28 Forerunner 50 Owner’s Manual
aPPendix
To replace the battery:
1. Locate the circular battery
cover on the back of the foot
pod.
2. Use a coin to twist the cover
counter-clockwise until it is
loose enough to remove.
3. Remove the cover and
replace the battery with the
positive side facing up.
NOTE: Be careful not to
damage or lose the o-ring
gasket on the cover.
4. Use a coin to twist the cover
back into place.
NOTE: You do not
need to repeat pairing
or calibration following
battery replacement.
190-00839-00_0D.indd 28 7/31/2007 1:48:45 PM
Forerunner 50 Owner’s Manual 29
aPPendix
Caring for Your
Forerunner and
Accessories
Clean the Forerunner and accessories
using a cloth dampened with a mild
detergent solution, and then wipe
dry. Avoid chemical cleaners and
solvents that may damage plastic
components.
Do not store the Forerunner and
accessories where prolonged
exposure to temperature extremes
may occur (such as in the trunk of
a car), as permanent damage may
result.
Technical
Specications
Forerunner 50
Watch size: 58 mm x 42 mm x
20 mm
Wrist band size: 204 mm x 28
mm x 3 mm
Weight: 44 g
LCD Display: 23.75 mm x 18.25
mm, with backlight
Water Resistance: 30 m
continuous
NOTE: To maintain
the water resistance, do
not operate Forerunner
buttons under water.
Data storage: Up to 100 laps and
up to seven hours of exercise les
•
•
•
•
•
•
190-00839-00_0D.indd 29 7/31/2007 1:48:45 PM
30 Forerunner 50 Owner’s Manual
aPPendix
Computer interface: Wireless,
automatic USB ANT stick
Battery type: User-replaceable
CR2032 (3 volts)
Battery life: 12 months,
depending on usage
Operating temperature range:
5° F to 158° F (-15° C to 70° C)
Radio frequency/protocol: 2.4
GHz/Dynastream ANT+Sport
wireless communications protocol
USB ANT stick
Physical size: 59 mm x 18 mm
x 7 mm
Weight: 6 g
Transmission range:
Approximately 5 m (16.4 ft)
Operating temperature: 14°F to
122°F (-10°C to 50°C)
•
•
•
•
•
•
•
•
•
Radio frequency/protocol: 2.4
GHz / Dynastream ANT wireless
communications protocol
Power source: USB
Heart Rate Monitor
Physical size: 34.7 cm x 3.4 cm
x 1.1 cm
Weight: 44 g
Water Resistance: 10 m
Transmission range:
approximately 3 m (9.8 ft)
Battery: User-replaceable
CR2032 (3 volts)
Battery Life: approximately 3
years (1 hour per day)
•
•
•
•
•
•
•
•
190-00839-00_0D.indd 30 7/31/2007 1:48:45 PM
Forerunner 50 Owner’s Manual 31
aPPendix
Operating temperature: 14°F to
122°F (-10°C to 50°C)
NOTE: In cold
conditions, wear
appropriate clothing
to keep the heart rate
monitor near your body
temperature.
Radio frequency/protocol: 2.4
GHz/Dynastream ANT+Sport
wireless communications protocol
Accuracy may be degraded by
poor sensor contact, electrical
interference, and receiver distance
from transmitter.
•
•
Foot Pod
Physical size: 42 mm x 10 mm
Weight: 27 g (including battery)
Water Resistance: 10 m
Transmission range:
Approximately 3 m (9.8 ft)
Speed and distance accuracy:
Uncalibrated 95%, calibrated
98%
Battery: User-replaceable
CR2032 (3 volts)
Battery life: 200 hours run time
NOTE: After 30 minutes
of inactivity, the foot pod
automatically powers off
to conserve the battery.
•
•
•
•
•
•
•
190-00839-00_0D.indd 31 7/31/2007 1:48:45 PM
32 Forerunner 50 Owner’s Manual
aPPendix
Operating temperature: 14°F to
140°F (-10°C to 60°C)
Sensor Accuracy Range: 32°F to
104°F (0°C to 40°C)
Radio frequency/protocol: 2.4
GHz/Dynastream ANT+Sport
wireless communications protocol
Accuracy may be degraded by
electrical interference, receiver
distance from transmitter, and
extreme temperatures.
For a complete list of specications,
see www.garmin.com/products/
forerunner50.
•
•
•
190-00839-00_0D.indd 32 7/31/2007 1:48:45 PM
Forerunner 50 Owner’s Manual 33
aPPendix
Troubleshooting
Problem Solution/Answer
The buttons don’t
respond. How do I
reset the Forerunner?
CAUTION: This procedure deletes all information that you have
entered. Press view, mode, and start/stop simultaneously
to reset the Forerunner software. This restores the factory
settings. Workout data is deleted. You must reset the time and
custom settings. If you are still having problems, remove and
then replace the battery (see page 26).
How do I set the time
to AM or PM?
Verify that the time mode is set to 12-H (12 hour). Use + and
- to select the correct hour. The A or P icon appears above the
seconds on the Time page. For more information, see page 3.
The Forerunner will
not send data to my
computer.
See page 17 to enable computer pairing.
The heart rate
monitor or foot pod
will not pair with the
Forerunner.
Stay 10 m away from other ANT sensors while pairing.
Bring the Forerunner within range (3 m) of the heart rate
monitor while pairing.
If the problem persists, replace the battery.
•
•
•
The heart rate monitor
strap is too big.
A smaller elastic strap is sold separately. Go to http://shop
.garmin.com.
190-00839-00_0D.indd 33 7/31/2007 1:48:45 PM
34 Forerunner 50 Owner’s Manual
aPPendix
Problem Solution/Answer
The heart rate data is
inaccurate or erratic.
Make sure the heart rate monitor is snug against your body.
Warm up for 5–10 minutes. If the problem persists, continue
with the following suggestions.
Reapply moisture to the sensors. Use water, saliva, or
electrode gel. Clean the sensors. Dirt and sweat residue on
the sensor can interfere with heart rate signals.
Syntheticfabricsthatruborapagainsttheheartrate
monitor can create static electricity that interferes with heart
rate signals. Wear a cotton shirt or wet your shirt if suitable
for your activity.
Position the heart rate monitor on your back instead of your
chest.
Strongelectromagneticeldsandsome2.4GHzwireless
sensors can interfere with your heart rate monitor. Sources
of interference may include very high voltage power lines,
electric motors, microwave ovens, 2.4 GHz cordless
phones, and wireless LAN access points. After you move
away from the source of interference, your heart rate data
should return to normal.
•
•
•
•
•
•
190-00839-00_0D.indd 34 7/31/2007 1:48:45 PM
Forerunner 50 Owner’s Manual 35
aPPendix
Product Warnings and
Important Information
Contact your local waste department
to properly dispose of the units and
batteries. Do not incinerate.
Keep used batteries away from
children. Do not disassemble,
puncture, or damage the battery.
Perchlorate Material: Special
handling may apply, see www.dtsc
.ca.gov/hazardouswaste/perchlorate.
The Forerunner has no user-
serviceable parts. Should you ever
encounter a problem with your unit,
please take it to an authorized Garmin
dealer for repairs.
Always consult your physician before
beginning or modifying any exercise
program. If you have a pacemaker
or other implanted electronic device,
consult your physician before using a
heart rate monitor.
The Forerunner, heart rate monitor,
•
•
•
•
•
and foot pod are consumer devices,
not medical devices, and could suffer
from interference from external
electrical sources. The heart rate
readings are for reference only and
no responsibility can be accepted for
the consequences of any erroneous
readings.
The California Electronic Waste
Recycling Act of 2003 requires the
recycling of certain electronics. For more
information on the applicability to this
product, see www.erecycle.org.
WARNING: This product, its packaging,
and its components contain chemicals
known to the State of California to cause
cancer, birth defects, or reproductive
harm. This Notice is provided in
accordance with California’s Proposition
65. See www.garmin.com/prop65 for
more information.
190-00839-00_0D.indd 35 7/31/2007 1:48:45 PM
36 Forerunner 50 Owner’s Manual
aPPendix
Software License
Agreement
BY USING THE Forerunner, YOU
AGREE TO BE BOUND BY THE
TERMS AND CONDITIONS OF THE
FOLLOWING SOFTWARE LICENSE
AGREEMENT. PLEASE READ THIS
AGREEMENT CAREFULLY.
Garmin grants you a limited license to
use the software embedded in this device
(the “Software”) in binary executable
form in the normal operation of the
product. Title, ownership rights, and
intellectual property rights in and to the
Software remain in Garmin.
You acknowledge that the Software
is the property of Garmin and is
protected under the United States
of America copyright laws and
international copyright treaties. You
further acknowledge that the structure,
organization, and code of the Software
are valuable trade secrets of Garmin
and that the Software in source code
form remains a valuable trade secret of
Garmin. You agree not to decompile,
disassemble, modify, reverse assemble,
reverse engineer, or reduce to human
readable form the Software or any part
thereof or create any derivative works
based on the Software. You agree not to
export or re-export the Software to any
country in violation of the export control
laws of the United States of America.
Declaration of
Conformity
Hereby, Garmin declares that this
Forerunner product is in compliance
with the essential requirements and
other relevant provisions of Directive
1999/5/EC.
To view the full Declaration of
Conformity, see the Garmin Web site for
your Garmin product: www.garmin.com/
products/forerunner50. Click Manuals,
and then select the Declaration of
Conformity.
190-00839-00_0D.indd 36 7/31/2007 1:48:46 PM
Forerunner 50 Owner’s Manual 37
aPPendix
Limited Warranty
This Garmin product is warranted to
be free from defects in materials or
workmanship for one year from the date
of purchase. Within this period, Garmin
will, at its sole option, repair or replace
any components that fail in normal use.
Such repairs or replacement will be made
at no charge to the customer for parts or
labor, provided that the customer shall be
responsible for any transportation cost.
This warranty does not cover failures
due to abuse, misuse, accident, or
unauthorized alteration or repairs.
THE WARRANTIES AND REMEDIES
CONTAINED HEREIN ARE
EXCLUSIVE AND IN LIEU OF ALL
OTHER WARRANTIES EXPRESS,
IMPLIED, OR STATUTORY,
INCLUDING ANY LIABILITY
ARISING UNDER ANY WARRANTY
OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR
PURPOSE, STATUTORY OR
OTHERWISE. THIS WARRANTY
GIVES YOU SPECIFIC LEGAL
RIGHTS, WHICH MAY VARY FROM
STATE TO STATE.
IN NO EVENT SHALL GARMIN BE
LIABLE FOR ANY INCIDENTAL,
SPECIAL, INDIRECT, OR
CONSEQUENTIAL DAMAGES,
WHETHER RESULTING FROM THE
USE, MISUSE, OR INABILITY TO
USE THIS PRODUCT OR FROM
DEFECTS IN THE PRODUCT. Some
states do not allow the exclusion of
incidental or consequential damages, so
the above limitations may not apply to
you. Garmin retains the exclusive right to
repair or replace the unit or software or
offer a full refund of the purchase price
at its sole discretion. SUCH REMEDY
SHALL BE YOUR SOLE AND
EXCLUSIVE REMEDY FOR ANY
BREACH OF WARRANTY.
To obtain warranty service, contact your
local Garmin authorized dealer or call
190-00839-00_0D.indd 37 7/31/2007 1:48:46 PM
38 Forerunner 50 Owner’s Manual
aPPendix
Garmin Product Support for shipping
instructions and an RMA tracking
number. Securely pack the unit and a
copy of the original sales receipt, which
is required as the proof of purchase for
warranty repairs. Write the tracking
number clearly on the outside of the
package. Send the unit, freight charges
prepaid, to any Garmin warranty service
station.
Online Auction Purchases: Products
sold through online auctions are not
eligible for rebates or other special
offers from Garmin. Online auction
conrmations are not accepted for
warranty verication. To obtain warranty
service, an original or copy of the
sales receipt from the original retailer
is required. Garmin will not replace
missing components from any package
purchased through an online auction.
International Purchases: A separate
warranty is provided by international
distributors for units purchased outside
the United States. This warranty
is provided by the local in-country
distributor and this distributor provides
local service for your unit. Distributor
warranties are only valid in the area of
intended distribution. Units purchased
in the United States or Canada must be
returned to the Garmin service center in
the United Kingdom, the United States,
Canada, or Taiwan for service.
FCC Compliance
This product has been tested and found
to comply with Part 15 of the FCC
interference limits for Class B digital
devices FOR HOME OR OFFICE USE.
These limits are designed to provide
more reasonable protection against
harmful interference in a residential
installation, and are more stringent than
“outdoor” requirements.
Operation of this device is subject to the
following conditions: (1) this device may
not cause harmful interference, and (2)
190-00839-00_0D.indd 38 7/31/2007 1:48:46 PM
Forerunner 50 Owner’s Manual 39
aPPendix
this device must accept any interference
received, including interference that may
cause undesired operation.
This equipment generates, uses, and
can radiate radio frequency energy and
may cause harmful interference to radio
communications if not installed and
used in accordance with the instructions.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does
cause harmful interference to radio
or television reception, which can be
determined by turning the equipment
off and on, the user is encouraged to try
to correct the interference by one of the
following measures:
Reorient or relocate the receiving
antenna.
Increase the separation between the
equipment and the receiver.
Connect the equipment into an outlet
that is on a different circuit from the
receiver.
•
•
•
Consult the dealer or an experienced
radio/TV technician for help.
This product does not contain any
user-serviceable parts. Repairs should
only be made by an authorized Garmin
service center. Unauthorized repairs or
modications could result in permanent
damage to the equipment, and void your
warranty and your authority to operate
this device under Part 15 regulations.
Industry Canada
Compliance
Category I radiocommunication
devices comply with Industry Canada
Standard RSS-210. Category II
radiocommunication devices comply
with Industry Canada Standard RSS-310.
•
190-00839-00_0D.indd 39 7/31/2007 1:48:46 PM
index
40 Forerunner 50 Owner’s Manual
index
A
accessories 5, 25
alarm 10
Auto Lap 13
B
backlight 2
batteries 26
bike accessories 25
buttons, watch 1
C
cadence sensor 9, 25
calibrating
auto 8
foot pod 8
manual 9
caring for your
Forerunner 29
changing modes 1
chimes 10
computer pairing 17
D
data uploading 4, 23
downloading software i, 4
drivers, USB 4, 23
F
FCC compliance 38
foot pod 7, 14, 27
calibrating 8
G
Garmin Connect i, 4, 24
Garmin Product Support i
Garmin Training Center i,
4, 24
GSC10 9, 25
H
heart rate monitor 5, 27
heart rate zones 15
History mode 20
I
icons 2
Industry Canada
compliance 39
Interval Timer mode 18
L
lap 1, 13
license agreement 36
limited warranty 37
M
memory 21
modes, change 1
MyGarmin i
P
pairing, computer 17
pairing sensors 3, 25
product registration i
product support i
R
running, foot pod 7, 14
running zones 14
190-00839-00_0D.indd 40 7/31/2007 1:48:46 PM
Forerunner 50 Owner’s Manual 41
index
S
sensors, pairing 3, 5, 25
setting the time 3
software downloads i, 4
software license
agreement 36
specications 29
speed and cadence
sensor 9, 25
T
technical specications 29
time, setting 3
Time mode 10
timers, setting 18
time zones 11
training zones 13
Train mode 12
transferring data 4, 23
troubleshooting 33
turning on Forerunner 2
U
units 12
uploading data 4, 23
USB ANT stick iv, 4
USB drivers 4, 23
W
warnings and important
information 35
warranty 37
workout data 20
190-00839-00_0D.indd 41 7/31/2007 1:48:46 PM
For the latest product information and accessories, visit the Garmin
Web site at www.garmin.com.
© 2007 Garmin Ltd. or its subsidiaries
Garmin International, Inc.
1200 East 151st Street, Olathe, Kansas 66062, USA
Garmin (Europe) Ltd.
Liberty House, Hounsdown Business Park, Southampton, Hampshire, SO40 9RB UK
Garmin Corporation
No. 68, Jangshu 2nd Road, Shijr, Taipei County, Taiwan
www.garmin.com
Part Number 190-00839-00 Rev. D
190-00839-00_0D.indd 42 7/31/2007 1:48:46 PM
