Appendix K: Manual
Please refer to the following page.
18 GETTING STARTED
Specific Precautions/Power Source
North America
The PC aligner is intended to operate from a power
source that will apply 120 VAC (nominal) 50/60 Hz
between the supply conductors of the power cordset.
Other Regions
The PC aligner is intended to operate from a power
source that will apply 230 VAC (nominal) 50/60 Hz
between the supply conductors of the power cordset.
The power supply cordset, supplied with this equipment,
may need modification to allow connection to the power
supply mains. Your Hunter service representative will
install the proper plug for your location.
A protective ground connection, through the
grounding conductor in the power cord, is
essential for safe operation. Use only a power
cord that is in good condition.
FUSING:
To avoid fire hazard, use only the fuse specified
for your product.
EQUIPMENT SERVICE:
This equipment contains no user serviceable
parts. All repairs must be referred to a qualified
Hunter Service Representative.
PROVISIONS FOR LIFTING AND
CARRYING:
No provision has been made for lifting or carrying
this equipment. The unit must be moved by
rolling it on its casters.
Equipment Specifications
Electrical
VOLTAGE: 120/230 volts (nominal)
AMPERAGE: 6/3 amps
WATTAGE: 720 watts
Atmospherics
TEMPERATURE: +32°F to +122°F (0°C to +50°C)
RELATIVE HUMIDITY: Up to 95% Non-condensing
ALTITUDE: Up to 10,000 ft. (3048 m)
Explanation of Symbols
These symbols appear on the equipment.
This equipment has been tested and found
to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference when the
equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used
in accordance with the instruction manual, may
cause harmful interference to radio communications.
Operation of this equipment in a residential area is
likely to cause harmful interference in which case the
user will be required to correct the interference at their
own expense.
Changes or modifications not expressly
approved by the manufacturer could void the
user’s authority to operate the equipment.
RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS.
Tread DepthTool: 221-731-1
Contains FCC ID: LS3-45-1443
IC: 2938A-451443
Model: 45-1443
-OR-
Contains FCC ID: LS3-45-1637
IC: 2938A-451637
Model 45-1637
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. this device may not cause harmful interference, and
2. this device must accept any interference received,
including interference that may cause undesired
operation.
This device complies with Industry Canada license-
exempt RSS standard(s). Operation is subject to the
following two conditions:
(1) this device may not cause interference, and (2)
this device must accept any interference, including
interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d’Industrie
Canada applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux conditions
suivantes: (1) l’appareil ne doit pas produire de
brouillage, et (2) l’utilisateur de l’appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le fonctionnement.
