GOLDEN CHINA AUDIO HX-P760 Jam Levity User Manual

GOLDEN CHINA AUDIO (HK) PRODUCT LIMITED (AOK) Jam Levity

User Manual

AOK UI INTRUCTION for HX-P760
TABLE OF CONTENT
Changehistory…………………………………………………………………………………………………………………………………………………………………………………2
1. Productsetting…………………………………………………………………………………………………………………………………………………………………………………2
2. Systemfeedback………………………………………………………………………………………………………………………………………………………………………………4
3. Productstates………………………………………………………….………………………………………………………………………………………………………………………6
Change History
Issue Date Handle by Comments
00 November-4-2015 Mir xie First release
1. Productsetting:buttons,LEDs,Audiosources
2.1 Buttons and switches and Touch, the systems have below buttons:
Button Power button, MFB, Vol+, Vol- button
2.2 Connection of Power and audio system, the system has the following connection:
Power port
In DC jack
Out USB out for charging
2.3 Button press Type and Duration. The following table describes how the buttons react and describes timing constraints
Button pressing time
Press type Duration(Seconds)
Short press X<0.5
Long press 2<x<3
Press & hold -
2.4 Feature List
#CategoryFeatureValue
1 OutoftheBox/After
FactoryReset 
Totalvolumelevel  16steps  
Defaultvolumelevel 10steps(equalto60%volume)
Defaultaudiosource  BT,
Durationforvolumetochangefrommintomax  <16seconds
Rememberpreviousaudiosource  NO
RememberpreviousconnectedBTdevices  Yes,IfAuxisnotconnected,alwaysreconnect
withlastdevicewhichconnectedduringpower
up 
Rememberpreviousvolumelevel  Yes(onlyifvolume<60%,usepreviousvolume,
elseuse60%) Volumeat10‐70%memory,
otherwisereverttothedefault60%
2 Powermode SupportsBatteryMode? Yes
Charginghour  Within2hours
Playbackhour  4hoursat70%volume 
AC Mode Input:100-240VAC, 50-60Hz
output:12VDC/2A
Externalchargingsourcing Yes(USB,Powerbank,etc.)
3 Batterymode  Batterymanagement i.Healthy:X>10% 
ii.Low:5%<X≤10% 
‐Lowbatteryindicationavailable(RedLED
flashingwarning)
‐whenX>95%chargingRedLEDoff
iii.Critical:X=5% 
‐DUToff. 
4 Connection  Audioinput  BTaudio 
Audiooutput No 
Physicalbuttonforaudioswitch  Nospecialbuttonavailable
Autoaudioswitchfeature  BTaudio. 
5 ERP(Energy related
product)compliance 
AutoStandby  Yes
AutoStandbyDuration  Without BT connection, after 2 minutes ,it will
shut off .
BT connection,but don't play, after 15 minutes,it
will shut off
PowerconsumptiontomeetERP <0.3W 
Autoshutoffwithoutpaired 2 minutes
6 Reset FactoryReset  Not
HardwareReset  Yes
7 Bluetoothconnectivity Bluetoothnaming  JamLevity
Wirelessrange  10m
Supportedaudiocodec  SBC 
Supportedprofiles  A2DP,AVRCPsoon
#ofsupporteddeviceinpairinglist  1paireddevicerecorded
SupportsDualdevices  NO
Volumesync  Synchronize volume with iOS
BT Pairing duration Within1minutes
BT Reconnect duration Power up = 10sec
Link lost = 10sec
BT reconnect method (single device or all devices)
Power up = attempt reconnect to same device.
Link lost = attempt reconnect to same device
twice, each time for 10 seconds
8 PC compatibility
Windows version No information
Mac version
MacBook (Pro, Air) with OS X 10.8.2 or later
9 Phone device
compatibility
Phone model with OS version
iPod touch (2-5 Gen), iPod Nano (7 Gen),
iPhone (6,5, 4s, 4, 3Gs, 3G), iPad (1, 2, 3, 4,
mini 1, 2),
2.5Audiosource,AvailableaudiosourceInput:
# Audio input Image
1 Bluetooth 
2.6 Available Audio Source Output: No audio output
Sequence & Priority
The audio source switch command shall allow DUT to switch sources using the following priority and sequence:
Priority Audio input Sequence Default Manual/Automatic
switch
1 Bluetooth  BTis1stSpeaker,isdefault NA
2. SYSTEM FEEDBACK
3.1 The system has the following indicators, list of Audio Indications. (Prompt tone)
# Indicator Description File Name
1 Power on Hold down the power button 3 seconds Provide by HMDX
2 Power down Hold down the power button 3 seconds Provide by HMDX
3 Auto power off No Bluetooth connection and Audio input Provide by HMDX
4 Low battery warning The batter low 3.5 Volts No
5 BT Pairing started Blue LED flashing Provide by HMDX
6 BT pairing successfully 蓝灯 5秒闪一次 Provided by HMDX
7 BT pairing timeout Blue LED flashing No
8 BT disconnect manually After pressing Vol+ button and Vol- button 5
seconds, then enter into paring status
Provided by HMDX
9 BT disconnect – link lost Entering into paring status No
10 BT reconnect successful As pairing successful Provided by HMDX
11 BT reconnect timeout Entering into paring status No
12 Max volume reached Reminder Provided by HMDX
13 Min volume reached no No
14 breathing light Playing Akin to fading in and out
Pause Solid light
3.2 List of Physical Visual Indications
Product off, USB connected
Indicator color Description
Product LED null off
Charging LED ● Solid as long as charging. Off when charging complete
Power off and USB not connected
Indicator color Description
Product LED null off
Charging LED null off
Powering up
Indicator color Description
Product LED
●
On
Powering down
Indicator color Description
Product LED null off
Product on
Event indicator color Description
BT audio source Product LED ● 1. At Re-connect or Pairing mode, Product LED flashing
2. After paired, 蓝灯5秒闪一次
Charging mode
EventIndicatorcolorDescription
ChargingChargingLED ● Solidaslongascharging.Offwhenchargingcomplete.
Battery mode
Event indicator color Description
Battery healthy Charging LED null Charging LED off, not required
Battery low Product LED ● Flashing 1 sec on, 1 sec off until USB cable is inserted or battery died.
Battery critical All LEDs null Off, device is off.
BT activity (The Flashing LED 0.2 seconds on and 0.2 seconds off)
Event indicator color Description
BTpairingProductLED● Speaker:BlueLEDSlowflashing(0.2secon,0.2secoff)for2minoruntil paired
successfully.Bluelightsflashuntilthepairingissuccessful
BTconnectedProductLED ● Speaker:BlueLEDstableon。 Bluelightsflashoncefiveseconds
BTdisconnectingProductLED ● PressingVol+andVolsimultaneouslyfor5seconds,disconnectcurrentBTdevice,
enterintopairingmode

