Huawei Technologies RRU3256-2500 Remote Radio Unit User Manual RRU3252 RRU3256 Hardware Maintenance Guide

Huawei Technologies Co.,Ltd Remote Radio Unit RRU3252 RRU3256 Hardware Maintenance Guide

RRU3256 Hardware Maintenance Guide-EN

DBS3900

V100R005C00

RRU3252/RRU3256 Hardware

Maintenance Guide

Issue Draft A

Date 2012-11-30

HUAWEI TECHNOLOGIES CO., LTD.

No part of this document may be reproduced or transmitted in any form or by any means without prior written

consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective holders.

Notice

The purchased products, services and features are stipulated by the contract made between Huawei and the

customer. All or part of the products, services and features described in this document may not be within the

purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information,

and recommendations in this document are provided "AS IS" without warranties, guarantees or representations

of any kind, either express or implied.

The information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute a warranty of any kind, express or implied.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: http://www.huawei.com

Email: support@huawei.com

Issue Draft A (2012-11-30) Huawei Proprietary and Confidential

About This Document

Purpose

This document describes routine maintenance procedures for an RRU3252/RRU3256 (referred

to as RRU in this document), such as equipment preventive maintenance and power-on and

power-off operations. It also describes how to replace the RRU and optical modules.

Product Version

The following table lists the product version related to this document.

Product Name Product Version

DBS3900 LTE TDD V100R005C00 and later versions

Intended Audience

This document is intended for:

lSystem engineers

lSite maintenance engineers

Organization

1 Change History

This chapter describes changes in the RRU3252/RRU3256 Hardware Maintenance Guide.

2 Preventive Maintenance Items for an RRU

Preventive maintenance for an RRU improves RRU reliability. You are advised to perform

scheduled maintenance yearly.

3 Powering On and Powering Off an RRU

DBS3900

RRU3252/RRU3256 Hardware Maintenance Guide About This Document

Issue Draft A (2012-11-30) Huawei Proprietary and Confidential

After an RRU is powered on, the RRU indicator status and voltage must be checked. Before an

RRU is powered off, you must decide whether to power off the RRU in a normal situation or an

emergency based on onsite requirements.

4 Replacing an RRU

A distributed base station consists of RRUs and a BBU. Replacing an RRU interrupts all the

services carried by the RRU, and alarms are generated.

5 Replacing an Optical Module

An optical module provides optical-electrical conversion ports, enabling optical transmission

between an RRU and other devices. Optical cables inserted into an optical module must be

removed before the optical module is replaced. Replacing an optical module interrupts CPRI

signal transmission.

Conventions

Symbol Conventions

The symbols that may be found in this document are defined as follows.

Symbol Description

Indicates a hazard with a high level of risk, which if not

avoided, will result in death or serious injury.

Indicates a hazard with a medium or low level of risk, which

if not avoided, could result in minor or moderate injury.

Indicates a potentially hazardous situation, which if not

avoided, could result in equipment damage, data loss,

performance degradation, or unexpected results.

Indicates a tip that may help you solve a problem or save

time.

Provides additional information to emphasize or supplement

important points of the main text.

General Conventions

The general conventions that may be found in this document are defined as follows.

Convention Description

Times New Roman Normal paragraphs are in Times New Roman.

Boldface Names of files, directories, folders, and users are in

boldface. For example, log in as user root.

Italic Book titles are in italics.

DBS3900

RRU3252/RRU3256 Hardware Maintenance Guide About This Document

Issue Draft A (2012-11-30) Huawei Proprietary and Confidential

iii

Convention Description

Courier New Examples of information displayed on the screen are in

Courier New.

Command Conventions

The command conventions that may be found in this document are defined as follows.

Convention Description

Boldface The keywords of a command line are in boldface.

Italic Command arguments are in italics.

[ ] Items (keywords or arguments) in brackets [ ] are optional.

{ x | y | ... } Optional items are grouped in braces and separated by

vertical bars. One item is selected.

[ x | y | ... ] Optional items are grouped in brackets and separated by

vertical bars. One item is selected or no item is selected.

{ x | y | ... }*Optional items are grouped in braces and separated by

vertical bars. A minimum of one item or a maximum of all

items can be selected.

[ x | y | ... ]*Optional items are grouped in brackets and separated by

vertical bars. Several items or no item can be selected.

GUI Conventions

The GUI conventions that may be found in this document are defined as follows.

Convention Description

Boldface Buttons, menus, parameters, tabs, window, and dialog titles

are in boldface. For example, click OK.

>Multi-level menus are in boldface and separated by the ">"

signs. For example, choose File > Create > Folder.

Keyboard Operations

The keyboard operations that may be found in this document are defined as follows.

