameters
0x6F4F Extended CCP
0x6F40 MSISDN
0x6F42 SMS parameters
0x6F43 SMS Status
0x6F44 Last number dialled
0x6F49 Service Dialling numbers
0x6F4A Extension 1
0x6F4B Extension 2
0x6F4C Extension 3
0x6F4D Barred Dialing Numbers
0x6F4E Extension 4
0x6F47 SMS reports
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
58
0x6F58 Comparison Method Information
0x6F54 Setup Menu elements
0x6F06 Access Rule reference
0x4F20 Image
0x4F30 Phone book reference file
0x4F22 Phone book synchronization center
0x4F23 Change counter
0x4F24 Previous Unique Identifier
<p1> <p2> <p3>
Integer type; parameters to be passed on by the Module to the SIM.
<data>
Information which shall be written to the SIM (hexadecimal character format, refer AT+CSCS).
<sw1> <sw2>
Status information from the SIM about the execution of the actual command. It is returned in both
cases, on successful or failed execution of the command.
<response>
Response data in case of a successful completion of the previously issued command.
“STATUS” and “GET RESPONSE”
commands return data, which gives information about the
currently selected elementary data field. This information includes the type of file and its size.
After “READ BINARY” or “READ RECORD” commands the requested data will be returned.
<response> is empty after “UPDATE BINARY” or “UPDATE RECORD” commands.
Examples
AT+CRSM=?
OK
4.6 AT+SPIC Times remain to input SIM PIN/PUK
Description
This command is used to inquire times remain to input SIM PIN/PUK.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+SPIC=? OK
Execution Command Responses
AT+SPIC +SPIC: <pin1>,<puk1>,<pin2>,<puk2>
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
59
Defined values
<pin1>
Times remain to input PIN1 code.
<puk1>
Times remain to input PUK1 code.
<pin2>
Times remain to input PIN2 code.
<puk2>
Times remain to input PUK2 code.
Examples
AT+SPIC=?
OK
AT+SPIC
+SPIC: 3,10,0,10
OK
4.7 AT+CSPN Get service provider name from SIM
Description
This command is used to get service provider name from SIM card.
SIM PIN References
YES Vendor
Syntax
Test Command
Responses
AT+CSPN=? OK
ERROR
Read Command Responses
AT+CSPN? +CSPN: <spn>,<display mode>
OK
OK
ERROR
+CME ERROR: <err>
Defined values
<spn>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
60
String type; service provider name on SIM
<display mode>
0 – doesn’t display PLMN. Already registered on PLMN.
1 – display PLMN
Examples
AT+CSPN=?
OK
AT+CSPN?
+CSPN: “CMCC”,0
OK
4.8 AT+CSQ Query signal quality
Description
This command is used to return received signal strength indication <rssi> and channel bit error rate
<ber> from the ME. Test command returns values supported by the TA as compound values.
SIM PIN References
NO 3GPP TS 27.007
Syntax
Test Command
Responses
AT+CSQ=? +CSQ: (list of supported <rssi>s),(list of supported <ber>s)
OK
Execution Command
Responses
AT+CSQ +CSQ: <rssi>,<ber>
OK
ERROR
Defined values
<rssi>
0 – -113 dBm or less
1 – -111 dBm
2...30 – -109... -53 dBm
31 – -51 dBm or greater
99 – not known or not detectable
100 – -116 dBm or less
101 – -115 dBm
102…191 – -114... -26dBm
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
61
191 – -25 dBm or greater
199 – not known or not detectable
100…199 – expand to TDSCDMA, indicate RSCP received
<ber>
(in percent)
0 – <0.01%
1 – 0.01% --- 0.1%
2 – 0.1% --- 0.5%
3 – 0.5% --- 1.0%
4 – 1.0% --- 2.0%
5 – 2.0% --- 4.0%
6 – 4.0% --- 8.0%
7 – >=8.0%
99 – not known or not detectable
Examples
AT+CSQ
+CSQ: 22,0
OK
4.9 AT+AUTOCSQ Set CSQ report
Description
This command is used to enable or disable automatic report CSQ info
rmation, when automatic
report enabled, the module reports CSQ information every five seconds or only after <rssi> or
<ber> is changed, the format of automatic report is “+CSQ: <rssi>,<ber>”.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+AUTOCSQ=? +AUTOCSQ: (list of supported<auto>s),(list of supported<mod
e>s)
OK
Read Command Responses
AT+AUTOCSQ? +AUTOCSQ: <auto>,<mode>
OK
Write Command Responses
AT+AUTOCSQ=<auto>[,<
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
62
mode>]
ERROR
Defined values
<auto>
0 – disable automatic report
1 – enable automatic report
<mode>
0 – CSQ automatic report every five seconds
1 – CSQ automatic report only after <rssi> or <ber> is changed
NOTE: If the parameter of <mode> is omitted when executing write command, <mode> will be set
to default value.
Examples
AT+AUTOCSQ=?
+AUTOCSQ: (0-1),(0-1)
OK
AT+AUTOCSQ?
+AUTOCSQ: 1,1
OK
AT+AUTOCSQ=1,1
OK
+CSQ: 23,0 (when <rssi> or <ber> changing)
4.10 AT+CSQDELTA Set RSSI delta change threshold
Description
This command is used to set RSSI delta threshold for signal strength reporting.
SIM PIN References
NO Vendor
Syntax
Test Command
Responses
AT+CSQDELTA=? +CSQDELTA: (list of supported <delta>s)
OK
Read Command Responses
AT+C SQDELTA? +CSQDELTA: <delta>
OK
ERROR
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
63
Write Command
Responses
AT+CSQDELTA=<delta> OK
ERROR
Execution Command Responses
AT+CSQDELTA Set default value
（
<delta>=5
）
:
OK
Defined values
<delta>
Range: from 0 to 5.
Examples
AT+CSQDELTA?
+CSQDELTA: 5
OK
4.11 AT+CATR Configure URC destination interface
Description
This command is used to configure the serial port which will be used to output
URCs. We
recommend configure a destination port for receiving URC in the system initialization phase, in
particular, in the case that transmitting large amounts of data, e.g. use TCP/UDP and MT SMS
related AT command.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CATR=? +CATR: (list of supported <port>s)
OK
Read Command Responses
AT+CATR? +CATR: <port>
OK
Write Command Responses
AT+CATR=<port>
OK
ERROR
Defined values
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
64
<port>
0 – all ports
1 – use UART port to output URCs
2 – use MODEM port to output URCs
3 – use ATCOM port to output URCs
4 – use cmux vritual port1 to output URCs
5 – use cmux virtual port2 to output URCs
6 – use cmux vritual port3 to output URCs
7 – use cmux vritual port4 to output URCs
Examples
AT+CATR=1
OK
AT+CATR?
+CATR: 1
OK
4.12 AT+CPOF Power down the module
Description
This command is used to power off the module. Once the AT+CPOF command is executed, The
module will store user data and deactivate from network, and then shutdown.
SIM PIN References
NO Vendor
Syntax
Test Command
Responses
AT+CPOF=? OK
Execution Command Responses
AT+CPOF OK
Examples
AT+CPOF
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
65
4.13 AT+CRESET Reset the module
Description
This command is used to reset the module.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CRESET=? OK
Execution Command
Responses
AT+CRESET OK
Examples
AT+CRESET=?
OK
AT+CRESET
OK
4.14 AT+CACM Accumulated call meter
Description
This command is used to reset the Advice of Charge related accumulated call meter value in SIM
file EFACM.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command
Responses
AT+CACM=?
OK
ERROR
Read Command Responses
AT+CACM? +CACM: <acm>
OK
ERROR
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
66
+CME ERROR: <err>
Write Command
Responses
AT+CACM=<passwd> OK
ERROR
+CME ERROR: <err>
Execution Command Responses
AT+CACM OK
ERROR
+CME ERROR: <err>
Defined values
<passwd>
String type, SIM PIN2.
<acm>
String type, accumulated call meter value similarly coded as <ccm> under +CAOC.
Examples
AT+CACM?
+CACM: "000000"
OK
4.15 AT+CAMM Accumulated call meter maximum
Description
This command is used to
set the Advice of Charge related accumulated call meter maximum value
in SIM file EFACMmax.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CAMM=?
OK
ERROR
Read Command
Responses
AT+CAMM? +CAMM: <acmmax>
OK
ERROR
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
67
+CME ERROR: <err>
Write Command
Responses
AT+CAMM=
<acmmax>[,<passwd>]
OK
ERROR
+CME ERROR: <err>
Execution Command Responses
AT+CAMM OK
ERROR
+CME ERROR: <err>
Defined values
<acmmax>
String type, accumulated call meter maximum value similarly coded as <ccm> under AT +CAOC,
value zero disables ACMmax feature.
<passwd>
String type, SIM PIN2.
Examples
AT+CAMM?
+CAMM: "000000"
OK
4.16 AT+CPUC Price per unit and currency table
Description
This command is used to set the parameters of Advice of Charge related price per unit and currency
table in SIM file EFPUCT..
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CPUC=? OK
ERROR
Read Command Responses
AT+CPUC? +CPUC: [<currency>,<ppu>]
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
68
ERROR
+CME ERROR: <err>
Write Command
Responses
AT+CPUC=<currency>,<pp
u>[,<passwd>]
OK
ERROR
+CME ERROR: <err>
Defined values
<currency>
String type, three-character currency code (e.g. "GBP", "DEM"), character
set as specified by
command Select TE Character Set AT +CSCS.
<ppu>
String type, price per unit, dot is used as a decimal separator. (e.g. "2.66").
<passwd>
String type, SIM PIN2.
Examples
AT+CPUC?
+CPUC: “GBP” , “2.66”
OK
4.17 AT+CCLK Real time clock management
Description
This command is used to manage Real Time Clock of the module.
SIM PIN References
NO 3GPP TS 27.007
Syntax
Test Command Responses
AT+CCLK=? OK
Read Command Responses
AT+CCLK? +CCLK: <time>
OK
Write Command Responses
AT+CCLK=<time> OK
ERROR
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
69
Defined values
<time>
String type value; format is “yy/MM/dd,hh:mm:ss±zz”
, where characters indicate year (two last
digits), month, day, hour, minutes, seconds and time zone (indicates the difference, expressed in
quarters of an hour, betw
een the local time and GMT; three last digits are mandatory, range
-47…+48). E.g. 6th of May 2008, 14:28:10 GMT+8 equals to “08/05/06,14:28:10+32”.
NOTE: 1. Time zone is nonvolatile, and the factory value is invalid time zone.
2. Command +CCLK? will
return time zone when time zone is valid, and if time zone is
00, command +CCLK? will return “+00”, but not “-00”.
Examples
AT+CCLK=“08/11/28,12:30:33+32”
OK
AT+CCLK?
+CCLK: “08/11/28,12:30:35+32”
OK
AT+CCLK=“08/11/26,10:15:00”
OK
AT+CCLK?
+CCLK: “08/11/26,10:15:02+32”
OK
4.18 AT+CMEE Report mobile equipment error
Description
This command is used to disable or enable the use of result code “+CME ERROR: <err>
” or
“+CMS ERROR: <err>” as an indication of an error relating to the functionality of ME; when
enabled, the format of <err> can be set to numeric or verbose string.
SIM PIN References
NO 3GPP TS 27.007
Syntax
Test Command Responses
AT+CMEE=?
+CMEE: (list of supported <n>s)
OK
Read Command Responses
AT+CMEE? +CMEE: <n>
OK
Write Command
Responses
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
70
AT+CMEE=<n>
OK
ERROR
Execution Command Responses
AT+CMEE
Set default value:
OK
Defined values
<n>
0 – Disable result code,i.e. only “ERROR” will be displayed.
1 – Enable error result code with numeric values.
2 – Enable error result code with string values.
Examples
AT+CMEE?
+CMEE: 2
OK
AT+CPIN="1234","1234"
+CME ERROR: incorrect password
AT+CMEE=0
OK
AT+CPIN="1234","1234"
ERROR
AT+CMEE=1
OK
AT+CPIN="1234","1234"
+CME ERROR: 16
4.19 AT+CPAS Phone activity status
Description
This command is used to return the activity status <pas> of the ME. It can be used to interrogate the
ME before requesting action from the phone.
NOTE: This command is same as AT+
CLCC, but AT+CLCC is more commonly used. So
AT+CLCC is recommended to use.
SIM PIN References
NO 3GPP TS 27.007
Syntax
Test Command
Responses
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
71
AT+CPAS=? +CPAS: (list of supported <pas>s)
OK
Execution Command Responses
AT+CPAS +CPAS: <pas>
OK
Defined values
<pas>
0 – ready (ME allows commands from TA/TE)
3 – ringing (ME is ready for commands from TA/TE, but the ringer is active)
4 – call in progress (ME is ready for commands from TA/TE, but a call is in progress)
Examples
RING (with incoming call)
AT+CPAS
+CPAS: 3
OK
AT+CPAS=?
+CPAS: (0,3,4)
OK
4.20 AT+SIMEI Set IMEI for the module
Description
This command is used to set the module’s IMEI value.
SIM PIN References
NO
Vendor
Syntax
Test Command Responses
AT+SIMEI=? OK
Read Command Responses
AT+SIMEI? +SIMEI: <imei>
OK
Write Command
Responses
AT+SIMEI=<imei> OK
ERROR
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
72
Defined values
<imei>
The 15-digit IMEI value.
Examples
AT+SIMEI=357396012183170
OK
AT+SIMEI?
+SIMEI:
357396012183170
OK
AT+SIMEI=?
OK
4.21 AT+SMEID Request Mobile Equipment Identifier
Description
Only task effect in 7600CE
SIM PIN References
NO 3GPP TS 27.007
Syntax
Read Command Responses
AT+SMEID? +SMEID: <MEID>
OK
ERROR
Defined values
<MEID>
Mobile Equipment Identifier (string, without double quotes).
Examples
AT+SMEID?
+SMEID: A1000021A5906F
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
73
4.22 AT+CSVM Voice Mail Subscriber number
Description
Execution command returns the voice mail number related to the subscriber.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command
Responses
AT+CSVM=? +CSVM: (0-1), “(0-9,+)”, (128-255)
OK
ERROR
Read Command Responses
AT+CSVM?
+CSVM: <valid>, “<number>”,<type>
OK
ERROR
Write Command
Responses
AT+CSVM=<valid>,
“<number>”,<type>
OK
ERROR
Defined values
<valid>
Whether voice mail number is valid:
0 – Voice mail number is invalid.
1 – Voice mail number is valid.
<number>
String type phone number of format specified by <type>.
<type>
Type of address octet in integer format. see also AT+CPBR <type>
Examples
AT+CSVM?
+CSVM: 1 ,"13697252277",129
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
74
4.23 AT+CUSBPIDSWITCH Change module’s PID
Description
Execution command change the module’s PID. This command will reset the module if change to
other PID (not current used PID).
SIM PIN References
NO
Vendor
Syntax
Test Command Responses
AT+CUSBPIDSWITCH=? +CUSBPIDSWITCH:
(9000,9001,9002,9003,9004,9005,9006,9007,9011,9016,9018,9019
,901A,901B,9020,9021,9022,9023,9024,9025,9026,9027,9028,902
9,902A),(0-1),(0-1)
OK
ERROR
Read Command Responses
AT+CUSBPIDSWITCH? +CUSBPIDSWITCH: <pid>
OK
ERROR
Write Command Responses
AT+CUSBPIDSWITCH=<p
id>, < reserve1>,< reserve2>
OK
ERROR
Defined values
<pid>
This command support pids, 9001 is the default value.
9000,9001,9002,9003,9004,9005,9006,9007,9011,9016,9018,9019,901A,901B,9020,9021,9022,90
23,9024,9025,9026,9027,9028,9029,902A
< reserve1>
0 or 1, this value is for the reserve
< reserve2>
0 or 1, this value is for the reserve
Examples
AT+CUSBPIDSWITCH?
+CUSBPIDSWITCH: 9001
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
75
AT+CUSBPIDSWITCH=9001,1,1
OK
PID configuration:
9000:Diag, NMEA, At, Modem, Audio, Rmnet
9001:Diag, NMEA, At, Modem, Audio, Rmnet
9002:Diag, NMEA, At, Modem, Audio, Rmnet
9003:Diag, NMEA, At, Modem, Audio, MBIM
9004:Diag, NMEA, At, Modem, Audio, GNSS, Rmnet
9005:Diag, NMEA, At, Modem, Audio, GNSS, MBIM
9006:Diag, NMEA, At,Modem
9007:Diag, NMEA, At, Modem, Audio, Rmnet,mass_storage
9011:RNDIS,Diag, NMEA, At, Modem, Audio
9016:Diag, Rmnet
9018:Diag, NMEA, At, Modem, Audio, Ecm
9019:RNDIS
901A: Diag, NMEA, At, Rmnet
901B:NMEA, At, Rmnet
9020: Diag, At, Modem
9021: Diag, Modem
9022: Diag, Modem, Rmnet
9023: Modem
9024: At, Modem
9025: Modem,rmnet
9026: Modem,Audio
9027: Modem,Audio, Rmnet
9028:Diag, Modem,Audio, Rmnet
9029:Diag, Modem,Audio
902A: At
4.24 Indication of EONS
This module supports EONS function; the following table shows the URC related EONS.
OPL INIT Description
OPL DONE This indication means EF-OPL
has been read successfully. Only
after this URC is reported, the AT+COPS? can query the network
name that supports EONS function.
PNN INIT Description
PNN DONE
This indication means EF-PNN has been read successfully
OPL UPDATING Description
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
76
OPL UPDATING This indication means the EF-OPL is updating using OTA message.
After updating, the “OPL DONE” should report.
PNN UPDATING
Description
PNN UPDATING This indication means the EF-
PNN is updating using OTA
message. After updating, the “PNN DONE” should report.
PNN UPDATING
This indication means the EF-PNN is updating using OTA
message. After updating, the “PNN DONE” should report.
4.25 Indication of Voice Mail
This module supports voice mail function; the subscriber number is configured by AT+CSVM
command, the following table shows the URC related Voice Mail.
Box Empty Description
+VOICEMAIL: EMPTY This indication means the voice mail box is empty
New Message Description
+VOICEMAIL: NEW MSG
This indication means there is a new voice mail message
notification received. This is for CPHS.
Voice Mail Status Updated
Description
+VOICEMAIL: WAITING,
<count>
This indication means that there are <count>
number of voice
mail messages that needs to be got.
Defined values
< count>
Count of voice mail message that waits to be got.
Examples
+VOICEMAIL: WAITING, <count>
+VOICEMAIL: WAITING, 5
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
77
5 AT Commands for Network
5.1 AT+CREG Network registration
Description
This command is used to control the presentation of an unsolicited result code +CREG: <stat>
when <n>=1 and there is a change in the ME network registration status, or code +CREG:
<stat>[,<lac>,<ci>] when <n>=2 and there is a change of the network cell.
Read command returns the status of result code presentation and an integer <stat> which shows
whether the
network has currently indicated the registration of the ME. Location information
elements <lac> and <ci> are returned only when <n>=2 and ME is registered in the network.
SIM PIN References
NO 3GPP TS 27.007
Syntax
Test Command
Responses
AT+CREG=? +CREG: (list of supported <n>s)
OK
Read Command Responses
AT+CREG? +CREG: <n>,<stat>[,<lac>,<ci>]
OK
ERROR
+CME ERROR: <err>
Write Command Responses
AT+CREG=<n> OK
ERROR
+CME ERROR: <err>
Execution Command
Responses
AT+CREG Set default value
（
<n>=0
）
:
OK
Defined values
<n>
0 – disable network registration unsolicited result code
1 – enable network registration unsolicited result code +CREG: <stat>
2 –
enable network registration and location information unsolicited result code +CREG:
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
78
<stat>[,<lac>,<ci>]
<stat>
0 – not registered, ME is not currently searching a new operator to register to
1 – registered, home network
2 – not registered, but ME is currently searching a new operator to register to
3 – registration denied
4 – unknown
5 – registered, roaming
<lac>
Two byte location area code in hexadecimal format(e.g.”00C3” equals 193 in decimal).
NOTE: The <lac> not supported in CDMA/HDR mode
<ci>
Cell Identify in hexadecimal format.
GSM : Maximum is two byte
WCDMA : Maximum is four byte
TDS-CDMA : Maximum is four byte
NOTE: The <ci> not supported in CDMA/HDR mode
Examples
AT+CREG?
+CREG: 0,1
OK
5.2 AT+COPS Operator selection
Description
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
79
Write command forces an attempt to select and register the GSM/UMTS network operator. <mode>
is used to select whether the selection is done automatically by the ME or is forced by this
command to operator <oper> (it shall be given in format <format>). If the selected operator is not
available, no other operator shall be selected (except <mode>
=4). The selected operator name
format shall apply to further read commands (AT +COPS?) also. <mode>=2 forces an attempt to
deregister from the network. The selected mode affects to all further network registration (e.g. after
<mode>=2, ME shall be unregistered until <mode>=0 or 1 is selected).
Read command returns the current mode and the currently selected operator. If no operator is
selected, <format> and <oper> are omitted.
Test command returns a list of quadruplets, each representing an operator present in the network.
Quadruplet consists of an integer indicating the availability of the operator <stat>, long and short
alphanumeric format of the name of the operator, and numeric format representation of the operator.
Any of the formats may be unavailable and should then be an empty field. The list of operators shall
be in order: home network, networks referenced in SIM, and other networks.
It is recommended (although optional) that after the operator list TA returns lists of supported
<mode>s and <format>s. These lists shall be delimited from the operator list by two commas.
When executing AT+COPS=? , any input from serial port will stop this command.
SIM PIN References
YES
3GPP TS 27.007
Syntax
Test Command Responses
AT+COPS=? [+COPS: [list of supported (<stat>,long alphanumeric <oper>
,short alphanumeric <oper>,numeric <oper>[,< AcT>])s]
[,,(list of supported <mode>s),(list of supported <format>s)]]
OK
ERROR
+CME ERROR: <err>
Read Command Responses
AT+COPS? +COPS: <mode>[,<format>,<oper>[,< AcT>]]
OK
ERROR
+CME ERROR: <err>
Write Command Responses
AT+COPS=<mode>[,<form
at>[,<oper>[,< AcT>]]]
OK
ERROR
+CME ERROR: <err>
Execution Command Responses
AT+COPS OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
80
Defined values
<mode>
0 – automatic
1 – manual
2 – force deregister
3 – set only <format>
4 – manual/automatic
5 –
manual,but do not modify the network selection mode(e.g GSM,WCDMA) after
module resets.
NOTE: if <mode> is set to 1, 4, 5 in write command, the <oper> is needed.
<format>
0 – long format alphanumeric <oper>
1 – short format alphanumeric <oper>
2
–
numeric <oper>
<oper>
string type, <format> indicates if the format is alphanumeric or numeric.
<stat>
0 – unknown
1 – available
2 – current
3 – forbidden
<AcT>
Access technology selected
0 – GSM
1 – GSM Compact
2 – UTRAN
7 – EUTRAN
8 – CDMA/HDR
NOTE: the value 8 do not follow the 3gpp spec, we add this value to distinguish cdma/hdr.
Examples
AT+COPS?
+COPS: 0,0,"China Mobile Com",0
OK
AT+COPS=?
+COPS: (2,"China Unicom","Unicom","46001",0),(3,"China Mobile Com","DGTMPT",
"46000",0),,(0,1,2,3,4,5),(0,1,2)
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
81
5.3 AT+CLCK Facility lock
Description
This command is used to lock, unlock or interrogate a ME or a network facility <fac>. Password is
normally needed to do such actions. When querying the status of a network service (<mode>=2) the
response line for 'not active' case (<status>=0) should be returned only if service is not active for
any <class>.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CLCK=? +CLCK: (list of supported <fac>s)
OK
ERROR
+CME ERROR: <err>
Write Command Responses
AT+CLCK=<fac>,<mode>
[,<passwd>[,<class>]]
OK
When <mode>=2 and command successful:
+CLCK:<status>[,<class1>[<CR><LF>
+CLCK: <status>,<class2>
[...]]
OK
ERROR
+CME ERROR: <err>
Defined values
<fac>
"PF" lock Phone to the very First inserted SIM card or USIM card
"SC" lock SIM card or USIM card
"AO" Barr All Outgoing Calls
"OI" Barr Outgoing International Calls
"OX" Barr Outgoing International Calls except to Home Country
"AI" Barr All Incoming Calls
"IR" Barr Incoming Calls when roaming outside the home country
"AB" All Barring services (only for <mode>=0)
"AG" All outGoing barring services (only for <mode>=0)
"AC" All inComing barring services (only for <mode>=0)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
82
"FD" SIM fixed dialing memory feature
"PN" Network Personalization
"PU" network subset Personalization
"PP" service Provider Personalization
"PC" Corporate Personalization
<mode>
0 – unlock
1 – lock
2 – query status
<status>
0 – not active
1 – active
<passwd>
Password.
string type; shall be the same as password specified for the facility from the ME user interface or
with command Change Password +CPWD
<classX>
It is a sum of integers each representing a class of information (default 7):
1 – voice (telephony)
2 – data (refers to all bearer services)
4 – fax (facsimile services)
8 – short message service
16 – data circuit sync
32 – data circuit async
64 – dedicated packet access
128 – dedicated PAD access
255 – The value 255 covers all classes
Examples
AT+CLCK="SC",2
+CLCK: 0
OK
5.4 AT+CPWD Change password
Description
Write
command sets a new password for the facility lock function defined by command Facility
Lock AT +CLCK.
Test command returns a list of pairs which present the available facilities and the maximum length
of their password.
SIM PIN References
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
83
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CPWD=? +CPWD: (list of supported (<fac>,<pwdlength>)s)
OK
ERROR
+CME ERROR: <err>
Write Command Responses
AT+CPWD=
<fac>,<oldpwd>,<newpwd>
OK
ERROR
+CME ERROR: <err>
Defined values
<fac>
Refer Facility Lock +CLCK for other values:
"SC" SIM or USIM PIN1
"P2" SIM or USIM PIN2
"AB" All Barring services
"AC" All inComing barring services (only for <mode>=0)
"AG" All outGoing barring services (only for <mode>=0)
"AI" Barr All Incoming Calls
"AO" Barr All Outgoing Calls
"IR" Barr Incoming Calls when roaming outside the home country
"OI" Barr Outgoing International Calls
"OX" Barr Outgoing International Calls except to Home Country
<oldpwd>
String type, it shall be the same as password specified for the facility from the ME user interface or
with command Change Password AT +CPWD.
<newpwd>
String type, it
is the new password; maximum length of password can be determined with
<pwdlength>.
<pwdlength>
Integer type, max length of password.
Examples
AT+CPWD=?
+CPWD: ("AB",4),("AC",4),("AG",4),("AI",4),("AO",4),("IR",4),("OI",4),("OX",4),(
"SC",8),("P2",8)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
84
OK
5.5 AT+CCUG Closed user group
Description
This command allows control of the Closed User Group supplementary service. Set command
enables the served subscriber to select a CUG index, to suppress the Outgoing Access (OA), and to
suppress the preferential C U G.
NOTE: This command not supported in CDMA/HDR mode.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command
Responses
AT+CCUG=? OK
ERROR
Read Command Responses
AT+CCUG? +CCUG: <n>,<index>,<info>
OK
ERROR
+CME ERROR: <err>
Write Command Responses
AT+CCUG=
<n>[,<index>[,<info>]]
OK
ERROR
+CME ERROR: <err>
Execution Command Responses
AT+CCUG Set default value:
OK
Defined values
<n>
0 – disable CUG temporary mode
1 – enable CUG temporary mode
<index>
0...9 – CUG index
10 – no index (preferred CUG taken from subscriber data)
<info>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
85
0 – no information
1 – suppress OA
2 – suppress preferential CUG
3 – suppress OA and preferential CUG
Examples
AT+CCUG?
+CCUG: 0,0,0
OK
5.6 AT+CUSD Unstructured supplementary service data
Description
This command allows control of the Unstructured Supplementary Service Data (USSD). Both
network and mobile initiated operations are supported. Parameter <n> is used to disable/enable the
presentation of an unsolicited result code (USSD response from the network, or network initiated
operation) +CUSD: <m>[,<str>,<dcs>] to the TE. In addition, value <n>=2 is used to cancel an
ongoing USSD session.
NOTE: This command not supported in CDMA/HDR mode.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CUSD=? +CUSD: (list of supported <n>s)
OK
Read Command Responses
AT+CUSD? +CUSD: <n>
OK
Write Command Responses
AT+CUSD=
<n>[,<str>[,<dcs>]]
OK
ERROR
+CME ERROR: <err>
Execution Command Responses
AT+CUSD
Set default value (<n>=0):
OK
Defined values
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
86
<n>
0 – disable the result code presentation in the TA
1 – enable the result code presentation in the TA
2 – cancel session (not applicable to read command response)
<str>
String type USSD-string.
<dcs>
Cell Broadcast Data Coding Scheme in integer format (default 0).
<m>
0 – no further user action required (network initiated USSD-
Notify, or no further
information needed after mobile initiated operation)
1 – further user action required (network initiated USSD-
Request, or further information
needed after mobile initiated operation)
2 – USSD terminated by network
4 – operation not supported
5 – network time out
Examples
AT+CUSD?
+CUSD: 1
OK
AT+CUSD=0
OK
5.7 AT+CAOC Advice of charge
Description
This command
refers to Advice of Charge supplementary service that enables subscriber to get
information about the cost of calls. With <mode>=0, the execute command returns the current call
meter value from the ME.
This command also includes the possibility to ena
ble an unsolicited event reporting of the CCM
information. The unsolicited result code +CCCM: <ccm> is sent when the CCM value changes, but
not more that every 10 seconds. Deactivation of the unsolicited event reporting is made with the
same command.
NOTE: This command not supported in CDMA/HDR mode.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
87
AT+CAOC=? +CAOC: (list of supported <mode>s)
OK
ERROR
Read Command
Responses
AT+CAOC? +CAOC: <mode>
OK
ERROR
+CME ERROR: <err>
Write Command
Responses
AT+CAOC=<mode> +CAOC: <ccm>
OK
OK
ERROR
+CME ERROR: <err>
Execution Command Responses
AT+CAOC Set default value (<mode>=1):
OK
ERROR
Defined values
<mode>
0 – query CCM value
1 – deactivate the unsolicited reporting of CCM value
2 – activate the unsolicited reporting of CCM value
<ccm>
S
tring type, three bytes of the current call meter value in hexadecimal format (e.g. "00001E"
indicates decimal value 30), value is in home units and bytes are similarly coded as ACMmax value
in the SIM.
Examples
AT+CAOC=0
+CAOC: "000000"
OK
5.8 AT+CSSN Supplementary service notifications
Description
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
88
This command refers to supplementary service related network initiated notifications. The set
command enables/disables the presentation of notification result codes from TA to TE.
When <n>
=1 and a supplementary service notification is received after a mobile originated call
setup, intermediate result code +CSSI: <code1>[,<index>] is sent to TE before any other MO call
setup result codes presented in the present document. When several different <code1>s are received
from the network, each of them shall have its own +CSSI result code.
When <m>
=1 and a supplementary service notification is received during a mobile terminated call
setup or dur
ing a call, or when a forward check supplementary service notification is received,
unsolicited result code +CSSU: <code2>[,<index>[,<number>,<type>[,<subaddr>,<satype>
]]] is
sent to TE. In case of MT call setup, result code is sent after every +CLIP resul
t code (refer
command "Calling line identification presentation +CLIP") and when several different <code2>s
are received from the network, each of them shall have its own +CSSU result code.
NOTE: This command not supported in CDMA/HDR mode.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CSSN=? +CSSN: (list of supported <n>s),(list of supported <m>s)
OK
ERROR
Read Command Responses
AT+CSSN? +CSSN: <n>,<m>
OK
ERROR
Write Command Responses
AT+CSSN=<n>[,<m>] OK
ERROR
+CME ERROR: <err>
Defined values
<n>
Parameter sets/shows the +CSSI result code presentation status in the TA:
0 – disable
1 – enable
<m>
Parameter sets/shows the +CSSU result code presentation status in the TA:
0 – disable
1 – enable
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
89
<code1>
0 – unconditional call forwarding is active
1 – some of the conditional call forwarding are active
2 – call has been forwarded
3 – call is waiting
5 – outgoing calls are barred
<index>
Refer "Closed user group +CCUG".
<code2>
0 – this is a forwarded call (MT call setup)
2 – call has been put on hold (during a voice call)
3 – call has been retrieved (during a voice call)
5 – call on hold has been released (this is not a SS notification) (during a voice call)
<number>
String type phone number of format specified by <type>.
<type>
T
ype of address octet in integer format; default 145 when dialing string includes international
access code character "+", otherwise 129.
<subaddr>
String type sub address of format specified by <satype>.
<satype>
Type of sub address octet in integer format, default 128.
Examples
AT+CSSN=1,1
OK
AT+CSSN?
+CSSN: 1,1
OK
5.9 AT+CPOL Preferred operator list
Description
This command is used to edit the SIM preferred list of networks.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CPOL=? +CPOL: (list of supported <index>s), (list of supported <format>s)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
90
OK
ERROR
Read Command Responses
AT+CPOL? [+CPOL:<index1>,<format>,<oper1>[<GSM_AcT1>,<GSM_Com
pact_AcT1>,<UTRAN_AcT1>,<LTE_AcT1>][<CR><LF>
+CPOL:
<index2>,<format>,<oper2>[,<GSM_AcT1>,<GSM_Compact_Ac
T1>,<UTRAN_AcT1>,<LTE_AcT1>]
[...]]]
OK
ERROR
Write Command Responses
AT+CPOL=<index>
[,<format>[,<oper>][,<GSM
_AcT1>,<GSM_Compact_A
cT1>,<UTRAN_AcT1>,<LT
E_AcT1> ]]
NOTE: If using USIM card,
the last four parameters must
set.
OK
ERROR
+CME ERROR: <err>
Defined values
<index>
Integer type, the order number of operator in the SIM preferred operator list.
If only input <index>, command will delete the value indicate by <index>.
<format>
0 – long format alphanumeric <oper>
1 – short format alphanumeric <oper>
2 – numeric <oper>
<operX>
String type.
<GSM_AcT
n
>
GSM access technology:
0 – access technology not selected
1 – access technology selected
<GSM_Compact_AcTn>
GSM compact access technology:
0 – access technology not selected
1 – access technology selected
<UTRA_AcTn>
UTRA access technology:
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
91
0 – access technology not selected
1 – access technology selected
<LTE_AcTn>
LTE access technology:
0 – access technology not selected
1 – access technology selected
Examples
AT+CPOL?
+CPOL: 1,2,"46001",0,0,1,0
OK
AT+CPOL=?
+CPOL: (1-8),(0-2)
OK
5.10 AT+COPN Read operator names
Description
This command is used to return the list of operator names from the ME. Ea
ch operator code
<numericX> that has an alphanumeric equivalent <alphaX> in the ME memory shall be returned.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+COPN=? OK
ERROR
Write Command
Responses
AT+COPN +COPN:<numeric1>,<alpha1>[<CR><LF>
+COPN: <numeric2>,<alpha2>
[...]]
OK
ERROR
+CME ERROR: <err>
Defined values
<numericX>
String type, operator in numeric format (see AT +COPS).
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
92
<alphaX>
String type, operator in long alphanumeric format (see AT+COPS).
Examples
AT+COPN
+COPN: "46000","China Mobile Com"
+COPN: "46001"," China Unicom"
……
OK
5.11 AT+CNMP Preferred mode selection
Description
This command is used to select or set the state of the mode preference.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CNMP=? +CNMP: (list of supported <mode>s)
OK
Read Command Responses
AT+CNMP? +CNMP: <mode>
OK
Write Command
Responses
AT+CNMP=<mode> OK
If <mode> not supported by module, this command will return
ERROR.
ERROR
Defined values
<mode>
2 – Automatic
13 – GSM Only
14 – WCDMA Only
38 – LTE Only
59 – TDS-CDMA Only(must use after AT+NETMODE, please refer to AT+NETMODE
command description)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
93
9 – CDMA Only
10 – EVDO Only
19 – GSM+WCDMA Only
22 – CDMA+EVDO Only
48 – Any modes but LTE
60 – GSM+TDSCDMA Only
63 – GSM+WCDMA+TDSCDMA Only
67 – CDMA+EVDO+GSM+WCDMA+TDSCDMA Only
39 – GSM+WDMA+LTE Only
54 – WDMA+LTE Only
Examples
AT+CNMP=13
OK
AT+CNMP?
+CNMP: 2
OK
5.12 AT+CNBP Preferred band selection
Description
This command is used to select or set the state of the band preference.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CNBP? +CNBP: <mode>[,<lte_mode>][,<tds_mode>]
OK
Write Command Responses
AT+CNBP=<mode>[,<lte_
mode>][,<tds_mode>]
OK
ERROR
Defined values
<mode>
64bit number, the value is “1” << “<pos>”, then or by bit.
Some special mode value declared below:
0x40000000 BAND_PREF_NO_CHANGE
<pos>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
94
Value:
0xFFFFFFFF7FFFFFFF Any (any value)
7 GSM_DCS_1800
8 GSM_EGSM_900
9 GSM_PGSM_900
16 GSM_450
17 GSM_480
18 GSM_750
19 GSM_850
20 GSM_RGSM_900
21 GSM_PCS_1900
22 WCDMA_IMT_2000
23 WCDMA_PCS_1900
24 WCDMA_III_1700
25 WCDMA_IV_1700
26 WCDMA_850
27 WCDMA_800
48 WCDMA_VII_2600
49 WCDMA_VIII_900
50 WCDMA_IX_1700
<lte_mode>
64bit number, the value is “1” << “<lte_pos>”, then or by bit.
NOTE: FDD(band1 ~ band32), TDD(band33 ~ band42)
<lte_pos>
Value:
0x000007FF3FDF3FFF Any (any value)
0 EUTRAN_BAND1(UL:1920-1980; DL:2110-2170)
1 EUTRAN_BAND2(UL:1850-1910; DL:1930-1990)
2 EUTRAN_BAND3(UL:1710-1785; DL:1805-1880)
3 EUTRAN_BAND4(UL:1710-1755; DL:2110-2155)
4 EUTRAN_BAND5(UL: 824-849; DL: 869-894)
5 EUTRAN_BAND6(UL: 830-840; DL: 875-885)
6 EUTRAN_BAND7(UL:2500-2570; DL:2620-2690)
7 EUTRAN_BAND8(UL: 880-915; DL: 925-960)
8 EUTRAN_BAND9(UL:1749.9-1784.9; DL:1844.9-1879.9)
9 EUTRAN_BAND10(UL:1710-1770; DL:2110-2170)
10 EUTRAN_BAND11(UL:1427.9-1452.9; DL:1475.9-1500.9)
11 EUTRAN_BAND12(UL:698-716; DL:728-746)
12 EUTRAN_BAND13(UL: 777-787; DL: 746-756)
13 EUTRAN_BAND14(UL: 788-798; DL: 758-768)
16 EUTRAN_BAND17(UL: 704-716; DL: 734-746)
17 EUTRAN_BAND18(UL: 815-830; DL: 860-875)
18 EUTRAN_BAND19(UL: 830-845; DL: 875-890)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
95
19 EUTRAN_BAND20(UL: 832-862; DL: 791-821)
20 EUTRAN_BAND21(UL: 1447.9-1462.9; DL: 1495.9-1510.9)
22 EUTRAN_BAND23(UL: 2000-2020; DL: 2180-2200)
23 EUTRAN_BAND24(UL: 1626.5-1660.5; DL: 1525 -1559)
24 EUTRAN_BAND25(UL: 1850-1915; DL: 1930 -1995)
25 EUTRAN_BAND26(UL: 814-849; DL: 859 -894)
26 EUTRAN_BAND27(UL: 807.5-824; DL: 852 -869)
27 EUTRAN_BAND28(703-748; DL: 758-803)
28 EUTRAN_BAND29(UL:1850-1910 or 1710-1755;
DL:716-728)
29 EUTRAN_BAND30(UL: 2305-2315 ; DL: 2350 - 2360)
32 EUTRAN_BAND33(UL: 1900-1920; DL: 1900-1920)
33 EUTRAN_BAND34(UL: 2010-2025; DL: 2010-2025)
34 EUTRAN_BAND35(UL: 1850-1910; DL: 1850-1910)
35 EUTRAN_BAND36(UL: 1930-1990; DL: 1930-1990)
36 EUTRAN_BAND37(UL: 1910-1930; DL: 1910-1930)
37 EUTRAN_BAND38(UL: 2570-2620; DL: 2570-2620)
38 EUTRAN_BAND39(UL: 1880-1920; DL: 1880-1920)
39 EUTRAN_BAND40(UL: 2300-2400; DL: 2300-2400)
40 EUTRAN_BAND41(UL: 2496-2690; DL: 2496-2690)
41 EUTRAN_BAND42(UL: 3400-3600; DL: 3400-3600)
42 EUTRAN_BAND43(UL: 3600-3800; DL: 3600-3800)
<tds_mode>
64bit number, the value is “1” << “<tds_pos>”, then or by bit.
<tds_pos>
Value:
0x000000000000003F Any (any value)
0 TDS Band A (1900-1920 MHz, 2010-2020 MHz)
1 TDS Band B (1850-1910 MHz, 1930-1990 MHz)
2 TDS Band C (1910-1930 MHz)
3 TDS Band D (2570-2620 MHz)
4 TDS Band E (2300-2400 MHz)
5 TDS Band F (1880-1920 MHz)
<term_mode>
0 – term permanent
1 – term until a power cycle
Examples
AT+CNBP=0x000700000FFF0380
OK
AT+CNBP?
+CNBP: 0x0000000000400003,0x000007FF03DF3FFF,0x000000000000003F
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
96
OK
5.13 AT+CNAOP Acquisitions order preference
Description
This command is used to reset the state of acquisitions order preference.
SIM PIN References
NO Vendor
Syntax
Read Command Responses
AT+CNAOP? +CNAOP: <mode>[,<sys_mode1>,[<sys_mode2>[,<sys_mode3>[,
<sys_mode4>[,<sys_mode5>[,<sys_mode6>]]]]]]
OK
Write Command Responses
AT+CNAOP=<mode>[,<sys
_mode1>[,<sys_mode2>[,<sy
s_mode3>[,<sys_mode4>[,<s
ys_mode5>[,<sys_mode6>]]]
]]]
OK
ERROR
Defined values
<mode>
7 – Acquistion by priority order list <sys_moden>s.
<sys_mode
n
>
sys_mode values:
2 – CDMA
3 – GSM
4 – HDR
5 – WCDMA
9 – LTE
11 – TDSCDMA
Examples
AT+CNAOP=7,9,5,3,11,2,4
OK
AT+CNAOP?
+CNAOP: 7,9,5,3,11,2,4
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
97
OK
5.14 AT+CPSI Inquiring UE system information
Description
This command is used to return the UE system information.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CPSI=? +CPSI: (scope of <time>)
OK
Read Command Responses
If camping on a cdma/evdo cell:
+CPSI: CDMA,<Operation Mode>[,<MCC>-
<MNC>,<CDMA ch
num>,<CDMA pilot PN>,<CDMA RX Chain 0 AGC>,<CDMA
RX Chain 1 AGC>,<CDMA Chain 0 LNA>,<
CDMA Chain 1
LNA>,<CDMA TX AGC>,<SID>,<NID>,<CDMA
EC/IO>,<BID>]
+CPSI: EVDO,<Operation Mode>[,<MCC>-
<MNC>,<EVDO ch
num>,<EVDO RX Chain 0 AGC>,<EVDO RX Chain 1 AGC>,<
EVDO TX AGC>,<EVDO Serving PN>,<EVDO Rel0
SCI>,<EVDO RelA SCI>,<EVDO EC/IO>]
OK
AT+CPSI?
If camping on a gsm cell:
+CPSI:<System Mode>,<Operation Mode>,<MCC>-<MNC>,<L
AC>,<Cell ID>,<Absolute RF Ch Num>,<RxLev>,
<Track LO Adjust>,<C1-C2>
OK
If camping on a wcdma cell:
+CPSI: <System Mode>,<Operation Mode>,<MCC>-<MNC>,<
LAC>,<Cell ID>,<Frequency Band>,<PSC>,<Freq>,<SSC>,<EC
/IO>,<RSCP>,<Qual>,<RxLev>,<TXPWR>
OK
If camping on a tds-cdma cell:
+CPSI: <System Mode>,<Operation Mode>,<MCC>-<MNC>,<
LAC>,<Cell ID>,<Frequency Band>,<Uarfcn>,<Cpid>
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
98
If camping on a lte cell:
+CPSI: <System Mode>,<Operation Mode>[,<MCC>-<MNC>,<
TAC>,<SCellID>,<PCellID>,<Frequency Band>,<earfcn>,<dlb
w>,<ulbw>,<RSRQ>,<RSRP>,<RSSI>,<RSSNR>]
OK
If camping on a cdma/evdo cell:
+CPSI: CDMA,<Operation Mode>[,<MCC>-
<MNC>,<CDMA ch
num>,<CDMA pilot PN>,<CDMA RX Chain 0 AGC>,<CDM
A
RX Chain 1 AGC>,<CDMA Chain 0 LNA>,<CDMA Chain 1
LNA>,<CDMA TX AGC>,<SID>,<NID>,<CDMA
EC/IO>,<BID>]
+CPSI: EVDO,<Operation Mode>[,<MCC>-
<MNC>,<EVDO ch
num>,<EVDO RX Chain 0 AGC>,<EVDO RX Chain 1 AGC>,<
EVDO TX AGC>,<EVDO Serving PN>,<EVDO Rel0
SCI>,<EVDO RelA SCI>,<EVDO EC/IO>]
OK
If camping on a cdma/ehrpd cell:
+CPSI: CDMA,<Operation Mode>[,<MCC>-
<MNC>,<CDMA ch
num>,<CDMA pilot PN>,<CDMA RX Chain 0 AGC>,<CDMA
RX Chain 1 AGC>,<CDMA Chain 0 LNA>,<CDMA Chain 1
LNA>,<CDMA TX AGC>,<SID>,<NID>,<CDMA
EC/IO>,<BID>]
+CPSI: eHRPD,<Operation Mode>[,<MCC>-
<MNC>,<EVDO ch
num>,<EVDO RX Chain 0 AGC>,<EVDO RX Chain 1 AGC>,<
EVDO TX AGC>,<EVDO Serving PN>,<EVDO Rel0
SCI>,<EVDO RelA SCI>,<EVDO EC/IO>]
OK
If camping on 1xlte cell:
+CPSI: CDMA,<Operation Mode>[,<MCC>-<M
NC>,<CDMA ch
num>,<CDMA pilot PN>,<CDMA RX Chain 0 AGC>,<CDMA
RX Chain 1 AGC>,<CDMA Chain 0 LNA>,<CDMA Chain 1
LNA>,<CDMA TX AGC>,<SID>,<NID>,<CDMA
EC/IO>,<BID>]
+CPSI: LTE,<Operation Mode>[,<MCC>-<MNC>,<TAC>,<SCe
llID>,<PCellID>,<Frequency Band>,<earfcn>,<dlbw>,<ulbw>,<R
SRQ>,<RSRP>,<RSSI>,<RSSNR>]
OK
If no service:
+CPSI: NO SERVICE, Online
OK
ERROR
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
99
Write Command
Responses
AT+CPSI=<time> OK
ERROR
Defined values
<time>
The range is 0-255, unit is second, after set <time> will report the system information every the
seconds.
<System Mode>
System mode, values: “NO SERVICE”, “GSM”, “WCDMA”, “LTE”, “TDS”…
If module in LIMITED SERVICE state and +CNLSA command is set to 1, the system mode will
display as “GSM-LIMITED”, “WCDMA-LIMITED”…
<Operation Mode>
UE operation mode, values: “Unknown”, “Online”, “Offline”, “Factory Test Mode”, “Reset”, “Low
Power Mode”.
<MCC>
Mobile Country Code (first part of the PLMN code)
<MNC>
Mobile Network Code (second part of the PLMN code)
<LAC>
Location Area Code (hexadecimal digits)
<Cell ID>
Service-cell Identify.
<Absolute RF Ch Num>
AFRCN for service-cell.
<Track LO Adjust>
Track LO Adjust
<C1>
Coefficient for base station selection
<C2>
Coefficient for Cell re-selection
<Frequency Band>
Frequency Band of active set
<PSC>
Primary synchronization code of active set.
<Freq>
Downlink frequency of active set.
<SSC>
Secondary synchronization code of active set
<EC/IO>
Ec/Io value
<RSCP>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
100
Received Signal Code Power
<Qual>
Quality value for base station selection
<RxLev>
RX level value for base station selection
<TXPWR>
UE TX power in dBm. If no TX, the value is 500.
<Cpid>
Cell Parameter ID
<TAC>
Tracing Area Code
<PCellID>
Physical Cell ID
<earfcn>
E-UTRA absolute radio frequency channel number for searching LTE cells
<dlbw>
Transmission bandwidth configuration of the serving cell on the downlink
<ulbw>
Transmission bandwidth configuration of the serving cell on the uplink
<RSRP>
Current reference signal received power in -1/10 dBm. Available for LTE
<RSRQ>
Current reference signal receive quality as measured by L1.
<RSSNR>
Average reference signal signal-to-noise ratio of the serving cell
<BID>
Base ID
Examples
AT+CPSI?
+CPSI: GSM,Online,460-00,0x182d,12401,27 EGSM 900,-64,2110,42-42
OK
AT+CPSI?
+CPSI: WCDMA,Online,460-01,0xA809,11122855,WCDMA IMT 2000,279,10663,0,1.5,62,33,
52,500
OK
AT+CPSI=?
+CPSI: (0-255)
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
101
5.15 AT+CNSMOD Show network system mode
Description
This command is used to return the current network system mode.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CNSMOD=? +CNSMOD: (list of supported <n>s)
OK
Read Command Responses
AT+CNSMOD? +CNSMOD: <n>,<stat>
OK
ERROR
+CME ERROR: <err>
Write Command Responses
AT+CNSMOD=<n> OK
ERROR
+CME ERROR: <err>
Defined values
<n>
0 – disable auto report the network system mode information
1 – auto report the network system mode information, command: +CNSMOD:<stat>
<stat>
0 – no service
1 – GSM
2 – GPRS
3 – EGPRS (EDGE)
4 – WCDMA
5 – HSDPA only(WCDMA)
6 – HSUPA only(WCDMA)
7 – HSPA (HSDPA and HSUPA, WCDMA)
8 – LTE
9 – TDS-CDMA
10 – TDS-HSDPA only
11 – TDS- HSUPA only
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
102
12 – TDS- HSPA (HSDPA and HSUPA)
13 – CDMA
14 – EVDO
15 – HYBRID (CDMA and EVDO)
16 – 1XLTE(CDMA and LTE)
23 – eHRPD
24 – HYBRID(CDMA and eHRPD)
Examples
AT+CNSMOD?
+CNSMOD: 0,2
OK
5.16 AT+CEREG EPS network registration status
Description
The set command controls the presentation of an unsolicited result code +CEREG: <stat> when
<n>=1 and there is a change in the MT's EPS network registration status in E-
UTRAN, or
unsolicited result code +CEREG: <stat>[,<tac>,<ci>[,<AcT>]] when <n>=2 and there is a change
of the network cell in E-UTRAN; in this latest case <AcT>, <tac> and <ci> are sent o
nly if
available.
NOTE 1: If the EPS MT in GERAN/UTRAN/E-UTRAN also supports circuit mode services and/or
GPRS services, the +CREG command and +CREG
: result codes and/or the +CGREG command
and +CGREG: result codes apply to the registration status and locat
ion information for those
services.
The read command returns the status of result code presentation and an integer <stat> which shows
whether the network has currently indicated the registration of the MT. Location information
elements <tac>, <ci> and <AcT>, if available, are returned only when <n>=2 and MT is registered
in the network.
SIM PIN References
NO 3GPP TS 24.008 [8]
Syntax
Test Command Responses
AT+C EREG=? +CEREG: (list of supported <n>s)
OK
ERROR
Read Command Responses
AT+C EREG? +CEREG: <n>,<stat>[,<tac>,<ci>[,<AcT>]]
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
103
ERROR
Write Command Responses
AT+CEREG=[<n>] OK
ERROR
+CME ERROR: <err>
Execution Command Responses
AT+CEREG
Set default value
（
<n>=0
）
:
OK
ERROR
Defined values
<n>
0 – disable network registration unsolicited result code
1 – enable network registration unsolicited result code +CEREG: <stat>
2 – enable network registration and location information unsolicit
ed result code
+CEREG: <stat>[,<tac>,<ci>[,<AcT>]]
<stat>
0 – not registered, MT is not currently searching an operator to register to
1 – registered, home network
2 – not registered, but MT is currently trying to attach or searching an operator to register to
3 – registration denied
4 – unknown (e.g. out of E-UTRAN coverage)
5 – registered, roaming
6 – registered for "SMS only", home network (not applicable)
7 – registered for "SMS only", roaming (not applicable)
8 – attached for emergency bearer services only (See NOTE 2)
<tac>
string type; two byte tracking area code in hexadecimal format (e.g. "00C3" equals 195 in decimal)
<ci>
string type; four byte E-UTRAN cell identify in hexadecimal format
<AcT>
A numberic parameter that indicates the access technology of serving cell
0 GSM (not applicable)
1 GSM Compact (not applicable)
2 UTRAN (not applicable)
3 GSM w/EGPRS (see NOTE 3) (not applicable)
4 UTRAN w/HSDPA (see NOTE 4) (not applicable)
5 UTRAN w/HSUPA (see NOTE 4) (not applicable)
6 UTRAN w/HSDPA and HSUPA (see NOTE 4) (not applicable)
7 E-UTRAN
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
104
Examples
AT+CEREG?
+CEREG: 0,4
OK
5.17 AT+CTZU Automatic time and time zone update
Description
This command is used to enable and disable automatic time and time zone update via NITZ
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CTZU=? +CTZU: (list of supported <on/off>s)
OK
Read Command Responses
AT+CTZU? +CTZU: < on/off >
OK
Write Command
Responses
AT+CTZU=< on/off > OK
ERROR
Defined values
<on/off>
Integer type value indicating:
0 – Disable automatic time zone update via NITZ (default).
1 – Enable automatic time zone update via NITZ.
NOTE: 1. The value of < on/off > is nonvolatile, and factory value is 0.
2. For automatic time and time zone update is enabled (+CTZU=1):
If time zone is only received from network and it isn’
t equal to local time zone
(AT+CCLK
), time zone is updated automatically, and real time clock is updated based
on local time and the difference between time zone from network and local time zone
(Local time zone must be valid).
If Universal Time and time zone are received from network, both time zone and real
time clock is updated automatically, and real time clock is based on Universal Time and
time zone from network.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
105
Examples
AT+CTZU?
+CTZU: 0
OK
AT+CTZU=1
OK
5.18 AT+CTZR Time and time zone reporting
Description
This command is used to enable and disable the time zone change event reporting. If the reporting
is enabled the MT returns the unsolicited result code +CTZV: <tz>[,<time>][,<dst>]whenever the
time zone is changed.
NOTE: The time zone reporting is not affected by the Automatic Time and Time Zone command
AT+CTZU.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CTZR=? +CTZR: (list of supported < on/off >s)
OK
Read Command
Responses
AT+CTZR? +CTZR: < on/off >
OK
Write Command Responses
AT+CTZR=< on/off >
OK
ERROR
Execution Command Responses
AT+CTZR Set default value:
OK
Defined values
<on/off>
Integer type value indicating:
0 – Disable time zone change event reporting (default).
1 – Enable time zone change event reporting.
+CTZV: <tz>[,<time>][,<dst>]
Unsolicited result code when time zone received from network isn’t equal to local time zone, and if
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
106
the informations from network don’t incl
ude date and time, time zone will be only reported, and if
network daylight saving time is present, it is also reported. For example:
+CTZV: 32 (Only report time zone)
+CTZV: 32,1 (Report time zone and network daylight saving time)
+CTZV: 32,08/12/09,17:00:00 (Report time and time zone)
+CTZV: 32,08/12/09,17:00:00,1 (Report time, time zone and daylight saving time)
For more detailed informations about time and time zone, please refer 3GPP TS 24.008.
<tz> Local time zone received from network.
<time> Universal time received from network, and the format is “yy/MM/dd,hh:mm:ss”,
where characters indicate year (two last digits), month, day, hour, minutes and
seconds.
<dst> Network daylight saving time, and if it is received from network, it indicates the
value that has been used to adjust the local time zone. The values as following:
0 – No adjustment for Daylight Saving Time.
1 – +1 hour adjustment for Daylight Saving Time.
2 – +2 hours adjustment for Daylight Saving Time.
NOTE: Herein, <time> is Universal Time or NITZ time, but not local time.
Examples
AT+CTZR?
+CTZR: 0
OK
AT+CTZR=1
OK
5.19 AT+NETMODE WCDMA & TDSCDMA mode select
Description
Syntax
Test Command Responses
AT+NETMODE=? +NETMODE: (list of supported <netmode>s)
OK
This command is used to select WCDMA mode or TDSCDMA mode.
NOTE: The
command will take effect after reboot system next time if you modify the current
mode. The WCDMA and TDSCDMA can not work at the same time. Only for 7500 and
7600 module.
SIM PIN References
NO
Vendor
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
107
Read Command
Responses
AT+NETMODE? +NETMODE: <netmode>
OK
Write Command Responses
AT+NETMODE=<netmode
>
OK
ERROR
Defined values
<netmode>
Integer type value indicating:
1 – TDSCDMA mode.
2 – WCDMA mode(default).
Examples
AT+NETMODE?
+NETMODE: 2
OK
AT+NETMODE=1
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
108
6 AT Commands for Call Control
6.1 AT+CVHU Voice hang up control
Description
Write command selects whether ATH or “drop DTR
” shall cause a voice connection to be
disconnected
or not. By voice connection is also meant alternating mode calls that are currently in
voice mode.
SIM PIN References
NO 3GPP TS 27.007
Syntax
Test Command
Responses
AT+CVHU=? +CVHU: (list of supported <mode>s)
OK
Read Command Responses
AT+CVHU? +CVHU: <mode>
OK
Write Command Responses
AT+CVHU=<mode> OK
ERROR
Execution Command Responses
AT+CVHU Set default value:
OK
Defined values
<mode>
0 – “Drop DTR” ignored but OK response given. ATH disconnects.
1 – “Drop DTR” and ATH ignored but OK response given.
Examples
AT+CVHU=0
OK
AT+CVHU?
+CVHU: 0
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
109
6.2 AT+CHUP Hang up call
Description
This command is used to cancel voice calls. If there is no call, it will do nothing but OK response is
given. After running AT+CHUP, multiple “VOICE CALL END: ” may be reported which relies on
how many calls exist before calling this command.
SIM PIN References
NO 3GPP TS 27.007
Syntax
Test Command Responses
AT+CHUP=? OK
Execution Command Responses
AT+CHUP VOICE CALL: END: <time>
[…
VOICE CALL: END: <time>]
OK
No call:
OK
Defined values
<time>
Voice call connection time.
Format – HHMMSS (HH: hour, MM: minute, SS: second)
Examples
AT+CHUP
VOICE CALL:END: 000017
OK
6.3 AT+CBST Select bearer service type
Description
Write command selects the bearer service <name> with data rate <speed>, and the connection
element <ce>
to be used when data calls are originated. Values may also be used during mobile
terminated data call setup, especially in case of single numbering scheme calls.
SIM PIN References
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
110
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CBST=? +CBST: (list of supported <speed>s), (list of supported <name>s),
(list of supported <ce>s)
OK
Read Command Responses
AT+CBST? +CBST: <speed>,<name>,<ce>
OK
Write Command Responses
AT+CBST=
<speed>[,<name>[,<ce>]]
OK
ERROR
Execution Command
Responses
AT+CBST Set default value:
OK
Defined values
<speed>
0 – autobauding(automatic selection of the speed; this setting is possible in case of 3.1
kHz modem and non-transparent service)
7 – 9600 bps (V.32)
12 – 9600 bps (V.34)
14 – 14400 bps(V.34)
16 – 28800 bps(V.34)
17 – 33600 bps(V.34)
39 – 9600 bps(V.120)
43 – 14400 bps(V.120)
48 – 28800 bps(V.120)
51 – 56000 bps(V.120)
71 – 9600 bps(V.110)
75 – 14400 bps(V.110)
80 – 28800 bps(V.110 or X.31 flag stuffing)
81 – 38400 bps(V.110 or X.31 flag stuffing)
83 – 56000 bps(V.110 or X.31 flag stuffing)
84 – 64000 bps(X.31 flag stuffing)
116 – 64000 bps(bit transparent)
134 – 64000 bps(multimedia)
<name>
0 – Asynchronous modem
1 – Synchronous modem
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
111
4 – data circuit asynchronous (RDI)
<ce>
0 – transparent
1 – non-transparent
NOTE: If <speed> is set to 116 or 134, it is necessary that <name> is equal to 1 and <ce> is equal
to 0.
Examples
AT+CBST=0,0,1
OK
AT+CBST?
+CBST:0,0,1
OK
6.4 AT+CRLP Radio link protocol
Description
Radio Link Protocol(RLP) parameters used when non-transparent data calls are originated may be
altered with write command.
Read command returns current settings for each supported RLP version <verX>
. Only RLP
parameters applicable to the corresponding <verX> are returned.
Test command returns values supported by the TA as a compound value. If ME/TA supports several
RLP versions <verX>, the RLP parameter value ranges for each <verX> are returned in a separate
line.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command
Responses
AT+CRLP=? +CRLP: (list of supported <iws>s), (list of supported <mws>
s),
(list of supported <T1>s), (list of supported <N2>s) [,<ver1>
[,(list of supported <T4>s)]][<CR><LF>
+CRLP: (list of supported <iws>s), (list of supported <mws>
s),
(list of supported <T1>s), (list of supported <N2>s) [,<ver2>
[,(list of supported <T4>s)]]
[...]]
OK
Read Command Responses
AT+CRLP? +CRLP: <iws>, <mws>, <T1>, <N2> [,<ver1> [, <T4>]][
<CR>
<LF>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
112
+CRLP:<iws>,<mws>,<T1>,<N2>[,<ver2>[,<T4>]]
[...]]
OK
Write Command Responses
AT+CRLP=<iws>
[,<mws>[,<T1>[,<N2>
[,<ver>[,<T4>]]]]]
OK
ERROR
Execution Command Responses
AT+CRLP OK
Defined values
<ver>, <verX>
RLP version number
in integer format, and it can be 0, 1 or 2; when version indication is not
present it shall equal 1.
<iws>
IWF to MS window size.
<mws>
MS to IWF window size.
<T1>
Acknowledgement timer.
<N2>
Retransmission attempts.
<T4>
Re-sequencing period in integer format.
NOTE: <T1> and <T4> are in units of 10 ms.
Examples
AT+CRLP?
+CRLP:61,61,48,6,0
+CRLP:61,61,48,6,1
+CRLP:240,240,52,6,2
OK
6.5 AT+CR Service reporting control
Description
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
113
Write command controls whether or not intermediate result code “+CR: <serv>” is returned from
the TA to the TE. If enabled, the intermediate result code is transmitted at the point during connect
negotiation at which the TA has determined which speed and quality of service will be used, before
any error control or data co
mpression reports are transmitted, and before the intermediate result
code CONNECT is transmitted.
SIM PIN References
YES
3GPP TS 27.007
Syntax
Test Command Responses
AT+CR=? +CR: (list of supported <mode>s)
OK
Read Command Responses
AT+CR? +CR: <mode>
OK
Write Command Responses
AT+CR=<mode> OK
Execution Command Responses
AT+CR Set default value:
OK
Defined values
<mode>
0 – disables reporting
1 – enables reporting
<serv>
ASYNC asynchronous transparent
SYNC synchronous transparent
REL ASYNC asynchronous non-transparent
REL sync synchronous non-transparent
GPRS [<L2P>] GPRS
The optional <L2P> proposes a layer 2 protocol to use between the MT and the TE.
Examples
AT+CR?
+CR:0
OK
AT+CR=1
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
114
6.6 AT+CRC Cellular result codes
Description
Write command controls whether or not the extended format of incoming call indication or GPRS
network request for PDP context activation is used. When enabled, an incoming call is indicated to
the TE with unsolicited result code “+CRING: <type>” instead of the normal RING.
Test command returns values supported by the TA as a compound value.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CRC=? +CRC: (list of supported <mode>s)
OK
Read Command Responses
AT+CRC?
+CRC: <mode>
OK
Write Command Responses
AT+CRC=<mode>
OK
Execution Command
Responses
AT+CRC Set default value:
OK
Defined values
<mode>
0 – disable extended format
1 – enable extended format
<type>
ASYNC asynchronous transparent
SYNC synchronous transparent
REL ASYNC asynchronous non-transparent
REL SYNC synchronous non-transparent
FAX facsimile
VOICE normal voice
VOICE/XXX voice followed by data(XXX
is ASYNC, SYNC, REL ASYNC or REL
SYNC)
ALT VOICE/XXX alternating voice/data, voice first
ALT XXX/VOICE alternating voice/data, data first
ALT FAX/VOICE alternating voice/fax, fax first
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
115
GPRS GPRS network request for PDP context activation
Examples
AT+CRC=1
OK
AT+CRC?
+CRC: 1
OK
6.7 AT+CLCC List current calls
Description
This command isused to r
eturn list of current calls of ME. If command succeeds but no calls are
available, no information response is sent to TE.
SIM PIN References
NO 3GPP TS 27.007
Syntax
Test Command Responses
AT+CLCC=? +CLCC: (list of supported <n>s)
OK
Read Command Responses
AT+CLCC? +CLCC: <n>
OK
Write Command
Responses
AT+CLCC=<n>
OK
Execution Command Responses
AT+CLCC +CLCC:<id1>,<dir>,<stat>,<mode>,<mpty>[,<number>,<type>[,<
alpha>]][<CR><LF>
+CLCC:<id2>,<dir>,<stat>,<mode>,<mpty>[,<number>,<type>[,<
alpha>]]
[...]]
OK
ERROR
+CME ERROR: <err>
Defined values
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
116
<n>
0 – Don’t
report a list of current calls of ME automatically when the current call status
changes.
1 – Report a list of current calls of ME automatically when the current call status changes.
<idX>
Integer type, call identification number, this number can be used in +CHLD command operations.
<dir>
0 – mobile originated (MO) call
1 – mobile terminated (MT) call
<stat>
State of the call:
0 – active
1 – held
2 – dialing (MO call)
3 – alerting (MO call)
4 – incoming (MT call)
5 – waiting (MT call)
6 – disconnect
<mode>
bearer/teleservice:
0 – voice
1 – data
2 – fax
9 – unknown
<mpty>
0 – call is not one of multiparty (conference) call parties
1 – call is one of multiparty (conference) call parties
<number>
String type phone number in format specified by <type>.
<type>
Type of address octet in integer format;
128 – Restricted number type includes unknown type and format
145 – International number type
161 – national number.The network support for this type is optional
177 – network specific number,ISDN format
129 – Otherwise
<alpha>
String type alphanumeric representation of <number> corresponding to the entry found in
phonebook; used character set should be the one selected with command Select TE Character Set
AT+CSCS.
Examples
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
117
ATD10011;
OK
AT+CLCC
+CLCC: 1,0,0,0,0,"10011",129,"sm"
OK
RING (with incoming call)
AT+CLCC
+CLCC: 1,1,4,0,0,"02152063113",128,"gongsi"
OK
6.8 AT+CEER Extended error report
Description
Execution command causes the TA to return the information text <report>, which should offer the
user of the TA an extended report of the reason for:
1 The failure in the last unsuccessful call setup(originating or answering) or in-call
modification.
2 The last call release.
3 The last unsuccessful GPRS attach or unsuccessful PDP context activation.
4 The last GPRS detach or PDP context deactivation.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CEER=? OK
Execution Command Responses
AT+CEER +CEER:<report>
OK
Defined values
<report>
Wrong information which is possibly occurred.
Examples
AT+CEER
+CEER: Invalid/incomplete number
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
118
OK
6.9 AT+CCWA Call waiting
Description
This command allow
s control of the Call Waiting supplementary service. Activation, deactivation
and status query are supported. When querying the status of a network service (<mode>=2) the
response line for 'not active' case (<status>=0) should be returned only if service is not active for
any <class>. Parameter <n>
is used to disable/enable the presentation of an unsolicited result code
+CCWA: <number>,<type>,<class>
to the TE when call waiting service is enabled. Command
should be abortable when network is interrogated.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CCWA=? +CCWA: (list of supported <n>s)
OK
Read Command Responses
AT+CCWA? +CCWA: <n>
OK
Write Command Responses
AT+CCWA=
<n>[,<mode>[,<class>]]
When <mode>=2 and command successful:
+CCWA:<status>,<class>[<CR><LF>
+CCWA: <status>, <class>[...]]
OK
ERROR
+CME ERROR: <err>
Execution Command
Responses
AT+CCWA Set default value (<n>=0):
OK
Defined values
<n>
Sets/shows the result code presentation status in the TA
0 – disable
1 – enable
<mode>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
119
When <mode> parameter is not given, network is not interrogated:
0 – disable
1 – enable
2 – query status
<class>
It is a sum of integers each representing a class of information (default 7)
1 – voice (telephony)
2 – data (refers to all bearer services)
4 – fax (facsimile services)
7 – voice,data and fax(1+2+4)
8 – short message service
16 – data circuit sync
32 – data circuit async
64 – dedicated packet access
128 – dedicated PAD access
255 – The value 255 covers all classes
<status>
0 – not active
1 – active
<number>
String type phone number of calling address in format specified by <type>.
<type>
Type of address octet in integer format;
128 – Restricted number type includes unknown type and format
145 – International number type
129 – Otherwise
Examples
AT+CCWA=?
+CCWA:(0-1)
OK
AT+CCWA?
+CCWA: 0
OK
6.10 AT+CHLD Call related supplementary services
Description
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
120
This command allows the control the following call related services:
1. A call can be temporarily disconnected from the ME but the connection is retained by the
network.
2. Multiparty conversation (conference calls).
3. The served subscriber who has two calls (one held and the other either active or alerting)
can connect the other parties and release the served subscriber's own connection.
Calls can be put on hold, recovered, released, added to conversation, and transferred. This is
based on the GSM/UMTS supplementary services.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CHLD=? +CHLD: (list of supported <n>s)
OK
Write Command Responses
AT+CHLD=<n> OK
ERROR
+CME ERROR: <err>
Execution Command
Responses
AT+CHLD
Default to <n>=2.
OK
ERROR
+CME ERROR: <err>
Defined values
<n>
0
– Terminate all held calls; or set User Determined User Busy for a waiting call
1 – Terminate all active calls and accept the other call (waiting call or held call)
1X – Terminate a specific call X
2 – Place all active calls on hold and accept the
other call (waiting call or held call) as
the active call
2X – Place all active calls except call X on hold
3 – Add the held call to the active calls
4
– Connect two calls and cut off the connection between users and them simultaneously
Examples
AT+CHLD=?
+CHLD: (0,1,1x,2,2x,3,4)
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
121
6.11 AT+CCFC Call forwarding number and conditions
Description
This command allows control of the call forwarding supplementary service. Registration, erasure,
activation, deactivation, and status query are supported.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CCFC=? +CCFC: (list of supported <reason>s)
OK
Write Command Responses
AT+CCFC=<reason>,<mode
>[,<number>[,<type>[,<clas
s>[,<subaddr>[,<satype>[,<ti
me> ]]]]]]
When <mode>=2 and command successful:
+CCFC: <status>,<class1>[,<number>,<type>
[,<subaddr>,<satype>[,<time>]]][<CR><LF>
+CCFC: <status>,<class2>[,<number>,<type>
[,<subaddr>,<satype>[,<time>]]][...]]
OK
ERROR
+CME ERROR:<err>
Defined values
<reason>
0 – unconditional
1 – mobile busy
2 – no reply
3 – not reachable
4 – all call forwarding
5 – all conditional call forwarding
<mode>
0 – disable
1 – enable
2 – query status
3 – registration
4 – erasure
<number>
String type phone number of forwarding address in format specified by <type>.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
122
<type>
Type of address octet in integer format:
145 – dialing string <number> includes international access code character ‘+’
129 – otherwise
<subaddr>
String type sub address of format specified by <satype>.
<satype>
Type of sub address octet in integer format, default 128.
<classX>
It is a sum of integers each representing a class of information (default 7):
1 – voice (telephony)
2 – data (refers to all bearer services)
4 – fax (facsimile services)
16 – data circuit sync
32 – data circuit async
64 – dedicated packet access
128 – dedicated PAD access
255 – The value 255 covers all classes
<time>
1...30 – when "no reply" is enabled or queried, this gives the time in seconds to wait before call
is forwarded, default value 20.
<status>
0 – not active
1 – active
Examples
AT+CCFC=?
+CCFC: (0,1,2,3,4,5)
OK
AT+CCFC=0,2
+CCFC: 0,255
OK
6.12 AT+CLIP Calling line identification presentation
Description
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
123
This command refers to the GSM/
UMTS supplementary service CLIP (Calling Line Identification
Presentation) that enables a called subscriber to get the calling line identity (CLI) of the calling
party when receiving a mobile terminated call.
Write command enables or disables the presentat
ion of the CLI at the TE. It has no effect on the
execution of the supplementary service CLIP in the network.
When the presentation of the CLI at the TE is enabled (and calling subscriber allows), +CLIP:
<number>,<type>,,[,[<alpha>][,<CLI validity>]] respo
nse is returned after every RING (or
+CRING: <type>; refer sub
clause "Cellular result codes +CRC") result code sent from TA to TE. It
is manufacturer specific if this response is used when normal voice call is answered.
SIM PIN References
YES
3GPP TS 27.007
Syntax
Test Command Responses
AT+CLIP=? +CLIP: (list of supported <n>s)
OK
Read Command Responses
AT+CLIP? +CLIP: <n>,<m>
OK
ERROR
+CME ERROR: <err>
Write Command Responses
AT+CLIP=<n> OK
ERROR
+CME ERROR: <err>
Execution Command Responses
AT+CLIP
Set default value(<n>=0):
OK
Defined values
<n>
Parameter sets/shows the result code presentation status in the TA:
0 – disable
1 – enable
<m>
0 – CLIP not provisioned
1 – CLIP provisioned
2 – unknown (e.g. no network, etc.)
<number>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
124
String type phone number of calling address in format specified by <type>.
<type>
Type of address octet in integer format;
128 – Restricted number type includes unknown type and format
145 – International number type
161 – national number.The network support for this type is optional
177 – network specific number,ISDN format
129 – Otherwise
<alpha>
String type alphanumeric representation of <number> corresponding to the entry found in phone
book.
<CLI validity>
0 – CLI valid
1 – CLI has been withheld by the originator
2 –
CLI is not available due to interworking problems or limitations of originating
network
Examples
AT+CLIP=1
OK
RING (with incoming call)
+CLIP: "02152063113",128,,,"gongsi",0
6.13 AT+CLIR Calling line identification restriction
Description
This command refers to CLIR-
service that allows a calling subscriber to enable or disable the
presentation of the CLI to the called party when originating a call.
Write command overrides the CLIR subscription (default is restricted or allowed) when temporary
mode is provisioned as a default adjustment for all following outgoing calls. This adjustment can be
revoked by using the opposite command.. If this command is used by a subscriber without
provision of CLIR in permanent mode the network will act.
Read command gives the default adjustment for all outgoing calls (given in <n>), and also triggers
an interrogation of the provision status of the CLIR service (given in <m>).
Test command returns values supported as a compound value.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
125
AT+CLIR=?
+CLIR: (list of supported <n>s)
OK
Read Command Responses
AT+CLIR? +CLIR: <n>,<m>
OK
ERROR
+CME ERROR: <err>
Write Command Responses
AT+CLIR=<n>
OK
ERROR
+CME ERROR: <err>
Defined values
<n>
0 – presentation indicator is used according to the subscription of the CLIR service
1 – CLIR invocation
2 – CLIR suppression
<m>
0 – CLIR not provisioned
1 – CLIR provisioned in permanent mode
2 – unknown (e.g. no network, etc.)
3 – CLIR temporary mode presentation restricted
4 – CLIR temporary mode presentation allowed
Examples
AT+CLIR=?
+CLIR:(0-2)
OK
6.14 AT+COLP Connected line identification presentation
Description
This command refers to
the GSM/UMTS supplementary service COLP(Connected Line
Identification Presentation) that enables a calling subscriber to get the connected line identity
(COL) of the called party after setting up a mobile originated call. The command enables or
disables t
he presentation of the COL at the TE. It has no effect on the execution of the
supplementary service COLR in the network.
When enabled (and called subscriber allows), +COLP:<number>, <type> [,<subaddr>, <satype>
[,<alpha>]] intermediate result code is returned from TA to TE before any +CR responses. It is
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
126
manufacturer specific if this response is used when normal voice call is established.
When the AT+COLP=1 is set, any data input immediately after the launching of “ATDXXX;” will
stop the execution of the ATD command, which may cancel the establishing of the call.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+COLP=? +COLP: (list of supported <n>s)
OK
Read Command Responses
AT+COLP? +COLP: <n>,<m>
OK
ERROR
+CME ERROR: <err>
Write Command Responses
AT+COLP =<n> OK
ERROR
+CME ERROR: <err>
Execution Command
Responses
AT+COLP Set default value(<n>=0, <m>=0):
OK
Defined values
<n>
Parameter sets/shows the result code presentation status in the TA:
0 – disable
1 – enable
<m>
0 – COLP not provisioned
1 – COLP provisioned
2 – unknown (e.g. no network, etc.)
Examples
AT+COLP?
+COLP: 1,0
OK
ATD10086;
VOICE CALL: BEGIN
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
127
+COLP: "10086",129,,,
OK
6.15 AT+VTS DTMF and tone generation
Description
This command allows the transmission of DTMF tones and arbitrary tones which cause the Mobile
Switching Center
(MSC) to transmit tones to a remote subscriber. The command can only be used
in voice mode of operation (active voice call).
NOTE: The END event of voice call will terminate the transmission of tones, and as an operator
option, the tone may be ceased after a pre-
determined time whether or not tone duration has been
reached.
SIM PIN References
NO 3GPP TS 27.007
Syntax
Test Command Responses
AT+VTS=? +VTS: (list of supported<dtmf>s)
OK
Write Command Responses
AT+VTS=<dtmf>
[,<duration>]
AT+VTS=<dtmf-string>
OK
ERROR
Defined values
<dtmf>
A single ASCII character in the set 0-9, *, #, A, B, C, D.
<duration>
Tone duration in 1/10 seconds, from 0 to 255. This i
s interpreted as a DTMF tone of different
duration from that mandated by the AT+VTD
command, otherwise, the duration which be set the
AT+VTD command will be used for the tone (<duration> is omitted).
<dtmf-string>
A sequence of ASCII character in the set 0-9, *, #, A, B, C, D, and maximal length of the string is
29. The string must be enclosed in double quotes (“”), and separated by commas between the ASCII
characters (e.g. “1,3,5,7,9,*”). Each of the tones with a duration which is set by the AT+VT D
command.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
128
Examples
AT+VTS=1
OK
AT+VTS=1,20
OK
AT+VTS=”1,3,5”
OK
AT+VTS=?
+VTS: (0-9,*,#,A,B,C,D)
OK
6.16 AT+VTD Tone duration
Description
This refers to an integer <n> that defines the length of tones emitted as a result of the AT+VTS
command. A value different than zero causes a tone of duration <n>/10 seconds.
SIM PIN References
YES
3GPP TS 27.007
Syntax
Test Command Responses
AT+VTD=? +VTD: (list of supported <n>s)
OK
Read Command
Responses
AT+VTD? +VTD: <n>
OK
Write Command
Responses
AT+VTD=<n>
OK
Defined values
<n>
Tone duration in integer format, from 0 to 255, and 0 is factory value.
0 Tone duration of every single tone is dependent on the network.
1…255 Tone duration of every single tone in 1/10 seconds.
Examples
AT+VTD=?
+VTD: (0-255)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
129
OK
AT+VTD?
+VTD: 0
OK
AT+VTD=5
OK
6.17 AT+CSTA Select type of address
Description
Write command is used to select the type of number for further dialing commands (AT D) according
to GSM/UMTS specifications.
Read command returns the current type of number.
Test command returns values supported by the Module as a compound value.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CSTA=? +CSTA:(list of supported <type>s)
OK
Read Command
Responses
AT+CSTA? +CSTA:<type>
OK
Write Command Responses
AT+CSTA=<type> OK
ERROR
Execution Command Responses
AT+CSTA OK
Defined values
<type>
Type of address octet in integer format:
145 – when dialling string includes international access code character “+”
161 – national number.The network support for this type is optional
177 – network specific number,ISDN format
129 – otherwise
NOTE:
Because the type of address is automatically detected on the dial string of dialing
command, command AT +CSTA has really no effect.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
130
Examples
AT+CSTA?
+CSTA: 129
OK
AT+CSTA=145
OK
6.18 AT+CMOD Call mode
Description
Write command selects the call mode of further dialing commands (AT D) or for next answering
command (ATA). Mode can be either single or alternating.
Test command returns values supported by the TA as a compound value.
SIM PIN References
NO 3GPP TS 27.007
Syntax
Test Command Responses
AT+CMOD=? +CMOD: (list of supported <mode>s)
OK
Read Command Responses
AT+CMOD? +CMOD: <mode>
OK
Write Command Responses
AT+CMOD=<mode> OK
ERROR
Execution Command Responses
AT+CMOD
Set default value:
OK
Defined values
<mode>
0 – single mode(only supported)
NOTE:
The value of <mode> shall be set
to zero after a successfully completed alternating mode
call. It shall be set to zero also after a failed answering. The power-on, factory and user resets shall
also set the value to zero. This reduces the possibility that alternating mode calls are originated or
answered accidentally.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
131
Examples
AT+CMOD?
+CMOD: 0
OK
AT+CMOD=0
OK
6.19 AT+VMUTE Speaker mute control
Description
This command is used to control the loudspeaker to mute and unmute during a voice call or a video
call which is connected. If there is not a connected call, write command can’t be used.
When all calls are disconnected, the Module sets the subparameter as 0 automatically.
SIM PIN References
NO
Vendor
Syntax
Test Command Responses
AT+VMUTE=? +VMUTE: (list of supported <mode>s)
OK
Read Command Responses
AT+VMUTE? +VMUTE: <mode>
OK
Write Command Responses
AT+VMUTE=<mode> OK
ERROR
Defined values
<mode>
0 – mute off
1 – mute on
Examples
AT+VMUTE=1
OK
AT+VMUTE?
+VMUTE:1
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
132
6.20 AT+CMUT Microphone mute control
Description
This
command is used to enable and disable the uplink voice muting during a voice call or a video
call which is connected. If there is not a connected call, write command can’t be used.
When all calls are disconnected, the Module sets the subparameter as 0 automatically.
SIM PIN References
NO 3GPP TS 27.007
Syntax
Test Command Responses
AT+CMUT=? +CMUT: (list of supported <mode>s)
OK
Read Command
Responses
AT+CMUT? +CMUT: <mode>
OK
Write Command Responses
AT+CMUT=<mode> OK
ERROR
Defined values
<mode>
0 – mute off
1 – mute on
Examples
AT+CMUT=1
OK
AT+CMUT?
+CMUT: 1
OK
6.21 AT+MORING Enable or disable report MO ring URC
Description
This command is used to enable or disable report MO ring URC
SIM PIN References
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
133
NO Vendor
Syntax
Test Command Responses
AT+MORING=? +MORING: (0-1)
OK
Read Command Responses
AT+MORING? +MORING: <mode>
OK
Write Command
Responses
AT+MORING=<mode> OK
ERROR
Defined values
<mode>
Enable or disable report MO ring URC:
0 – disable
1 – enable.
Examples
AT+MORING=1
OK
AT+MORING?
+MORING:1
OK
AT+MORING=?
+MORING: (0-1)
OK
6.22 AT+CSDVC Switch voice channel device
Description
This
command is used to switch voice channel device. After changing current voice channel device
and if there is a connecting voice
call, it will use the settings of previous device (loudspeaker
volume level, mute state of loudspeaker and microphone, refer to AT+CLVL, AT+VMUTE, and
AT+CMUT).
SIM PIN References
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
134
NO
Vendor
Syntax
Test Command Responses
AT+CSDVC=? +CSDVC: (list of supported <dev>s)
OK
Read Command Responses
AT+CSDVC? +CSDVC: <dev>
OK
Write Command Responses
AT+CSDVC=<dev> OK
Defined values
<dev>
1 – handset
3 – speaker phone
Examples
AT+CSDVC=1
OK
AT+CSDVC?
+CSDVC:1
OK
6.23 AT+CLVL Loudspeaker volume level
Description
Write command is used to select the volume of the internal loudspeaker audio output of the device.
Test command returns supported values as compound value.
SIM PIN References
NO
3GPP TS 27.007
Syntax
Test Command Responses
AT+CLVL=? +CLVL: (list of supported <level>s)
OK
Read Command Responses
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
135
AT+CLVL? +CLVL: <level>
OK
Write Command Responses
AT+CLVL=<level> OK
ERROR
Defined values
<level>
Integer type value which represents loudspeaker volume level. The range is from 0 to 5, and 0
represents the lowest loudspeaker volume level, 4 is default factory value.
NOTE: <level> is nonvolatile, and it is stored when restart.
Examples
AT+CLVL?
+CLVL:4
OK
AT+CLVL=3
OK
6.24 AT+SIDET Set sidetone
Description
This
command is used to enable or disable sidetone.
Please refer to related hardware design
document for more information. This command is only used after call start.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+SIDET=?
+SIDET: (list of supported <en>s)
OK
Read Command Responses
AT+SIDET? +SIDET: <en>
OK
Write Command
Responses
AT+SIDET=<en> OK
ERROR
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
136
Defined values
<en>
0: disable sidetone
1: enable sidetone
Examples
AT+SIDET?
+SIDET: 0
OK
AT+SIDET=?
+SIDET: (0-1)
OK
AT+SIDET=1
OK
6.25 AT+CACDBFN Change default ACDB filename
Description
This command is used to change default acdb filename. But there are six adcd files used by system,
we can’t change default acdb filename to them. These filenames including Bluetooth_cal.acdb,
General_cal.acdb, Global_cal.acdb, Hdmi_cal.acdb, Headset_cal.acdb, Speaker_cal.acdb
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CACDBFN=?
+CACDBFN: (acdb file(s) listed in /data <acdb file>s,except s
ix acdb file used by system)
OK
Read Command Responses
AT+CACDBFN?
+
CACDBFN: <acdb file>
OK
Write Command
Responses
AT+CACDBFN=<acdb file> OK
ERROR
Defined values
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
137
<acdb file>
<acdb file> file(s) in the directory /data with suffix: acdb, except six acdb file used by system
Examples
AT+CACDBFN=Handset_cal.acdb
OK
AT+
CACDBFN
?
+CACDBFN: Handset_cal.acdb
OK
AT+CACDBFN=?
+CACDBFN: (Handset_cal.acdb,Handset_tianmai.acdb)
OK
6.26 AT+CPCMREG USB audio control
Description
This command is used to start/stop usb audio function.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CPCMREG=? +CPCMREG: (list of supported < mode >s)
OK
Read Command Responses
AT+CPCMREG? +CPCMREG: <mode>
OK
Write Command Responses
AT+CPCMREG=<mode> OK
ERROR
Defined values
<mode>
0 – stop usb audio function,need used after call stop.
1 – start usb audio function,need used after call start(ATDxxx;)
Examples
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
138
AT+CPCMREG=1
OK
AT+CPCMREG?
+CPCMREG:1
OK
6.27 AT+CMICGAIN Adjust mic gain
Description
This command is used to adjust mic gain. If this command was used during cal
l, it will take
immediate effect. Otherwise, it will take effect in next call.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CMICGAIN=? +CMICGAIN: (list of supported <value>s)
OK
Read Command Responses
AT+CMICGAIN? +CMICGAIN: <value>
OK
Write Command Responses
AT+CMICGAIN=<value> OK
ERROR
Defined values
<value>
Gain value from 0-8, 8 is the max. 3 is the default value. This value will be reset to default value
after Module reset.
Examples
AT+CMICGAIN=1
OK
AT+CMICGAIN?
+CMICGAIN:1
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
139
6.28 AT+COUTGAIN Adjust out gain
Description
This command is used to adjust out(speaker/handset) gain. If this command was used during call, it
will take immediate effect . Otherwise, it will take effect in next call.
SIM PIN References
NO
Vendor
Syntax
Test Command Responses
AT+COUTGAIN=? +COUTGAIN: (list of supported <value>s)
OK
Read Command Responses
AT+COUTGAIN? +COUTGAIN: <value>
OK
Write Command Responses
AT+COUTGAIN=<value> OK
ERROR
Defined values
<mode>
Gain value from 0-8, 8 is the max. 8 is the default value. This value will be reset to default value
after Module reset.
Examples
AT+COUTGAIN=1
OK
AT+COUTGAIN?
+COUTGAIN:1
OK
6.29 AT+CTXVOL Adjust TX voice mic volume
Description
This command is used to adjust mic gain. It modify the TX_VOICE_VOL in DSP. This command
only be used during call and don’t save the parameter after call.
SIM PIN References
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
140
NO Vendor
Syntax
Test Command Responses
AT+CTXVOL=? +CTXVOL: (list of supported <value>s)
OK
Read Command Responses
AT+CTXVOL? +CTXVOL: <value>
OK
Write Command
Responses
AT+CTXVOL=<value> OK
ERROR
Defined values
<value>
Gain value from 0x0000-0xffff, default value is not a fixed value. It varies with different versions.
Examples
AT+CTXVOL=0x1234
OK
AT+CTXVOL?
+CTXVOL: 0x2d33
OK
6.30 AT+CTXMICGAIN Adjust TX voice mic gain
Description
This command is used to adjust mic gain. It modify the TX_VOICE_MIC_GAIN in DSP. This
command only be used during call and don’t save the parameter after call.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CTXMICGAIN=? +CTXMICGAIN: (list of supported <mode>,<value>s)
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
141
Read Command
Responses
AT+CTXMICGAIN? +CTXMICGAIN: <mode>,<value>
OK
Write Command
Responses
AT+CTXMICGAIN=<mode
>,<value>
OK
ERROR
Defined values
<mode>
mode value from 0-1, default value is not a fixed value. It varies with different versions.
<value>
gain value from 0x0000-0xffff, default value is not a fixed value. It varies with different versions.
Examples
AT+CTXMICGAIN=1,0x1234
OK
AT+CTXMICGAIN?
+CTXMICGAIN: 1,0x2000
OK
6.31 AT+CRXVOL Adjust RX voice output speaker volume
Description
This command is used to adjust digital Volume of output signal after speech decoder, before
summation of sidetone and DAC. It modify the RX_VOICE_SPK_GAIN in DSP. This command
only be used during call and don’t save the parameter after call.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CRXVOL=? +CRXVOL: (list of supported <value>s)
OK
Read Command Responses
AT+CRXVOL? +CRXVOL: <value>
OK
Write Command Responses
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
142
AT+CRXVOL=<value>
OK
ERROR
Defined values
<value>
Gain value from 0x0000-0xffff, default value is not a fixed value. It varies with different versions.
Examples
AT+CRXVOL=0x1234
OK
AT+CRXVOL?
+CRXVOL: 0x3fd9
OK
6.32 AT+CECH Inhibit far-end echo
Description
This command is used to adjust additional muting gain applied in DES during far-end only. It
modify the DENS_gamma_e_high of TX_VOICE_SMECNS in DSP.
The bigger the value, the
stronger the inhibition .This command only be used during call and don’t save the parameter after
call.
SIM PIN References
NO Vendor
Syntax
Test Command
Responses
AT+CECH=? +CECH: (list of supported <value>s)
OK
Read Command
Responses
AT+CECH? +CECH: <value>
OK
Write Command Responses
AT+CECH=<value> OK
ERROR
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
143
Defined values
<value>
Gain value from 0x0000-0x7fff, default value is not a fixed value. It varies with different versions.
Examples
AT+CECH=0x1234
OK
AT+CECH?
+CECH: 0x0200
OK
6.33 AT+CECDT Inhibit echo during doubletalk
Description
This command is used to adjust additional muting gain applied in DES during doubletalk. It modify
the DENS_gamma_e_dt of TX_VOICE_SMECNS in DSP. The bigger the value, the stronger the
inhibition .This command only be used during call and don’t save the parameter after call.
SIM PIN References
NO
Vendor
Syntax
Test Command Responses
AT+CECDT=? +CECDT: (list of supported <value>s)
OK
Read Command Responses
AT+CECDT? +CECDT: <value>
OK
Write Command
Responses
AT+CECDT=<value> OK
ERROR
Defined values
<value>
Gain value from 0x0000-0x7fff, default value is not a fixed value. It varies with different versions.
Examples
AT+CECDT=0x1234
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
144
OK
AT+CECDT?
+CECDT: 0x0100
OK
6.34 AT+CECWB Inhibit echo in the high band
Description
This command is used to adjust
the aggressiveness of EC in the high band (4 ~ 8 kHz). A higher
value is more aggressive and suppresses more high-band echo. Q-format - Q4.11WB_gamma_E =
2048 * gammaWhere gamma is in the range [0,15]. It modify the WB_gamma_e of
TX_VOICE_SMECNS in DSP. The bigger the value, the stronger the inhibition .This command
only be used during call and don’t save the parameter after call.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CECWB=?
+CECWB: (list of supported <value>s)
OK
Read Command Responses
AT+CECWB? +CECWB: <value>
OK
Write Command
Responses
AT+CECWB=<value> OK
ERROR
Defined values
<value>
Gain value from 0x0000-0x7fff, default value is not a fixed value. It varies with different versions.
Examples
AT+CECWB=0x1234
OK
AT+CECWB?
+CECWB: 0x0300
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
145
6.35 AT+CNSN MIC NOISE suppression
Description
This command is used to adjust oversubtraction factor and bias compensation for noise estimation.
It modify the DENS_gamma_n of TX_VOICE_SMECNS in DSP.
The bigger the value, the
stronger the noise suppression .This command only be used during call and don’
t save the
parameter after call.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CNSN=? +CNSN: (list of supported <value>s)
OK
Read Command Responses
AT+CNSN? +CNSN: <value>
OK
Write Command Responses
AT+CNSN=<value> OK
ERROR
Defined values
<value>
Gain value from 0x0000-0x7fff, default value is not a fixed value. It varies with different versions.
Examples
AT+CNSN=0x1234
OK
AT+CNSN?
+CNSN: 0x0258
OK
6.36 AT+CNSLIM MIC NOISE suppression
Description
This command is used to controls the maximum amount of noise suppression. I
t modify the
DENS_limit_NS of TX_VOICE_SMECNS in DSP. The bigger the value, the stronger the noise
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
146
suppression .This command only be used during call and don’t save the parameter after call.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CNSLIM=?
+CNSLIM: (list of supported <value>s)
OK
Read Command Responses
AT+CNSLIM? +CNSLIM: <value>
OK
Write Command Responses
AT+CNSLIM=<value> OK
ERROR
Defined values
<value>
Gain value from 0x0000-0x7fff, default value is not a fixed value. It varies with different versions.
Examples
AT+CNSLIM=0x1234
OK
AT+CNSLIM?
+CNSLIM: 0x16c4
OK
6.37 AT+CFNSMOD Adjust parameter fnsMode of RX_VOICE_FNS
Description
This command is used to modify the fnsMode of RX_VOICE_FNS in DSP. This command only be
used during call and don’t save the parameter after call.
SIM PIN References
NO
Vendor
Syntax
Test Command Responses
AT+CFNSMOD=? +CFNSMOD: (list of supported <value>s)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
147
OK
Read Command Responses
AT+CFNSMOD? +CFNSMOD: <value>
OK
Write Command Responses
AT+CFNSMOD=<value>
OK
ERROR
Defined values
<value>
Gain value is bellow, default value is not a fixed value. It varies with different versions.
0x00FF – Maximum NS
0x0073 – Basic stationary NS
0x00F3 – Enhanced stationary NS
0x01FF – Aggressive NS
Examples
AT+CFNSMOD=0x0073
OK
AT+CFNSMOD?
+CFNSMOD: 0x0073
OK
6.38 AT+CFNSIN Adjust parameter fnsInputGain of RX_VOICE_FNS
Description
This command is used to modify the fnsInputGain of RX_VOICE_FNS in DSP. This command
only be used during call and don’t save the parameter after call.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CFNSIN=?
+CFNSIN: (list of supported <value>s)
OK
Read Command Responses
AT+CFNSIN? +CFNSIN: <value>
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
148
Write Command
Responses
AT+CFNSIN=<value> OK
ERROR
Defined values
<value>
Gain value from 0x2000-0x7fff, default value is not a fixed value. It varies with different versions.
Examples
AT+CFNSIN=0x2234
OK
AT+CFNSIN?
+CFNSIN: 0x2000
OK
6.39 AT+CFNSLVL Adjust parameter fnsTargetNS of RX_VOICE_FNS
Description
This command is used to modify the fnsTargetNS of RX_VOICE_FNS in DSP. This command only
be used during call and don’t save the parameter after call.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CFNSLVL=? +CFNSLVL: (list of supported <value>s)
OK
Read Command Responses
AT+CFNSLVL? +CFNSLVL: <value>
OK
Write Command Responses
AT+CFNSLVL=<value> OK
ERROR
Defined values
<value>
Gain value from 0x0000-0x7fff, default value is not a fixed value. It varies with different versions.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
149
Examples
AT+CFNSLVL=0x2234
OK
AT+CFNSLVL?
+CFNSLVL: 0x1000
OK
6.40 AT+CECRX Enable or disable VOICE_MOD_ENABLE
Description
This command is used to enable or disable VOICE_MOD_ENABLE. I
t modify the
VOICE_MOD_ENABLE in DSP. This command only be used during call and don’
t save the
parameter after call.
SIM PIN References
NO
Vendor
Syntax
Test Command Responses
AT+CECRX=? +CECRX: (list of supported <value>s)
OK
Read Command Responses
AT+CECRX? +CECRX: <value>
OK
Write Command Responses
AT+CECRX=<value> OK
ERROR
Defined values
<value>
This default value is not a fixed value. It varies with different versions.
1: Enable
0: Disable
Examples
AT+CECRX=1
OK
AT+CECRX?
+CECRX: 1
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
150
OK
6.41 AT+CNLPPG Modify the NLPP_gain in DSP
Description
This command is used to modify the NLPP_gain of VOICE_ECRX_PARAM in DSP. This
command only be used during call and don’t save the parameter after call.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CNLPPG=? +CNLPPG: (list of supported <value>s)
OK
Read Command Responses
AT+CNLPPG? +CNLPPG: <value>
OK
Write Command Responses
AT+CNLPPG =<value>
OK
ERROR
Defined values
<value>
Gain value from 0x0000-0x7fff, default value is not a fixed value. It varies with different versions.
Examples
AT+CNLPPG=0x1234
OK
AT+CNLPPG?
+CNLPPG: 0x1000
OK
6.42 AT+CNLPPL Modify the NLPP_limit in DSP
Description
This command is used to modify the NLPP_limit of VOICE_ECRX_PARAM in DSP. This
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
151
command only be used during call and don’t save the parameter after call.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CNLPPL=? +CNLPPL: (list of supported <value>s)
OK
Read Command Responses
AT+CNLPPL? +CNLPPL: <value>
OK
Write Command
Responses
AT+CNLPPL =<value> OK
ERROR
Defined values
<value>
Value from 0x0000-0x7fff, default value is not a fixed value. It varies with different versions.
Examples
AT+CNLPPL=0x1234
OK
AT+CNLPPL?
+CNLPPL: 0x7fff
OK
6.43 AT+CECM Adjust echo canceller
Description
This AT command is used to select the echo cancellation mode.
Write command only be used
during call.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CECM=? +CECM: (list of supported <value>s)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
152
OK
Read Command Responses
AT+CECM? +CECM: <value>
OK
Write Command Responses
AT+CECM=<value>
OK
ERROR
Defined values
<value>
This default value is not a fixed value. It varies with different versions.
0: disable EC mode
1: EC mode recommended for Handset
2: EC mode recommended for Headset
3: EC mode recommended for HANDSFREE
4: EC mode recommended for Bluetooth (least aggressive)
5: EC mode recommended for Bluetooth (less aggressive)
6: EC mode recommended for Bluetooth
7: EC mode recommended for Speaker least aggressive
8: EC mode recommended for Speaker phone medium
9: EC mode recommended for Speaker phone aggressive
Examples
AT+CECM=1
OK
AT+CECM?
+CECM: 1
OK
6.44 AT+CPCMFRM Set usb audio sample rate to 16k bit
Description
This command is used to set usb audio sample rate to 16K bit.
NOTE: This command only support for usb audio 8k to 16k switching, but not support for 16k to
8k switching.
IM PIN References
NO
Vendor
Syntax
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
153
Test Command
Responses
AT+CPCMFRM=? +CPCMFRM: (list of supported <value>s)
OK
Read Command
Responses
AT+CPCMFRM? +CPCMFRM: <value>
OK
Write Command Responses
AT+CPCMFRM=<value> OK
ERROR
Defined values
<value>
Gain value from 0-1, default value is 0.
0 : usb audio use 8k bit
1 : usb audio use 16k bit
Examples
AT+CPCMFRM=1
OK
AT+CPCMFRM?
+CPCMFRM: 1
OK
6.45 AT+CPTONE Play tone
Description
This AT command is used to local play a tone.
SIM PIN References
NO Vendor
Syntax
Read Command Responses
AT+CPTONE=? +CPTONE: (list of supported <tone>s)
OK
Write Command Responses
AT+CPTONE=<tone> OK
AT+CPTONE=<tone>,<time>,<gain
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
154
>
Defined values
<tone>
Support 0-16.
< time>
Duration , the default value is 50ms. Support 1-1000.
<gain>
The default value is 4000. Support 1-9999.
Examples
AT+CPTONE=1
OK
AT+CPTONE=1,200,1000
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
155
7 AT Commands for SMS
7.1 AT+CSMS Select message service
Description
This command is used to select messaging service <service>.
Note: This command not support in CDMA/EVDO mode
SIM PIN References
YES 3GPP TS 27.005
Syntax
Test Command Responses
AT+CSMS=? +CSMS: (list of supported <service>s)
OK
Read Command Responses
AT+CSMS? +CSMS: <service>,<mt>,<mo>,<bm>
OK
Write Command Responses
AT+CSMS=<service> +CSMS: <mt>,<mo>,<bm>
OK
ERROR
+CMS ERROR: <err>
Defined values
<service>
0 – SMS at command is compatible with GSM phase 2.
1 – SMS at command is compatible with GSM phase 2+.
<mt>
Mobile terminated messages:
0 – type not supported.
1 – type supported.
<mo>
Mobile originated messages:
0 – type not supported.
1 – type supported.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
156
<bm>
Broadcast type messages:
0 – type not supported.
1 – type supported.
Examples
AT+CSMS=0
+CSMS:1,1,1
OK
AT+CSMS?
+CSMS:0,1,1,1
OK
AT+CSMS=?
+CSMS:(0-1)
OK
7.2 AT+CPMS Preferred message storage
Description
This command is used to select memory storages <mem1>, <mem2> and <mem3> to be used for
reading, writing, etc.
SIM PIN References
YES 3GPP TS 27.005
Syntax
Test Command Responses
AT+CPMS=?
+CPMS: (list of supported <mem1>s), (list of supported
<mem2>s), (list of supported <mem3>s)
OK
Read Command
Responses
AT+CPMS? +CPMS:<mem1>,<used1>,<total1>,<mem2>,<used2>,<total2>,
<mem3>,<used3>,<total3>
OK
ERROR
+CMS ERROR: <err>
Write Command
Responses
AT+CPMS=<mem1>
[,<mem2>[,<mem3>]]
+CPMS: <used1>,<total1>,<used2>,<total2>,<used3>,<total3>
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
157
ERROR
+CMS ERROR: <err>
Execution Command Responses
AT+CPMS Set default value (<mem1>=”SM”, <mem2>=”SM”
,
<mem3>=”SM”):
+CPMS: <used1>,<total1>,<used2>,<total2>,<used3>,<total3>
OK
ERROR
Defined values
<mem1>
String type, memory from which messages are read and deleted (commands List Messages
AT+CMGL, Read Message AT +CMGR and Delete Message AT +CMGD).
“ME” and “MT” FLASH message storage
“SM” SIM message storage
“SR” Status report storage
（
not used in CDMA/EVDO mode
）
<mem2>
String type, memory to which writing and sending operations are made (commands Send Message
from Storage AT +CMSS and Write Message to Memory AT +CMGW).
“ME” and “MT” FLASH message storage
“SM” SIM message storage
“SR” Status report storage
（
not used in CDMA/EVDO mode
）
<mem3>
String type, memory to which received SMS is preferred to be stored (unless forwarded directly to
TE; refer command New Message Indications AT +CNMI).
“ME” FLASH message storage
“SM” SIM message storage
<usedX>
Integer type, number of messages currently in <memX>.
<totalX>
Integer type, total number of message locations in <memX>.
Examples
AT+CPMS=?
+CPMS: ("ME","MT","SM","SR"),("ME","MT","SM","SR"),("ME","SM")
OK
AT+CPMS?
+CPMS:"ME", 0, 23,"ME", 0, 23,"ME", 0, 23
OK
AT+CPMS="SM","SM","SM"
+CPMS:3,50,3,50,3,50
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
158
OK
7.3 AT+CMGF Select SMS message format
Description
This command is used to specify the input and output format of the short messages.
SIM PIN References
YES 3GPP TS 27.005
Syntax
Test Command Responses
AT+CMGF=? +CMGF: (list of supported <mode>s)
OK
ERROR
Read Command
Responses
AT+CMGF? +CMGF: <mode>
OK
ERROR
Write Command Responses
AT+CMGF=<mode> OK
ERROR
Execution Command
Responses
AT+CMGF Set default value (<mode>=0):
OK
ERROR
Defined values
<mode>
0 – PDU mode
1 – Text mode
Examples
AT+CMGF?
+CMGF: 0
OK
AT+CMGF=?
+CMGF: (0-1)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
159
OK
AT+CMGF=1
OK
7.4 AT+CSCA SMS service centre address
Description
This command is used to up
date the SMSC address, through which mobile originated SMS are
transmitted.
Note: This command not support in CDMA/EVDO mode
SIM PIN References
YES 3GPP TS 27.005
Syntax
Test Command
Responses
AT+CSCA=? OK
Read Command Responses
AT+CSCA? +CSCA: <sca>,<tosca>
OK
Write Command
Responses
AT+CSCA=<sca>[,<tosca>] OK
Defined values
<sca>
Service Center Address, value field in string format, BCD numbers (or GSM 7 bit default alphabet
characters) are converted to characters of the currently selected TE character set (refer to command
AT+CSCS), type of address given by <tosca>.
<tosca>
SC address Type-of-Address octet in integer format, when first character of <sca> is + (IRA 43)
default is 145, otherwise default is 129.
Examples
AT+CSCA="+8613012345678"
OK
AT+CSCA?
+CSCA: "+8613010314500", 145
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
160
7.5 AT+CSCB Select cell broadcast message indication
Description
The test command returns the supported <mode>s as a compound value.
The read command displays the accepted message types.
Depending on the <mode>
parameter, the write command adds or deletes the message types
accepted.
Note: This command not support in CDMA/EVDO mode
SIM PIN References
YES 3GPP TS 27.005
Syntax
Test Command Responses
AT+CSCB=? +CSCB: (list of supported <mode>s)
OK
ERROR
Read Command
Responses
AT+CSCB? +CSCB: <mode>,<mids>,<dcss>
OK
ERROR
Write Command Responses
AT+CSCB=<mode>[,<mids
>[,<dcss>]]
OK
ERROR
+CMS ERROR: <err>
Defined values
<mode>
0 – message types specified in <mids> and <dcss> are accepted.
1 – message types specified in <mids> and <dcss> are not accepted.
<mids>
String type; all different possible combinations of CBM message identifiers.
<dcss>
String type; all different possible combinations of CBM data coding scheme
s(default is empty
string)
Examples
AT+CSCB=?
+CSCB: (0-1)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
161
OK
AT+CSCB=0,”15-17,50,86”,””
OK
7.6 AT+CSMP Set text mode parameters
Description
This
command is used to select values for additional parameters needed when SM is sent to the
network or placed in storage when text format message mode is selected.
Note: This command not support in CDMA/EVDO mode
SIM PIN References
YES 3GPP TS 27.005
Syntax
Test Command
Responses
AT+CSMP=? OK
Read Command Responses
AT+CSMP? +CSMP: <fo>,<vp>,<pid>,<dcs>
OK
Write Command
Responses
AT+CSMP=[<fo>[,<vp>[,<p
id>[,<dcs>]]]]
OK
Defined values
<fo>
Depending on the Command or result code: first octet of GSM 03.40 SMS-DELIVER,
SMS-SUBMIT (default 17), SMS-STATUS-REPORT, or SMS-COMMAND (default 2) in integer
format. SMS status report is supported under text mode if <fo> is set to 49.
<vp>
Depending on SMS-SUBMIT <fo> setting: GSM 03.40,TP-Validity-Period either in integer format
(default 167), in time-string format, or if is supported, in enhanced format (hexadecima
l coded
string with quotes), (<vp> is in range 0... 255).
<pid>
GSM 03.40 TP-Protocol-Identifier in integer format (default 0).
<dcs>
GSM 03.38
SMS Data Coding Scheme (default 0), or Cell Broadcast Data Coding Scheme in
integer format depending on the command or result code.
Examples
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
162
AT+CSMP=17,23,64,244
OK
7.7 AT+CSDH Show text mode parameters
Description
This command is used to
control whether detailed header information is shown in text mode result
codes.
Note: This command not support in CDMA/EVDO mode
SIM PIN References
YES 3GPP TS 27.005
Syntax
Test Command Responses
AT+CSDH=? +CSDH: (list of supported <show>s)
OK
ERROR
Read Command Responses
AT+CSDH? +CSDH: <show>
OK
Write Command Responses
AT+CSDH=<show> OK
ERROR
Execution Command Responses
AT+CSDH Set default value (<show>=0):
OK
ERROR
Defined values
<show>
0 – do not show header values defined in commands AT+CSCA and AT +CSMP (<sca>,
<tosca>, <fo>, <vp>, <pid> and <dcs>) nor <length>, <toda> or <tooa> in +CMT,
AT+CMGL, AT +CMGR result codes for SMS-DELIVERs and SMS-SUBMITs in text
mode; for SMS-COMMANDs in AT+CMGR result code, do not show <pid>, <mn>,
<da>, <toda>, <length> or <data>
1 – show the values in result codes
Examples
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
163
AT+CSDH?
+CSDH: 0
OK
AT+CSDH=1
OK
7.8 AT+CNMA New message acknowledgement to ME/TA
Description
This command is used to confirm successful receipt of a new message (SMS-
DELIVER or
SMS-STATUSREPORT) routed directly to the TE. If ME does not receive acknowledgement within
required time (network timeout), it will send RP-ERROR to the network.
NOTE: The execute / write command shall only be used when AT+CSMS parameter <service>
equals 1 (= phase 2+) and appropriate URC has been issued by the module, i.e.:
<+CMT> for <mt>=2 incoming message classes 0, 1, 3 and none;
<+CMT> for <mt>=3 incoming message classes 0 and 3;
<+CDS> for <ds>=1.
Note: This command not support in CDMA/EVDO mode
SIM PIN References
YES 3GPP TS 27.005
Syntax
Test Command Responses
AT+CNMA=? if text mode(AT+CMGF=1):
OK
if PDU mode (AT+CMGF=0):
+CNMA: (list of supported <n>s)
OK
Write Command Responses
AT+CNMA=<n> OK
ERROR
+CMS ERROR: <err>
Execution Command Responses
AT+CNMA OK
ERROR
+CMS ERROR: <err>
Defined values
<n>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
164
Parameter required only for PDU mode.
0 – Command operates similarly as execution command in text mode.
1 – Send positive (RP-ACK) acknowledgement to the network. Accepted only in PDU
mode.
2 – Send negative (RP-ERROR) acknowledgement to the network. Accepted only in PDU
mode.
Examples
AT+CNMI=1,2,0,0,0
OK
+CMT:”1380022xxxx”,””,”02/04/03,11 :06 :38+32”<CR><LF>
Testing
(receive new short message)
AT+CNMA(send ACK to the network)
OK
AT+CNMA
+CMS ERROR
：
340
(the second time return error, it needs ACK only once)
7.9 AT+CNMI New message indications to TE
Description
This command is used to
select the procedure how receiving of new messages from the network is
indicated to the TE when TE is active, e.g. DTR signal is ON. If TE is inactive (e.g. DTR signal is
OFF). If set <mt>＝3 or <ds>＝1, make sure <mode>＝1, If set <mt>=2,make sure <mode>=1 or
2, otherwise it will return error.
SIM PIN References
YES 3GPP TS 27.005
Syntax
Test Command Responses
AT+CNMI=? +CNMI: (list of supported <mode>s),(list of supported <mt>
s),(list
of supported <bm>s),(list of supported <ds>
s),(list of supported
<bfr>s)
OK
Read Command Responses
AT+CNMI? +CNMI: <mode>,<mt>,<bm>,<ds>,<bfr>
OK
Write Command Responses
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
165
AT+CNMI=<mode>[,<mt>[,
<bm>[,<ds> [,<bfr>]]]]
OK
ERROR
+CMS ERROR: <err>
Execution Command Responses
AT+CNMI Set default value:
OK
Defined values
<mode>
0 –
Buffer unsolicited result codes in the TA. If TA result code buffer is full, indications
can
be buffered in some other place or the oldest indications may be discarded and
replaced with the new received indications.
1 –
Discard indication and reject new received message unsolicited result codes when
TA-TE link is reserved (e.g. in on-line data mode). Otherwise forward them directly
to the TE.
2 – Buffer unsolicited result codes in the TA when TA-TE link is reserved (e.g. in on-line
data mode) and flush them to the TE after reservation. Otherwise forward them
directly to the TE.
<mt>
The r
ules for storing received SMS depend on its data coding scheme, preferred memory storage
(AT+CPMS) setting and this value:
0 – No SMS-DELIVER indications are routed to the TE.
1 – If SMS-DELIVER is stored into ME/TA, indication of the memory location is routed
to the TE using unsolicited result code: +CMTI: <mem3>,<index>.
2 – SMS-
DELIVERs (except class 2 messages and messages in the message waiting
indication group (store message)) are routed directly to the TE using unsolicited
result code:
+CMT:[<alpha>],<length><CR><LF><pdu> (PDU mode enabled); or
+CMT:<oa>,[<alpha>],<scts>[,<tooa>,<fo>,<pid>,<dcs>,<sca>,<tosca>,<length>]
<CR> <LF><data>
(text mode enabled, about parameters in italics, refer command Show Text Mode
Parameters AT +CSDH).
3 – Class 3 SMS-
DELIVERs are routed directly to TE using unsolicited result codes
defined in <mt>
=2. Messages of other data coding schemes result in indication as
defined in <mt>=1.
<bm> （not used in CDMA/EVDO mode）
T
he rules for storing received CBMs depend on its data coding scheme, the setting of Select CBM
Types (AT+CSCB) and this value:
0 – No CBM indications are routed to the TE.
2 – New CBMs are routed directly to the TE using unsolicited result code:
+CBM: <length><CR><LF><pdu> (PDU mode enabled); or
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
166
+CBM: <sn>,<mid>,<dcs>,<page>,<pages><CR><LF><data> (text mode enabled)
<ds> （not used in CDMA/EVDO mode）
0 – No SMS-STATUS-REPORTs are routed to the TE.
1 – SMS-STATUS-REPORTs are routed to the TE using unsolicited result code:
+CDS: <length><CR><LF><pdu> (PDU mode enabled); or
+CDS: <fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<st> (text mode enabled)
2 – If SMS-STATUS-REPORT is stored into ME/TA, indication of the memory location is
routed to the TE using unsolicited result code: +CDSI: <mem3>,<index>.
<bfr>
0 –
TA buffer of unsolicited result codes defined within this command is flushed to the TE
when <mode> 1 to 3 is entered (OK response shall be given before flushing the codes).
1 –
TA buffer of unsolicited result codes defined within this command is cleared when
<mode> 1 to 3 is entered.
Examples
AT+CNMI?
+CNMI: 0,0,0,0,0
OK
AT+CNMI=?
+CNMI: (0,1,2),(0,1,2,3),(0,2),(0,1,2),(0,1)
OK
AT+CNMI=2,1 (unsolicited result codes after received messages.)
OK
7.10 AT+CGSMS Select service for MO SMS messages
Description
The write
command is used to specify the service or service preference that the MT will use to send
MO SMS messages.
The test command is used for requesting information on which services and service preferences can
be set by using the AT+CGSMS write command
The read command returns the currently selected service or service preference.
Note: This command not support in CDMA/EVDO mode
SIM PIN References
YES
3GPP TS 27.007
Syntax
Test Command Responses
AT+CGSMS=? +CGSMS: (list of supported <service>s)
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
167
Read Command
Responses
AT+CGSMS? +CGSMS: <service>
OK
Write Command
Responses
AT+CGSMS=<service> OK
ERROR
+CME ERROR: <err>
Defined values
<service>
A numeric parameter which indicates the service or service preference to be used
0 – GPRS(value is not really supported and is internally mapped to 2)
1 – circuit switched(value is not really supported and is internally mapped to 3)
2 – GPRS preferred (use circuit switched if GPRS not available)
3 – circuit switched preferred (use GPRS if circuit switched not available)
Examples
AT+CGSMS?
+CGSMS: 3
OK
AT+CGSMS=?
+CGSMS: (0-3)
OK
7.11 AT+CMGL List SMS messages from preferred store
Description
This command is used to return messages with status value <stat> from message storage <mem1>
to the TE.
If the status of the message is 'received unread', the status in the storage changes to 'received read'.
SIM PIN References
YES
3GPP TS 27.005
Syntax
Test Command Responses
AT+CMGL=? +CMGL: (list of supported <stat>s)
OK
Write Command Responses
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
168
AT+CMGL=<stat>
If text mode (AT+CMGF=1), command successful and SMS-S
UBMITs and/or SMS-DELIVERs:
+CMGL:<index>,<stat>,<oa>/<da>,[<alpha>],[<scts>][,<tooa>/<t
oda>,<fo>,<pid>,<dcs>,<sca>,<tosca>,<length>]<CR><LF><data
>[<CR><LF>
+CMGL:<index>,<stat>,<oa>/<da>,[<alpha>],[<scts>][,<tooa>/<t
oda>,<fo>,<pid>,<dcs>,<sca>,<tosca>,<length>]<CR><LF><data
>[...]]
OK
If text mode (AT+CMGF=1), command successful and SMS-
STATUS-REPORTs:
+CMGL:<index>,<stat>,<fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<s
t>[<CR><LF>
+CMGL:<index>,<stat>,<fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<s
t>[...]]
OK
If text mode (AT+CMGF=1), command successful and SMS-
COMMANDs:
+CMGL: <index>,<stat>,<fo>,<ct>[<CR><LF>
+CMGL: <index>,<stat>,<fo>,<ct>[...]]
OK
If text mode (AT+CMGF=1
), command successful and CBM
storage:
+CMGL:<index>,<stat>,<sn>,<mid>,<page>,<pages>
<CR><LF><data>[<CR><LF>
+CMGL:<index>,<stat>,<sn>,<mid>,<page>,<pages>
<CR><LF><data>[...]]
OK
If PDU mode (AT+CMGF=0) and Command successful:
+CMGL:<index>,<stat>,[<alpha>],<length><CR><LF><pdu>[<C
R><LF>
+CMGL:<index>,<stat>,[<alpha>],<length><CR><LF><pdu>
[…]]
OK
+CMS ERROR: <err>
Defined values
<stat>
1. Text Mode:
"REC UNREAD" received unread message (i.e. new message)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
169
"REC READ" received read message
"STO UNSENT" stored unsent message
"STO SENT" stored sent message
"ALL" all messages
2. PDU Mode:
0 – received unread message (i.e. new message)
1 – received read message
2 – stored unsent message
3 – stored sent message
4 – all messages
<index>
Integer type; value in the range of location numbers supported by the associated memory and start
with zero.
<oa>
Originating-Address, Address-
Value field in string format; BCD numbers (or GSM 7 bit default
alphabet characters) are converted to characters of the currently selected TE character set, type of
address given by <tooa>.
<da>
Destination-Address, Address-
Value field in string format; BCD numbers (or GSM 7 bit default
alphabet characters) are converted to characters of the currently selected TE character set, type of
address given by <toda>.
<alpha>
String type alphanumeric representation of <da> or <oa> corresponding to the entry found in MT
phonebook; implementation of this feature is manufacturer specific; used character set should be
the one selected with command Select TE Character Set AT +CSCS.
<scts>
TP-Service-Centre-Time-Stamp in time-string format (refer <dt>).
<tooa>
TP-Originating-Address, Type-of-Address octet in integer format. (default refer <toda>).
<toda>
TP-Destination-Address, Type-of-Address octet in integer format. (when first character of <da> is +
(IRA 43) default is 145, otherwise default is 129). The range of value is from 128 to 255.
<length>
Integer type value indicating in the text mode (AT+CMGF
=1) the length of the message body
<data> in characters; or in PDU mode (AT+CMGF=0), the leng
th of the actual TP data unit in
octets. (i.e. the RP layer SMSC address octets are not counted in the length)
<data>
In the case of SMS: TP-User-Data in text mode responses; format:
1. If <dcs> indicates that GSM 7 bit default alphabet is used and <fo>
indicates that
TP-User-Data-Header-Indication is not set:
a. I
f TE character set other than "HEX": ME/TA converts GSM alphabet into current TE
character set.
b. If TE character set is "HEX": ME/TA converts each 7-
bit character of GSM 7 bit
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
170
default alphabet into two IRA character long hexadecimal numbers. (e.g. character Π
(GSM 7 bit default alphabet 23) is presented as 17 (IRA 49 and 55))
2. If <dcs> indicates that 8-bit or UCS2 data coding scheme is used, or <fo> indicates that
TP-User-Data-Header-Indication is set: ME/TA converts each 8-
bit octet into two IRA
character long hexadecimal numbers. (e.g. octet with integer value 42 is presented to TE as
two characters 2A (IRA 50 and 65))
3. If <dcs> indicates that GSM 7 bit default alphabet is used:
a. If TE character set other than "HEX":
ME/TA converts GSM alphabet into current TE
character set.
b. If TE character set is "HEX": ME/TA converts each 7-bit character of the GSM 7 bit
default alphabet into two IRA character long hexadecimal numbers.
4. If <dcs> indicates that 8-
bit or UCS2 data coding scheme is used: ME/TA converts each
8-bit octet into two IRA character long hexadecimal numbers.
<fo>
Depending on the command or result code: first octet of GSM 03.40 SMS-DELIVER,
SMS-SUBMIT (default 17), SMS-STAT U S-REPORT, or SMS-COMMAND (default 2) in integer
format. SMS status report is supported under text mode if <fo> is set to 49.
<mr>
Message Reference
GSM 03.40 TP-Message-Reference in integer format.
<ra>
Recipient Address
GSM 03.40 TP-Recipient-Address Address-
Value field in string format;BCD numbers (or GSM
default alphabet characters) are converted to characters of the currently selected TE character
set(refer to command AT+CSCS);type of address given by <tora>
<tora>
Type of Recipient Address
GSM 04.11 TP-Recipient-Address Type-of-Address octet in integer format (default refer <toda>)
<dt>
Discharge Time
GSM 03.40 TP-Discharge-Time in time-string format:”yy/MM/dd,hh:mm:ss+zz”,where characters
indicate year (two last digits),month,day,hour,minutes,seconds and time zone.
<st>
Status
GSM 03.40 TP-Status in integer format
0…255
<ct>
Command Type
GSM 03.40 TP-Command-Type in integer format
0…255
<sn>
Serial Number
GSM 03.41 CBM Serial Number in integer format
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
171
<mid>
Message Identifier
GSM 03.41 CBM Message Identifier in integer format
<page>
Page Parameter
GSM 03.41 CBM Page Parameter bits 4-7 in integer format
<pages>
Page Parameter
GSM 03.41 CBM Page Parameter bits 0-3 in integer format
<pdu>
In the case of SMS: SC address followed by TPDU
in hexadecimal format: ME/TA converts each
octet of TP data unit into two IRA character long hexadecimal numbers. (e.g. octet with integer
value 42 is presented to TE as two characters 2A (IRA 50 and 65)).
Examples
AT+CMGL=?
+CMGL: ("REC UNREAD","REC READ","STO UNSENT","STO SENT","ALL")
OK
AT+CMGL="ALL"
+CMGL: 1,"STO UNSENT","+10011",,,145,4
Hello World
OK
7.12 AT+CMGR Read message
Description
This command is used to
return message with location value <index> from message storage
<mem1> to the TE.
SIM PIN References
YES 3GPP TS 27.005
Syntax
Test Command Responses
AT+CMGR=? OK
Write Command
Responses
AT+CMGR=<index> If text mode (AT+CMGF=1), command successful and SMS-
DELIVER:
+CMGR: <stat>,<oa>,[<alpha>],<scts>[,<tooa>,<fo>,<pid>,<dcs>
,
<sca>, <tosca>, <length>]<CR><LF><data>
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
172
If text mode (AT+CMGF=1), command successful and SMS-
SUBMIT:
+CMGR:<stat>,<da>,[<alpha>][,<toda>,<fo>,<pid>,<dcs>,[<vp>],
<sca>, <tosca>,<length>]<CR><LF><data>
OK
If text mode (AT+CMGF=1), command successful and SMS-
STATUS-REPORT:
+CMGR: <stat>,<fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<st>
OK
If text mode (AT+CMGF=1), command successful and SMS-
COMMAND:
+CMGR:<stat>,<fo>,<ct>[,<pid>,[<mn>],[<da>],[<toda>],<length
>]<CR><LF><data>
OK
If text mode (AT+CMGF=1), command successful and CBM
storage:
+CMGR:<stat>,<sn>,<mid>,<dcs>,<page>,<pages><CR><LF><d
ata>
OK
If PDU mode (AT+CMGF=0) and Command successful:
+CMGR:<stat>,[<alpha>],<length><CR><LF><pdu>
OK
+CMS ERROR: <err>
Defined values
<index>
Integer type; valu
e in the range of location numbers supported by the associated memory and start
with zero.
<stat>
1.Text Mode：
"REC UNREAD" received unread message (i.e. new message)
"REC READ" received read message
"STO UNSENT" stored unsent message
"STO SENT" stored sent message
2. PDU Mode：
0 – received unread message (i.e. new message)
1 – received read message.
2 – stored unsent message.
3 – stored sent message
<oa>
Originating-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit default
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
173
alphabet characters) are converted to characters of the currently selected TE character set, type of
address given by <tooa>.
<alpha>
String type alphanumeric representation of <da> or <oa> corresponding to the entry found in MT
phonebook; implem
entation of this feature is manufacturer specific; used character set should be
the one selected with command Select TE Character Set AT +CSCS.
<scts>
TP-Service-Centre-Time-Stamp in time-string format (refer <dt>).
<tooa>
TP-Originating-Address, Type-of-Address octet in integer format. (default refer <toda>).
<fo>
Depending on the command or result code: first octet of GSM 03.40 SMS-DELIVER,
SMS-SUBMIT (default 17), SMS-STATUS-REPORT, or SMS-COMMAND (default 2) in integer
format. SMS status report is supported under text mode if <fo> is set to 49.
<pid>
Protocol Identifier
GSM 03.40 TP-Protocol-Identifier in integer format
0…255
<dcs>
D
epending on the command or result code: SMS Data Coding Scheme (default 0), or Cell
Broadcast Data Coding Scheme in integer format.
<sca>
RP SC address Address-Value field in string format; BCD numbers (or GSM 7 bit default alphabet
characters) are converted to characters of the currently selected TE character set, type of address
given by <tosca>.
<tosca>
RP SC address Type-of-Address octet in integer format (default refer <toda>).
<length>
Integer type value indicating in the text mode (AT +CMGF
=1) the length of the message body
<data> > (or <cdata>) in characters; or in PDU mode (AT +CMGF=0), the length of the actual TP
data unit in octets. (i.e. the RP layer SMSC address octets are not counted in the length).
<data>
In the case of SMS: TP-User-Data in text mode responses; format:
1 – If <dcs> indicates that GSM 7 bit default alphabet is used and <fo> indicat
es that
TP-User-Data-Header-Indication is not set:
a. I
f TE character set other than "HEX": ME/TA converts GSM alphabet into current
TE character set.
b. If TE character set is "HEX": ME/TA converts each 7-bit character of GSM 7 bit
default alphabet into two IRA character long hexadecimal numbers. (e.g. character
Π (GSM 7 bit default alphabet 23) is presented as 17 (IRA 49 and 55)).
2 – If <dcs> indicates that 8-bit or UCS2 data coding scheme is used, or <fo> indicates that
TP-User-Data-Header-Indication is set: ME/TA converts each 8-bit octet into two IRA
character long hexadecimal numbers. (eg. octet with integer value 42 is presented to TE
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
174
as two characters 2A (IRA 50 and 65)).
3 – If <dcs> indicates that GSM 7 bit default alphabet is used:
a. If TE c
haracter set other than "HEX": ME/TA converts GSM alphabet into current
TE character set.
b. If TE character set is "HEX": ME/TA converts each 7-bit character of the GSM 7
bit default alphabet into two IRA character long hexadecimal numbers.
4 – If <dcs> indicates that 8-
bit or UCS2 data coding scheme is used: ME/TA converts
each 8-bit octet into two IRA character long hexadecimal numbers.
<da>
Destination-Address, Address-
Value field in string format; BCD numbers (or GSM 7 bit default
alphabet characte
rs) are converted to characters of the currently selected TE character set, type of
address given by <toda>.
<toda>
TP-Destination-Address, Type-of-Address octet in integer format. (when first character of <da> is +
(IRA 43) default is 145, otherwise default is 129). The range of value is from 128 to 255.
<vp>
Depending on SMS-SUBMIT <fo> setting: TP-Validity-
Period either in integer format (default
167) or in time-string format (refer <dt>).
<mr>
Message Reference
GSM 03.40 TP-Message-Reference in integer format.
<ra>
Recipient Address
GSM 03.40 TP-Recipient-Address Address-
Value field in string format;BCD numbers(or GSM
default alphabet characters) are converted to characters of the currently selected TE character
set(refer to command AT+CSCS);type of address given by <tora>
<tora>
Type of Recipient Address
GSM 04.11 TP-Recipient-Address Type-of-Address octet in integer format (default refer <toda>)
<dt>
Discharge Time
GSM 03.40 TP-Discharge-Time in time-string format:”yy/MM/dd,hh:mm:ss+zz”,where characters
indicate year (two last digits),month,day,hour,minutes,seconds and time zone.
<st>
Status
GSM 03.40 TP-Status in integer format
0…255
<ct>
Command Type
GSM 03.40 TP-Command-Type in integer format
0…255
<mn>
Message Number
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
175
GSM 03.40 TP-Message-Number in integer format
<sn>
Serial Number
GSM 03.41 CBM Serial Number in integer format
<mid>
Message Identifier
GSM 03.41 CBM Message Identifier in integer format
<page>
Page Parameter
GSM 03.41 CBM Page Parameter bits 4-7 in integer format
<pages>
Page parameter
GSM 03.41 CBM Page Parameter bits 0-3 in integer format
<pdu>
In the case of SMS: SC address followed by TPDU in hexadecimal format: ME/TA converts each
octet of TP data unit into two IRA character long hexadecimal numbers. (eg. octet with integer
value 42 is presented to TE as two characters 2A (IRA 50 and 65)).
Examples
AT+CMGR=1
+CMGR: "STO UNSENT","+10011",,145,17,0,0,167,"+8613800100500",145,11
Hello World
OK
7.13 AT+CMGS Send message
Description
This command is used to send message from a TE to the network (SMS-SUBMIT).
SIM PIN References
YES 3GPP TS 27.005
Syntax
Test Command Responses
AT+CMGS=? OK
Write Command Responses
If text mode (AT+CMGF=1):
AT+CMGS=<da>[,<toda>]<
CR>Text is entered.
<CTRL-Z/ESC>
If sending successfully:
+CMGS: <mr>
OK
If cancel sending:
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
176
If PDU mode(AT+CMGF=
0):
AT+CMGS=<length><CR>
PDU is entered
<CTRL-Z/ESC>
OK
If sending fails:
ERROR
If sending fails:
+CMS ERROR: <err>
Defined values
<da>
Destination-Address, Address-Value field in string
format; BCD numbers (or GSM 7 bit default
alphabet characters) are converted to characters of the currently selected TE character set, type of
address given by <toda>.
<toda>
TP-Destination-Address, Type-of-Address octet in integer format. (when first character of <da> is +
(IRA 43) default is 145, otherwise default is 129). The range of value is from 128 to 255.
<length>
integer type value indicating in the text mode (AT+CMGF
=1) the length of the message body
<data> > (or <cdata>) in characters; or in PDU mode (AT +CMGF=0), the length of the actual TP
data unit in octets. (i.e. the RP layer SMSC address octets are not counted in the length)
<mr>
Message Reference
GSM 03.40 TP-Message-Reference in integer format.
NOTE: In text mode, the maximum length of an SMS depends on the used coding scheme: It is
160 characters if the 7 bit GSM coding scheme is used.
Examples
AT+CMGS="13012832788"<CR>(TEXT MODE)
> ABCD<ctrl-Z/ESC>
+CMGS: 46
OK
7.14 AT+CMSS Send message from storage
Description
This command is used to send message with location value <index>
from preferred message
storage <mem2> to the network (SMS-SUBMIT or SMS-COMMAND).
SIM PIN References
YES 3GPP TS 27.005
Syntax
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
177
Test Command
Responses
AT+CMSS=? OK
Write Command
Responses
AT+CMSS=
<index> [,<da>[,<toda>]]
+CMSS: <mr>
OK
ERROR
If sending fails:
+CMS ERROR: <err>
Defined values
<index>
Integer type; value in the range of location numbers supported by the associated memory and start
with zero.
<da>
Destination-Address, Address-Value fi
eld in string format; BCD numbers (or GSM 7 bit default
alphabet characters) are converted to characters of the currently selected TE character set, type of
address given by <toda>.
<mr>
Message Reference
GSM 03.40 TP-Message-Reference in integer format.
<toda>
TP-Destination-Address, Type-of-Address octet in integer format. (when first character of <da> is +
(IRA 43) default is 145, otherwise default is 129). The range of value is from 128 to 255.
NOTE:
In text mode, the maximum length of an SMS depends on the used coding scheme: It is
160 characters if the 7 bit GSM coding scheme is used.
Examples
AT+CMSS=3
+CMSS: 0
OK
AT+CMSS=3,"13012345678"
+CMSS: 55
OK
7.15 AT+CMGW Write message to memory
Description
This command is used to store message (either SMS-DELIVER or SMS-SUBMIT) to memory
storage <mem2>.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
178
SIM PIN References
YES 3GPP TS 27.005
Syntax
Test Command
Responses
AT+CMGW=? OK
Write Command Responses
If text mode(AT+CMGF=1):
AT+CMGW=<oa>/<da>[,<t
ooa>/<toda>[,<stat>]]<CR>
Text is entered.
<CTRL-Z/ESC>
If PDU mode(AT+CMGF=
0):
AT+CMGW=<length>[,<sta
t>]<CR>PDU is entered.
<CTRL-Z/ESC>
If write successfully:
+CMGW: <index>
OK
If cancel write:
OK
If write fails:
ERROR
If write fails:
+CMS ERROR: <err>
Defined values
<index>
Integer type; va
lue in the range of location numbers supported by the associated memory and start
with zero.
<oa>
Originating-Address, Address-
Value field in string format; BCD numbers (or GSM 7 bit default
alphabet characters) are converted to characters of the current
ly selected TE character set, type of
address given by <tooa>.
<tooa>
TP-Originating-Address, Type-of-Address octet in integer format. (default refer <toda>).
<da>
Destination-Address, Address-Value field in string format; BCD numbers (or GSM 7 bit default
alphabet characters) are converted to characters of the currently selected TE character set, type of
address given by <toda>.
<toda>
TP-Destination-Address, Type-of-Address octet in integer format. (when first character of <da> is +
(IRA 43) default is 145, otherwise default is 129). The range of value is from 128 to 255.
<length>
Integer type value indicating in the text mode (AT +CMGF
=1) the length of the message body
<data> > (or <cdata>) in characters; or in PDU mode (AT+CMGF=0), the length of the actual TP
data unit in octets. (i.e. the RP layer SMSC address octets are not counted in the length).
<stat>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
179
1. Text Mode:
"STO UNSENT" stored unsent message
"STO SENT" stored sent message
2. PDU Mode:
2 – stored unsent message
3 – stored sent message
NOTE: In text mode, the maximum length of an SMS depends on the used coding scheme: It is
160 characters if the 7 bit GSM coding scheme is used.
Examples
AT+CMGW="13012832788" <CR> (TEXT MODE)
ABCD<ctrl-Z/ESC>
+CMGW:1
OK
7.16 AT+CMGD Delete message
Description
This command is used to delete message from preferred message storage <mem1> location
<index>. If <delflag> is present and not set to 0 then the ME shall ignore <index> and follow the
rules for <delflag> shown below.
SIM PIN References
YES 3GPP TS 27.005
Syntax
Test Command Responses
AT+CMGD=? +CMGD: (list of supported <index>
s)[,(list of supported
<delflag>s)]
OK
Write Command
Responses
AT+CMGD=
<index>[,<delflag>]
OK
ERROR
+CMS ERROR: <err>
Defined values
<index>
Integer type;
value in the range of location numbers supported by the associated memory and start
with zero.
<delflag>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
180
0 – (or omitted) Delete the message specified in <index>.
1 – Delete all read messages from preferred message storage, leaving unread messages and
stored mobile originated messages (whether sent or not) untouched.
2 – Delete all read messages from preferred message storage and sent mobile originated
messages, leaving unread messages and unsent mobile originated messages untouched.
3 – Delete all read messages from preferred message storage, sent and unsent mobile
originated messages leaving unread messages untouched.
4 – Delete all messages from preferred message storage including unread messages.
NOTE: If set <delflag>=1, 2, 3 or 4, <index> is omitted, such as AT+CMGD=,1.
Examples
AT+CMGD=1
OK
7.17 AT+CMGMT Change message status
Description
This command is used to
change the message status. If the status is unread, it will be changed read.
Other statuses don’t change.
Note: This command not support in CDMA/EVDO mode
SIM PIN References
YES Vendor
Syntax
Test Command Responses
AT+CMGMT=? OK
Write Command Responses
AT+CMGMT=<index>
OK
ERROR
+CMS ERROR: <err>
Defined values
<index>
Integer type; value in the range of location numbers supported by the associated memory and start
with zero.
Examples
AT+CMGMT=1
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
181
OK
7.18 AT+CMVP Set message valid period
Description
This command is used to set valid period for sending short message.
Note: This command not support in CDMA/EVDO mode
SIM PIN References
YES Vendor
Syntax
Test Command Responses
AT+CMVP=? +CMVP: (list of supported <vp>s)
OK
Read Command Responses
AT+CMVP? +CMVP:<vp>
OK
Write Command Responses
AT+CMVP=<vp> OK
ERROR
+CMS ERROR: <err>
Defined values
<vp>
Validity period value:
0 to 143 (<vp>+1) x 5 minutes (up to 12 hours)
144 to 167 12 hours + (<vp>-143) x 30 minutes
168 to 196 (<vp>-166) x 1 day
197 to 255 (<vp>-192) x 1 week
Examples
AT+CMVP=167
OK
AT+CMVP?
+CMVP: 167
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
182
7.19 AT+CMGRD Read and delete message
Description
This command is used to read message, and delete the message at the same time. It integrate
AT+CMGR and AT +CMGD, but it doesn’t change the message status.
Note: This command not support in CDMA/EVDO mode
SIM PIN References
YES Vendor
Syntax
Test Command Responses
AT+CMGRD=? OK
Write Command Responses
AT+CMGRD=<index> If text mode(AT+CMGF=1),command successful and SMS-DE-
LIVER:
+CMGRD:<stat>,<oa>,[<alpha>],<scts>[,<tooa>,<fo>,<pid>,<dcs
>, <sca>,<tosca>,<length>]<CR><LF><data>
OK
If text mode(AT+CMGF=1),command successful and SMS-SU-
BMIT:
+CMGRD:<stat>,<da>,[<alpha>][,<toda>,<fo>,<pid>,<dcs>,[<vp
>], <sca>,<tosca>,<length>]<CR><LF><data>
OK
If text mode(AT+CMGF=1),command successful and SMS-STA-
TUS- REPORT:
+CMGRD: <stat>,<fo>,<mr>,[<ra>],[<tora>],<scts>,<dt>,<st>
OK
If text mode(AT+CMGF=1),command successful and SMS-CO-
MMAND:
+CMGRD:<stat>,<fo>,<ct>[,<pid>,[<mn>],[<da>],[<toda>],<lengt
h><CR><LF><data>]
OK
If text mode(AT+CMGF=1),command successful and CBM sto-
rage:
+CMGRD:<stat>,<sn>,<mid>,<dcs>,<page>,<pages><CR><LF><
data>
OK
If PDU mode(AT+CMGF=0) and command successful:
+CMGRD: <stat>,[<alpha>],<length><CR><LF><pdu>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
183
OK
ERROR
+CMS ERROR: <err>
Defined values
Refer to command AT+CMGR.
Examples
AT+CMGRD=6
+CMGRD:"REC READ","+8613917787249",,"06/07/10,12:09:38+32",145,4,0,0, "+86138002105
00",145,4
How do you do
OK
7.20 AT+CMGSEX Send message
Description
This command is used to send message from a TE to the network (SMS-SUBMIT).
Note: This command not support in CDMA/EVDO mode
SIM PIN References
YES 3GPP TS 27.005
Syntax
Test Command
Responses
AT+CMGSEX=? OK
Write Command
Responses
If text mode (AT+CMGF=1):
AT+CMGSEX=<da>[,<toda
>][,<mr>, <msg_seg>,
<msg_total>]<CR>Text is
entered.
<CTRL-Z/ESC>
If sending successfully:
+CMGSEX: <mr>
OK
If cancel sending:
OK
If sending fails:
ERROR
If sending fails:
+CMS ERROR: <err>
Defined values
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
184
<da>
Destination-Address, Address-
Value field in string format; BCD numbers (or GSM 7 bit default
alphabet characters) are convert
ed to characters of the currently selected TE character set, type of
address given by <toda>.
<toda>
TP-Destination-Address, Type-of-Address octet in integer format. (When first character of <da> is
+ (IRA 43) default is 145, otherwise default is 129). The range of value is from 128 to 255.
<mr>
Message Reference
GSM 03.40 TP-Message-Reference in integer format.
<msg_seg>
The segment number for long sms
<msg_total>
The total number of the segments for long sms. Its range is from 2 to 255.
NOTE: In text mode, the maximum length of an SMS depends on the used coding scheme: For
single SMS, it is 160 characters if the 7 bit GSM coding scheme is used; For multiple long sms, it is
153 characters if the 7 bit GSM coding scheme is used.
Examples
AT+CMGSEX="13012832788", 190, 1, 2<CR>(TEXT MODE)
> ABCD<ctrl-Z/ESC>
+CMGSEX: 190
OK
AT+CMGSEX="13012832788", 190, 2, 2<CR>(TEXT MODE)
> EFGH<ctrl-Z/ESC>
+CMGSEX: 190
OK
7.21 AT+CMSSEX Send multi messages from storage
Description
This command is used to send messages with location value <index1>,<index2>,<index3>… from
preferred message storage <mem2> to the network (SMS-SUBMIT or SMS-COMMAND).The
max count of index is 13 one time.
Note: This command not support in CDMA/EVDO mode
SIM PIN References
YES 3GPP TS 27.005
Syntax
Test Command
Responses
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
185
AT+CMSSEX=?
OK
Write Command Responses
AT+CMSSEX=
<index> [,<index >[,… ]]
+CMSSEX: <mr>[,<mr>[,…]]
OK
ERROR
If sending fails:
[+CMSSEX: <mr>[,<mr>[,…]]]
+CMS ERROR: <err>
Defined values
<index>
Integer type; v
alue in the range of location numbers supported by the associated memory and start
with zero.
<mr>
Message Reference
GSM 03.40 TP-Message-Reference in integer format.
NOTE: In text mode, the maximum length of an SMS depends on the used coding scheme: It is
160 characters if the 7 bit GSM coding scheme is used.
Examples
AT+CMSSEX=0,1
+CMSSEX: 239,240
OK
AT+CMSSEX=0,1
+CMSSEX: 238
+CMS ERROR: Invalid memory index
7.22 AT+CMGP Set cdma/evdo text mode parameters
Description
The command is used to select
values for additional parameters needed when SM is sent to the
network or placed in storage when text format message mode is selected.
NOTE: take effect in CDMA/EVDO mode
SIM PIN References
NO 3GPP TS 27.005
Syntax
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
186
Test Command
Responses
AT+CMGP=? OK
Read Command
Responses
AT+CMGP? +CMGP: <tid>,<vpf>,<vp>,<ddtf>,<ddt>
OK
Write Command
Responses
AT+CMGP=[Tid][,<vpf>,<v
p>[,<ddtf>,<ddt>]]
OK
Defined values
<tid>
Teleservice ID, value maybe 4095,4096,4097,4098,4099,4100,4101,4102
Default 4098
<vpf>
Valid Period Format
0, Absolute
1, Relative
<vp>
Valid Period
“YY/MM/DD,HH/MM/SS” if vpf=0,
Integer not exceed 248 if vpf=1
<ddtf>
Deferred Delivery Time Format
0, Absolute
1, Relative
<ddt>
Deferred Delivery Time
“YY/MM/DD,HH/MM/SS” if ddtf=0,
Integer not exceed 248 if ddtf=1
Examples
AT+CMGP=4098,0,”11/04/22,16:21:00”,1,12
OK
8 AT Commands for Phonebook
8.1 AT+CPBS Select phonebook memory storage
Description
This command selects the active phonebook storage,i.e.the phonebook storage that all subsequent
phonebook commands will be operating on.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CPBS=?
+CPBS: (list of supported <storage>s)
OK
Read Command Responses
AT+CPBS? +CPBS: <storage>[,<used>,<total>]
OK
+CME ERROR: <err>
Write Command Responses
AT+CPBS=<storage>
OK
ERROR
+CME ERROR: <err>
Execution Command Responses
AT+CPBS Set default value “SM”:
OK
Defined values
<storage>
Values reserved by the present document:
"DC" ME dialed calls list
Capacity: max. 100 entries
AT+CPBW command is not applicable to this storage.
"MC" ME missed (unanswered received) calls list
Capacity: max. 100 entries
AT+CPBW command is not applicable to this storage.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
188
"RC" ME received calls list
Capacity: max. 100 entries
AT+CPBW command is not applicable to this storage.
"SM" SIM phonebook
Capacity: depending on SIM card
"ME" Mobile Equipment phonebook
Capacity: max. 500 entries
"FD" SIM fixdialling-phonebook
Capacity:depending on SIM card
"ON" MSISDN list
Capacity:depending on SIM card
"LD" Last number dialed phonebook
Capacity: depending on SIM card
AT+CPBW command is not applicable to this storage
"EN" Emergency numbers
Capacity: depending on SIM card
AT+CPBW command is not applicable to this storage.
<used>
Integer type value indicating the number of used locations in selected memory.
<total>
Integer type value indicating the total number of locations in selected memory.
Examples
AT+CPBS=?
+CPBS: ("SM","DC","FD","LD","MC","ME","RC","EN","ON")
OK
AT+CPBS=”SM”
OK
AT+CPBS?
+CPBS: "SM",1,200
OK
8.2 AT+CPBR Read phonebook entries
Description
This command gets the record information from the selected memory storage in phonebook. If the
storage is selected as “SM” then the command will return the record in SIM phonebook, the same to
others.
SIM PIN References
YES 3GPP TS 27.007
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
189
Syntax
Test Command Responses
AT+CPBR=? +CPBR: (<minIndex>-<maxIndex>), [<nlength>], [<tlength>]
OK
+CME ERROR: <err>
Write Command Responses
AT+CPBR=
<index1>[,<index2>]
[+CPBR: <index1>,<number>,<type>,<text>[<CR><LF>
+CPBR: <index2>,<number>,<type>,<text>[…]]]
OK
ERROR
+CME ERROR: <err>
Defined values
<index1>
Integer type value in the range of location numbers of phonebook memory.
<index2>
Integer type value in the range of location numbers of phonebook memory.
<index>
Integer type.the current position number of the Phonebook index.
<minIndex>
Integer type the minimum <index> number.
<maxIndex>
Integer type the maximum <index> number
<number>
String type, phone number of format <type>, the maximum length is <nlength>.
<type>
Type of phone number octet in integer format, default 145 when dialing string includes international
access code character "+", otherwise 129.
<text>
String type field of maximum length <tlength>; often this value is set as name.
<nlength>
Integer type value indicating the maximum length of field <number>.
<tlength>
Integer type value indicating the maximum length of field <text>.
Examples
AT+CPBS?
+CPBS: "SM",2,200
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
190
AT+CPBR=1,10
+CPBR: 1,"1234567890",129,"James"
+CPBR: 2,"0987654321",129,"Kevin"
OK
8.3 AT+CPBF Find phonebook entries
Description
This command finds the record in phonebook
(from the current phonebook memory storage
selected with AT+CPBS) which alphanumeric field has substring <findtext>.If <findtext> is null, it
will lists all the entries.
SIM PIN References
YES
3GPP TS 27.007
Syntax
Test Command Responses
AT+CPBF=? +CPBF: [<nlength>],[<tlength>]
OK
+CME ERROR: <err>
Write Command Responses
AT+CPBF=[<findtext>] [+CPBF: <index1>,<number>,<type>,<text>[<CR><LF>
+CPBF: <indexN>,<number>,<type>,<text>[…]]]
OK
ERROR
+CME ERROR: <err>
Defined values
<findtext>
String type,
this value is used to find the record. Character set should be the one selected with
command AT+CSCS.
<index>
Integer type values in the range of location numbers of phonebook memory.
<number>
String type, phone number of format <type>, the maximum length is <nlength>.
<type>
Type of phone number octet in integer format, default 145 when dialing string includes international
access code character "+", otherwise 129.
<text>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
191
String type field of maximum length <tlength>; Often this value is set as name.
<nlength>
Integer type value indicating the maximum length of field <number>.
<tlength>
Integer type value indicating the maximum length of field <text>.
Examples
AT+CPBF=" James "
+CPBF: 1,"1234567890",129," James "
OK
8.4 AT+CPBW Write phonebook entry
Description
This command writes phonebook entry in location number <index>
in the current phonebook
memory storage selected with AT+CPBS.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command
Responses
AT+CPBW=?
+CPBW:(list of supported <index>s),[<nlength>],
(list of supported <type>s),[<tlength>]
OK
+CME ERROR:<err>
Write Command Responses
AT+CPBW=[<index>][,<nu
mber>[,<type>[,<text>]]]
OK
ERROR
+CME ERROR:<err>
Defined values
<index>
Integer type values in the range of location numbers of phonebook memory.If <index> is not given,
the first free entry will be used. If <index> is given as the only
parameter, the phonebook entry
specified by <index> is deleted.If record number <index> already exists, it will be overwritten.
<number>
String type, phone number of format <type>, the maximum length is <nlength>.It
must be an
non-empty string.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
192
<type>
Type of address octet in integer format, The range of value is from 129 to 255.
If <number>
contains a leading “+” <type> = 145 (international) is used.Supported value are:
145 – when dialling string includes international access code character “+”
161 – national number.The network support for this type is optional
177 – network specific number,ISDN format
129 – otherwise
NOTE: Other value refer TS 24.008 [8] subclause 10.5.4.7.
<text>
String type field of maximum length <tlength>; character set as specified by command Select TE
Character Set AT +CSCS.
<nlength>
Integer type value indicating the maximum length of field <number>.
<tlength>
Integer type value indicating the maximum length of field <text>.
NOTE:
If the parameters of <type> and <text> are omitted and the first character of <number> is
‘+’，it will specify <type> as 145(129 if the first character isn’t ‘+’) and <text> as NULL.
Examples
AT+CPBW=3,"88888888",129,"John"
OK
AT+CPBW=,”6666666”,129,”mary”
OK
AT+CPBW=1
OK
8.5 AT+CNUM Subscriber number
Description
Execution command returns the MSISDNs related to the subscriber (this information can be stored
in the SIM or in the ME). If subscriber has different MSISDN for different services, each MSISDN
is returned in a separate line.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CNUM=?
OK
Execution Command Responses
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
193
AT+CNUM
[+CNUM: <alpha>,<number>,<type>[<CR><LF>
+CNUM: <alpha>, <number>,<type> [...]]]
OK
+CME ERROR: <err>
Defined values
<alpha>
Optional alphanumeric string associated with <number>,
used character set should be the one
selected with command Select TE Character Set AT +CSCS.
<number>
String type phone number of format specified by <type>.
<type>
Type of address octet in integer format.see also AT+CPBR <type>
Examples
AT+CNUM
+CNUM: "","13697252277",129
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
194
9 AT Commands for GPRS
9.1 AT+CGREG GPRS network registration status
Description
This command controls the presentation of an unsolicited result code “+CGREG: <stat>” when
<n>=1 and there is a change in the MT's GPRS network registration status.
The read command returns the status of result code presentation and an integer <stat> which shows
Whether the network has currently indicated the registration of the MT.
SIM PIN References
NO 3GPP TS 27.007
Syntax
Test Command Responses
AT+CGREG=? +CGREG: (list of supported <n>s)
OK
Read Command Responses
AT+CGREG? +CGREG: <n>,<stat>[,<lac>,<ci>]
OK
Write Command Responses
AT+CGREG=<n>
OK
Execution Command Responses
AT+CGREG Set default value:
OK
Defined values
<n>
0 – disable network registration unsolicited result code
1 – enable network registration unsolicited result code +CGREG: <stat>
2 – there is a change in the ME network registration status or a change of the network cell:
+CGREG: <stat>[,<lac>,<ci>]
<stat>
0 – not registered, ME is not currently searching an operator to register to
1 – registered, home network
2 – not registered, but ME is currently trying to attach or searching an operator to register
to
3 – registration denied
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
195
Examples
AT+CGREG=?
+CGREG: (0-1)
OK
AT+CGREG?
+CGREG: 0,0
OK
9.2 AT+CGATT Packet domain attach or detach
Description
The write command is used to attach the MT to, or detach the MT from, the Packet Domain service.
The read command returns the current Packet Domain service state.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CGATT=? +CGATT: (list of supported <state>s)
OK
ERROR
Read Command Responses
AT+CGATT? +CGATT: <state>
OK
4 – unknown
5 – registered, roaming
<lac>
Two bytes location area code in hexadecimal format (e.g.”00C3” equals 193 in decimal).
NOTE: The <lac> not supported in CDMA/HDR mode
<ci>
Cell ID in hexadecimal format.
GSM : Maximum is two byte
WCDMA : Maximum is four byte
TDS-CDMA : Maximum is four byte
NOTE: The <ci> not supported in CDMA/HDR mode
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
196
ERROR
Write Command
Responses
AT+CGATT=<state> OK
ERROR
+CME ERROR: <err>
Defined values
<state>
Indicates the state of Packet Domain attachment:
0 – detached
1 – attached
Examples
AT+CGATT?
+CGATT: 0
OK
AT+CGATT=1
OK
9.3 AT+CGACT PDP context activate or deactivate
Description
The write command is used to activate or deactivate the specified PDP context (s). This command is
not used in CDMA/EVDO mode.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CGACT=? +CGACT: (list of supported <state>s)
OK
Read Command Responses
AT+CGACT? +CGACT: [<cid>, <state> [<CR><LF>
+CGACT: <cid>, <state>
[...]]]
OK
Write Command Responses
AT+CGACT=<state> OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
197
[,<cid>]
ERROR
+CME ERROR: <err>
Defined values
<state>
Indicates the state of PDP context activation:
0 – deactivated
1 – activated
<cid>
A numeric parameter which specifies a particular PDP context definition (see AT+CGDCONT
command).
1…24,100…179
Examples
AT+CGACT?
+CGACT: 1,1
OK
AT+CGACT=?
+CGACT: (0,1)
OK
AT+CGACT=0,1
OK
9.4 AT+CGDCONT Define PDP context
Description
The set command specifies PDP context para
meter values for a PDP context identified by the
(local) context identification parameter <cid>
. The number of PDP contexts that may be in a
defined state at the same time is given by the range returned by the test command. A special form of
the write command (AT+CGDCONT=<cid>) causes the values for context <cid>
to become
undefined.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CGDCONT=? +CGDCONT: (range of supported<cid>s),<PDP_type>
,,,(list of
supported <d_comp>s),(list of supported <h_comp>
s)(list of
<ipv4_ctrl>s),(list of <emergency_flag>s)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
198
OK
ERROR
Read Command Responses
AT+CGDCONT? +CGDCONT: [<cid>, <PDP_type>, <APN>,<PDP_addr>,
<d_comp>, <h_comp>,<ipv4_ctrl>,<emergency_flag>[<CR><LF>
+CGDCONT: <cid>, <PDP_type>, <APN>, <PDP_addr>,
<d_comp>, <h_comp>,< ipv4_ctrl>,<emergency_flag>[...]]]
OK
ERROR
Write Command
Responses
AT+CGDCONT=<cid>[,<P
DP_type>[,<APN>[,<PDP_a
ddr>[,<d_comp>[,<h_comp>
][,<ipv4_ctrl>[,<emergency_
flag>]]]]]]
OK
ERROR
Execution Command Responses
AT+CGDCONT
OK
ERROR
Defined values
<cid>
(PDP Context Identifier) a numeric parameter which specifies a particular PDP context definition.
The parameter is local to the TE-MT interface and is used in other PDP context-related commands.
The range of permitted values (minimum value = 1) is returned by the test form of the command.
1…24,100…179
<PDP_type>
(Packet Data Protocol type) a string parameter which specifies the type of packet data protocol.
IP Internet Protocol
PPP Point to Point Protocol
IPV6 Internet Protocol Version 6
IPV4V6 Dual PDN Stack
<APN>
(Access Point Name) a string parameter which is a logical name that is used to select the GGSN or
the external packet data network.
<PDP_addr>
A string parameter that identifies the MT in the address space applicable to the PDP.
R
ead command will continue to return the null string even if an address has been allocated during
the PDP startup procedure. The allocated address may be read using command AT+CGPADDR.
<d_comp>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
199
A numeric parameter that controls PDP data compression, this value may depend on platform:
0 – off (default if value is omitted)
1 – on
2 – V.42bis
<h_comp>
A numeric parameter that controls PDP header compression, this value may depend on platform:
0 – off (default if value is omitted)
1 – on
2 – RFC1144
3 – RFC2507
4 – RFC3095
<ipv4_ctrl>
Parameter that controls how the MT/TA requests to get the IPv4 address information:
0 – Address Allocation through NAS Signaling
1 – on
<emergency_flag>
emergency_flag:
0 – off (default if value is omitted)
1 – on
Examples
AT+CGDCONT?
+CGDCONT: 1,"IPV4V6","","0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0",0,0,0,0
+CGDCONT: 2,"IPV6","ims","0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0",0,0,0,0
+CGDCONT: 3,"IPV4V6","","0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0",0,0,0,1
OK
AT+CGDCONT=?
+CGDCONT: (1-24,100-179),"IP",,,(0-2),(0-4),(0-1),(0-1)
+CGDCONT: (1-24,100-179),"PPP",,,(0-2),(0-4),(0-1),(0-1)
+CGDCONT: (1-24,100-179),"IPV6",,,(0-2),(0-4),(0-1),(0-1)
+CGDCONT: (1-24,100-179),"IPV4V6",,,(0-2),(0-4),(0-1),(0-1)
OK
9.5 AT+CGDSCONT Define Secondary PDP Context
Description
The set command specifies PDP context parameter values for a Secondary PDP context identified
by the (local) context identification parameter, <cid>. The number of PDP contexts that may be in a
defined state at the same time is given by the range returned by the test command. A special form of
the set command, AT
+CGDSCONT=<cid> causes the values for context number <cid> to become
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
200
undefined.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CGDSCONT=? +CGDSCONT: (range of supported <cid>s),(list of <p_cid>s for
active primary contexts), <PDP_type>, (list of supported
<d_comp>s),(list of supported <h_comp>s)
OK
ERROR
Read Command Responses
AT+CGDSCONT? +CGDSCONT: [<cid>,<p_cid>,<d_comp>,<h_comp>
[<CR><LF>+CGDSCONT: <cid>,<p_cid>,<d_comp>,<h_comp>
[...]]]
OK
ERROR
Write Command
Responses
AT
+CGDSCONT=<cid>[,<p_ci
d>[,<d_comp>[,<h_comp>]]
]
OK
ERROR
Defined values
<cid>
a numeric parameter which specif
ies a particular PDP context definition. The parameter is local to
the TE-MT interface and is used in other PDP context-related commands. The range of permitted
values (minimum value = 1) is returned by the test form of the command.
NOTE: The <cid>s for network-
initiated PDP contexts will have values outside the ranges
indicated for the <cid> in the test form of the commands +CGDCONT and +CGDSCONT.
<p_cid>
a numeric parameter which specifies a particular PDP context definition which has been specified
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
201
by use of the +CGDCONT command. The parameter is local to the TE-MT interface. The list of
permitted values is returned by the test form of the command.
<PDP_type>
(Packet Data Protocol type) a string parameter which specifies the type of packet data protocol.
IP Internet Protocol
PPP Point to Point Protocol
IPV6 Internet Protocol Version 6
IPV4V6 Dual PDN Stack
<d_comp>
a numeric parameter that controls PDP data compression (applicable for SNDCPonly) (refer
3GPP TS 44.065 [61])
0 off
1 on (manufacturer preferred compression)
2 V.42bis
Other values are reserved.
<h_comp>
a numeric parameter that controls PDP header compression (refer 3GPP TS 44.065
[61] and
3GPP TS 25.323 [62])
0 off
1 on (manufacturer preferred compression)
2 RFC1144 (applicable for SNDCP only)
3 RFC2507
4 RFC3095 (applicable for PDCP only)
Other values are reserved.
Examples
AT+CGDSCONT?
+CGDSCONT: 2,1,0,0
OK
AT+CGDSCONT=2,1
OK
AT+CGDSCONT=?
+CGDSCONT: (1-24,100-179),(4,5,6),"IP",(0-2),(0-4)
+CGDSCONT: (1-24,100-179),(4,5,6),"PPP",(0-2),(0-4)
+CGDSCONT: (1-24,100-179),(4,5,6),"IPV6",(0-2),(0-4)
+CGDSCONT: (1-24,100-179),(4,5,6),"IPV4V6",(0-2),(0-4)
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
202
9.6 AT+CGTFT Traffic Flow Template
Description
This command allows the TE to specify a Packet Filter - PF for a Traffic Flow Template - TFT that
is used in the GGSN in UMTS/GPRS and Packet GW in EPS for routing of packets onto different
QoS flows towards the TE. The concept is further described in the 3GPP TS 23.060
[47]. A TFT
consists of from one and up to 16 Packet Filters, each identified by a unique <packet filter
identifier>. A Packet Filter also has an <evaluation precedence index> that is unique within all TFTs
associated with all PDP contexts that are associated with the same PDP address.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command
Responses
AT+CGTFT=? +CGTFT: <PDP_type>,(list of supported
<packet filter
identifier>s),(list of supported
<evaluation precedence
index>s),(list of supported
<source address and subnet
mask>s),(list of supported
<protocol number (ipv4) / next header
(ipv6)>s),(list of supported <destination port range>
s),(list of
supported <source port range>s),(list of supported
<ipsec security
parameter index (spi)>s),(list of supported
<type of service (tos)
(ipv4) and mask / traffic class (ipv6) and mask>
s),(list of supported
<flow label (ipv6)>s)
[<CR><LF>+CGTFT: <PDP_type>,(list of supported
<packet filter
identifier>s),(list of supported
<evaluation precedence
index>s),(list of supported <source address and subnet
mask>s),(list of supported
<protocol number (ipv4) / next header
(ipv6)>s),(list of supported <destination port range>
s),(list of
supported <source port range>s),(list of supported
<ipsec security
parameter index (spi)>s),(list of supported <type of servi
ce (tos)
(ipv4) and mask / traffic class (ipv6) and mask>
s),(list of supported
<flow label (ipv6)>s)
[...]]
OK
ERROR
Read Command Responses
AT+CGTFT? +CGTFT: [<cid>,<packet filter identifier>,
<evaluation precedence
index>,<source address and subnet mask>,
<protocol number (ipv4)
/ next header (ipv6)>,<destination port range>,
<source port
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
203
range>,<ipsec security parameter index (spi)>,<type of service (tos)
(ipv4) and mask / traffic class (ipv6) and mask>,
<flow label
(ipv6)>
[<CR><LF>+CGTFT: <cid>,<packet filter identifier>,
<evaluation
precedence index>,<source address and subnet mask>,<protocol
number (ipv4) / next header (ipv6)>,
<destination port
range>,<source port range>,
<ipsec security parameter index
(spi)>,<type of service (tos) (ipv4) and mask / tr
affic class (ipv6)
and mask>,<flow label (ipv6)>
[...]]]
OK
ERROR
Write Command Responses
AT+CGTFT=<cid>[,[<packe
t filter
identifier>,<evaluation
precedence index>[,<source
address and subnet
mask>[,
<protocol number
(ipv4) / next header
(ipv6)>[,<dest
ination port
range>[,
<source port
range>[,
<ipsec security
parameter index
(spi)>[,
<type of service (tos)
(ipv4) and mask / traffic
class (ipv6) and
mask>[,
<flow label
(ipv6)>]]]]]]]]]
OK
ERROR
Execute Command Responses
AT+CGTFT OK
ERROR
Defined values
<cid>
a numeric parameter which specifies a particular PDP context definition (see theAT +CGDCONT
and AT +CGDSCONT commands).
<PDP_type>
(Packet Data Protocol type) a string parameter which specifies the type of packet data protocol.
IP Internet Protocol
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
204
PPP Point to Point Protocol
IPV6 Internet Protocol Version 6
IPV4V6 Dual PDN Stack
<packet filter identifier>
a numeric parameter, value range from 1 to 16.
<evaluation precedence index>
a numeric parameter. The value range is from 0 to 255.
<source address and subnet mask>
string type The string is given as dot-separated numeric (0-255) parameters on the form:
"a1.a2.a3.a4.m1.m2.m3.m4" for IPv4 or
"a1.a2.a3.a4.a5.a6.a7.a8.a9.a10.a11.a12.a13.a14.a15.a16.m1.m2.m3.m4.m5.m6.m7.m8.m9.m10.m1
1.m12.m13.m14.m15.m16", for IPv6.
<protocol number (ipv4) / next header (ipv6)>
a numeric parameter, value range from 0 to 255.
<destination port range>
string type. The string is given as dot-separated numeric (0-65535) parameters on the form "f.t".
<source port range>
string type. The string is given as dot-separated numeric (0-65535) parameters on the form "f.t".
<ipsec security parameter index (spi)>
numeric value in hexadecimal format. The value range is from 00000000 to FFFFFFFF.
<type of service (tos) (ipv4) and mask / traffic class (ipv6) and mask>
string type. The string is given as dot-separated numeric (0-255) parameters on the form "t.m".
<flow label (ipv6)>
numeric value in hexadecimal format. The value range is from 00000 to FFFFF. Valid for IPv6 only.
Examples
AT+CGTFT?
+CGTFT: 2,1,0,"74.125.71.99.255.255.255.255",0,0.0,0.0,0,0.0,0
OK
AT+CGTFT=2,1,0,"74.125.71.99.255.255.255.255"
OK
AT+CGTFT=?
+CGTFT: "IP",(1-2),(0-255),,(0-255),(0-65535.0-65535),(0-65535.0-65535),(0-FFFFF
FFF),(0-255.0-255),(0-FFFFF)
+CGTFT: "PPP",(1-2),(0-255),,(0-255),(0-65535.0-65535),(0-65535.0-65535),(0-FFFF
FFFF),(0-255.0-255),(0-FFFFF)
+CGTFT: "IPV6",(1-2),(0-255),,(0-255),(0-65535.0-65535),(0-65535.0-65535),(0-FFF
FFFFF),(0-255.0-255),(0-FFFFF)
+CGTFT:"IPV4V6",(1-16),(0-255),,(0-255),(0-65535.0-65535),(0-65535.0-65535),(0-FFFFFFFF)
,(0-255.0-255),(0-FFFFF)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
205
OK
9.7 AT+CGQREQ Quality of service profile (requested)
Description
This command allows the TE to specify a Quality of Service Profile that is used when the MT sends
an Activate PDP Context Request message to the network..
A special form of the set command
(AT+CGQREQ=<cid>) causes the requested profile for context number <cid>
to become
undefined.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CGQREQ=? +CGQREQ: <PDP_type>, (list of supported <precedence>s), (list
of supported <delay>s), (list of supported <reliability>s) , (list of
supported <peak>s), (list of supported <mean>s) [<CR><LF>
+CGQREQ: <PDP_type>, (list of supported <precedence>s), (list
of supported <delay>s), (list of supported <reliability>s) , (list of
supported <peak>s), (list of supported <mean>s)
[…]]
OK
ERROR
Read Command Responses
AT+CGQREQ?
+CGQREQ: [<cid>, <precedence >, <delay>, <reliability>,
<peak>, <mean>[<CR><LF>
+CGQREQ: <cid>, <precedence >, <delay>, <reliability.>, <peak>
,
<mean>[…]]]
OK
ERROR
Write Command Responses
AT+CGQREQ=<cid>[,<prec
edence>[,<delay>[,<reliabilit
y>[,<peak>[,<mean>]]]]]
OK
ERROR
Execution Command Responses
AT+CGQREQ OK
ERROR
Defined values
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
206
<cid>
A numeric parameter which specifies a particular PDP context definition (see AT+CGDCONT
command). The range is from 1 to 24,100 to 179
<PDP_type>
(Packet Data Protocol type) a string parameter which specifies the type of packet data protocol.
IP Internet Protocol
PPP Point to Point Protocol
IPV6 Internet Protocol Version 6
IPV4V6 Dual PDN Stack
<precedence>
A numeric parameter which specifies the precedence class:
0 – network subscribed value
1 – high priority
2 – normal priority
3 – low priority
<delay>
A numeric parameter which specifies the delay class:
0 – network subscribed value
1 – delay class 1
2 – delay class 2
3 – delay class 3
4 – delay class 4
<reliability>
A numeric parameter which specifies the reliability class:
0 – network subscribed value
1 – Non real-time traffic,error-sensitive application that cannot cope with data loss
2 – Non real-time traffic,error-sensitive application that can cope with infrequent data loss
3 – Non real-time traffic,error-sensitive application that can cope with data loss, GMM/-
SM,and SMS
4 – Real-time traffic,error-sensitive application that can cope with data loss
5 – Real-time traffic error non-sensitive application that can cope with data loss
<peak>
A numeric parameter which specifies the peak throughput class:
0 – network subscribed value
1 – Up to 1000 (8 kbit/s)
2 – Up to 2000 (16 kbit/s)
3 – Up to 4000 (32 kbit/s)
4 – Up to 8000 (64 kbit/s)
5 – Up to 16000 (128 kbit/s)
6 – Up to 32000 (256 kbit/s)
7 – Up to 64000 (512 kbit/s)
8 – Up to 128000 (1024 kbit/s)
9 – Up to 256000 (2048 kbit/s)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
207
<mean>
A numeric parameter which specifies the mean throughput class:
0 – network subscribed value
1 – 100 (~0.22 bit/s)
2 – 200 (~0.44 bit/s)
3 – 500 (~1.11 bit/s)
4 – 1000 (~2.2 bit/s)
5 – 2000 (~4.4 bit/s)
6 – 5000 (~11.1 bit/s)
7 – 10000 (~22 bit/s)
8 – 20000 (~44 bit/s)
9 – 50000 (~111 bit/s)
10 – 100000 (~0.22 kbit/s)
11 – 200000 (~0.44 kbit/s)
12 – 500000 (~1.11 kbit/s)
13 – 1000000 (~2.2 kbit/s)
14 – 2000000 (~4.4 kbit/s)
15 – 5000000 (~11.1 kbit/s)
16 – 10000000 (~22 kbit/s)
17 – 20000000 (~44 kbit/s)
18 – 50000000 (~111 kbit/s)
31 – optimization
Examples
AT+CGQREQ?
+CGQREQ:
OK
AT+CGQREQ=?
+CGQREQ: "IP",(0-3),(0-4),(0-5),(0-9),(0-18,31)
+CGQREQ: "PPP",(0-3),(0-4),(0-5),(0-9),(0-18,31)
+CGQREQ: "IPV6",(0-3),(0-4),(0-5),(0-9),(0-18,31)
+CGQREQ: "IPV4V6",(0-3),(0-4),(0-5),(0-9),(0-18,31)
OK
9.8 AT+CGEQREQ 3G quality of service profile (requested)
Description
The test command returns values supported as a compound value.
The read command returns the current settings for each defined context for which a QOS was
explicitly specified.
The write command allows the TE to specify a Quality of Service Profile for the context identified
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
208
by the context identification parameter <cid>
which is used when the MT sends an Activate PDP
Context Request message to the network.
A special form of the write command, AT+CGEQREQ=<cid> causes the req
uested profile for
context number <cid> to become undefined.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CGEQREQ=? +CGEQREQ: <PDP_type>,(list of supported <Traffic class>
s),(list
of supported <Maximum bitrate UL>s),(list of supported
<Maximum bitrate DL>s),(list of supported
<Guaranteed bitrate
UL>s,(list of supported <Guaranteed bitrate DL>
s),(list of
supported <Deliv ery order>s),(list of supported
<Maximum SDU
size>s),(list of supported <SDU error ratio>s),(list of supporte
d
<Residual bit error Ratio>s),(list of supported
<Delivery of
erroneous SDUs>s),(list of Supported <Transfer delay>
s),(list of
supported <Traffic handling priority>s),(list of supported <
Source
statistics descriptor>s),(list of supported <Signaling indica
tion
flag>s)
OK
ERROR
Read Command Responses
AT+CGEQREQ? +CGEQREQ: [<cid>,<Traffic class>,<Maximum bitrate UL>,
<Maximum bitrate DL>,<Guaranteed bitrate UL>,<Guaranteed
bitrate DL>,<Delivery order>,<Maximum SDU size>,<SDU error
ratio>,<Residual bit error ratio>,<Delivery of erroneous SDUs>,
<Transfer Delay>,<Traffic handling priority>,<Source statistics
descriptor>,< Signaling indication flag>][<CR><LF>+CGEQREQ:
<cid>,<Traffic class>,<Maximum bitrate UL>,<Maximum bitrate
DL>,<Guaranteed bitrate UL>,<Guaranteed bitrate DL>,<Delivery
order>,<Maximum SDU size>,<SDU error ratio>,<Residual bit
error ratio>,<Delivery of erroneous SDUs>,<Transfer Delay>,
<Traffic handling priority>,<Source statistics descriptor>,
<Signaling indication flag> […]]
OK
ERROR
Write Command Responses
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
209
AT+CGEQREQ=<cid>[,<Tr
affic class>[,<Maximum bit
rate UL>[,<Maximum bitrat
e DL>[,<Guaranteed bitrate
UL>[,<Guaranteed bitrate
DL>[,<Delivery order>[,<M
aximum SDU size>[,<SDU
error ratio>[,<Residual bit
error ratio>[,<Delivery of
erroneous SDUs>[,<Transfe
r delay>[,<Traffic handling
priority>[,<Source statistic
s descriptor>[,<Signaling in
dication flag>]]]]]]]]]]]]]]
OK
ERROR
+CME ERROR: <err>
Execution Command Responses
AT+CGEQREQ
OK
ERROR
Defined values
<cid>
Parameter specifies
a particular PDP context definition.The parameter is also used in other PDP
context-related commands. The range is from 1 to 24,100 to 179
<Traffic class>
0 – conversational
1 – streaming
2 – interactive
3 – background
4 – subscribed value
<Maximum bitrate UL>
This parameter indicates the maximum number of kbits/s delivered to UMTS(up-link traffic)at a
SAP. As an example a bitrate of 32kbit/s would be specified as 32(e.g. AT+CGEQREQ=…,32,…).
The range is from 0 to 11520. The default value is
0. If the parameter is set to '0' the subscribed
value will be requested.
<Maximum bitrate DL>
This parameter indicates the maximum number of kbits/s delivered to UMTS(down-link traffic)at a
SAP.As an example a bitrate of 32kbit/s would be specified as 32(e.g. AT+CGEQREQ=…,32,…).
The range is from 0 to 42200
. The default value is 0. If the parameter is set to '0' the subscribed
value will be requested.
<Guaranteed bitrate UL>
This parameter indicates the guaranteed number of kbit/s delivered to UMTS(up-link traffic)at a
SAP(provided that there is data to deliver).As an example a bitrate of 32kbit/s would be specified as
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
210
32(e.g.AT+CGEQREQ=…,32,…).
The range is from 0 to 11520
. The default value is 0. If the parameter is set to '0' the subscribed
value will be requested.
<Guaranteed bitrate DL>
This parameter indicates the guaranteed number of kbit/s delivered to UMTS(down-link traffic)at a
SAP(provided that there is data to deliver).As an example a bitrate of 32kbit/s would be specified as
32(e.g.AT+ C G EQREQ=…,32,…).
The range is from 0 to 42200
. The default value is 0. If the parameter is set to '0' the subscribed
value will be requested.
<Delivery order>
This parameter indicates whether the UMTS bearer shall provide in-sequence SDU delivery or not.
0 – no
1 – yes
2 – subscribed value
<Maximum SDU size>
This parameter indicates the maximum allowed SDU size in octets.
The range is from 0 to 1520. The default value is 0. If the parameter is set to '0' the subscribed value
will be requested.
<SDU error ratio>
This parameter indicates the target value for the fraction of SDUs lost or detected as erroneous.SDU
error ratio is defined only for conforming traffic.As an example a target SDU error ratio of 5*10-3
would be specified as “5E3”(e.g.AT+CGEQREQ=..,”5E3”,…).
“0E0” – subscribed value
“1E2”
“7E3”
“1E3”
“1E4”
“1E5”
“1E6”
“1E1”
<Residual bit error ratio>
This parameter indicates the target value for the undetected bit error ratio in the delivered SDUs. If
no error detection is requested,Resi
dual bit error ratio indicates the bit error ratio in the delivered
SDUs.As an example a target residual bit error ratio of 5*10-3 would be specified as “5E3”(e.g.
AT+CGEQREQ=…,”5E3”,..).
“0E0” – subscribed value
“5E2”
“1E2”
“5E3”
“4E3”
“1E3”
“1E4”
“1E5”
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
211
“1E6”
“6E8”
<Delivery of erroneous SDUs>
This parameter indicates whether SDUs detected as erroneous shall be delivered or not.
0 – no
1 – yes
2 – no detect
3 – subscribed value
<Transfer delay>
This parameter indicates the targeted time
between request to transfer an SDU at one SAP to its
delivery at the other SAP,in milliseconds.
The range is 0 and from 100
to 4000. The default value is 0. If the parameter is set to '0' the
subscribed value will be requested.
<Traffic handling priority>
This parameter specifies the relative importance for handling of all SDUs belonging to the UMTS
Bearer compared to the SDUs of the other bearers.
The range is from 0 to 3. The default value is 0. If the parameter is set to '0' the subscribed value
will be requested.
<Source statistics descriptor>
This parameter indicates profile parameter that
Source statistics descriptor for requested UMTS
QoS
The range is from 0 to 1
. The default value is 0. If the parameter is set to '0' the subscribed value
will be requested.
<Signaling indication flag>
This parameter indicates Signaling flag.
The range is from 0 to 1 The default value is 0. If the parameter is set to '0' the subscribed value will
be requested.
<PDP_type>
(Packet Data Protocol type) a string parameter which specifies the type of packet data protocol.
IP Internet Protocol
PPP Point to Point Protocol
IPV6 Internet Protocol Version 6
IPV4V6 Dual PDN Stack
Examples
AT+CGEQREQ?
+CGEQREQ:
OK
AT+CGEQREQ=?
+CGEQREQ: "IP",(0-4),(0-11520),(0-42200),(0-11520),(0-42200),(0-2),(0-1520),("0E0","1E
1","1E2","7E3","1E3","1E4","1E5","1E6"),("0E0","5E2","1E2","5E3","4E3","1E3","1E
4","1E5","1E6","6E8"),(0-3),(0,100-4000),(0-3) ,(0-1),(0-1)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
212
+CGEQREQ: "PPP",(0-4),(0-11520),(0-42200),(0-11520),(0-42200),(0-2),(0-1520),("0E0","1
E1","1E2","7E3","1E3","1E4","1E5","1E6"),("0E0","5E2","1E2","5E3","4E3","1E3","1
E4","1E5","1E6","6E8"),(0-3),(0,100-4000),(0-3) ,(0-1),(0-1)
+CGEQREQ: "IPV6",(0-4),(0-11520),(0-42200),(0-11520),(0-42200),(0-2),(0-1520),("0E0","
1E1","1E2","7E3","1E3","1E4","1E5","1E6"),("0E0","5E2","1E2","5E3","4E3","1E3","
1E4","1E5","1E6","6E8"),(0-3),(0,100-4000),(0-3) ,(0-1),(0-1)
+CGEQREQ:"IPV4V6",(0-4),(0-11520),(0-42200),(0-11520),(0-42200),(0-2),(0-1520),("0E0","1E1
","1E2","7E3","1E3","1E4","1E5","1E6"),("0E0","5E2","1E2","5E3","4E3","1E3","1E4","1E5","1
E6","6E8"),(0-3),(0,100-4000),(0-3),(0-1),(0-1)
OK
9.9 AT+CGQMIN Quality of service profile (minimum acceptable)
Description
This command allows the TE to specify a minimum acceptable profile which is checked by the MT
against the negotiated profile returned in the Activate PDP Context Accept message.A special form
of the set command,AT+CGQMIN=<cid>
causes the minimum acceptable profile for context
number <cid> to become undefined.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CGQMIN=? +CGQMIN: <PDP_type>, (list of supported <precedence>s), (list
of supported <delay>s), (list of supported <reliability>s) , (list of
supported <peak>s), (list of supported <mean>s) [<CR><LF>
+CGQMIN: <PDP_type>, (list of supported <precedence>s), (list
of supported <delay>s), (list of supported <reliability>s) , (list of
supported <peak>s), (list of supported <mean>s)[…]]
OK
ERROR
Read Command Responses
AT+CGQMIN? +CGQMIN: [<cid>, <precedence >, <delay>, <reliability>,
<peak>, <mean>[<CR><LF>
+CGQMIN: <cid>, <precedence >, <delay>, <reliability.>, <peak>,
<mean>
[…]]]
OK
ERROR
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
213
Write Command
Responses
AT+CGQMIN=<cid>[,<prec
edence>[,<delay>[,<reliabilit
y>[,<peak> [,<mean>]]]]]
OK
ERROR
Execution Command Responses
AT+CGQMIN OK
ERROR
Defined values
<cid>
A numeric parameter which specifies a particular PDP context definition (see AT+CGDCONT
command). The range is from 1 to 24,100 to 179.
<PDP_type>
(Packet Data Protocol type) a string parameter which specifies the type of packet data protocol.
IP Internet Protocol
PPP Point to Point Protocol
IPV6 Internet Protocol Version 6
IPV4V6 Dual PDN Stack
<precedence>
A numeric parameter which specifies the precedence class:
0 – network subscribed value
1 – high priority
2 – normal priority
3 – low priority
<delay>
A numeric parameter which specifies the delay class:
0 – network subscribed value
1 – delay class 1
2 – delay class 2
3 – delay class 3
4 – delay class 4
<reliability>
A numeric parameter which specifies the reliability class:
0 – network subscribed value
1 – Non real-time traffic,error-sensitive application that cannot cope with data loss
2 – Non real-time traffic,error-sensitive application that can cope with infrequent data loss
3 – Non real-time traffic,error-sensitive application that can cope with data loss, GMM/-
SM,and SMS
4 – Real-time traffic,error-sensitive application that can cope with data loss
5 – Real-time traffic error non-sensitive application that can cope with data loss
<peak>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
214
A numeric parameter which specifies the peak throughput class:
0 – network subscribed value
1 – Up to 1000 (8 kbit/s)
2 – Up to 2000 (16 kbit/s)
3 – Up to 4000 (32 kbit/s)
4 – Up to 8000 (64 kbit/s)
5 – Up to 16000 (128 kbit/s)
6 – Up to 32000 (256 kbit/s)
7 – Up to 64000 (512 kbit/s)
8 – Up to 128000 (1024 kbit/s)
9 – Up to 256000 (2048 kbit/s)
<mean>
A numeric parameter which specifies the mean throughput class:
0 – network subscribed value
1 – 100 (~0.22 bit/s)
2 – 200 (~0.44 bit/s)
3 – 500 (~1.11 bit/s)
4 – 1000 (~2.2 bit/s)
5 – 2000 (~4.4 bit/s)
6 – 5000 (~11.1 bit/s)
7 – 10000 (~22 bit/s)
8 – 20000 (~44 bit/s)
9 – 50000 (~111 bit/s)
10 – 100000 (~0.22 kbit/s)
11 – 200000 (~0.44 kbit/s)
12 – 500000 (~1.11 kbit/s)
13 – 1000000 (~2.2 kbit/s)
14 – 2000000 (~4.4 kbit/s)
15 – 5000000 (~11.1 kbit/s)
16 – 10000000 (~22 kbit/s)
17 – 20000000 (~44 kbit/s)
18 – 50000000 (~111 kbit/s)
31 – optimization
Examples
AT+CGQMIN?
+CGQMIN:
OK
AT+CGQMIN=?
+CGQMIN: "IP",(0-3),(0-4),(0-5),(0-9),(0-18,31)
+CGQMIN: "PPP",(0-3),(0-4),(0-5),(0-9),(0-18,31)
+CGQMIN: "IPV6",(0-3),(0-4),(0-5),(0-9),(0-18,31)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
215
+CGQMIN: "IPV4V6",(0-3),(0-4),(0-5),(0-9),(0-18,31)
OK
9.10 AT+CGEQMIN 3G quality of service profile (minimum acceptable)
Description
The test command returns values supported as a compound value.
The read command returns the current settings for each defined context for which a QOS was
explicitly specified.
The write command allow the TE to specify a Quallity of Service Profile for the context identified
by the context identification parameter <cid>
which is checked by the MT against the negotiated
profile returned in the Activate/Modify PDP Context Accept message.
A special form of the write command, AT+CGEQMIN=<cid>
causes the requested for context
number <cid> to become undefined.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command
Responses
AT+CGEQMIN=? +CGEQMIN: <PDP_type>,(list of supported <Traffic class>
s),(list
of supported <Maximum bitrate UL>
s),(list of supported
<Maximum bitrate DL>s),(list of supported
<Guaranteed bitrate
UL>s,(list of supported <Guaranteed bitrate DL>
s),(list of
supported <Deliv ery order>s),(list of supported
<Maximum SDU
size>s),(list of supported <SDU error ratio>
s),(list of supported
<Residual bit error Ratio>s),(list of supported
<Delivery of
erroneous SDUs>s),(list of Supported <Transfer delay>
s),(list of
supported <Traffic handling priority>s),(list of supported <
Source
statistics descriptor>s),(list of supported <
Signaling indication
flag>s)
OK
ERROR
Read Command Responses
AT+CGEQMIN? +CGEQMIN: [<cid>,<Traffic class>,<Maximum bitrate UL>,
<Maximum bitrate DL>,<Guaranteed bitrate UL>,<Guaranteed
bitrate DL>,<Delivery order>,<Maximum SDU size>,<SDU error
ratio>,<Residual bit error ratio>,<Delivery of erroneous SDUs>,
<Transfer Delay>,<Traffic handling priority>,<Source statistics
descriptor>,< Signaling indication flag>][<CR><LF>+CGEQMIN:
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
216
<cid>,<Traffic class>,<Maximum bitrate UL>,<Maximum bitrate
DL>,<Guaranteed bitrate UL>,<Guaranteed bitrate DL>,<Delivery
order>,<Maximum SDU size>,<SDU error ratio>,<Residual bit
error ratio>,<Delivery of erroneous SDUs>,<Transfer Delay>,
<Traffic handling priority>,<Source statistics descriptor>,
<Signaling indication flag>[…]]
OK
ERROR
Write Command Responses
AT+CGEQMIN=<cid>[,<Tr
affic class>[,<Maximum bit
rate UL>[,<Maximum bitrat
e DL>[,<Guaranteed bitrate
UL>[,<Guaranteed bitrate
DL>[,<Delivery order>[,<M
aximum SDU size>[,<SDU
error ratio>[,<Residual bit
error ratio>[,<Delivery of
erroneous SDUs>[,<Transfe
r delay>[,<Traffic handling
priority>[,<Source statistic
s descriptor>[,<Signaling in
dication flag>]]]]]]]]]]]]]]
OK
ERROR
+CME ERROR: <err>
Execution Command Responses
AT+CGEQMIN
OK
ERROR
Defined values
<cid>
Parameter specifies a particular PDP context definition.The parameter is also used in other PDP
context-related commands. The range is from 1 to 24,100 to 179.
<Traffic class>
0 – conversational
1 – streaming
2 – interactive
3 – background
4 – subscribed value
<Maximum bitrate UL>
This parameter indicates the maximum number of kbits/s delivered to UMTS(up-link traffic)at a
SAP.As an example a bitrate of 32kbit/s would be specified as 32(e.g. AT+CGEQMIN=…,32,…).
The range is from 0 to 11520. The default value is 0.
If the parameter is set to '0' the subscribed
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
217
value will be requested.
<Maximum bitrate DL>
This parameter indicates the maximum number of kbits/s delivered to UMTS(down-link traffic)at a
SAP.As an example a bitrate of 32kbit/s would be specified as 32(e.g. AT+CGEQMIN=…,32,…).
The range is from 0 to 42200. The default value is 0. If the parameter is set to '0' the subscribed
value will be requested.
<Guaranteed bitrate UL>
This parameter indicates the guaranteed number of kbit/s delivered to UMTS(up-link traffic)at a
SAP(provided that there is data to deliver).As an example a bitrate of 32kbit/s would be specified as
32(e.g.AT+CGEQMIN=…,32,…).
The range is from 0 to 11520. The default value is 0.
If the parameter is set to '0' the subscribed
value will be requested.
<Guaranteed bitrate DL>
This parameter indicates the guaranteed number of kbit/s delivered to UMTS(down-link traffic)at a
SAP(provided that there is data to deliver).As an example a bitrate of 32kbit/s would be specified as
32(e.g.AT+CGEQMIN=…,32,…).
The range is from 0 to 42200. The default value is 0. If the parameter is set to '0' the subscribed
value will be requested.
<Delivery order>
This parameter indicates whether the UMTS bearer shall provide in-sequence SDU delivery or not.
0 – no
1 – yes
2 – subscribed value
<Maximum SDU size>
This parameter indicates the maximum allowed SDU size inoctets.
The range is from 0 to 1520. The default value is 0. If the parameter is set to '0' the subscribed value
will be requested.
<SDU error ratio>
This parameter indicates the target value for the fraction of SDUs lost or detected as erroneous.SDU
error ratio is defined only for conforming traffic.As an example a target SDU error ratio of 5*10-3
would be specified as “5E3”(e.g.AT+CGEQMIN=..,”5E3”,…).
“0E0” – subscribed value
“1E2”
“7E3”
“1E3”
“1E4”
“1E5”
“1E6”
“1E1”
<Residual bit error ratio>
This parameter indicates the target value for the undetected bit error ratio in the delivered SDUs. If
no error detection is requested,Residual bit error ratio indicates the bit error ratio in the delivered
SDUs.As an example a target residual bit error ratio of 5*10-3 would be specified as “5E3”(e.g.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
218
AT+CGEQMIN=…,”5E3”,..).
“0E0” – subscribed value
“5E2”
“1E2”
“5E3”
“4E3”
“1E3”
“1E4”
“1E5”
“1E6”
“6E8”
<Delivery of erroneous SDUs>
This parameter indicates whether SDUs detected as erroneous shall be delivered or not.
0 – no
1 – yes
2 – no detect
3 – subscribed value
<Transfer delay>
This parameter indicates the targeted time between request to transfer an SDU at one SAP to its
delivery at the other SAP,in milliseconds.
The range is 0 and from 100 to 4000. The default value is 0. If the parameter is
set to '0' the
subscribed value will be requested.
<Traffic handling priority>
This parameter specifies the relative importance for handling of all SDUs belonging to the UMTS
Bearer compared to the SDUs of the other bearers.
The range is from 0 to 3. The default value is 0. If the parameter is set to '0' the subscribed value
will be requested.
<Source statistics descriptor>
This parameter indicates profile parameter that
Source statistics descriptor for requested UMTS
QoS
The range is from 0 to 1. The
default value is 0. If the parameter is set to '0' the subscribed value
will be requested.
<Signaling indication flag>
This parameter indicates Signaling flag.
The range is from 0 to 1 The default value is 0. If the parameter is set to '0' the subscribed value will
be requested.
<PDP_type>
(Packet Data Protocol type) a string parameter which specifies the type of packet data protocol.
IP Internet Protocol
PPP Point to Point Protocol
IPV6 Internet Protocol Version 6
IPV4V6 Dual PDN Stack
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
219
Examples
AT+CGEQMIN?
+CGEQMIN:
OK
AT+CGEQMIN=?
+CGEQMIN: "IP",(0-4),(0-11520),(0-42200),(0-115200),(0-42200),(0-2),(0-1520),("0E0","1E
1","1E2","7E3","1E3","1E4","1E5","1E6"),("0E0","5E2","1E2","5E3","4E3","1E3","1E
4","1E5","1E6","6E8"),(0-3),(0,100-4000),(0-3) ,(0-1),(0-1)
+CGEQMIN: "PPP",(0-4),(0-11520),(0-42200),(0-115200),(0-42200),(0-2),(0-1520),("0E0","1
E1","1E2","7E3","1E3","1E4","1E5","1E6"),("0E0","5E2","1E2","5E3","4E3","1E3","1
E4","1E5","1E6","6E8"),(0-3),(0,100-4000),(0-3) ,(0-1),(0-1)
+CGEQMIN: "IPV6",(0-4),(0-11520),(0-42200),(0-115200),(0-42200),(0-2),(0-1520),("0E0","
1E1","1E2","7E3","1E3","1E4","1E5","1E6"),("0E0","5E2","1E2","5E3","4E3","1E3","
1E4","1E5","1E6","6E8"),(0-3),(0,100-4000),(0-3) ,(0-1),(0-1)
+CGEQMIN:"IPV4V6",(0-4),(0-11520),(0-42200),(0-115200),(0-42200),(0-2),(0-1520),("0E0","1E
1","1E2","7E3","1E3","1E4","1E5","1E6"),("0E0","5E2","1E2","5E3","4E3","1E3","1E4","1E5","
1E6","6E8"),(0-3),(0,100-4000),(0-3),(0-1),(0-1)
OK
9.11 AT+CGDATA Enter data state
Description
The command cause
s the MT to perform whatever actions are necessary to establish
communication between the TE and the network using one or more Packet Domain PDP types. This
may include performing a PS attach and one or more PDP context activations. The command is not
used in CDMA/EVDO mode.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command
Responses
AT+CGDATA=? +CGDATA: (list of supported <L2P>s)
OK
ERROR
Write Command Responses
AT+CGDATA=[<L2P>,[<ci
d>]]
CONNECT [<text>]
NO CARRIER
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
220
ERROR
+CME ERROR: <err>
Defined values
<L2P>
A string parameter that indicates the layer 2 protocol to be used between the TE and MT.
PPP Point-to-point protocol for a PDP such as IP
<text>
CONNECT result code string; the string formats please refer ATX/AT\V/AT&E command.
<cid>
A numeric parameter which specifies a particular PDP context definition (see AT+CGDCONT
command).
1…24,100…179
Examples
AT+CGDATA=?
+CGDATA: ("PPP")
OK
AT+CGDATA="PPP",1
CONNECT 115200
9.12 AT+CGPADDR Show PDP address
Description
The write command returns a list of PDP addresses for the specified context identifiers.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CGPADDR=? [+CGPADDR: (list of defined <cid>s)]
OK
ERROR
Write Command Responses
AT+CGPADDR=
<cid>[,<cid>[,…]]
[+CGPADDR:<cid>,<PDP_addr>[<CR><LF>
+CGPADDR: <cid>,<PDP_addr>[...]]]
OK
SIM card supports IPV4V6 type
and the PDP_type of the command
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
221
“at+cgdcont” defined is ipv4v6 :
[+CGPADDR: <cid>,<PDP_addr_IPV4>,<PDP_addr_IPV6>]
+CGPADDR: <cid>,<PDP_addr_IPV4>,<PDP_addr_IPV6> [...]]]
OK
ERROR
+CME ERROR: <err>
Execution Command
Responses
AT+CGPADDR [+CGPADDR: <cid>,<PDP_addr>]
+CGPADDR: <cid>,<PDP_addr>[...]]]
OK
SIM card supports IPV4V6 type
and the PDP_type of the command
“at+cgdcont” defined is ipv4v6 :
[+CGPADDR: <cid>,<PDP_addr_IPV4>,<PDP_addr_IPV6>]
+CGPADDR: <cid>,<PDP_addr_IPV4>,<PDP_addr_IPV6> [...]]]
OK
ERROR
+CME ERROR: <err>
Defined values
<cid>
A numeric parameter which specifies a particular PDP context definition (see AT+CGDCONT
command). If no <cid> is specified, the addresses for all defined contexts are returned.
1…24,100…179
<PDP_addr>
A
string that identifies the MT in the address space applicable to the PDP. The address may be static
or dynamic. For a static address, it will be the one set by the AT+CGDCONT command when the
context was defined. For a dynamic address it will be the one assigned during the last PDP context
activation that used the context definition referred to by <cid>. <PDP_addr> is omitted if none is
available.
<PDP_addr_IPV4>
A string parameter that identifies the MT in the address space applicable to the PDP.
<PDP_addr_IPV6>
A string parameter that identifies the MT in the address space applicable to the PDP
when the
sim_card supports ipv6. The pdp type must be set to “ipv6” or “ipv4v6” by the AT +CGDCONT
command.
Examples
AT+CGPADDR =?
+CGPADDR: (1)
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
222
AT+CGPADDR=1
+CGDCONT: 1,"IPV4V6","","0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0",0,0,0,0
OK
AT+CGPADDR
+CGPADDR: 1,10.195.1.140,36.9.136.148.128.48.134.218.173.205.47.44.88.174.123.200
+CGPADDR: 2,10.195.34.92,36.9.136.148.128.48.146.115.92.140.135.230.248.131.5.90
+CGPADDR: 3,0.0.0.0,0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0
OK
9.13 AT+CGCLASS GPRS mobile station class
Description
This command is used to set the MT to operate according to the specified GPRS mobile class.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command
Responses
AT+CGCLASS=? +CGCLASS: (list of supported <class>s)
OK
ERROR
Read Command Responses
AT+CGCLASS?
+CGCLASS: <class>
OK
ERROR
Write Command Responses
AT+CGCLASS=<class>
OK
ERROR
+CME ERROR: <err>
Execution Command Responses
AT+CGCLASS
Set default value:
OK
ERROR
Defined values
<class>
A string parameter which indicates the GPRS mobile class (in descending order of functionality)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
223
A – class A (highest)
Examples
AT+CGCLASS=?
+CGCLASS: ("A")
OK
AT+CGCLASS?
+CGCLASS: "A"
OK
9.14 AT+CGEREP GPRS event reporting
Description
The write command enables or disables sending of unsolicited result codes, “+CGEV” from MT to
TE in the case of certain events occurring in the Packet Domain MT or the network. <mode>
controls the processing of unsolicited result codes specified within this command. <bfr> controls
the effect on buffered codes when <mode> 1 or 2 is entered. If a setting is not supported by the MT,
ERROR or +CME ERROR: is returned.
Read command returns the current <mode> and buffer settings.
Test command returns the modes and buffer settings supported by the MT as compound values.
SIM PIN References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CGEREP=? +CGEREP: (list of supported <mode>s),(list of supported <bfr>s)
OK
ERROR
Read Command
Responses
AT+CGEREP? +CGEREP: <mode>,<bfr>
OK
ERROR
Write Command Responses
AT+CGEREP=
<mode>[,<bfr>]
OK
ERROR
+CME ERROR: <err>
Execution Command Responses
AT+CGEREP OK
ERROR
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
224
Defined values
<mode>
0 –
buffer unsolicited result codes in the MT; if MT result code buffer is full, the oldest
ones can be discarded. No codes are forwarded to the TE.
1 – discard unsolicited result codes when MT-TE link is reserved (e.g. in on-
line data
mode); otherwise forward them directly to the TE.
2 – buffer unsolicited result codes in the MT when MT-TE link is reserved (e.g. in on-line
data mode) and flush them to the TE when MT-TE link becomes available; otherwise
forward them directly to the TE.
<bfr>
0 –
MT buffer of unsolicited result codes defined within this command is cleared when
<mode> 1 or 2 is entered.
1 – MT buffer of unsolicited result codes defined within this command is flushed to the TE
when <mode> 1 or 2 is entered (OK response shall be given before flushing the codes).
The following unsolicited result codes and the corresponding events are defined:
+CGEV: REJECT <PDP_type>, <PDP_addr>
A netwo
rk request for PDP context activation occurred when the MT was unable to
report it to the TE with a +CRING unsolicited result code and was automatically
rejected.
+CGEV: NW REACT <PDP_type>, <PDP_addr>, [<cid>]
The network has requested a context reactivation. The <cid> that was used to reactivate
the context is provided if known to the MT.
+CGEV: NW DEACT <PDP_type>, <PDP_addr>, [<cid>]
The network has forced a context deactivation. The <cid> that was used to activate the
context is provided if known to the MT.
+CGEV: ME DEACT <PDP_type>, <PDP_addr>, [<cid>]
The mobile equipment has forced a context deactivation. The <cid> that was used to
activate the context is provided if known to the MT.
+CGEV: NW DETACH
The network has forced a Packet Domain detach. This implies that all active contexts
have been deactivated. These are not reported separately.
+CGEV: ME DETACH
The mobile equipment has forced a Packet Domain detach. This implies that all active
contexts have been deactivated. These are not reported separately.
+CGEV: NW CLASS <class>
The network has forced a change of MS class. The highest available class is reported
(see AT+CGCLASS).
+CGEV: ME CLASS <class>
The mobile equipment has forced a change of MS class. The highest available class is
reported (see AT +CGCLASS).
Examples
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
225
AT+CGEREP=?
+CGEREP: (0-2),(0-1)
OK
AT+CGEREP?
+CGEREP: 0,0
OK
9.15 AT+CGAUTH Set type of authentication for PDP-IP connections of
GPRS
Description
This command is used to set type of authentication for PDP-IP connections of GPRS.
SIM PIN References
YES Vendor
Syntax
Test Command
Responses
AT+CGAUTH=? +CGAUTH:, ,127 ,127(for CDMA1x-EvDo only)
+CGAUTH:(range of supported <cid>s),(list of supported <auth_-
type> s),127,127
(NOTE: the first line of the response is for CDMA 1x a
nd Evdo
only)
OK
ERROR
+CME ERROR: <err>
Read Command
Responses
AT+CGAUTH? +CGAUTH: ,,"user ","passwd"(for CDMA1x-EvDo only)
+CGAUTH:[ <cid>,<auth_type>[,<user>,<passwd>]]<CR><LF>
…
OK
ERROR
+CME ERROR: <err>
Write Command Responses
AT+CGAUTH=<cid>[,<aut
h_type>[,<passwd>[,<user>]
]]
OK
ERROR
AT+CGAUTH=,,<user>,<pa
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
226
sswd> (for
CDMA1x-EvDo)
+CME ERROR: <err>
Execution Command Responses
AT+CGAUTH OK
ERROR
+CME ERROR: <err>
Defined values
<cid>
Parameter specifies a particular PDP context definition. This is also used in other PDP
context-related commands.
1…24,100…179
<auth_type>
Indicate the type of authentication to be used for the specified context. If CHAP is selected another
parameter <passwd> needs to be specified. If PAP is selected two additional parameters <passwd>
and <user> need to specified.
0 – none
1 – PAP
2 – CHAP
3 – PAP or CHAP
<passwd>
Parameter specifies the password used for authentication.
<user>
Parameter specifies the user name used for authentication.
Examples
AT+CGAUTH=?
+CGAUTH: ,,127,127(for CDMA1x-EvDo only)
+CGAUTH: (1-24,100-179),(0-3),127,127
OK
AT+CGAUTH=1,1,”123”,”SIMCOM”
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
227
10 Hardware Related Commands
10.1 AT+CVALARM Low and high voltage Alarm
Description
This command is used to open or close the low voltage alarm function.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CVALARM=? +CVALARM: (list of supported <enable>s), (list of supported <
<low voltage>s), (list of supported high < high voltage>s)
OK
Read Command
Responses
AT+CVALARM? +CVALARM: <enable>,<low voltage>, <high voltage>
OK
Write Command Responses
AT+CVALARM=<enable>[,<l
ow voltage>],[<high voltage>]
OK
ERROR
Defined values
<enable>
0 – Close
1 – Open. If voltage < < low voltage>, it will report “UNDER-VOLTAGE WARNNING”
every 10s. If voltage > <high voltage>, it will report “OVER-VOLTAGE
WARNNING” every 10s.
<low voltage>
Between 3300mV and 4000mV. Default value is 3300.
<high voltage>
Between 4000mV and 4300mV. Default value is 4300.
NOTE
：
The three parameters will be saved automatically.
Examples
AT+CVALARM=1,3400,4300
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
228
AT+CVALARM?
+CVALARM: 1,3400,4300
OK
AT+CVALARM=?
+CVALARM: (0,1),(3300-4000),(4000-4300)
OK
10.2 AT+CVAUXS Set state of the pin named VREG_AUX1
Description
This command is used to set state of the pin which is named VREG_AUX1.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CVAUXS=? +CVAUXS: (list of supported <state>s)
OK
Read Command Responses
AT+CVAUXS? +CVAUXS: <state>
OK
Write Command
Responses
AT+CVAUXS=<state> OK
ERROR
Defined values
<state>
0 – the pin is closed.
1 – the pin is opend(namely, open the pin)
Examples
AT+CVAUXS=1
OK
AT+CVAUXS?
+CVAUXS: 1
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
229
10.3 AT+CVAUXV Set voltage value of the pin named VREG_AUX1
Description
This command is used to set the voltage value of the pin which is named VREG_AUX1.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CVAUXV=? +CVAUXV: (list of supported <voltage>s)
OK
Read Command Responses
AT+CVAUXV? +CVAUXV: <voltage>
OK
Write Command
Responses
AT+CVAUXV=<voltage> OK
ERROR
Defined values
<voltage>
Voltage value of the pin which is named VREG_AUX1. The unit is in mV. And the value must the
multiple of 50mv.
Examples
AT+CVAUXV=?
+CVAUXV: (1700-3050)
OK
AT+CVAUXV=2800
OK
AT+CVAUXV?
+CVAUXV: 2800
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
230
10.4 AT+CADC Read ADC value
Description
This command is used to read the ADC value from modem. ME supports 2 types of ADC, which
are raw type and voltage type.
SIM PIN References
NO
Vendor
Syntax
Test Command Responses
AT+CADC=? +CADC: (range of supported <adc>s)
OK
Write Command Responses
AT+CADC=<adc> +CADC: <value>
OK
ERROR
Defined values
<adc>
ADC type:
0 – raw type.
2 – voltage type(mv)
<value>
Integer type value of the ADC.
Examples
AT+CADC=?
+CADC: (0,2)
OK
AT+CADC=0
+CADC: 187
OK
10.5 AT+CADC2 Read ADC2 value
Description
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
231
This command is used to read the ADC2 value from modem. ME supports 2 types of ADC, which
are raw type and voltage type.
SIM PIN References
NO Vendor
Syntax
Test Command
Responses
AT+CADC2=? +CADC2: (range of supported <adc>s)
OK
Write Command
Responses
AT+CADC2=<adc> +CADC2: <value>
OK
ERROR
Defined values
<adc>
ADC2 type:
0 – raw type.
2 – voltage type(mv)
<value>
Integer type value of the ADC2.
Examples
AT+CADC2=?
+CADC2: (0,2)
OK
AT+CADC2=0
+CADC2: 187
OK
10.6 AT+CMTE Control the module whether power shutdown when
the module’s temperature upon the critical temperature
Description
This command is used to control the module whether power shutdown when the module’s
temperature upon the critical temperature
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
232
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CMTE=? +CMTE: (list of supported<on/off>s)
OK
Read Command
Responses
AT+CMTE? +CMTE: <on/off >
OK
Write Command Responses
AT+CMTE=<on/off >
OK
ERROR
Defined values
<on/off>
0 – Disable temperature detection
1 – Enable temperature detection
Examples
AT+CMTE?
+CMTE: 1
OK
AT+CMTE=1
OK
AT+CMTE=?
+CMTE: 1
OK
NOTE:
- When temperature is extreme high or low, product will power off.
- URCs indicating the alert level “+CMTE:-1” or “+CMTE:1” are intended to enable the user
to take appropriate
precaution, such as protect the module from exposure to extreme conditions, or save or back
up data etc.
- Level “+CMTE:-2”or “+CMTE:2” URCs are followed by immediate shutdown.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
233
10.7 AT+CPMVT Low and high voltage Power Off
Description
This command is used to open or close the low and high voltage power off function.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CPMVT=? +CPMVT: (list of supported <enable>s), (list of supported < low
voltage>s), (list of supported < high voltage>s)
OK
Read Command Responses
AT+CPMVT? +CPMVT: <enable>,<low voltage>, <high voltage>
OK
Write Command Responses
AT+CPMVT=<enable>[,<low
voltage>],[<high voltage>]
OK
ERROR
Defined values
<enable>
0 – Close
1 – Open. If voltage < < low voltage>, it will report “UNDER-
VOLTAGE WARNNING
POWER DOWN” and power off the module. If voltage > <high voltage>, it will report
“OVER-VOLTAGE WARNNING POWER DOWN” and power off the module
<low voltage>
Between 3200mV and 4000mV. Default value is 3200.
<high voltage>
Between 4000mV and 4300mV. Default value is 4300.
NOTE
：
The three parameters will be saved automatically.
Examples
AT+CPMVT=1,3400,4300
OK
AT+CPMVT?
+CPMVT: 1,3400,4300
OK
AT+CPMVT=?
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
234
+CPMVT: (0-1),(3200-4000),(4000-4300)
OK
10.8 AT+CDELTA Set the module go to recovery mode
Description
This command is used to set the module go to recovery mode.
SIM PIN References
NO
Vendor
Syntax
Write Command Responses
AT+CDELTA OK
ERROR
Defined values
NOTE
：the command will write flag to the module and reboot the module, then the module will
reboot and read the flag and enter recovery mode to update the firmware.
Examples
AT+CDELTA
OK
10.9 AT+CRIIC Read values from register of IIC device
Description
This command is used to read values from register of IIC device.
SIM PIN References
NO
Vendor
Syntax
Test Command Responses
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
235
AT+CRIIC=? OK
Write Command Responses
AT+CRIIC=
<addr>,<reg>,<len>
+CRIIC: <data>
OK
ERROR
Defined values
<addr>
Device address. Input format must be hex, such as 0xFF.
<reg>
Register address. Input format must be hex, such as 0xFF.
<len>
Read length. Range:1-4; unit:byte.
<data>
Data read. Input format must be hex, such as 0xFF.
Examples
AT+CRIIC=0x34, 0x02, 2
+CRIIC: 0x01,0x5d
OK
10.10 AT+CWIIC Write values to register of IIC device
Description
This command is used to write values to register of IIC device.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CWIIC=? OK
Write Command
Responses
AT+CWIIC=
<addr>,<reg>,<data>,<len>
OK
ERROR
Defined values
<addr>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
236
Device address. Input format must be hex, such as 0xFF.
<reg>
Register address. Input format must be hex, such as 0xFF.
<len>
Read length. Range: 1-4; unit: byte.
<data>
Data written. Input format must be hex, such as 0xFF – 0xFFFFFFFF.
Examples
AT+CWIIC=0x34, 0x03, 0x5d, 1
OK
10.11 AT+CBC Read the voltage value of the power supply
Description
This command is used to read the voltage value of the power supply
SIM PIN References
NO
Vendor
Syntax
Read Command Responses
AT+CBC +CBC: <vol>
OK
ERROR
Defined values
<vol>
The voltage value, such as 3.8.
Examples
AT+CBC
+CBC: 3.591V
OK
10.12 AT+CPMUTEMP Read the temperature of the module
Description
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
237
This command is used to read the temperature of the module
SIM PIN References
NO Vendor
Syntax
Read Command Responses
AT+CPMUTEMP +CPMUTEMP: <temp>
OK
ERROR
Defined values
<temp>
The Temperature value, such as 29.
Examples
AT+CPMUTEMP
+CPMUTEMP: 29
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
238
11 AT Commands for SIM Application Toolkit
11.1 AT+STIN SAT Indication
Description
Every time the SIM Application issues a Proactive Command, via the ME, the TA will receive an
indication. This indicates the type of Proactive Command issued.
AT+STGI must then be used by the TA to request the parameters of the Proactive Command from
the ME. Upon receiving the +STGI response from the ME, the TA must send AT+STGR to confirm
the execution of the Proactive Command and provide any required user response, e.g. a selected
menu item.
SIM PIN References
YES Vendor
Syntax
Test Command
Responses
AT+STIN=? OK
Read Command
Responses
AT+STIN? +STIN: <cmd_id>
OK
Unsolicited Result Codes
+STIN: <cmd_id>
Proactive Command notification
21 – display text
22 – get inkey
23 – get input
24 – select item
+STIN: 25
Notification that SIM Application has returned to main menu. If user doesn’t do any action in 2
minutes, application will return to main menu automatically.
Defined values
<cmd_id>
21 – display text
22 – get inkey
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
239
23 – get input
24 – select item
25 – set up menu
81 – session end (pdu mode only)
0 – none command
Examples
AT+STIN?
+STIN: 24
OK
11.2 AT+STGI Get SAT information
Description
Regularly this command is used upon receipt of an URC "+STIN" to request the parameters of the
Proactive Command. Then the TA is expected to acknowledge the AT +STGI
response with
AT+STGR to confirm that the Proactive Command has been executed. AT+STGR will also provide
any user information, e.g. a selected menu item. The Proactive Command type value specifies to
which "+STIN" the command is related.
NOTE: Please check the format refered to AT+STKFMT
SIM PIN References
YES Vendor
Syntax
Test Command Responses
AT+STGI=? OK
Write Command Responses
AT+STGI=
<
cmd_id
>
PDU format
+STGI:
<
cmd_id
>,<
tag
>,<
pdu_len
>,<
pdu_value
>
OK
AT+STGI=
<
cmd_id
>
NOT PDU format, listed below:
If <cmd_id>=10:
OK
If <cmd_id>=21:
+STGI:21,<prio>,<clear_mode>,<text_len>,<text>
OK
If <cmd_id>=22:
+STGI: 22,< rsp_format>,< help>,<text_len>,<text>
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
240
If <cmd_id>=23:
+STGI:23,<rsp_format>,<max_len>,<min_len>,<help>,<show>,<t
ext_len>,<text>
OK
If <cmd_id>=24:
+STGI:24,<help>,<softkey>,<present>,<title_len>,<title>,<item_n
um>
+STGI:24,<item_id>,<item_len>,<item_data>
[…]
OK
If <cmd_id>=25:
+STGI:25,<help>,<softkey>,<title_len>,<title>,<item_num>
+STGI:25,<item_id>,<item_len>,<item_data>
[...]
OK
Defined values
<cmd_id>
21 – display text
22 – get inkey
23 – get input
24 – select item
25 – set up menu
<prio>
Priority of display text
0 – Normal priority
1 – High priority
<clear_mode>
0 – Clear after a delay
1 – Clear by user
<text_len>
Length of text
<rsp_format>
0 – SMS default alphabet
1 – YES or NO
2 – numerical only
3 – UCS2
<help>
0 – Help unavailable
1 – Help available
<max_len>
Maximum length of input
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
241
<min_len>
Minimum length of input
<show>
0 – Hide input text
1 – Display input text
<softkey>
0 – No softkey preferred
1 – Softkey preferred
<present>
Menu presentation format available for select item
0 – Presentation not specified
1 – Data value presentation
2 – Navigation presentation
<title_len>
Length of title
<item_num>
Number of items in the menu
<item_id>
Identifier of item
<item_len>
Length of item
<title>
Title in ucs2 format
<item_data>
Content of the item in ucs2 format
<text>
Text in ucs2 format.
<tag>
Not used now.
<pdu_len>
Integer type, pdu string length
<pdu_value>
String type, the pdu string.
Examples
AT+STGI=25 (NOT PDU format)
+STGI:25,0,0,10,"795E5DDE884C59295730",15
+STGI:25,1,8,"8F7B677E95EE5019"
+STGI:25,2,8,"77ED4FE17FA453D1"
+STGI:25,3,8,"4F1860E05FEB8BAF"
+STGI:25,4,8,"4E1A52A17CBE9009"
+STGI:25,5,8,"8D448D3963A88350"
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
242
+STGI:25,6,8,"81EA52A9670D52A1"
+STGI:25,7,8,"8F7B677E5F6994C3"
+STGI:25,8,8,"8BED97F367425FD7"
+STGI:25,9,10,"97F34E506392884C699C"
+STGI:25,10,8,"65B095FB59296C14"
+STGI:25,11,8,"94C358F056FE7247"
+STGI:25,12,8,"804A59294EA453CB"
+STGI:25,13,8,"5F005FC34F1195F2"
+STGI:25,14,8,"751F6D3B5E388BC6"
+STGI:25,21,12,"00530049004D53614FE1606F"
OK
AT+STGI=24 (PDU format)
+STGI:24,0,48,"D02E81030124008202818285098070ED70B963A883508F0A018053057F574E0
78C618F0C02809177917777ED6D88606F"
OK
11.3 AT+STGR SAT respond
Description
The TA is expected to acknowledge the AT+STGI response with AT+STGR to confirm that the
Proactive Command has been executed. AT+STGR will also provide any user information, e.g. a
selected menu item.
NOTE: Please check the format refered to AT+STKFMT
SIM PIN References
YES Vendor
Syntax
Test Command Responses
AT+STGR=? OK
Write Command Responses
AT+STGR=<cmd_id>[,<dat
a>]
NOT PDU format
OK
AT+STGR=<pdu_len>,<pdu
_value>
PDU format
OK
Defined values
<cmd_id>
22 – get inkey
23 – get input
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
243
24 – select item
25 – set up menu
81 – session end
83 – session end by user
84 – go backward
<data>
If <cmd_id>=22:
Input a character
If <cmd_id>=23:
Input a string.
If <rsp_format> is YES or NO, i
nput of a character in case of ANSI character set requests one
byte, e.g. “Y”.
If <rsp_format> is numerical only, input the characters in decimal number, e.g. “123”
If <rsp_faomat> is UCS2, requests a 4 byte string, e.g. “0031”
<rsp_faomat> refer to the response by AT+STGI=23
If <cmd_id>=24:
Input the identifier of the item selected by user
If <cmd_id>=25:
Input the identifier of the item selected by user
If <cmd_id>=83:
<data> ignore
Note: It could return main menu during Proactive Command id is not 22 or 23
If <cmd_id>= 84:
<data> ignore
<pdu_len>
Integer type, pdu string length
<pdu_value>
String type, the pdu string.
Examples
AT+STGR=25,1 (NOT PDU format)
OK
+STIN: 24
AT+STGR=30,"810301240002028281830100900101" (PDU format)
OK
11.4 AT+STK STK switch
Description
This command is used to disable or enable the STK function. If the argument is 1, it is enabled.
While if the argument is 0, it is disabled.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
244
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+STK=? +STK: (list of supported <value>s)
OK
Read Command Responses
AT+STK? +STK: <value>
OK
Write Command
Responses
AT+STK=<value> OK
ERROR
Execution Command
Responses
AT+STK Set default value (<value>=0):
OK
Defined values
<value>
0 – Disable STK
1 – Enable STK
Examples
AT+STK=1
OK
11.5 AT+STKFMT Set STK pdu format
Description
This command is used to disable or enable the STK pdu mode. If the argument is 1, it is enabled.
While if the argument is 0, it is disabled.
NOTE: Module should reboot to take effective.
SIM PIN References
YES Vendor
Syntax
Read Command
Responses
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
245
AT+STKFMT? +STKFMT: <value>
OK
Write Command Responses
AT+STKFMT=<value> OK
ERROR
Defined values
<value>
0 – Disable STK pdu format, decoded command mode.
1 – Enable STK pdu format
NOTE: 7100 default value 0, 7500/7600 default value 1.
Examples
AT+STKFMT=1
OK
11.6 AT+STENV Original STK PDU Envelope Command
Description
This command is used to original stk pdu envelope command.
NOTE: PDU format supported only.
SIM PIN References
YES Vendor
Syntax
Test Command Responses
AT+STENV=?
OK
Write Command
Responses
AT+STENV=<len>,<pdu>
OK
ERROR
Defined values
<len>
Integer type, pdu string length
<pdu>
String type, pdu value
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
246
Examples
AT+STENV=18,"D30782020181900101"
OK
11.7 AT+STSM Get STK Setup Menu List with PDU Mode
Description
This command is used to get the stk setup menu list with pdu mode
NOTE: PDU format supported only.
SIM PIN References
YES Vendor
Syntax
Test Command Responses
AT+STSM=?
OK
Read Command Responses
AT+STSM? +STSM: <cmd_id>,<tag>,<pdu_len>, <pdu_value>
OK
ERROR
Defined values
<cmd_id>
Integer type, please refer to AT+STIN
<tag>
Not used now.
<pdu_len>
Integer type, pdu string length
<pdu_value>
String type, the pdu string.
Examples
AT+STSM?
+STSM:25,0,120,"D07681030125008202818285078065B052BF529B8F0A018070ED70B963A883
508F06028070AB94C38F0A03806D41884C77ED4FE18F0A048081EA52A9670D52A18F0A0580
624B673A97F34E508F0606808D854FE18F0A07805A314E50753162118F0A0880767E53D8751F
6D3B8F0A09806D596C5F98919053"
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
247
12 AT Commands for Hardware
12.1 AT+IPREX Set local baud rate permanently
Description
This command sets the baud rate of module’
s serial interface permanently, after reboot the baud rate
is also valid, if set to 0, then support autobaud, and the value of the IPR will be changed to current
baudrate when the autobaud is successful.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+IPREX=? +IPREX: (list of supported<speed>s)
OK
Read Command Responses
AT+IPREX? +IPREX: <speed>
OK
Write Command Responses
AT+IPREX=<speed> OK
ERROR
Execution Command Responses
AT+IPREX Set default value 115200:
OK
Defined values
<speed>
Baud rate per second:
0, 300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200, 230400, 460800, 921600,
3000000, 3200000, 3686400
Examples
AT+IPREX?
+IPREX: 115200
OK
AT+IPREX=?
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
248
+IPREX: (0,300,600,1200,2400,4800,9600,19200,38400,57600,115200,230400,460800,921600,
3000000,3200000,3686400)
OK
AT+IPREX=115200
OK
AT+IPREX=0
OK
12.2 AT+CFGRI Indicate RI when using URC
Description
This command is used to configure whether pulling down <URC time>milliseconds the RI pin of
UART when URC reported. If <status> is 1, host may be wake up by RI pin, add setting <URC
time>, <SMS time>pulling down time of RI pin.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CFGRI=? +CFGRI: (range of supported <status>s), (range of supported
<URC time>s), (range of supported <SMS time>s)
OK
Read Command Responses
AT+CFGRI? +CFGRI: <status>,<URC time>,<SMS time>
OK
Write Command Responses
AT+CFGRI=<status>,<URC
time>,<SMS time>
OK
ERROR
Execution Command Responses
AT+CFGRI Set <status> = 0
Set <URC time> = 60
Set <SMS time> = 120
OK
Defined values
<status>
0 off
1 on
<URC time>
a numeric parameter which is number of milliseconds to assert RI delay to reset RI. The range is
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
249
10 to 6000.
<SMS time>
a numeric parameter which is number of milliseconds to assert RI delay to reset RI. The range is
10 to 6000.
Examples
AT+CFGRI=?
+CFGRI: (0-1),(10-6000),(20-6000)
OK
AT+CFGRI?
+CFGRI: 0,60,120
OK
AT+CFGRI=1
OK
AT+CFGRI
OK
12.3 AT+CSCLK Control UART Sleep
Description
This command is used to enable UART Sleep or always work,
if set to 1, UART can sleep when DTR pull high
if set to 0, UART always work
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CSCLK=? +CSCLK: (range of supported <status>s)
OK
Read Command Responses
AT+CSCLK? +CSCLK: <status>
OK
Write Command
Responses
AT+CSCLK=<status> OK
ERROR
Execution Command Responses
AT+CSCLK
Set <status> = 0
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
250
OK
Defined values
<status>
0 off
1 on
Examples
AT+CSCLK=?
+
CSCLK
: (0-1)
OK
AT+CSCLK?
+CSCLK: 0
OK
AT+
CSCLK
=1
OK
AT+CSCLK
OK
12.4 AT+CMUX Enable the multiplexer over the UART
Description
This command is used to enable the multiplexer over the UART, after enabled four virtual ports can
be used as AT command port or MODEM port, the physical UART can no longer transfer data
directly under this case.
By default all of the four virtual ports are used as AT command port.
Second serial port is not support this command.
SIM PIN References
NO
Vendor
Syntax
Test Command Responses
AT+CMUX=? +CMUX: (0),(0),(1-8),(1-1500),(0),(0),(2-1000)
OK
Read Command
Responses
AT+CMUX? +CMUX:<value>,<subset>,<port_speed>,<N1>,<T1>,<N2>,<T2>
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
251
Write Command
Responses
AT+CMUX=
<value>[,<subset>[,<port
_speed>[,<N1>[,<T1>[,
<
N2
>[,<
T2
>]]]]]]
OK
ERROR
Defined values
< value >:
0 – currently only 0 is supported (basic operation mode).
< subset >:
Currently omitted
< port_speed >:
Currently omitted, you can set speed before enable multiplexer
< N1>:
1-1500
< T1>:
Currently omitted
< N2>:
Currently omitted
< T2>:
2-1000
Examples
AT+CMUX=?
+CMUX: (0),(0),(1-8),(1-1500),(0),(0),(2-1000)
OK
AT+CMUX?
+CMUX: 0,0,5,1500,0,0,600
OK
AT+CMUX=0
OK
NOTE: Currently only basic operation mode is supported.
12.5 AT+CGFUNC Enable/disable the function for the special GPIO
Description
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
252
SIM7500/SIM7600 supplies many GPIOs, all of which can be used as General Purpose
Input/Output pin, interrupt pin and some of them can be used as function pin.
This command is used to enable/disable the function for the special GPIO. Please consult the
document “SIM7500_SIM7600 Series_GPIO_Application_Note” for more details.
The configuration will be saved automatically.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CGFUNC=? +CGFUNC: (list of supported <GPIO>s),(
list of supported
<function>s)
OK
Read Command Responses
AT+CGFUNC=<gpio> +CGFUNC: <gpio>,<function>
OK
ERROR
Write Command Responses
AT+CGFUNC=<gpio>,
<function>
OK
ERROR
Defined values
<GPIO>
7500C/CE GPIO:
40: GPIO40/STATUS
44: GPIO44/SD_DETECT
7500A GPIO:
40: GPIO40/STATUS
<FUNC>
0 : gpio function.
1 : function1
Examples
AT+CGFUNC=40,1
OK
AT+CGFUNC=40
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
253
+CGFUNC: 40,1
OK
12.6 AT+CGDRT Set the direction of specified GPIO
Description
This command is used to set the specified GPIO to input or output state. If setting to input state,
then this GPIO can not be set to high or low value.
SIM PIN References
NO Vendor
Syntax
Test Command
Responses
AT+CGDRT=? +CGDRT: (list of supported <GPIO>s),(list of supported <
gpio_io >s)
OK
Write Command Responses
AT+CGDRT=<GPIO>,
<gpio_io>
OK
ERROR
Read Command Responses
AT+CGDRT=<GPIO> +CGDRT: <GPIO>,<gpio_io>
OK
ERROR
Defined values
<GPIO>
The value is GPIO ID, different hardware versions have different values.
<gpio_io>
0 – in
1 – out
Examples
AT+CGDRT=43,0
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
254
12.7 AT+CGSETV Set the value of specified GPIO
Description
This command is used to set the value of the specified GPIO to high or low.
SIM PIN References
NO Vendor
Syntax
Test Command
Responses
AT+CGSETV=? +CGSETV: (list of supported <GPIO>s),(list of supported <
gpio_hl >s)
OK
Write Command
Responses
AT+CGSETV=<GPIO>,<gp
io_hl>
OK
ERROR
Defined values
<GPIO>
The value is GPIO ID, different hardware versions have different values.
<gpio_hl>
0 – low
1 – high
Examples
AT+CGSETV=43,0
OK
12.8 AT+CGGETV Get the value of specified GPIO
Description
This command is used to get the value (high or low) of the specified GPIO.
SIM PIN References
NO Vendor
Syntax
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
255
Test Command
Responses
AT+CGGETV=? +CGGETV: (list of supported <GPIO>s)
OK
Write Command
Responses
AT+CGGETV=<GPIO> +CGGETV: <GPIO>,<gpio_hl>
OK
ERROR
Defined values
<GPIO>
The value is GPIO ID, different hardware versions have different values.
<gpio_hl>
0 – low
1 – high
NOTE: The GPIO must be set to GP
IO FUNCTION through AT+CGFUNC, then it will set
success.
