Grand Mate TX143 Remote controller User Manual
Grand Mate Co., Ltd Remote controller
User Manual
1/3
TX121 Remote Electronic Ignition and Control System
OPERATING INSTRUCTIONS -FOR OEM USE ONLY
Fire or explosion hazard. Attempted disassembly or repair
of controls can cause property damage, severe injury or
death. Do not disassemble the gas valve; it contains no ser-
viceable components.
Read these instructions carefully. Failure to follow them
could result in a fire or explosion causing property dam-
age, personal injury, or loss of life. The product must be installed
and operated according to all local regulations.
A.
● Do not light any appliance.
● Do not touch any electrical switch; do not use any
phone in your building.
●
● If you cannot reach the gas supplier, call the fire de-
partment.
B. Use only your hand to push in or turn the gas control
knobs. Never use tools. If a knob will not push in or turn
by hand, don’t try to repair it, call a qualified service tech-
nician. Force or attempted repair may result in a fire or
explosion.
C. Do not use this control or any gas appliance if any part has
been under water or in contact with water. Immediately call
a qualified service technician to replace the control sys-
tem and any gas control system which has been under
water or in contact with water.
D. These instructions are to be referenced as a user guide,
and do not supersede appliance manufacturer’s lighting
instructions.
APPLICATION
TX121 is a battery-powered electronic remote ignition and
control system for gas appliances with pilot burners and ODS
systems.
GENERAL NOTES
TX121
Radio frequency Remote
315 MHz for US, Canada;
⚠WARNING
NOTE: This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This de-
vice may not cause harmful interference, and (2) This device must
accept any interference received, including interference that may
cause undesired operation. Changes or modifications not ex-
pressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency ener-
gy and, if not installed and used in accordance with the instruc-
tions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful in-
terference to radio or television reception, which can be deter-
mined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the follow-
ing measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for
help.
NOTE: This device complies with CAN ICES-3 (B)/NMB-3(B)
◆ This product meets the applicable Innovation, Science and
Economic Development Canada technical specifications.
Ce produit repond aux specifications techniques applicables a
l'innovation, Science et Developpement economique Canada.
◆ Canadian Compliance Statement
This device complies with Industry Canada license-exempt
RSSs. Operation is subject to the following two conditions:
1) This device may not cause interference, and
2) This device must accept any interference, including
interference that may cause undesired operation of the
device.
Le present appareil est conforme aux CNR d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploita-
tion est autorisee aux deux conditions suivantes :
1) l’appareil ne doit pas produire de brouillage;
2) l’utilisateur de l’appareil doit accepter tout brouillage
radioelectrique subi, meme si le brouillage est suscepti-
ble d’en compromettre le fonctionnement.
Batteries - Remote Handset:
3 x1.5V “AAA” (quality alkaline recommended)
4.5V 100mA
NOTE: These remote handsets, receiver, wall switches, are not in-
terchangeable with previous versions.
For all lighting/ignition instructions please refer to appliance manu-
facturer’s instructions.
TX121—Operating Instructions D02
2/3
TX143 SERIES REMOTE HANDSET FEATURES
Remote
Controller
Model
315MHz
Unidirectional
TX121 TX142 TX143
ON/ OFF ★ ★ ★
Childproof ★ ★ ★
Revo Home Compatible ★ ★ ★
Flame Height Adjustment ★ ★
Standing Pilot* ★
LCD
Low Battery Indicator
Second Burner
Thermostat
Timer
Error Code Notification*
Fan Speed ★
Light Dimmer
AUX ON/ OFF
Fan Delay ON/ OFF
Clock
Daily Program Thermostat
3 Independent Access Keys
*Disabled for Europe
TX121 TX142 TX143
TX121—Operating Instructions D02
3/3
TURN ON THE FIRE
Press button, the
● Main burner and rear burner turn on
once pilot ignition is confirmed.
● Main gas goes Max flame height first,
and will goes last flame height memory.
TURN OFF THE FIRE
Press button,
NOTE: There is a 3 second delay
before the next ignition is
possible.
CHILDPROOF
There’s a slide switch can select
lock or unlock.
Lock: The handset is rendered in-
operable include the off function.
Wiring of valve and receiver must be completed be-
fore starting ignition. Failure to do so could damage
the electronics.
⚠WARNING
When pilot ignition is confirmed, main flame valve turn
on to maximum flame height.
MISCELLANEOUS
Battery replacement
Battery replacement is recommended at the beginning of
each heating season. Do not use metal tools to remove bat-
teries. Using a metal tool could cause a short that may
damage the receiver.
Dexen Industries, Inc
9220 Norwalk Blvd
Santa Fe Springs, CA 90670
Tel: +1 5626998490
1/4
TX142 Remote Electronic Ignition and Control System
OPERATING INSTRUCTIONS -FOR OEM USE ONLY
Fire or explosion hazard. Attempted disassembly or repair
of controls can cause property damage, severe injury or
death. Do not disassemble the gas valve; it contains no ser-
viceable components.
Read these instructions carefully. Failure to follow them
could result in a fire or explosion causing property dam-
age, personal injury, or loss of life. The product must be installed
and operated according to all local regulations.
A.
● Do not light any appliance.
● Do not touch any electrical switch; do not use any
phone in your building.
●
● If you cannot reach the gas supplier, call the fire de-
partment.
B. Use only your hand to push in or turn the gas control
knobs. Never use tools. If a knob will not push in or turn
by hand, don’t try to repair it, call a qualified service tech-
nician. Force or attempted repair may result in a fire or
explosion.
C. Do not use this control or any gas appliance if any part has
been under water or in contact with water. Immediately call
a qualified service technician to replace the control sys-
tem and any gas control system which has been under
water or in contact with water.
D. These instructions are to be referenced as a user guide,
and do not supersede appliance manufacturer’s lighting
instructions.
APPLICATION
TX142 is a battery-powered electronic remote ignition and
control system for gas appliances with pilot burners and ODS
systems.
GENERAL NOTES
TX142
Radio frequency Remote
315 MHz for US, Canada;
⚠ WARNING
NOTE: This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This de-
vice may not cause harmful interference, and (2) This device must
accept any interference received, including interference that may
cause undesired operation. Changes or modifications not ex-
pressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency ener-
gy and, if not installed and used in accordance with the instruc-
tions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful in-
terference to radio or television reception, which can be deter-
mined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the follow-
ing measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for
help.
NOTE: This device complies with CAN ICES-3 (B)/NMB-3(B)
◆ This product meets the applicable Innovation, Science and
Economic Development Canada technical specifications.
Ce produit repond aux specifications techniques applicables a
l'innovation, Science et Developpement economique Canada.
◆ Canadian Compliance Statement
This device complies with Industry Canada license-exempt
RSSs. Operation is subject to the following two conditions:
1) This device may not cause interference, and
2) This device must accept any interference, including
interference that may cause undesired operation of the
device.
Le present appareil est conforme aux CNR d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploita-
tion est autorisee aux deux conditions suivantes :
1) l’appareil ne doit pas produire de brouillage;
2) l’utilisateur de l’appareil doit accepter tout brouillage
radioelectrique subi, meme si le brouillage est suscepti-
ble d’en compromettre le fonctionnement.
Batteries - Remote Handset:
3 x1.5V “AAA” (quality alkaline recommended)
4.5V 100mA
NOTE: These remote handsets, receiver, wall switches, are not in-
terchangeable with previous versions.
For all lighting/ignition instructions please refer to appliance manu-
facturer’s instructions.
TX142—Operating Instructions D03
2/3
TX143 SERIES REMOTE HANDSET FEATURES
Remote
Controller
Model
315MHz
Unidirectional
TX121 TX142 TX143
ON/ OFF ★ ★ ★
Childproof ★ ★ ★
Revo Home Compatible ★ ★ ★
Flame Height Adjustment ★ ★
Standing Pilot* ★
LCD
Low Battery Indicator
Second Burner
Thermostat
Timer
Error Code Notification*
Fan Speed ★
Light Dimmer
AUX ON/ OFF
Fan Delay ON/ OFF
Clock
Daily Program Thermostat
3 Independent Access Keys
*Disabled for Europe
TX121 TX142 TX143
TX142—Operating Instructions D03
3/3
TURN ON THE FIRE
Press button, the
● Main burner and rear burner turn on
once pilot ignition is confirmed.
● Main gas goes Max flame height first,
and will goes last flame height memory.
FLAME HEIGHT ADJUSTMENT
Handset
During the appliance flame on, briefly
pressing the button changes the
flame height in the following order:
Flame height 3 2 1 and back to 3.
TURN OFF THE FIRE
Press button,
NOTE: There is a 3 second delay
before the next ignition is
possible.
CHILDPROOF
There’s a slide switch can select
lock or unlock.
Lock: The handset is rendered in-
operable include the off function.
Wiring of valve and receiver must be completed be-
fore starting ignition. Failure to do so could damage
the electronics.
⚠ WARNING
When pilot ignition is confirmed, main flame valve turn
on to maximum flame height.
PILOT FLAME
Handset
Press button to activate appliance
to pilot flame.
Press button to deactivate appli-
ance to pilot flame.
FAN SPEED ADJUSTMENT
Handset
During the appliance flame on, briefly
pressing the button changes the
fan speed of thermostat in the follow-
ing order:
Fan speed 3 2 1 0 and back
to Fan speed 3
MISCELLANEOUS
Battery replacement
Battery replacement is recommended at the beginning of
each heating season. Do not use metal tools to remove bat-
teries. Using a metal tool could cause a short that may
damage the receiver.
