HTC PL POLA100 User Manual 2 Revised 0725

HTC Corporation POLA100 2 Revised 0725

User Manual 2 Revised 0725

www.htc.com

PDA Phone

User Manual

Please Read Before Proceeding

THE BATTERY IS NOT CHARGED WHEN YOU TAKE IT OUT OF THE BOX.

DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS CHARGING.

YOUR WARRANTY IS INVALIDATED IF YOU OPEN OR TAMPER WITH THE

DEVICE’S OUTER CASING.

PRIVACY RESTRICTIONS

Some countries require full disclosure of recorded telephone conversations,

and stipulate that you must inform the person with whom you are speaking

that the conversation is being recorded. Always obey the relevant laws and

regulations of your country when using the recording feature of your PDA

Phone.

INTELLECTUAL PROPERTY RIGHT INFORMATION

, , ExtUSB, HTC Touch, Touch Cruise, TouchFLO, and HTC

Care are trademarks and/or service marks of High Tech Computer Corp.

Microsoft, MS-DOS, Windows, Windows NT, Windows Server, Windows

Mobile, Windows XP, Windows Vista, ActiveSync, Windows Mobile Device

Center, Internet Explorer, MSN, Hotmail, Windows Live, Outlook, Excel,

PowerPoint, Word, and Windows Media are either registered trademarks

or trademarks of Microsoft Corporation in the United States and/or other

countries.

Bluetooth and the Bluetooth logo are trademarks owned by Bluetooth SIG,

Inc.

Wi-Fi is a registered trademark of the Wireless Fidelity Alliance, Inc.

microSD is a trademark of SD Card Association.

Java, J2ME and all other Java-based marks are trademarks or registered

trademarks of Sun Microsystems, Inc. in the United States and other

countries.

Macromedia, Flash, Macromedia Flash, Macromedia Flash Lite and Reader

are trademarks and/or registered trademarks of Macromedia Netherlands,

B.V. or Adobe Systems Incorporated.

Sprite Backup is a trademark or service mark of Sprite Software.

trademarks of ArcSoft, Inc. in the United States and/or other countries.

All other company, product and service names mentioned herein are

trademarks, registered trademarks or service marks of their respective

owners.

HTC shall not be liable for technical or editorial errors or omissions

contained herein, nor for incidental or consequential damages resulting

from furnishing this material. The information is provided “as is” without

warranty of any kind and is subject to change without notice. HTC also

reserves the right to revise the content of this document at any time

without prior notice.

No part of this document may be reproduced or transmitted in any form or

by any means, electronic or mechanical, including photocopying, recording

or storing in a retrieval system, or translated into any language in any form

without prior written permission of HTC.

Disclaimers

THE WEATHER INFORMATION, DATA AND DOCUMENTATION ARE PROVIDED

“AS IS” AND WITHOUT WARRANTY OR TECHNICAL SUPPORT OF ANY KIND

FROM HTC. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,

HTC AND ITS AFFILIATES expressly disclaim any and all representations

and warranties, express or implied, arising by law or otherwise, regarding

the Weather Information, Data, Documentation, or any other Products

and services, including without limitation any express or implied warranty

of merchantability, express or implied warranty of fitness for a particular

purpose, non-infringement, quality, accuracy, completeness, effectiveness,

reliability, usefulness, that the Weather Information, Data and/or

Documentation will be error-free, or implied warranties arising from course

of dealing or course of performance.

Without limiting the foregoing, it is further understood that HTC and

its Providers are not responsible for Your use or misuse of the Weather

Information, Data and/or Documentation or the results from such use.

HTC and its Providers make no express or implied warranties, guarantees

or affirmations that weather information will occur or has occurred as

the reports, forecasts, data, or information state, represent or depict and

it shall have no responsibility or liability whatsoever to any person or

entity, parties and non-parties alike, for any inconsistency, inaccuracy, or

omission for weather or events predicted or depicted, reported, occurring

or occurred. WITHOUT LIMITING THE GENERALITY OF THE FOREGOING,

YOU ACKNOWLEDGE THAT THE WEATHER INFORMATION, DATA AND/OR

DOCUMENTATION MAY INCLUDE INACCURACIES AND YOU WILL USE

COMMON SENSE AND FOLLOW STANDARD SAFETY PRECAUTIONS IN

CONNECTION WITH THE USE OF THE WEATHER INFORMATION, DATA OR

DOCUMENTATION.

Limitation of Damages

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT

SHALL HTC OR ITS PROVIDERS BE LIABLE TO USER OR ANY THIRD PARTY

FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, INCIDENTAL OR PUNITIVE

DAMAGES OF ANY KIND, IN CONTRACT OR TORT, INCLUDING, BUT NOT

LIMITED TO, INJURY, LOSS OF REVENUE, LOSS OF GOODWILL, LOSS OF

BUSINESS OPPORTUNITY, LOSS OF DATA, AND/OR LOSS OF PROFITS

ARISING OUT OF, OR RELATED TO, IN ANY MANNER, OR THE DELIVERY,

PERFORMANCE OR NONPERFORMANCE OF OBLIGATIONS, OR USE OF

THE WEATHER INFORMATION, DATA OR DOCUMENTATION HEREUNDER

REGARDLESS OF THE FORESEEABILITY THEREOF.

Important Health Information and Safety Precautions

When using this product, the safety precautions below must be taken to

avoid possible legal liabilities and damages.

Retain and follow all product safety and operating instructions. Observe all

warnings in the operating instructions on the product.

To reduce the risk of bodily injury, electric shock, fire, and damage to the

equipment, observe the following precautions.

ELECTRICAL SAFETY

This product is intended for use when supplied with power from the

designated battery or power supply unit. Other usage may be dangerous

and will invalidate any approval given to this product.

SAFETY PRECAUTIONS FOR PROPER GROUNDING INSTALLATION

CAUTION: Connecting to an improperly grounded equipment can result in

an electric shock to your device.

This product is equipped with a USB cable for connecting the product

to a desktop or notebook computer. Be sure your computer is properly

grounded (earthed) before connecting the product to the computer. The

power supply cord of a desktop or notebook computer has an equipment-

grounding conductor and a grounding plug. The plug must be plugged

into an appropriate outlet which is properly installed and grounded in

accordance with all local codes and ordinances.

SAFETY PRECAUTIONS FOR POWER SUPPLY UNIT

• Use the correct external power source

A product should be operated only from the type of power source

indicated on the electrical ratings label. If you are not sure of the type

of power source required, consult your authorized service provider or

local power company. For a product that operates from battery power

or other sources, refer to the operating instructions that are included

with the product.

• Handle battery packs carefully

This product contains a Li-ion battery. There is a risk of fire and burns

if the battery pack is handled improperly. Do not attempt to open or

service the battery pack. Do not disassemble, crush, puncture, short

external contacts or circuits, dispose of in fire or water, or expose a

battery pack to temperatures higher than 60˚C (140˚F).

WARNING: Danger of explosion if battery is incorrectly replaced.

To reduce risk of fire or burns, do not disassemble, crush, puncture,

short external contacts, expose to temperature above 60°C (140°F),

or dispose of in fire or water. Replace only with specified batteries.

Recycle or dispose of used batteries according to the local regulations

or reference guide supplied with your product.

• Take extra precautions

• Keep the battery or device dry and away from water or any liquid

as it may cause a short circuit.

• Keep metal objects away so they don’t come in contact with the

battery or its connectors as it may lead to short circuit during

operation.

• Do not use a battery that appears damaged, deformed, or

discolored, or the one that has any rust on its casing, overheats, or

emits a foul odor.

• Always keep the battery out of the reach of babies and small

children, to avoid swallowing of the battery. Consult the doctor

immediately if the battery is swallowed.

If the battery leaks:

• Do not allow the leaking fluid to come in contact with skin

or clothing. If already in contact, flush the affected area

immediately with clean water and seek medical advice.

• Do not allow the leaking fluid to come in contact with eyes.

If already in contact, DO NOT rub; rinse with clean water

immediately and seek medical advice.

• Take extra precautions to keep a leaking battery away from fire

as there is a danger of ignition or explosion.

• Communicate the appropriate steps immediately in case a hazard

occurs

SAFETY PRECAUTIONS FOR DIRECT SUNLIGHT

Keep this product away from excessive moisture and extreme temperatures.

Do not leave the product or its battery inside a vehicle or in places where

the temperature may exceed 60°C (140°F), such as on a car dashboard,

window sill, or behind a glass that is exposed to direct sunlight or strong

ultraviolet light for extended periods of time. This may damage the product,

overheat the battery, or pose a risk to the vehicle.

PREVENTION OF HEARING LOSS

CAUTION: Permanent hearing loss may occur if earphones or

headphones are used at high volume for prolonged periods of time.

NOTE: For France, Headphones and Earphones (listed below) for this device

have been tested to comply with the Sound Pressure Level requirement laid

down in the applicable NF EN 50332-1:2000 and/or NF EN 50332-2:2003

standards as required by French Article L. 5232-1.

• Earphone, manufactured by HTC, Model name: HS S168 and S200.

SAFETY IN AIRCRAFT

Due to the possible interference caused by this product to an aircraft’s

navigation system and its communications network, using this device’s

phone function on board an airplane is against the law in most countries. If

you want to use this device when on board an aircraft, remember to turn off

the phone by switching to Flight Mode.

ENVIRONMENT RESTRICTIONS

Do not use this product in gas stations, fuel depots, chemical plants or

where blasting operations are in progress, or in potentially explosive

atmospheres such as fuelling areas, fuel storehouses, below deck on

boats, fuel or chemical transfer or storage facilities, and areas where the

air contains chemicals or particles, such as grain, dust, or metal powders.

Please be aware that sparks in such areas could cause an explosion or fire

resulting in bodily injury or even death.

EXPLOSIVE ATMOSPHERES

When in any area with a potentially explosive atmosphere or where

flammable materials exist, the product should be turned off and the user

should obey all signs and instructions. Sparks in such areas could cause an

explosion or fire resulting in bodily injury or even death. Users are advised

not to use the equipment at refueling points such as service or gas stations,

and are reminded of the need to observe restrictions on the use of radio

equipment in fuel depots, chemical plants, or where blasting operations

are in progress. Areas with a potentially explosive atmosphere are often,

but not always, clearly marked. These include fueling areas, below deck on

boats, fuel or chemical transfer or storage facilities, and areas where the air

contains chemicals or particles, such as grain, dust, or metal powders.

ROAD SAFETY

Vehicle drivers in motion are not permitted to use telephony services with

handheld devices, except in the case of emergency. In some countries,

using hands-free devices as an alternative is allowed.

SAFETY PRECAUTIONS FOR RF EXPOSURE

• Avoid using your device near metal structures (for example, the steel

frame of a building).

• Avoid using your device near strong electromagnetic sources, such as

microwave ovens, sound speakers, TV and radio.

• Use only original manufacturer-approved accessories, or accessories

that do not contain any metal.

• Use of non-original manufacturer-approved accessories may violate

your local RF exposure guidelines and should be avoided.

INTERFERENCE WITH MEDICAL EQUIPMENT FUNCTIONS

This product may cause medical equipment to malfunction. The use of this

device is forbidden in most hospitals and medical clinics.

If you use any other personal medical device, consult the manufacturer

of your device to determine if it is adequately shielded from external

RF energy. Your physician may be able to assist you in obtaining this

information.

Turn the phone OFF in health care facilities when any regulations posted in

these areas instruct you to do so. Hospitals or health care facilities may be

using equipment that could be sensitive to external RF energy.

HEARING AIDS

Some digital wireless phones may interfere with some hearing aids. In the

event of such interference, you may want to consult your service provider,

or call the customer service line to discuss alternatives.

NONIONIZING RADIATION

Your device has an internal antenna. This product should be operated in

its normal-use position to ensure the radiative performance and safety

of the interference. As with other mobile radio transmitting equipment,

users are advised that for satisfactory operation of the equipment and

for the safety of personnel, it is recommended that no part of the human

body be allowed to come too close to the antenna during operation of the

equipment.

Use only the supplied integral antenna. Use of unauthorized or modified

antennas may impair call quality and damage the phone, causing loss of

performance and SAR levels exceeding the recommended limits as well

as result in non-compliance with local regulatory requirements in your

country.

To assure optimal phone

performance and ensure human

exposure to RF energy is within the

guidelines set forth in the relevant

standards, always use your device

only in its normal-use position.

Do not touch or hold the antenna

area unnecessarily when placing

or receiving a phone call. Contact

with the antenna area may impair

call quality and cause your device

to operate at a higher power level

than needed. Avoiding contact with

the antenna area when the phone

is IN USE optimizes the antenna

performance and the battery life.

Antenna location

General Precautions

• Avoid applying excessive press ure to the device

Do not put heavy objects or apply excessive pressure on the device to

prevent damaging the device or distorting the touch screen display.

Also avoid carrying the device inside your pocket for extensive

lengths of time.

• Heed service markings

Except as explained elsewhere in the Operating or Service

documentation, do not service any product yourself. Service needed

on components inside these compartments should be done by an

authorized service technician or provider.

• Damage requiring service

Unplug the product from the electrical outlet and refer servicing to

an authorized service technician or provider under the following

conditions:

• Liquid has been spilled or an object has fallen into the product.

• The product has been exposed to rain or water.

• The product has been dropped or damaged.

• There are noticeable signs of overheating.

• The product does not operate normally when you follow the

operating instructions.

• Avoid hot areas

The product should be placed away from heat sources such as

radiators, heat registers, stoves, or other products (including

amplifiers) that produce heat.

• Avoid wet areas

Never use the product in a wet location.

• Avoid using your device after a dramatic change in temperature

When you move your device between environments with very

different temperature and/or humidity ranges (For example, from

warm indoor conditions in a cottage on a mountain to freezing

outdoor conditions), condensation may form on or within the device.

To avoid damaging the device, allow sufficient time for the moisture

to evaporate before using the device.

NOTICE: When taking the device from low-temperature conditions into a

warmer environment or from high-temperature conditions into

a cooler environment, allow the device to acclimate to room

temperature before turning on power.

• Avoid pushing objects into product

Never push objects of any kind into cabinet slots or other openings

in the product. Slots and openings are provided for ventilation. These

openings must not be blocked or covered.

• Mounting accessories

Do not use the product on an unstable table, cart, stand, tripod,

or bracket. Any mounting of the product should follow the

manufacturer’s instructions, and should use a mounting accessory

recommended by the manufacturer.

• Avoid unstable mounting

Do not place the product with an unstable base.

• Use product with approved equipment

This product should be used only with personal computers and

options identified as suitable for use with your equipment.

• Adjust the volume

Turn down the volume before using headphones or other audio

devices.

• Cleaning

Unplug the product from the wall outlet before cleaning. Do not use

liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning, but

NEVER use water to clean the LCD screen.

Contents

Chapter 1 Getting Started 17

1.1 Getting to Know Your PDA Phone and Accessories ..................... 18

1.2 Installing the USIM/SIM Card and Battery ................................... 22

1.3 Installing a Storage Card ............................................................... 25

1.4 Starting Up ..................................................................................... 26

1.5 The Today Screen ........................................................................... 29

1.6 The Start Menu ............................................................................... 30

1.7 Quick Menu .................................................................................... 31

1.8 HTC Home™ .................................................................................... 31

1.9 TouchFLO™...................................................................................... 37

1.10 Status Icons .................................................................................. 44

1.11 Programs ...................................................................................... 46

1.12 Settings ........................................................................................ 49

Chapter 2 Entering Text and Searching for Information 53

2.1 Entering Information ..................................................................... 54

2.2 Using the On-screen Keyboard ..................................................... 55

2.3 Using the Touch Keyboard ............................................................ 55

2.4 Using the Touch Keypad ................................................................ 58

2.5 Using the Symbol Pad ................................................................... 59

2.6 Using Letter Recognizer ................................................................ 60

2.7 Using Block Recognizer ................................................................. 60

2.8 Using Transcriber ........................................................................... 61

2.9 Searching for Information............................................................. 62

Chapter 3 Using Phone Features 63

3.1 Using the Phone ............................................................................. 64

3.2 Making a Call .................................................................................. 66

3.3 Receiving a Call .............................................................................. 69

3.4 Making a Video Call ....................................................................... 71

3.5 Receiving a Video Call ................................................................... 75

3.6 Smart Dialing ................................................................................. 75

3.7 Additional Dialing Information .................................................... 77

3.8 Setting Up Bluetooth SIM Access for Car Kit Phones .................. 77

Chapter 4 Setting Up Your Device 79

4.1 Basic Settings ................................................................................. 80

4.2 Personalizing the Today Screen .................................................... 83

4.3 Protecting Your Device .................................................................. 85

Chapter 5 Synchronizing Information With Your Computer 87

5.1 About Synchronization ................................................................. 88

5.2

Setting Up Windows Mobile® Device Center on Windows Vista® 89

5.3 Setting Up ActiveSync® on Windows XP® ..................................... 91

5.4 Synchronizing With Your Computer ............................................. 92

5.5 Synchronizing via Bluetooth ........................................................ 93

5.6 Synchronizing Music and Video ................................................... 94

Chapter 6 Organizing Contacts, Appointments, Tasks, and Other

Information 95

6.1 Contacts .......................................................................................... 96

6.2 SIM Manager ................................................................................100

6.3 Calendar .......................................................................................102

6.4 Tasks ..............................................................................................105

6.5 Notes ............................................................................................. 107

6.6 Voice Recorder ............................................................................. 109

Chapter 7 Exchanging Messages 111

7.1 Messaging ....................................................................................112

7.2 Text Messages ..............................................................................113

7.3 MMS ..............................................................................................115

7.4 Types of E-mail Accounts .............................................................119

7.5 E-mail Setup Wizard .....................................................................120

7.6 Using E-mail ................................................................................. 123

Chapter 8 Working With Company E-mails and Meeting

Appointments 129

8.1 Synchronizing with the Exchange Server .................................. 130

8.2 Working With Company E-mails .................................................131

8.3 Managing Meeting Requests ...................................................... 135

8.4 Finding Contacts in the Company Directory ............................. 137

Chapter 9 Working With Documents and Files 139

9.1 Microsoft® Office Mobile .............................................................140

9.2 Adobe® Reader® LE ......................................................................141

9.3 Copying and Managing Files ...................................................... 142

9.4 ZIP .................................................................................................143

9.5 Backing Up Data .......................................................................... 144

Chapter 10 Getting Connected 147

10.1 Comm Manager ......................................................................... 148

10.2 Connection Setup ...................................................................... 149

10.3 Ways of Connecting to the Internet .........................................150

10.4 Wi-Fi ............................................................................................ 150

10.5 GPRS/3G .....................................................................................153

10.6 Dial-up ........................................................................................154

10.7 Starting a Data Connection ...................................................... 155

10.8 Internet Explorer® Mobile ......................................................... 155

10.9 Windows Live™ ........................................................................... 157

10.10 Using Your Device as a Modem (Internet Sharing) ...............162

10.11 Bluetooth .................................................................................164

Chapter 11 Using GPS 173

11.1 Guidelines and Preparation for Using GPS .............................. 174

11.2 Downloading Satellite Data via QuickGPS ..............................176

11.3 GPS Controls .............................................................................. 178

Chapter 12 Experiencing Multimedia 179

12.1 Camera........................................................................................180

12.2 Camera Album ...........................................................................192

12.3 Pictures & Videos ....................................................................... 196

12.4 Windows Media® Player Mobile ................................................ 198

12.5 Streaming Media .......................................................................203

12.6 Audio Manager ..........................................................................205

12.7 Using Audio Booster .................................................................. 209

12.8 Using FM Radio .......................................................................... 211

Chapter 13 Managing Your Device 217

13.1 Adding and Removing Programs ............................................. 218

13.2 Using Task Manager ..................................................................218

13.3 Resetting Your Device ............................................................... 220

13.4 Managing Memory ....................................................................222

13.5 Windows Update ........................................................................ 223

13.6 Battery Saving Tips ....................................................................224

Chapter 14 Using Other Applications 225

14.1 Voice Speed Dial ........................................................................226

14.2 Java .............................................................................................228

14.3 Spb GPRS Monitor .....................................................................230

Appendix 233

A.1 Regulatory Notices ......................................................................234

A.2 Specifications .............................................................................. 238

Index 241

Chapter 1

Getting Started

1.1 Getting to Know Your PDA

Phone and Accessories

1.2 Installing the USIM/SIM Card

and Battery

1.3 Installing a Storage Card

1.4 Starting Up

1.5 The Today Screen

1.6 The Start Menu

1.7 Quick Menu

1.8 HTC Home™

1.9 TouchFLO™

1.10 Status Icons

1.11 Programs

1.12 Settings

18 Getting Started

1.1 Getting to Know Your PDA Phone and

Accessories

Top panel

POWER

Press to turn off the display temporarily. To turn off the power, press

and hold for about 5 seconds. For more information, see “Starting Up”

in this chapter.

Left panel Right panel

VOICE COMMAND

• Press to activate or cancel

voice recognition. See

Chapter 14 for details.

• Press and hold to record a

voice note.

Volume Control

During a call or

when playing

music, slide up or

down to adjust the

sound volume.

CAMERA

Press to launch the

Camera. See Chapter

12 for details.

Stylus

microSD Slot

See "Installing a

Storage Card" for

details.

Getting Started 19

Front panel

INTERNET EXPLORER

See Chapter 10 for

details.

Notification LEDs

* See description below.

Earpiece

Listen to a phone call

from here.

Touch Screen

TALK

Press to answer an

incoming call or dial a

number.

NAVIGATION WHEEL/ENTER

• Use to scroll left, right, up, or down.

• Rotate or press the wheel to scroll through items or screens.

• Carry out a selection by pressing the center button.

• When using the Camera or GPS software, rotate the

NAVIGATION WHEEL to zoom in and out.

END

Press to end a call or

to return to the Today

screen. Press and hold to

open the Quick List where

you can select an action

to perform.

In the Quick List, touch

Settings to set the

behavior when pressing

and holding the END key.

Second Camera

Use this video

camera for video call

conversations, or to

take a self-portrait.

GPS Button

Press to launch the

GPS software.

* Right LED: Shows green and amber lights for HSDPA/UMTS/EDGE/GSM/GPRS

standby, message, and network status as well as for notification and

battery charging status. Shows a flashing red light when the battery level

reaches 5% or lower.

Left LED: Shows a flashing blue light for Bluetooth system notification of powered-

up and ready to transmit or receive Bluetooth signals, or a flashing green

light for Wi-Fi status. When both Bluetooth and Wi-Fi are enabled, their

lights flash alternately. Shows flashing amber light for GPS status.

20 Getting Started

Back panel

Speaker

3 Megapixel

Camera

See Chapter 12

for details.

Back Cover

Slide the back

cover downward

to remove it.

GPS Antenna

Connector

Peel off the rubber

cap and connect an

external GPS antenna

for better GPS signal

reception.

Note Use only the

external GPS

antenna with

model number

GA S120.

Self-portrait

Mirror

Bottom Panel

Sync Connector/Earphone Jack

Connect the supplied USB cable to synchronize information or plug in the

AC adapter to recharge the battery. You can also connect the supplied USB

stereo headset for hands-free conversation or for listening to audio media.

Microphone

RESET

Press the RESET

button with the

stylus to soft-reset

your device.

Lanyard/Strap Holder

Getting Started 21

Accessories

4 7

User Manual

Read Me First

Screen

Protector

No. Accessory Function

1 Battery Insert into the device before turning it on.

2 Screen protector Protects the touch screen from scratches.

3 Stereo headset Provides a volume control slider and a Send/End button.

Press the Send/End button to pick up a call or put a call

on hold; press and hold the button to end the call.

4 AC adapter Recharges the battery.

5 USB sync cable Connects your device to a PC and synchronizes data.

6 Extra stylus Use to tap items onscreen.

7 User manual and

ReadMeFirst

Provide instructions for using your device.

8 Pouch Acts as a protective carrying case for your device.

9 Getting Started

and Applications

discs

Sources for additional tools and programs.

10 1G microSD™ Card

22 Getting Started

1.2 Installing the USIM/SIM Card and Battery

Always turn off your device before installing/replacing the USIM/SIM card

and battery. The USIM/SIM card contains your phone number, service

details, and phonebook/message memory. Your device supports both 1.8V

and 3V SIM cards. Some legacy SIM cards will not function with your device.

You should consult with your service provider for a replacement USIM/SIM

card. There may be fees for this service.

Your device contains a rechargeable Li-ion battery and is designed to use

only manufacturer-specified original batteries and accessories. Battery

performance depends on many factors, including network configuration,

signal strength, the temperature of the environment in which you operate

your device, the features and/or settings you select and use, items attached

to connecting ports, and your voice, data, and other program usage

patterns.

Battery life estimates (approximations):

• Standby time: Up to 400 hours for GSM

Up to 450 hours for UMTS

• Talk time: Up to 7 hours for GSM

Up to 4 hours for UMTS

Note: Battery life estimates subject to network and phone usage.

• Media playback time: Up to 8 hours for WMV

Up to 12 hours for WMA

Warning! To reduce risk of fire or burns:

• Do not attempt to open, disassemble, or service the battery pack.

• Do not crush, puncture, short external contacts, or dispose of in fire

or water.

• Do not expose to temperatures above 60oC (140oF).

• Replace only with the battery pack designated for this product.

• Recycle or dispose of used battery as stipulated by local

regulations.

Important Before opening the SIM card holder, make sure you turn off the device

first. Opening the SIM card holder while the device is turned on may

damage the device.

Getting Started 23

To remove the back cover

Before installing the USIM/SIM card or battery, remove the back cover.

1. Make sure your device is

turned off.

2. Slide the back cover off to

remove it.

To install the USIM/SIM card

1. Make sure your device is turned off.

2. Push the SIM card holder to the right to unlock it and then flip the

card holder up.

3. Insert the USIM/SIM card with its

gold contacts facing down and its

cut-off corner facing the battery

compartment.

Cut-off

corner

SIM card

holder

4. Push the SIM card holder down until it snaps into place to lock it.

When you insert the battery, the SIM card holder secures the SIM card

in place.

24 Getting Started

To remove the USIM/SIM card

1. Remove the battery if it is installed.

2. Push the USIM/SIM card in to unlock the SIM card holder.

3. Flip the SIM card up, and then remove the SIM card.

To install the battery

Install the battery by aligning its exposed copper contacts with the battery

connectors inside the battery compartment. Insert the contact’s side of the

battery rst, then gently push the battery into place. Make sure that you

leave the black strip extended to make it easy for you to remove the battery.

Battery connectors

Black strip

After you have inserted the battery, replace the back cover.

To remove the battery

1. Make sure your device is turned off.

2. Slide the back cover off.

3. Remove the battery by lifting the black strip.

Getting Started 25

1.3 Installing a Storage Card

A storage card slot is located on the right side of your device. To have

additional storage for your images, videos, music, and files, you can

purchase a microSDTM card and insert it into the slot.

To insert a microSD card

1. Pry open the storage card slot cover.

2. Insert the microSD card into the slot with the gold contacts facing up.

Gold

contacts

Slot cover

3. Replace the card slot cover.

Note To remove the microSD card, press the microSD card to eject it from the slot.

26 Getting Started

1.4 Starting Up

After inserting your USIM/SIM card and battery and charging the battery,

you can now power on and start using your device.

Turn your device on and off

To turn on the power

• Press and hold the POWER button for a few seconds.

When you turn on your device for the first time, a Quick Start Wizard

guides you through the calibration process and the setup of regional

settings, date and time, and password. For more information about

touch screen calibration, see “Calibrate the device” later in this

chapter. After the Quick Start Wizard finishes, the device installs

customization settings, and then the device will restart.

Note After the device restarts, you may be prompted to set up an e-mail

account. Refer to Chapter 7 for details.

To turn off the power

• Press and hold the POWER button for a few seconds.

A message prompts you to choose whether or not to turn off the

device completely.

Auto configure the data connection settings

The first time you power on your device,

you will see a notification message from

Connection Setup on the Today screen.

Connection Setup automatically configures

your device’s data connections, such as GPRS,

WAP, and MMS, so that you do not need to

enter the settings manually for your device.

Getting Started 27

To automatically configure data connection settings

1. When you see the notification message from the Connection Setup,

tap Yes.

Note If you do not see the notification message, tap on the title bar to

display the message.

If your SIM card supports multiple network operator profiles, a

message will appear with network profile choices.

2. Select the profile you want to use and tap OK.

3. Connection Setup then starts to configure your device’s data

connection settings.

4. After the Connection Setup completes the configuration, tap Restart.

For more information about Connection Setup, see Chapter 10.

Charge the battery

New batteries are shipped partially charged. Before you start using your

device, it is recommended that you install and charge the battery. Some

batteries perform best after several full charge/discharge cycles. You can

charge the battery in two ways:

•

Charging the device’s battery by connecting the power adapter.

• Connecting your device to a PC using the provided USB Sync cable.

Note Only the AC adapter and USB cable provided with your device should be

used to charge the device.

Charging is indicated by a solid amber light on the right LED indicator.

As the battery is being charged while the device’s power is on, a charging

icon appears on the title bar of the Today screen. After the battery has

been fully charged, the right LED charging indicator becomes green and a

full battery icon appears on the Today screen’s title bar.

Warning! • Do not remove the battery from the device while you are charging it

using the AC or car adapter.

• As a safety precaution, the battery stops charging when it overheats.

28 Getting Started

Calibrate the device

Calibrating the touch screen involves tapping the center of a cross with the

stylus as the cross moves around the screen. This process ensures that when

you tap the screen with your stylus, the tapped item is activated.

If your device does not accurately respond to screen taps, follow these steps

to re-calibrate it:

1. Tap Start > Settings > System tab > Screen.

2. On the General tab, tap Align Screen and follow the on-screen

instructions to complete the calibration.

Manage screen settings

The device’s display has the following orientation modes: Portrait and

Landscape. To change the orientation, tap Start > Settings > System tab >

Screen, and select the orientation you want.

Tip To quickly change the screen orientation, you can also tap the Rotate Screen

icon in HTC Home’s Launcher. See “HTC Home” later in this chapter for details.

To smooth the edges of screen fonts for many programs, on the ClearType

tab, select the Enable ClearType check box.

To increase the readability or to see more content on the screen, on the

Text Size tab, adjust the text size by moving the slider.

Switch your device to Sleep mode

Press and immediately release the POWER button to turn off the display

temporarily and switch your device to Sleep mode. Sleep mode suspends

your device to a low power state while the display is off in order to save

battery power.

Your device also automatically goes into Sleep mode when you leave the

device idle after a certain period of time.

To specify the timeout period before your device goes into Sleep mode

1. Tap Start > Settings > System tab > Power > Advanced tab.

2. Under On battery power, make sure the Turn off device if not used

for check box is selected.

3. Select the battery timeout period, then tap OK.

Getting Started 29

You will still be able to receive messages and calls while your device is in

Sleep mode. Pressing the POWER button again or incoming calls/messages

will wake up your device.

1.5 The Today Screen

The Today screen displays important information, such as upcoming

appointments and status indicators. Tap items on the screen to open the

associated program.

Your upcoming

appointments

Open Start Menu

Notification

Signal strength

Adjust volume

Battery status

HTC Home

(See “HTC Home”

in this chapter

for details)

Open Quick Menu

(See “Quick Menu” in

this chapter for details)

Connection status

• To access the Today screen, tap Start > Today.

• To customize the Today screen display, including the background

image, tap Start > Settings > Personal tab > Today.

For more information about customizing the Today screen, see Chapter 4.

30 Getting Started

1.6 The Start Menu

The Start menu, located at the top left corner of the Today screen, displays a

list of programs. You can start a program by scrolling through the programs

list and then pressing ENTER, or by tapping a program with the stylus.

View Help information for the

current screen.

View and change settings.

Access more programs.

Open a recently-used program.

Open a program.

(The items displayed in the

Start menu can be customized

by tapping Start > Settings >

Personal tab > Menus).

Switch to the Today screen.

Tip By default, the Start menu is displayed in a large size to make it easier

for you to select menu items by touching them with your finger.

To display the Start menu in its normal size, tap Start > Settings >

Personal tab > Large Start Menu then clear the Enable large Start

menu check box.

Getting Started 31

1.7 Quick Menu

The Quick Menu, located at the top right corner of the Today screen, shows

the currently running programs. You can quickly switch between running

programs, stop programs, and see how much program memory is being

used.

Tap this button to open

the Quick Menu.

• To switch to a running

program, tap the

program name.

• To stop a running

program, tap .

Customize Task Manager

settings. (See “Using Task

Manager” in Chapter 13.)

Stop all

currently

running

programs.

Shows the total

percentage of program

memory in use. Tap to

open Memory settings.

1.8 HTC Home™

HTC Home™ is a Today screen plug-in that gives you up-to-date local

information at a glance, such as time, date and weather information, and

displays new messages and missed calls. HTC Home also has a customizable

launcher where you can add your favorite applications for one-touch access

and a Profile selector where you can quickly change the profile or ring tone

of your device.

HTC Home has four

components: Home,

Weather, Launcher and

Sounds.

A toolbar at the bottom

enables you to switch

between these components.

HTC Home

Toolbar

Home Weather Launcher Sounds

32 Getting Started

To switch between the different components of HTC Home

Do any of the following:

• Touch the tabs in the toolbar using your finger.

• Tap the tabs in the toolbar using the stylus.

• Use the NAVIGATION CONTROL. If the toolbar is not selected, press

NAVIGATION up/down first to select the toolbar. Press NAVIGATION

left/right to select a tab, then press ENTER.

Home

Home displays the current date and local time. When you have new

incoming messages and calls, it shows you the number of new e-mails,

SMS/MMS messages, and missed calls. If you have set up the alarm, it also

shows the Alarm icon.

Number of new e-mails.

Touch this icon to view

your e-mail. Number of new SMS/MMS messages.

Touch this icon to view your SMS and MMS messages.

Alarm icon

Number of missed calls.

Touch this icon to view

the Call History.

Time display.

Touch this display area

when you want to

change the date or time,

or to enable the alarm.

Date

Getting Started 33

Weather

Weather shows you the current weather as well as weather information for

the next four days of the week. The first time you use this feature, you need

to select your city first to download weather information.

To select your city

1. Select the Weather tab ( ).

2. Tap the area that shows Select your city here.

3. On the Select City screen, type in the city name whose weather

information you want to track, then tap .

Tip You can also browse through the list of cities to choose your city.

4. Select the city on the list and tap Select.

To view weather information

After selecting your city, your device automatically connects to the Internet

via GPRS/3G and downloads weather information of the current day and

the next four days of the week. The current temperature, the highest and

lowest temperatures, and a visual indicator of the climate (showing if it’s a

cloudy or rainy day, etc.) will be displayed in the Weather tab.

34 Getting Started

Weather for the next 4 days

Tap this area

to return to

the current

day’s weather.

Current day’s weather

Tap this area to view

weather information for the

next four days of the week.

Tap this area

to select

another city.

Shows the time that has elapsed

since the last download of

weather information. Tap this

item to download the latest

weather data.

Tip You can also use the Wi-Fi connection of your device to download weather

data. For more information about using Wi-Fi, see Chapter 10.

Note If you have not connected to the Internet and downloaded weather

information for five days, the following error message will be displayed:

"Unable to retrieve data for selected city. Select here to retry." Use GPRS/3G

or Wi-Fi to connect your device to the Internet, then tap the area that shows

the error message to download weather data.

To customize weather settings

1. Tap the city name.

2. On the Select City screen, select Menu > Weather Options.

3. Enable or disable the following options:

• Download weather data automatically. When this check box is

selected, weather information will automatically be downloaded

from the AccuWeather Web site whenever you select the Weather

tab, if the data has not been updated within the last three hours.

Weather data will also be downloaded every time an ActiveSync

connection occurs (through over-the-air or USB connections).

Getting Started 35

Clear this check box if you prefer to manually download weather

information.

• Download when roaming. Select

this check box only if you want

to allow automatic download of

weather data when roaming. This

may incur additional costs.

• Temperature Scale. Choose

whether to display temperature in

Celsius or Fahrenheit.

Tip To check for more detailed weather information on the AccuWeather Web

site, select Menu > About Weather on the Select City screen and then

tap the AccuWeather.com link. Internet Explorer Mobile then opens and

displays the AccuWeather Web site.

Launcher

Launcher allows you to add quick shortcuts to your favorite programs and

settings for one-touch access. Quick settings such as Adjust Backlight,

Rotate Screen and Lock Device, and a few program shortcuts are added by

default. They can be replaced with your preferred settings and programs.

Remove shortcuts

Touch a quick

shortcut to open

the associated

program or apply

the associated

setting.

Touch an empty slot to add

a shortcut to a setting or

your favorite program.

36 Getting Started

Touch a shortcut to remove it.

Return

Note To replace a shortcut, you must delete it first and then add a shortcut to a

program or setting.

Sound

Sound provides a selection of profiles, each preconfigured with a different

volume setting. It also lets you quickly change the ring tone of your device.

Tap a button to select a

profile (from left to right):

Normal, Silent, Vibrate,

Automatic.

Tap to open the

phone sound

settings where

you can select

the ring tone.

Tap to select the Automatic profile. If Automatic is selected, the device

will vibrate during a scheduled event in your calendar; when there is no

scheduled event in your calendar, the device will use the Normal mode

settings.

Note For information about manually adjusting the device volume, see Chapter 3.

Getting Started 37

1.9 TouchFLO™

TouchFLO™ is a special feature that gives you a better touch panel

experience on your device. With TouchFLO, you can use your thumb or

fingers to scroll and pan the screen.

TouchFLO also features the Touch Cube where you can launch messaging

programs, Internet Explorer® Mobile, and more. You can also add your

favorite contacts, play music, and access your pictures and videos.

Note Touch Cube is displayed in portrait view only. To be able to open Touch Cube,

make sure your display is set to portrait mode.

Touch Cube

To open the Touch Cube

Slide your thumb upward, starting

from the bottom of the touch screen

where it shows a logo image.

To close the Touch Cube

To close the Touch Cube and return to

the screen prior to opening the Touch

Cube, slide your thumb downward on

the touch screen.

38 Getting Started

To navigate the Touch Cube

The Touch Cube is a three-dimensional, cubic user interface. To flip the

interface from one side to another, slide your thumb left or right on the

touch screen.

Touch Cube screens

There are three sides to the Touch Cube interface:

• On the first side of the interface, you can add up to nine favorite

contacts. If you make calls to certain people frequently, you can add

them as favorite contacts for quicker access.

Note You must already have contacts with phone numbers stored on your

device or SIM card before you can add them as favorite contacts. For

more information about creating contacts, see Chapter 6.

For more information about synchronizing contacts and other

information between your device and computer, see Chapter 5.

For information about synchronizing your device with the Exchange

Server, see Chapter 8.

Getting Started 39

Select an empty slot

to add a favorite

contact. If the

contact has more

than one contact

number, select

the number to call

when you touch the

contact.

Open Call History.

(See Chapter 3 for details.)

Tap to call the number

associated with the

contact. Tap and hold to

display the Contact card.

Open the Phone

program.

(See Chapter 3 for

details.)

Delete favorite

contacts.

Open Contacts.

(See Chapter 6 for details)

When you add a favorite

contact and there is no photo

associated to that contact, the

contact’s first name (or last

name) will be displayed.

When you have several

phone numbers assigned

to the same contact, an

icon appears on the top

left corner of the contact

square to tell you which

number is assigned to the

particular square.

Select a favorite

contact to remove it.

Return to your

list of favorite

contacts.

40 Getting Started

• The second side of the interface

provides quick shortcuts to your

e-mail messages, text and MMS

messages, the Internet, and

other applications.

Simply touch the icons

on the screen to open the

corresponding program.

• On the third side of the interface, you can play back music and access

the images and video files on your device.

Touch this icon to open Audio Manager and

play back music files. (For more information

about using Audio Manager, see Chapter 12.)

Touch these buttons

to control music

playback.

From left to right:

backward, play/pause,

forward.

While playback is in

progress in Audio

Manager, return to this

screen to see playback

controls and the

music title, artist, and

remaining playback

time of the current

music.

Open Camera Album to

view still images.

(See Chapter 12 for

details.)

Open Camera Album to

browse videos.

(See Chapter 12 for details.)

Getting Started 41

Finger scrolling and finger panning

With TouchFLO, you can use finger scrolling and finger panning when

viewing content that cannot be fit entirely on the screen, such as Web

pages, documents, and messages. Finger scrolling can also be used to scroll

up and down lists such as the contacts list, file list, message list, calendar

appointments list, and more.

Note Finger scrolling and panning works in both portrait and landscape modes.

To use finger scrolling

• Slide your finger downward to scroll up the screen.

• Slide your finger upward to scroll down the screen.

When finger

scrolling up

and down, slide

anywhere within

this area.

• To scroll towards the left, slide your finger to the right.

• To scroll towards the right, slide your finger to the left.

• While the screen is scrolling, you can stop the scrolling by pressing

your finger on the touch screen.

Note Scrollbars on the screen indicate that there is content that doesn’t fit on

the screen. You can finger-scroll up and down only when there's a vertical

scrollbar shown on the screen. Likewise, you can finger-scroll left and right

only when there's a horizontal scrollbar.

42 Getting Started

To use finger panning

• To pan downward, touch and hold on the touch screen then drag

your finger upward.

• To pan upward, touch and hold on the touch screen then drag your

finger downward.

• To pan towards the right, touch and hold on the touch screen then

drag your finger to the left.

• To pan towards the left, touch and hold on the touch screen then

drag your finger to the right.

• You can also pan diagonally.

Note Scrollbars on the screen indicate that there is content that doesn’t fit on

the screen. You can only use finger panning when scrollbars appear on the

screen.

To continuously pan

1. Drag your finger towards the boundary and hold. The Web page,

document, or message that you are viewing then continuously pans.

Left and right boundaries

Top and

bottom

boundaries

2. Release your finger to stop panning.

Getting Started 43

To go to the next or previous message

While reading a message, slide your finger

across the screen to go to the next or

previous message.

To go to the next message, slide your finger

from right to left on the screen; To go to the

previous message, slide your finger from left

to right on the screen.

To go to the next or previous messaging account

While on a messaging account screen, you can slide your finger across the

screen to go to next or previous messaging account.

TouchFLO settings

You can enable or mute the finger scrolling and panning sound. Tap Start >

Settings > System tab > TouchFLO then select or clear the Enable sound

when finger scrolling and panning check box.

44 Getting Started

1.10 Status Icons

The following are some of the status icons that you may see on the device.

Icons that appear in this area

GPRS available

EDGE available

HSDPA available

UMTS available

Wi-Fi function enabled, but

device not connected to a

wireless network yet

Connected to a wireless

network

Synchronizing via Wi-Fi

Connection is active

Connection is not active

Synchronization in progress

Icons that appear in this area

Connection Setup

Multiple notifications; tap the

icon to view all

New text messages;

SMS notification of voice mail

Sending MMS

Receiving MMS

MMS sent

Cannot send MMS

New incoming MMS

New Windows Live™ message

Missed call

Speakerphone on

Roaming

Alarm

Other wireless network(s)

detected

Bluetooth headset detected

ActiveSync notification

Synchronization error

Getting Started 45

Icons that appear in this area

Battery charging

Battery full

Battery very low

Icons that appear in this area

Vibrate mode

Sound on

Sound off

Icons that appear in this area

GPRS connecting

GPRS in use

EDGE connecting

EDGE in use

HSDPA connecting

HSDPA in use

UMTS connecting

UMTS in use

Maximum signal strength

No signal

Phone is turned off

No phone service

Searching for phone service

Voice call in progress

Call on hold

Calls are forwarded

Dialing while no USIM/SIM

card is inserted

No USIM/SIM card inserted

46 Getting Started

1.11 Programs

The following are programs you can find on your device or install from the

Applications Disc.

Programs in the Start Menu

Icon Description

Phone Make and receive calls, switch between calls, and set up

conference calling.

Calendar Keep track of your appointments and create meeting

requests.

Contacts Keep track of your friends and colleagues.

Internet Explorer Mobile Browse Web and WAP sites as well as

download new programs and files from the Internet.

Messaging Send and receive e-mail, MMS, and text messages.

Office Mobile Use the complete suite of Microsoft® Office applications

for your mobile device.

Excel Mobile Create new workbooks or view and edit Excel

workbooks.

PowerPoint Mobile View PowerPoint slides and presentations.

Word Mobile Create, view, and edit Word documents.

Help See Help topics for the current screen or program.

Programs screen

Icon Description

Games Play two pre-installed games: Bubble Breaker and Solitaire.

ActiveSync Synchronize information between your device and a PC or

the Exchange Server.

Getting Started 47

Icon Description

Adobe Reader LE View PDF (Portable Document Format) files on your

device.

Audio Booster Enhances your music experience by providing you with

controls for adjusting equalizer, 3D sound, treble, and bass settings.

Audio Manager Browse for music files by organizing music files into

categories.

Bluetooth Explorer Search for other Bluetooth devices that have file

sharing enabled and access their Bluetooth shared folder.

Calculator Perform basic arithmetic and calculations, such as addition,

subtraction, multiplication, and division.

Camera Take photos or shoots video clips with accompanying audio.

Camera Album View photos that you captured using the device

camera.

Comm Manager Manage your device’s connections (including Wi-Fi,

GPRS, and Bluetooth), turn the phone on or off, and enable or disable the

Direct Push function.

File Explorer Organize and manage files on your device.

FM Radio Lets you listen to your favorite FM radio stations.

Internet Sharing Connect your notebook computer to the Internet

using your device's data connection.

Java Download and install Java applications, such as games and tools,

on your device.

Messenger This is the mobile version of Windows Live™ Messenger.

Notes Create handwritten or typed notes, drawings, and voice

recordings.

Opera Browser The mobile version of the award winning browser.

48 Getting Started

Icon Description

Pictures & Videos View, organize, and sort pictures, animated GIFs, and

video files on your device or a storage card.

QuickGPS Downloads satellite data over the Internet via ActiveSync,

Wi-Fi or GPRS to speed up the time for determining your current GPS

position.

SAPSettings Enables Bluetooth Remote SIM access on your phone. See

Chapter 3 for more details.

Search Search contacts, data, and other information on your device.

SIM Manager Manage the contacts that are stored on your USIM/SIM

card. You can also use this program to copy USIM/SIM contents to

Contacts on your device.

Spb GPRS Monitor You will find this program in the provided disc. You

can install and use this program to measure the amount of data transfers

that you have made via the GPRS or GSM network connection, and

calculate network usage costs. See Chapter 14 for details.

Sprite Backup Provides you with a quick and easy way to create

backups of your data.

STK (SIM Tool Kit) Service Access information and other services

offered by your wireless service provider.

Streaming Media Stream live or on-demand video.

Tasks Keep track of your tasks.

Voice Recorder Record your voice, play it back, then send it via e-mail,

MMS or beaming. You can also set the recorded voice as your ring tone.

Voice Speed Dial Allows you to record voice tags so that you can dial a

phone number or launch programs by speaking a word.

Windows Live Use this mobile version of Windows Live™ to find

information on the Web. It also lets you sign into your Windows Live

account so that you can access your Live Mail messages and send/receive

instant messages in Live Messenger.

Getting Started 49

Icon Description

Windows Media Player Mobile Play back audio and video files.

ZIP Save memory and free up storage space on your device by

compressing files in the conventional ZIP format.

1.12 Settings

You can adjust the device settings to suit the way you work. To see all

available settings, tap Start > Settings, then tap the Personal, System, and

Connections tabs located at the bottom of the screen.

Personal tab

Icon Description

Buttons Assign a program or function to a hardware button.

Input Set options for each of the input methods.

Large Start Menu Enable or disable the large Start menu.

Lock Set a password for your device.

Menus Set which programs will appear in the Start menu.

Owner Information Enter your personal information on your device.

Phone Customize phone settings such as ring tone, set a PIN number for

your USIM/SIM card, and more.

Sounds & Notifications Enable sounds for events, notifications, and

more, and set the type of notification for different events.

Today Customize the appearance and the information to be displayed

on the Today screen.

Voice Speed Dial Create voice tags for voice dialing contacts and USIM/

SIM contacts as well as for launching programs.

50 Getting Started

System tab

Icon Description

About This is where you can see basic information such as the Windows

Mobile® version and type of processor used on your device. You can also

specify a name for your device.

Backlight Set the backlight timeout and adjust brightness.

Certificates See information about certificates that are installed on your

device.

Clear Storage Tap this icon only when you need to remove all your

data and files from the memory and reset your device to factory default

settings.

Clock & Alarms Set the device clock to the date and time of your locale

or to a visiting time zone when you’re traveling. Alarms can also be set at

specified days and times of a week.

Customer Feedback Set your device to automatically send information

about how you use Windows Mobile. By default, this option is disabled.

Device Information See information about the firmware version,

hardware, identity, and the duration of calls made on your device.

Encryption Allow files on your storage card to be encrypted. Encrypted

files will be readable only on your device.

Error Reporting Enable or disable the device's error reporting function.

When this function is enabled and a program error occurs, technical data

about the state of the program and your computer will be logged in a

text file and delivered to Microsoft's technical support if you choose to

send it.

External GPS Set the appropriate GPS communication ports, if required.

You may need to do this when there are programs on your device that

access GPS data or you have connected a GPS receiver to your device.

See Help for details.

Key Lock Lock the buttons on your device except for the POWER button

when the device is in Sleep mode. This ensures you will not switch the

device on by accident and consume unnecessary power.

Getting Started 51

Icon Description

Long Press End Key Lets you set the behavior when you press and hold

the END key.

Memory Check the device memory allocation status and memory card

information. You can also stop currently running programs.

Microphone AGC Adjust the volume of your voice automatically when

you are recording.

Power Check the remaining battery power. You can also set the timeout

for turning off the display (switching device to Sleep mode) to conserve

battery power.

Regional Settings Set the regional configuration to use, including the

format for displaying numbers, currency, date, and time on your device.

Remove Programs Remove programs that you installed on your device.

Screen Change the screen orientation, re-calibrate the screen, and

change the screen text size.

Task Manager Stop running programs and set the ( ) button to end

programs immediately when you tap the button. For more information,

see "Task Manager" in Chapter 13.

TouchFLO Enable or mute the finger scrolling and panning sound. See

"TouchFLO settings" in this chapter for details.

Windows Update Link to Microsoft's Web site and update Windows

Mobile® on your device with the latest security patches or fixes.

52 Getting Started

Connections tab

Icon Description

Beam Set your device to receive incoming Bluetooth beams.

Bluetooth Turn Bluetooth on, set your device to visible mode, and scan

for other Bluetooth devices.

Comm Manager Manage your device’s connections (including Wi-Fi,

GPRS, and Bluetooth), turn the phone on or off, and enable or disable the

Direct Push function.

Connection Setup Configure your device’s data connections, such

as GPRS, WAP, and MMS, based on the detected or selected network

operator. See Chapter 10 for details.

Connections Set up one or more types of modem connections for your

device, such as phone dial-up, GPRS, and more, so that your device can

connect to the Internet or a private local network.

CSD Line Type Set the line type to use when making a circuit switch

data (CSD) connection. Normally, you do not need to change the setting

unless you encounter a problem on establishing a connection.

GPRS Setting Set the GPRS authentication method.

HSDPA Turn High Speed Data Packet Access (HSDPA on or off.

HSDPA is a 3.5G digital data service that provides high-speed

downstream data rates. In order for your device to attain the high

connection speed of HSDPA, your wireless service provider must support

this feature and you must be within the coverage area of your service

provider’s HSDPA network.

Note: Your device supports up to 3.6 Mbps download speeds.

SMS Service Enables sending of SMS text messages via a data

connection, such as GPRS or a circuit-switched connection.

USB to PC Set a USB serial connection between your device and PC

when there are problems connecting ActiveSync.

Wi-Fi Scan for available wireless networks.

Wireless LAN See information about the active wireless network, and

customize Wi-Fi settings.

Chapter 2

Entering Text and Searching

for Information

2.1 Entering Information

2.2 Using the On-screen Keyboard

2.3 Using the Touch Keyboard

2.4 Using the Touch Keypad

2.5 Using the Symbol Pad

2.6 Using Letter Recognizer

2.7 Using Block Recognizer

2.8 Using Transcriber

2.9 Searching for Information

54 Entering Text and Searching for Information

2.1 Entering Information

When you start a program or select a field that requires text or numbers, the

Input Panel icon becomes available on the menu bar.

Tap the Input Selector arrow (that appears next to the Input Panel icon)

to open a menu where you can select a text input method and customize

input options. After selecting a text input method, the corresponding Input

Panel is displayed, which you can use to enter text. To switch the Input

Panel display on and off, tap the Input Panel icon.

Input Panel

(Touch

Keyboard)

Input Selector

arrow

Input Panel icon

Icon Input method

On-screen Keyboard

Touch Keyboard

Touch Keypad

Letter Recognizer or Block Recognizer

Transcriber

Note Some text input methods may not be available in certain language versions

of the device.

Entering Text and Searching for Information 55

2.2 Using the On-screen Keyboard

When using Windows Mobile’s standard on-screen Keyboard, you can enter

text by tapping keys on the keyboard that is displayed on the screen.

To enter text using the on-screen Keyboard

1. In a program, tap the Input Selector arrow, and tap Keyboard.

2. Enter text by tapping keys on the on-screen Keyboard.

To enlarge the on-screen Keyboard

1. Tap the Input Selector arrow, then tap Options.

2. In the Input method list, select Keyboard.

3. Tap Large keys.

2.3 Using the Touch Keyboard

The Touch Keyboard is another type of on-screen keyboard which features

20 keys. With its large, touch-friendly keys and enhanced features such as

XT9 predictive input, you can enter text faster and more accurately.

Tap to enter letters

or symbols.

• Tap to enter an

uppercase letter

• Tap twice to turn

on Caps Lock.

Tap to cycle through the input

methods: XT9, Multitap, and

Numeric. The keyboard changes

to a numeric keyboard when in the

numeric mode.

Tap to open the

Symbol pad.

Tap to create a

new line.

Tap to delete the

previous character.

Displays the word

candidate list in XT9

mode. Tap a word to

insert it into your text.

Tap the + symbol to add

a word.

56 Entering Text and Searching for Information

To enter text using the Touch Keyboard

1. Start a program that accepts text input, such as Word Mobile.

2. Tap the Input Selector arrow, and tap Touch Keyboard.

3. On the last row of the Touch Keyboard, tap the second key from the

left to cycle through these input modes: XT9, Multitap or Numeric.

See “XT9 mode”, “Multitap mode”, and “Numeric mode” to learn how to

enter text with these modes.

XT9 mode

By default, the Touch Keyboard is set to XT9 mode. XT9 is a predictive text

input mode which displays a word candidate list as you enter the first few

characters so you can just select the word that you want. XT9 can also be

set to predict the next word based on previous phrases or sentences you

have entered.

To enter text using XT9 mode

1. Start entering the first few letters of a word. As you enter each letter,

predicted words will appear above the keyboard.

2. Tap the desired word to immediately insert it to your text.

Note Navigate through the word candidate list if there are more words to

choose from.

3. If the Next Word Prediction setting is enabled, the next predicted

word will appear in gray. If this is the correct word, tap the Enter key

( ) to confirm.

See “To customize XT9 settings for the Touch Keyboard” to find out

how to enable Next Word Prediction and other XT9 settings.

To add a word to the word candidate list

If the word that you entered is not found in the dictionary, you can add it to

the dictionary by tapping .

To customize XT9 settings for the Touch Keyboard

1. Tap the Input Selector arrow, and tap Options.

2. In the Input Method tab, select Touch Keyboard from the Input

method drop-down list and then tap Options.

3. Tap XT9 Settings.

Entering Text and Searching for Information 57

4. On the XT9 Settings screen, select or clear the following options

according to your preferences:

• Spell Correction. Lets you correct typographical errors by

selecting from a list of possible words that reflect the characters of

the keys you have tapped as well as characters of nearby keys.

• Next Word Prediction. Predicts the next word in your text based

on previous phrases you have constructed. As you enter more text,

the software learns your pattern and attempts to predict the word

that you will likely type next.

• Auto-Append. Automatically adds your constructed words that

are not in the dictionary to the predicted word list.

• Auto-Substitution. Automatically inserts an apostrophe when

you type common contracted words (e.g. “dont” automatically

becomes “don’t”).

• Word Completion. Lets you select from a list of possible words

based on the keys that you tapped and on the words available in

the dictionary.

• Multitap Word Completion. Lets you select from a list of possible

combinations based on the characters that appear on the keys

that you tapped.

5. Tap Done.

Multitap mode

In Multitap mode ( abc ), enter a character by tapping a key until the

desired character is displayed on the screen.

• To enter the first letter that shows on a key, tap the key once. To enter

the second letter, tap twice.

• To enter a punctuation mark, symbol, or number that appears on the

upper right corner of a key, tap and hold the key.

Numeric mode

Use Numeric mode ( 123 ) for faster data entry of numerical information

such as phone numbers. Enter numbers by tapping the number keys on the

keyboard.

58 Entering Text and Searching for Information

2.4 Using the Touch Keypad

The Touch Keypad is a 12-key on-screen keypad that has a similar layout

as mobile phone keypads, plus some additional keys. Touch Keypad has

large keys and enhanced input features such as XT9 predictive input, which

makes it faster for you to enter text in your messages and documents.

Tap to enter

letters or symbols.

• Tap to enter an

uppercase letter.

• Tap twice to turn

on Caps Lock.

Tap to cycle through the three input

modes: XT9, Multitap, and Numeric.

The keyboard changes to a numeric

keyboard when in Numeric mode.

Tap to open the

Symbol pad.

Tap to create a

new line.

Tap to delete the

previous character.

Displays the word

candidate list in XT9

mode. Tap to insert

a word to your text.

Tap the + symbol to

add a word.

To enter text using the Touch Keypad

1. Start a program that accepts text input, such as Word Mobile.

2. Tap the Input Selector arrow, and tap Touch Keypad.

3. On the last row of the Touch Keypad, tap the second key from the left

to cycle through these input modes: XT9, Multitap or Numeric.

See “XT9 mode”, “Multitap mode”, and “Numeric mode” earlier in this

chapter to learn how to enter text with these modes.

To customize XT9 settings for the Touch Keypad

Follow the same steps in “To customize XT9 settings for the Touch

Keyboard”. Be sure to select Touch Keypad in the Input method tab before

tapping Options.

Entering Text and Searching for Information 59

2.5 Using the Symbol Pad

Symbol Pad provides a comprehensive list of common symbols such as

parentheses, braces, currency signs, and more, as well as punctuation marks

and special characters. The Symbol pad is available when using both the

Touch Keyboard and Touch Keypad.

Tap a symbol to insert it into the message.

Tap to display the previous page of symbols.

Tap to display the next page of symbols.

Tap to close the Symbol Pad without

selecting a symbol.

Indicates the current page and the total

number of symbol pages. Tap to go to the

next page of symbols.

To open the Symbol Pad and select a symbol

• While using the Touch Keyboard or Touch Keypad, tap the Sym key.

Browse through the symbols and then tap one to insert it to your text.

• By default, the Symbol Pad allows you to select only one symbol at a

time and immediately closes after your selection. To be able to select

several symbols at a time, follow these steps:

1. Tap the Input Selector arrow, and tap Options.

2. In the Input Method tab, select Touch Keyboard or Touch

Keypad from the Input method drop-down list and then tap

Options.

3. Clear the Enable single selection only in Symbol Pad check box.

60 Entering Text and Searching for Information

2.6 Using Letter Recognizer

With Letter Recognizer, you can write individual letters, numbers, and

punctuation marks, which are then converted into typed text.

Note Letter Recognizer is available when text entry is possible.

To use Letter Recognizer

1. From a program, tap the Input Selector arrow, and tap Letter

Recognizer.

2. Write characters, numbers, and symbols in the designated writing

area.

• Enter uppercase letters by writing in the ABC (left) area of the box.

• Enter lowercase letters by writing in the abc (middle) area of the box.

• Enter numbers by writing in the 123 (right) area of the box.

• Enter punctuation and symbols by writing the desired character in

the 123 (right) area of the box.

Tip For help with writing characters, tap the question mark near the writing area.

2.7 Using Block Recognizer

With Block Recognizer, you use a single stroke to write letters, numbers,

symbols, and punctuation, which are then converted into typed text.

Note Block Recognizer is available when text entry is possible.

To use Block Recognizer

1. From a program, tap the Input Selector arrow, and tap Block

Recognizer.

2. Write characters, numbers, and symbols in the designated writing

area.

• Enter letters by writing in the abc (left) area of the box.

• Enter numbers by writing in the 123 (right) area of the box.

• Enter symbols and punctuation by tapping the left or right area

of the box (a gray dot appears) and then writing the desired

character.

Tip For help with writing characters with Block Recognizer, tap the question

mark near the writing area.

Entering Text and Searching for Information 61

2.8 Using Transcriber

Transcriber is a handwriting recognition program that enables you to write

in cursive, print, or a combination of both.

To write using Transcriber

1. Start a program that accepts user input, such as Word Mobile.

2. Tap the Input Selector arrow, and tap Transcriber. The Transcriber

introductory screen appears. Read the introduction and tap OK.

3. Position the cursor where you want text to appear.

4. Use the stylus to write anywhere on the screen. The handwriting will

be converted to text shortly after you lift the stylus from the screen.

To enter punctuation and symbols

Transcriber comes with an on-screen keyboard that provides an easy way to

add punctuation or a special symbol to existing text. To use this on-screen

keyboard, tap on the Transcriber toolbar.

The keyboard remains visible until you tap the button again.

Tips • To reposition the keyboard, tap and hold the title bar, then drag to the

desired location.

• When no text is selected, you can open the keyboard by using the

gesture (draw a line straight down and then straight up). For more

information about using Transcriber gestures, see Help on your device.

To edit text

1. In a program, draw a line from left to right across the text you want to

edit.

2. After you lift the stylus from the screen, the line disappears and the

selected text will be highlighted.

3. Do either of the following:

• Rewrite the text.

• Use gestures to capitalize letters, insert a space, and so on. For

information about using Transcriber gestures, see Help on your

device.

62 Entering Text and Searching for Information

2.9 Searching for Information

You can search for files and other items stored in My Documents folder or

on an installed storage card of your device. You can search by file name

or by words located in the item. For example, you can search in e-mail

messages, notes, appointments, contacts, and tasks, as well as in online

Help.

To search for a file or an item

1. Tap Start > Programs > Search.

2. In the Search for field, you can:

• Enter the le name, word, or other information you want to search

for.

• Tap the down arrow icon ( ), and from the list, select an item

that you have looked for before.

3. In the Type field, you can tap the down arrow icon ( ) and select a

data type from the list to help narrow your search.

4. Tap Search. The system then starts searching the matched files in the

My Documents folder and subfolders.

5. In the Results list, tap the item you want to open.

Note The storage card symbol ( or ) is displayed next to the names of files

saved on a storage card.

Chapter 3

Using Phone Features

3.1 Using the Phone

3.2 Making a Call

3.3 Receiving a Call

3.4 Making a Video Call

3.5 Receiving a Video Call

3.6 Smart Dialing

3.7 Additional Dialing

Information

3.8 Setting Up Bluetooth SIM

Access for Car Kit Phones

64 Using Phone Features

3.1 Using the Phone

Like a standard mobile phone, you can use your device to make, receive,

and keep track of calls and send messages. You can also dial directly

from Contacts, and easily copy phonebook entries from your SIM card to

Contacts on your device.

The Phone screen

From the Phone screen, you can access Call History, Speed Dial, and Phone

settings. To open the Phone screen, do either of the following:

• Tap Start > Phone.

• Press the TALK button.TALK button. TALK

button

Enter your PIN

Most SIM cards are preset with a PIN (personal identification number) that is

provided by your wireless service provider.

1. Enter the preset PIN assigned by your wireless service provider.

2. Tap Enter.

Note If your PIN is entered incorrectly three times, the SIM card will be blocked. If

this happens, you can unblock it with the PUK (PIN Unblocking Key) obtained

from your wireless service provider.

Turn the phone function on and off

In many countries, you are required by law to turn off the phone while on

board an aircraft.

To enable or disable the phone function

1. Tap Start > Programs > Comm Manager.

2. On the Comm Manager screen, tap the Phone button to enable

or disable the phone function. When enabled, the ON indicator is

activated.

Using Phone Features 65

To enable or disable Airplane Mode

Another way to turn off the phone function is to switch your device to

Airplane Mode.

When you enable Airplane Mode, all wireless radios on your device are

turned off, including the phone function, Bluetooth, and Wi-Fi.

When you disable Airplane Mode, the phone function is turned back on and

the previous states of Bluetooth and Wi-Fi are restored.

1. Tap Start > Programs > Comm Manager.

2. On the Comm Manager screen, tap the Airplane Mode button to

enable or disable Airplane Mode. When enabled, the ON indicator is

activated.

Adjust the device volume

1. Tap the Speaker icon ( ) in the title bar.

2. Under Volume, do the following:

• Adjust the phone volume ( ) or

device volume ( ) by moving the

slider to the desired volume level..

• Tap On, Vibrate, or Off to change both

the device and ringer volume settings.

Tip Use the volume control on the left side of the device to control the device

volume when not in a call. When in a call, use the volume control to adjust

the phone volume.

Notes • To adjust the conversation phone volume, you must do it during a call.

Adjusting the volume at another time will only affect the ring, notification,

and MP3 sound levels.

• When you activate Vibrate mode, sound is automatically muted and your

device will vibrate when an incoming call is received. The Vibrate icon

will appear in the title bar to indicate that Vibrate mode is activated.

66 Using Phone Features

3.2 Making a Call

With your device, you can make a call from Phone, Contacts, TouchFLO,

Speed Dial, Call History, and SIM Manager.

Make a call from Phone

1. Tap Start > Phone.

2. On the Phone keypad, touch the keys

with your finger or tap the keys using

the stylus to enter the phone number.

Tip If you tap a wrong number, tap Delete

( ) to erase each subsequent

digit of a number. To erase the entire

number, tap and hold Delete.

3. Press the TALK button on your device toTALK button on your device to

place the call.

Make a call from Contacts

Tap Contacts on the Today screen or tap Start > Contacts, then do one of

the following:

• Select a contact, and press TALK.

• Tap the desired contact in the contacts list, and tap the phone

number that you want to call.

• Tap and hold the desired contact, and on the shortcut menu, tap Call

Work, Call Home, or Call Mobile.

Using Phone Features 67

To choose one of the numbers of a contact to dial

By default, the mobile phone number (m) of a contact is dialed when you

make a call from Contacts. However, you can specify that a different phone

number is dialed instead.

1. Tap Start > Contacts.

2. Select the contact.

3. Press NAVIGATION left or right. The letters representing the number

will change as you scroll through them.

Make a call from the Touch Cube

To place a call to a favorite contact that you added to TouchFLO’s Touch

Cube, follow these steps:

1. Open the Touch Cube by sliding your

finger upward, starting from the bottom

of the touch screen where it shows a

logo image.

(See Chapter 1 for detailed instructions.)

2. Slide your nger left or right to rotate

the cube and navigate to the screen

where it shows your favorite contacts.

3. Touch the photo or name of the contact

whom you want to call.

Tip Touch and hold the contact to open the contact's summary.

Make a call from Call History

1. On the Phone screen, tap the Call History button .

Tip On the phone screen, rotate the NAVIGATION WHEEL counterclockwise

to view the Call History.

2. You can either finger-scroll through all calls in Call History, or tap

Menu > Filter and select from a category of call types: All calls,

Missed calls, Outgoing calls, and Incoming calls.

3. Navigate to the desired contact or phone number, and press TALK or

tap Call.

68 Using Phone Features

One-touch Speed Dial

Use Speed Dial to call frequently-used numbers with a single tap. For

example, if you assign a contact to the location 2 in Speed Dial, you can

tap and hold the number 2 key on the Phone screen to dial the contact’s

number. Before you can create a Speed Dial entry, the number must already

exist in Contacts.

To create a Speed Dial entry

1. On the Phone screen, tap Menu > Speed Dial.

Tip On the phone screen, rotate the NAVIGATION WHEEL clockwise to view

Speed Dial entries.

2. Tap Menu > New.

3. Tap a contact. Select the phone number that you want assigned to a

speed dial key.

4. In the Location box, select an available key to use as the speed dial

key.

5. Tap OK.

Note If you want to place a phone number in a position that is already occupied,

the new number will replace the number that is already there.

Tips • To create a Speed Dial entry from Contacts or SIM card contacts, tap the

contact, select the number you want to add to Speed Dial and then tap

Menu > Add to Speed Dial.

• To delete a Speed Dial entry, in the Speed Dial list, tap and hold the

desired entry, and tap Delete.

To call voicemail

Number 1 is generally reserved for your voicemail. Tap and hold this button

on the Phone screen to call voicemail.

Using Phone Features 69

Make a call from SIM Manager

SIM Manager allows you to view the contents of your SIM card, transfer SIM

phonebook entries to Contacts on your device, and make a call from your

SIM card.

To call a SIM contact

1. Tap Start > Programs > SIM Manager.

Wait for your SIM card contents to load.

2. Tap and hold the name or phone number of the person you want to

call, and tap Call.

For more information about SIM Manager, see Chapter 6.

3.3 Receiving a Call

When you receive a phone call, a message will appear, giving you the

option to either answer or ignore the incoming call.

To answer or reject an incoming call

• To answer the call, tap Answer, or press TALK on the device.

• To reject the call, tap Ignore, or press END on the device.

To end a call

Once an incoming or outgoing call is in progress, you can tap End or press

END on the device to hang up.

To check a missed call

You will see the icon in the title bar when you have missed a call. To

check who the caller was, do one of the following:

• Tap , then tap View.

• On the Phone screen, tap the Call History button ( ). You can

view missed calls as well as incoming and outgoing calls in Call

History.

70 Using Phone Features

To put a call on hold

Your device notifies you when you have another incoming call, and gives

you the choice of rejecting or accepting the call. If you are already on a call

and accept the new call, you can choose to switch between the two callers,

or set up a conference call between all three parties.

1. Tap Answer to take the second call, and put the first one on hold.

2. To end the second call and return to the first call, tap End or press

END on the device.

To switch between two calls

Tap Swap.

To set up a conference call

1. Either put a call on hold, and dial a second number; or, accept a

second incoming call when you already have one in progress.

2. Tap Menu > Conference.

Note Not all service providers support conference calling. Contact your service

provider for details.

To turn on and off the Speakerphone

The built-in Speakerphone on your device allows you to talk hands-free or

lets other people listen to the conversation.

• During a call, tap Speaker On, or press and hold TALK until the

speakerphone turns on. The speakerphone icon appears in the

title bar.

• To turn off the speakerphone, tap Speaker Off, or press and hold

TALK again until the speakerphone turns off.

Warning! To avoid damage to your hearing, do not hold your device against your

ear when the Speakerphone is turned on.

To mute a call

You can turn off the microphone during a call, so that you can hear the

caller but the caller cannot hear you.

• During a call, tap Mute.

• When the microphone is turned off, the mute icon appears on the

screen. Tap Unmute to turn on the microphone again.

Using Phone Features 71

3.4 Making a Video Call

Your device allows you to make video calls when you are within a 3G

network coverage area. You need to use a 3G enable SIM card to make video

calls.

To make a video call

Do any of the following:

• On the Phone keypad, tap the phone number to call, then tap .

• On the Phone keypad, tap the phone number to call, then tap

Menu > Video Call to start a video call.

• From Contacts, tap and hold the desired contact, and tap Video Call.

• From Call History, tap and hold the desired phone number or contact,

and tap Video Call.

Note The other party’s image will appear on the screen about 3 to 5 seconds after

a connection is established, depending on the signal strength. The streaming

images quality may also be influenced by the signal.

When the video call is unsuccessful, a message pops up asking you if you

want to try again, make a voice call instead, or send an SMS/MMS message.

Change Video Call settings

While on a video call, you can change certain settings such as the size of the

image, brightness of the image, the camera to use, and more.

The following page shows the Video Call screen and control buttons during

an ongoing call.

72 Using Phone Features

1Status area. Displays your service

provider name, the other party's

information, and call timer.

2Image display area. Displays your image

and the other party's image, depending

on the selected Swap Image setting.

3Camera On/Off. Tap to turn the camera

on and off. When the camera is turned

off, the image displayed depends on the

Video Call options you have set. See “Set

up video call options” for details.

4Audio Mute/Unmute. Tap to mute/

unmute audio.

5Main/Second camera. Tap to switch

between the Main (back) and Second

(front) camera.

6Swap Image. Tap continuously to cycle

through the available image display

options.

456

Swap Image options

Both parties

(My video small)

The other party's image is large while your

image is small. This is the default setting.

Both parties

(My video large)

The other party's image is small while your

image is large.

Both parties (equal) Both your image and the other party appear

the same size.

Other party only Only the other party's image is displayed.

Using Phone Features 73

To adjust the brightness

You can adjust the brightness of the display

image. When you press NAVIGATION up or

down or rotate the NAVIGATION WHEEL during

a video call, a brightness bar appears at the

bottom the screen.

• Press NAVIGATION right or rotate the

NAVIGATION WHEEL counterclockwise to

increase brightness.

• Press NAVIGATION left or rotate the

NAVIGATION WHEEL clockwise to

decrease brightness.

Brightness bar

Tips • You can also press NAVIGATION up or down to adjust the brightness.

• You can also adjust the brightness by tapping Menu > Brightness.

Set up video call options

On the Phone screen, or on the screen of the ongoing video call,

tap Menu > Video Call Options. You can set the following options:

Video Call Options: General tab Video Call Options: Services tab

74 Using Phone Features

General tab

•Show still image. Select the image you want to display when you

turn off the camera.

•Preset (female). Displays a female picture in place of your image.

•Preset (male). Displays a male picture in place of your image.

•Custom image. Lets you use an image from file as your display

picture. When this option is selected, the File Name box and theWhen this option is selected, the File Name box and the is selected, the File Name box and the, the File Name box and theFile Name box and theile Name box and theName box and theame box and the

Browse button will be enabled, allowing you to select an imagerowse button will be enabled, allowing you to select an image, allowing you to select an image

file.

•Last video frame. Uses the last video frame before you stopped

the camera as your display image.

• Video screen preference. To change how your image and the other

party’s image are displayed on the screen, select your preference from

the Video screen preference list or tap the Swap Image button on

the Video Call screen.

• Camera options:

•Flip the 2nd camera video. Select this check box if you are going

to show a text document to the other party using the second

camera.

•Switch camera off when answering video call. Select this check

box if you do not want to send a video feed of yourself to the

other party. Instead, the option you selected in Show still image

will be displayed.

• Display info:

•Show call timer. Select this check box to display the call period in

the status area.

•Show phone number and name. Select this check box to display

the other party’s phone number and name in the status area.

Services tab

To set up further calling options for Video Call, tap the Services tab. On

the Services screen, select the desired service from the list, then tap Get

Settings to access its settings.

Using Phone Features 75

3.5 Receiving a Video Call

To answer or reject an incoming video call

• To answer the video call, tap Answer, or press TALK on your device.

• To reject the video call, tap Ignore, or press END on your device.

To end a video call

Once an incoming or outgoing video call is in progress, press END on the

device to hang up.

3.6 Smart Dialing

Smart Dialing makes it easy for you

to dial a phone number.

When you start entering a phone

number or contact name, Smart

Dialing will automatically search and

sort the contact entries on the SIM

card, in Contacts, and the phone

numbers in Call History (including

incoming, outgoing, and missed

calls). You can then select the desired

number or contact from the filtered

list to dial.

Smart

Dialing

panel

To find a contact name or number

You can just enter the first letter of the name or number of a contact. Smart

Dialing will search for contact phone numbers and the first character of

a contact name as well as from the character that appears after a space,

dash, or underscore in a contact name. For example, if you tap number “2”

on the phone keypad, which is associated with [a, b, and c] on the Phone

keypad, contact names such as the following will be considered matches:

“Ben Miller”, “George Adams”, “John-Carter”, “Carter, Ellen”, “Dixon, Allan”,

“Thomas_Clark”, “JaneCampbell”.

76 Using Phone Features

If the matching list is long and you want to narrow down the search further,

enter another letter. Using the same example above, if you continue to

tap “3” which is associated with [d, e, f], the matching list will be narrowed

down to the following names: “Ben Miller”, “George Adams”, “Carter, Ellen”,

“Dixon, Allan”.

Make a call or send a text message using Smart Dialing

1. Press the TALK button on your device to open the Phone screen.

2. Begin entering the first few numbers or characters.

When you start entering a number or letter, the Smart Dialing panel

will display matches found.

3. In the Smart Dialing panel, browse the list by sliding your finger or the

stylus up or down or by using NAVIGATION up or down.

4. You can do one of the following:

• When the desired contact is selected, press the TALK button tothe TALK button toTALK button to

place a call.

• To send a text message to the selected contact, tap and hold the

contact, and then tap Send Text Message.

• To call a different phone number associated with the selected

contact, tap and hold the contact, and then tap the phone

number you want to call.

Using Phone Features 77

3.7 Additional Dialing Information

Make an emergency call

Enter the international emergency number for your locale, and press the

TALK button on your device.

Tip Additional emergency numbers may be included in your SIM card. Contact

your service provider for details.

Make an international call

1. Tap and hold the number 0 key on the phone screen until the plus (+)

sign appears.

The plus (+) sign replaces the international prefix of the country that

you are calling.

2. Enter the full phone number you want to dial, and press the TALK

button on your device. The full phone number includes country code,

area code (without the leading zero, if any) and phone number.

3.8 Setting Up Bluetooth SIM Access for

Car Kit Phones

Bluetooth car kits that support the SIM Access Profile (SAP) can connect to

your device and access its SIM card via Bluetooth. Once a SAP connection

has been established, you can download SIM contacts from your device to

the car kit phone. You can also use the car kit phone to answer and make

calls using your device’s SIM card.

Note To enable downloading contacts onto the car kit, ensure that all contacts

on the device are stored in the SIM card and not in the device memory.

Configure the car kit to download contacts only from the SIM card.

1. On your device, make sure that Bluetooth is turned on and set to

visible mode. For information about turning on Bluetooth and

enabling visible mode, see “Bluetooth modes” in Chapter 10.

2. Tap Start > Settings > Connections tab > Bluetooth > SIM Access

tab.

78 Using Phone Features

3. Select the Remote SIM Access check box, then tap OK.

4. Connect the car kit phone to your device via Bluetooth. To learn how

to connect, consult your car kit phone’s manual.

5. If this is the first time you are pairing the car kit phone with your

device, enter the car kit’s passcode on your device.

6. A pop-up message should appear on your device saying that a

connection has been established between your device and car kit

phone. Tap OK.

7. On the Bluetooth screen, tap the SIM Access tab, then tap Connect.

Note You will not be able to make/receive calls, send/receive messages or perform

related activities on your device when the SIM Access Profile connection

is active. You’ll only be able to do all these from the car kit phone during

this time. After the connection is disconnected, you will be able to use your

device as before.

Chapter 4

Setting Up Your Device

4.1 Basic Settings

4.2 Personalizing the Today Screen

4.3 Protecting Your Device

80 Setting Up Your Device

4.1 Basic Settings

Time and date

To set the time and date

1. Tap Start > Settings > System tab > Clock & Alarms > Time tab.

2. Select the correct time zone and change the date or time.

Note During synchronization, the time on your device is updated with the time on

your PC.

To set the time and date for a different location

If you visit or communicate with someone in a particular time zone often,

you can select it as your visiting time zone.

1. Tap Start > Settings > System tab > Clock & Alarms > Time tab.

2. Tap Visiting.

3. Select the correct time zone and change the time or date.

Regional settings

The style in which numbers, currency, dates, and times are displayed is

specified in regional settings.

1. Tap Start > Settings > System tab > Regional Settings.

2. On the Region tab, select your region from the list.

Note This does not change the Operating System language of your device.

3. The region you select determines which options will be available on

the other tabs.

4. To customize settings further, tap the appropriate tabs and select the

desired options.

Display settings

To adjust screen brightness

1. Tap Start > Settings > System tab > Backlight > Brightness tab.

2. Move the slider to adjust the brightness.

Setting Up Your Device 81

To set the backlight to dim after a time delay

1. Tap Start > Settings > System tab > Backlight.

2. Tap the Battery power or External power tab.

3. Select the Turn off backlight if device is not used for check box, and

specify the time delay.

To increase or decrease the size of text on the screen

1. Tap Start > Settings > System tab > Screen > Text Size tab.

2. Move the slider to increase or decrease the text size.

Device name

The device name is used to identify your device in the following situations:

• Synchronizing with a PC

• Connecting to a network

• Restoring information from a backup

Note If you synchronize multiple devices with the same PC, each device must have

a unique name.

To change the device name

1. Tap Start > Settings > System tab > About.

2. Tap the Device ID tab.

3. Enter a name.

Note The device name must begin with a letter, consist of letters from A to

Z, numbers from 0 to 9, and cannot contain spaces. Use the underscore

character to separate words.

Ringer settings

To change the ring type and ring tone

1. On the Phone screen, tap Menu > Options > Phone tab.

2. In the Ring type list, choose whether to be notified of incoming calls

by a ring, a vibration, or a combination of both.

3. In the Ring tone list, tap the sound you want to use.

82 Setting Up Your Device

Tips • You can use *.wav, *.mid, *.mp3, *.wma, or other types of sound files

that you downloaded from the Internet or copied from your PC as ring

tones. For a complete list of supported audio file formats for ring tones,

see "Specifications" in the Appendix.

• To use your sound files as ring tones, copy them first to the /My

Documents/My Ringtones folder on your device, then select the sound

from the Ring tone list of your device. For more information about

copying files, see Chapter 9.

Alarms and notifications

To set an alarm

1. Tap Start > Settings > System tab > Clock & Alarms > Alarms tab.

2. Tap <Description> and enter a name for the alarm.

3. Tap the day of the week for the alarm. Select multiple days by tapping

each desired day. Tap again to deselect the day.

4. Tap the time to open a clock and set the time for the alarm.

Tip You can drag the hour and minute hand of the clock to set the time.

5. Tap the alarm icon ( ) to specify the type of alarm you want. You

can choose a flashing light, a single sound, a repeating sound, or

vibration.

6. If you choose to play a sound, tap the list next to the Play sound

check box and tap the sound you want.

To choose how to be notified about events or actions

1. Tap Start > Settings > Personal tab > Sounds & Notifications.

2. On the Sounds tab, choose how you want to be notified by selecting

the appropriate check boxes.

3. On the Notifications tab, in Event, tap an event name and choose

how you want to be notified by selecting the appropriate check

boxes. You can choose from several options, such as a special sound, a

message, or a flashing light.

Tip Turning off sounds and the flashing light helps conserve battery power.

Setting Up Your Device 83

Phone services

Your device can directly link to the mobile phone network, and enable

you to access and change the settings of various phone services for your

device. Phone services may include Call Forwarding, Call Waiting, Voicemail,

and more. Contact your wireless service provider to find out about the

availability of phone services for your device.

To access and change settings of phone services

1. Tap Start > Settings > Personal tab > Phone > Services tab.

2. Select the service you want to use, then tap Get Settings.

3. Choose your desired options, then tap OK.

For more information about customizing settings of phone services, see

Help on your device.

4.2 Personalizing the Today Screen

The Today screen shows your upcoming appointments, active tasks, and

information about incoming messages. You can customize what to display

on the Today screen.

To customize the Today screen

1. Tap Start > Settings > Personal tab > Today.

2. On the Appearance tab, select the desired theme for the background

of the Today screen.

3. On the Items tab, select the items you want to appear on the Today

screen.

To use a custom background image

You can use one of your own pictures as the background image on the

Today screen.

1. Tap Start > Settings > Personal tab > Today.

2. Select the Use this picture as the background check box, and tap

Browse to view a list of your picture files.

3. Tap the file name of the picture you want to use.

4. Tap OK.

84 Setting Up Your Device

To display owner information

Having owner information displayed on the Today screen makes it easier for

someone to return your device to you if it is lost.

1. Tap Start > Settings > Personal tab > Owner Information.

2. On the Identification tab, enter your personal information.

Tips • If you don’t see owner information on the Today screen, tap Start >

Settings > Personal tab > Today. On the Items tab, select the Owner

Info check box.

• You can set your device to display the ‘my info’ screen when your device

is turned on. This screen shows your complete personal information. To

display the 'my info' screen, tap Start > Settings > Personal tab > Owner

Information > Options tab then select the Identification information

check box.

To set options for displaying appointments on the Today screen

If you have a large number of appointments, you may want to specify the

kind of appointments that are displayed on the Today screen.

1. Tap Start > Settings > Personal tab > Today.

2. Tap the Items tab.

3. Select Calendar and tap Options.

4. Do any of the following:

• Select Next appointment to show only the next appointment

in your schedule, or Upcoming appointments to show multiple

appointments.

• Clear the Display all day events check box if you do not want to

display all-day events.

For more information about using Calendar, see Chapters 6 and 8.

To set options for displaying tasks on the Today screen

If you have a large number of tasks, you may want to specify the kind of

tasks that are displayed on the Today screen.

1. Tap Start > Settings > Personal tab > Today.

2. Tap the Items tab.

3. Select Tasks and tap Options.

Setting Up Your Device 85

4. Do any of the following:

• Under Display number of, select the type of tasks you want to

appear on the Today screen.

• In the Category list, select whether to display only tasks assigned

to a specific category or to display all tasks.

For more information about creating tasks on your device, see Chapter 6.

Customize the Start menu

You can choose which items appear in the Start menu.

1. Tap Start > Settings > Personal tab > Menus.

2. Select the check boxes of the items you want to appear in the Start

menu. You can select up to seven items.

Tip You can also create folders and shortcuts to appear in the Start menu

Programs folder. Navigate to the /Windows/Start Menu/Programs folder of

your device, then create folders and shortcuts that you want.

4.3 Protecting Your Device

Protect your SIM card with a PIN

You can protect your SIM card from unauthorized use by assigning a PIN

(personal identification number). The default PIN will be given to you by

your wireless service provider.

To change the PIN

1. On the Phone screen, tap Menu > Options > Phone tab.

2. Select the Require PIN when phone is used check box.

3. To change the PIN at any time, tap Change PIN.

Tip Emergency calls can be placed at any time, without requiring a PIN.

Protect your device with a password

You can help keep your data more secure by requiring a password every

time the device is turned on.

86 Setting Up Your Device

To set a device password

1. Tap Start > Settings > Personal tab > Lock.

2. Select the Prompt if device unused for check box, and in the box to

the right, select how long your device must be idle before a password

is required.

3. In the Password type box, select the type of password you would like

to use. If your device is configured to connect to a network, use an

alphanumeric password for increased security for your device.

4. Enter the password in both the Password and Confirm boxes.

5. Tap OK. The next time the device is turned on, you will be prompted

to enter your password.

Notes • To ensure you can always make emergency calls, do not begin your

password with the digits of your local emergency number.

• If you entered a hint, the hint will be displayed after the wrong password

is entered five times.

• Each time a wrong password is entered, the device response time gets

longer until the device appears to be not responding.

• If you forget your password, you can hard reset or clear the device

memory. Before you do this, make sure you back up your data and files

so that you can restore them back to your device. For more information

about hard resetting the device and clearing the memory, see Chapter 13.

Encrypt files on your storage card

You can set your device to encrypt files as they are saved on the storage

card.

1. Tap Start > Settings > System tab > Encryption.

2. Select Encrypt files placed on storage cards.

Notes • Encrypted files can be read only on the device that encrypted them.

• Encrypted files are opened just like other files, provided you are using the

device that encrypted them. There is no separate step for you to take to

read these files.

Chapter 5

Synchronizing Information

With Your Computer

5.1 About Synchronization

5.2 Setting Up Windows Mobile® Device

Center on Windows Vista®

5.3 Setting Up ActiveSync® on

Windows XP®

5.4 Synchronizing With Your Computer

5.5 Synchronizing via Bluetooth

5.6 Synchronizing Music and Video

88 Synchronizing Information With Your Computer

5.1 About Synchronization

You can take information from your computer wherever you go by

synchronizing them to your device. The following types of information can

be synchronized between your computer and your device:

• Microsoft Outlook® information, which include Outlook e-mail,

contacts, calendar, tasks, and notes

• Media, such as pictures, music and video

• Favorites, which are the bookmarked links to your favorite web sites

• Files, such as documents and other files

Before you can synchronize, you need to install and set up first the

synchronization software on your computer. For more information, see

“Setting Up Windows Mobile Device Center on Windows Vista®” and “Setting

Up ActiveSync® on Windows XP®”.

Ways to synchronize

After you have installed the synchronization software to your computer,

connect and synchronize your device with your computer by using one of

the following methods:

• Connect and synchronize using the supplied USB sync cable.

Upon connecting the sync cable to your device and your computer,

the synchronization process starts automatically.

• Connect and synchronize using Bluetooth.

You must first set up a Bluetooth partnership between your device

and your computer before you can synchronize information between

them using Bluetooth. For more information about setting up

a Bluetooth partnership, see Chapter 10. For information about

synchronizing through Bluetooth, see “Synchronizing via Bluetooth”

later in this chapter.

Try to synchronize frequently in order to keep information up-to-date in

both your device and your computer.

Note You can also synchronize Outlook e-mail, contacts, calendar, and tasks on

your device with the Exchange Server at your work. For more information

about setting up your device to synchronize with the Exchange Server, see

Chapter 8.

Synchronizing Information With Your Computer 89

5.2 Setting Up Windows Mobile® Device Center on

Windows Vista®

Microsoft Windows Mobile® Device Center is the replacement for

Microsoft® ActiveSync® on Windows Vista®.

Note Some versions of Windows Vista come with Windows Mobile Device Center

already installed. If Windows Mobile Device Center is not available on your

Windows Vista, you can install it from the Getting Started Disc that came with

your device.

Set up synchronization in Windows Mobile Device Center

When you connect your device to your PC and start Windows Mobile

Device Center for the first time, you are asked to create a Windows

Mobile partnership with your device. Follow the steps below to create a

partnership.

1. Connect your device to your PC. Windows Mobile Device Center

configures itself and then opens.

2. On the license agreement screen, click Accept.

3. On the Windows Mobile

Device Center’s Home

screen, click Set up your

device.

Note Choose Connect

without setting up

your device if you only

want to transfer media

files, check for updates,

and explore your device

but not sync Outlook

information.

4. Select the items you want to synchronize, then click Next.

5. Enter a device name and click Set Up.

When you finish the setup wizard, Windows Mobile Device Center

synchronizes your device automatically. Notice that Outlook e-mails and

other information will appear on your device after synchronization.

90 Synchronizing Information With Your Computer

Use Windows Mobile Device Center

To open Windows Mobile Device Center, click Start > All Programs >

Windows Mobile Device Center on your Windows Vista® computer.

On Windows Mobile Device Center, you can do the following:

• Click Mobile Device Settings to change synchronization settings.

• When you click Pictures, Music and Video > ___ new pictures/

video clips are available for import, a wizard guides you to tag

and transfer photos from your device to the Photo Gallery on your

Windows Vista PC.

• Click Pictures, Music and Video > Add media to your device from

Windows Media Player to synchronize music and video files using

Windows Media™ Player. For more information, see “Windows Media®

Player Mobile” in Chapter 12.

• Click File Management > Browse the contents of your device to

view documents and files from your device.

Note See Windows Mobile Device Center Help for more information.

Synchronizing Information With Your Computer 91

5.3 Setting Up ActiveSync® on Windows XP®

The Getting Started Disc that comes with your device contains Microsoft

ActiveSync 4.5 or later. Follow the steps in this section to install and set up

ActiveSync on Windows XP or other compatible Windows systems.

Note For a list of compatible Windows systems, please go to

http://www.microsoft.com/windowsmobile/activesync/activesync45.mspx.

Install ActiveSync

1. Insert the Getting Started Disc into the disc drive on your PC.

2. Click Setup and Installation.

3. Select the ActiveSync check box and click Install.

4. Read the license terms and click Accept.

5. When installation is complete, click Done.

6. On the Getting Started with Windows Mobile screen, click Close.

Set up synchronization in ActiveSync

Follow the steps below to set up a synchronization partnership.

1. Connect your device to your PC. The Synchronization Setup Wizard

automatically starts and guides you to create a synchronization

partnership. Click Next to proceed.

2. To synchronize your device with your PC, clear the Synchronize

directly with a server running Microsoft Exchange check box then

click Next.

3. Select the information types that you want to synchronize then click

Next.

4. Select or clear the Allow wireless data connections check box

according to your preference.

5. Click Finish.

When you finish the wizard, ActiveSync synchronizes your device

automatically. Notice that Outlook e-mails and other information will

appear on your device after synchronization.

92 Synchronizing Information With Your Computer

5.4 Synchronizing With Your Computer

Connect and synchronize your device with your PC using the USB cable or

Bluetooth connection.

Start and stop synchronization

You can manually synchronize either from your device or PC.

From your device

• Tap Start > Programs > ActiveSync, then tap Sync.

To end synchronization before it completes, tap Stop.

Tip To delete a partnership with one PC completely, disconnect your device

from that PC first. In ActiveSync on your device, tap Menu > Options, tap the

computer name, then tap Delete.

From Windows Mobile Device Center

1. Click Start > All Programs > Windows Mobile Device Center.

2. Click at the lower left of the Windows Mobile Device Center.

To end synchronization before it completes, click .

From ActiveSync on your PC

When you connect your device to your PC, ActiveSync automatically opens

on your PC and synchronizes.

• To manually start synchronization, click .

• To end synchronization before it completes, click .

Change which information is synchronized

You can change the information types and the amount of information to

synchronize for each type either on your device or your PC. Follow the steps

below to change synchronization settings on your device.

Note Before changing synchronization settings on your device, disconnect it from

your PC.

1. In ActiveSync on your device, tap Menu > Options.

2. Select the check box for any items you want to synchronize. If you

cannot select a check box, you might have to clear the check box for

the same information type elsewhere in the list.

Synchronizing Information With Your Computer 93

3. To change synchronization settings for an information type, for

instance, E-mail, select it and tap Settings.

You can then set the download size limit, specify the time period of

information to download, and more.

Notes • Some information types such as Favorites, Files and Media cannot be

selected in ActiveSync Options on your device. You can only select or clear

these items from your PC’s Windows Mobile Device Center or ActiveSync.

• A PC can have sync partnerships with many different Windows Mobile

powered devices, but a device can have sync partnerships with at most

two PCs. To ensure that your device will synchronize properly with both

PCs, set up the second PC using the same synchronization settings you

used on the first PC.

• Outlook e-mail can be synchronized with only one PC.

Troubleshoot sync connection problem

When a PC is connected to the Internet or a local network, in some cases,

the PC may disconnect the connection with your device in favor of the

Internet or network connection.

If this happens, tap Start > Settings > Connections tab > USB to PC, then

clear the Enable advanced network functionality check box. This makes

your PC utilize a serial USB connection with your device.

The USB to PC ( ) icon appears on the Today Screen when serial USB

connection is used. You can tap this icon to disconnect from the PC.

5.5 Synchronizing via Bluetooth

You can connect and synchronize your device with the PC using Bluetooth.

Note To connect and synchronize your device with a computer via Bluetooth, your

computer must have built-in Bluetooth or installed with a Bluetooth adapter

or dongle.

To synchronize with a computer via Bluetooth

1. Set up Windows Mobile Device Center or ActiveSync on your PC

to synchronize through Bluetooth. See the program’s Help for

instructions.

94 Synchronizing Information With Your Computer

2. On your device, tap Start > Programs > ActiveSync.

3. Make sure that Bluetooth on both your device and the computer

are turned on and set to visible mode. For more information, see

“Bluetooth” in Chapter 10.

If this is the first time you have connected to this computer via

Bluetooth, you must first complete the Bluetooth wizard on your

device and set up a Bluetooth partnership between your device

and the computer. For more information about creating a Bluetooth

partnership, see “Bluetooth partnerships” in Chapter 10.

4. Tap Menu > Connect via Bluetooth. Make sure the Bluetooth

function of both your device and the computer are turned on and set

to visible mode.

Note To preserve battery power, turn off Bluetooth when not in use.

5.6 Synchronizing Music and Video

If you want to carry your music or other digital media along with you while

you travel, set up Microsoft® Windows Media® Player on your computer to

synchronize music and video with your device.

Other than selecting the Media information type to be synchronized, all

media synchronization settings must be set in Windows Media Player.

Before media can be synchronized, you must do the following:

• Install Windows Media Player Version 11 on the PC. (Windows Media

Player 11 works only in Windows XP or later versions).

• Connect your device to the PC with a USB cable. If your device is

currently connected using Bluetooth, you must end that connection

before media can be synchronized.

• Set up a sync partnership between your device and your PC’s

Windows Media® Player.

For more information about using Windows Media® Player Mobile, see

Chapter 12.

Chapter 6

Organizing Contacts,

Appointments, Tasks, and

Other Information

6.1 Contacts

6.2 SIM Manager

6.3 Calendar

6.4 Tasks

6.5 Notes

6.6 Voice Recorder

96 Organizing Contacts, Appointments, Tasks, and Other Information

6.1 Contacts

Contacts is your address book and information storage for people and

businesses you communicate with. You can create the following types of

contacts on your device:

• Outlook contacts. Contacts that are

stored on your device, which can be

created on your device or synchronized

with your PC or the Exchange Server.

• SIM contacts. Contacts that are stored

on the SIM card. Only a name and phone

number can be stored for each entry.

• Windows Live contacts. Contacts that

you communicate with using Windows

Live Messenger or MSN. Just like Outlook

contacts, you can also enter complete

information for a Windows Live contact.

For more information, see “Add Windows

Live contacts” in Chapter 10.

Note You can only add Windows Live contacts after you have set up Windows

Live on your device.

Add new contacts

To add a contact on your device

1. Tap Start > Contacts.

2. Tap New, select Outlook Contact, and

enter the contact information.

3. In the File as field, choose how you

want the contact name to appear in the

contact list.

4. To add a photo of the contact, tap Select a picture, then select the

picture file or tap Camera to take a photo of the contact.

Organizing Contacts, Appointments, Tasks, and Other Information 97

This photo appears on the Phone screen when you receive a call from

the contact.

5. To assign a ring tone to the contact, tap the Ring tone field, scroll

through the list of tones, then select a desired tone.

6. When finished, tap OK.

Tips • If someone who is not in your list of contacts calls you, create a contact

from Call History by tapping and holding a phone number and then

tapping Save to Contacts from the shortcut menu.

• To save a phone number that is contained in a message, tap the phone

number, then tap Menu > Save to Contacts.

• To edit contact information, tap the contact name then tap Menu > Edit.

To add a contact to your SIM card

1. Tap Start > Contacts.

2. Tap New then select SIM Contact.

3. Enter a contact name and phone number.

4. Tap OK.

Tip You can also use the SIM Manager to add and edit contacts on your SIM card.

For more information, see "SIM Manager" later in this chapter.

View, organize and search

To view contact information

1. Tap Start > Contacts.

2. Slide your finger upward on the touch screen to scroll down the

contact list.

To scroll up the contact list, slide your finger downward on the touch

screen.

Note For detailed instructions on how to use finger scrolling, see "Finger

scrolling and finger panning" in Chapter 1.

98 Organizing Contacts, Appointments, Tasks, and Other Information

3. Touch the name of a contact to open his

or her contact card.

On the contact card, you will see the

last outgoing or incoming call as well

as detailed information such as phone

numbers of the contact, e-mail address,

and more.

To find a contact on your device

There are several ways to find a contact when your contact list is long.

1. Tap Start > Contacts.

2. Do one of the following:

• On the Quick Scroll

bar on the right of the

screen, scroll to or tap

a letter to go directly to

the part of the Contacts

list where contact names

start with that letter.

Quick Scroll

bar

Note You can disable the Quick Scroll bar by tapping Menu > Options and

selecting the Show alphabetical index check box. This will show the

alphabetical index at the top of the Contacts list.

• Begin entering a contact name in the provided text box until the

contact you want is displayed.

• Filter the list by categories. In the contact list, tap Menu > Filter,

then tap a category you’ve assigned to a contact. To show all

contacts again, select Menu > Filter > All Contacts.

Organizing Contacts, Appointments, Tasks, and Other Information 99

To group similar contacts

You can group similar contacts for easier management by assigning them

to categories.

1. Create a new Outlook contact or edit an existing Outlook contact.

2. Tap Categories.

3. Select a preset category such as Business or Personal, or tap New to

create your own category.

4. When finished, tap OK.

To view contacts by category

• Tap Menu > Filter then select the desired category.

Share contact information

To beam a contact’s details

You can quickly send contact information to another mobile phone or

device through Bluetooth beaming.

1. Tap Start > Contacts, then select a contact.

2. Tap Menu > Send Contact > Beam then select a device where to

beam the contact to.

Note Before beaming, make sure Bluetooth is turned on and set to visible mode

on your device and the target mobile device. You can also beam contact

information to your PC. See "Bluetooth" in Chapter 10 for details.

To send contact information via text messaging

1. Tap Start > Contacts, then select a contact.

2. Tap Menu > Send Contact > SMS \ MMS.

3. Select the contact information you want to send, then tap Done.

4. In the new text message, enter the mobile phone number of the

recipient, then tap Send.

To send contact information as a vCard

A vCard (virtual business card) is a standard file format used for exchanging

contact information. vCard files can be exported to Outlook on the PC. From

your device, you can send a vCard containing contact information as a file

attachment in an MMS message.

100 Organizing Contacts, Appointments, Tasks, and Other Information

1. Tap Start > Contacts, then select a contact.

2. Tap Menu > Send as vCard.

3. A new MMS message is created with the vCard file attached. Enter

the mobile phone number or e-mail address of the recipient then tap

Send.

For more information, see “MMS” in Chapter 7.

6.2 SIM Manager

SIM Manager allows you to view the contents of your SIM card, transfer

contacts from your SIM card to your device or vice versa, and make a call to

a SIM contact.

To create a contact on your SIM card

1. Tap Start > Programs > SIM Manager.

2. Tap New and enter a contact name and phone number.

3. Tap Save to save the information on your SIM card.

Tip: To change contact information on your SIM card, tap a SIM contact and edit

it. After modifying, tap Save.

To copy SIM contacts to your device

If you have saved contacts on your SIM card, you can copy them into

Contacts on your device.

1. Tap Start > Programs > SIM Manager.

2. Select the desired contact, or select all SIM contacts by tapping Menu

> Select All.

3. Tap Menu > Save to Contacts.

To copy contacts to the SIM card

Only one phone number per contact name can be stored on a SIM card.

When you copy a contact that has several phone numbers to your SIM card,

SIM Manager saves each number under a separate name.

To save each number under a different contact name on the SIM card, SIM

Manager appends an indicator at the end of each name.

Organizing Contacts, Appointments, Tasks, and Other Information 101

By default, /M, /W and /H are appended to indicate mobile, work and home

phone numbers respectively. You can edit this indicator first before you

start copying contacts to your SIM card. Indicators of the other types of

phone numbers are left empty for you to define them.

1. Tap Start > Programs > SIM Manager, then tap Menu > Tools >

Options.

2. Select the check boxes of the types of phone numbers that you want

to be added to the SIM card.

3. Under the Mark column, you can

change the indicator that will be

appended to the SIM contact names

for each phone number type. To do so,

select a phone type, tap Edit, enter your

desired indicator, then tap Save.

4. After modifying, tap OK.

5. Tap Menu > Contacts to SIM.

6. Select the check boxes of the contact’s

phone numbers that you want to copy

to your SIM card, then tap Save.

To store your SIM card’s phone number

1. On the SIM Manager

screen, tap Menu >

Tools > List of Own

Numbers.

2. Tap [Voice Line 1].

3. Change the name, if

desired, then enter

your mobile phone

number.

4. Tap Save.

When your phone

number is stored

on the SIM card,

it will appear on

the SIM Manager

screen.

102 Organizing Contacts, Appointments, Tasks, and Other Information

6.3 Calendar

Use Calendar to create appointments, including meetings and other

events. You can also synchronize Calendar appointments between your

device and PC.

Create appointments

To schedule an appointment

1. Tap Start > Calendar.

2. Tap Menu > New Appointment.

3. Enter a name for the appointment.

4. Do one of the following:

• If it is a special occasion such as a birthday or a whole-day event,

set the All Day option to Yes.

• If there is a time frame for the appointment, select the start and

end dates and time.

5. Specify the type of category for your appointment, so that it can be

grouped with other related appointments. Tap Categories, then

select a preset category (Business, Holiday, Personal, or Seasonal), or

tap New to create your own category.

6. When finished, tap OK to return to the calendar.

Notes • All-day events do not occupy blocks of time in Calendar; instead, they

appear in banners at the top of the calendar.

• To remove an appointment, tap Menu > Delete Appointment.

Tip To have the time entered automatically in Day view, tap and drag to select a

time slot for the new appointment, and tap Menu > New Appointment.

To set a default reminder for all new appointments

You can have a reminder automatically turned on for all new appointments

that you schedule.

1. Tap Start > Calendar.

2. Tap Menu > Tools > Options > Appointments tab.

3. Select the Set reminders for new items check box.

Organizing Contacts, Appointments, Tasks, and Other Information 103

4. Set the time when you want the reminder to alert you.

5. Tap OK to return to the calendar.

View appointments

By default, Calendar displays appointments in Agenda view. You can also

look at your appointments in Day, Week, Month, and Year views.

The highlighted hours

here indicate the time of

your appointments.

Tap to view appointment

details.

Agenda view

Tap to switch views.

Indicates

that there

is a conflict

with another

appointment.

• To see detailed appointment information in any view, tap the

appointment.

• To view appointments by category, tap Menu > Filter then select the

desired category.

• To change the default view that Calendar uses to display

appointments, tap Menu > Tools > Options > General tab. Tap the

Start in box then choose the calendar view.

• When in Month view, you will see the following indicators:

Morning appointment

Afternoon or evening appointment

Both morning and afternoon/evening appointments

All-day event

104 Organizing Contacts, Appointments, Tasks, and Other Information

Send appointments

To send a meeting request

Use Calendar to schedule meetings via e-mail with contacts who use

Outlook or Outlook Mobile.

1. Tap Start > Calendar.

2. Schedule a new appointment, or open an existing one and tap Menu

> Edit.

3. Tap Attendees, then tap Add Required Attendee or Add Optional

Attendee and add the contacts whom you want to invite.

Note You can specify if an attendee is required or optional only if your

device is connected to a Microsoft Exchange 2007 server. Otherwise,

all attendees are designated as required. For more information, see

Chapter 8.

4. When you have finished adding attendees, tap Done.

5. Tap OK to send.

Tip To choose the e-mail account to use for sending meeting requests, tap

Menu > Tools > Options > Appointments tab. Tap the Send meeting

requests via box and choose to send via your Outlook E-mail, POP3/IMAP4

or Windows Live account.

Notes • If you’re sending the meeting request using your Outlook E-mail account,

it will be sent to the attendees the next time you synchronize your device

with your PC or Exchange Server.

• When attendees accept your meeting request, the meeting is

automatically added to their schedules. When their response is sent back

to you, your calendar is updated as well.

To send appointment details as a vCalendar

A vCalendar is a standard file format used for exchanging scheduling and

task information. vCalendar files can be exported to Outlook on the PC.

Tap Menu > Send as vCalendar to send a vCalendar containing

appointment details as a file attachment in an MMS message. For more

information, see “MMS” in Chapter 7.

Organizing Contacts, Appointments, Tasks, and Other Information 105

6.4 Tasks

Use Tasks to keep track of things you need to do. A task can occur once or

repeatedly (recurring). You can set reminders for your tasks and you can

organize them using categories.

Your tasks are displayed in a task list. Overdue tasks are displayed in red.

To create a task

1. Tap Start > Programs > Tasks.

2. Tap Menu > New Task, enter a subject for the task, and fill in

information such as start and due dates, priority, and so on.

3. Specify the type of category for your task, so that it can be grouped

with other related tasks. Tap Categories, then select a preset category

(Business, Holiday, Personal, or Seasonal), or tap New to create your

own category.

4. When finished, tap OK.

Tip You can easily create a short, to-do type task. Simply tap the Tap here to add

a new task box, enter a subject, and tap the Enter button on the on-screen

keyboard. If the task entry box is not available, tap Menu > Options and

select the Show Tasks entry bar check box.

To change the priority of a task

Before you can sort tasks by priority, you need to specify a priority level for

each task.

1. Tap Start > Programs > Tasks.

2. Tap the task you want to change the priority for.

3. Tap Edit, and tap a priority level in the Priority box.

4. Tap OK to return to the task list.

Note All new tasks are assigned a Normal priority by default.

106 Organizing Contacts, Appointments, Tasks, and Other Information

To set the default reminder for all new tasks

1. Tap Start > Programs > Tasks.

2. Tap Menu > Options.

3. Select the Set reminders for new items check box.

4. Tap OK to return to the task list.

Note The new tasks must have due dates set in order for the reminder to take

effect.

To show start and due dates in the task list

1. Tap Start > Programs > Tasks.

2. Tap Menu > Options.

3. Select the Show start and due dates check box.

4. Tap OK.

To locate a task

When your list of tasks is long, you can display a subset of the tasks or sort

the list to quickly find a specific task.

1. Tap Start > Programs > Tasks.

2. In the task list, do one of the following:

• Sort the list. Tap Menu > Sort By, and tap a sort option.

• Filter the list by category. Tap Menu > Filter, and tap the category

you want displayed.

Tip To filter your tasks further, tap Menu > Filter > Active Tasks or Completed

Tasks.

To send task information as a vCalendar

Tap Menu > Send as vCalendar to send a vCalendar containing task details

as a file attachment in an MMS message. For more information, see “MMS”

in Chapter 7.

Organizing Contacts, Appointments, Tasks, and Other Information 107

6.5 Notes

Using Notes, you can create handwritten and typed notes, record voice

notes, convert handwritten notes to text for easy readability, and more.

To create a note

1. Tap Start > Programs > Notes. In the note list, tap New.

2. Tap the Input Selector arrow next to the Input Method icon on the

menu bar, tap the input method you want, and enter your text.

3. If the Input Selector arrow is not displayed, tap the Input Method

icon.

4. When finished, tap OK to return to the note list.

Notes • To select handwritten text, tap and hold next to the writing. As soon as

dots appear, and before they form a complete circle, quickly drag across

the writing.

• If a letter crosses three ruled lines, it is treated as a drawing rather than

text.

To draw in a note

1. Tap Start > Programs > Notes.

2. In the note list, tap New.

3. To draw on the screen, use the stylus like

a pen. A selection box appears around

your drawing.

4. When finished, tap OK to return to the

note list.

Note To select a drawing (for example, to copy or

delete it), tap and hold the drawing briefly.

When you lift the stylus, the drawing is

selected.

108 Organizing Contacts, Appointments, Tasks, and Other Information

To record a voice note

You can create a stand-alone recording (voice note) or you can add a

recording to a note.

1. Tap Start > Programs > Notes.

2. If you do not see the Recording toolbar, tap Menu > View Recording

Toolbar.

3. Do one of the following:

• To create a stand-alone recording, record from the note list.

• To add a recording to a note, create or open a note.

4. Tap the Record icon ( ) to begin recording your voice. Tap the

Stop icon ( ) when finished recording.

To change recording formats

1. Tap Start > Settings > Personal tab > Input.

2. Tap the Options tab, and select the desired format you want in the

Voice recording format list.

3. Tap OK.

Note

You can also change recording formats from within Notes. In the note list, tap

Menu > Options > Global Input Options link (at the bottom of the page),

then tap the Options tab.

Organizing Contacts, Appointments, Tasks, and Other Information 109

6.6 Voice Recorder

Voice Recorder lets you record your voice and then quickly send it in an

MMS or e-mail, beam it, or set the recorded voice as your ring tone.

Note

Voice Recorder saves voice recordings in AMR-NB (Adaptive Multi-Rate

Narrowband) format only. This is a common speech audio format used in

mobile devices.

To record your voice

1. Tap Start > Programs > Voice Recorder.

2. Hold the device’s microphone close to your mouth.

3. Tap Record or to start recording a voice clip. Tap Stop or to

end the recording.

All recordings are saved in the My Voices folder by default. You can choose

another folder to save voice recordings by tapping beside the folder name

on the top-left of the screen and then in the menu, choose the folder where

to save future recordings.

To play back a voice recording

• On the Voice Recorder screen, select a voice recording then tap .

Tips • Tap to increase the volume; tap to decrease the volume.

• Tap to toggle between muting and unmuting the volume.

To send the voice recording through MMS

• Select a voice recording then tap Menu > Send via MMS. A new

MMS message is then created with the voice recording automatically

inserted as an audio clip.

See “MMS” in Chapter 7 to learn how to compose and send MMS

messages.

To send the voice recording via e-mail

• Select a voice recording then tap Menu > Send > Outlook E-mail.

This creates a new Outlook e-mail message with the voice recording

inserted as a file attachment.

See “Using E-mail” in Chapter 7 to learn how to send e-mails.

110 Organizing Contacts, Appointments, Tasks, and Other Information

To beam the voice recording

1. Select the voice recording(s) you want to beam then tap Menu >

Beam File.

Tip To select multiple recordings, tap and drag over the desired recordings

or tap Menu > Select All.

2. Tap the device you want to send the voice recording(s) to.

3. On the other device, accept the file transfer to receive the file.

To set the voice recording as a ring tone

• Select the desired voice recording the tap Menu > Set as Ringtone.

To rename or move a recording

1. Select a voice recording then tap Menu > Rename/Move.

Tip To select multiple recordings, tap and drag over the desired recordings

or tap Menu > Select All. Note that you can only move multiple files;

you cannot rename them.

2. Enter the new Name for the voice recording.

3. To move the voice recording, select the new destination Folder and

Location.

4. Tap OK.

HTC PL POLA100 User Manual 2 Revised 0725

HTC Corporation POLA100 2 Revised 0725

Contents

User Manual 2 Revised 0725

Navigation menu

Namespaces

Views

Navigation
