USER MANUAL
Headphone introduction
Specifications
Charging
Aux In Answer the phone/End the phone/Refuse to answer the phone
Pairing
Power
Wearing
Volume+/Next song
Volume-/Last song
MIC
Indicate light
Aux in
Charging port
Power on/off
Play/Pause
Bluetooth Headphone
Bluetooth Version:
If do not use the devise often, pls charge it at least one time monthly.
Charging Time: 2-3hours
Talk Time: 15hours
Music Time: 10hours
Standby Time: 25hours
Material: Plastic&Metal
Product Weight: 175g
Product Size: 160*178*80mm
Accessory: Charging Cable*1
3.5mm Audio Cable*1
V4.2
Support Agreement: A2DP, Hands-free
Impedance: 32Ω
Speaker Unit: 10mm
Battery: 500mAh Lithium polymer battery
Bluetooth Distance: 10m( No Obstacle)
Output Power: 100mW
SNR: 90dB
Power Supply: DC V5V
For first time using, battery should be in full state. Insert the Micro USB port
to earphone’s charging port, connect the other side of USB port to
computer’s USB port, then the device is charging.
Indicate light: the red light is flashing when charging, the light is off when it is
in full battery.
Power on: Press the power button over 5-7 seconds, blue light is flashing
means the device is power on.
Power off: Press the power button 5 seconds, the device is power off after
blue light flashes.
This device is over-head headphone, pls keep the earmuffs close to your
ears, and adjust the ear strap length on your demand.
When you use Aux in function, it is no need to make device power on. Insert
the audio cable’s 3.5mm port to Aux in port, insert another side of 3.5mm
Answer the phone manually: When call is coming, short press the power
button to answer phone.
End the phone manually: When in call state, short press the power button to
end it.
Refuse to answer phone manually: When call is coming, double click the
power button to refuse it.
When it is in standby state, double click the power button to re-dial the last
phone No.
Pls note that the pairing longest time of Bluetooth headphone is 120
seconds, if the light is off, the Bluetooth state stops, if it still can not pair
successfully, pls do the 4 steps once again.
When pull out 3.5mm port, the headphone will not switch to Bluetooth
mode automatically, it need to turn on the headphone to evoke Bluetooth
mode.
This product is 1 to 2 design, that is, it can connect two devices with
Bluetooth function; if it is set successfully first time, there is no need to set it
again, it will connect automatically when the product is power on.
1) Pls make sure that cell phone’s Bluetooth is on, and in Bluetooth mode.
2) Press the power button 5-10 seconds, when the indicate light flashes in
blue and red alternately, the headphone is in pairing state.
3) About 5 seconds, cell phone can search H1 , click it and cell phone
will paired with device automatically. ( Part of cell phones need to input
passwords ”0000” to pair.)
4) After pairing successfully, it will show connected.
5) If you want to pair with second cell phone, pls shut down the Bluetooth of
first cell phone, and shut down the headphone, then power on the
headphone again, do 1-4 steps, then it can pair successfully.
6) At this time, disconnect the second phone’s Bluetooth, and open the first
phone’s Bluetooth, the headphone will pair first cell phone automatically.
7) All finished, two cellphones can connect automatically.
Headphone Mobile phone tabletPC
Bluetooth
Last Phone No. re-dial
When in music state, press the Play/Pause button to play or pause music.
Play/Pause
Long press ”+” to increase volume, long press “-” to decrease volume.
Pls note that if use Aux in to play music, the operation is useless, pls use
player to control volume.
Volume
Short press “+” to next song, short press “-” to last song.
Pls note that if use Aux in to play music, the operation is useless, pls use
player to control volume.
Last song and Next song
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which
can be determined by turning the equipment off and on, the user is encouraged
to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for
compliance
could void the user's authority to operate the equipment. This device complies
with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may
cause undesired operation.
