Gospell Smarthome Electronic T5886HAA HD WiFi Camera User Manual T5886 Manual 3 5

Shenzhen Gospell Smarthome Electronic Co., Ltd. HD WiFi Camera T5886 Manual 3 5

15_T5886HAA UserMan

Antenna
Thermo sensitive induction
Micro SD card slot
SET key
Indicator light
Power adapter port
Appearance
Microphone
I
Light sensor
Camera Lens
Note: There is no sensor which the
product is without the temperature
control induction.
-14--15-
Troubleshooting
2. Red indicator remains, network connection is failed.
a) Ensure that the password of Wi-Fi is correct.
b) Ensure that the network connects to Internet freely.
c) Ensure that the camera is in range of Wi-Fi hotspot.
5.Push message: when movement is detected, alarm
message can be sent to server and pushed to your
phone.
6.Remote monitoring: after the camera is connected to
Internet successfully, app can view the monitor via
Internet, anytime, anywhere.
7.Temperature alarm: In case that the temperature
detected by the device is higher than the set value,
audible alarm will be activated on cell phone (once
every 2 minutes).
Note: There is no function which the product is without
the temperature control induction
3. Green indicator flashes, connection to server failed.
a) Ensure that Wi-Fi signal is strong enough and
bandwidth is enough for connection. Move near to Wi-Fi hotspot
or increase the bandwidth.
b) Ensure that camera is not under interferon of other 2.4GHz signal.
Tips
1.Suggest using qualified micro-SD card to avoid
incompatibility. Format micro-SD card before using.
2.Movement detection: when movement is detected
within the scope of camera, the camera will record video
and take photos automatically. Videos and photos will
be saved in micro-SD card.
1. Wi-Fi cannot be connected
a) Ensure that the antenna of camera is fixed well.
b) Ensure that camera is in range of router. Keep the distance
less than 40fts between router and indoor camera, less than
65fts for outdoor camera.
c) Ensure that SSID and password of Wi-Fi contains no special
characters. Modify the SSID and password of Wi-Fi with only
English characters, no special characters.
d) Ensure that SSID and password are no longer than 16 characters
e) Ensure that SSID is broadcasted.
f ) Ensure that the DHCP is enabled on router.
g) Ensure that Wi-Fi encryption method is WPA2-PSK/
WPA-PSK or AES.
h) Ensure that Wi-Fi signal is 2.4GHz.
i ) Ensure that there is no MAC filter on router or add MAC address
to router whitelist
j )
We suggest rebooting the router, and the "security settings,
encryption method" of WiFi password should never choose
"auto-select".
k )
Reset the camera to set up connection again. Press and hold
SET key for 5 seconds.
9.When this machine has a crash fault or other abnormal
conditions influencing the usage, it is recommended to
cut out the power and restart; or press SET key for 10
seconds, which can restore factory settings, and then
please reconnect the router.
8.Only support the special characters in English mode,
such as: " @, #, &, *, ~, , , -, =, +, /, ?, (, )",
Dont support the special characters, such as:"%", "\",
"<>".
3.Share your camera to friends: Share QR code of the
device with your friends.
4.The main account to delete the camera, this time friends
to share Will be deleted together.
(You have to re-add the camera to use it again)
The Maximum Permissible Exposure (MPE) level has been calculated based
on a distance of d=20 cm between the device and the human body. To maintain
compliance with RF exposure requirement, use product that maintain a 20cm
distance between the device and human body. Hereby, we declares that this
device is in compliance with the essential requirements and other relevant
provisions of Directive 2014/53/EU.
Notice: Observe the national local regulations in the location where the device I
s to be used. This device may be restricted for use in some or all member states
of the European Union (EU)
This equipment generates uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
The operated frequency is 2.4G~2.4835G with B/G/N20/N40.
The Max output power on 802.11b is 16.96dBm.
The Max output power on 802.11g is 14.98dBm.
The Max output power on 802.11n-20 is 15.12dBm.
