Manual Part 2
![](/img.php?id=1093725&img=bg1.png)
13
Easy Search/Contents/Precautions
F-08A_E1kou
If you have weak heart, be careful
when setting the Vibrate alert
(vibration) or alert volume setting.
Could affect heart function.
If it starts thunder while using the
terminal outdoors, turn the power
OFF immediately, and move to a safe
location.
May be subject to lightning strike and could
cause electric shock.
Turn FOMA terminal OFF near high-
precision electronic control equipment
or electronic equipment using low-
power signals.
May cause the equipment to fail or
malfunction.
*
Examples of electronic equipment to avoid.
Hearing aids, implanted pacemakers or
defibrillators, other electronic medical equipment,
fire alarms, automatic doors and other automatic
control equipment.
Users wearing implanted pacemakers or
defibrillators or other electronic medical
equipment should check with the manufacturer or
sales outlet about the effect of radio frequencies
on the equipment.
When the display or camera lens is
accidentally broken, be careful of
broken glass or exposed internal parts
of FOMA terminal.
Surfaces of display and camera lens are
made of plastic panels and they are
structured for the glass not to scatter,
however, if you mistakenly touch broken or
exposed parts, you may be injured.
CAUTION
Do not swing FOMA terminal by its
strap.
May cause the terminal damage or failure, or
injury to yourself or others.
When using the motion tracking or
motion sensor, check the safety
around you, hold FOMA terminal
firmly, and do not shake it
unnecessarily.
The motion tracking and motion sensor are
functions to operate by tilting or shaking
FOMA terminal. There is a risk that FOMA
terminal hits people or objects around you
by shaking it too much, causing a serious
accident or damage.
If you put a metal strap or the like to
FOMA terminal, be careful not to let
the strap hit people or objects around
you when performing motion tracking
or using motion sensor.
Accidents such as injury, malfunction or
damage may result.
Do not place magnetic disks or cards
with magnetic stripes near FOMA
terminal or place inside and fold the
terminal.
Data stored on media such as cash cards,
credit cards, telephone cards and floppy
disks may be erased if the storage medium is
placed near the phone.
Do not bring magnetized objects close
to FOMA terminal.
Bringing strong magnetism close may cause
a malfunction.
If the display part is accidentally
broken and liquid crystal leaks out, do
not put the liquid in your mouth,
inhale, or make contact with your skin.
If the liquid gets into your eyes or
mouth, rinse it with clean water and
see a doctor immediately.
And, if the liquid adheres to skin or
clothing, use alcohol etc. to wipe it off,
then wash with soap.
May cause loss of sight or skin problems.
Do not bring the speaker close to your
ear when the ring alert is sounding or
you are playing a melody with FOMA
terminal.
May cause hearing loss.
In rare cases, using the phone in some
vehicle models can cause the vehicle's
electronic equipment to malfunction
or fail.
In this case, do not use the phone because it
may hamper safe driving.
Do
Do
Do
Do
Don't
Don't
Don't
Don't
Don't
Don't
Don't
Do
L02.fm Page 13 Friday, March 27, 2009 6:57 PM
![](/img.php?id=1093725&img=bg2.png)
14 Easy Search/Contents/Precautions
F-08A_E1kou
Mobile phones can give some users
skin problems such as itching, allergic
reactions or rashes. If you develop skin
problems, stop using the phone
immediately, and see a doctor.
FOMA terminal contains metal in the
parts below.
When opening or closing FOMA
terminal, take care not to have your
fingers or strap caught by the terminal.
May cause injuries or damages.
When watching 1Seg, take a certain
distance from the display in a fully
bright place.
May cause your eyesight to be impaired.
◆
Handling battery pack
■
Check that the battery type matches the
type displayed on the battery pack label.
DANGER
Do not connect a wire or other metal
objects to the jack. And, do not carry or
store FOMA terminal with objects like
a metal necklace.
May cause the battery pack to leak, heat,
burst or ignite.
Do not try to force the battery pack
onto FOMA terminal if you are having
trouble installing it. Always install it
after checking that it is correctly
oriented.
May cause the battery pack to leak, heat,
burst or ignite.
Do not throw the battery pack into the
fire.
May cause the battery pack to leak, heat,
burst or ignite.
Do not nail the battery pack, hit with a
hammer or step on it.
May cause the battery pack to leak, heat,
burst or ignite.
If the battery pack's fluid contacts
eyes, immediately flush the eyes with
clean water and see a doctor right
away. Do not rub the eyes.
May cause loss of sight.
WARNING
If the battery pack seems to have
abnormalities such as deformation or
scratches due to an external impact or
falling, stop using it immediately.
May cause the battery pack to leak, heat,
burst or ignite, and the equipment to
malfunction or catch fire.
If the battery pack does not have a full
charge after being charged for the
specified time, stop charging it.
May cause the battery pack to leak, heat,
burst or ignite.
If the battery pack leaks or gives off a
strange smell, immediately remove it
from the vicinity of open flames.
The vapors from leaking battery pack fluid
may ignite or explode.
Be careful not to let your pet bite the
battery pack.
May cause the battery pack to leak, heat,
burst or ignite, and the equipment to
malfunction or catch fire.
Part Material Surface
treatment
Charging jack Copper Gold plating
Slide and swing module SUS Black coating
Widget key PC-ABS Metal
evaporation
Lock plate of back cover SUS None
Screw to fix slide and swing
module
Copper Black nickel
plating
Screw to fix a case Steel Zinc plating
Do
Do
Do
Display Battery type
Li-ion 00 Li-ion battery
Don't
Don't
Don't
Don't
Do
Don't
Do
Do
Do
L02.fm Page 14 Friday, March 27, 2009 6:57 PM
![](/img.php?id=1093725&img=bg3.png)
15
Easy Search/Contents/Precautions
F-08A_E1kou
CAUTION
Do not discard old battery packs
together with other garbage.
May cause igniting or environmental
destruction. Tape the terminals of old
battery packs to insulate them, and then
bring them into a sales outlet such as
docomo Shop. If your local municipality has
a battery recycling program, dispose of them
as provided for.
Do not charge a wet battery pack.
May cause heat generation, ignition or
rupture of the battery pack.
If the battery pack's fluid contacts skin
or clothes, immediately flush the
contacted area thoroughly with clean
water.
May hurt the skin.
◆
Handling optional devices (AC
Adapter/DC Adapter/Desktop
Holder/In-Car Holder)
WARNING
Do not use the adapter (including
battery charger) cord or power cord if
it gets damaged.
May cause electric shock, heat or fire.
Do not use the AC adapter or desktop
holder in a bathroom or other highly
humid area.
May cause electric shock.
Always use the DC adapter with a
negative-ground vehicle. Do not plug it
into a positive-ground vehicle.
May cause fire.
When it starts to thunder, do not touch
FOMA terminal and adapter (including
battery charger).
May be subject to lightning strike and could
cause electric shock.
Do not short the charging jack while it
is connected to the outlet or cigarette
lighter socket. Do not touch the
charging jack with a part of your body
such as your hand or finger.
May cause fire, malfunction, electric shock
or injuries.
Place battery charger and desktop
holder in a stable location while
charging. Do not cover or wrap battery
charger and desktop holder with a
cloth, blanket, etc.
May cause FOMA terminal to be removed or
the optional devices to be heated, resulting
in fire or troubles.
Do not place heavy objects on the
adapter (including battery charger)
cord or power cord.
May cause electric shock or fire.
Do not touch the adapter (including
battery charger) cord or outlet with
wet hands.
May cause electric shock.
Only use with the specified power
source and voltage.
If incorrect voltage is used, this may cause
fire or failure. When using FOMA terminal
overseas, use AC Adapter for global use.
AC adapter : AC100V
DC adapter : 12 or 24V DC (specific for
negative ground vehicle)
AC adapter for global use : Between 100V
and 240V AC (Connect to the AC outlet for
internal household use)
If the DC adapter's fuse blows, replace
it only with the specified fuse.
Using other fuses may cause fire or
equipment failure. For the specified fuse, see
the instructions that come with the DC
adapter.
Wipe off any dust that accumulates on
the power plug.
May cause fire.
When you connect the AC adapter to
an outlet, make sure not to touch with
metal such as metal straps and firmly
connect to the outlet.
May cause electric shock, electrical short or
fire.
Don't
Don't
Do
Don't
Don't
Don't
Don't
Don't
Don't
Don't
No wet hands
Do
Do
Do
Do
L02.fm Page 15 Friday, March 27, 2009 6:57 PM
![](/img.php?id=1093725&img=bg4.png)
16 Easy Search/Contents/Precautions
F-08A_E1kou
When you disconnect the adapter
(including battery charger) from the
outlet or cigarette lighter socket, do
not pull the adapter (including battery
charger) cord or power cord with
excessive force; instead hold the plug
to disconnect.
Pulling the cord could damage it, possibly
leading to electric shock or fire.
Always remove the power plug from
the outlet when not using the adapter
for an extended period.
May cause electric shock, fire or
malfunction.
Immediately remove the power plug
from the outlet or cigarette lighter
socket if water or other fluids get into
the adapter.
May cause electric shock, smoke or fire.
Always remove the power plug from
the cigarette lighter socket when
cleaning the equipment.
May cause electric shock.
◆
Handling UIM
CAUTION
Be careful of the cut surface when
removing UIM (ICs).
May hurt hands or fingers.
◆
Handling mobile phones near
electronic medical equipment
■
These precautions are based on the
guidelines produced at the
Electromagnetic Compatibility
Conference Japan, regarding the
protection of electronic medical
equipment from radio waves emitted by
mobile phone units.
WARNING
Obey the following rules inside
medical facilities.
・
Do not bring FOMA terminal into
operating rooms (ORs), intensive care
units (ICUs) or coronary care units (CCUs).
・
Turn FOMA terminal OFF in hospital
wards.
・
Turn FOMA terminal OFF in hospital
lobbies and corridors if electronic medical
equipment could be nearby.
・
If the medical facility has specified zones
where use or possession of mobile
devices is prohibited, obey those
instructions.
・
If the function to automatically turn ON
the power is set, cancel the setting before
turning the power OFF.
Turn FOMA terminal OFF in crowded
trains or other public places where
pacemaker or defibrillator wearers
could be nearby.
FOMA terminal's signals may affect the
operation of implanted pacemakers or
defibrillators, and other devices.
Wearers of implanted pacemakers or
defibrillators must carry and use
FOMA terminal at least 22 cm away
from the implanted device.
FOMA terminal's signals may affect the
operation of implanted pacemakers or
defibrillators, and other devices.
When electronic medical equipment
other than implanted pacemakers or
defibrillators are in use outside of
medical facilities (such as in home care
settings), check with the device
manufacturer to determine how the
device is affected by electrical signals.
FOMA terminal's signals may affect the
performance of electronic medical
equipment.
Do
Unplug
Unplug
Unplug
Do
Do
Do
Do
Do
L02.fm Page 16 Friday, March 27, 2009 6:57 PM
![](/img.php?id=1093725&img=bg5.png)
17
Easy Search/Contents/Precautions
F-08A_E1kou
Handling precautions
◆
General
・
Do not get FOMA terminal etc. wet
- FOMA terminal, battery back, adapter (including battery charger) and UIM are not water-
proof. Do not use them in extremely humid places such as a bath, and do not expose them to
rain. When you carry the terminal close to your body, dampness from sweat may cause internal
corrosion and malfunction. Malfunctions deemed to have been caused by water are not
covered by the warranty, and repairs may not be possible. Since these conditions are outside
the scope of the warranty, a repair, if at all possible, is charged.
・
Clean FOMA terminal with a dry soft cloth (such as a cloth for eyeglasses).
- The display of FOMA terminal may have been applied special coating to improve clearness of
the color LCD. When cleaning FOMA terminal, rubbing it roughly with a dry cloth can scratch
the display. Take care when handling the unit, and clean it with a dry soft cloth (such as a cloth
for eyeglasses). Drops of water or dirt left on the display can cause stains or remove the
coating.
- If FOMA terminal is wiped with alcohol, paint thinner, benzine or detergent, the printing may
disappear or color may fade.
・
Clean the jack occasionally with a dry cotton swab.
- If the jack is dirty, the contact may become poor and the power may shut OFF. A dirty jack
can result in poor charging, so clean it with a dry cloth or cotton swab.
・
Do not place FOMA terminal near an air-conditioner outlet.
- The rapid change in temperature may cause condensation, causing internal corrosion and
malfunction.
・
When using, be careful not to subject excessive force to FOMA terminal or the
battery.
- If FOMA terminal is crammed into a brimming bag or placed in a pocket and sat on, display,
internal PCBs or battery pack may be damaged or malfunction. And, if external devices are
plugged into the external connection jack (earphone/microphone jack), the breakage of the
connector or malfunction may result.
・
Carefully read the separate instructions that come with FOMA terminal, adapter
(including battery charger) and desktop holder.
・
Do not rub or scrape the display with a metal piece etc.
- It may scratch the display, causing malfunction or damage.
・
Do not press the surface of the touch panel strongly or operate it with sharp
objects such as a nail, a ballpoint pen and a pin.
- It may damage the touch panel.
◆
FOMA terminal
・
Avoid extreme temperature.
- Use FOMA terminal where the ambient temperature ranges between 5 and 35
℃
and humidity
ranges between 45 and 85%.
・
FOMA terminal may affect land-line phones, TVs or radios in use nearby, so use
it as far as possible from these appliances.
・
Maintain a separate record of the data you saved in your FOMA terminal.
- If the data is deleted, DOCOMO assumes no responsibility for the loss of any data.
・
Do not drop FOMA terminal or subject it to shocks.
-May cause malfunction or damage.
・
Do not plug external devices into the external connection jack (earphone/
microphone jack) at a slant, or do not pull it forcibly while it is plugged.
-May cause malfunction or damage.
・
Do not close FOMA terminal with the strap etc. held inside.
-May cause malfunction or damage.
・
It is normal for FOMA terminal to become warm during use or charging. Continue
to use it.
・
Do not leave FOMA terminal with the camera in areas under strong direct
sunlight.
-May cause discoloring or burn-in of materials.
・
FOMA terminal should normally be used with the external connection jack cap
and the microSD card slot cover closed.
-Dust and/or water brought into FOMA terminal cause troubles.
・
Do not use FOMA terminal with the back cover removed.
-It may cause the battery to come off, or may cause a malfunction or damage.
・
Do not attach labels or stickers on the exposed rear side of the FOMA terminal
display.
- Labels or stickers may get stuck when FOMA terminal is opened/closed causing malfunction
or damage.
・
Do not put strong impact on the fingerprint sensor or scratch its surface.
-It may cause malfunction of fingerprint sensor and disable authentication operation and
pointing operation.
・
Clean the fingerprint sensor with a dry soft cloth (such as a cloth for eyeglasses).
L02.fm Page 17 Friday, March 27, 2009 6:57 PM
![](/img.php?id=1093725&img=bg6.png)
18 Easy Search/Contents/Precautions
F-08A_E1kou
- If the fingerprint sensor is dirty or water is sit on its surface, the sensor does not read
fingerprints, decreases its authentication performance, erroneously operates authentication
function with no finger on it, disables pointing operation.
・
While microSD card is being accessed, do not take the card out and do not turn
off FOMA terminal.
-It may cause data loss or malfunction.
◆
Battery pack
・
The battery pack is a consumable part.
- Replace the battery pack if FOMA terminal has extremely short operation time on a full
charge, though it may vary by operating conditions. Purchase a new battery pack of the
specified type.
・
Charge the battery in an area within the proper ambient temperature range (5-35
℃
).
・
Always charge before using it for the first time or after extended disuse.
・
The operation time provided by the battery pack varies by the operating
environment and battery pack's deterioration.
・
The battery pack may swell out as it comes to near the end of its lifetime
depending on the usage conditions, but it is not a problem.
・
Be careful especially about the following points when preserving or leaving the
battery pack for a long time.
- Keeping under the state of the full charge (right after charging ends)
- Keeping under the state of the empty charge (too exhausted to turn on FOMA terminal)
They may cause the battery pack performance to be degraded or its lifetime to be
shortened.
For necessary battery level to keep for a long time, the display of battery icon is a
state of approximately 2 or 3 cells.
◆
Adapter (including battery charger)
・
Charge the battery in an area within the proper ambient temperature range (5-35
℃
).
・
Do not charge the battery in the areas below.
- In areas of excessive humidity, dust or vibrations
- Near land-line phones or TVs/radios
・
It is normal for the adapter (including battery charger) to become warm while
charging. Continue to use it.
・
When using the DC adapter for charging, keep the vehicle engine running.
- The vehicle's battery could become flat.
・
When using an outlet with a mechanism preventing unplugging, follow the
handling instructions for that outlet.
・
Do not give strong shock. Do not deform the charging jack.
- May cause malfunction.
◆
UIM
・
Do not use excessive force to install/remove UIM.
・
It is normal for UIM to become warm during use. Continue to use it.
・
Note that DOCOMO assumes no responsibility for malfunctions occurring as the
result of inserting and using a UIM with another IC card reader/writer.
・
Always keep UIM ICs clean.
・
Clean UIM with a soft, dry cloth (such as a cloth for eyeglasses).
・
Maintain a separate record of the data you saved in UIM.
- If the data is deleted, DOCOMO assumes no responsibility for the loss of any data.
・
To preserve the environment, bring the old UIM to a sales outlet such as docomo
Shop.
・
Avoid extreme temperature.
・
Take care not to scratch, touch accidentally or short IC.
- May cause data loss or malfunction.
・
Do not drop UIM or subject it to shocks.
- May cause malfunction.
・
Do not bend UIM or place heavy objects on it.
- May cause malfunction.
・
Do not install UIM into FOMA terminal with a label or sticker put on UIM.
- May cause malfunction.
L02.fm Page 18 Friday, March 27, 2009 6:57 PM
![](/img.php?id=1093725&img=bg7.png)
19
Easy Search/Contents/Precautions
F-08A_E1kou
◆
FeliCa reader/writer
・
FeliCa reader/writer function of FOMA terminal uses weak waves requiring no
licenses for radio stations.
・
It uses 13.56 MHz frequency band. When using other reader/writers in your
surroundings, keep FOMA terminal away sufficiently from them. Before using the
FeliCa reader/writer, confirm that there are no radio stations using the same
frequency band nearby.
◆
CAUTION
・
Do not use a remodeled FOMA terminal. Using a remodeled terminal violates the
Radio Law.
FOMA terminal is certified according to technical standard conformance of
specified wireless equipment based on the Radio Law, and as a proof of it, the
"Technical Compliance Mark " is depicted on the engraved sticker of FOMA
terminal.
If you remodel FOMA terminal by removing its screws, your certification of
technical standard conformance becomes invalid.
Do not use FOMA terminal with its certification of technical standard
conformance invalid as it violates the Radio Law.
・
Be careful when you use FOMA terminal while driving a car etc.
Using a mobile phone while driving is subject to penal regulations.
If you inevitably receive a call, tell the caller that you will "call back" by handsfree,
then park in a safe place and call back.
・
Use the Bluetooth function only in Japan.
The Bluetooth function of the FOMA terminal is compliant with wireless
standards and is authorized for use only in Japan.
If you use this function overseas, you may be punished.
・
Use FeliCa reader/writer function only in Japan.
FeliCa reader/writer function of FOMA terminal conforms to Japanese radio
standards.
If you use this function overseas, you may be punished.
Waterproofness
F-08A is waterproof to IPX5 (former JIS protection code 5)
*1
and IPX7 (former JIS
protection code 7)
*2
standards if the external connection jack cap is strictly closed
as well as the back cover is mounted and locked.
*1
IPX5 means that F-08A phone keeps functioning after directly applying a jet flow of 12.5 L/
min. for at least 3 minutes from a distance of 2.5-3 m on a rotating turntable.
*2
IPX7 means that F-08A phone keeps functioning after it is slowly submerged to depth of 1 m
in static tap water at room temperature, left there for 30 minutes and then taken out.
❖
Advantages in actual operation
・
You can talk or watch 1Seg programs without using an umbrella in the rain (for
rainfall of 20 mm or less per hour).
*
When your hands or FOMA terminal are wet, avoid installing/removing the back cover or
opening/closing the external connection jack cap.
・
You can wash the FOMA terminal by submerging and moving it forth and back in
still water in a basin etc.
*
When washing, use only your hands, not a brush or sponge, with FOMA terminal locked,
the back cover installed and the external connection jack cap held in position.
・
You can use the FOMA terminal in a poolside area. Do not put the terminal in the
water of a swimming pool.
*
If FOMA terminal gets wet with water from the swimming pool, wash it as described above.
*
Do not use FOMA terminal underwater. May cause malfunction.
・
You can use FOMA terminal in a bathroom. Do not put the terminal in the bathtub.
*
Never put FOMA terminal in hot spring water or water containing soap, detergent or bath
powder.
*
Do not use FOMA terminal underwater. May cause malfunction.
◆
Important precautions
To keep the FOMA terminal waterproof, be sure to observe the points below.
・
Securely close the external connection jack cap and back cover.
・
Make sure that the cap and back cover are completely closed without floating.
・
Before using, make sure that the back cover lever is at the LOCK position.
L02.fm Page 19 Friday, March 27, 2009 6:57 PM
![](/img.php?id=1093725&img=bg8.png)
20 Easy Search/Contents/Precautions
F-08A_E1kou
❖
Opening/Closing external connection jack cap
■
Opening
Place your finger at groove on the hinge side to open the cap.
■
Closing
Close with the tab for the back cover at the rear side of the cap fitted into the
concave of this terminal.
❖
Installing back cover
Align 8 tabs of the back cover with concaves of FOMA terminal. While pressing the
back cover in the direction of
a
so that there is no gap between FOMA terminal and
back cover, slide the back cover in the direction of
b
to install, then slide the back
cover lever in the direction of
c
to lock.
・
Do not use FOMA terminal underwater (including opening/closing and keypad
operations).
・
Do not let FOMA terminal get wet with liquids other than water at room
temperature.
To keep the FOMA terminal waterproof, replacement of parts is required every 2
years regardless of whether FOMA terminal appears normal or abnormal.
Groove on the hinge side
Tab on the back
cover side
Back cover
ab
Lever
<Example>
Soap/Detergent/Bath powder Ocean water Swimming pool
Sand/Mud
Hot spring
L02.fm Page 20 Friday, March 27, 2009 6:57 PM
![](/img.php?id=1093725&img=bg9.png)
21
Easy Search/Contents/Precautions
F-08A_E1kou
DOCOMO replaces the parts as a chargeable service. Bring FOMA terminal to a
sales outlet such as a DOCOMO Shop.
◆
Precautions
・
Securely lock the back cover and firmly close the external connection jack cap.
Even a fine obstacle (one hair, one grain of sand, tiny fiber, etc.) put between
contact surfaces may allow water to enter.
・
If FOMA terminal gets wet with water or other liquids with the external connection
jack cap or back cover open, the liquid may get inside the terminal causing electric
shocks or malfunction. Stop using FOMA terminal, turn the power OFF, remove
the battery pack and contact a DOCOMO-specified repair office.
・
The external connection jack cap and the rubber packing of the inner lid play an
important role for keeping waterproof. Do not remove or scratch them. Also,
prevent dust from adhering to them.
If rubber gasket on the external connection jack cap or inner lid is damaged or
deformed, replace it at DOCOMO-specified repair office.
・
Do not leave water on FOMA terminal. In a cold region, water may freeze causing
malfunction.
・
Do not apply water flow stronger than allowed (e.g., such water flow that gives
you pain when applied to your skin directly from a faucet or shower). May cause
malfunction though F-08A provides waterproof performance of IPX5.
・
Do not wash FOMA terminal in a washing machine etc.
・
Accessories and optional devices are not waterproof.
When watching 1Seg etc. with FOMA terminal installed in the desktop holder, do
not use it in a bath room, shower room, kitchen or lavatory even if it is not
connected to the AC adapter.
・
Do not put FOMA terminal in hot water, use it in a sauna or apply hot airflow (from
a hair dryer etc.) to it.
・
Never try to charge the battery pack when FOMA terminal is wet.
・
Do not poke the microphone, earpiece or speaker with a swab or sharp object.
May damage the waterproof performance.
・
Do not leave FOMA terminal wet. May short-circuit the power jacks.
・
FOMA terminal does not float on water.
・
Do not let FOMA terminal fall. It may become scratched causing the waterproof
performance to degrade.
・
If the back cover is damaged, replace it. Water may enter inside from a damaged
section causing troubles such as electric shocks or corrosion of the battery.
・
Do not leave water on the microphone, earpiece or speaker. Such water may
interfere with talking.
DOCOMO does not guarantee actual operations under all states. Malfunctions
deemed to be caused by inappropriate operation by the customer are not covered
by the warranty.
◆
Draining water when the FOMA terminal gets wet
When FOMA terminal is wet, water may flow out after wiping it off; drain the water
following the steps below.
a
Wipe FOMA terminal surface with dry, clean cloth etc.
b
Shake FOMA terminal approximately 20 times, firmly holding its hinge section,
until there is no more water splattering.
L02.fm Page 21 Friday, March 27, 2009 6:57 PM
![](/img.php?id=1093725&img=bga.png)
22 Easy Search/Contents/Precautions
F-08A_E1kou
c
Softly press dry, clean cloth etc., against FOMA terminal to wipe off water
remaining in the microphone, earpiece, speaker, keys or hinges.
d
Remove the back cover and wipe off any drops of water around the inner lid and
the rear side of the back cover. After wiping off the water, install and lock the
back cover.
Removing back cover
→
P41
■
Attaching
a
in "Attaching/Removing battery
pack"
*
Never open the inner lid.
e
Wipe off water drained from FOMA terminal with dry, clean cloth etc.
To drain water off the speaker, shake FOMA terminal with the speaker upward
Rear side of the back cover
Around the inner lid
L02.fm Page 22 Friday, March 27, 2009 6:57 PM
![](/img.php?id=1093725&img=bgb.png)
23
Easy Search/Contents/Precautions
F-08A_E1kou
*
Water, if any, remaining in FOMA terminal may ooze up after wiping off.
*
Do not wipe off water remaining in concaves directly with a cotton swab etc.
◆
Charging
Accessories and optional devices are not waterproof. Check the following before
and after charging.
・
Check that FOMA terminal is not wet. If wet, adequately drain FOMA terminal and
wipe off water with dry, clean cloth etc. before connecting a desktop holder or
opening the external connection jack cap.
・
When charging the battery after FOMA terminal is wet, adequately drain it and
wipe off water with a dry, clean cloth etc., before connecting a desktop holder or
opening the external connection jack cap.
・
When the external connection jack cap is opened for charging, close the cap
firmly after charging.
It is recommended that the desktop holder be used for charging to prevent water
from seeping inside from the external connection jack.
*
Never try to charge the battery pack when FOMA terminal is wet.
*
Do not touch the AC adapter or desktop holder with wet hands. May cause electric shock.
*
Do not use the AC adapter or desktop holder in a place subject to water. May cause fire or
electric shock.
*
Do not use the AC adapter or desktop holder in a bathroom, kitchen, lavatory or other highly
humid area. May cause fire or electric shock.
L02.fm Page 23 Friday, March 27, 2009 6:57 PM
![](/img.php?id=1093725&img=bgc.png)
24 Easy Search/Contents/Precautions
F-08A_E1kou
Accessories and main options
Manual
F-08A
(including Back Cover F39 and the written warranty)
Instruction manual
CD-ROM for F-08A
* Quick Manual is appended
on PXXX.
* The PDF version of "Manual for PC Connection" and
"Kuten Code List" are contained in the CD-ROM.
<Standard accessory kit>
FOMA AC Adapter 01/02
(including written warranty and
operation manual)
<Main options>
Desktop Holder F30
(including operation manual)
Other options
→PXXX
Battery Pack F09
L02.fm Page 24 Friday, March 27, 2009 6:57 PM
![](/img.php?id=1093725&img=bgd.png)
25
F-08A_E1kou
Before Using the Handset
Part names and functions ................................................................................................................................................... 26
Viewing display ................................................................................................................................................................... 29
Sub-display/Light overview ............................................................................................................................................... 32
Selecting functions from menu .......................................................................................................................................... 35
Using motion sensor ........................................................................................................................................................... 39
Using UIM (FOMA card) ...................................................................................................................................................... 41
Attaching/Removing battery pack .................................................................................................................................... 43
Charging ............................................................................................................................................................................... 45
Checking battery level .............................................................................................................. Remaining battery level 48
Turning power ON/OFF ........................................................................................................................... Power ON/OFF 49
Changing screen display to English ...................................................................................................... Select language 50
Setting date and time ................................................................................................................................... Date & time 50
Notifying the other party of your phone number ......................................................................... Caller ID notification 51
Checking your own phone number ..................................................................................................... User information 51
L03.fm Page 25 Friday, March 27, 2009 4:15 PM
![](/img.php?id=1093725&img=bge.png)
26 Before Using the Handset
F-08A_E1kou
Part names and functions
<Using Earphone>
Connect an optional external connection jack
compatible earphone.
When using an earphone that is non-compliant to
external connection jack, connect an optional plug
adapter to use it.
<1Seg antenna>
The terminal has a built-in 1Seg antenna, and an
entire body of the terminal can work as an antenna.
To receive signals, minimize the covered part of
FOMA terminal when holding it with your hands to
watch 1Seg in better conditions.
→
P213
d
a
b
c
h
a
b
c
d
f
g
e
e
i
k
l
m
j
n
f
i
j
h
g
q
k
l
n
m
p
o
o
s
r
Example of connecting Flat-Plug Earphone/
Microphone with Switch (optional)
External connection jack
Plug for the terminal
Flat-plug earphone jack
Connecting plug of Flat-plug
Earphone/Microphone with
Switch
L03.fm Page 26 Friday, March 27, 2009 4:15 PM
