Dräger Safety AG & Co. KGaA Firefighting Communication System 1902717463

user manual annex

Material / Werkstoff Modification Text / Änderungstext
Amends / Kommt vor
0X
Scale / Maßstab
General Tolerance / Allgemeintoleranzen
=EX= =QS= =QF=
Registration/ Ser.Type / Ser.art Docum. / Erf.beleg Doc.Type / Dok.art Total SL(tA) / Ges.halt. Min.u.time(tG) / Min.n.d
--- --- --- No/Nein No/Nein
Created by/
Bearbeitung
Date / Datum
(dd.mm.yyyy)
Checked by /
Verantwortlich
Date / Datum
(dd.mm.yyyy)
Department /
Abteilung
Skrabs S 17.12.2015 Rüffert L 17.12.2015 st5430
Description / Benennung DCC Number / Nummer Status / Reifegrad
FPS-COM 7000 Extract IFU
FPS-COM 7000 Extract IFU
/ / Prep
Part No. / Sachnummer – Rev / ÄZ Appr./Zul.
SE23682 - 00 Y
Document Type / Dokumententyp TEXT_DRAWING A4 Page / Seite 1 of / von 2 Repl. for / Ersatz für
Schutzvermerk ISO 16016 beachten.
Use of this document / contents is forbidden
without expressed written authority. All rights reserved.
Dräger Safety
Extract from Instruction for Use for FPS-COM 7000
(technical segment: “radio”, “EMC”)
Europe (EU):
EU Declaration of Conformity (accompanied by a copy of the EU declaration of conformity)
HINWEIS
Die abgebildeten Geräteaufkleber sind nur Beispiele. Die
jeweilige Klassifizierung ist auf dem Geräteaufkleber an der
Kommunikationseinheit aufgeführt
NOTICE
The device labels shown are intended as an example only.
The respective classification is indicated on the device label
on the communication unit.
Funkfrequenzen /
Radio frequencies
abgestarhlte Sendeleistung
(ERP) /
Effective radiated power
(ERP)
zugelassen in /
Approved in
863 MHz ... 865 MHz
(Teamfunk) / (Team radio)
≤ 10 dBm EU, TR, CY
915 MHz ... 928 MHz
(Teamfunk) / (Team radio)
≤ 10 dBm AU, NZ
2402 MHz ... 2480 MHz
(Bluetooth)
≤ 7 dBm EU, US, CA, AU,
NZ
127 kHz
(LFC)
≤ -50 dBm US, CA, AU, NZ
on the label:
“FPS COM 7000”
“863-865MHz”
Example:
USA/Canada:
“This device complies with Industry Canada licence-exempt RSS standard(s) and part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation.
Description / Benennung
Status / Reifegrad
FPS-COM 7000 Extract IFU
FPS-COM 7000 Extract IFU
Prep
Part No. / Sachnummer
–
Rev / ÄZ Y
SE23682 - 00
Document Type / Dokumententyp TEXT_DRAWING A4 Page / Seite 2 of / von 2 Repl. for / Ersatz für
Schutzvermerk ISO 16016 beachten.
Use of this document / contents is forbidden
without expressed written authority. All rights reserved.
Dräger Safety
Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.”
“EMC” related :
“Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.”
on the label, USA requirement:
“FCC ID: X6O-FPSCOM7000”
“902-928MHz”
on the label, Canadian requirement:
“IC: 5895F-FPSCOM7000”
“902-928MHz”
“EMC” related :
“CAN ICES-3 (B) / NMB-3 (B)”
Australia:
on the label:
“FPS COM 7000”
“915-928MHz”
Example:
