GuangZhou SunFieldAimo Electronic Technology CG-1301 Single Axis Wireless Mini Controller User Manual Mini Fingerwheel Controller Manual
GuangZhou SunFieldAimo Electronic Technology Co., Ltd Single Axis Wireless Mini Controller Mini Fingerwheel Controller Manual
User Manual
MANUAL BOOK
© 2017 Cine Gears INC. All Rights Reserved.
Single Axis
Wireless Mini Controller
Product Name: Single Axis Wireless Mini Controller
Brand: CINEGEARS
Model:CG-1301,CG-2107
Manufacture: GuangZhou SunFieldAimo Electronic Technology Co., Ltd
Instructions
Turn On/Off the Fingerwheel Controller
Hold the (REC) button for three seconds to turn the Fingerwheel Controller On/Off. Hold the (REC) button
on your Fingerwheel controller for three seconds to turn it on. When your Fingerwheel Controller is on,
hold the (REC) button for three seconds to turn it off. The number that shows up on your Fingerwheel
controller when you turn it on will show the Fingerwheel controller’s battery percentage.
Synchronize the Fingerwheel Controller
Hold the button on the motor for three seconds then hold all three buttons on the Fingerwheel switch
controller for three seconds. Hold the button on your motor for three seconds, when it changes from flashing
blue to green, press and hold all three buttons, (REC), (A) and (B) on your Fingerwheel controller for three
seconds. In this way, it synchronizes both the Fingerwheel controller and motor together.
Automatic Lens Calibration
Hold the (REC) and (A) button for three seconds. After your Fingerwheel controller and motor are
synchronized, press and hold (REC) and (A) button on your Fingerwheel controller at the same time for
three seconds, this activates the automatic lens calibration. This option is for the camera lens that has the
hard stops. For the camera lens that does not have the hard stops, read the following manual lens
calibration below.
Manual Lens Calibration
Hold the (REC) and (B) button for three seconds. Press the (A) button to rotate the lens clockwise, and then
press the (A) button again to stop the rotation and press the (REC) button to set the start point. Press the
(B) button to rotate counter clockwise and press the (B) button again to stop the rotation, and then press the
(REC) button to choose the end point. After your Fingerwheel controller and motor are synchronized, press
and hold the (REC) and the (B) button on your Fingerwheel Controller at the same time for three
seconds until S-1 flashes.Then press and hold the (A) button for three seconds until the gear rotates. When
your camera lens reaches the minimum focus distance, press on the (A) button again which makes the gear
stop rotating. Then press the (REC) button to set your camera minimum focus distance point. After you set
the minimum focus distance point, S-2 should be flashing. Then press and hold the (B) button for three
seconds, the gear will then rotate to the opposite direction. When it reaches your camera’s maximum focus
distance point, you have to press the (B) button again to stop the rotation of the gear. Then press the (REC)
button to set the camera’s maximum focus distance. Remember, you can always press on the (A) button or
the (B) button for the micro adjustments when it passes the camera’s focus distance.
Setting up Two Preset Points
Push the switch, press and hold (A) and (B) button for three seconds Push the Fingerwheel switch on your
Fingerwheel controller to a lens focus distance point, then press and hold the (A) button for three seconds
to record that point. Then move on to the next lens focus distance point, press and hold the (B) button for
three seconds to record your second lens focus distance point.
© 2017 Cine Gears INC. All Rights Reserved. 1
Instructions
© 2017 Cine Gears INC. All Rights Reserved. 2
Setting up a Preset
Hold the (A) and (B) button for three seconds to get the accessibility to the espresso function manual. F01
is the motor rotating speed option. F03 is the manual lens calibration option. F05 is the recalibrating focus
controller option. When you press and hold the (A) and (B) button on your Fingerwheel controller for three
seconds, this gives you the accessibility to your espresso controller’s function manual. To enter each function
you can just simply press the (REC) button. The F01 Function is the speed control which makes the gear
rotate at a different range of speeds. Press on the (A) button or (B) button to change the number, the larger
the number goes, the faster the gear rotates. After you choose a speed number, press the (REC) button again
to let your Fingerwheel controller to record that number.
Recalibrating the Focus Controller
After you get to your Fingerwheel controller function manual, go to the F05 function. Push your Fingerwheel
switch to the beginning point then press the (REC) button. Push your Fingerwheel switch again to a distance
that you want then press the (REC) button again. First, go to your Fingerwheel function manual by pressing
and holding the (A) and (B) button for three seconds at the same time. Then, go to the F05 function by
pressing the (B) button for four times and press the (REC) button to enter that function. Push your
Fingerwheel switch to beginning point and hold the (REC) button to record that rotation angle. Then push the
switch again to your designated rotation angle, and hold the (REC) button again to record your second rotation
angle. This sets up your full camera lens traveling distance to the angle you have set. In other words, the
rotating distances of your camera lens will length while the distance of the controller will shorten.
Manual Function Controls
To access the function menu, hold down the A and B buttons for 3 seconds. You can navigate between
functions with the A (Back) and B (Forward) buttons. Select function to adjust with REC button. Some
functions are adjusted with the A (Reduce) and B (Increase) buttons, while others are adjusted with the
Fingerwheel Switch itself.
F01 – Speed Adjustment setting. Choose from 1 -15 using the A and B buttons, 1 being the
slowest speed and 15 being the fastest.
F02 – Automatic Motor Calibration. Yields the same result as holding down REC, A and B for
3 seconds.
F03 – Manual lens Calibration. Allows you to manually set the maximum and minimum motor
positions.
F04 – EXIT. This function exits the menu without any changes.
F05 – Manual Range. This will allow you to set the effective range of your Fingerwheel
Switch.
F06 – Reverse Spin Direction. Determines which way the motor will spin, it yields the same
result as the button on the motor itself.
F07 – Flip the LED display. This function flips the LED display upside-down, for those who
prefer to use the Fingerwheel Switch in different ways.
FCC Caution.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
IC Warning
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to
the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts
de licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement
