User Manual Addendum
MDS 05-2708A01, Rev. A Page 1 of 2
MDS iNET 900 Transceiver
ADDENDUM
Addendum to MDS 05-2806A01, Rev. A July 1, 2002
Microwave Data Systems Inc., 175 Science Parkway, Rochester, NY 14620 U.S.A.
General Business +1 (585) 242-9600, FAX +1 (585) 242-9620
This addendum contains corrections and additions to the MDS iNET 900 User’s Guide (MDS P/N 05-2806A01,
Rev. A) published in March 2002. The Bolded text below indicates new or revised material. You may wish to
make these pen & ink changes directly to your manual or include a reference to this addendum in the appropriate
sections.
ITEM 1—RF Exposure Notice, Page vii
The following statement replaces the text under RF Exposure notice on Page vii:
The radio equipment described in this guide emits radio frequency energy. Although the power level is low, the
concentrated energy from a directional antenna system may pose a health hazard. Do not allow people to come
closer than 23 centimeters (9.05 inches) to the antenna when the transmitter is operating in indoor or outdoor
environments. More information on RF exposure is available at www.fcc.gov/oet/info/documents/bulletins.
ITEM 2—Approvals, Page vii
UL approval has been granted to the iNET transceiver, provided it is used with an MDS-supplied locking DC
power connector. Contact MDS for additional information or upgrade instructions.
ITEM 3—Internal Fuse Replacement, Page 111
Reverse polarity will not cause the transceiver’s fuse to blow.
ITEM 4— Antenna Feedline Selection, Pages 101-104
When using RG-214 feedline with an MDS-supplied omni-directional antenna, the following cable lengths and
appropriate cable loss must be adhered to maintain compliance with the FCC maximum limit of +36dBi.
Example, a 3 meter length of RG-214 will loose 1 dB at 928Mhz, thus the 5dBd (7dBi) antenna tested for this
application was 3.1 meters.
Antenna spec.(dBd) Antenna Gain (dBi) Minimum Cable Loss (dB) Max +36dBi
Unity 2.15 1.0 (3 meters) +31.15dBi
3 dBd 5.15 1.0 (3 meters) +34.15dBi
5 dBd 7.15 1.2 (3.1 meters) +35.95dBi
In no case shall the user allow the EIRP of the iNET installation to exceed 36 dBm.
Check with MDS for the status on additional antenna/feedline approvals that are pending.
End of Document
