User Manual
![](/img.php?id=837089&img=bg1.png)
MOTOROLA and the Stylized M Logo are registered in the US
Patent & Trademark Office. The use of wireless devices and their
accessories may be prohibited or restricted in certain areas.
Always obey the laws and regulations on the use of these
products. The Bluetooth trademarks are owned by their
proprietor and used by Motorola, Inc. under license. All other
product or service names are the property of their respective
owners.
© Motorola, Inc. 2007.
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
1-877-MOTOBLU
1-888-390-6456 (TTY/TDD United States for
hearing impaired)
Guide Number: 680xxxxAxx-O
Bluetooth ID: xxxxxxx
Volume
Buttons
Boom
Multi-Color
Indicator Light
Call
Button
Microphone
Speaker
(on reverse
side)
Indicator Light
(steadily blue
for pairing mode)
BEFORE YOU
BEGIN
Before using this product, read the Important Safety and
Legal Information pamphlet and follow its instructions.
Take a moment before you get started to
familiarize yourself with your new
H710 Headset.
1
Charge your headset's battery for 2 hours:
Plug the Motorola charger into the end of
the headset.
The indicator light turns red when the
battery is charging. It may take up to 1
minute for the indicator light to turn on.
When the headset's battery is fully charged
(about 2 hours), the indicator light turns
green.
Disconnect the charger.
1
2
CHARGE YOUR
HEADSET
Note: Headset is not functional while charging.
2
START BLUETOOTH
FEATURE
Your Phone
Press (Menu) > Settings > Connection >
Bluetooth Link > Setup.
Scroll to Power.
Select Change.
Scroll to On.
Press Select to turn on the Bluetooth
feature. The Bluetooth feature remains on
until you turn the feature off.
Note: These steps are for most Motorola phones.
For other phones, see your phone's user's guide.
1
2
3
4
5
Your phone's Bluetooth feature is off by default.
To use your headset, you must turn on the
Bluetooth feature in your phone.
For most Motorola phones (at the main menu):
M
3
PAIR
Your Headset and Phone
Before you can use your headset, you must pair
(link) it with your phone.
Step A - ENSURE HEADSET IS IN PAIRING
MODE
Power on headset by opening the headset
boom to initiate easy pairing. After a few
moments, the indicator light will be steadily lit
in blue to indicate headset is in pairing mode.
If the headset does not enter pairing mode,
see TROUBLESHOOTING for help.
Step B - SET YOUR PHONE TO LOOK FOR
YOUR HEADSET
3
4
5
1
2
For most Motorola phones:
On your Motorola phone, press (Menu) >
Settings > Connection > Bluetooth Link >
Handsfree > Look for Devices.
The phone lists Bluetooth devices it finds.
Select Motorola H710.
Select OK or Yes to pair your headset with
your phone.
Enter the passkey: 0000
Select OK.
When your headset successfully pairs with
your phone, the indicator light flashes purple
and blue.
Note: These steps are for most Motorola phones.
For other phones, see your phone's user's guide.
M
Your phone and headset are now paired and
ready to make and receive calls. To confirm they
are operating properly, make a call:
TEST AND USE
Place the headset over your ear.
On the phone, dial the number you want to
call and press SEND key on your phone.
If your phone and headset are successfully
paired, you will hear ringing on the headset.
4
1
2
3
After you have successfully paired your phone
and headset, you don't need to repeat these
steps. For daily use, ensure that your headset is
turned ON and that your phone's Bluetooth
feature is ON.
To save battery power, turn OFF the headset
when you don't use it for an extended time by
closing the boom.
USING YOUR H710
See
Features and
Functions Guide
on the reverse side
for information on
using your H710
TROUBLESHOOTING
My headset will not enter pairing mode.
Make sure that any devices previously paired with
the headset are turned off. If the indicator light is
flashing in blue, first turn off the other device,
then close and reopen the headset boom. The
indicator light becomes steadily lit in blue
indicating the headset is now in pairing mode.
My phone doesn't find my headset.
Make sure the indicator light on your headset is
on (lit in blue) and steady when your phone is
searching for devices (see step ).
My headset worked before but now it's not
working.
Make sure your phone is on and the Bluetooth
feature is turned on in your phone (see step ).
If the Bluetooth feature was turned off or was
turned on only temporarily, you may need to
restart the Bluetooth feature (see step ) and
pair your phone and headset again (see step ).
Support.
If you need more help, contact us at
1-877-MOTOBLU or visit us at
www.hellomoto.com//Bluetoothsupport
USING A SECOND PHONE?
Your headset allows a simultaneous, multipoint
connection to two Bluetooth phones.
To pair a second phone to your headset, follow
these steps:
Turn off any phones already paired with your
headset.
Turn off your headset by closing the headset
boom.
Perform Step 2 (“Start Bluetooth Feature”),
Step 3 (”Pair”), and Step 4 (”Test and Use”)
to pair your headset with your second
phone.
To connect to both phones, turn on first
phone.
Close the headset boom and then re-open
it. The headset automatically connects to
both phones.
1
2
3
4
PAIR CONTINUED
Your Headset and Phone
Use the following tips when operating the
headset while connected to two phones:
The most recently paired device connected
to the headset is labeled the primary phone
(the other phone is labeled the Secondary
phone).
Incoming calls can be answered from both
phones. When answering a call, the idle
phone is disconnected from the headset.
When the call ends, connection to idle phone
is automatically reestablished.
Voice dial calls can be made from either
phone. Use different key actions to select
which phone to make a voice dial call (see
“Making Calls” for details).
Redialing a last call dials the number on the
phone with the last outgoing call.
●
●
●
●
TIPS FOR USING HEADSET
WITH TWO PHONES
5
3
3
2
2
DRAFT
DRAFT
![](/img.php?id=837089&img=bg2.png)
Multi-Color
Indicator Light Volume
Buttons
Call
Button
IMPORTANT:
Be sure to first follow the
Quick Start Guide
on the reverse side
of this guide
to complete initial setup
of your H710.
Features and
Functions Guide
TURNING HEADSET
ON AND OFF
To turn your headset on, open the headset
boom. The indicator light flashes blue (if
connected with a device) or is steadilly lit (if
ready to be paired).
To turn your headset off, close the
headset boom. The indicator light will turn
off.
WEARING THE HEADSET
Open the headset boom, then open the
earhook.
Loop the earhook over your ear.
Press the headset to your ear.
Point the headset boom towards your
mouth.
1
2
3
4
CHANGING VOLUME
BUTTON ORIENTATION
You can also change the orientation of the
volume buttons on your headset.
Turn the headset power off.
Press and hold down the desired
"volume up" button and open the boom.
Keep the button held down until the
indicator light flashes blue three times.
1
2
• The essential requirements and
other relevant provisions of Directive
1999/5/EC.
• All other relevant EU Directives.
European Union Directives
Conformance Statement
Product
Approval
Number
The above gives an example of a typical Product
Approval Number.
You can view your product’s Declaration of Conformity
(DoC) to Directive 1999/5/EC (to R&TTE Directive) at
www.motorola.com/rtte. To find your DoC, enter the
product Approval Number from your product’s label in
the “Search” bar on the web site.
Hereby, Motorola declares that this
product is in compliance with:
MAKING CALLS
Note: Your H710 supports both Handsfree and Headset
Profiles. Accessing call functions depends upon which
profile your phone supports. See your phone's user's guide
for more information.
Function Action
Make a voice dial call Tap the Call button
(Primary phone) and speak the
name after the tone
Make a voice dial call Tap the Call button
(Secondary phone) and either Voume
button and speak the
name after the tone
End a call Tap the Call button
Answer a call Open headset boom
or tap the Call button
(if boom is already
open)
Ignore a call Press and hold the
Call button until you
hear a beep
MAKING CALLS CONTINUED
Function Action
Redial last call Press and hold the
Call button until you
hear a beep
Answer a second Press and hold the
incoming call Call button (places
first call on hold)
Reject second incoming Press and hold either
call Volume button until
you hear a beep
Transfer a call from the Press both Volume
headset to the phone buttons and Call
button
Disable the Press and hold
indicator light both Volume
buttons while
powering on headset
Mute or unmute a call Tap both Volume
buttons
Note: Some features are phone/network dependent.
CHANGING FOR USE
ON OTHER EAR
Open the headset boom,
then open the earhook
(90
°
from the headset).
Gently lift and pull the
top of the earhook up
and off the upper hinge
pin. Then, pull it away to
remove it.
Flip the headset over.
Hook the bottom of the
earhook onto the lower
hinge pin, then lift and
pull the top of the
earhook over the upper
hinge pin.
1
2
3
4
You can wear your H710 headset on your left or
right ear. The headset comes ready for the right
ear. To change the headset for the left ear:
1Open Earhook
2Pull Earhook
Up
Hinge
Pin
INDICATOR LIGHT
With the Charger Plugged In
Headset Indicator Headset Status
Red Charging (battery
level less than 80%
charge)
Yellow Charging (battery
level more than 80%
charge)
Green Charging complete
When Checking Battery Level
Headset Indicator Headset Status
Red Battery at less than
10% charge
Yellow Battery between
10% and 80% charge
Green Battery at more than
80% charge
With No Charger Plugged In
Headset Indicator Headset Status
Off Power off
Three blue flashes Powering on/off
Steady blue Pairing mode
Rapid blue/purple flashes Pairing successful
Quick blue flash Incoming/outgoing call
Slow blue pulse Connected (on a call)
Slow blue flash Standby (not on a call)
Slow red flash Idle (not connected
to phone)
Slow purple pulse Connected call muted
Quick red flash Low battery
Note: After 20 minutes on a call or of inactivity, the light stops
flashing to conserve power, but the headset remains on.
INDICATOR LIGHT AUDIO TONES
CHECKING
BATTERY LEVEL
While turned on and not on a call, you can
check your headset’s battery charge level
by pressing and holding both Volume
buttons.
The indicator light displays charge status
until you release the buttons. See “Indicator
Light” for details on indicator light and
charge status.
DRAFT
DRAFT