Examples
AT+CGGETV=43
+CGGETV: 43,0
OK
12.9 AT+CGISR Set GPIO interrupt trigger condition
Description
The module supplies many GPIOs, all of which can be used as General Purpose Input/Oupt pin,
interrupt pin and some of them can be used as function pin.
This command is used to set one GPIO pin as an interrupt source, and then set the detect
type[optional] and polarity type[optional], and enable interrupt. Please consult the document
“SIM7500_SIM7600 Series_GPIO_Application_Note” for more details.
SIM PIN References
No
Syntax
Test Command
Responses
AT+CGISR=? +CGISR: (list of supported <GPIO>s), <detect>,<polarity>,<
URC
char [size(49)]>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
256
OK
Read Command Responses
AT+CGISR=<GPIO> opened:
+CGISR: < GPIO >,<detect>,<polarity>,<URC>
not opened:
+CGISR: < GPIO >,< detect >
OK
Write Command Responses
AT+CGISR=<GPIO >,<dete
ct>,<polarity>,[<URC>]
OK
Defined values
< GPIO >
The value is GPIO ID, different hardware versions have different values.
< detect >
0 – no detect.
1 – level detection
2 – edge detection
< polarity >
0 – low level/edge detection
1 – high level/edge detection
<URC >
Your ISR string
Examples
AT+CGISR=41
+CGISR : 41,1,1,GPIO_41_ISR! If the pin ISR is opened
OK
+CGISR : 41,0 If the pin ISR is not opened
OK
AT+CGISR=41,0,1
OK
NOTE:
1. if the interruption is triggered SIM7500/SIM7600 will send the following URC to host, URC is your
ISR string or GPIO_< GPIO >_ISR
2. Default <detect> is 0 and default <polarity> is 1.
3. After setting one GPIO pin as an interrupt source successfully, the setting will be saved.
4. If the gpio use to interruption,before the gpio mustbe config on GPIO function
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
257
13 AT Commands for File System
The file system is used to store files in a hierarchical (tree) structure, and there are some definitions and
conventions to use the Module.
Local storage space is mapped to “C:”, “D:” for TF card, “E:” for multimedia.
NOTE: General rules for naming (both directories and files):
1 The length of actual fully qualified names of directories and files can not exceed 254.
2 Directory and file names can not include the following characters:
\ : * ? “ < > | , ;
3 Between directory name and file/directory name, use character “/” as list separator, so it can not
appear in directory name or file name.
4 The first character of names must be a letter or a numeral or underline, and the last character can
not be period “.” and oblique “/”.
13.1 AT+FSCD Select directory as current directory
Description
This command is used to select a directory. The Module supports absolute path and relative path.
Read Command will return current directory without double quotation marks. Support “C:”, “D:”,
“E:”.
SIM PIN References
NO Vendor
Syntax
Test Command
Responses
AT+FSCD=? OK
Read Command Responses
AT+FSCD? +FSCD: <curr_path>
OK
Write Command
Responses
AT+FSCD=<path> +FSCD: <curr_path>
OK
ERROR
Defined values
<path>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
258
String without double quotes, directory for selection.
NOTE: If <path> is “..”, it will go back to previous level of directory.
<curr_path>
String without double quotes, current directory.
Examples
AT+FSCD=C:
+FSCD: C:/
OK
AT+FSCD=C:/
+FSCD: C:/
OK
AT+FSCD?
+FSCD: C:/
OK
AT+FSCD=..
+FSCD: C:/
OK
AT+FSCD=D:
+FSCD: D:/
OK
AT+FSCD?
+FSCD:D:/
OK
13.2 AT+FSMKDIR Make new directory in current directory
Description
This command is used to create a new directory in current directory. Support “C:”, “D:”, “E:”.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+FSMKDIR=? OK
Write Command Responses
AT+FSMKDIR=<dir> OK
ERROR
Defined values
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
259
<dir>
String without double quotes, directory name which does not already exist in current directory.
Examples
AT+FSMKDIR= SIMTech
OK
AT+FSCD?
+FSCD: C:/
OK
AT+FSLS
+FSLS: SUBDIRECTORIES:
SIMTech
OK
13.3 AT+FSRMDIR Delete directory in current directory
Description
This command is used to delete existing directory in current directory. Support “C:”, “D:”, “E:”.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+FSRMDIR=? OK
Write Command Responses
AT+FSRMDIR=<dir> OK
ERROR
Defined values
<dir>
String without double quotes.
Examples
AT+FSRMDIR=SIMTech
OK
AT+FSCD?
+FSCD: C:/
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
260
OK
AT+FSLS
+FSLS: SUBDIRECTORIES:
Audio
Video
VideoCall
OK
13.4 AT+FSLS List directories/files in current directory
Description
This command is used to list informations of directories and/or files in current directory. Support
“C:”, “D:”, “E:”.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+FSLS=? +FSLS: (list of supported <type>s)
OK
Read Command Responses
AT+FSLS? +FSLS: SUBDIRECTORIES:<dir_num>,FILES:<file_num>
OK
Write Command
Responses
AT+FSLS=<type> [+FSLS: SUBDIRECTORIES:
<list of subdirectories>
<CR><LF>]
[+FSLS: FILES:
<list of files>
<CR><LF>]
OK
Execution Command Responses
AT+FSLS [+FSLS: SUBDIRECTORIES:
<list of subdirectories>
<CR><LF>]
[+FSLS: FILES:
<list of files>
<CR><LF>]
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
261
Defined values
<dir_num>
Integer type, the number of subdirectories in current directory.
<file_num>
Integer type, the number of files in current directory.
<type>
0 – list both subdirectories and files
1 – list subdirectories only
2 – list files only
Examples
AT+FSLS?
+FSLS: SUBDIRECTORIES:2,FILES:2
OK
AT+FSLS
+FSLS: SUBDIRECTORIES:
FirstDir
SecondDir
+FSLS: FILES:
OK
AT+FSLS=2
+FSLS: FILES:
OK
13.5 AT+FSDEL Delete file in current directory
Description
This command is used to delete a file in current directory. Before do that, it needs to use AT+FSCD
select the father directory as current directory. Support “C:”, “D:”, “E:”.
SIM PIN References
NO Vendor
Syntax
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
262
Test Command
Responses
AT+FSDEL=?
OK
Write Command Responses
AT+FSDEL=<filename> OK
ERROR
Defined values
<filename>
String with or without double quotes, file name which is relative and already existing.
If <filename> is *.*, it means delete all files in current directory.
If the file path contains non-
ASCII characters, the filename parameter should contain a prefix of
{non-ascii} and the quotation mark.
Examples
OK
13.6 AT+FSRENAME Rename file in current directory
Description
This command is used to rename a file in current directory. Support “
C:
”, “
D:
”, “
E:
”.
SIM PIN References
NO Vendor
Syntax
Test Command
Responses
AT+FSRENAME=? OK
Write Command Responses
AT+FSRENAME=
<old_name>,<new_name>
OK
ERROR
Defined values
<old_name>
String with or without double quotes, file name which is existed in current directory. If the file path
contains non-ASCII characters, the file path parameter should contain a prefix of {non-ascii} and
the quotation mark.
<new_name>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
263
New name of specified file, string with or without double quotes.
If the file path contains
non-ASCII characters, the file path parameter should contain a prefix of {non-
ascii} and the
quotation mark.
Examples
AT+FSRENAME=image_0.jpg, image_1.jpg
OK
AT+FSRENAME= "my test.jpg", {non-ascii}"E6B58BE8AF95E99984E4BBB62E6A7067"
OK
13.7 AT+FSATTRI Request file attributes
Description
This command is used to request the attributes of file which exists in current directory. Support
“C:”, “D:”, “E:”.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+FSATTRI=?
OK
Write Command Responses
AT+FSATTRI=<filename> +FSATTRI: <file_size>, <create_date>
OK
Defined values
<filename>
String with or without double quotes, file name which is in current directory.
If the file path
contains non-ASCII characters, the file path parameter should contain a prefix of {non-ascii} and
the quotation mark.
<file_size>
The size of specified file, and the unit is in Byte.
<create_date>
Create date and time of specified file, the format is YYYY/MM/DD HH/MM/SS Week.
Week – Mon, Tue, Wed, Thu, Fri, Sat, Sun
Examples
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
264
+FSATTRI: 8604, 2008/04/28 10:24:46 Tue
OK
AT+FSATTRI={non-ascii}"E6B58BE8AF95E99984E4BBB62E6A7067"
+FSATTRI: 6296, 2012/01/06 00:00:00 Sun
OK
13.8 AT+FSMEM Check the size of available memory
Description
This command is used to check the size of available memory. The response will list total size and
used size of local storage space if present and mounted. Support “C:”, “D:”, “E:”.
SIM PIN References
NO
Vendor
Syntax
Test Command Responses
AT+FSMEM=? OK
Execution Command Responses
AT+FSMEM
+FSMEM: C:(<total>, <used>)
OK
Defined values
<total>
The total size of local storage space.
<used>
The used size of local storage space.
NOTE:
The unit of storage space size is in Byte.
Examples
AT+FSMEM
+FSMEM: C:(11348480, 2201600)
OK
13.9 AT+FSLOCA Select storage place
Description
This command is used to set the storage place for media files. Support “C:”.
SIM PIN References
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
265
NO Vendor
Syntax
Test Command
Responses
AT+FSLOCA=? +FSLOCA: (list of supported <loca>s)
OK
Read Command
Responses
AT+FSLOCA? +FSLOCA: <loca>
OK
Write Command Responses
AT+FSLOCA=<loca> OK
ERROR
Defined values
<loca>
0 – store media files to local storage space (namely “C:/”)
Examples
AT+FSLOCA=0
OK
AT+FSLOCA?
+FSLOCA: 0
OK
13.10 AT+FSCOPY Copy an appointed file
Description
This command is used to copy an appointed file on C:/ to an appointed directory on C:/, the new file
name should give in parameter. Support “C:”, “D:”, “E:”.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+FSCOPY=? OK
Write Command Responses
AT+FSCOPY=<file1>,<file +FSCOPY: <percent>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
266
2>[<sync_mode>] [+FSCOPY: <percent>]
OK
OK
+FSCOPY: <percent>
[+FSCOPY: <percent>]
+FSCOPY: END
If found any error:
SD CARD NOT PLUGGED IN
FILE IS EXISTING
FILE NOT EXISTING
DIRECTORY IS EXISTED
DIRECTORY NOT EXISTED
FORBID CREATE DIRECTORY UNDER \"C:/\"
FORBID DELETE DIRECTORY
INVALID PATH NAME
INVALID FILE NAME
SD CARD HAVE NO ENOUGH MEMORY
EFS HAVE NO ENOUGH MEMORY
FILE CREATE ERROR
READ FILE ERROR
WRITE FILE ERROR
ERROR
Defined values
<file1>
The sources file name or the whole path name with sources file
name. If the file path contains
non-ASCII characters, the file path parameter should contain a prefix of {non-
ascii} and the
quotation mark.
<file2>
The destination file name or the whole path name with destination file name. If the file path
contains non-ASCII characters, the file path parameter should contain a prefix of {non-ascii} and
the quotation mark.
<percent>
The percent of copy done. The range is 0.0 to 100.0
<sync_mode>
The execution mode of the command:
0 – synchronous mode
1 – asynchronous mode
NOTE:
1. The <file1> and <file2> should give the whole path and name, if only given file name, it will
refer to current path (AT+FSCD) and check the file’s validity.
2. If <file2> is a whole path and name, make sure the directory exists, make sure that the file
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
267
name does not exist or the file name is not the same name as the sub folder name, otherwise return
error.
3. <percent> report refer to the copy file size. The big file maybe report many times, and little
file report less.
4. If <sync_mode>
is 1, the command will return OK immediately, and report final result with
+FSCOPY: END.
Examples
AT+FSCD?
+FSCD: C:/
OK
AT+FSCOPY= C:/TESTFILE,COPYFILE (Copy file TESTFILE on C:/ to C:/COPYFILE)
+FSCOPY: 1.0
+FSCOPY: 9.7
+FSCOPY: 19.4
…
+FSCOPY: 100.0
OK
AT+FSCOPY= "my test.jpg", {non-ascii}"E6B58BE8AF95E99984E4BBB62E6A7067"
+FSCOPY:1.0
+FSCOPY:100.0
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
268
14 AT Commands for File Transmission
14.1 AT+CFTRANRX Transfer a file to EFS
Description
This command is used to transfer a file to EFS.Support SDcard.
SIM PIN References
NO Vendor
Syntax
Test Command
Responses
AT+CFTRANRX=? +CFTRANRX: [{non-ascii}]"FILEPATH"
OK
Write Command Responses
AT+CFTRANRX=“<filepat
h>”,<len>
>
OK
>
ERROR
ERROR
Defined values
<filepath>
The path of the file on EFS.
<len>
The length of the file data to send.
NOTE
The <filepath> must be a full path with the directory path.
Examples
AT+CFTRANRX=”c:/MyDir/t1.txt”,10
>testcontent
OK
AT+CFTRANRX=”d:/MyDir/t1.txt”,10
>testcontent
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
269
14.2 AT+CFTRANTX Transfer a file from EFS to host
Description
This command is used to transfer a file from EFS to host. Before using this command, the
AT+C AT R must be used to set the correct port used. Support SDcard.
SIM PIN References
NO
Vendor
Syntax
Test Command Responses
AT+CFTRANTX=? +CFTRANTX: [{non-ascii}]"FILEPATH"
OK
Write Command Responses
AT+CFTRANTX=“<filepath
>”[,<location>,<size>]
[+CFTRANTX: DATA,<len>
…
+CFTRANTX: DATA,<len>]
+CFTRANTX: 0
OK
ERROR
Defined values
<filepath>
The path of the file on EFS.
<len>
The length of the following file data to output.
<location>
The beginning of the file data to output.
<size>
The length of the file data to output.
NOTE
The <filepath> must be a full path with the directory path.
Examples
AT+CFTRANTX=”c:/MyDir/t1.txt”
+CFTRANTX: DATA, 11
Testcontent
+CFTRANTX: 0
OK
AT+CFTRANTX=”d:/MyDir/t1.txt”
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
270
+CFTRANTX: DATA, 11
Testcontent
+CFTRANTX: 0
OK
AT+CFTRANTX=”d:/MyDir/t1.txt”,1,4
+CFTRANTX: DATA, 4
estc
+CFTRANTX: 0
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
271
15 AT Commands for Internet Service
15.1 PDP
15.1.1 AT+CSOCKSETPN Set active PDP context’s profile number
Description
This command sets default active PDP context’s profile number. W
hen we activate PDP by using
AT+NETOPEN command, we need use the default profile number, and the context of this profile is
set by AT+CGDCONT command.
SIM PIN References
YES Vendor
Syntax
Test Command
Responses
AT+CSOCKSETPN=? +CSOCKSETPN: (list of supported <profile_number>s)
OK
ERROR
Read Command Responses
AT+CSOCKSETPN? +CSOCKSETPN: <profile_number>
OK
ERROR
Write Command Responses
AT+CSOCKSETPN=<profil
e_number>
OK
ERROR
Execution Command Responses
AT+CSOCKSETPN OK
ERROR
Defined values
<profile_number>
A numeric parameter that identifies default profile number, the range of permitted values is one to
sixteen.
1…24,100…179
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
272
Examples
AT+CSOCKSETPN=1
OK
15.1.2 AT+CIPDNSSET Set DNS query parameters
Description
This command is used to set DNS query parameters. The timeout value for performing DNS query
is <net_open_time> + 3000ms + 1000ms*<dns_query_retry_coun
ter>. Here <net_open_time> is
the time for opening PS network. <dns_query_retry_counter> is the retry counter for sending DNS
query using UDP packet.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CIPDNSSET=?
OK
Read Command
Responses
AT+CIPDNSSET? +CIPDNSSET:
<max_net_retries>,<net_timeout>,<max_query_retries>
OK
Write Command Responses
AT+CIPDNSSET=[<ma
x_net_retries>][,
[<net_timeout>][,
[<max_query_retries>]]]
OK
ERROR
Defined values
<max_net_retries>
Maxmimum retry times for opening PS network to perform DNS query. The range is from 0 to 3.
Default value is 3.
<net_timeout>
Timeout value for each opening PS network operation when performing DNS query. The range is
from 3000ms to 120000ms. Default value is 30000ms.
<max_query_retries>
Maximum retry times for performing DNS query using UDP packet. The range is from 0 to 7.
Default value is 7.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
273
Examples
AT+CIPDNSSET?
+CIPDNSSET: 1,30000,3
OK
AT+CIPDNSSET=1,30000,1
OK
15.1.3 AT+CDNSGIP Query the IP address of given domain name
Description
This command is used to query the IP address of given domain name.
SIM PIN References
YES Vendor
Syntax
Test Command Responses
AT+CDNSGIP=? OK
ERROR
Write Command Responses
AT+CDNSGIP=<domain
name>
If successful,return:
+CDNSGIP: 1,<domain name>,<IP address>
OK
If fail,return:
+CDNSGIP: 0,<dns error code>
ERROR
ERROR
Defined values
<domain name>
A string parameter (string should be included in quotation marks) which indicates the do
ma-in name.
<IP address>
A string parameter (string should be included in quotation marks) which indicates the IP
address corresponding to the domain name.
<dns error code>
A numeric parameter which indicates the error code.
10 DNS GENERAL ERROR
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
274
Examples
AT+CDNSGIP=?
OK
AT+CDNSGIP=”www.google.com”
+CDNSGIP: 1,"www.google.com","203.208.39.99"
OK
15.1.4 AT+CDNSGHNAME Query the domain name of given IP
address
Description
This command is used to query the domain name of given IP address.
SIM PIN References
YES Vendor
Syntax
Test Command Responses
AT+CDNSGHNAME=? OK
ERROR
Write Command Responses
AT+CDNSGHNAME=<IP
address>
If successful,return:
+CDNSGHNAME: <index>,<domain name>,<IP address>
OK
If fail,return:
+CDNSGHNAME: 0,<dns error code>
ERROR
ERROR
Defined values
<domain name>
A string parameter (string should be included in quotation marks) which indicates the do
ma-in name.
<IP address>
A string parameter (string should be included in quotation marks) which indicates the IP
address corresponding to the domain name.
<dns error code>
A numeric parameter which indicates the error code.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
275
10 DNS GENERAL ERROR
<index>
A numeric parameter which indicates DNS result index. This value is always 1 if performing
successfully. Currently only the first record returned from the DNS server will be reported.
Examples
AT+CDNSGHNAME=?
OK
AT+CDNSGHNAME=” 58.32.231.148”
+CDNSGHNAME: 1,"mail.sim.com","58.32.231.148"
OK
15.1.5 AT+CPING Ping destination address
Description
This command is used to ping destination address.
SIM PIN References
YES Vendor
Syntax
Test Command Responses
AT+CPING=? +CPING: IP address,
(list of supported
<dest_addr_type>s),(1-100),(4-188),(1000-10000),(10000-10
0000), (16-255)
OK
ERROR
Write Command Responses
AT+CPING=<dest_addr>,<dest_ad
dr_type>
[,<num_pings>[,<data_packet_size
>[,<interval_time>[,<wait_time>
[,<TTL>]]]]]
OK
If ping’s result_type = 1
+CPING:
<result_type>,<resolved_ip_addr>,<data_packet_size>,<rtt>,
<TTL>
If ping’s result_type = 2
+CPING: <result_type>
If ping’s result_type = 3
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
276
+CPING:
<result_type>,<num_pkts_sent>,<num_pkts_recvd>,<num_p
kts_lost>,<min_rtt>,<max_rtt>,<avg_rtt>
ERROR
Defined values
<dest_addr>
The destination is to be pinged; it can be an IP address or a domain name.
<dest_addr_type>
Integer type. Address family type of the destination address
1 – IPv4.
2 – IPv6(reserved)
<num_pings>
Integer type. The num_pings specifies the number of times the ping request (1-100) is to be sent.
The default value is 4.
<data_packet_size>
Integer type. Data byte size of the ping packet (4-188). The default value is 64 bytes.
<interval_time>
Integer type. Interval between each ping. Value is specified in milliseconds (1000ms-10000ms). The
default value is 2000ms.
<wait_time>
Integer type. Wait time for ping respo
nse. An ping response received after the timeout shall not be
processed. Value specified in milliseconds (10000ms-100000ms). The default value is 10000ms.
<TTL>
Integer type. TTL(Time-To-
Live) value for the IP packet over which the ping(ICMP ECHO
Request message) is sent (16-255), the default value is 255.
<result_type>
1 – Ping success
2 – Ping time out
3 – Ping result
<num_pkts_sent>
Indicates the number of ping requests that were sent out.
<num_pkts_recvd>
Indicates the number of ping responses that were received.
<num_pkts_lost>
Indicates the number of ping requests for which no response was received.
<min_rtt>
Indicates the minimum Round Trip Time(RTT).
<max_rtt>
Indicates the maximum RTT.
<avg_rtt>
Indicates the average RTT.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
277
<resolved_ip_addr>
Indicates the resolved ip address.
< rtt>
Round Trip Time.
Examples
AT+CPING=?
+CPING:IP address,(1,2), (1-100), (4-188),(1000-10000),(10000-100000), (16-255)
OK
AT+CPING="www.baidu.com",1,4,64,1000,10000,255
OK
+CPING: 1,119.75.217.56,64,410,255
+CPING: 1,119.75.217.56,64,347,255
+CPING: 1,119.75.217.56,64,346,255
+CPING: 1,119.75.217.56,64,444,255
+CPING: 3,4,4,0,346,444,386
15.1.6 AT+CPINGSTOP Stop an ongoing ping session
Description
This command is used to stop an ongoing ping session.
SIM PIN References
YES
Vendor
Syntax
Test Command Responses
AT+CPINGSTOP=? OK
Write Command Responses
AT+CPINGSTOP +CPING:
<result_type>,<num_pkts_sent>,<num_pkts_recvd>,<num_p
kts_lost>,<min_rtt>,<max_rtt>,<avg_rtt>
OK
OK
ERROR
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
278
Defined values
<result_type>
1 – Ping success
2 – Ping time out
3 – Ping result
<num_pkts_sent>
Indicates the number of ping requests that were sent out.
<num_pkts_recvd>
Indicates the number of ping responses that were received.
<num_pkts_lost>
Indicates the number of ping requests for which no response was received.
<resolved_ip_addr>
Indicates the resolved ip address.
<min_rtt>
Indicates the minimum Round Trip Time (RTT).
<max_rtt>
Indicates the maximum RTT.
<avg_rtt>
Indicates the average RTT.
Examples
AT+CPINGSTOP
OK
15.1.7 AT+CTCPFIN Configure TCP FIN
Description
This command is used to
configure whether the module should wait for TCP_FIN in
TCP_FINWAIT2 state.
SIM PIN References
YES Vendor
Syntax
Test Command
Responses
AT+CTCPFIN=? +CTCPFIN: (list of supported <TCP_FIN_Enable>s)
OK
ERROR
Read Command Responses
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
279
AT+CTCPFIN?
+CTCPFIN:<TCP_FIN_Enable>
OK
ERROR
Write Command
Responses
AT+CTCPFIN=<TCP_FIN_
Enable>
OK
ERROR
Defined values
< TCP_FIN_Enable >
a numeric parameter which sets whether waiting for TCP_FIN inTCP_FINWAIT2 state.
0 not waiting
1 waiting
Examples
AT+CTCPFIN=?
+CTCPFIN: (0,1)
OK
AT+CTCPFIN=1
OK
15.1.8 AT+CTCPKA Conigure TCP heartbeat
Description
This command is used to set TCP heartbeat parameters..
SIM PIN References
YES Vendor
Syntax
Test Command
Responses
AT+CTCPKA=? +CTCPKA: (list of supported <TCP_KA_Enable>
s),(list of
supported <KeepIdleTm>
s) ,(list of supported
<KeepAliveMaxTry>s)
OK
Read Command Responses
AT+CTCPKA?
+CTCPKA:<TCP_KA_Enable>,<KeepIdleTm>,<KeepAliveMaxT
ry>
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
280
Write Command
Responses
AT+CTCPKA=<TCP_KA_
Enable>,<KeepIdleTm>,<Ke
epAliveMaxTry>
OK
ERROR
Defined values
< TCP_KA_Enable >
a numeric parameter which sets whether enable TCP heartbeat function or not.
0 disable
1 enable
<KeepIdleTm>
a numeric parameter which is number of minutes
to delay after last time of sending TCP data. The
range is 1 to 120.
<KeepAliveMaxTry>
Maximum times for sending Keep-Alive checking. The range is 1 to 10.
Examples
AT+CTCPKA=?
+CTCPKA: (0,1),(1-120) ,(1-10)
OK
AT+CTCPKA=1,3,3
OK
15.1.9 AT+CTEUTP Set unknown incoming TCP packet echo
Description
This command is used to enable or disable unknown incoming TCP packet echo.
SIM PIN References
YES Vendor
Syntax
Test Command Responses
AT+CTEUTP=? +CTEUTP: (list of supported <Echo_Unknown_TCP_Enable>s)
OK
ERROR
Read Command Responses
AT+CTEUTP? +CTEUTP:<Echo_Unknown_TCP_Enable>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
281
OK
ERROR
Write Command Responses
AT+CTEUTP=<Echo_Unkn
own_TCP_Enable>
OK
ERROR
Defined values
<Echo_Unknown_TCP_Enable>
a numeric parameter which sets whether enable or disable unknown incoming TCP packet echo
option.
0 disable
1 enable
Examples
AT+CTEUTP=?
+CTEUTP: (0,1)
OK
AT+CTEUTP=1
OK
15.1.10 AT+CUPURE Set UDP port unreachable ICMP echo
Description
This command is used to enable or disable UDP port unreachable echo.
SIM PIN References
YES Vendor
Syntax
Test Command Responses
AT+CUPURE=? +CUPURE:
(list of supported
<UDP_PORT_UNREACHABLE_Enable>s)
OK
ERROR
Read Command Responses
AT+CUPURE? +CUPURE:< UDP_PORT_UNREACHABLE_Enable>
OK
ERROR
Write Command Responses
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
282
AT+CUPURE=<UDP_POR
T_UNREACHABLE_Enabl
e>
OK
ERROR
Defined values
<UDP_PORT_UNREACHABLE_Enable>
a numeric parameter which sets whether enable or disable UDP port unreachable ICMP echo
option.
0 disable
1 enable
Examples
AT+CUPURE=?
+CUPURE: (0,1)
OK
AT+CUPURE=1
OK
15.1.11 AT+CINICMPALLOW Preferred ICMP filter
Description
This command is used to filter the incoming ICMP packets that are not allowed.
SIM PIN References
YES Vendor
Syntax
Test Command Responses
AT+C INICMPALLOW=? +CINICMPALLOW: (list of supported <mode>s)
OK
ERROR
Read Command Responses
AT+C INICMPALLOW? +CINICMPALLOW: <mode>
OK
ERROR
Write Command Responses
AT+CINICMPALLOW=<m
ode>
OK
ERROR
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
283
Defined values
<mode>
64bit number, the value is “1” << “<pos>” , then or by bit.
<pos>
Flag value from 0 to 63.
Value:
0 ICMP ECHO REPLY
3 ICMP DESTINATION UNREACH
4 ICMP SOURCE QUENCH
5 ICMP REDIRECT
8 ICMP ECHO REQUEST
9 MIP AGENT ADVERTISEMENT
10 MIP AGENT SOLICITATION
11 TIME-TO-ALIVE EXCEEDED
12 PARAMETER PROBLEM
13 ICMP TIMESTAMP
14 ICMP TIME REPLY
15 INFORMATION REQUEST
16 INFORMATION REPLY
17 ADDRESS MASK REQUEST
18 ADDRESS MASK REPLY
37 DOMAIN NAME REQUEST
38 DOMAIN NAME REPLY
Examples
AT+CINICMPALLOW=0xFFFFFFFFFFFFFEFF
OK
AT+CINICMPALLOW?
+CINICMPALLOW: 0xFFFFFFFFFFFFFEFF
OK
15.1.12 AT+CDNSSRV Get dns server ip address
Description
The write command is used to query the dns server ip address of the specified PDP context (s).
SIM PIN References
YES 3GPP TS 27.007
Syntax
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
284
Read Command
Responses
AT+CDNSSRV? [+CDNSSRV: [<cid>, <ip_addr>,<prm_dns>,<sec_dns>
[<CR><LF>
+CDNSSRV: <cid>, <ip_addr>,<prm_dns>,<sec_dns>
[...]]]]
OK
Defined values
<cid>
A numeric parameter which specifies a particular PDP context definition (see AT+CGDCONT
command).
1…24,100…179
<ip_addr>
A string that identifies the IP address when the PDP context is activaed.
<pri_dns>
A string that identifies the primary DNS server address when the PDP context is activaed.
<sec_dns>
A string that identifies the secondary DNS server address when the PDP context is activaed.
Examples
AT+CDNSSRV?
+CDNSSRV: 1, "10.85.202.25","210.22.70.3","211.95.1.97"
OK
15.2 HTP
These AT Commands of HTP related are used to synchronize system time with HTTP server.
15.2.1 AT+CHTPSERV Set HTP server info
Description
This command is used to
add or delete HTP server information. There are maximum 16 HTP
servers.
SIM PIN References
YES
Vendor
Syntax
Test Command Responses
AT+CHTPSERV=? +CHTPSERV:"ADD","HOST",(1-65535),
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
285
(0-1)[,"PROXY",(1-65535)]
+CHTPSERV: "DEL",(0-15)
OK
Read Command Responses
AT+CHTPSERV? +CHTPSERV:<index>"<host>",<port>,<http_version>
[,"<proxy>",<proxy_port>]
…
+CHTPSERV:<index>"<host>",<port>[,"<proxy>",< proxy_port>]
OK
OK (if HTP server not setted)
Write Command Responses
AT+CHTPSERV=
"<cmd>","<host_or_idx>"[,<
port>,<http_version>
[,"<proxy>",<proxy_port>]]
OK
ERROR
Defined values
<cmd>
This command to operate the HTP server list
.
“ADD”: add a HTP server item to the list
“DEL”: delete a HTP server item from the list
<host_or_idx>
If the <cmd> is “ADD”, this field is the same as <host>, needs quotation marks; If the <cmd> is
“DEL”, this field is the index of
the HTP server item to be deleted from the list, does not need
quotation marks.
<host>
The HTP server address.
<port>
The HTP server port.
<http_version>
The HTTP version of the HTP server:
0- HTTP 1.0
1- HTTP 1.1
<proxy>
The proxy address
<proxy_port>
The port of the proxy
<index>
The HTP server index.
Examples
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
286
AT+CHTPSERV=”ADD”,”www.google.com”,80,1
OK
15.2.2 AT+CHTPUPDATE Updating date time using HTP protocol
Description
This command is used to updating date time using HTP protocol.
SIM PIN References
YES Vendor
Syntax
Test Command Responses
AT+CHTPUPDATE=? OK
Read Command
Response
AT+CHTPUPDATE? +CHTPUPDATE:<status>
OK
Execute Command Responses
AT+CHTPUPDATE OK
+CHTPUPDATE: <err>
ERROR
Defined values
<status>
The status of HTP module:
Updating: HTP module is synchronizing date time
NULL: HTP module is idle now
<err>
The result of the HTP updating
Examples
AT+CHTPUPDATE
OK
+CHTPUPDATE: 0
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
287
15.2.3 Unsolicited HTP Codes
Code of <err>
Description
0 Operation succeeded
1 Unknown error
2 Wrong parameter
3
Wrong date and time calculated
4 Network error
15.3 NTP
These AT Commands of NTP related are used to synchronize system time with NTP server.
15.3.1 AT+CNTP Update system time
Description
This command is used to update system time with NTP server.
SIM PIN References
YES Vendor
Syntax
Test Command Responses
AT+CNTP=? +CNTP: 255,(-47~48)
OK
Read Command Responses
AT+CNTP? +CNTP: <host>,<timezone>
OK
Write Command
Responses
AT+CNTP
=”<host>”[,<tim
ezone>]
OK
ERROR
Write Command Responses
AT+CNTP
OK
+CNTP:<err_code>
ERROR
Defined values
<host>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
288
NTP server address,length is 255.
<timezone>
Local time zone,the range is(-47 to 48),default value is 32.
Examples
AT+CNTP="202.120.2.101",32
OK
AT+CNTP
OK
+CNTP: 0
15.3.2 Unsolicited NTP Codes
Code of <err> Description
0 Operation succeeded
1
Unknown error
2 Wrong parameter
3 Wrong date and time calculated
4 Network error
5
Time zone error
6 Time out error
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
289
16 AT Commands for Open/Close Network
16.1 AT+CNETSTART Open network
Description
This command opens packet network.
SIM PIN References
YES Vendor
Syntax
Read Command Responses
AT+CNETSTART? +CNETSTART: <net_state>
OK
ERROR
Execution Command Responses
AT+CNETSTART OK
+CNETSTART: <err>
+CNETSTART: <err>
OK
+CNETSTART: <err>
ERROR
ERROR
Defined values
<net_state>
a numeric parameter that indicates the state of PDP context activation:
0 network close (deactivated)
1 network is opening
2 network open(activated)
3
network is closing
<err >
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
290
The result of operation, 0 is success, other value is failure.
Examples
AT+CNETSTART
OK
+CNETSTART: 0
AT+CNETSTART?
+CNETSTART: 2
OK
16.2 AT+CNETSTOP Close network
Description
This command
closes network. Before calling this command, all opened sockets must be closed
first.
SIM PIN References
YES
Vendor
Syntax
Execution Command Responses
AT+CNETSTOP OK
+CNETSTOP: <err>
+CNETSTOP: <err>
OK
+CNETSTOP: <err>
ERROR
ERROR
Defined values
<err>
The result of operation, 0 is success, other value is failure.
Examples
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
291
AT+CNETSTOP
OK
+CNETSTOP: 0
16.3 AT+CNETIPADDR Inquire PDP address
Description
This command inquires the IP address of current active PDP.
SIM PIN References
YES
Vendor
Syntax
Read Command
Responses
AT+
CNETIPADDR?
+CNETIPADDR: < ip_address>
OK
+CNETIPADDR: <err_info>
ERROR
ERROR
Defined values
<ip_address>
A string parameter that identifies the IP address of current active socket PDP.
<err_info>
A string parameter that displays the cause of occurring error.
Examples
AT+CNETIPADDR?
+CNETIPADDR: 10.71.155.118
OK
16.4 Unsolicited Open/Close network command <err> Codes
Code of <err> Description
0 Operation succeeded
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
292
1
Unknown error
2 Open network failed
3 Close network failed
4
5
6
7
8
Network not opened
Operation not support
Busy
Network has been opened
Network is also in use
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
293
17 AT Commands for GPS
17.1 AT+CGPS Start/Stop GPS session
Description
This command is used to start or stop GPS session.
NOTE:
1. Output of NMEA sentences is automatic; no control via AT commands is provided. At
present the module only supports standalone mode. If executing AT+CGPS=1, the GPS
session will choose cold or hot start automatically.
2. UE-based and UE-assisted mode depend on URL (AT+CGPSURL). When UE-based
mode fails, it will switch standalone mode.
3. UE-assisted mode is singly fixed. Standalone and UE-based mode is consecutively
fixed.
4. After the GPS closed, it should to wait about 2s~30s for start again. Reason：If the
signal conditions are right (strong enough signals to allow ephemeris demodulation) or
ephemeris demodulation is on going, sometimes MGP will stay on longer in order to
demodulate more ephemeris.
This will help the engine provide faster TTFF and
possibly better yield later (up to 2 hours), because it has the benefit of more ephemeris
available.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CGPS=? +CGPS: (list of supported <on/off>s),( list of supported <mode>s)
OK
Read Command
Responses
AT+CGPS? +CGPS: <on/off>,<mode>
OK
Write Command
Responses
AT+CGPS=<on/off>
[,<mode>]
OK
If UE-assisted mode, when fixed will report indication:
+CAGPSINFO:<lat>,<lon>,<alt>,<date>,<time>
If <off>, it will report indication:
+CGPS: 0
ERROR
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
294
Defined values
<on/off>
0 – stop GPS session
1 – start GPS session
<mode>
Ignore - standalone mode
1 – standalone mode
2 – UE-based mode
3 – UE-assisted mode
<lat>
Latitude of current position. Unit is in 10^8 degree
<log>
Longitude of current position. Unit is in 10^8 degree
<alt>
MSL Altitude. Unit is meters.
<date>
UTC Date. Output format is ddmmyyyy
<time>
UTC Time. Output format is hhmmss.s
< unconfidence >
Unconfidence of the location, GPS fixed report 39, cell fixed report 100.
< uncertainty_meter >
Uncertainty meters.
Examples
AT+CGPS?
OK
AT+CGPS=1,1
OK
17.2 AT+CGPSINFO Get GPS fixed position information
Description
This command is used to get current position information.
SIM PIN References
NO Vendor
Syntax
Test Command
Responses
AT+CGPSINFO=? +CCGPSINFO: (scope of <time>)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
295
OK
Read Command Responses
AT+CGPSINFO? +CCGPSINFO: <time>
OK
Write Command Responses
AT+CGPSINFO=<time> OK
+CGPSINFO: [<lat>],[<N/S>],[<log>],[<E/W>],[<date>],[
<UTC
time>],[<alt>],[<speed>],[<course>]
OK (if <time>=0)
Execution Command Responses
AT+CGPSINFO +CGPSINFO: [<lat>],[<N/S>],[<log>],[<E/W>],[<date>],[
<UTC
time>],[<alt>],[<speed>],[<course>]
OK
Defined values
<lat>
Latitude of current position. Output format is ddmm.mmmmmm
<N/S>
N/S Indicator, N=north or S=south
<log>
Longitude of current position. Output format is dddmm.mmmmmm
<E/W>
E/W Indicator, E=east or W=west
<date>
Date. Output format is ddmmyy
<UTC time>
UTC Time. Output format is hhmmss.s
<alt>
MSL Altitude. Unit is meters.
<speed>
Speed Over Ground. Unit is knots.
<course>
Course. Degrees.
<time>
The range is 0-255, unit is second, after set <time> will report the GPS information
every the
seconds.
Examples
AT+CGPSINFO=?
+CGPSINFO: (0-255)
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
296
OK
AT+CGPSINFO?
+CGPSINFO: 0
OK
AT+CGPSINFO
+CGPSINFO:3113.343286,N,12121.234064,E,250311,072809.3,44.1,0.0,0
OK
17.3 AT+CGPSCOLD Cold start GPS
Description
This command is used to cold start GPS session.
NOTE: Before using this command,it must use AT+CGPS=0 to stop GPS session.
Syntax
Test Command Responses
AT+CGPSCOLD=? OK
Execution Command Responses
AT+CGPSCOLD
OK
Examples
AT+CGPSCOLD=?
OK
AT+CGPSCOLD
OK
17.4 AT+CGPSHOT Hot start GPS
Description
This command is used to hot start GPS session
NOTE: Before using this command, AT+CGPS=0 must be used to stop GPS session.
SIM PIN References
NO
Vendor
Syntax
Test Command Responses
AT+CGPSHOT=? OK
SIM PIN References
NO Vendor
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
297
Execution Command
Responses
AT+CGPSHOT OK
Examples
AT+CGPSHOT=?
OK
AT+CGPSHOT
OK
17.5 AT+CGPSURL Set AGPS default server URL
Description
This command is used to set AGPS default server URL. It will take effect only after restarting.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CGPSURL=? OK
Read Command
Responses
AT+CGPSURL? +CGPSURL: <URL>
OK
Write Command Responses
AT+CGPSURL=<URL> OK
ERROR
Defined values
<URL>
AGPS default server URL. It needs double quotation marks.
Examples
AT+CGPSURL=”123.123.123.123:8888”
OK
AT+CGPSURL?
+CGPSURL: ”123.123.123.123:8888”
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
298
17.6 AT+CGPSSSL Set AGPS transport security
Description
This command is used to select transport security, used certificate or not. The certificate gets from
local carrier. If the AGPS server doesn’t need certificate, execute AT+CGPSSSL=0.
SIM PIN References
NO
Vendor
Syntax
Test Command Responses
AT+CGPSSSL=? +CGPSSSL: (list of supported <SSL>s)
OK
Read Command Responses
AT+CGPSSSL? +CGPSSSL: <SSL>
OK
Write Command Responses
AT+CGPSSSL=<SSL> OK
ERROR
Defined values
<SSL>
0 – don’t use certificate
1 – use certificate
Examples
AT+CGPSSSL=0
OK
17.7 AT+CGPSAUTO Start GPS automatic
Description
This command is used to start GPS automaticly when module powers on, GPS is closed defaultly.
NOTE: If GPS start automatically, its operation mode is standalone mode.
SIM PIN References
NO Vendor
Syntax
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
299
Test Command
Responses
AT+CGPSAUTO=? +CGPSAUTO:( list of supported <auto>s)
OK
Read Command Responses
AT+CGPSAUTO? +CGPSAUTO:<auto>
OK
Write Command Responses
AT+CGPSAUTO=<auto>
OK
ERROR
Defined values
<auto>
0 – Non-automatic
1 – automatic
Examples
AT+CGPSAUTO=1
OK
17.8 AT+CGPSNMEA Configure NMEA sentence type
Description
This command is used to
configure NMEA output sentences which are generated by the gpsOne
engine when position data is available.
NOTE: If nmea bit 2 GPGSV doesn’t configure, GPGSV sentence also doesn’t output on
AT/modem port even set AT+CGPSFTM=1.
Module should reboot to take effect.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CGPSNMEA=? +CGPSNMEA: (scope of <nmea>)
OK
Read Command Responses
AT+CGPSNMEA? +CGPSNMEA: <nmea>
OK
Write Command Responses
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
300
AT+CGPSNMEA=<nmea>
OK
If GPS engine is running:
ERROR
Defined values
<nmea>
Range – 0 to 262143
Each bit enables an NMEA sentence output as follows:
Bit 0 – GPGGA (global positioning system fix data)
Bit 1 – GPRMC (recommended minimum specific GPS/TRANSIT data)
Bit 2 – GPGSV (GPS satellites in view)
Bit 3 – GPGSA (GPS DOP and active satellites)
Bit 4 – GPVTG (track made good and ground speed)
Bit 5 – PQXFI (Global Positioning System Extended Fix Data.)
Bit 6 – GLGSV (GLONASS satellites in view GLONASS fixes only)
Bit 7 – GNGSA (1. GPS/2. Glonass/3. GALILE DOP and Active Satellites.)
Bit 8 – GNGNS (fix data for GNSS receivers;output for GPS,GLONASS,GALILEO)
Bit 9 – Reserved
Bit 10 – GAGSV (GALILEO satellites in view)
Bit 11 –Reserved
Bit 12 –Reserved
Bit 13 –Reserved
Bit 14 –Reserved
Bit 15 –Reserved,
Bit 16 –BDGSA/PQGSA (BEIDOU/QZSS DOP and active satellites)
Bit 17 –BDGSV/PQGSV (BEIDOUQZSS satellites in view)
Set the desired NMEA sentence bit(s). If multiple NMEA sentence formats are desired, “OR” the
desired bits together.
NOTE: Reserved default 0, set invalid.
Examples
AT+CGPSNMEA=200191
OK
17.9 AT+CGPSNEMARATE Set NMEA output rate
Description
This command is used to set nmea output rate
NOTE: send the command before open gps
SIM PIN References
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
301
NO Vendor
Syntax
Test Command Responses
AT+CGPSNMEARATE=? +CGPSNMEARATE: (scope of < rate >)
OK
Read Command Responses
AT+CGPSNMEARATE? +CGPSNMEARATE: <rate>
OK
Write Command
Responses
AT+CGPSNMEARATE=<r
ate>
OK
ERROR
Defined values
<rate>
0 output rate 1HZ
1 output rate 10HZ
Examples
AT+
CGPSNMEARATE
=1
OK
17.10 AT+CGPSMD Configure AGPS MO method
Description
This command specifies if the Mobile-Originated (MO) GPS session should use the control plane
session or user plane session.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CGPSMD=?
+CGPSMD: (scope of <method>)
OK
Read Command Responses
AT+CGPSMD? +CGPSMD: <method>
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
302
Write Command
Responses
AT+CGPSMD=<method> OK
If GPS engine is running:
ERROR
Defined values
<method>
0 – Control plane
1 – User plane
Examples
AT+CGPSMD=1
OK
17.11 AT+CGPSFTM Start GPS test mode
Description
This command is used to start GPS test mode.
NOTE:
1. If test mode starts, the URC will report on AT port, Modem port and UART port.
2. If testing on actual signal, <SV> should be ignore
d, and GPS must be started by AT+CGPS,
AT+CGPSCOLD or AT+CGPSHOT.
3. If testing on GPS signal simulate equipment, <SV> must be choiced
, and GPS will start
automatically.
4. URC sentence will report every 1 second.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CGPSFTM=? OK
Read Command Responses
AT+CGPSFTM? +CGPSFTM: <on/off>
OK
Write Command Responses
AT+CGPSFTM=<on/off> OK
ERROR
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
303
Defined values
<on/off>
0 – Close test mode
1 – Start test mode
<CNo>
Satellite CNo value. Floating value.
URC format
$GPGSV[,<SV>,<CNo>][...]
$GLGSV[,<SV>,<CNo>][...]
$BDGSV[,<SV>,<CNo>][...]
$GAGSV[,<SV>,<CNo>][...]
$PQGSV[,<SV>,<CNo>][...]
Examples
AT+CGPSFTM=1
OK
$GLGSV,78,20.6,66,25.6,77,21.6,79,21.9,67,26.2,68,23.6
$GPGSV,10,36.3,12,33.5,14,26.5,15,27.0,18,30.6,20,29.4,21,14.9,24,32.8,25,30.6,31,29.1,32,27.0
$BDGSV,201,28.7,204,29.0,206,27.3,207,25.9,209,25.0,210,18.5
17.12 AT+CGPSDEL Delete the GPS information
Description
This command is used to delete the GPS information. After executing the command, GPS start is
cold start.
NOTE:
This command must be executed after GPS stopped.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CGPSDEL=?
OK
Execution Command
Responses
AT+CGPSDEL OK
ERROR
Examples
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
304
AT+CGPSDEL=?
OK
AT+CGPSDEL
OK
17.13 AT+CGPSXE Enable/Disable GPS XTRA function
Description
This command is used to enable/disable the GPS XTRA function.
NOTE:
XTRA function must do
wnload the assistant file from network by HTTP, so the APN must
be set by AT +C G DCONT command.
SIM PIN References
NO Vendor
Syntax
Test Command
Responses
AT+CGPSXE=? +CGPSXE: (list of supported <on/off>s)
OK
Read Command Responses
AT+CGPSXE? +CGPSXE: <on/off>
OK
Write Command Responses
AT+CGPSXE=<on/off> OK
ERROR
Defined values
<on/off>
0 – Disable GPS XTRA
1 – Enable GPS XTRA
Examples
AT+CGPSXE=?
+CGPSXE: (0,1)
OK
AT+CGPSXE=0
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
305
17.14 AT+CGPSXD Download XTRA assistant file
Description
This command
is used to download the GPS XTRA assistant file from network through http
protocol. Module will download the latest assistant file form server and write the file into module.
SIM PIN References
NO
Vendor
Syntax
Test Command Responses
AT+CGPSXD=? +CGPSXD: (list of supported <server>s)
OK
Read Command Responses
AT+CGPSXD? +CGPSXD: <server>
OK
Write Command Responses
AT+CGPSXD=<server> OK
+CGPSXD: <resp>
+CGPSXD: <resp>
ERROR
Defined values
<server>
0 – XTRA primary server (precedence)
1 – XTRA secondary server
2 – XTRA tertiary server
<resp>
refer to Unsolicited XTRA download Codes
Examples
AT+CGPSXD=?
+CGPSXD: (0-2)
OK
AT+CGPSXD=0
OK
+CGPSXD: 0
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
306
17.15 AT+CGPSXDAUTO Download XTRA assistant file automatically
Description
This command is used to control download assistant file automatically or not when GPS start.
XTRA function must enable for using this command. If assistant file doesn’t exist or check error,
the module will download and inject the assistant file automatically.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CGPSXDAUTO=? +CGPSXDAUTO: (list of supported <on/off>s)
OK
Read Command Responses
AT+CGPSXDAUTO? +CGPSXDAUTO: <on/off>
OK
Write Command Responses
AT+CGPSXDAUTO=<on/o
ff>
OK
ERROR
Defined values
<on/off>
0 – disable download automatically
1 – enable download automatically
NOTE: Some URCs will report when downloading, it’s same as AT+CGPSXD command.
Examples
AT+
CGPSXDAUTO
=?
+CGPSXDAUTO: (0,1)
OK
AT+CGPSXDAUTO=0
OK
17.16 AT+CGPSINFOCFG Report GPS NMEA-0183 sentence
Description
This command is used to report NMEA-0183 sentence.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
307
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CGPSINFOCFG=? +CGPSINFOCFG: (scope of <time>),(scope of <config>)
OK
Read Command Responses
AT+CGPSINFOCFG? +CGPSINFOCFG: <time>,<config>
OK
Write Command Responses
AT+CGPSINFOCFG=<time
>[,<config>]
OK
(NMEA-0183 Sentence)
……
OK (if <time>=0)
Defined values
<time>
The range is 0-255, unit is second, after set <time> will report the GPS NMEA sentence every the
seconds.
If <time>=0, module stop reporting the NMEA sentence.
<config>
Range – 0 to 262143
Each bit enables an NMEA sentence output as follows:
Bit 0 – GPGGA (global positioning system fix data)
Bit 1 – GPRMC (recommended minimum specific GPS/TRANSIT data)
Bit 2 – GPGSV (GPS satellites in view)
Bit 3 – GPGSA (GPS DOP and active satellites)
Bit 4 – GPVTG (track made good and ground speed)
Bit 5 – PQXFI (Global Positioning System Extended Fix Data.)
Bit 6 – GLGSV (GLONASS satellites in view GLONASS fixes only)
Bit 7 – GNGSA (1. GPS/2. Glonass/3. GALILE DOP and Active Satellites.)
Bit 8 – GNGNS (fix data for GNSS receivers;output for GPS,GLONASS,GALILEO)
Bit 9 – Reserved
Bit 10 – GAGSV (GALILEO satellites in view)
Bit 11 –Reserved
Bit 12 –Reserved
Bit 13 –Reserved
Bit 14 –Reserved
Bit 15 –Reserved,
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
308
Bit 16 –BDGSA/PQGSA (BEIDOU/QZSS DOP and active satellites)
Bit 17 –BDGSV/PQGSV (BEIDOUQZSS satellites in view)
Set the desired NMEA sentence bit(s). If multiple NMEA sentence formats are desired, “OR” the
desired bits together.
NOTE: Reserved default 0, set invalid.
For example:
If want to report GPRMC sentence by 10 seconds, should execute AT+CGPSINFOCFG=10,2
Examples
AT+CGPSINFOCFG=?
+CGPSINFO: (0-255),(0-262143)
OK
AT+CGPSINFOCFG=10,31
OK
$GPGSV,4,1,16,04,53,057,44,02,55,334,44,10,61,023,44,05,45,253,43*7D
$GPGSV,4,2,16,25,10,300,40,17,25,147,40,12,22,271,38,13,28,053,38*77
$GPGSV,4,3,16,26,09,187,35,23,06,036,34,24,,,,27,,,*7A
$GPGSV,4,4,16,09,,,,31,,,,30,,,,29,,,*7D
$GPGGA,051147.0,3113.320991,N,12121.248076,E,1,10,0.8,47.5,M,0,M,,*45
$GPVTG,NaN,T,,M,0.0,N,0.0,K,A*42
$GPRMC,051147.0,A,3113.320991,N,12121.248076,E,0.0,0.0,211211,,,A*66
$GPGSA,A,3,02,04,05,10,12,13,17,23,25,26,,,1.4,0.8,1.2*3B
17.17 AT+CGPSPMD Configure positioning mode
Description
This command is used to configure the positioning modes support.
NOTE: Need to restart the module after setting the mode.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CGPSPMD=? +CGPSPMD: (scope of <mode>)
OK
Read Command Responses
AT+CGPSPMD? +CGPSPMD: <mode>
OK
Write Command Responses
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
309
AT+CGPSPMD=<mode> OK
ERROR
Defined values
<mode>
Default is 0xFF7F
Each bit enables a supported positioning mode as follows:
Bit 0 – Standalone
Bit 1 – UP MS-based
Bit 2 – UP MS-assisted
Bit 3 – CP MS-based (2G)
Bit 4 – CP MS-assisted (2G)
Bit 5 – CP UE-based (3G)
Bit 6 – CP UE-assisted (3G)
Bit 7 – NOT USED
Bit 8 – UP MS-based (4G)
Bit 9 – UP MS-assisted(4G)
Bit 10 – CP MS-based (4G)
Bit 11 – CP MS-assisted (4G)
Set the desired mode sentence bit(s). If multiple modes are desired, “OR” the desired bits together.
Example, support standalone, UP MS-based and UP MS-assisted, set Binary value 0000 0111, is 7.
Examples
AT+CGPSPMD=127
OK
17.18 AT+CGPSMSB Configure based mode switch to standalone
Description
This command is used to configure AGPS based mode switching to standalone mode automatically
or not.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CGPSMSB=? +CGPSMSB: (scope of <mode>)
OK
Read Command Responses
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
310
AT+CGPSMSB? +CGPSMSB: <mode>
OK
Write Command Responses
AT+CGPSMSB=<mode> OK
ERROR
Defined values
<mode>
0 – Don’t switch to standalone mode automatically
1 – Switch to standalone mode automatically
Examples
AT+CGPSMSB=0
OK
17.19 AT+CGPSHOR Configure positioning desired accuracy
Description
The command is used to configure the positioning desired accuracy threshold in meters.
SIM PIN References
NO Vendor
Syntax
Test Command
Responses
AT+CGPSHOR=? +CGPSHOR: (scope of <acc>), (scope of < acc_f >)
OK
Read Command Responses
AT+CGPSHOR? +CGPSHOR: <acc>,<acc_f>
OK
Write Command Responses
AT+CGPSHOR=<acc>[,<ac
c_f>]
OK
ERROR
Defined values
<acc>
Range – 0 to 1800000
Default value is 50
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
311
<acc_f>
Reserved
Examples
AT+CGPSHOR=50
OK
17.20 AT+CGPSNOTIFY LCS respond positioning request
Description
This command is used to respond to the incoming request for positioning request message.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CGPSNOTIFY=?
+CGPSNOTIFY: (list of supported <resp>s)
OK
Write Command Responses
AT+CGPSNOTIFY=<resp>
OK
ERROR
Defined values
<resp>
0 – LCS notify verify accept
1 – LCS notify verify deny
2 – LCS notify verify no response
Examples
AT+CGPSNOTIFY=?
+CGPSNOTIFY: (0-2)
OK
AT+CGPSNOTIFY=0
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
312
17.21 AT+CGNSSINFO Get GNSS fixed position information
Description
This command is used to get current position related information.
SIM PIN References
NO
Vendor
Syntax
Test Command
Responses
AT+CGNSSINFO=? +CGNSSINFO: (scope of <time>)
OK
Read Command
Responses
AT+CGNSSINFO? +CGNSSINFO: <time>
OK
Write Command Responses
AT+CGNSSINFO=<time> OK
+CGNSSINFO:
[<mode>],[<GPS-SVs>],[<GLONASS-SVs>],[BEIDOU-SVs],
[<lat>],[<N/S>],[<log>],[<E/W>],[<date>],[<UTC-time>],[<alt>],
[<speed>],[<course>],[<PDOP>],[HDOP],[VDOP]
OK (if <time>=0)
Execution Command
Responses
AT+CGNSSINFO
+CGNSSINFO:
[<mode>],[<GPS-SVs>],[<GLONASS-SVs>],[BEIDOU-SVs],
[<lat>],[<N/S>],[<log>],[<E/W>],[<date>],[<UTC-time>],[<alt>],
[<speed>],[<course>],[<PDOP>],[HDOP],[VDOP]
OK
Defined values
<mode>
Fix mode 2=2D fix 3=3D fix
<GPS-SVs>
GPS satellite valid numbers scope: 00-12
< GLONASS-SVs >
GLONASS satellite valid numbers scope: 00-12
<BEIDU-SVs>
BEIDOU satellite valid numbers scope: 00-12
<lat>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
313
Latitude of current position. Output format is ddmm.mmmmmm
<N/S>
N/S Indicator, N=north or S=south
<log>
Longitude of current position. Output format is dddmm.mmmmmm
<E/W>
E/W Indicator, E=east or W=west
<date>
Date. Output format is ddmmyy
<UTC time>
UTC Time. Output format is hhmmss.s
<alt>
MSL Altitude. Unit is meters.
<speed>
Speed Over Ground. Unit is knots.
<course>
Course. Degrees.
<time>
The range is 0-255, unit is second, after set <time> will report the GPS information
every the
seconds.
<PDOP>
Position Dilution Of Precision.
<HDOP>
Horizontal Dilution Of Precision.
<VDOP>
Vertical Dilution Of Precision.
Examples
AT+CGNSSINFO=?
+CGNSSINFO: (0-255)
OK
AT+CGNSSINFO?
+CGPSINFO: 0
OK
AT+CGNSSINFO
+CGNSSINFO:
2,09,05,00,3113.330650,N,12121.262554,E,131117,091918.0,32.9,0.0,255.0,1.1,0.8,0.7
OK
AT+CGNSSINFO (if not fix,will report null)
+CGNSSINFO: ,,,,,,,,,,,,,,,
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
314
17.22 AT+CGNSSMODE Configure GNSS support mode
Description
This command is used to configure GPS, GLONASS, BEIDOU and QZSS support mode.
And DPO(Dynamic power optimization) status
Module should reboot to take effective.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CGNSSMODE=? +CGNSSMODE: (scope of <gnss_mode>),(scope of <dpo_mode>)
OK
Read Command Responses
AT+CGNSSMODE? +CGNSSMODE: <gnss_mode>,<dpo_mode>
OK
Write Command Responses
AT+CGNSSMODE=<mode
>[,<dpo_mode>]
OK
ERROR
Defined values
<gnss_mode>
Range – 0 to 15
Bit0: GLONASS
Bit1: BEIDOU
Bit2: GALILEO
Bit3: QZSS
1: enable 0:disable
GPS always support
<dpo_mode>
1: enable DPO
0: disable DPO
Examples
AT+CGNSSMODE=15,1
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
315
17.23 Unsolicited XTRA download Codes
Code of <err> Description
0 Assistant file download successfully
1 Assistant file doesn’t exist
2 Assistant file check error
220 Unknown error for HTTP
221 HTTP task is busy
222 Failed to resolve server address
223
HTTP timeout
224 Failed to transfer data
225 Memory error
226 Invalid parameter
227 Network error
220~227 codes are same as Unsolicited HTTP codes
17.24 AT+CLBS Base station location
Description
The write command is used to base station location.
NOTE:
1. The LBS is only support in GSM/WCDMA/CDMA/LTE net mode.
2. It needs
to execute AT+CNETSTART to open network before execute the AT+CLBS write
command. It needs to execute AT+CNETSTOP to close network after complete the LBS operation.
SIM PIN
References
YES 3GPP TS 27.007
Syntax
Test Command Responses
AT+CLBS=? +CLBS:
(1,2,3,4,9),(1-24,100-179),(-180.000000-180.000000),(-90.000000-
90.000000),(0,1)
OK
Write Command Responses
AT+CLBS=<type>[,<cid>[,
[<longitude>,<latitude>],[<l
on_type>]]]
OK
1)type = 1,get longitude and latitude
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
316
+CLBS: <ret_code>[,<longitude>,<latitude>,<acc>]
2)type = 2,get detail address
+CLBS: <ret_code>[,<detail_addr>]
3)type = 3,get access times
+CLBS: <ret_code>[,<times>]
4)type = 4,get longitude latitude and date time
+CLBS:
<ret_code>[,<longitude>,<latitude>,<acc>,<date>,<time>]
5)type = 9, report positioning error
+CLBS: <ret_code>
ERROR
+CLBS: <ret_code>
ERROR
Defined values
<type>
A numeric parameter which specifies the location type.
1 use 3 cell’s information
2 get detail address
3 get access times
4 get longitude latitude and date time
9 report positioning error
<cid>
A numeric parameter which specifies a particular PDP context definition (see AT+CGDCONT
command).
1…24,100…179
NOTE：This parameter takes no effect in SIM7500/SIM7600, it’s only in order to keep compatible
with the previous software version and other projects, support convenience for the customers.
<longitude>
Current longitude in degrees.
<latitude>
Current latitude in degrees.
<detail_addr>
Current detail address
. It based the UCS2 coding. Each 4 characters in the URC is for one
UCS2 character.
<acc>
Positioning accuracy.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
317
<lon_type>
The type of longitude and latitude
0 WGS84，the default type
1 GCJ02.
<times>
access service times.
<data>
service date(UTC, the format is YYYY/MM/DD).
<time>
service time(UTC, the format is HH:MM:SS).
<ret_code>
The result code.
0 Success
1 Parameter error returned by server.
2 Service out of time returned by server.
3 Location failed returned by server.
4 Query timeout returned by server.
5 Certification failed returned by server.
6 Server LBS error success.
7 Server LBS error failed.
80 Report LBS to server success
81 Report LBS to server parameter error
82 Report LBS to server failed
110 Other Error
8 LBS is busy.
9 Open network error.
10 Close network error.
11 Operation timeout.
12 DNS error.
13 Create socket error.
14 Connect socket error.
15 Close socket error.
16 Get cell info error.
17 Get IMEI error.
18 Send data error.
19 Receive data error.
20 NONET error.
21 Net not opened.
Examples
AT+CLBS=?
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
318
+CLBS: (1,2,3,4,9),( 1-24,100-179),(-180.000000-180.000000),(-90.000000-90.000000),(0,1)
OK
AT+CLBS=1
OK
+CLBS: 0,31.228525,121.380295,500
AT+CLBS=2
OK
+CLBS: 0,
4e0a6d775e020020957f5b81533a002091d1949f8def002097608fd166688baf79d162805927697c
AT+CLBS=3
OK
+CLBS: 0,22
AT+CLBS=4
OK
+CLBS: 0,31.228525,121.380295,500,2025/06/07,10:49:08
AT+CLBS=9
OK
+CLBS: 80
17.25 AT+CLBSCFG Base station location configure
Description
The write command is used to set and query the base station location configure.
SIM PIN References
YES
3GPP TS 27.007
Syntax
Test Command Responses
AT+CLBSCFG=? +CLBSCFG: (0-1), 3,”Param Value”
OK
Write Command Responses
AT+CLBSCFG=<operate>,<
para>[,<value>]
+CLBSCFG: 0,<para>,<value>
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
319
OK
OK
ERROR
+CLBSCFG: <ret_code>
ERROR
Defined values
<operate>
A numeric parameter which specifies the operator.
0 read operator
1 write operator
<para>
A numeric parameter which specifies the operator parameter.
3 Server’s address
lbs-simcom.com:3002
<value>
The value of parameter.
The allowed
<value>
is "lbs-simcom.com:3002".
Server’s address of "lbs-simcom.com:3002" is free.
<ret_code>
Please refer to the <ret_code> of AT+CLBS.
Examples
AT+CLBSCFG=?
+CLBSCFG: (0-1),3,"Param Value"
OK
AT+CLBSCFG=0,3
+CLBSCFG: 0,3,"lbs-simcom.com:3002"
OK
AT+CLBSCFG=1,3,”lbs-simcom.com:3002”
OK
17.26 AT+CASSISTLOC Base station location of LTE/CDMA1x mode
Description
The write command is used to base station location. This command only is applicable to CDMA
only or CDMA and LTE hybrid network or CDMA and EVDO hybrid network.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
320
SIM PIN References
YES 3GPP TS 27.007
Syntax
Write Command Responses
AT+CASSISTLOC=<mode> +CASSISTLOC: <longitude>,<latitude>,,
+CASSISTLOC: <ret_code>
OK
+CASSISTLOC: ,,,,
OK
ERROR
Defined values
<mode>
1 – get longitude and latitude.
<longitude>
Current east longitude in degrees.
<latitude>
Current north latitude in degrees.
<ret_code>
The result code.
0 Success
Examples
AT+CASSISTLOC=1
+CASSISTLOC:31.220278,121.353058,,
+CASSISTLOC:0
OK
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
321
18 Audio Application Commands
18.1 AT+CREC record wav audio file
Description
This command is used to record a wav audio file.
It can record wav file during a call or not, the
record file should be put into the “E:/”.
SIM PIN References
NO Vendor
Syntax
Read Command Responses
AT+CREC? +CREC: <status>
OK
Write Command Responses
AT+CREC=<record_path>,<filenam
e>
+CREC:1
OK
AT+CREC=<mode> +CREC:0
OK
Defined values
<file_name>
The name of wav audio file.
< record _path>
1 – local path
2 – remote path
<status>
0 – free
1 – busy
<mode>
0 – stop record
Examples
AT+CREC=1,” E:/record.wav”
+CREC: 1
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
322
OK
AT+CREC=0
+CREC: 0
OK
18.2 AT+CCMXPLAYWAV Play wav audio file
Description
This command is used to play a wav audio file. It can play wav file during a call or not.
NOTE
Wav file format require mono channel, 8kHz sampling frequency, 16bit sampling size,
128kbps.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CCMXPLAYWAV=? +CCMXPLAYWAV: (list of supported <play_path>s),
(list of
supported <repeat>s)
OK
Write Command Responses
AT+CCMXPLAYWAV=
<file_name>,<play_path>
+WAVSTATE: wav play
OK
Report URC automatically after playing end
+WAVSTATE: wav play stop
ERROR
Defined values
<file_name>
The name of wav audio file.
<play_path>
1 – remote path
2 – local path
<repeat>
This parameter is reserved.
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
323
Examples
AT+CCMXPLAYWAV=”E:/record.wav”,2
+WAVSTATE: wav play
OK
18.3 AT+CCMXSTOPWAV Stop playing wav audio file
Description
This command is used to stop playing wav audio file. Execute this c
ommand during wav audio
playing.
SIM PIN References
NO Vendor
Syntax
Test Command Responses
AT+CCMXSTOPWAV=?
OK
Execution Command
Responses
AT+CCMXSTOPWAV [+WAVSTATE: wav play stop]
OK
Examples
AT+CCMXSTOPWAV
+WAVSTATE: wav play stop
OK
18.4 AT+CCMXPLAY Play audio file
Description
The command is used to play an audio file.
SIM PIN References
NO Vendor
Syntax
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
324
Test Command
Responses
AT+CCMXPLAY=? +CCMXPLAY: (list of supported <play_path>s),
(list of supported
<repeat>s)
OK
Write Command Responses
AT+CCMXPLAY=
<file_name>[,<play_path>[,
<repeat>]]
+AUDIOSTATE: audio play
OK
ERROR
Defined values
<file_name>
The name of audio file. Support audio file format midi, mp3, aac, amr, qcp, wav.
<play_path>
0 – local path
<repeat>
0 – don’t play repeat. Play only once.
1…255 – play repeat times. E.g. <repeat>=1, audio will play twice.
Examples
at+ccmxplay="E:/ring.mp3",0,255
+CCMXPLAY:
OK
18.5 AT+CCMXSTOP Stop playing audio file
Description
The command is used to stop playing audio file. Execute this command during audio playing.
SIM PIN References
NO Vendor
Syntax
Execution Command Responses
AT+CCMXSTOP +CCMXSTOP:
OK
+AUDIOSTATE: audio play stop
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
325
Examples
AT+CCMXSTOP
+CCMXSTOP:
OK
+AUDIOSTATE: audio play stop
19 Appendixes
19.1 Verbose code and numeric code
Verbose result code Numeric (V0 set) Description
OK 0 Command executed, no errors, Wake up after reset
CONNECT 1 Link established
RING 2 Ring detected
NO CARRIER 3 Link not established or disconnected
ERROR 4 Invalid command or command line too long
NO DIALTONE 6 No dial tone, dialing impossible, wrong mode
BUSY 7 Remote station busy
NO ANSWER 8 Connection completion timeout
19.2 Response string of AT+CEER
Number
Response string
CS internal cause
0 Phone is offline
21 No service available
25 Network release, no reason given
27
Received incoming call
29 Client ended call
34 UIM not present
35 Access attempt already in progress
36 Access failure, unknown source
38
Concur service not supported by network
29 No response received from network
45 GPS call ended for user call
46 SMS call ended for user call
47 Data call ended for emergency call
48
Rejected during redirect or handoff
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
326
100 Lower-layer ended call
101
Call origination request failed
102
Client rejected incoming call
103 Client rejected setup indication
104 Network ended call
105 No funds available
106 No service available
108
Full service not available
109 Maximum packet calls exceeded
301 Video connection lost
302 Video call setup failure
303
Video protocol closed after setup
304 Video protocol setup failure
305 Internal error
CS network cause
1
Unassigned/unallocated number
3
No route to destination
6 Channel unacceptable
8 Operator determined barring
16 Normal call clearing
17 User busy
18
No user responding
19 User alerting, no answer
21 Call rejected
22 Number changed
26
Non selected user clearing
27 Destination out of order
28 Invalid/incomplete number
29 Facility rejected
30 Response to Status Enquiry
31
Normal, unspecified
34
No circuit/channel available
38 Network out of order
41 Temporary failure
42 Switching equipment congestion
43 Access information discarded
44
Requested circuit/channel not available
47 Resources unavailable, unspecified
49 Quality of service unavailable
50 Requested facility not subscribed
55
Incoming calls barred within the CUG
57 Bearer capability not authorized
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
327
58 Bearer capability not available
63
Service/option not available
65
Bearer service not implemented
68 ACM >= ACMmax
69 Requested facility not implemented
70 Only RDI bearer is available
79 Service/option not implemented
81
Invalid transaction identifier value
87 User not member of CUG
88 Incompatible destination
91 Invalid transit network selection
95
Semantically incorrect message
96 Invalid mandatory information
97 Message non-existent/not implemented
98 Message type not compatible with state
99 IE non-existent/not implemented
100
Conditional IE error
101
Message not compatible with state
102 Recovery on timer expiry
111 Protocol error, unspecified
117 Interworking, unspecified
CS network reject
2 IMSI unknown in HLR
3 Illegal MS
4 IMSI unknown in VLR
5
IMEI not accepted
6 Illegal ME
7 GPRS services not allowed
8 GPRS & non GPRS services not allowed
9 MS identity cannot be derived
10
Implicitly detached
11
PLMN not allowed
12 Location Area not allowed
13 Roaming not allowed
14 GPRS services not allowed in PLMN
15 No Suitable Cells In Location Area
16
MSC temporarily not reachable
17 Network failure
20 MAC failure
21 Synch failure
22
Congestion
23 GSM authentication unacceptable
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
328
32 Service option not supported
33
Requested service option not subscribed
34
Service option temporarily out of orde
38 Call cannot be identified
40 No PDP context activated
95 Semantically incorrect message
96 Invalid mandatory information
97
Message type non-existent
98 Message type not compatible with state
99 Information element non-existent
101 Message not compatible with state
161
RR release indication
162 RR random access failure
163 RRC release indication
164 RRC close session indication
165 RRC open session failure
166
Low level failure
167
Low level failure no redial allowed
168 Invalid SIM
169 No service
170 Timer T3230 expired
171 No cell available
172
Wrong state
173 Access class blocked
174 Abort message received
175 Other cause
176
Timer T303 expired
177 No resources
178 Release pending
179 Invalid user data
PS internal cause lookup
0
Invalid connection identifier
1 Invalid NSAPI
2 Invalid Primary NSAPI
3 Invalid field
4 SNDCP failure
5
RAB setup failure
6 No GPRS context
7 PDP establish timeout
8 PDP activate timeout
9
PDP modify timeout
10 PDP inactive max timeout
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
329
11 PDP lowerlayer error
12
PDP duplicate
13
Access technology change
14 PDP unknown reason
PS network cause
25 LLC or SNDCP failure
26
Insufficient resources
27 Missing or unknown APN
28 Unknown PDP address or PDP type
29 User Aauthentication failed
30
Activation rejected by GGSN
31 Activation rejected, unspecified
32 Service option not supported
33 Requested service option not subscribed
34 Service option temporarily out of order
35
NSAPI already used (not sent)
36
Regular deactivation
37 QoS not accepted
38 Network failure
39 Reactivation required
40 Feature not supported
41
Semantic error in the TFT operation
42 Syntactical error in the TFT operation
43 Unknown PDP context
44 PDP context without TFT already activated
45
Semantic errors in packet filter
46 Syntactical errors in packet filter
81 Invalid transaction identifier
95 Semantically incorrect message
96 Invalid mandatory information
97
Message non-existent/not implemented
98
Message type not compatible with state
99 IE non-existent/not implemented
100 Conditional IE error
101 Message not compatible with state
111 Protocol error, unspecified
19.3 Summary of CME ERROR codes
Description
This result code is similar to the regular ERROR result code. The format of <err> can be either
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
330
numeric or verbose string, by setting AT+CMEE command.
SIM PIN References
NO 3GPP TS 27.007
Syntax
+CME ERROR: <err>
Defined values
<err>
Values (numeric format followed by verbose format):
0 phone failure
1 no connection to phone
2 phone adaptor link reserved
3 operation not allowed
4 operation not supported
5 PH-SIM PIN required
6 PH-FSIM PIN required
7 PH-FSIM PUK required
10 SIM not inserted
11 SIM PIN required
12 SIM PUK required
13 SIM failure
14 SIM busy
15 SIM wrong
16 incorrect password
17 SIM PIN2 required
18 SIM PUK2 required
20 memory full
21 invalid index
22 not found
23 memory failure
24 text string too long
25 invalid characters in text string
26 dial string too long
27 invalid characters in dial string
30 no network service
31 network timeout
32 network not allowed - emergency calls only
40 network personalization PIN required
41 network personalization PUK required
42 network subset personalization PIN required
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
331
43 network subset personalization PUK required
44 service provider personalization PIN required
45 service provider personalization PUK required
46 corporate personalization PIN required
47 corporate personalization PUK required
100 Unknown
103 Illegal MESSAGE
106 Illegal ME
107 GPRS services not allowed
111 PLMN not allowed
112 Location area not allowed
113 Roaming not allowed in this location area
132 service option not supported
133 requested service option not subscribed
134 service option temporarily out of order
148 unspecified GPRS error
149 PDP authentication failure
150 invalid mobile class
257 network rejected request
258 retry operation
259 invalid deflected to number
260 deflected to own number
261 unknown subscriber
262 service not available
263 unknown class specified
264 unknown network message
273 minimum TFTS per PDP address violated
274 TFT precedence index not unique
275 invalid parameter combination
“CME ERROR” codes of MMS:
170 Unknown error for mms
171 MMS task is busy now
172 The mms data is over size
173 The operation is overtime
174 There is no mms receiver
175 The storage for address is full
176 Not find the address
177 Invalid parameter
178 Failed to read mss
179 There is not a mms push message
180 Memory error
181 Invalid file format
182 The mms storage is full
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
332
183 The box is empty
184 Failed to save mms
185 It’s busy editing mms now
186 It’s not allowed to edit now
187 No content in the buffer
188 Failed to receive mms
189 Invalid mms pdu
190 Network error
191 Failed to read file
192 None
“CME ERROR” codes of FTP:
201 Unknown error for FTP
202 FTP task is busy
203 Failed to resolve server address
204 FTP timeout
205 Failed to read file
206 Failed to write file
207 It’s not allowed in current state
208 Failed to login
209 Failed to logout
210 Failed to transfer data
211 FTP command rejected by server
212 Memory error
213 Invalid parameter
214
Network error
Examples
AT+CPIN="1234","1234"
+CME ERROR: incorrect password
19.4 Summary of CMS ERROR codes
Description
Final result code +CMS ERROR: <err> indicates an error related to mobile equipment or network.
The operation is similar to ERROR result code. None of the following commands in the same
command line is executed. Neither ERROR nor OK result code shall be returned.
ERROR is
returned normally when error is related to syntax or invalid parameters. The format of <err> can be
either numeric or verbose. This is set with command AT +CMEE.
SIM PIN References
---
3GPP TS 27.005
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
333
Syntax
+CMS ERROR: <err>
Defined values
<err>
300 ME failure
301 SMS service of ME reserved
302 Operation not allowed
303 Operation not supported
304 Invalid PDU mode parameter
305 Invalid text mode parameter
310 SIM not inserted
311 SIM PIN required
312 PH-SIM PIN required
313 SIM failure
314 SIM busy
315 SIM wrong
316 SIM PUK required
317 SIM PIN2 required
318 SIM PUK2 required
320 Memory failure
321 Invalid memory index
322 Memory full
330 SMSC address unknown
331 no network service
332 Network timeout
340 NO +CNMA ACK EXPECTED
341 Buffer overflow
342 SMS size more than expected
500 unknown error
Examples
AT+CMGS=02112345678
+CMS ERROR: 304
Smart Machine Smart Decision
SIM7500_SIM7600 Series_AT Command Manual_V1.10 2018-10-08
334