Format Description

Key Press the key. For example, press Enter and press Tab.

DBS3900

RRU3252/RRU3256 Hardware Maintenance Guide About This Document

Issue Draft A (2012-11-30) Huawei Proprietary and Confidential

Format Description

Key 1+Key 2 Press the keys concurrently. For example, pressing Ctrl+Alt

+A means the three keys should be pressed concurrently.

Key 1, Key 2 Press the keys in turn. For example, pressing Alt, A means

the two keys should be pressed in turn.

Mouse Operations

The mouse operations that may be found in this document are defined as follows.

Action Description

Click Select and release the primary mouse button without moving

the pointer.

Double-click Press the primary mouse button twice continuously and

quickly without moving the pointer.

Drag Press and hold the primary mouse button and move the

pointer to a certain position.

DBS3900

RRU3252/RRU3256 Hardware Maintenance Guide About This Document

Issue Draft A (2012-11-30) Huawei Proprietary and Confidential

Contents

About This Document.....................................................................................................................ii

1 Change History..............................................................................................................................1

2 Preventive Maintenance Items for an RRU..............................................................................2

3 Powering On and Powering Off an RRU..................................................................................4

3.1 Powering On an RRU.........................................................................................................................................5

3.2 Powering Off an RRU........................................................................................................................................6

4 Replacing an RRU.........................................................................................................................7

5 Replacing an Optical Module...................................................................................................10

DBS3900

RRU3252/RRU3256 Hardware Maintenance Guide Contents

Issue Draft A (2012-11-30) Huawei Proprietary and Confidential

1 Change History

This chapter describes changes in the RRU3252/RRU3256 Hardware Maintenance Guide.

Draft A (2012-11-30)

This is a draft.

DBS3900

RRU3252/RRU3256 Hardware Maintenance Guide 1 Change History

Issue Draft A (2012-11-30) Huawei Proprietary and Confidential

2 Preventive Maintenance Items for an RRU

Preventive maintenance for an RRU improves RRU reliability. You are advised to perform

scheduled maintenance yearly.

DANGER

While working at a high place, be careful not to drop any objects. Falling objects may cause

serious injury or death. All maintenance personnel must wear a helmet and avoid standing in

areas with a danger.

The items listed in the following table are not mandatory but strongly recommended. Table

2-1 lists the preventive maintenance items for an RRU.

Table 2-1 Preventive maintenance items for an RRU

SN Checklist

1All RRUs are properly installed and in good conditions.

2 Cables at the cable inlet of a cabinet are sealed properly.

3 All RF cables are intact and free from any cracks, cuts, or other damage.

4 All RF cable connectors are sealed properly.

5 All RF cable conduits are in good conditions.

6 All power cables are intact and free from any cracks, cuts, or other damage.

7 All power cable connectors are in good conditions.

8 All power cable conduits are in good conditions.

9 All shield layers of power cables are in good conditions.

10 All power cables are sealed properly.

11 All CPRI fiber optic cables are intact and free from any cracks, cuts, or other damage.

12 All screws are tightened on the cover plate of the maintenance cavity.

DBS3900

RRU3252/RRU3256 Hardware Maintenance Guide 2 Preventive Maintenance Items for an RRU

Issue Draft A (2012-11-30) Huawei Proprietary and Confidential

SN Checklist

13 All optional RET cables are intact and free from any cracks, cuts, or other damage.

14 Connectors of all optional RET cables are sealed properly.

15 All optional alarm cables are securely installed and free from any damage.

If any of the statements in the checklist cannot be complied with, perform the following

corrective actions:

1. Tighten all connections.

2. Report any other faults found when filling in the checklist to the supervisor, because only

qualified or trained field engineers are permitted to climb towers for further repairs.

DBS3900

RRU3252/RRU3256 Hardware Maintenance Guide 2 Preventive Maintenance Items for an RRU

Issue Draft A (2012-11-30) Huawei Proprietary and Confidential

3 Powering On and Powering Off an RRU

About This Chapter

After an RRU is powered on, the RRU indicator status and voltage must be checked. Before an

RRU is powered off, you must decide whether to power off the RRU in a normal situation or an

emergency based on onsite requirements.

3.1 Powering On an RRU

Set the corresponding circuit breaker on the auxiliary power device for the RRU to ON, and

check the operating status of the RRU by observing the status of RRU indicators.

3.2 Powering Off an RRU

You can power off an RRU either in a normal situation or an emergency. A normal situation

refers to the cases such as equipment reparenting or anticipated interruption of regional mains

supply. An emergency refers to the cases such as a fire, smoke, and water damage at the site.

DBS3900

RRU3252/RRU3256 Hardware Maintenance Guide 3 Powering On and Powering Off an RRU

Issue Draft A (2012-11-30) Huawei Proprietary and Confidential

3.1 Powering On an RRU

Set the corresponding circuit breaker on the auxiliary power device for the RRU to ON, and

check the operating status of the RRU by observing the status of RRU indicators.

Prerequisites

lThe RRU hardware is installed and RRU cable connections are secure.

lThe input voltage of the RRU ranges from -32 V DC to -60 V DC.

Context

CAUTION

After you unpack an RRU, you must power on it within 24 hours. If you power off the RRU for

maintenance, you must restore power to the RRU within 24 hours.

Procedure

Step 1 Set the corresponding circuit breaker on the auxiliary power device for the RRU to ON to power

on the RRU.

DANGER

Do not look into the optical module without eye protection after the RRU is powered on.

Step 2 Keep the RRU running for three to five minutes to check the status of RRU indicators. For

details, see RRU Indicators.

NOTE

If RRUs are cascaded, check the status of all RRU indicators.

Step 3 Take corresponding actions based on the status of the indicators.

If... Then...

The RRU is working properly End the power-on check task.

The RRU is faulty Set the circuit breaker to OFF. Rectify the

fault, and then go to Step 1.

----End

DBS3900

RRU3252/RRU3256 Hardware Maintenance Guide 3 Powering On and Powering Off an RRU

Issue Draft A (2012-11-30) Huawei Proprietary and Confidential

3.2 Powering Off an RRU

You can power off an RRU either in a normal situation or an emergency. A normal situation

refers to the cases such as equipment reparenting or anticipated interruption of regional mains

supply. An emergency refers to the cases such as a fire, smoke, and water damage at the site.

Procedure

lPower-off in a normal situation

Set the corresponding circuit breaker on the auxiliary power device for the RRU to OFF.

lPower-off in an emergency

CAUTION

Power-off in an emergency may damage the RRU, and do not use it in normal situations.

1. Power off the auxiliary power device for the RRU.

2. If time permits, set the corresponding circuit breaker on the auxiliary power device

for the RRU to OFF.

----End

DBS3900

RRU3252/RRU3256 Hardware Maintenance Guide 3 Powering On and Powering Off an RRU

Issue Draft A (2012-11-30) Huawei Proprietary and Confidential

4 Replacing an RRU

A distributed base station consists of RRUs and a BBU. Replacing an RRU interrupts all the

services carried by the RRU, and alarms are generated.

Prerequisites

lThe test UE communicates with the base station properly.

lThe types of faulty RRUs are confirmed as follows:

–If RRUs can be queried online, run the DSP BRDMFRINFO command on the LMT

to query the electronic labels of the RRUs.

–If RRUs cannot be queried online, the information about the RRUs can be queried offline

on the M2000. For details, see the procedure for querying inventory data in the M2000

documentation.

lTools and materials, such as ESD gloves, M4 Phillips screwdrivers, M6 Phillips

screwdrivers, waterproof tape, and PVC insulation tape, are ready.

lThe number of RRUs to be replaced are confirmed, and new RRUs are ready.

Procedure

Step 1 Run the BLK BRD command to block the RRU.

Step 2 Power off the RRU by referring to 3.2 Powering Off an RRU.

Step 3 Wear ESD gloves.

CAUTION

lTake proper ESD protection measures, for example, wear ESD gloves, to prevent electrostatic

damage to modules or electronic components.

lPay attention to the high temperature while replacing an RRU without housing.

Step 4 Use an M4 Phillips screwdriver to loosen the protection screw on the cover plate of the RRU

cabling cavity, and pull the handle outwards to open the cover plate.

Step 5 Record the cable connections in the cabling cavity.

DBS3900

RRU3252/RRU3256 Hardware Maintenance Guide 4 Replacing an RRU

Issue Draft A (2012-11-30) Huawei Proprietary and Confidential

Step 6 Disconnect cables from the cabling cavity and the bottom of the RRU.

Step 7 Use an M4 Phillips screwdriver to loosen the captive screws on the two hoist clamps on the main

mounting bracket, as shown in Figure 4-1.

NOTE

In scenarios where RRUs are installed in centralized mode, the RRU in the middle can be removed without

removing the two RRUs on its right and left sides, in the same procedure as that for removing a single RRU.

Figure 4-1 Loosening the screws on the main mounting bracket

Step 8 Hold the RRU and move it upwards to remove it, as shown in Figure 4-2.

Figure 4-2 Removing an RRU

DBS3900

RRU3252/RRU3256 Hardware Maintenance Guide 4 Replacing an RRU

Issue Draft A (2012-11-30) Huawei Proprietary and Confidential

CAUTION

When removing the RRU, hold the RRU handle with one hand, support the RRU bottom with

the other hand, and move the RRU upwards.

Step 9 Tighten the captive screws on the two hoist clamps on the main mounting bracket with a torque

of 1.4 N·m (12.39 lbf·in.).

Step 10 Install a new RRU.

Step 11 Install all required cables to the RRU and ensure that a waterproof block is inserted into each

vacant cable trough in the cabling cavity.

Step 12 Close the cover plate of the RRU cabling cavity, and then tighten the protection screw on the

cover plate with a torque of 0.8 N·m (7.08 lbf·in.).

Step 13 Power on the RRU by referring to 3.1 Powering On an RRU.

Step 14 Check the operating status of the new RRU by observing the status of RRU indicators. For details

about the status of the indicators, see RRU Indicators.

Step 15 Run the UBL BRD command to unblock the RRU.

Step 16 Take off the ESD gloves, and pack up all the tools.

----End

Follow-up Procedure

lPlace the removed RRU into the ESD box or bag. Then, place the ESD box or bag into a

foam-padded carton or the packing box of the new RRU.

lFill in the fault form with detailed information about the removed component.

lContact the local Huawei office to handle the faulty component.

DBS3900

RRU3252/RRU3256 Hardware Maintenance Guide 4 Replacing an RRU

Issue Draft A (2012-11-30) Huawei Proprietary and Confidential

5 Replacing an Optical Module

An optical module provides optical-electrical conversion ports, enabling optical transmission

between an RRU and other devices. Optical cables inserted into an optical module must be

removed before the optical module is replaced. Replacing an optical module interrupts CPRI

signal transmission.

Prerequisites

lNew optical modules are sufficient and the type of them is the same as that of the faulty

ones based on the labels on optical modules.

lThe following tools and materials are available: M4 Phillips screwdriver, ESD gloves, and

ESD box or bag.

Context

lOptical modules are hot-swappable when the same CPRI port is used.

lIt takes about 5 minutes to replace an optical module on the RRU, which involves removing

fiber optic cables and a faulty optical module, installing a new optical module and the fiber

optic cable, and waiting for CPRI links to recover.

Procedure

Step 1 Wear ESD gloves.

CAUTION

Take proper ESD protection measures, for example, wear ESD gloves, to prevent electrostatic

damage to the boards, modules, or electronic components.

Step 2 Use an M4 Phillips screwdriver to loosen the protection screw on the cover plate of the RRU

cabling cavity and then pull the handle outwards to open the cover plate.

Step 3 Record the connections of the optical module and fiber optic cables.

Step 4 Press the latch on the connector of the fiber optic cable, and then remove the connector from the

faulty optical module.

DBS3900

RRU3252/RRU3256 Hardware Maintenance Guide 5 Replacing an Optical Module

Issue Draft A (2012-11-30) Huawei Proprietary and Confidential

WARNING

Do not look into the fiber optic cable and optical module without eye protection after the fiber

optic cable is removed from the optical module.

Step 5 Lower the puller on the faulty optical module, and then pull the puller until the optical module

is removed from the RRU.

Step 6 Install the new optical module on the RRU.

NOTE

An optical module to be replaced or installed must match the data transmission rate over a CPRI port.

Step 7 Connect the fiber optic cable to the new optical module.

Step 8 Observe the indicators near the CPRI0/IR0 and CPRI1/IR1 ports and check whether CPRI signal

transmission is normal. For details about the indicator meanings, see RRU Indicators.

Step 9 Reinstall the cables in the cabling cavity.

Step 10 Close the cover plate of the RRU cabling cavity and then tighten the protection screw on the

cover plate with a torque of 0.8 N·m (7.08 lbf·in.).

Step 11 Take off the ESD gloves and pack up all tools.

----End

Follow-up Procedure

lPlace the removed optical module into an ESD box or bag. Then, place the ESD box or bag

into a foam-padded carton or into the packing box of the new optical module.

lFill in the fault form with detailed information about the removed component.

lContact the local Huawei office to handle the faulty optical module.

DBS3900

RRU3252/RRU3256 Hardware Maintenance Guide 5 Replacing an Optical Module

Issue Draft A (2012-11-30) Huawei Proprietary and Confidential

Huawei Technologies RRU3256-2500 Remote Radio Unit User Manual RRU3252 RRU3256 Hardware Maintenance Guide

Huawei Technologies Co.,Ltd Remote Radio Unit RRU3252 RRU3256 Hardware Maintenance Guide

Contents

RRU3256 Hardware Maintenance Guide-EN

Navigation menu

Namespaces

Views

Navigation
