CM9-C1 Installation
MODULAR USAGE
This device is intended only for installation into the Miltope
Cabin Access Point (CAP) under the following conditions:
1) The antenna must be installed such that 20 cm is
maintained between the antenna and users.
2) The transmitter module may not be co-located with any
other transmitter or antenna
3) The final product containing this device must be labeled
in a visible manner with the following; “ Contains FCC ID
RTP550-10016-7”
4) The end product user manual must contain the following
information in a prominent location; “Important Note: To
comply with FCC RF exposure requirements, the
antenna used for this transmitter must be installed to
provide a separation distance of at least 20cm from all
persons and must not be co-located or operated in
conjunction with any other antenna or transmitter.
5) This radio module is approved for use only in the Miltope
CAP (Cabin Access Point) which is deployed only in
aircraft and is professionally installed per FAA
regulations.
200 West Street phone: +1 781-684-0001
Waltham, MA 02451 fax: +1 781-684-0009
USA
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help. FCC
Caution: To assure continued compliance, (example - use only shielded interface
cables when connecting to computer or peripheral devices) any changes or
modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
200 West Street phone: +1 781-684-0001
Waltham, MA 02451 fax: +1 781-684-0009
USA
CM9-C1 IMPORTANT OPERATION INFORMATION
This device has been designed to operate with the antennas listed below, and
having a maximum gain of 4.85 dBi@ 2.4 GHz, 5.0 dBi @ 5.25GHz and 4.0 dBi
@ 5.875GHz. Antennas not included in this list or having a gain greater than
those listed are strictly prohibited for use with this device. The required antenna
impedance is 50 ohms.
To reduce potential radio interference to other users, the antenna type and its
gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.)
is not more than that permitted for successful communication.
Operation in the band 5.15-5.25GHz is restricted to indoor use only.
Approved antennas
The table below lists the antennas approved for use with the model CM9-
C1:
Manufacturer Part # 2.4 GHz Gain 5.3 GHz Gain 5.7 GHz Gain Location
Miltope 901167-2 2.6 dBi 1.2 dBi 1.2 dBi Indoor
Miltope 901563-2 4.85 dBi 5.0 dBi 4.0 dBi Outdoor
Miltope 901167-1 3.5 dBi 3.5 dBi 3.5 dBi Indoor
Miltope 901058-1 5.0 dBi N/A N/A Outdoor
Gore GSC10-82701-XX -30 dBi -30 dBi -30 dBi Indoor
