ZBT1WF-1501S100 WIFI Module Datasheet
Version：V1.0
Date：Apr, 2017
Genbyte Technology Inc. ZBT1WF-1501S100 WIFI Module
Genbyte Technology Inc. Confidential Page 2 of 7
ZBT1WF-1501S100 WIFI Module
General Description
ZBT1WF-1501S100 module is a low power
consumption, high performance WIFI Smart
home / IoT solution, and design based on TI
CC3200 SimpleLink Wi-Fi —Consists of
Applications Microcontroller, Wi-Fi Network
Processor, and Power-Management
Subsystems in a single chip for IEEE 802.11
b/g/n compatible. It supports smartconfig
technology for customer easy connected (APP).
It can implement the wireless network function on the air-condition, refrigerator and
other wireless devices easily.
Features
Support IEEE802.11 b/g/n(2.4G only), WiFi Direct(P2P), soft-AP;
Embedded ARM® Cortex®-M4 Core;
Support Smartconfig Technology;
Consists of TCP/IP Stack;
PCB sniffer ANT(or External ANT);
Support UART/SPI/I2C;
Small dimension: 32mm*23mm, Surface mounted;
IAR/CCS Programming environment;
PIN number:36 PIN;
Dimension: 32.8mm*23.1mm;
Application:
Smart home (Refrigerator/Air-condition, etc..);
Wireless IoT;
Genbyte Technology Inc. ZBT1WF-1501S100 WIFI Module
Genbyte Technology Inc. Confidential Page 3 of 7
Specification:
Table 1: Environment condition:
Parameter value
Operation temperature -20℃ to 80℃
Storage temperature -40℃ to 120℃
Table 2: Electrical condition:
MIN TYP MAX Unit
VDD -0.3 3.3 3.6 Vdc
VIO -0.3 3.3 3.6 Vdc
Mechanical Specification:
Genbyte Technology Inc. ZBT1WF-1501S100 WIFI Module
Genbyte Technology Inc. Confidential Page 4 of 7
PIN Description:
Number Signal Name Signal Description Note
1 GND Module GND
2 EXRESET External reset PIN
3 SOP2 SOP Boot config
4 SOP0 SOP Boot config
5 VDD 3.3V
6 VDD 3.3V
7 GND Module GND
8 GND Module GND
9 GPIO30 GPIO
10 GPIO0 GPIO
UART0_CTS
11 GPIO6 GPIO
UART0_ RTS
12 GPIO1 GPIO
UART0_TXD
13 GPIO2 GPIO
UART0_RXD
ADC0 ADC Channel 0
Analog Input (1.5V
max)
14 GPIO3 GPIO
UART1_TXD
ADC1 ADC Channel 1
Analog Input (1.5V
max)
15 GPIO4 GPIO
UART1_RXD
ADC2 ADC Channel 2
Analog Input (1.5V
max)
16 GPIO5 GPIO
ADC3 ADC Channel 3
Analog Input (1.5V
max)
17 GPIO7 GPIO
UART1_ RTS
18 GPIO8 GPIO
19 GPIO9 GPIO
20 GPIO10 GPIO
I2C_CLK
Genbyte Technology Inc. ZBT1WF-1501S100 WIFI Module
Genbyte Technology Inc. Confidential Page 5 of 7
21 GPIO11 GPIO
I2C_DATA
22 GPIO12 GPIO
23 GPIO13 GPIO
24 GPIO14 GPIO
SPI_CLK
25 GPIO15 GPIO
SPI_MISO
26 GPIO16 GPIO
SPI_MOSI
27 GPIO17 GPIO
SPI_SS
28 GND Module GND
29 VDD 3.3V
30 GPIO22 GPIO
31 GPIO28 GPIO
32 JTAG_TDI JTAG_TDI
33 JTAG_TDO JTAG_TDO
34 JTAG_TCK JTAG_TCK
35 JTAG_TMS JTAG_TMS
36 GND Module GND
ZB-W3200 WIFI module mode configuration:
SOP0 SOP2 MODE
0 1 UART Download Firmware
1 0 Operation mode
0 0 Operation mode
RF Performance
For 802.11b,802.11g and 802.11n-HT20 mode,11 channels are provided.
Channel Frequence(MHz) Channel Frequence(MHz)
1 2412 8 2447
2 2417 9 2452
3 2422 10 2457
4 2427 11 2462
5 2432
6 2437
7 2442 /
/
/
Genbyte Technology Inc. ZBT1WF-1501S100 WIFI Module
Genbyte Technology Inc. Confidential Page 6 of 7
FCC Caution:
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment .This equipment should be installed and operated with
minimum distance 20cm between the radiator& your body.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
This module is intended for OEM integrator. The OEM integrator is still responsible for the FCC
compliance requirement of the end product, which integrates this module.
The final end product must be labeled in a visible area with the following" Contains
FCC ID: 2AMRBZBT1WF-CC3200" and the frequency can't be changed by end users.
Genbyte Technology Inc. ZBT1WF-1501S100 WIFI Module
Genbyte Technology Inc. Confidential Page 7 of 7
Important notice :
Genbyte Technology Inc. reserve the right to make corrections, enhancements,
improvements and other changes to its products.
Buyer acknowledges and agrees that it is solely responsible for compliance with all
legal, regulatory and safety-related requirements concerning its products.
Reversion History
Rev Author Date Note
V1.0 Leon 2017.04.28 First release
