Manual
EX-4.9 Series
Digital Microwave Radio Module
Part Number: 5xxxxxxx
Date: 2007-07-16
Exalt Communications, Inc.
Exalt EX-4.9Series Module Guide
5xxxxxxx 1
2007-07-16
Legal Notice
The information contained herein is the property of Exalt Communications, Inc. (“Exalt”)
and is supplied without liability for errors or omissions. No part of this document may be
reproduced, in any form, except as authorized by contract or other written permission
from the owner.
Any brand names and product names included in this manual are trademarks, registered
trademarks, or trade names of their respective holders.
The contents of this document are current as of the date of publication. Exalt reserves the
right to change the contents without prior notice.
The publication of information in this document does not imply freedom from patent or
other rights of Exalt or others.
© 2007 Exalt Communications Inc. All rights reserved.
The Exalt logo is a trademark of Exalt Communications, Inc.
Open-Source License Information
In addition to proprietary software/firmware, which is the sole intellectual property of
Exalt, the Exalt EX-4.9 Series of Digital Microwave Radios make use of public (open-
source) software/firmware within the terms of use of their respective shared license
agreements. Exalt will supply copies of any of this code, within the terms of their
individual licensing agreements, upon request.
Open-Source Code License Agreement Website
Linux Operating
System GNU GPL Version 2 www.gnu.org
BusyBox CLI GNU GPL Version 2 www.gnu.org;
www.busybox.net
GoAhead Web Server Copyright (c) 2003 GoAhead Software,
Inc. All Rights Reserved. www.goahead.com
U-boot Boot Code GNU GPL Version 2 www.gnu.org
www.sourceforge.net
Net-SNMP (see Copyright Notices on page 10) www.sourceforge.net
Exalt Communications, Inc.
Exalt EX-4.9 Series Guide
5xxxxxxx 2
2007-07-16
About this Document
This manual provides a description of the Exalt EX-4.9 Series Digital Microwave Radio
Module.
Revision History
Date Products and Release code
2007-07-16 EX-4.9 Series Radio Module Guide
Exalt Communications, Inc.
Exalt EX-4.9Series Module Guide
5xxxxxxx 3
2007-07-16
General Compliance and Safety
The usage of radio transmission devices is subject to specific regulatory requirements
governed by regional legislation. In most cases, the specific device must be authorized
for use in a given country and must be installed and adjusted in accordance with specific
radio-frequency settings and in a manner that has been authorized specific to the device
itself in accordance with the specific location of the device. Some users may be
completely or partially restricted from use of the device. Please consult local
governmental agency/agencies for regulatory requirements before use, or contact Exalt or
your Exalt authorized dealer for assistance.
Do not modify this device in any way without the express written consent of Exalt.
Modification voids the manufacturer warranty, and may also be illegal in accordance to
government regulations. In addition, there are no user-serviceable parts or assemblies
inside the product housing. There may also be voltages, signals, and mechanisms within
the device that could be harmful to human safety.
The mounting of the system and associated peripherals and connections (inclusive of
antenna mast, antenna, cabling, egress, lightning protection devices, grounding, power,
and so on) may be subject to regional requirements for health and human safety. A
qualified professional installer and an electrician may be required by law.
Exalt cannot warranty the device or be found liable for any
unauthorized use or installation of the device.
Safety Icons
The following icons denote specific types of information.
Note This symbol means take note. Notes contain helpful suggestions or references to
materials not contained in the manual.
Caution This symbol means be careful. There is a risk of equipment damage, loss
of data, or injury to persons. To reduce the risk, follow the instructions. This is a general
warning, caution, or risk of danger.
Warning This warning symbol means there is a risk of electric shock. This situation
could cause bodily injury. To reduce the risk, before working on any equipment, be
aware of the hazards involved with electrical circuitry and be familiar with standard
practices for preventing accidents.
Exalt Communications, Inc.
Exalt EX-4.9 Series Guide
5xxxxxxx 4
2007-07-16
Safety Notices
1. Review this entire guide for important installation instructions BEFORE attempting
to install this product.
2. The end-product is intended to be installed, used, and maintained by experienced
telecommunications personnel only.
3. Do not move or alter the marking labels.
Exalt Communications, Inc.
Exalt EX-4.9Series Module Guide
5xxxxxxx 5
2007-07-16
Table of Contents
Legal Notice........................................................................................................................ 1
Open-Source License Information...................................................................................... 1
About this Document.......................................................................................................... 2
Revision History ............................................................................................................. 2
General Compliance and Safety.......................................................................................... 3
Safety Icons..................................................................................................................... 3
Safety Notices..................................................................................................................... 4
Introduction......................................................................................................................... 6
Related Documentation and Software ............................................................................ 6
The Exalt EX-4.9 Series of Digital Microwave Radio Module...................................... 6
Radio A/B Configuration............................................................................................ 7
Installation........................................................................................................................... 8
EX- 4.9 System Specifications ........................................................................................... 9
Copyright Notices............................................................................................................. 10
Net-SNMP..................................................................................................................... 10
General Regulatory Notices.............................................................................................. 15
Antennas ....................................................................................................................... 15
Region 1 Specifics ............................................................................................................ 18
Federal Communications Commission (FCC), United States ...................................... 18
United States Compliance................................................................................................. 18
Industry Canada (IC), Canada....................................................................................... 19
Antennas Supported in Canada................................................................................. 19
Canada Compliance .......................................................................................................... 19
EX-4.9 EIRP for the US and Canada................................................................................ 20
4940-4990 MHz Band................................................................................................... 20
Index ................................................................................................................................. 21
List of Tables
Table 1 Factory Default Settings ................................................................................. 7
Table 2 EX-4.9 supported antennas........................................................................... 16
Exalt Communications, Inc.
Exalt EX-4.9 Series Guide
5xxxxxxx 6
2007-07-16
Introduction
Exalt Communications, Inc. thanks you for your purchase. Our goal is to build the
highest quality, highest reliability digital microwave radio products. This commitment to
quality and reliability extends to our employees and partners alike. We appreciate any
comments on how we can improve our products, as well as your sales and Customer Care
experience.
Customer Care Hotline (USA): (408) 871-9890
Toll-Free Customer Care Hotline (USA): (877) EXALT-01 (392-5801)
Direct-Dial Telephone (USA): (408) 871-1804
Website: www.exaltcom.com
Sales e-mail: sales@exaltcom.com
Customer Care e-mail: support@exaltcom.com
Mailing Address: Exalt Communications, Inc.
580 Division St.
Campbell, CA 95008
USA
Related Documentation and Software
This manual makes reference to other documentation and software files that may be
necessary. Any document or software mentioned in this manual can be found at:
http://www.exaltcom.com/support/downloads.htm
The Quick Start Guide provides any necessary username and password information to
gain access to these documents.
The Exalt EX-4.9 Series of Digital Microwave Radio Module
The Exalt EX-4.9 Series of Digital Microwave Radios are the most advanced carrier-
class point-to-point terrestrial radio communications devices operating in the 4940 to
4990 MHz frequency bands, respectively.
The EX-4.9 Series radios connect voice and/or digital data from one location to another,
obviating the need for copper or fiber connectivity, or enhancing existing connectivity by
providing a redundancy solution, a primary solution, and/or additional capacity.
The EX-4.9 Series Digital Microwave Radio Module is installed in Exalt’s EX-4.9 Series
products. Please refer to the Installation and Management Guide for your end-product for
detailed information on installation, set-up, troubleshooting, and maintenance.
There are no user serviceable parts inside the end-product including the EX-4.9 Series
Module, opening the end-product voids all warranties.
Exalt Communications, Inc.
Exalt EX-4.9Series Module Guide
5xxxxxxx 7
2007-07-16
Generally, the EX-4.9 Series products require a clear line-of-sight and proper path
clearance to achieve a high-performance, reliable connection. Perform professional path
engineering and site planning BEFORE installing this equipment.
Note: It is the professional installer’s responsibility to ensure that
the radio system is implemented in a legal fashion. Exalt is not liable
for any unsafe or illegal installations.
Radio A/B Configuration
Use the Exalt GUI to configure the radio terminals for Radio A and Radio B orientation.
Since many other parameters also need to be set, and the Exalt GUI is needed for these
configurations, this is the best way to completely configure the radio terminals.
Radios arrive from manufacture in default configuration, orientated as Radio B and
configured as shown in Table 1.
Table 1 Factory Default Settings
Parameter EX-4.9
Frequency 4965 MHz
Transmit Power +4 dBm
Bandwidth 10 MHz
Mode Mode 1
Link Distance <10 miles
TDD Frame Size 2ms
Link Security Key 000000000000
Administration Password password
User Password password
IP Address 10.0.0.1
IP Mask 255.0.0.0
IP Gateway 0.0.0.0
Ethernet Interfaces Enabled, 100/Full
AUX port NMS Access In-Band
T1/E1 Settings (-16 models) All Enabled, T1, B8ZS, AIS
T1/E1 Settings (std. models) Disabled
Exalt Communications, Inc.
Exalt EX-4.9 Series Guide
5xxxxxxx 8
2007-07-16
Installation
Each Exalt Digital Microwave Radio Module is installed in an EX-4.9 Series product.
There are no user-serviceable parts, Installation and Management need to be as described
in the Installation and Management Guide applicable to the end-product.
Exalt Communications, Inc.
Exalt EX-4.9Series Module Guide
5xxxxxxx 9
2007-07-16
EX- 4.9 System Specifications
Frequency Band 4940 to 4990 MHz
Tunable Range 4945 to 4985 MHz
Output Power (at full power, Mode 1) +24 dBm (20 MHz BW)
+22 dBm (10 MHz BW)
Output Power (at minimum power) +4 dBm
Selectable Channel Bandwidths 10 MHz, 20 MHz*
Receiver Threshold (BER=10-6)
Maximum RSL Mode 1: -25dBm error-free; 0dBm no damage
Non-overlapping channels 10 MHz: 5; 20 MHz, 2
Regulatory Compliance FCC Part 90; IC RSS-111
Contains FCC ID TTM-104P90M
IC ID 6254A-104P90I/R
Emission Designator(s)
* Mode 2 for 20 MHz BW is enabled through firmware options.
dBm Mode 1 Mode 2
10 MHz -86 -78
20 MHz -83 -75
10 MHz 8M72D7D
20 MHz 19M0W7D
Exalt Communications, Inc.
Exalt EX-4.9 Series Guide
5xxxxxxx 10
2007-07-16
Copyright Notices
This section present copyright notices for third-party software licensed to Exalt
Communications, Inc.
Net-SNMP
The following copyright notice applies to the open-source licensing agreement for
Net-SNMP.
Copyright 1989, 1991, 1992 by Carnegie Mellon University
Derivative Work - 1996, 1998-2000
Copyright 1996, 1998-2000 The Regents of the University of California
All Rights Reserved
Permission to use, copy, modify and distribute this software and its documentation for
any purpose and without fee is hereby granted, provided that the above copyright notice
appears in all copies and that both that copyright notice and this permission notice appear
in supporting documentation, and that the name of CMU and The Regents of the
University of California not be used in advertising or publicity pertaining to distribution
of the software without specific written permission.
CMU AND THE REGENTS OF THE UNIVERSITY OF CALIFORNIA DISCLAIM
ALL WARRANTIES WITH REGARD TO THIS SOFTWARE, INCLUDING ALL
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS. IN NO EVENT
SHALL CMU OR THE REGENTS OF THE UNIVERSITY OF CALIFORNIA BE
LIABLE FOR ANY SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES OR
ANY DAMAGES WHATSOEVER RESULTING FROM THE LOSS OF USE, DATA
OR PROFITS, WHETHER IN AN ACTION OF CONTRACT, NEGLIGENCE OR
OTHER TORTIOUS ACTION, ARISING OUT OF OR IN CONNECTION WITH THE
USE OR PERFORMANCE OF THIS SOFTWARE.
Exalt Communications, Inc.
Exalt EX-4.9Series Module Guide
5xxxxxxx 11
2007-07-16
Network Associates Technology, Inc.
Copyright (c) 2001-2003, Networks Associates Technology, Inc
All rights reserved.
Redistribution and use in source and binary forms, with or without modification, are
permitted provided that the following conditions are met:
* Redistributions of source code must retain the above copyright notice, this list of
conditions and the following disclaimer.
* Redistributions in binary form must reproduce the above copyright notice, this list of
conditions and the following disclaimer in the documentation and/or other materials
provided with the distribution.
* Neither the name of the Networks Associates Technology, Inc nor the names of its
contributors may be used to endorse or promote products derived from this software
without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND
CONTRIBUTORS ''AS IS'' AND ANY EXPRESS OR IMPLIED WARRANTIES,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDERS OR
CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,
SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT
NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;
LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER
CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT,
STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE)
ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF
ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Cambridge Broadband, Ltd.
Portions of this code are copyright (c) 2001-2003, Cambridge Broadband Ltd.
All rights reserved.
Redistribution and use in source and binary forms, with or without modification, are
permitted provided that the following conditions are met:
* Redistributions of source code must retain the above copyright notice, this list of
conditions and the following disclaimer.
* Redistributions in binary form must reproduce the above copyright notice, this list of
conditions and the following disclaimer in the documentation and/or other materials
provided with the distribution.
* The name of Cambridge Broadband Ltd. may not be used to endorse or promote
products derived from this software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDER ``AS IS'' AND
ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED
Exalt Communications, Inc.
Exalt EX-4.9 Series Guide
5xxxxxxx 12
2007-07-16
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE
COPYRIGHT HOLDER BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,
SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT
NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;
LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER
CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT,
STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE)
ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF
ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Sun Microsystems, Inc.
Copyright © 2003 Sun Microsystems, Inc., 4150 Network Circle, Santa Clara,
California 95054, U.S.A. All rights reserved.
Use is subject to license terms below.
This distribution may include materials developed by third parties.
Sun, Sun Microsystems, the Sun logo and Solaris are trademarks or registered trademarks
of Sun Microsystems, Inc. in the U.S. and other countries.
Redistribution and use in source and binary forms, with or without modification, are
permitted provided that the following conditions are met:
* Redistributions of source code must retain the above copyright notice, this list of
conditions and the following disclaimer.
* Redistributions in binary form must reproduce the above copyright notice, this list of
conditions and the following disclaimer in the documentation and/or other materials
provided with the distribution.
* Neither the name of the Sun Microsystems, Inc. nor the names of its contributors may
be used to endorse or promote products derived from this software without specific prior
written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND
CONTRIBUTORS ''AS IS'' AND ANY EXPRESS OR IMPLIED WARRANTIES,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDERS OR
CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,
SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT
NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;
LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER
CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT,
STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE)
ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF
ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Exalt Communications, Inc.
Exalt EX-4.9Series Module Guide
5xxxxxxx 13
2007-07-16
Sparta, Inc.
Copyright (c) 2003-2005, Sparta, Inc
All rights reserved.
Redistribution and use in source and binary forms, with or without modification, are
permitted provided that the following conditions are met:
* Redistributions of source code must retain the above copyright notice, this list of
conditions and the following disclaimer.
* Redistributions in binary form must reproduce the above copyright notice, this list of
conditions and the following disclaimer in the documentation and/or other materials
provided with the distribution.
* Neither the name of Sparta, Inc nor the names of its contributors may be used to
endorse or promote products derived from this software without specific prior written
permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND
CONTRIBUTORS ''AS IS'' AND ANY EXPRESS OR IMPLIED WARRANTIES,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDERS OR
CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,
SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT
NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;
LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER
CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT,
STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE)
ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF
ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Cisco, Inc.
Copyright (c) 2004, Cisco, Inc and Information Network
Center of Beijing University of Posts and Telecommunications.
All rights reserved.
Redistribution and use in source and binary forms, with or without modification, are
permitted provided that the following conditions are met:
* Redistributions of source code must retain the above copyright notice, this list of
conditions and the following disclaimer.
* Redistributions in binary form must reproduce the above copyright notice, this list of
conditions and the following disclaimer in the documentation and/or other materials
provided with the distribution.
* Neither the name of Cisco, Inc, Beijing University of Posts and Telecommunications,
nor the names of their contributors may be used to endorse or promote products derived
from this software without specific prior written permission.
Exalt Communications, Inc.
Exalt EX-4.9 Series Guide
5xxxxxxx 14
2007-07-16
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND
CONTRIBUTORS ''AS IS'' AND ANY EXPRESS OR IMPLIED WARRANTIES,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
DISCLAIMED. IN NO EVENT SHALL THE COPYRIGHT HOLDERS OR
CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,
SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT
NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;
LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER
CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT,
STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE)
ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF
ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Fabasoft R&D Software GmbH & Co.
Copyright (c) Fabasoft R&D Software GmbH & Co KG, 2003
oss@fabasoft.com
Author: Bernhard Penz
Redistribution and use in source and binary forms, with or without modification, are
permitted provided that the following conditions are met:
* Redistributions of source code must retain the above copyright notice, this list of
conditions and the following disclaimer.
* Redistributions in binary form must reproduce the above copyright notice, this list of
conditions and the following disclaimer in the documentation and/or other materials
provided with the distribution.
* The name of Fabasoft R&D Software GmbH & Co KG or any of its subsidiaries, brand
or product names may not be used to endorse or promote products derived from this
software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDER ``AS IS'' AND
ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE
COPYRIGHT HOLDER BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL,
SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT
NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;
LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER
CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT,
STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE)
ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF
ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Exalt Communications, Inc.
Exalt EX-4.9Series Module Guide
5xxxxxxx 15
2007-07-16
Appendix A - Regulatory Compliance
General Regulatory Notices
Antennas
Table 2 lists antennas recommended for use with the EX-4.9 Series radios. In some
countries, antennas exceeding a certain level of gain may be unlawful.
Exalt Communications, Inc.
Exalt EX-4.9 Series Guide
5xxxxxxx 16
2007-07-16
Table 2 lists antennas supported by the EX-4.9 family of Digital Microwave Radios.
Table 2 EX-4.9 supported antennas
Manufacturer Model # Description Mid-band Gain dBi
(mid-band)
Andrew PL4-44 4' dish 33
Andrew PL6-44 6' dish 36.6
Andrew PL8-44 8' dish 39.3
Andrew PL10-44 10' dish 41
Andrew PL12-44 12' dish 42.6
Andrew PL15-44 15' dish 44.5
Gabriel EPD1-49 1' panel 21.9
Gabriel EPD249N 2' panel 23
Gabriel QFD2-49-N 2' dish 27.7
Gabriel QFD2.5-49-N 2.5' dish 29.7
Gabriel QFD6-49-N 6' dish 33.7
Gabriel QFD4-49-N 4' dish 33.7
Gabriel RFB15-44 15' dish 44.5
Mars MA-WA49-1X 1' panel 21
MaxRad MPRW49027 2' dish 28
MaxRad MPRW49029 2.5' dish 30
MaxRad MPRW49031 3' dish 32
MTI MT-465005 1' panel 21
MTI MT-466004 1.5' panel 25
MTI MT-466003 2' panel 27
Mwave GS2-54-N 2' grid dish 25
Exalt Communications, Inc.
Exalt EX-4.9Series Module Guide
5xxxxxxx 17
2007-07-16
Mwave RP2-54-N 2' dish 26.7
Radiall/Larsen R380.500.222 1' panel 18.8
RadioWaves SP1-4.7NS 1' dish 24.6
RadioWaves SP2-4.7 2' dish 26.6
RadioWaves SP3-4.7NS 3' dish 30
RadioWaves SP4-4.7NS 4' dish 32.6
RadioWaves SP6-4.7NS 6' dish 35.6
RadioWaves SP8-4.7NS 8' dish 39
Exalt Communications, Inc.
Exalt EX-4.9 Series Guide
5xxxxxxx 18
2007-07-16
Region 1 Specifics
Region 1 is designated for USA and Canada installations.
Note: The professional installer is responsible to ensure that RF output power is
properly adjusted to not exceed the regulatory limit.
Federal Communications Commission (FCC), United States
The device is allowed to be used provided it does not cause interference to other devices.
It is not guaranteed to provide protection against interference from other electronic and
radio devices.
The system has been tested and found to comply with the limits of a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Shielded cables and I/O cords must be used for this equipment to comply with the
relevant FCC regulations.
Changes or modifications not expressly approved in writing by Exalt may void the user’s
authority to operate this equipment.
This device must be professionally installed.
To comply with regulations, the output power of this device may need to be adjusted in
accordance to the associated transmission system.
The antenna associated with the EX-4.9 family shall be mounted in a location that is at
least 10’/3m away from humans that may be subject to long-term or continuous exposure.
United States Compliance
The EX-4.9 product families operate under FCC Rule Parts 90 as a licensed device. They
may only be used as a point-to-point transmission device for fixed or temporary-fixed
(non-mobile) installations. The devices are subject to the following restrictions:
Exalt Communications, Inc.
Exalt EX-4.9Series Module Guide
5xxxxxxx 19
2007-07-16
• Do not use external amplifiers to boost the power or overcome transmission system
losses, unless the specific amplifier/cable/antenna combination has expressly been
authorized by the FCC. The output power must never exceed +50 dBm.
• Cross-border transmissions are expressly prohibited, except with written permission
from both the FCC and the governing body of the neighboring country (Cofetel for
Mexico; Industry Canada for Canada).
– Use only parabolic dish antennas or directional flat-panel antennas. No other
types of antennas (omni-directional, yagi, and so on) are authorized. Parabolic
dishes of either grid or solid type are allowed. Maximum mid-band gain of
each type of antenna certified are:
¶ EX-4.9 models:
– Parabolic dish: 26dBi (larger gains are allowed, with Tx power reduction)
– Directional flat panel: 26 dBi (larger gains are allowed, with Tx power
reduction)
–
Industry Canada (IC), Canada
This device complies with RSS-210 of Industry Canada. Operation is subject to the
following two conditions:
4. this device may not cause interference, and
5. this device must accept any interference, including interference that may cause
undesired operation of the device.
Antennas Supported in Canada
The EX-4.9 family has been designed to operate with the antennas listed in Table 2 which
have a maximum gain of 37.9 dBi. Antennas not included in the list or having a gain
greater than 37.9 dBi are prohibited for use with this device. The required antenna
impedance is 50 Ohms.
The antenna associated with the EX-4.9 family shall be mounted in a location that is at
least 10’/3m away from humans that may be subject to long-term or continuous exposure.
Canada Compliance
EX-4.9 models operate under RSS-210 of Industry Canada regulations. Operation is
subject to the following conditions, unless express permission is granted by Industry
Canada to operate in a different manner:
• External amplifiers cannot be used to boost the power or to overcome transmission
system losses, unless the specific amplifier/cable/antenna combination is expressly
authorized by Industry Canada.
Exalt Communications, Inc.
Exalt EX-4.9 Series Guide
5xxxxxxx 20
2007-07-16
• Cross-border transmissions are expressly prohibited, except with written permission
from both Industry Canada and the governing body of the neighboring country (FCC
for USA)
• Only parabolic dish antennas or directional flat-panel antennas may be used. No other
types of antennas (omni-directional, yagi, and so on) are authorized. Parabolic dishes
of either grid or solid type are allowed. Maximum gain of each type of antenna
allowed is:
¶ EX-4.9 models:
– Parabolic dish: 37.9 dBi (6'/1.8m diameter)
– Directional flat panel: 28 dBi (~2'/61cm square)
EX-4.9 EIRP for the US and Canada
4940-4990 MHz Band
For the EX-4.9r model, within the 4940–4990 MHz band, the maximum EIRP allowed is
+50dBm. The maximum output power of the radio shall never exceed +24dBm.
For the EX-4.9r models, the transmit power must be reduced from maximum (+20dBm
for 40 MHz BW, +24dBm for 20MHz BW, +22dBm for 10MHz) by 1 dB for every 1dB
that the antenna gain exceeds 26dBi (including transmission system losses).
– The professional installer is responsible to ensure that RF output power is
properly adjusted so that it does not exceed the regulatory limit of these
conditions.
Exalt Communications, Inc.
Exalt EX-4.9Series Module Guide
5xxxxxxx 21
2007-07-16
Index
A
antennas
EX-4.9
Canada, 19
US, 16
C
contact information, 6
D
documentation, related, 6
R
radio
default settings, 7
Radio A, 7
regulatory requirements
EX-4.9i FCC EIRP, 20
USA, 18
regulatory rquirements
Canada, 19
Exalt Communications, Inc.
Exalt EX-4.9 Series Guide
5xxxxxxx
2007-06-29
© 2007 Exalt Communications Inc.
580 Division St. Campbell, CA 95008 USA)
