Users Manual Rev2







. Overview

CongratulationsandthankyouforpurchasingtheBluetooth

EDGEWirelessModem.(Brand:Getac;Model:Energy)

Thisguideprovidesinstructionsonusingthemodemwith

WindowsMobile5.0/6.1devicesandWindowsXP/Vista

computers.

Packing List

 

Modem   Battery



 

ACadapter Externalantenna

Specifications

Frequency Bands Quad‐bandEGSM/GPRS/EGPRS

900/1800/850/1900MHz

Bluetooth Profile SerialPortProfile(SPP)

Dial‐upNetworkingProfile(DUN)

Application Datatransmission

OS Support WindowsMobile5.0/6.0

WindowsXP/Vista

Power Rechargeable3.7volt2400mAh

Li‐ionbatterypack

Powerjackfor5Vpowersupply

Indicators



Power

Off Poweroff

Green Poweron

Red Poweronwithlowbattery

Orange Batterycharginginprogress

Red Flash Twice Nobatteryorcriticallylowbattery

Red Flash Errorincharging

Red/Green Flash Bluetoothpairmode



GSM/GPRS

Off GSMoff

Green Flash Ready,idle,ordatatransferinprogress

Green Datacallinprogress



Bluetooth

Off Bluetoothoff

Blue Readytobepaired

Blue Slow Flash ActiveBluetoothconnection



. Hardware Setup

1. Loosenthebottomscrew(n)

withascrewdriverandslidethe

batterycoveroutward(o)to

detachitfromthemodem.

CAUTION:Themodemdoesnot

supportPINcodesofSIMcards.

IfaPINcodehasbeenset,disable

thePINcodebeforeinstallingthe

SIMcard.

2. Notetheorientationofthe

SIMcardandinsertthecard

intotheSIMcardslot.

3. Notetheorientationofthe

batteryandfititintothe

compartment.

4. Replacethebatterycoverand

tightenthescrew.

5. Locatethepowerconnectorofthe

modembyopeningtherubber

cover.Connectoneendofthe

ACadapterintothe

powerconnector(n)

andtheotherend

intoanelectrical

outlet(o).

Thischargesthe

batterypack.



6. Anexternalantennaisprovidedfor

bettersignalreceptioninacar.

Locatetheantennaconnectorofthe

modembyopeningtherubbercover.

Connectoneendoftheantennainto

theantennaconnectorandattach

theotherendtothehighestpossible

position.

7. Turnonthemodembypressing

thepowerbutton.



. Software Setup – Windows Mobile 5.0/6.1

NOTE:



WindowsMobile5.0screensareusedinthissectionas



examples.

EasySetup Installation

AprogramcalledEasySetuphelpsyousetupWindowsMobile

5.0/6.1devicesforusingthemodem.Pleasecontactyourdealer

orGetactoobtainthefilenamedEasySetupInstaller.CAB.

ToinstallEasySetup,executethefileEasySetupInstaller.CAB.

Then,followtheonscreeninstructionstocompletethe

installation.

Bluetooth Pairing and Dial-up Settings

1. OnyourWindowsMobiledevice,turnontheBluetooth

functionandsetitto“visible.”

2. Pressthepowerbuttonofthemodemforatleast3seconds.

ThiswillpreparethemodemforBluetoothpairing.

3. TapStart Æ Programs Æ EasySetup.

4. EasySetupwilltrytopairwiththemodem.Whenthepairing

iscompleted,amessageappearstoinformyou.

5. EasySetupwillacquirethemobileoperator’sdatafromthe

SIMcardandlistthedial‐upnumber(s)foryoutoselect.

SelectthecorrectnumberandtapOK.

6. TheEasySetupshortcuticon  appearsatthebottom

rightcornerofthescreen.

Network Connection and Disconnection

Oncetheshortcuthasbeencreatedasdescribedbefore,you

canconnecttothemobilenetworkthroughthemodemat

anytime.

1. OnyourWindowsMobiledevice,turnontheBluetooth

functionandsetitto“visible.”

2. Poweronthemodem.

3. Toconnect,taptheEasySetupshortcuticon  andtap

Connect.

4. Inthe“LogontoServer”screen,entertheinformation

providedbyyourmobileoperator.Donotdisablethe

Save passworditem.ThentapOK.

5. Whenmobilenetworkconnectioniscompleted,a

messageappearstoinformyou.TheWindowsMobile

devicecannowaccesstheInternetthroughthemodem.

6. Todisconnect,taptheEasySetupshortcuticonand

tapDisconnect.

7. Ifthereisaneedtostoptheprogramsoitwillnotoccupy

thesystemmemory,taptheEasySetupshortcuticon



andtapExit.

NOTE:IfyouchangetheSIMcard,youhavetorecreatethe

shortcutoverwritingthepreviousone.

BluetoothEDGE



WirelessModem



REFERENCE GUIDE Ru

ed Mobile Com

utin

Solutions





. Software Setup – Windows XP/Vista

. Regulatory Statements and Safety Precautions

NOTE:



WindowsVistascreensareusedinthissectionas



examples.

EasySetup Installation

AprogramcalledEasySetuphelpsyousetupWindows

XP/Vistacomputersforusingthemodem.Pleasecontactyour

dealerorGetactoobtainthefilenamed

EasySetupInstaller.msi.

ToinstallEasySetup:

1. ExecutethefileEasySetupInstaller.msi.

2. Inthesetupwizardscreen,clickNext.

3. Whentheinstallationiscompleted,clickClose.

Bluetooth Pairing and Dial-up Settings

NOTE:EasySetupisdesignedfortheWindows’built‐in

Bluetoothdriveronly.Ifyourcomputercomeswitha

third‐partyBluetoothdriver,youhavetouseitsspecific

Bluetoothutilitytopairthecomputerwiththemodem.

(Checkthedocumentationofyourcomputertoknowhowto

performtheBluetoothpairingprocedure.)Whilepairing,the

passkey0000isrequired.Afterthemanualpairing,youcan

useEasySetupfordial‐upsettings.

1. Onyourcomputer,turnontheBluetoothfunctionandset

itto“visible.”

2. Pressthepowerbuttonofthemodemforatleast3

seconds.ThiswillpreparethemodemforBluetooth

pairing.

3. FromWindowsdesktop,clickStart Æ EasySetup.

EasySetupwillautomaticallypairwiththeBluetooth

modem.

4. EasySetupwillacquirethemobileoperator’sdatafromthe

SIMcardandlistthedial‐upnumber(s)foryoutoselect.

SelectthecorrectnumberandclickOK.

5. TheEasySetupshortcuticon  appearsintheWindows

taskbar.



Network Connection and Disconnection

Oncetheshortcuthasbeencreatedasdescribedbefore,you

canconnecttothemobilenetworkthroughthemodematany

time.

1. Onyourcomputer,turnontheBluetoothfunctionandsetit

to“visible.”

2. Poweronthemodem.

3. Toconnect,clicktheEasySetupshortcuticonandclick

Dial-up.

4. Whenmobilenetworkconnectioniscompleted,the“ON

LINE…”messageappears.Yourcomputercannowaccess

theInternetthroughthemodem.

5. Todisconnect,clicktheEasySetupiconandclickDisconnect.



6. Ifthereisaneedtostoptheprogramsoitwillnotoccupythe

systemmemory,clicktheEasySetupshortcuticonand

clickExit.

NOTE:IfyouchangetheSIMcard,youhavetorecreatethe

shortcutoverwritingthepreviousone.



European Notice

ProductswiththeCEmarkingcomplywithRadio&

TelecommunicationTerminalEquipmentDirective(R&TTE)

(1999/5/EEC),theElectromagneticCompatibilityDirective

(89/336/EEC)andtheLowVoltageDirective(73/23/EEC)–as

amendedbyDirective93/68/ECC–issuedbytheCommissionof

theEuropeanCommunity.

