User manual
Installing the Enterasys Wireless Outdoor
AP3660
Forcompleteinstallationinstructionsandinformation
abouttheEnterasysWirelessOutdoorAP3660,seethe
EnterasysWirelessOutdoorAP3660InstallationGuideathttp:/
/www.enterasys.com/support/manuals.
Overview of the Enterasys Wireless Outdoor
AP3660
TheEnterasysWirelessOutdoorAPenablesyoutoextend
yourWirelessLANbeyondtheboundariesofindoor
locations.Theyareresistanttoharshoutdoorconditions
andextremetemperatures.Usingtheadvancedwireless
distributionmeshfeatureofEnterasysWirelessLAN,the
EnterasysWirelessOutdoorAP3660canextendyour
WirelessLANtooutdoorlocationswithoutEthernet
cabling.Amountingbracketisavailabletoenablequick
andeasymountingoftheEnterasysWirelessOutdoorAPs
towallsandpoles.
Figure 1 Enterasys Wireless Outdoor AP3660
TheEnterasysWirelessOutdoorAP3660supportsthe
902.11n,802.11a,802.11g,andfullbackwardcompatibility
withlegacy802.11bdevices.TheEnterasysWireless
OutdoorAP3660withexternalantennaconnectors
supportsavarietyofantennas,providingrangeand
coverageversatility.
TheEnterasysWirelessOutdoorAP3660interoperatesfully
withEnterasysWirelessLAN,includingsupportfor
VoWLAN,branchofficemode,guestservices,RTLS,
availabilityandmobilityfeatures.
Unpacking the Enterasys Wireless Outdoor AP3660
UnpacktheAPfromitscarton.Thefollowingcomponents
aresuppliedwiththeEnterasysWirelessOutdoorAP3660
package
•1mountingbracket
•2stainlesssteeltiebackstrapsthatsupportpole
diametersupto4inches
•4M6screws
•4washers
Electrical Hazard: Only qualified personnel should perform installation
procedures.
AntennaConnectors
•4springwashers
•1groundscrew
•RJ45waterproofconnectorassembly
•AprintedcopyoftheEnterasysWirelessOutdoorAccess
PointQuickReference‐AP3660
Mounting and Connecting the Enterasys
Wireless Outdoor AP3660
MountingandconnectingtheEnterasysWirelessOutdoor
AP3660canbeaccomplishedeasilyandsafelybyfollowing
theinstructionsinthefullEnterasysWirelessOutdoorAccess
PointAP3660InstallationGuide.Theinstallationofthe
OutdoorAPshouldbeperformedbyaprofessional
installertoensureproperoperationandcompliancewith
safetyguidelines.
Mounting the Outdoor AP3660:
1. AttachthemountingbrackettotheAP3660usingfour
M6screwsandwashers.Youcanattachthebrackettothe
APineithertheverticalorhorizontalpositionasshown
inFigures2and3.
Figure 2 Mounting Bracket - Vertical Position
Figure 3 Mounting Bracket - Horizontal Position
2. YoucanmounttheAP3660toeitherapoleorawall:
a. TomounttheAP3660withtheattachedmounting
brackettoapole,usethesuppliedstainlesssteeltie
backstraps.
YoucanmounttheAP3660toapoleinoneofthree
possibleconfigurations,asshowninFigures4,5,and6.
Note: Before you start mounting the Enterasys Wireless Outdoor
AP3660, read the Safety Guidelines below.
Figure 4 AP3660 - Pole Mount Option 1
Figure 5 AP3660 - Pole Mount Option 2
Figure 6 AP3660 - Pole Mount Option 3
b.MounttheAP3660andtheattachedmountingbracket
toawallusingfourwood/gyprockscrewsasshownin
Figure7.
Figure 7 AP3660 - Wall Mount
3. Installtheexternalantennaintendedforareacoverage.
Forinformationaboutantennaselectionandinstallation,
refertotheExternalAntennaSitePreparationand
InstallationGuide.
4. AttachtheexternalantennacablestotheRP‐N
connectorsontheAP.
Connecting and powering the AP
YoucanpoweruptheAPinoneofthefollowingways:
•PoweroverEthernet:AddingPoEinjector
YoucanprovidepowertotheEthernetcablewithaPoE
injector.ThePoEinjectormustbe802.3atcompliant.The
PoEinjectorisnotprovidedwiththeAP.
AwaterproofRJ45connectorisprovidedtoconnectthe
PoEinjectortotheAP3660.YoumustconnecttheRJ45
connectortotheRJ45cable.Forinstructions,refertothe
fullEnterasysWirelessOutdoorAccessPointAP3660
InstallationGuide.
•Powerbyexternalpowersupply:
Youcanpurchaseanexternalpowersupplyunit(WS‐
PS3660‐MR)topowertheAP.SeeyourEnterasyssales
representativefordetails.
Forpowersupplyinstallationinstructions,refertothe
EnterasysWirelessOutdoorAccessPointAP3660Installation
Guide.
Regulatory and Compliance information
Federal Communications Commission (FCC) Notice:
ThisdevicecomplieswithPart15oftheFCCrules.
Operationissubjecttothefollowingtwoconditions:(1)this
devicemaynotcauseharmfulinterference,and(2)this
devicemustacceptanyinterferencereceived,including
interferencethatmaycauseundesiredoperation.
Industry Canada Notice:
ThisdigitalapparatusdoesnotexceedtheClassBlimitsfor
radionoiseemissionsfromdigitalapparatussetoutinthe
RadioInterferenceRegulationsfortheCanadian
DepartmentofCommunications.
Leprésentappareilnumériquen’émetpasdebruits
radioélectriquesdépassantleslimitesapplicablesaux
appareilsnumériquesdelaclassBprescritesdansle
Règlementsurlebrouillageradioélectriqueédictéparle
ministèredesCommunicationsduCanada.
RefertotheHiPathWirelessController,AccessPoints,and
ConvergenceSoftwareUserGuideInstallationGuide,
AppendixB,ʺRegulatoryinformation,ʺforcomplete
regulatoryinformation.
Warning: Changes or modifications made to this device which are
not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment
17x11 bleed template; DragonNotice; large text
Safety Guidelines
Thissectioncontainsnoticesthatyouhavetoadhereto
ensureyourpersonalsafetyandtopreventanydamageto
theequipment.
Qualified Personnel:
Grounding Warning:
Lightning Protection Warning:
Electrical Hazard: Only qualified personnel should perform
installation procedures. Within the context of the safety notes in
this documentation qualified persons are defined as persons who
are authorized to commission, ground and label devices, systems
and circuits in accordance with established safety practices and
standards. A qualified person understands the requirements risks
involved with installing outdoor electrical equipment in accordance
with national codes.
Warning: To operate the Enterasys Wireless Outdoor AP3660
safely, the chassis ground connector must have a suitable cable
connected. Do not use the Enterasys Wireless Outdoor AP3660
without a ground cable connected.
Warning: Antennas installed outdoors must be within the area
covered by a lightning protection system. Make sure that all
conducting systems entering from outdoors can be protected by a
lightning protection potential equalization system.When
implementing your lightning protection concept, make sure you
adhere to the VDE 0182 or IEC 62305 standard.
The AP3660 has a built-in lightning protector; no external lightning
protector is required. You must however note that the lightning
protector is not an adequate protection against a lightning strike.
The lightening protector only works within the framework of a
comprehensive lightning protection concept. If you have
questions, ask a qualified specialist company.
ѻક䇈ᯢк䰘ӊ
Supplement to Product Instructions
᳝↦᳝ᆇ⠽䋼ܗ㋴(Hazardous Substance)
䚼ӊৡ⿄
(Parts) 䪙
3E
∲
+J
䬝
&G
݁Ӌ䫀
&U
⒈㘨㣃
3%%
⒈Ѡ㣃䝮
3%'(
䞥ሲ䚼ӊ
(Metal Parts)
h ƻ ƻ h ƻ ƻ
⬉䏃ഫ
(
Circuit Modules)
h ƻ ƻ h ƻ ƻ
⬉㓚ঞ⬉㓚㒘ӊ
(
Cables & Cable Assemblies)
h ƻ ƻ h ƻ ƻ
ล᭭㘮ড়⠽䚼ӊ
(Plastic and Polymeric parts)
ƻ ƻ ƻ ƻ ƻ h
⬉䏃ᓔ݇
(
Circuit Breakers)
ƻ ƻ h h ƻ ƻ
ƻ˖ 㸼⼎䆹᳝↦᳝ᆇ⠽䋼䆹䚼ӊ᠔᳝ഛ䋼ᴤ᭭Ёⱘ䞣ഛ SJ/T 11363-2006 ᷛޚ㾘ᅮⱘ䰤䞣㽕∖ҹϟDŽ
Indicates that the concentration of the hazardous substance in all homogeneous materials in the parts is
below the relevant threshold of the SJ/T 11363-2006 standard.
h˖ 㸼⼎䆹᳝↦᳝ᆇ⠽䋼㟇ᇥ䆹䚼ӊⱘᶤϔഛ䋼ᴤ᭭Ёⱘ䞣䍙ߎSJ/T 11363-2006 ᷛޚ㾘ᅮⱘ䰤䞣㽕∖DŽ
Indicates that the concentration of the hazardous substance of at least one of all homogeneous
materials in the parts is above the relevant threshold of the SJ/T 11363-2006 standard.
ᇍ䫔ଂП᮹ⱘ᠔ଂѻકᴀ㸼ᰒ⼎
߃߯կᑨ䫒ⱘ⬉ᄤֵᙃѻકৃ㛑ࣙ䖭ѯ⠽䋼DŽ⊼ᛣ᠔ଂѻકЁৃ㛑Ӯгৃ㛑ϡӮ᳝᠔᳝᠔߫ⱘ䚼ӊDŽ
This table shows where these substances may be found in the supply chain of Enterasys’ electronic
information products, as of the date of sale of the enclosed product. Note that some of the component types
listed above may or may not be a part of the enclosed product.
50
ℸ⦃ֱՓ⫼ᳳ䰤া䗖⫼ѢѻકᰃѻકݠЁ᠔㾘ᅮⱘᴵӊϟᎹ
The Environmentally Friendly Use Period (EFUP) for all enclosed products and their parts
are per the symbol shown here, unless otherwise marked. Certain parts may have a
different EFUP (for example, battery modules) and so are marked to reflect such. The
Environmentally Friendly Use Period is valid only when the product is operated under the
conditions defined in the product manual.
䰸䴲⡍߿ⱘᷛ⊼ℸᷛᖫЎ䩜ᇍ᠔⍝ঞѻકⱘ⦃ֱՓ⫼ᳳᷛᖫᶤѯ䳊䚼ӊӮ
᳝ϔϾϡৠⱘ⦃ֱՓ⫼ᳳ՟བ⬉∴ऩܗഫ䌈݊ѻકϞ
Hazardous Substances
ThisproductcomplieswiththerequirementsofEuropean
Directive,2002/95/EC,RestrictionofHazardousSubstances
(RoHS)inElectricalandElectronicEquipment.
European Waste Electrical and Electronic
Equipment (WEEE) Notice
InaccordancewithDirective2002/96/ECoftheEuropean
Parliamentonwasteelectricalandelectronicequipment(WEEE):
1. Thesymbolaboveindicatesthatseparatecollectionofelectrical
andelectronicequipmentisrequiredandthatthisproductwas
placedontheEuropeanmarketafterAugust13,2005,thedate
ofenforcementforDirective2002/96/EC.
2. Whenthisproducthasreachedtheendofitsserviceablelife,it
cannotbedisposedofasunsortedmunicipalwaste.Itmustbe
collectedandtreatedseparately.
3. IthasbeendeterminedbytheEuropeanParliamentthatthere
arepotentialnegativeeffectsontheenvironmentandhuman
healthasaresultofthepresenceofhazardoussubstancesin
electricalandelectronicequipment.
4. Itistheusers’responsibilitytoutilizetheavailablecollection
systemtoensureWEEEisproperlytreated.
Forinformationabouttheavailablecollectionsystem,pleasego
towww.enterasys.com/services/support/ orcontactEnterasys
CustomerSupportat35361705586(Ireland).
Declaration of Conformity
A“DeclarationofConformity”inaccordancewiththepreceding
directivesandstandardshasbeenmadeandisonfileatDellInc.
ProductsEuropeBV,Limerick,Ireland.
Notice
EnterasysNetworksreservestherighttomakechangesin
specificationsandotherinformationcontainedinthisdocument
anditsWebsitewithoutpriornotice.Thereadershouldinall
casesconsultEnterasysNetworkstodeterminewhetheranysuch
changeshavebeenmade.
Thehardware,firmware,orsoftwaredescribedinthisdocument
issubjecttochangewithoutnotice.
INNOEVENTSHALLEnterasysNetworksBELIABLEFOR
ANYINCIDENTAL,INDIRECT,SPECIAL,OR
CONSEQUENTIALDAMAGESWHATSOEVER(INCLUDING
BUTNOTLIMITEDTOLOSTPROFITS)ARISINGOUTOFOR
RELATEDTOTHISDOCUMENT,WEBSITE,ORTHE
INFORMATIONCONTAINEDINTHEM,EVENIFEnterasys
NetworksHASBEENADVISEDOF,KNEWOF,ORSHOULD
HAVEKNOWNOF,THEPOSSIBILITYOFSUCHDAMAGES.
EnterasysNetworks,Inc.
50MinutemanRoad
Andover,MA01810
©2010EnterasysNetworks,Inc.Allrightsreserved.
PartNumber: 9034581 September 2010
ENTERASYSandENTERASYSNETWORKSandanylogos
associatedtherewith,aretrademarksorregisteredtrademarksof
EnterasysNetworks,Inc.,intheUnitedStatesand/orother
countries.ForacompletelistofEnterasystrademarks,seehttp://
www.enterasys.com/company/trademarks.aspx.
Allotherproductnamesmentionedinthisdocumentmaybe
trademarksorregisteredtrademarksoftheirrespective
companies. Enterasys Wireless
Outdoor Access Point
Quick Reference
AP3660
17x11 bleed template; DragonNotice; large text
P/N 9034581
Installing the Enterasys Wireless Outdoor
AP3660 Power Supply
Forcompleteinstallationinstructionsandinformation
abouttheEnterasysWirelessOutdoorAP3660power
supply,seetheEnterasysWirelessOutdoorAP3660
InstallationGuideathttp://www.enterasys.com/support/
manuals.
Overview of the Outdoor AP3660 Power
Supply
TheEnterasysWirelessOutdoorAP3660powersupply
providespowertotheEnterasysWirelessOutdoorAP3660
whichenablesyoutoextendyourWirelessLANbeyond
theboundariesofindoorlocations.Thepowersupplyis
resistanttoharshoutdoorconditionsandextreme
temperatures.Amountingbracketisprovidedtoenable
quickandeasymountingoftheHiPathWirelessOutdoor
AP3660powersupplytowallsandpoles.
Figure 1 Enterasys Wireless Outdoor AP3660 Power Supply
Specifications:
•ACInputFrequencyRange:50‐60Hz,1AMax
•ACInputVoltageRange:100‐240VAC
•OutputVoltage:+12Vdc
•OutputCurrent:3.33Amax
Unpacking the Enterasys Wireless Outdoor AP3660
Power Supply
ThefollowingcomponentsaresuppliedwiththeEnterasys
WirelessOutdoorAP3660powersupplypackage:
•1mountingbracket
•2stainlesssteeltiebackstrapsthatsupportpole
diametersupto4inches
•4M5screws
•4washers
•4springwashers
•1groundscrew
•1DCtoDCcable
•1ACadapter
•AprintedcopyoftheEnterasysOutdoorAccessPointQuick
Reference‐PowerSupply
Electrical Hazard: Only qualified personnel should perform installation
procedures.
Note: Before you start mounting the Enterasys Wireless Outdoor
AP3660 power supply, read the Safety Guidelines below.
Mounting and Connecting the Outdoor
AP3660 Power Supply
MountingandconnectingtheEnterasysWirelessOutdoor
AP3660powersupplycanbeaccomplishedeasilyand
safelybyfollowingtheinstructionsinthefullEnterasys
WirelessOutdoorAccessPointAP3660InstallationGuide.The
installationoftheOutdoorAPpowersupplyshouldbe
performedbyaprofessionalinstallertoensureproper
operationandcompliancewithsafetyguidelines.
Mounting the Outdoor AP3660 Power Supply:
1. AttachthemountingbrackettotheAP3660powersupply
usingfourscrewsperpowersupply.Youcanattachthe
brackettothepowersupplyineithertheverticalor
horizontalposition,asshowninFigures2and3.
Figure 2 Mounting Bracket - Vertical Position
Inthehorizontalposition,youcanattachtwopower
suppliestoonebracket,asshowninFigure3.
Figure 3 Mounting Bracket - Horizontal Position
2. YoucanmounttheAP3660powersupplytoeitherapole
orawall:
a. TomounttheAP3660powersupplyandtheattached
mountingbrackettoawall,usefourwood/gyprock
screws,asshowninFigure4.
Figure 4 Power Supply - Wall Mount
b.TomounttheAP3660powersupplywiththeattached
mountingbrackettoapole,usethesuppliedstainless
steelmountingstraps,asshowninFigures5,6,and7.
Figure 5 AP3660 Power Supply - Pole Mount Option 1
Figure 6 AP3660 Power Supply - Pole Mount Option 2
Figure 7 AP3660 Power Supply - Pole Mount Option 3
Cabling the Power Supply
ToconnectthepowersupplytotheAP3660:
1. LocatetheDCtoDCcable.
2. InsertoneendoftheDCtoDCcableintotheDC
connectoronthebottomoftheAP3660.Screwonand
handtightentheknurledknobsecurely.
Figure 8 DC Connector on AP3660 Back Panel
DCConnector
3. InsertoneendoftheDCtoDCcableintotheDC
connectoronthebottomoftheAP3660powersupply.
Screwonandhandtightentheknurledknobsecurely
Figure 9 DC Connector on the Power Supply
4. InserttheACadapterintothepowerreceptacleonthe
powersupply.Screwonandhandtightentheknurled
knobsecurely.
5. Inserttheplugintothepowersource.
Regulatory and Compliance information
Federal Communications Commission (FCC) Notice:
ThisdevicecomplieswithPart15oftheFCCrules.
Operationissubjecttothefollowingtwoconditions:(1)this
devicemaynotcauseharmfulinterference,and(2)this
devicemustacceptanyinterferencereceived,including
interferencethatmaycauseundesiredoperation.
Industry Canada Notice:
ThisdigitalapparatusdoesnotexceedtheClassBlimitsfor
radionoiseemissionsfromdigitalapparatussetoutinthe
RadioInterferenceRegulationsfortheCanadian
DepartmentofCommunications.
Leprésentappareilnumériquen’émetpasdebruits
radioélectriquesdépassantleslimitesapplicablesaux
appareilsnumériquesdelaclassBprescritesdansle
Règlementsurlebrouillageradioélectriqueédictéparle
ministèredesCommunicationsduCanada.
RefertotheHiPathWirelessController,AccessPoints,and
ConvergenceSoftwareUserGuideInstallationGuide,
AppendixB,ʺRegulatoryinformation,ʺforcomplete
regulatoryinformation.
Safety Guidelines
Thissectioncontainsnoticesthatyouhavetoadhereto
ensureyourpersonalsafetyandtopreventanydamageto
theequipment.
Note: Using the supplied AC adapter, you must create your own
power cord. For instructions, refer to the full Enterasys Wireless
Outdoor Access Point AP3660 Installation Guide.
Warning: Changes or modifications made to this device which are
not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment
DCConnector
PowerReceptacle
17x11 bleed template; AP3660PwrSupply; large text
Qualified Personnel:
Grounding Warning:
Line Voltage Warning:
Electrical Hazard: Only qualified personnel should perform
installation procedures. Within the context of the safety notes in
this documentation qualified persons are defined as persons who
are authorized to commission, ground and label devices, systems
and circuits in accordance with established safety practices and
standards. A qualified person understands the requirements risks
involved with installing outdoor electrical equipment in accordance
with national codes.
Warning: To operate the Enterasys Wireless Outdoor AP3660
safely, the chassis ground connector must have a suitable cable
connected. Do not use the Enterasys Wireless Outdoor AP3660
without a ground cable connected.
Warning: If the housing is not perfectly sealed, there is a danger
to life due to the line voltage if the Enterasys Wireless AP3660
Power Supply is subjected to spray water or dampness. Make sure
that you keep to the following safety rules:
• Before connecting, turn off the power supply
• The sealing of the cable feedthroughs of the Enterasys Wireless
Outdoor Power Supply is only assured when the cable has a
suitable diameter and adequate tensile strength. Only use
cables that meet the specifications as mentioned in the
Enterasys Wireless Outdoor Power Supply Installation Guide.
• Never wrap insulating tape or other materials around thinner
cables to achieve the required diameter. In the case, neither the
housing seal nor the strain relief clamps can fulfil their function.
Close all unused openings in the housing seal with the sealing
plugs supplied with the Enterasys Wireless Outdoor AP Power
Supply package. Do not use fillers or any other material under any
circumstances.
ѻક䇈ᯢк䰘ӊ
Supplement to Product Instructions
᳝↦᳝ᆇ⠽䋼ܗ㋴(Hazardous Substance)
䚼ӊৡ⿄
(Parts) 䪙
3E
∲
+J
䬝
&G
݁Ӌ䫀
&U
⒈㘨㣃
3%%
⒈Ѡ㣃䝮
3%'(
䞥ሲ䚼ӊ
(Metal Parts) h ƻ ƻ h ƻ ƻ
⬉䏃ഫ
(Circuit Modules) h ƻ ƻ h ƻ ƻ
⬉㓚ঞ⬉㓚㒘ӊ
(Cables & Cable Assemblies) h ƻ ƻ h ƻ ƻ
ล᭭㘮ড়⠽䚼ӊ
(Plastic and Polymeric parts) ƻ ƻ ƻ ƻ ƻ h
⬉䏃ᓔ݇
(Circuit Breakers) ƻ ƻ h h ƻ ƻ
ƻ˖ 㸼⼎䆹᳝↦᳝ᆇ⠽䋼䆹䚼ӊ᠔᳝ഛ䋼ᴤ᭭Ёⱘ䞣ഛ SJ/T 11363-2006 ᷛޚ㾘ᅮⱘ䰤䞣㽕∖ҹϟDŽ
Indicates that the concentration of the hazardous substance in all homogeneous materials in the parts is
below the relevant threshold of the SJ/T 11363-2006 standard.
h˖ 㸼⼎䆹᳝↦᳝ᆇ⠽䋼㟇ᇥ䆹䚼ӊⱘᶤϔഛ䋼ᴤ᭭Ёⱘ䞣䍙ߎSJ/T 11363-2006 ᷛޚ㾘ᅮⱘ䰤䞣㽕∖DŽ
Indicates that the concentration of the hazardous substance of at least one of all homogeneous
materials in the parts is above the relevant threshold of the SJ/T 11363-2006 standard.
ᇍ䫔ଂП᮹ⱘ᠔ଂѻકᴀ㸼ᰒ⼎
߃߯կᑨ䫒ⱘ⬉ᄤֵᙃѻકৃ㛑ࣙ䖭ѯ⠽䋼DŽ⊼ᛣ᠔ଂѻકЁৃ㛑Ӯгৃ㛑ϡӮ᳝᠔᳝᠔߫ⱘ䚼ӊDŽ
This table shows where these substances may be found in the supply chain of Enterasys’ electronic
information products, as of the date of sale of the enclosed product. Note that some of the component types
listed above may or may not be a part of the enclosed product.
50
ℸ⦃ֱՓ⫼ᳳ䰤া䗖⫼ѢѻકᰃѻકݠЁ᠔㾘ᅮⱘᴵӊϟᎹ
The Environmentally Friendly Use Period (EFUP) for all enclosed products and their parts
are per the symbol shown here, unless otherwise marked. Certain parts may have a
different EFUP (for example, battery modules) and so are marked to reflect such. The
Environmentally Friendly Use Period is valid only when the product is operated under the
conditions defined in the product manual.
