user manual3

F-08B_EN_FCC

Introduction

・

FeliCa reader/writer function of FOMA terminal uses weak waves requiring no

licenses for radio stations.

・

It uses 13.56 MHz frequency band. When using other reader/writers in your

surroundings, keep FOMA terminal away sufficiently from them. Before using

the FeliCa reader/writer, confirm that there are no radio stations using the same

frequency band nearby.

・

Do not use a remodeled FOMA terminal. Using a remodeled terminal violates

the Radio Law.

FOMA terminal is certified according to technical standard conformance of

specified wireless equipment based on the Radio Law, and as a proof of it, the

"Technical Compliance Mark " is depicted on the engraved sticker of FOMA

terminal.

If you remodel FOMA terminal by removing its screws, your certification of

technical standard conformance becomes invalid.

Do not use FOMA terminal with its certification of technical standard conformance

invalid as it violates the Radio Law.

・

Be careful when you use FOMA terminal while driving a car etc.

Using a mobile phone while driving is subject to penal regulations.

If you inevitably receive a call, tell the caller that you will "call back" by handsfree,

then park in a safe place and call back.

・

Use FeliCa reader/writer function only in Japan.

FeliCa reader/writer function of FOMA terminal conforms to Japanese radio

standards.

If you use this function overseas, you may be punished.

FeliCa reader/writer

CAUTION

Waterproofness

F-08B is provided with the following waterproofness by firmly

closing the external connection jack cap, installing the back cover

and locking the cover.

・

IPX5 (Former JIS protection code 5)

・

IPX8

that is a higher standard than IPX7 (former JIS protection

code 7)

Code IPX5 means that a phone keeps functioning after directly applying a

jet flow of 12.5 L/min. for at least 3 minutes from a distance of 2.5-3 m on a

rotating turntable.

Code IPX7 means that a phone keeps functioning after it is slowly

submerged to depth of 1 m in static tap water at room temperature, left there

for 30 minutes and then taken out.

Code IPX8 means that it provides waterproofness of which exceeds of IPX7

standard.

F-08B provides the following waterproof performances of IPX8.

･

F-08B keeps functioning after it is slowly submerged to depth of 1.5

m in static tap water at room temperature, left there for 30 minutes

and then taken out.

･

The mobile phone keeps shooting still images or moving pictures in

30 minutes in static tap water at room temperature.

F-08B_EN_FCC

Introduction

✜

What you can do with waterproofness of F-08B

・

You can talk or watch 1Seg programs without using an umbrella in

the rain (for rainfall of 20 mm or less per hour).

- When your hands or FOMA terminal are wet, avoid installing/

removing the back cover or opening/closing the external

connection jack cap.

・

You can also shoot still images and moving pictures in the pool

depth of 1.5 m.

- Do not perform other operations underwater than shooting still

images and moving pictures.

- If you put the terminal in water of swimming pool, be sure to have

it within 30 minutes.

- If FOMA terminal gets wet with water from the swimming pool,

wash it in after-mentioned procedure and drain the water as

predefined (

⇒

P18).

・

You can use FOMA terminal in a bathroom.

- Do not put the terminal in the bathtub. Do not use the terminal in

hot water. Doing so may cause malfunction.

- Never put FOMA terminal in hot spring water or water containing

soap, detergent or bath powder.

・

You can immerse FOMA terminal in static water of wash bowl and

wash dirt out with shaking the terminal.

- Install the back cover and with it locked, holding the external

connection jack cap not to be opened and wash it with your hands

not using brush, sponge, etc.

To ensure waterproofness

To avoid water ingress, be sure to observe the points below.

・

Do not throw any liquid other than room-temperature tap water on

FOMA terminal, or soak it in such liquid.

・

Open/close the external connection jack cap as described below.

Place your finger at groove on the hinge side to open the cap.

Close with the tab for the back cover at the rear side of the cap fitted

into the concave of this terminal. Make sure that the cap is

completely closed without slack.

Groove on the hinge side

Tab on the back

side cover

F-08B_EN_FCC

Introduction

・

Install the back cover as described below.

Align 8 tabs of the back cover with concaves of FOMA terminal.

While pressing the back cover in the direction of

so that there is

no gap between FOMA terminal and back cover, slide the back cover

in the direction of

to install, then slide the back cover lever in the

direction of

to lock.

Make sure that the back cover is completely closed without slack. Slide the

back cover in the direction of the arrow shown on the lever, and then make

sure the cover is securely locked before using.

・

Securely lock the back cover and firmly close the external connection

jack cap. Even a fine obstacle (one hair, one grain of sand, tiny fiber,

etc.) put between contact surfaces may allow water to enter.

・

Do not poke the microphone, earpiece or speaker with a swab or

sharp object.

・

Do not let FOMA terminal fall. It may become scratched causing the

waterproof performance to degrade.

・

The external connection jack cap and the rubber packing of the inner

lid play an important role for keeping waterproof performance. Do

not remove or scratch it. Also, prevent dust from adhering to it.

To keep the FOMA terminal waterproof, replacement of parts is

required every 2 years regardless of whether FOMA terminal appears

normal or abnormal. DOCOMO replaces the parts as a chargeable

service. Bring FOMA terminal to a sales outlet such as a DOCOMO-

specified repair office.

Important precautions

Do not perform actions shown in the illustrations below.

Observe the following precautions to use FOMA terminal properly.

・

Accessories and optional devices are not waterproof. When

watching 1Seg etc. with FOMA terminal installed in the included

desktop holder, do not use it in a bath room, shower room, kitchen

or lavatory even if it is not connected to the AC adapter.

Back cover

Lever

Using Soap/Detergent/

Bath power

Soaking in ocean water

Applying strong water flow Using in hot spring

Soiling with sand/mud

F-08B_EN_FCC

Introduction

・

Do not apply water flow stronger than allowed (

⇒

P15) (e.g., such

water flow that gives you pain when applied to your skin directly

from a faucet or shower). F-08B provides the following waterproof

performances of IPX5. However, it causes malfunction.

・

Do not put FOMA terminal in hot water, use it in a sauna or apply hot

airflow (from a hair dryer etc.) to it.

・

Do not move in water or slam the terminal against the surface of

water with FOMA terminal opened.

・

If you put the terminal in tap water or in water of swimming pool, be

sure to have it within 30 minutes.

・

When you use the terminal in swimming pool, obey rules of the

facility.

・

FOMA terminal does not float on water.

・

Do not leave water on FOMA terminal. May short-circuit the power

jacks, or in a cold region, water may freeze causing malfunction.

・

Do not leave water on the microphone, earpiece or speaker. Such

water may interfere with talking.

・

If the back cover is damaged, replace it. Water may enter inside from

a damaged section causing troubles such as electric shocks or

corrosion of the battery.

・

If FOMA terminal gets wet with water or other liquids with the

external connection jack cap or back cover open, the liquid may get

inside the terminal causing electric shocks or malfunction. Stop

using FOMA terminal, turn the power OFF, remove the battery pack

and contact a DOCOMO-specified repair office.

・

If rubber gasket on the external connection jack cap or inner lid is

damaged or deformed, replace it at DOCOMO-specified repair office.

DOCOMO does not guarantee actual operations under all states.

Malfunctions deemed to be caused by inappropriate operation by the

customer are not covered by the warranty.

When FOMA terminal is wet, water may flow out after wiping it off;

drain the water in the following steps.

Wipe FOMA terminal surface with dry, clean cloth etc.

Draining the water from FOMA terminal

F-08B_EN_FCC

Introduction

Shake FOMA terminal approximately 20 times, firmly holding its

hinge section, until there is no more water splattering.

Softly press dry, clean cloth etc., against FOMA terminal to wipe

off water remaining in the microphone, earpiece, speaker, keys,

hinges or charging jack.

Remove the back cover and wipe off any drops of water around

the inner lid and the rear side of the back cover. Never open the

inner lid. After wiping off the water, install and lock the back

cover.

Removing back cover

⇒

P21

Wipe off water drained from FOMA terminal with dry, clean cloth

etc., and dry naturally.

･

Water, if any, remaining in FOMA terminal may ooze up after

wiping off.

･

Do not wipe off water remaining in concaves directly with a cotton

swab etc.

To drain water off the speaker, shake

FOMA terminal with the speaker upward

Rear side of the back cover

Around the inner lid

F-08B_EN_FCC

Introduction

Check the following before and after charging.

・

Check that FOMA terminal is not wet. Never try to charge the battery

pack when FOMA terminal is wet.

・

Accessories and optional devices are not waterproof.

・

When charging the battery when or after FOMA terminal is wet,

adequately drain it and wipe off water with a dry, clean cloth etc.,

before connecting the included desktop holder or opening the

external connection jack cap.

・

When the external connection jack cap is opened for charging, close

the cap firmly after charging. It is recommended that the desktop

holder be used for charging to prevent water from seeping inside

from the external connection jack.

・

Do not use the AC adapter or desktop holder in a bathroom, shower

room, kitchen, lavatory or other highly humid area. May cause fire or

electric shock.

・

Do not touch the AC adapter or desktop holder with wet hands. May

cause electric shock.

Charging

F-08B_EN_FCC

Basic Operation

Before Using

Attaching UIM (FOMA card)/battery pack

After turning power OFF, close FOMA terminal and hold it in your

hand so that you can properly attach UIM/battery pack.

✜

Removing Back Cover

Slide the lever in the direction of

to unlock, pressing the back cover with a

thumb and slide approximately

●

mm in the direction of

to remove. Pinch

the tab of inner lid and hold it up in the direction of

to open until it stops.

✜

Installing UIM

Pull the tab with your nail and pull out the tray until it clicks (

). Hold

UIM with the IC side down, align the beveled corner with the tray (

)

and push into the tray until it stops (

Point

･

UIM (blue) is not available for this FOMA terminal. If you have the UIM

(blue), bring it to a docomo Shop.

✜

Installing battery pack

With the label side of the battery pack upward, align convex parts of the battery pack

with concave parts of FOMA terminal and slide the battery pack in the direction of

, press the battery pack in the direction of

to set it in and close the inner lid.

✜

Installing back cover

Place the 4 tabs of back cover to the notches, press back cover in the

direction of

to avoid forming any clearance between FOMA

terminal and back cover, then slide it in the direction of

to install it.

Point

･

The inner lid is designed to be closed firmly to maintain waterproofness.

Note that forcibly opening may hurt your nail or finger.

･

To avoid damage by forcible opening, hinge of the inner lid (joint part to

terminal body) is designed to be removed. If it is removed, align the pin metal

of the inner lid with groove of FOMA terminal and push it until it clicks.

Press here with your thumb

Back cover

Lever

Tray

Tab

Corner cut

UIM

Battery pack

Convex parts

Concave parts

Back cover

Lever

F-08B_EN_FCC

Basic Operation

Before Using

Charging

The battery pack does not have a full charge at time of purchase.

Use AC adapter for FOMA terminal to charge the battery before

using FOMA terminal.

Insert the AC adapter to the attached desktop holder,

with the arrow on the AC adapters connector upward.

Unfold the AC adapters power plug and insert it into a

100V AC outlet.

With FOMA terminal closed, insert it into the desktop holder.

Check that the light turns on.

After charging is completed, remove FOMA terminal

from the desktop holder.

Open jack cap (

) of FOMA terminal, hold the

connector horizontally with the arrow side upward and

insert it to the jack. (

)

Unfold the power plug and insert it into a 100V AC

outlet.

Check that the light turns on.

When charging is over, pull out the power plug from

the outlet, and pull out from FOMA terminal

horizontally while pressing the release buttons on both

sides of the connector.

✜

Operations for charging

When charging starts, a charge start alert sounds. While charging, the

light turns on and the battery icons on the display and the sub-display

blink. When charging is over, a charge completion alert sounds.

Using desktop holder and AC adapter in

combination for charging

100V AC outlet

Light

Release

buttons

Connector

Desktop holder

Insert at the back side

AC adapter

Power plug

Charging using AC adapter

Connector

Release buttons

External

connection

jackJack cap

Power plug

AC adapter

100V AC outlet

Light

F-08B_EN_FCC

Basic Operation

Before Using

Turning power ON - Configuring default setting

Perform the following operations after turning the power ON for

the first time.

(2 sec. or more)

"Yes" or "No" on a confirmation

screen of enlarged menu setting

The screen shown to the right appears.

Set required items

[Complete]

Always set Change security code and

Request permit/deny. If you exit without

setting, Initial setting screen reappears

when the power is turned ON the next

time.

on a confirmation screen of software update

function

The stand-by display appears.

Point

･

If no operation is performed, the display light is turned off automatically

according to the settings in Light time-out or Power saver setting. The

display light turns on again if there is any operation or incoming call.

Turning power off :

(2 sec. or more)

Changing the initial setting :

mehgeg

Changing screen display to English :

mehbfce

Select "English"

Before Using

User information

Check your own phone number.

For details of checking/changing a mail address, refer to "Mobile

Phone User's Guide [i-mode] FOMA version".

ame0

User information

The screen shown to the right appears.

Point

Editing user information :

On User information edit screen,

Authenticate

Edit

Checking a phone number during a call :

se0

<User information

screen>

F-08B_EN_FCC

Basic Operation

Screen Explanation

Viewing display

The current state can be checked by the icon appearing on the screen. Major icons are as follows.

Battery level (Battery icon)

Signal strength (Antenna icon)

Self mode ON

In data transfer mode

Connecting to i-mode

Infrared communication in operation

The total calls cost exceeds the limit

Communication using handsfree-

compatible device in progress

Handsfree ON

eco mode ON

Lock on close or Lock when immobile

Kid-safe mode ON

A phonebook entry or schedule has

secret attribute

High-pitched alarm ON

Unread Area Mail exists

Unread i-mode mail exists

Arrival i-concier information exists

Unreceived i-mode mail exists in i-

mode Center

Displaying SSL/TLS page etc.

Auto-send mail exists

Music&Video Channel program

obtaining reservation exists

During i-

ppli operation

ppli call exists

Alarm clock ON

Schedule reminder ON

Inside OFFICEED area

Top of the display

Ample

charge

Almost exhausted

(Charge the battery)

Strong

Out of service area or where

radio waves do not reach

Weak

Arrival information (Starting from the left,

missed call, recorded message, voice mail

service, unread message, unread ToruCa,

ppli call)

Silent mode ON

Call alert volume OFF

Vibrator for voice call ON

In Public mode (Drive mode)

Record message ON

Keypad dial lock ON

Personal data lock ON

Music&Video Channel program

obtaining failure

Reading UIM

IC card lock ON

Available multi-cursor key

Performing 1Seg recording reservation

ppli Auto start failed

microSD card installed during

Communication mode

Connected to external device using

USB cable

Pedometer/ACT monitor is set

Software update rewrite notice

Auto-update of latest pattern definition

failure

Bottom of the display

F-08B_EN_FCC

Basic Operation

Task area

The icon indicating the function

(task) in progress appears in the

task area.

Guide area and key operation

Operations that can be performed

by pressing

and

are displayed in the

guide area. To perform an

operation in the guide area, press

the corresponding key.

on the guide area corresponds

to multi-cursor keys

Task area

Guide area

Screen Explanation

Viewing sub-display and light

Even when FOMA terminal is closed, the

icons in the sub-display and light provide

information. When no operation is

performed for a certain period of time, the

sub-display light is turned off, but it turns on again when you press

either side key.

✜

Switching views

Each time you press

, the view switches in the order of icon and

clock

⇒

date and clock

⇒

big clock. When "Use" is set to Set

Pedometer/Activity monitor, each time you press

, the view switches

in the order of steps

⇒

activity

⇒

clock.

✜

Arrival information

When a missed call, recorded message, unread message, or voice

message of Voice Mail service, etc. exists, press

with clock

displayed to display the number of calls or messages, and then press

to scroll reception date/time and information about the senders.

✜

Light

The light turns on or blinks when the battery charges, the camera is

activated, light alert (

⇒

P39) is set, etc.

･

The light on the sub-display turns on just by tilting FOMA terminal.

【背面自動点灯設定

(Auto light on)

】

Information

F-08B_EN_FCC

Basic Operation

Screen Explanation

Menu operation

On the stand-by display, press

and then perform the

functions from the menu. You can select a menu item with

shortcut operations, which use the keypad,

and

, or with

multi-cursor operation, which uses the multi-cursor key to move

the cursor.

<Example> Selecting "Calculator"

Shortcut operations

ame7e4

Multi-cursor key operations

ame

Move the cursor to "

Accessory"

[Select]

Move the cursor to "

Calculator"

[Select]

Point

･

Even when a function is running, you can perform the same operation if

"MENU" is displayed on the guide area.

･

To return to the previous screen, press

. To return to the stand-by

display, press

･

On the stand-by display with Info/calendar layout, Shortcut icons set, or

with arrival information icon or i-concier information displayed, press

to change the display to Focus mode that allows you to quickly display the

related information.

You can switch among "Kisekae menu", the design of which can be

changed using Kisekae Tool (

⇒

P39), "Basic menu", which has the

fixed menu numbers, and "Custom menu", to which menu items

can be saved freely.

A Kisekae menu matched with the color of FOMA terminal is set by

default.

Point

･

In some types of Kisekae menus, the menu structure is changed according

to usage frequency, or the number assigned to menu item (item number)

may not be applicable.

･

The menu that appears when

is pressed on the stand-by display can

be changed from the start menu.

⇒

P35

m 7 4

Switching menu screens

F-08B_EN_FCC

Basic Operation

Screen Explanation

Motion sensor

You can operate FOMA terminal by double-tapping (tapping it

twice) or tilting it.

✜

Stopping an alarm/displaying details of arrival

information

When FOMA terminal is closed and the alarm sounds, double-tapping

the front or back side stops the alarm. When the clock is displayed on

the sub-display, double-tapping the side displays details of arrival

information.

✜

Tilting FOMA terminal

Tilting FOMA terminal while pressing and holding

when

Browser screen is displayed scrolls the screen or switches the

orientation of view for the clock on the sub-display.

ameh

Settings & NW service

Clock &

Other

Motion sensor

ON or

OFF

Setting Motion sensor

Front

Side

Back

Side

Screen Explanation

使いかたガイド

(Guide)

You can check overviews and operations of functions, and

troubleshooting. (In Japanese only)

amef

LifeKit

Guide

Select

a search method

(Contents) :

Search from a list of

functions.

索引

(Index) :

Search from a list of words

sorted according to Japanese syllabary.

フリーワード検索

(Free word search) :

Enter a keyword to search for.

ブックマーク

(Bookmark) :

Search from a

list of registered bookmarks.

困ったときには

(Troubleshooting) :

Search from lists of

troubles or error messages.

Point

･

On a description screen, select "

この機能を使う

(Use this function)" to

perform a function. Selecting a link item in "

関連機能

(related functions)",

or "

→コチラ

(See more)" displays a corresponding description screen.

･

Terms indicated with

【】

in this manual are index terms in "Guide".

･

You can also access

フリーワード検索

from

クイック検索

⇒

P104

Information

F-08B_EN_FCC

Basic Operation

You can notify your phone number (caller ID) to the other party's

terminal when making a voice call.

ameh

Settings & NWservices

NW Services

Caller ID

Caller ID notification

Activate/

Deactivate

Notify

Select "

Not notify" if you do not want to inform.

Point

･

Caller ID is your important personal information. Carefully consider

whether you want to include caller ID information when making a call.

･

If an announcement of requesting caller ID is heard when making a call,

make a call again after setting Caller ID notification or adding prefix "186".

Caller ID notification

(At subscription : Notify)

F-08B_EN_FCC

132

Others

Appendix

Specific absorption rate (SAR) of mobile phone

This model phone FOMA F-08B meets the MIC's

technical regulation

governing exposure to radio waves.

The technical regulation established permitted levels of radio frequency

energy, based on standards that were developed by independent scientific

organizations through periodic and thorough evaluation of scientific studies.

The regulation employs a unit of measurement known as the Specific

Absorption Rate, or SAR. The SAR limit is 2 watts/kilogram (W/kg)

averaged

over 10 grams of tissue. The limit includes a substantial safety margin designed

to assure the safety of all persons, regardless of age and health. The value of

the limit is equal to the international guidelines recommended by ICNIRP.

All phone models should be confirmed to comply with the regulation, before

they are available for sale to the public. The highest SAR value for this FOMA

F-08B is 1.440 W/kg. It was taken by the Telecom Engineering Center (TELEC).

The test for SAR was conducted according to the MIC testing procedure using

standard operating positions with the phone transmitting at its highest

permitted power level in all tested frequency bands. While there may be

differences between the SAR levels of various phones and at various positions,

they all meet the MIC's technical regulation. Although the SAR is determined at

the highest certified power level, the actual SAR of the phone during operation

can be well below the maximum value.

For further information about SAR, please see the websites below.

World Health Organization (WHO) :

http://www.who.int/peh-emf/en/

ICNIRP :

http://www.icnirp.de/

MIC :

http://www.tele.soumu.go.jp/e/sys/ele/index.htm

TELEC :

http://www.telec.or.jp/ENG/Index_e.htm

NTT DOCOMO :

http://www.nttdocomo.co.jp/english/product/sar/

FUJITSU LIMITED :

http://www.fmworld.net/product/phone/sar/

Ministry of Internal Affairs and Communications.

The technical regulation is provided in Article 14-2 of the Ministry Ordinance

Regulating Radio Equipment.

International Commission on Non-Ionizing Radiation Protection.

The product "F-08B" is declared to conform with the essential requirements of

European Union Directive 1999/5/EC Radio and Telecommunications Terminal

Equipment Directive 3.1(a), 3.1(b) and 3.2.The Declaration of Conformity can be

found on http://www.fmworld.net/product/phone/doc/.

This mobile phone complies with the EU requirements for exposure to radio

waves.

Your mobile phone is a radio transceiver, designed and manufactured not to

exceed the SAR

limits

for exposure to radio-frequency(RF) energy, which

SAR

value, when tested for compliance against the standard was 1.410W/Kg.

While there may be differences between the SAR

levels of various phones and

at various positions, they all meet

***

the EU requirements for RF exposure.

* The exposure standard for mobile phones employs a unit of measurement

known as the Specific Absorption Rate, or SAR.

** The SAR limit for mobile phones used by the public is 2.0 watts/kilogram (W/

Kg) averaged over ten grams of tissue, recommended by The Council of the

European Union. The limit incorporates a substantial margin of safety to give

additional protection for the public and to account for any variations in

measurements.

*** Tests for SAR have been conducted using standard operation positions with

the phone transmitting at its highest certified power level in all tested

frequency bands. Although the SAR is determined at the highest certified

power level, the actual SAR level of the phone while operating can be well

below the maximum value. This is because the phone is designed to operate

at multiple power levels so as to use only the power required to reach the

network. In general, the closer you are to a base station antenna, the lower the

power output.

Declaration of Conformity

F-08B_EN_FCC

133

Others

･

This device complies with part 15 of the FCC rules.

Operation is subject to the following two conditions :

this device may not cause harmful interference, and

this device must accept any interference received, including interference

that may cause undesired operation.

･

Changes or modifications made in or to the radio phone, not expressly

approved by the manufacturer, will void the user's authority to operate the

equipment.

This model phone meets the U.S. Government's requirements for exposure to

radio waves.