Compliancewiththesedirectivesimpliesconformitytothe

followingEuropeanStandards:

EN301489-1: ElectroniccompatibilityandRadiospectrum

Matters(ERM),ElectroMagneticCompatibility(EMC)standard

forradioequipmentandservices;Part1:Commontechnical

requirements

EN301489-17: ElectroniccompatibilityandRadiospectrum

Matters(ERM),ElectroMagneticCompatibility(EMC)standard

forradioequipmentandservices;Part17:Specificconditions

for2.4GHzwidebandtransmissionsystemsand5GHzhigh

performanceRLANequipment

EN55022:Radiodisturbancecharacteristics

EN55024: Immunitycharacteristics

EN6100-3-2: Limitsforharmoniccurrentemissions

EN6100-3-3:Limitationofvoltagefluctuationandflickerin

low‐voltagesupplysystem

EN62311:ProductSafety

Themanufacturercannotbeheldresponsibleformodifications

madebytheUserandtheconsequencesthereof,whichmay

altertheconformityoftheproductwiththeCEMarking.

USA FCC (Federal Communications Commission) Radio

Frequency Interference Statement

Warning: Changesormodificationstothisunitnotexpressly

approvedbythepartyresponsibleforcompliancecouldvoid

theuserauthoritytooperatetheequipment.

ThisdevicecomplieswithPart15oftheFCCRules.Operationis

subjecttothefollowingtwoconditions:

(1)thisdevicemaynotcauseharmfulinterference,and

(2)thisdevicemustacceptanyinterferencereceived,including

interferencethatmaycauseundesiredoperation.

Safety Precautions

z UseonlytheACadaptersuppliedwithyourdevice.Useof

anothertypeofACadapterwillresultinmalfunctionand/or

danger.

z ThisproductisintendedtobesuppliedbyaLISTEDPower

Unitmarkedwith“LPS,”“LimitedPowerSource,”and

outputrated+5Vdc/2.2A.

z Useaspecifiedbatteryintheequipment.

z Donotusethe



ACadapter



inahighmoisture



environment.NevertouchtheACadapterwhenyour

handsorfeetarewet.

z AllowadequateventilationaroundtheACadapterwhen

usingittooperatethedeviceorchargethebattery.Do

notcovertheACadapterwithpaperorotherobjects

thatwillreducecooling.DonotusetheACadapterwhile

itisinsideacarryingcase.

z ConnecttheACadaptertoaproperpowersource.The

voltageandgroundingrequirementsarefoundonthe

productcaseand/orpackaging.

z DonotusetheACadapterifthecordbecomes

damaged.

z Donotattempttoservicetheunit.Thereareno

serviceablepartsinside.Replacetheunitifitisdamaged

orexposedtoexcessmoisture.

z UseaspecifiedACadapterapprovedbythe

manufacturer.

z Donotmutilate,puncture,ordisposeofbatteryinfire.

Thebatterycanburstorexplode,releasinghazardous

chemicals.

z Importantinstructions

Caution:Riskofexplosionifbatteryisreplacedbyan

incorrecttype.Disposeofusedbatteriesaccordingtothe

instructions.

Replaceonlywiththesameorequivalenttype

recommendedbythemanufacturer.

Thebatterymustberecycledordisposedofproperly.

Usethebatteryonlyinthespecifiedequipment.

RF Exposure (SAR) Warning

z ThisequipmentcomplieswithFCCRFradiationexposure

limitssetforthforanuncontrolledenvironment,under

47CFR2.1093paragraph(d)(2).

z Endusersmustfollowthespecificoperationinstruction

forsatisfyingRFexposurecompliance.

z Thistransmittermustnotbeco‐locatedoroperatingin

conjunctionwithanyotherantennaortransmitter

exceptthosethataredescribedwithinthisfiling.

z ThemeasuredSARlevelsevaluatedareincompliance

withtheFCCRFexposureguidelines.

z ThemaximumreportedBodyMaximumSAR

Measurement(1g)valueis:1.198W/Kg.



561582600001R00



Getac Technology ENERGY Bluetooth EDGE Wireless Modem User Manual Energy Getac QSG 1207V2

Getac Technology Corporation Bluetooth EDGE Wireless Modem Energy Getac QSG 1207V2

Contents

Users Manual Rev2

Navigation menu

Namespaces

Views

Navigation