䰸䴲⡍߿ⱘᷛ⊼ℸᷛᖫЎ䩜ᇍ᠔⍝ঞѻકⱘ⦃ֱՓ⫼ᳳᷛᖫᶤѯ䳊䚼ӊӮ
᳝ϔϾϡৠⱘ⦃ֱՓ⫼ᳳ՟བ⬉∴ऩܗഫ䌈݊ѻકϞ
Hazardous Substances
ThisproductcomplieswiththerequirementsofEuropean
Directive,2002/95/EC,RestrictionofHazardousSubstances
(RoHS)inElectricalandElectronicEquipment.
European Waste Electrical and Electronic
Equipment (WEEE) Notice
InaccordancewithDirective2002/96/ECoftheEuropean
Parliamentonwasteelectricalandelectronicequipment(WEEE):
1. Thesymbolaboveindicatesthatseparatecollectionofelectrical
andelectronicequipmentisrequiredandthatthisproductwas
placedontheEuropeanmarketafterAugust13,2005,thedate
ofenforcementforDirective2002/96/EC.
2. Whenthisproducthasreachedtheendofitsserviceablelife,it
cannotbedisposedofasunsortedmunicipalwaste.Itmustbe
collectedandtreatedseparately.
3. IthasbeendeterminedbytheEuropeanParliamentthatthere
arepotentialnegativeeffectsontheenvironmentandhuman
healthasaresultofthepresenceofhazardoussubstancesin
electricalandelectronicequipment.
4. Itistheusers’responsibilitytoutilizetheavailablecollection
systemtoensureWEEEisproperlytreated.
Forinformationabouttheavailablecollectionsystem,pleasego
towww.enterasys.com/services/support/ orcontactEnterasys
CustomerSupportat35361705586(Ireland).
Declaration of Conformity
A“DeclarationofConformity”inaccordancewiththepreceding
directivesandstandardshasbeenmadeandisonfileatDellInc.
ProductsEuropeBV,Limerick,Ireland.
Notice
EnterasysNetworksreservestherighttomakechangesin
specificationsandotherinformationcontainedinthisdocument
anditsWebsitewithoutpriornotice.Thereadershouldinall
casesconsultEnterasysNetworkstodeterminewhetheranysuch
changeshavebeenmade.
Thehardware,firmware,orsoftwaredescribedinthisdocument
issubjecttochangewithoutnotice.
INNOEVENTSHALLENTERASYSNETWORKSBELIABLE
FORANYINCIDENTAL,INDIRECT,SPECIAL,OR
CONSEQUENTIALDAMAGESWHATSOEVER(INCLUDING
BUTNOTLIMITEDTOLOSTPROFITS)ARISINGOUTOFOR
RELATEDTOTHISDOCUMENT,WEBSITE,ORTHE
INFORMATIONCONTAINEDINTHEM,EVENIFENTERASYS
NETWORKSHASBEENADVISEDOF,KNEWOF,ORSHOULD
HAVEKNOWNOF,THEPOSSIBILITYOFSUCHDAMAGES.
EnterasysNetworks,Inc.
50MinutemanRoad
Andover,MA01810
©2010EnterasysNetworks,Inc.Allrightsreserved.
PartNumber: 9034582 September 2010
ENTERASYSandENTERASYSNETWORKSandanylogos
associatedtherewith,aretrademarksorregisteredtrademarksof
EnterasysNetworks,Inc.,intheUnitedStatesand/orother
countries.ForacompletelistofEnterasystrademarks,seehttp://
www.enterasys.com/company/trademarks.aspx.
Allotherproductnamesmentionedinthisdocumentmaybe
trademarksorregisteredtrademarksoftheirrespective
companies. Enterasys Wireless
Outdoor Access Point
Quick Reference
Power Supply
17x11 bleed template; AP3660PwrSupply; large text
P/N 9034582
FCC Statement
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
● Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate this equipment.
This devic e complies with Part 15 of the FCC Rule s. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept an y
interference received, including interference that may cause undesired operation.
For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of
other channels is not possible.
This dev ice and it s antenna(s) must not be co-located or operation in conjunction with any other
antenna or transmitter.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 100cm between the radiator &
your body.