Factory Reset
indicator color Description
Product LED null Unknown
3. Product status
State Description
Off Details: When device is Off without USB connected or Power off (MCU off, Amp off, charging off, BT off,)
To Enter: Removed USB cable and battery off
To Exit: Insert USB cable charging
On Details: Device is on (MCU on, Amp on, charging on, BT on – connectable)
To Enter: Power on
To Exit: Power off
BT on Details: Device is on (MCU on, Amp on, charging on, BT on – discoverable, connected, connecting)
To Enter: BT activity in progress
To Exit: Power off
Key Assignment
Power switch
States vs Press type On position Off position
On Power on /
Off / Power off
Play/Pause
States vs Press type SP (<0.5) LP >2~3s)
On Play or pause No response
On-aux inserted Play or pause No response.
BT on power up reconnect No response No response
BT on pairing No response No response.
BT on connected Play/pause No response
<Vol+> or <Vol->
States vs Press type SP (<0.5) LP >2~5s)
Off No response No response
On Change volume by 1 step. No response
BT on power up re-connect Change volume by 1 step. No response
BT on pairing Change volume by 1 step. No response
BT on connected Change volume by 1 step. next or previous
Vol+ and Vol- pressing at the same time transfer other language Disconnect current BT, enter into
pairing mode.
4. UI
Refer to “SPC-0028 - HMDX Controls Logic Specification - Bluetooth Loudspeakers(D)” for the UI flow chart
5. FCC Statement
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation
