User Manual
USER’S MANUAL
SB-300
■ To prevent damage or injury, be sure to read and understand these User’s Manual before using your IGO AUDIO
SOUND BASE SYSTEM
■ Please keep these instructions handy for future reference.
SOUND BASE SYSTEM
USER’S MANUAL
SB-300
■
To prevent damage or injury, be sure to read and understand these User’s Manual before using
■
Please keep these instructions handy for future reference.
SOUND BASE SYSTEM
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat resisters, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has
two blades and a third grounding prong. The wide blade
or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lighting storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been
dropped.
For customers in the United States
Important Safety Instructions
THIS CLASS B DIGITAL APPARATUS COMPLIES
WITH CANADIAN ICES-003. CET APPAREIL
NUMÉRIQUE DE LA CLASSE B EST CONFORME
À LA NORME NMB-003 DU CANADA.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS;
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
FCC Information for use
The following FCC statement applies only to the version of this
model manufactured for sale in the U.S.A. Other versions may
not comply with FCC technical regulation.
CAUTION
You are cautioned that any changes or modifications not
expressly
approved in this manual could void your authority
to operate this equipment.
NOTE:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
– Change the direction or location of the receiving antenna.
–
Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
–
Consult the dealer or an experienced radio/TV technician for
help.
WARNING : SHOCK HAZARD - DO NOT OPEN
AVIS : RISQUE DE CHOC ÉLECTRIQUE - NE PAS OUVRIR
These symbols on the products, packaging, and/or
accompanying documents mean that used electrical and
electronic products and batteries should not be mixed with
general household waste. For proper treatment, recovery
and recycling of old products and used batteries, please take
them to applicable collection points, in accordance with your
national legislation and the Directives 2002/96/EC and
2006/66/EC.
By disposing of these products and batteries correctly, you
will help to save valuable resources and prevent any
potential negative effects on human health and the
environment which could otherwise arise from inappropriate
waste handling.
For more information about collection and recycling of old
products and batteries, please contact your local municipal-
ity, your waste disposal service or the point of sale where
you purchased the items.
[Information on Disposal in other Countries outside the
European Union]
These symbols are only valid in the European Union. If you
wish to discard these items, please contact your local
authorities or dealer and ask for the correct method of
disposal.
Note for the battery symbol:
This symbol might be used in combination with a chemical
symbol. In this case it complies with the requirement set by
the Directive for the chemical involved.
Important precautions are provided on the product and in
these operating instructions to prevent potential personal
injury to users and other people as well as damage to
property, and to ensure the safe and proper use of the
product.
Understand the indications, marks and symbols fully before
reading the rest of the instructions. Observe the precautions.
Explanation of Indications
*1: Serious injury refers to loss of sight, injuries, burns (high-and
low-temperature), electric shock, broken bones and poisoning,
etc. that cause after-effects or require hospitalization or
prolonged outpatient treatment.
*2: Minor injury refers to injuries, burns and electric shock that
require no hospitalization or prolonged outpatient treatment.
*3: Damage to property refers to extended damage to houses,
buildings, furniture, livestock, pets and others.
Explanation of Symbols
For customers in Europe
Information for Users on Collection and Disposal of
Old Equipment and used Batteries
Getting Started
Supplied Accessories
Getting Started
Supplied Accessories
Safety Precautions
Remote control (IRT-S100)
AAA R03 batteries
Pin Cable
Optical Cable
User’s Manual
■ The following accessories are supplied with your IGO
AUDIO SOUND BASE SYSTEM. Please make sure that
these accessories are included in the package.
■ If you wish to use a pin cable or an optical cable other
than those supplied, purchase a commercially-available
cable suitable for the location, jack type and usage
environment of the unit.
Accessory Quantity
MeaningIndication
1
2
1
1
1
Indicates improper handling or operation
could result in death or serious injury*1.
Indicates improper handling or operation
could result in minor injury*2 or damage*3
to property.
MeaningSymbol
Indicates prohibition
(an action that is not allowed).
What is prohibited will be described in or
near the symbol in either text or picture
form.
Indicates an instruction that must be
followed (a compulsory action).
Detailed instructions will be described in
or near the symbol in either text or picture
form.
Indicates disconnection.
■
If the unit emits smoke or an unusual smell, disconnect
the power plug from the wall outlet immediately.
Using the unit under such conditions may
result in fire or electric shock.
Make sure that the unit no longer emits the
smoke and then contact your dealer.
■ If the unit produces no sound, disconnect
the power plug from the wall outlet immediately.
Using the unit under such a condition may
result in fire.
Contact your dealer for inspection.
■
If water or other foreign objects enter the unit, disconnect
the power plug from the wall outlet immediately.
Using the unit under such conditions may result
in fire or electric shock.
Contact your dealer for inspection.
■
If the cabinet is damaged, disconnect the power plug
from the wall outlet immediately.
Using the unit under such a condition may result
in fire or electric shock.
Handling the unit with damaged cabinet may
cause injury.
Contact your dealer for inspection or repair.
■
If the power cord or plug is damaged or becomes hot,
press the POWER button on the unit to turn it off.
Make sure that the power plug is cooled down and
then disconnect from the wall outlet.
Using the unit under such conditions may result
in fire or electric shock.
If the power cord or plug is damaged, contact
your dealer for replacement.
On abnormal operation and breakdown
■ I
nstall this unit where the power plug is easily
accessible in case of unforeseen problems or
breakdown or when you are not going to use
the unit for a long time.
■ Do not install this unit in a place subject to
water splashes such as the bathroom or
outdoors. This may cause fire or electric
shock.
■
Do not install this unit in an uneven location such
as an inclined surface.
The TV may fall and cause injury.
Install the unit on a level, stable surface.
■
Do not install this unit in a location subject
to vibration.
The unit may move or fall, resulting in injury.
■
Fully insert the power plug into a wall outlet.
Improper plug connections may cause the
unit to overheat and result in fire.
Avoid using a damaged power plug or a
loose wall outlet.
■
Do not place any objects or pets on the unit.
Metals, liquids, cosmetics and pets may cause fire
or electric shock if they enter the unit.
A heavy object placed on the unit may cause
injury if it falls.
■
If the installed TV is wider than this unit, be careful
not to allow any protruding portion of the TV to
come into contact with other objects.
The TV may fall or be damaged, resulting in injury.
A heavy object placed on the unit may cause
injury if it falls.
On installation ■
Do no install this unit in a place subject to humidity,
oil mist or high levels of dust.
Installing the unit near a humidifier or cooking
stove or in a dusty place may cause fire or
electric shock.
■
If no measure is taken to prevent the TV from
falling or toppling, there may be a high risk of
injury.
■
Do not block the ventilation holes.
Blocked ventilation holes may cause heat build-up and
result in fire.
·
The gap created around the amplifier is there to dissipate
its heat emissions. Do not place objects on the amplifier
or block the gap.
·
Do not push the unit against the wall. (Allow a gap of
approximately 4 inches between the unit and the wall.)
·
Do not push the unit into a place with poor
ventilation, such as a closet.
·
Do not place the unit with its front side
facing up, on its side or upside down.
■
Do not place any equipment exceeding the specified
maximum weight on the top, shelf or bottom board
of the unit.
Prolonged use of the unit with overweight objects
placed on it may cause injury or damage to the unit.
·
The weight limits for the objects to be placed on
each board
·
Do not place any objects other than a TV on
the top board.
■ Do not repair, modify or disassemble the unit.
High-voltage components inside the unit may
cause electric shock or fire.
Contact your dealer for internal inspection,
adjustment or repair.
■ Do not:
·
damage, modify (e.g. use an extension), heat (place
close to any heating appliance) the power cord or
plug;
·
pull, pinch or place heavy objects on the
power cord or plug; or
·
forcedly bend, twist or bundle the power
cord or plug.
Doing so may cause fire or electric shock.
■
Do not put foreign objects into the unit.
If metals or flammable objects such as papers
enter the unit from the ventilation hole, fire or
electric shock may result.
■
Do not touch the power cord of the unit or the
cables/cords of the components connected to
this unit during a lightning storm.
Doing so may cause electric shock.
On operation
■ When installing a TV:
·
Take measures to prevent falling.
Failure to observe this caution may cause the
TV to fall, resulting in injury or damage.
Be extra careful with children.
■
Do not exceed the maximum rated output power
when using a wall outlet or wiring device.
Avoid sharing a single outlet with an
unreasonable number of other devices.
Doing so may cause fire or electric shock.
■ Be careful that some parts of this unit may become hot
during use.
■ If you move the unit to a remote place (e.g. moving house)
cover it with an object such as a blanket to avoid damage.
Do not subject the unit to strong impact or vibration.
■ Do not spray volatile solvents such as insecticides.
Do not allow rubber or plastic/vinyl products to come into
prolonged contact with the unit. This may cause deterioration
or damage to the surface finishing.
■ Avoid placing magnetic cards such as ATM cards or video
tapes near the unit. Data or information stored inside may
be lost due to magnetism from the unit.
■ External input images or sound may be slightly delayed
causing discomfort to users;
• when enjoying Karaoke using a Karaoke equipment
connected to the unit; or
• when listening to the sound from a DVD or video directly
connected to the unit.
On operation
Disconnect the power plug from the wall outlet before
cleaning the unit.
Failure to observe this caution may cause electric shock.
■
Do not use benzene or alcohol.
·
Do not use any volatile solvents such as benzene or
alcohol. Use of such substances may cause the cabinet
to deteriorate or damage the surface finishing.
Disconnect the power plug from the wall outlet before
cleaning the unit.
Failure to observe this caution may cause electric shock.
■
Cleaning the cabinet and control panel.
·
Remove the dirt and dust accumulated on the cabinet
and then lightly wipe with a commercially-available
cleaning cloth or soft cloth. Wiping or rubbing the
cabinet or control panel with a dirty cloth or an abrasive
cloth may damage or scratch the cabinet surface.
·
When using a chemical cleaning cloth, follow the
instructions on the package.
On cleaning
On operation
■ FORMOSA PROSONIC INDUSTRIES BERHAD shall not
be liable for any damages arising out of or in connection
with a natural disaster such as an earthquake or lightning,
fire, act of any third party, other accidents, intentional or
negligent act of customer, misuse and/or use of this
product under other abnormal conditions.
■ FORMOSA PROSONIC INDUSTRIES BERHAD shall not
be liable for any incidental damages arising out of or in
connection with the use or unavailability of this product
(including damages to business interests, business
interruption and loss of viewing fees).
■ FORMOSA PROSONIC INDUSTRIES BERHAD shall not
be liable for any damages arising out of or in connection
with non-observance of the contents of these Operating
Instructions.
■ FORMOSA PROSONIC INDUSTRIES BERHAD shall not
be liable for compensation for and/or incidental damages
arising out of or in connection with any data, including
videos, pictures and sound, that failed to be recorded
correctly in the recording device connected to this unit, or
that were altered or lost.
■ FORMOSA PROSONIC INDUSTRIES BERHAD shall not
be liable for any damages arising out of or in connection
with malfunctions, defects or improper operations
(including breakdown of the recording device connected
to the unit and alteration or loss of recorded data)
occurred by adding other equipment connected to the
unit.
■ The settings stored in the unit may be altered or lost due
to malfunction or noise including static electricity.
FORMOSA PROSONIC INDUSTRIES BERHAD shall not
be liable for such an incidence.
Disclaimer
■ Dispose of this product following the local guidelines or
regulations for its disposal. Contact your local government
for more detailed information on disposal.
On disposal
■
If you are not going to use the unit for a long time (e.g. if
you are travelling) be sure to disconnect the power plug
from the wall outlet for safety.
If the power plug is not disconnected, fire may result in
the event of breakdown.
The unit is not completely disconnected from the power
source even if the TV monitor is turned off by pressing the
POWER button on the TV or remote control.
To completely disconnect this unit from the
power source, disconnect the power plug
from the wall outlet.
■
Do not pull the power cord to disconnect the power plug.
Pulling the power cord to disconnect the power plug from
the wall outlet may cause damage to the power
cord or plug, resulting in fire or electrical shock.
Grasp the power plug to disconnect it.
■
Avoid plugging or unplugging the power plug
with wet hands.
Doing so may cause electric shock.
■
Do not hang or climb on this unit or TV;
and do not use this unit as a step ladder.
Doing so may damage the unit or TV or cause
it to fall or topple, resulting in injury.
Be extra careful with children.
■ Disconnect and inspect the power plug occasionally.
Clean the dirt and dust accumulated on the blades and
the surface on which the blades are installed.
Failure to observe this warning may cause the
insulation to deteriorate, resulting in fire.
On cleaning
■
Do not install this unit in a place subject to high
temperature.
Installing the unit in a place subject to high
temperature, such as a location near a heater
may cause fire.
It may also deform or damage the cabinet,
resulting in electric shock.
On installation
■ To move or carry this unit:
·
When moving the unit, disconnect the unit’s power
plug, and any cables and wires connected to the unit
and topple-prevention device
.
Moving the unit without disconnecting these components
may cause fire or electric shock from a damaged power
cord or injury due the TV toppling from the top of the unit.
·
Handle with care to avoid impact.
Failure to observe this caution could result in damage
to the unit and injury.
·
Remove TV from unit before moving.
TV could topple and cause serious injury
or damage.
■
Avoid prolonged listening to the audio at high volume
levels.
Listening to sound at such a high volume that it
irritates ears may damage your hearing.
■
Do not allow rubber or plastic/vinyl products to
come into prolonged contact with the unit.
This may cause deterioration or damage to the
surface finishing.
■
Do not place objects that are easily influenced by
magnetism, such as clocks, on this unit.
This may cause these objects to stop working.
■
Do not place hot objects such as a heated pan or
kettle on the unit.
The top surface may break and cause injury
or damage to the unit.
■ Batteries used for the remote control:
·
Do not use any batteries other than those specified.
·
Follow the polarity markings inside the compartment.
·
Do not charge, heat, disassemble or short-circuit the
batteries.
·
Do not expose the batteries to excessive heat such
as fire or direct sunlight.
·
Do not leave expired or drained batteries inside the
remote control.
·
Do not use different types of batteries or a new
battery with an old one at the same time.
Failure to observe these cautions may result in burns or
injury due to battery leakage or explosion.
Leaked battery fluid may harm your eyes or skin. If it gets
in contact with your eyes or skin, flush the affected area
with clean water and seek medical attention immediately.
If battery fluid comes in contact with clothing, flush
the affected area with clean water immediately.
If battery fluid has spilled on the apparatus,
wipe it off avoiding direct contact.
Notes and Precautions on use
Front view
Control panel
About this Unit
Control panel (see below)
Front speaker (right)
Center speaker
• Functioning when surround mode is ON.
Front speaker (left)
TV > DVD > AUDIO 1> AUDIO 2 (Bluetooth)
POWER
• Press to turn the power ON and OFF.
INPUT selector
• Each time you press the button,
the input source changes as follows:
VOLUME +/–
• Press to adjust the volume level.
POWER indicator
Display panel
Rear view
Remote control
Information display
• Displays the information on the status.
• The information display will disappear if you do
not press any operation button within five seconds.
Power cord
• When connecting external equipment such as a TV or BD/DVD player,
connect the power cord to the wall outlet only after the necessary
connections have been completed.
Amplifier connections
Optical digital audio input jacks
• “TV” is only for connection to the
optical digital output jack on the TV.
• Use these jacks to connect external
equipment with an optical digital audio
output jack.
Analog audio input jacks
• Use these jacks to connect
external equipment with an
analog audio output jack.
• Audio 2 is purposely used
for Bluetooth, Please do
not remove the caps
■ Buttons on the remote control and their key functions are
as described below (some buttons may have different
functions from ordinary operations).
Signal transmitter
• To operate the unit, point it at the
remote sensor on the unit.
POWER
• Press to switch
“Power ON” and “Standby”.
MUTING
•
Press to mute the sound temporarily.
Press again to restore the sound.
INPUT SELECTOR
• Press to select the input source.
SURROUND MODE
• Press to turn the
surround mode ON and OFF.
VOLUME +/–
• Press to adjust the volume level.
BASS
• Press to switch the BASS BOOST
setting
Battery compartment cover
• Remove this cover to insert
batteries.
Front view
Rear view
Website : http://www.igoaudio.com/
Printed in Malaysia
650-0SB300-00
(Open) size:750 x 315mm / (Close) size: 150 x 158mm / 11.11.13 / 19.11.13 / 20.11.13 / 21.11.13
Sound Base SB-300
Sound Base SB-300
Remote sensor
Input indicator
• Indicates the selected input.
Sound Base SB-300
Instruction
Sound Base SB-300
Sound Base SB-300
■ Point the remote control at the remote sensor on the unit.
■ Avoid exposing the remote sensor to intense light.
The remote control may not function under such a
condition.
■ Do not place obstacles in the path between the remote
control and remote sensor. Otherwise, the remote control
may not work or will respond slowly.
Check the power plug connection.
■ Insert the power plug into the wall outlet securely.
■ Contact an electrician in the event of loose outlet.
Check the polarity of the batteries inserted in the remote
control.
Check if old batteries are being used.
■ Check the polarity (+, –) markings on the batteries.
■ Replace with new batteries and see if the problem is
remedied.
Check for any loose jacks or disconnected cables.
■ Securely connect the unit and equipment.
Crack sound from the cabinet.
■ A crack sound is heard when the cabinet expands and
contracts due to changes in the room temperature. This is
not an issue unless you experience a problem in the sound.
The unit becomes hot even when it is not in use.
■ The temperature of the unit rises slightly even in standby
mode.
Connecting a TV
■ Read the operating instructions of the connected
equipment together with these instructions.
■ Before connecting external equipment, be sure to turn
them off and unplug the power cord of the equipment.
When you wish to add any equipment, turn off and unplug
the IGO AUDIO SOUND BASE SYSTEM as well
as the equipment being installed before proceeding.
■ Connect the power cord of each piece of equipment only
after all the connections have been completed.
Cables to be used
White
Red
White
Red
Optical cable (supplied)
• Check the jack type of the connected equipment before purchasing additional
cable. The type of the plug to be connected to the unit is
Pin cable (supplied)
For connections via an optical cable
■ Set the digital audio output setting on the connected
equipment (such as a TV) to “PCM”, etc. Refer to the
operating instructions of the connected equipment for
setup.
Connecting the Video Player
Selecting the input source
■ Power on IGO Amplifer, select audio source to (AUDIO 2).
■ Go to the Bluetooth manager of your device, search for a
new Bluetooth connection name IGO Audio.
■ Confirm the connection and your device is automatically
pairing with the IGO Audio. A single “DU” tone voice will
sound when pairing successfully, You do not need any
pin-code for connection.
■ IGO Audio is now connected and ready to play music
from your device.
Bluetooth
When using Audio Player
Amplifier connections
When the TV set has optical (audio digital) OUT, connect using an optical
cable.
When the TV set does not have optical OUT, connect using a pin cable.
Optical cable
(supplied)
To Optical
Digital Audio
IN (TV)
Signal
To Optical
Digital Audio OUT
Pin cable
(supplied)
To Analog
Audio OUT
• Refer to the TV operating instructions for connecting.
• TV volume should be set to “0” or “Muting”. Simultaneous sound
output by both TV and RACK would result in an unpleasant audio
experience.
The optical digital audio input
jack is covered. Just insert the
plug into the covered jack after
making sure it is pointing the
correct way.
* Connect to the Digital Audio
IN (TV).
White
Red
White
Red
White
Red
White
Red
Signal
TV
Video cord
(Refer to the operating
instructions of the
connected equipment
for set up.)
When using optical cable
Signal
Player
TV
Optical cableOptical cable
To Optical Digital
Audio IN (DVD)
To Optical Digital
Audio IN (DVD)
To Video
(OUT)
To Video (IN)
Refer to TV connection
When using HDMI cable or pin cable
Player
TV
To Video
(OUT)
Refer to
TV connection
(Refer to the operating instructions of
the connected equipment for set up.)
or
HDMI cable
(not supplied)
HDMI cable
(not supplied)
Pin cable
(not supplied)
Pin cable
(not supplied)
Connecting the Audio Player
Connecting the Power Cord
White
Red
White
Red
White
Red
Pin cable (1 piece supplied, for connection to either TV or audio player)
Pin cable (not supplied)
■ Refer to the operating instructions of each equipment to
connect equipment.
■ Cables to be used
■ Be sure to connect the power cord only after all the
connections have been done.
■ INFO
• The sound volume may be lower if an
audio cable with a built-in resistor is used.
• When the unit is connected to a TV or player
with an audio cable, use the remote control
of the connected equipment to change the
sound setting for sound multiplex
broadcasting programs.
■ INFO
• This unit will automatically turn to standby mode if there is no signal from
selected input within ten minutes.
CAUTION
■ About the remote control
• Do not drop, swing or apply impact to the remote control.
• Do not splash water on the remote control or place it on
a wet object.
• Do not disassemble the remote control.
• Do not place the remote control in a place subject to high
temperature or humidity.
■ INFO
• About batteries
• Battery life differs depending on how the battery is used.
Replace both of two batteries with new ones if you experience
difficulty in using the remote control or if the signal transmission
distance shortens.
• Dispose of the used batteries following your local regulations for
disposal.
Amplifier connections
White
Red
Mini plug
CD Player
Audio Player etc.
To Audio OUT
To Analog
Audio OUT
Connecting to the wall outlet should be the last connection made.
■ Firmly insert the power plug fully into outlet.
■ Be sure to power OFF the unit before disconnecting the
power plug.
■ To close the cover, insert the protrusion at the
bottom of the cover into the notch on the remote
control and then push down the top of the cover
until a click is heard.
Inserting batteries into the
remote control
About the remote control’s
operating range
Resetting the unit in the event
of freeze-up
The sound is output from both
the unit and the TV
Unable to operate the unit with
the remote control
Preparing the Remote Control
These do not Constitute
a Malfunction
■
Use this troubleshooting guide to check possible solutions
for symptoms such as improper functioning of the unit.
■ Should the problem persists, disconnect the power plug
from the wall outlet and consult your dealer.
■ Design, specifications and software used are subject to change without
prior notice for product improvement.
■ The material designation of major plastic parts of this product are indicated
for recycling purpose.
■ Some exaggerations and omissions are made to the illustrations and
monitor displays featured in these instructions to facilitate understanding.
Actual items may vary from the illustrations.
Find Solution according
to the Symptoms
■ Use two R03 or LR03 (size AAA) batteries.
■ Two R03 (size AAA) batteries are supplied with the unit.
·
Remove the cover and insert the batteries.
1 To remove the cover, lift its latch while pressing
it in the direction.
2 Check the polarity markings + and - to insert the
batteries correctly.
1
Bottom of the cover
Top of the cover
2
Turning on the Power
or
■ After connecting your external equipment, turn on the
power of the unit.
Make sure that the standby indicator on
the front panel is lit in red, then press
on the unit or on the remote control.
1
■ Selecting the input source with the INPUT SELECTOR
button on the front panel.
Select the input source by pressing
button repeatedly.
The input source changes in the following order:
(Actual change of the input source may be slower
than the display.)
■ You can select one of the four BASS levels.
Select the desired BASS level by
pressing button repeatedly.
■ BASS level is displayed on the front display panel.
1
Make sure that the standby
indicator in standby mode.
The standby indicator is OFF
and the input indicator light is ON.
Press on the
front panel to turn
on the power.
Press on the
remote control to turn
on the power.
■ From the remote sensor:
Distance – Within 16 ft (5m)
Angle – Within 30˚ (horizontal); Within 20˚ (vertical)
Remote
sensor
Within about
16 ft (5 m)
About 30º About 30º
Functions
Listening to the Sound
Troubleshooting
Check the Following First
Others
Specifications
Installation
Connecting a TV and Player
Input sequence Display panel
TV
DVD
AUDIO 1
AUDIO 2
(BLUETOOTH)
■
Selecting the input source with the remote control
Press the INPUT button for the desired source.
Adjusting the volume level
Turning off the sound temporarily (Muting)
Operation
The power does not turn on
The display disappears
Selecting BASS level during playback
Press to control the volume level.
1VOL
12
1 When decreasing the volume level, two indicators on the left
side flash.
2 When increasing the volume level, three indicators on the right
side flash.
■ The volume level is displayed by five indicators on the
front display panel.
■ The volume level can be controlled by pressing
on the front panel.
1
Press .
1
■ Input indicator will flash.
■ Press again to return to the original volume level.
■ The mute mode is cancelled if you control the volume
or turn the unit off/on.
BASS level
BASS 0
(Flat)
BASS 2
(High boost)
BASS 1
(Low boost:
Default)
BASS 3
(EX. High
boost)
Display panel
Polarity
Polarity
■ Perform the following operation in the event that the unit
cannot be operated using the control buttons on the
remote control or the unit; or if the connected equipment
is not recognized.
How to reset
1 Disconnect the power plug from the wall outlet.
2 Wait for more than 1 minute.
3 Connect the power plug to the wall outlet and turn on the
power.
Check If: Possible Solution / Other
The power plug is
disconnected.
• Connect the power plug to the
wall outlet.
Check If: Possible Solution / Other
The sound is a digital
sound not supported by
the unit.
• Check if it is a digital sound
supported by the unit.
Sound
No sound output (General)
Check If: Possible Solution / Other
A button was pressed
within the last five
seconds.
• The information display will
disappear if you do not press
any operation button within
five seconds.
Sudden Power off
Check If: Possible Solution / Other
There is an input signal. • This unit will automatically
turn to standby mode if there is
no signal from selected input
within ten minutes.
The equipment is not
connected correctly.
•
Check the connections between
the unit and equipment. If there
is no connection problem, there
could be a problem with the
cable. Use another cable to
connect the equipment and
see if the problem is solved.
The digital signal is not
supported by the unit.
•
Check if the digital signal is
supported by the unit.
Check If: Possible Solution / Other
There is an obstacle in
the path between the
remote control and
remote sensor.
The batteries of the
remote control are
empty.
The unit can be
operated with the
buttons on the unit.
• Remove the obstacle.
• Replace the batteries with
new ones.
•
If you are still unable to operate
the unit using the remote
control even after trying the
above possible solutions, the
remote could be defective.
Consult your dealer.
Check If: Possible Solution / Other
The volume level is set
to minimum.
• Increase the volume by
pressing .
VOL
Input indicator is flashing
on the display panel.
• Muting is cancelled by
pressing .
(Muting can also be canceled
by pressing .)
VOL
Sound is interrupted or there is noise
Check If: Possible Solution / Other
Check TV volume level. • Set TV volume to “0” or
“mute”.
Type
AC power source
Power consumption
Dimensions inch
(W × D × H) (Approx.) mm
Maximum load
Mass (Approx.)
Left
Speakers
Center
Right
Subwoofer
Power output (Rated)
Power output (Reference)
Optical digital audio IN (TV/optical digital)
Analog audio input jack
Operating environment conditions
Supported Audio Decode Formats
Accessories
For USA Model Power output and
total harmonic distortion (FTC)
Input
Terminal AMP Output Power
IGO SOUND BASE SYSTEM
AC 110V - 240V 50/60Hz
32 W / Standby mode: 0.5 W
38½” × 15" × 4"
980 mm × 380 mm × 99 mm
66 lbs (30 kg)
30.8 Ibs (14 kg)
Cone type; Full Range (80 mm) 6 Ω
Cone type; Full Range (80 mm) 6 Ω
Cone type; Full Range (80 mm) 6 Ω
Cone type; Subwoofer (80 mm) 3 Ω × 4
Front L / Front R: 20 W + 20 W (at 6 Ω, 1 kHz 1 % THD)
S/PDIF (OPTICAL)
Pin jack (200 mV [rms], 22 kΩ and above)
Bluetooth Ver 3.0 (A2DP, aptX)
Temperature: 32 ˚F to 104 ˚F (0 ˚C to 40 ˚C);
Relative humidity: 20 % to 80 % (no condensation)
DIGITAL IN (OPTICAL): PCM 2ch (Sampling Frequency:
less than 192 kHz)
See “Supplied Accessories”
Front L + Front R: With 6 Ω loads, both channels driven,
from 150-20,000 Hz; rated 20 W per channel minimum
RMS power, with no more than 1 % total harmonic distortion
from 250 mW to rate output.
Front L / Front R: 28 W (per channel at 6 Ω, 1 kHz)
Center: 28 W (at 6 Ω, 1 kHz)
Subwoofer 1/2: 27 W (per channel at 6 Ω, 100 Hz)
Total Power: 138W
Enjoying Surround Sound
Turning on SURROUND mode
Turn on SURROUND mode by pressing
1
OFFON
SRS and the symbol are trademarks
of SRS Labs, Inc.
SRS technology is incorporated under
license from SRS Labs, Inc.
■ Each time you press
the surround mode changes as ON/OFF.
The Bluetooth word mark and logo are registered or owned by Bluetooth SIG, Inc,
and any use of such marks by FORMOSA PROSONIC INDUSTRIES BERHAD is under license.
Other trademarks and trade names are those of their respective owners.
aptX word & logos marked with a TM or ® are trademarks registered or owned by CSR plc or one of its
group companies and may be registered in one or more jurisdictions except that not all such marks aw
registered in all countries where products are available.
Sound Base SB-300
SRS and the symbol are trademarks of SRS Labs, Inc.
SRS technology is incorporated under license from SRS Labs, Inc.