This model phone contains a radio transmitter and receiver. This model phone

is designed and manufactured not to exceed the emission limits for exposure

to radio frequency (RF) energy as set by the FCC of the U.S. Government. These

limits are part of comprehensive guidelines and establish permitted levels of RF

energy for the general population. The guidelines are based on standards that

were developed by independent scientific organizations through periodic and

thorough evaluation of scientific studies.

The exposure standard for wireless mobile phones employs a unit of

measurement known as the Specific Absorption Rate (SAR). The SAR limit set

by the FCC is 1.6 W/kg. Tests for SAR are conducted using standard operating

positions as accepted by the FCC with the phone transmitting at its highest

certified power level in all tested frequency bands. Although the SAR is

determined at the highest certified power level, the actual SAR level of the

phone while operating can be well below the maximum value. This is because

the phone is designed to operate at multiple power levels so as to use only the

power required to reach the network. In general, the closer you are to a wireless

base station antenna, the lower the power output level of the phone.

Before a phone model is available for sale to the public, it must be tested and

certified to prove to the FCC that it does not exceed the limit established by the

U.S. government-adopted requirement for safe exposure. The tests are

performed on position and locations (for example, at the ear and worn on the

body) as required by FCC for each model. The highest SAR value for this model

phone as reported to the FCC, when tested for use at the ear, is 0.854W/kg, and

when worn on the body, is 0.821W/kg. (Body-worn measurements differ

among phone models, depending upon available accessories and FCC

requirements).

While there may be differences between the SAR levels of various phones and

at various positions, they all meet the U.S. government requirements.

The FCC has granted an Equipment Authorization for this model phone with all

reported SAR levels evaluated as in compliance with the FCC RF exposure

guidelines. SAR information on this model phone is on file with the FCC and

can be found under the Equipment Authorization Search section at http://

www.fcc.gov/oet/ea/fccid/ (please search on FCC ID VQK-F08B).

For body worn operation, this phone has been tested and meets the FCC RF

exposure guidelines when used with an accessory designated for this product

or when used with an accessory that contains no metal and which positions the

handset at a minimum distance of 1.5 cm from the body.

In the United States, the SAR limit for wireless mobile phones used by the general public

is 1.6 Watts/kg (W/kg), averaged over one gram of tissue. SAR values may vary

depending upon national reporting requirements and the network band.

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not

occur in a particular installation.

Federal Communications Commission

(FCC) Notice

FCC RF Exposure Information

F-08B_EN_FCC

134

Others

If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the

following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

AIRCRAFT

Switch off your wireless device when boarding an aircraft or whenever you are

instructed to do so by airline staff. If your device offers flight mode or similar

feature consult airline staff as to whether it can be used on board.

DRIVING

Full attention should be given to driving at all times and local laws and

regulations restricting the use of wireless devices while driving must be

observed.

HOSPITALS

Mobile phones should be switched off wherever you are requested to do so in

hospitals, clinics or health care facilities. These requests are designed to

prevent possible interference with sensitive medical equipment.

PETROL STATIONS

Obey all posted signs with respect to the use of wireless devices or other radio

equipment in locations with flammable material and chemicals. Switch off your

wireless device whenever you are instructed to do so by authorized staff.

INTERFERENCE

Care must be taken when using the phone in close proximity to personal

medical devices, such as pacemakers and hearing aids.

Pacemakers

Pacemaker manufacturers recommend that a minimum separation of 15 cm be

maintained between a mobile phone and a pace maker to avoid potential

interference with the pacemaker. To achieve this use the phone on the opposite

ear to your pacemaker and does not carry it in a breast pocket.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the

event of such interference, you may want to consult your hearing aid

manufacturer to discuss alternatives.

For other Medical Devices :

Please consult your physician and the device manufacturer to determine if

operation of your phone may interfere with the operation of your medical

device.

Important Safety Information

F-08B_EN_FCC

135

Others

Appendix

Export Administration Regulations

This product and its accessories may be under coverage of the Export

Administration Regulations of Japan ("Foreign Exchange and Foreign Trade

Control Laws" and the related laws and regulations). And, they are also under

coverage of Export Administration Regulations of the U.S. When exporting

and reexporting this product and its accessories, take necessary procedures

on your responsibility and expense. For details, contact Ministry of Economy,

Trade and Industry of Japan or US Department of Commerce.

Appendix

Intellectual Property Right

Except for the case protected by copyright laws such as personal use, use of

FOMA terminal to reproduce, alter, or publicly transmit recorded pictures or

sounds, or copyrighted text, images, music or software downloaded from

websites without the copyright holder's authorization is prohibited.

Note that taking photos or recordings at some demonstrations, performances

or exhibitions may be prohibited even when only for personal use.

Avoid taking pictures of others with FOMA terminal without their consent or

disclosing recorded pictures of others without their consent to general public

through Internet websites etc., because they may infringe on portrait rights.

Company and product names mentioned in this manual are trademarks or

registered trademarks of their respective holders.

･

"FOMA", "i-mode", "i-

ppli", "i-motion", "Deco-mail", "Chara-den", "ToruCa",

"mopera", "WORLD CALL", "DCMX", "WORLD WING", "OFFICEED", "2in1",

"docomo STYLE series" and logos of "FOMA", "i-mode", "i-

ppli",

"Music&Video Channel", "DCMX", "iD" and "iC" are trademarks or registered

trademarks of NTT DOCOMO.

･

"Catch Phone (Call Waiting Service)" is a registered trademark of Nippon

Telegraph and Telephone Corporation.

･

Free Dial logo mark is a registered trademark of NTT Communications

Corporation.

･

McAfee

is registered trademarks or trademarks of McAfee, Inc. and/or its

affiliates in the US and/or other countries.

･

G-GUIDE, G-GUIDE MOBILE and their logos are registered

trademarks in Japan of U.S. Gemstar-TV Guide International, Inc.

and/or its affiliates.

Copyrights and portrait rights

Trademarks

F-08B_EN_FCC

136

Others

･

This product contains Adobe

Flash

Lite

and Adobe Reader

technology of Adobe Systems Incorporated.

Adobe Flash Lite Copyright

2003-2010 Adobe Systems Incorporated. All

rights reserved.

Adobe Reader Mobile Copyright

1993-2010 Adobe Systems Incorporated.

Adobe, Adobe Reader, Flash and Flash Lite are either

registered trademarks or trademarks of Adobe Systems

Incorporated in the United States and/or other countries.

･

This product contains NetFront Browser,

NetFront Sync Client of ACCESS CO., LTD.

ACCESS, the ACCESS logo and NetFront are trademarks or registered

trademarks of ACCESS CO., LTD. in the United States, Japan and/or other

countries.

･

™

rights reserved.

JBlend and JBlend-related trademarks are trademarks or registered

trademarks of Aplix Corporation in Japan and other countries.

･

is a registered trademark of FeliCa Networks, Inc.

･

FeliCa is a registered trademark of Sony Corporation.

･

QR code is a registered trademark of Denso Wave Inc.

･

microSDHC logo is a trademark of D-3C,LLC.

･

"Multitask" is a registered trademark of NEC Corporation.

･

QuickTime is a registered trademark of Apple Inc. in the US and other

countries.

･

Microsoft

, Windows

, Windows Vista

, Windows Media

and

PowerPoint

are trademarks or registered trademarks of "Microsoft

Corporation" in the US and other countries.

･

The abbreviations of operating systems (Japanese versions) below are used

in this manual.

- Windows 7 stands for Microsoft

Windows

7(Starter, Home Basic, Home

Premium, Professional, Enterprise Ultimate).

- Windows Vista stands for Windows Vista

(Home Basic, Home Premium,

Business, Enterprise and Ultimate).

- Windows XP indicates the Microsoft

Windows

XP Professional

operating system or Microsoft

Windows

XP Home Edition operating

system.

･

Google is registered trademark of Google Inc.

･

"CROSS YOU" is a trademark of Sony Corporation.

･

Manufactured under license from Dolby Laboratories. Dolby and the double-

D symbol are trademarks of Dolby Laboratories.

･

ATOK + APOT of Justsystem Corporation is installed in this product as

Japanese character conversion function.

"ATOK" "APOT (Advanced Prediction Optimization Technology)" are

registered trademarks of Justsystem Corporation.

･

This equipment is provided with the software licensed by Symbian Software

Ltd. or the licensor

1998-2010. and Symbian OS are trademarks of

Symbian Ltd. or the licensor.

･

"Privacy mode" is a registered trademark of FUJITSU LIMITED.

･

"Uni-Type" is a registered trademark of LIM Corp., Ltd.

･

FrameSolid is the registered trademark of Morpho, Inc. in Japan and other

countries.

･

The auto object tracking technology utilized is TrackSolid

™

, a product of

Morpho, Inc. TrackSolid

™

is trademark of Morpho, Inc.

･

ズーキーパー

(Zookeeper) is a trademark or registered trademark of

KITERETSU Inc.

･

日英版しゃべって翻訳

for F (J-E Speech Translation for F)" is trademark of

ATR-Trek.

･

Other company and product names mentioned in this manual are

trademarks or registered trademarks of their respective holders.

F-08B_EN_FCC

137

Others

･

FeliCa is a contactless IC card technology developed by Sony Corporation.

･

This product contains a module developed by the Independent JPEG Group.

･

The image interpolation technology utilized is FrameSolid, a product of

Morpho, Inc.

･

This product is equipped with the technologies of GestureTek, Inc.

･

学研モバイル国語辞典

(Gakken Mobile JpnDic)", "

学研モバイル和英辞典

(Gakken Mobile JE Dic)", "

学研モバイル英和辞典

(Gakken Mobile EJ Dic)", "

今

日は何の日

(Today's trivia)" and "

今日の歴史

(Today in history)" are

copyrighted by GAKKEN CO., LTD.

･

This product is licensed based on MPEG-4 Visual Patent Portfolio License.

The use of MPEG-4 Video Codec function is allowed for personal and

nonprofit use only in the cases below.

- Recording moving pictures and i-motion that conform to MPEG-4 Visual

Standard (hereinafter referred to as MPEG-4 Video)

- Playing MPEG-4 Videos recorded personally by consumers not engaged in

profit activities

- Playing MPEG-4 Video supplied from the provider licensed from MPEG-LA

For further utilizing such as promotion, in-house use or profit-making

business, please contact MPEG LA, LLC in U.S.

･

Content owners use Windows Media digital rights management technology

(WMDRM) to protect their intellectual property, including copyrights. This

device uses WMDRM software to access WMDRM-protected content. If the

WMDRM software fails to protect the content, content owners may ask

Microsoft to revoke the software's ability to use WMDRM to play or copy

protected content. Revocation does not affect unprotected content. When

downloading licenses for protected content, you agree that Microsoft may

include a "Revocation List" with the licenses. Content owners may require

you to upgrade WMDRM to access their content. If you decline an upgrade,

you cannot access a content that requires the upgrade.

Others

* Available from mobile phones and PHSs.

(including non-DOCOMO phones).

* Unavailable from part of IP phones.

* Unavailable from land-line phones, etc.

Repairs

■

From DOCOMO mobile phones

(In Japanese only)

■

From land-line phones

(In Japanese only)

0120-800-000

(toll free)

(No prefix)

151

(toll free)

●

Please confirm the phone number before you dial.

●

For Applications or Repairs and After-Sales Service, please contact the above-mentioned information center or the docomo shop etc. near you on the NTT DOCOMO website or the i-mode site.

NTT DOCOMO website http://www.nttdocomo.co.jp/english/ i-mode site iMenu⇒お客様サポート (user support)⇒ドコモショップ (docomo Shop) * In Japanese only

* Service available in: English, Portuguese, Chinese, Spanish, Korean.

* Available from mobile phones and PHSs (including non-DOCOMO phones).

* Unavailable from part of IP phones.

General Inquiries <docomo Information Center>

0120-005-250 (toll free)

* You are charged a call fee to Japan when calling from a land-line phone, etc.

※If you use F-08B, you should dial the number ＋81-3-6832-6600 (to enter '＋',

press and hold the '0' key for at least one second).

* You are charged a call fee to Japan when calling from a land-line phone, etc.

※If you use F-08B, you should dial the number ＋81-3-6718-1414 (to enter '＋',

press and hold the '0' key for at least one second).

Loss or theft of FOMA terminal or payment of cumulative cost overseas

(available 24 hours a day)

■

From DOCOMO mobile phones

(available 24 hours a day)

■

From DOCOMO mobile phones

International call access code

for the country you stay

■

From land-line phones <Universal number>

International prefix number

for the universal number

■

From land-line phones <Universal number>

-81-3-6832-6600* (toll free) International call access code

for the country you stay -81-3-6718-1414* (toll free)

-8000120-0151*International prefix number

for the universal number -8005931-8600*

Don't forget your mobile phone ･･･ or your manners!

When using your mobile phone in a public place, don't forget to

show common courtesy and consideration for others around you.

■

From DOCOMO mobile phones

(In Japanese only)

■

From land-line phones

(In Japanese only)

0120-800-000

(toll free)

(No prefix)

113

(toll free)

* Unavailable from land-line phones, etc.

* Available from mobile phones and PHSs.

(including non-DOCOMO phones).

* Unavailable from part of IP phones.

●

If you lose your FOMA terminal or have it stolen, immediately take the steps necessary for suspending the use of the FOMA terminal.

●

If the FOMA terminal you purchased is damaged, bring your FOMA terminal to a repair counter specified by DOCOMO after returning to Japan.

You might be charged a domestic call fee according to the call rate for the country you stay.

※

For international call access codes for major countries/international prefix numbers

for the universal number, refer to DOCOMO International Services website.

You might be charged a domestic call fee according to the call rate for the country you stay.

※

For international call access codes for major countries/international prefix numbers

for the universal number, refer to DOCOMO International Services website.

Failures encountered overseas

CA92002-XXXX

2010.X (1st Edition)

To prevent damage to the environment,

bring used battery packs to a docomo

service counter, a docomo agent or a

recycle center.

(Business hours : 9:00 a.m. to 9:00 p.m.) (Business hours : 24 hours (open all year round)

(Business hours : 9:00 a.m. to 8:00 p.m.)

Fujitsu F08B Mobile Phone User Manual L01

Fujitsu Limited Mobile Phone L01

Contents

user manual3

Navigation menu

Namespaces

Views

Navigation