Dexen Industries, Inc
9220 Norwalk Blvd
Santa Fe Springs, CA 90670
Tel: +1 5626998490
1/3
TX143 Remote Electronic Ignition and Control System
OPERATING INSTRUCTIONS -FOR OEM USE ONLY
Fire or explosion hazard. Attempted disassembly or repair
of controls can cause property damage, severe injury or
death. Do not disassemble the gas valve; it contains no ser-
viceable components.
Read these instructions carefully. Failure to follow them
could result in a fire or explosion causing property dam-
age, personal injury, or loss of life. The product must be installed
and operated according to all local regulations.
A.
● Do not light any appliance.
● Do not touch any electrical switch; do not use any
phone in your building.
●
● If you cannot reach the gas supplier, call the fire de-
partment.
B. Use only your hand to push in or turn the gas control
knobs. Never use tools. If a knob will not push in or turn
by hand, don’t try to repair it, call a qualified service tech-
nician. Force or attempted repair may result in a fire or
explosion.
C. Do not use this control or any gas appliance if any part has
been under water or in contact with water. Immediately call
a qualified service technician to replace the control sys-
tem and any gas control system which has been under
water or in contact with water.
D. These instructions are to be referenced as a user guide,
and do not supersede appliance manufacturer’s lighting
instructions.
NOTE: This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This de-
vice may not cause harmful interference, and (2) This device must
accept any interference received, including interference that may
cause undesired operation. Changes or modifications not ex-
pressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency ener-
gy and, if not installed and used in accordance with the instruc-
tions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful in-
terference to radio or television reception, which can be deter-
mined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the follow-
ing measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for
help.
APPLICATION
TX143 is a battery-powered electronic remote ignition and
control system for gas appliances with pilot burners and ODS
systems.
GENERAL NOTES
TX143
Radio frequency Remote
315 MHz for US, Canada;
⚠WARNING
NOTE: This device complies with CAN ICES-3 (B)/NMB-3(B)
◆ This product meets the applicable Innovation, Science and
Economic Development Canada technical specifications.
Ce produit repond aux specifications techniques applicables a
l'innovation, Science et Developpement economique Canada.
◆ Canadian Compliance Statement
This device complies with Industry Canada license-exempt
RSSs. Operation is subject to the following two conditions:
1) This device may not cause interference, and
2) This device must accept any interference, including
interference that may cause undesired operation of the
device.
Le present appareil est conforme aux CNR d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploita-
tion est autorisee aux deux conditions suivantes :
1) l’appareil ne doit pas produire de brouillage;
2) l’utilisateur de l’appareil doit accepter tout brouillage
radioelectrique subi, meme si le brouillage est suscepti-
ble d’en compromettre le fonctionnement.
Batteries - Remote Handset:
3 x1.5V “AAA” (quality alkaline recommended)
4.5V 100mA
NOTE: These remote handsets, receiver, wall switches, are not in-
terchangeable with previous versions.
For all lighting/ignition instructions please refer to appliance manu-
facturer’s instructions.
TX143—Operating Instructions D03
2/3
TX143 SERIES REMOTE HANDSET FEATURES
Remote
Controller
Model
315MHz
Unidirectional
TX121 TX142 TX143
ON/ OFF ★ ★ ★
Childproof ★ ★ ★
Revo Home Compatible ★ ★ ★
Flame Height Adjustment ★ ★
Standing Pilot* ★
LCD
Low Battery Indicator
Second Burner
Thermostat
Timer
Error Code Notification*
Fan Speed ★
Light Dimmer
AUX ON/ OFF
Fan Delay ON/ OFF
Clock
Daily Program Thermostat
3 Independent Access Keys
*Disabled for Europe
TX121 TX142 TX143
TX143—Operating Instructions D03
3/3
TURN ON THE FIRE
Press button, the
● Main burner and rear burner turn on
once pilot ignition is confirmed.
● Main gas goes Max flame height first,
and will goes last flame height memory.
FLAME HEIGHT ADJUSTMENT
Handset
During the appliance flame on, briefly
pressing the or button chang-
es the flame height.
TURN OFF THE FIRE
Press button,
NOTE: There is a 3 second delay
before the next ignition is
possible.
CHILDPROOF
There’s a slide switch can select
lock or unlock.
Lock: The handset is rendered in-
operable include the off function.
Wiring of valve and receiver must be completed be-
fore starting ignition. Failure to do so could damage
the electronics.
⚠WARNING
When pilot ignition is confirmed, main flame valve turn
on to maximum flame height.
MISCELLANEOUS
Battery replacement
Battery replacement is recommended at the beginning of
each heating season. Do not use metal tools to remove bat-
teries. Using a metal tool could cause a short that may
damage the receiver.
Dexen Industries, Inc
9220 Norwalk Blvd
Santa Fe Springs, CA 90670
Tel: +1 5626998490