The Max output power on 802.11n-40 is 14.67dBm
-16-
EU Environmental Provisions
E-waste cannot be mixed with household
garbage; corresponding local government
sector or recycling stations shall be
responsible for circular process.
-13-
Function Features
Packing List
Camera Power
adapter Quick Guide
USB cable
The picture is only for reference and the real object shall prevail
Screws
24/7 live video streaming
HD provides excellent video quality
Smart motion detection and notification
Advanced video recording on micro-SD card (Maximally
support the cyclic recording of 64GB micro SD card.)
Motorized Pan/Tilt
Night vision (5m visibility)
Two-way voice transmit
Quick & easy to set up
Model: T5886HAA
Quick Start Guide
Before using the product, please read the guide carefully to avoid
any damages to the product in virtue of faulty operation or misuse.
HD WiFi Camera
10
9
FCC/CE Certification Information
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
11
Product Specifications
No additional notice will be made in case of any
minor change. Our company reserves the right of
final interpretation.
6 7
8
-1- -2--3- -4- -5- -6- -7- -8-
-12--10--9--17-
1. 2.4G wireless router is required.
2. support Android 4.4 and above, iOS 8.0 and above
3. Download and install the APP:
A. Open the App Store , search “GOSCOM” and install.
B. Open the Google Play Store , search “GOSCOM” and install.
4. Here is an operation example of Android APP, and
it can serve as a reference for the iOS APP.
5. power-on Camera and there will be prompt sound
indicating power on succeed
Preparation prior to Installation
Camera
2Installation
Power Adapter Wall Socket
TIP: For user ID registration, please use an effective email
address, (example XXXX@qq.com), in order to retrieve the
password.
(2)
(1)
(3)
Step 1: Tap the “GOSCOM” APP icon to open it (figure 1);
Step 2: Use email address for user ID registration (figure 2-3);
Step 3: After registration, enter the email address and then
password to log in (figure 2)
Register/Login
Quick Register
Enter address
Enter pa ssword
Enter pa ssword again
Register
Get c ode
please enter verification code sent to
your email(case sensitive)
Pass word fo rmat: 8 -16 cha racte rs in len gth, co ntain a t least
two kinds among numbers,capital letters and lowercase
let ters
I have raed this Agreem ent and agre e to the
terms an d conditi ons User agre ement
No Se rvice 11:5 0
Email
Enter pass wor d
Login
Reg ist er Remember password
Forget password
No Service 11:5 0
Scan QR Code to Add
Device List
Add device
Exper ience Cen ter
No Service 11:5 0
Add friends share
Add by network cable
Add device
sca n the QR co de to a dd
Add b y WiFi
No Se rvice 11:5 0
WiFi setting
Confirm
please confirm the SSID and password arecorrect,
and SSID matches the WiFi of device
Reset
PASS WORD
No Service 11:5 0
Camera does not support 5G Wi -Fi;i f this is n ot the
network you want,click to change
WiFi setting
Confirm
please confirm the SSID and password arecorrect,
and SSID matches the WiFi of device
Reset
PASS WORD
No Service 11:5 0
Camera does not support 5G Wi -Fi;i f this is n ot the
network you want,click to change
1.Click “Add Camera scan the QR code to add
(figure 5)
(figure 4) Click
2.Configure WIFI, enter WiFi name and password, and
Confirm” after that. (figure 6)P.S:Device does not support 5G
Wi-Fi network; if this is not your desired network, tap to toggle.
(figure 7)
Click
(4) (5)
(6) (7)
Scan QR Code Album
No Service 11:5 0
Add Dev ice
Next
Device NameCamera
Sca n
ID
No Se rvice 11:5 0
Press and hold the SET key for 1 second and then
you will hear Star t Configurtion Mode
Album
No Service 11:5 0
4.Click the QR code icon (Figure 9) , switch to the QR code
scanning mode, and scan the ID QR code
QR Code on the camera sticker (Figure 10) ;
Or choose the QR code picture from the album for ID scanning
(Figure 11)
5.When the APP Switch to the precaution page before scanning,
please read the prompts carefully and click "Next step"(Figure 12)
When the mobile phone shows a QR code interface, please align
the QR code to the camera, with a distance of about 10 ~ 20cm
(Figure 13); if scanning succeeds, you will hear “Beep”twice.
3.Please press the “SET” key for 1 second, and then
you will hear a “Beep” sound(figure 8)
(8)
(9) (10) (11)
10-20cm
I Have Heard It
Put t his QR co de at 10- 20cm fr om the
cam era, an d when yo u hear a "b eep"
pro mpt sou nd, cli ck “I hav e hear d it”
Confirm
No pr ompt so und
Scan QR Code
No Se rvice 11:5 0
Scan QR Code
I have heard it
Did y ou hear a “ beep” so und?
Did n ot hear a ny soun d?
No Service 11:5 0
Device List
Add device
Experience Center
Liv ing Roo m
No Service 11:5 0
Living Room
2017/04/21 13:00
31°C
No Se rvice 11:5 0
Speak
Sound Snapshot
6.After scan the QR Code, and when you hear "Beep" twice Click “I
Have Heard It(Figure 14), and now the camera is connecting to the
router WiFi. When you see that the indicator on the device turns from
blinking green to be steady on, it indicates that the device is connected
and will automatically skip to the device list. (Figure 15)
Click the device to enter the real-time monitoring interface.(Figure 16)
(12) (13)
(16)(15)(14)
Add by WIFI
Device List
Add device
Experience Center
No Service 11:5 0
Add friends share
Add by network cable
Add device
sca n the QR co de to a dd
Add b y WiFi
No Se rvice 11:5 0
WiFi setting
Confirm
please confirm the SSID and password arecorrect,
and SSID matches the WiFi of device
Reset
PASS WORD
No Service 11:5 0
Camera does not support 5G Wi -Fi;i f this is n ot the
network you want,click to change
1.Click “Add Camera Add by WIFI
Figure 18)→ Configure WIFI, enter WiFi name and password,
and click “Confirm” after that.(Figure 19)P.S:Device does not
support 5G Wi-Fi network; if this is not your desired network,
Click to toggle
(Figure 17) Click (
2.Please press and hold the “SET” key for 1 second, and then
you will hear a “Beep” sound(Figure 20)
3.Click the QR code icon (Figure 21) , switch to the QR code
scanning mode, and scan the ID QR code
QR Code on the camera sticker (Figure 22) ;
Or choose the QR code picture from the album for ID scanning
(Figure 23)
(17) (18) (19)
(20)
Add by Wi Fi
It will take about 1-2 minutes to WiFi network,
please wait
con necti ng fail de in ove r 2 min ute s
Ste p 1: Connec ting
Ste p 3: Connec t succe eded
Ste p 2: Bindin g
No Service 11:5 0
Device List
Add device
Exper ience Cen ter
Living Room
No Service 11:5 0
Living Room
2017/04/21 13:00
31°C
No Se rvice 11:5 0
Speak
Sound Snapshot
Scan QR Code Album
No Service 11:5 0
Add Device
Next
Device NameCamera
Sca n
ID
No Service 11:5 0
Press and hold the SET key for 1 second and then
you will hear Star t Configurtion Mode
Album
No Service 11:5 0
4.
indicates that the camera is connecting to the router.(Figure 24)
When you see that the indicator on the device turns from blinking
green to be steady on, it indicates that the device is connected
and will automatically skip to the device list. (Figure 25)
Click the device to enter the real-time monitoring interface.
(Figure 26)
After you click “Confirm”, when you will hear “Beeptwice,
(21) (22) (23)
(24) (25) (26)
Living Room
2017/04/21 13:00
31°C
No Se rvice 11:5 0
Speak
Sound Snapshot
HD
3
7
9
5
6
8
3
2
4
1
View Monitoring and Operate
After the device is connected, you can view real-time
monitoring, and take a picture, record a video, speak, set
up and make other operations on your mobile phone.
1. Voice button: Click to close/disclose the voice
2. Talkback button: press and hold this button to talk with the
camera.
3. Capture button: click to fast capture (save in the settings
directory Album Book option).
4. Playback button: Click to enter the playback page, you can
view the camera SD card video file.
5. Record button: Click to start recording, click the button again
(stored in the set the directory of the album option).
6. PTZ button: Click this button, APP pop-up PTZ control interface
for Head level \ vertical angle to adjust (Figure 28).
7. Sharpness button: Click to adjust the Resolution pixel for
real-time video monitoring (HD/SD)
8.Thermometer: Real-time temperature detection
9.Set button: Click this button to set the camera-related functions.
Living Room
2017/04/21 13:00
31°C
No Se rvice 11:5 0
HD
Roc ker
(27) (28)
Software Upgrade
1. Click “Settings” icon Click “Device Information
(Figure 30) Click “System Firmware” (Figure 31) Click “Update
Now” (Figure 32)(It can only be upgraded if there is a small red spot
on the top right corner of the application firmware)
(Figure 29)
4Features
2017/04/21 13:00
31°C
Living Room
No Se rvice 11:5 0
Speak
Sound Snapshot
No Se rvice 11:5 0
Can Upd ate t o 00.0 0.00.01
1.Optimize APP network pairing
pro cedur e
2.Optimize…
3.Optimize…
Upd ate Now Another Time
Update
No Se rvice 11:5 0
Setting
Sta tus indicator
Rot ate video 180 degrees
Night vision
Sha re with f riend s
WiF i set ting
Device information
Delete device
Album
Camera time c heck
No Se rvice 11:5 0
(29) (30)
(32) (31)
-11-
Device Unbinding
1. Settings” icon “Delete Device”
APP will automatically switch to camera list, delete the camera you
want to Unbundled it from the APP
Click (Figure 33) Click (Figure 34)
Setting
Sta tus indicator
Rot ate video 180 degrees
Night vision
Share with friends
WiF i set ting
Device information
Delet e device
Album
Camera time c heck
No Se rvice 11:5 0
Living Room
2017/04/21 13:00
31°C
No Se rvice 11:5 0
Speak
Sound Snapshot
Generate a QR code for sharing(can share this QR Code to
multi- users)
1. Clicksetting” icon(Figure 35) Click "share with friends"
(Figure 36) you can have the QR code(Figure 37)
Add Friends to Share
Setting
Sta tus indicator
Rot ate video 180 degrees
Night vision
Share with friends
WiF i setting
Device information
Delet e device
Album
Camera time c heck
No Se rvice 11:5 0
share with friends
Steps to share with friends
Step 1:OpenAdd Cameraon the mobile phone of
a friend
Step 2:Select the fourth way to add,and scan QR
code
No Se rvice 11:5 0
Living Room
2017/04/21 13:00
31°C
No Se rvice 11:5 0
Speak
Sound Snapshot
(33) (34)
(35) (36) (37)
Add friends share
Add by network cable
Add device
sca n the QR co de to a dd
Add b y WiFi
No Se rvice 11:5 0
Add Device
Sca nID
No Service 11:5 0
Scan the QR code for sharing with friends
Device List
Add device
Experience Center
Living Room
No Service 11:5 0
Indicates that power failure or network not
connected.
Red indicator
remains
Red indicator
flashes
Indicates that camera is connecting to
network.
Green
indicator
flashes
Indicates the router connected
successfully (no Internet).
Green
indicator
remains
Indicates the camera is connected to server
and working well.
Camera Indicator Instruction
5
(38) (39) (40)
If other users want to add the camera, Click "Add Camera"
sele ct "Add Friends to Shar e" mode(Figure 38)Click the QR
code icon (Figure 39) , switch to the QR code scanning
modescan the QR code shared by friendsEnter the Device
List(Figure 40)

Navigation menu
