Integrated Microwave Technologies 23GP2-L5 Video Booster Amplifier User Manual 1

Integrated Microwave Technologies, LLC. Video Booster Amplifier Users Manual 1

Users Manual 1

Nucomm Inc.
101 Bilby Road
Hackettstown, NJ 07840
Tel: 908-852-3700 Fax: 908-813-0399
www.Nucomm.com
GOPAC
Docking Station and Amplifier
User Manual
M13-0002-00A - REV D.3
GoPac
M13-0002-00A Rev D.3 2 User Manual
CAUTION!
RISK OF ELECTRICAL SHOCK. DO NOT REMOVE COVERS.
Do not remove any covers.
Refer servicing to qualified technicians only.
Disconnect all power before servicing.
Read and perform all instructions carefully. Failure to follow suggested instructions and
guidelines may void all warranties.
© Copyrighted 2007, Nucomm, Inc., Hackettstown, New Jersey 08740
FCC STATEMENT
This equipment has been tested and found to comply with Part 74.637 (a) (2) of
the FCC Rules and Regulations. Any unauthorized changes or modifications not
expressly approved by Nucomm, Inc. could void the user’s authority to operate
the equipment, and invalidate the equipment’s warranty.
Operation of this device is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference
that may cause undesired operation of the device”.
RF Exposure Warning
This unit is a radio transmitter designed to permit, produce and emit RF radiation into an
antenna for the purpose of delivering RF to an appropriate receiving device.
The Maximum Permissible Exposure (MPE) limit for units of this type is 1.0mW/cm2. This
low-powered device will generally not create RF exposure in excess of the MPE limits issued
by the FCC (US) in OET Bulletin 65; 97-01, unless properly connected to an antenna, at which
time the radiated power can exceed the MPE limits.
The user is solely and exclusively responsible for determining the level of RF exposure when
connecting the unit to an antenna or other equipment, taking appropriate steps to limit RF
exposure, and for ensuring compliance with the FCC requirements in OET Bulletin 65.
GoPac
M13-0002-00A Rev D.3 3 User Manual
Proprietary & Disclaimer Notice
All information and graphic images herein contained within this manual are considered the sole
property of Nucomm, Inc. and is issued in the strictest of confidence. This material may not be
reproduced, stored, copied, or converted in any form, nor shall it be disclosed to others or used for
manufacturing or any other purpose without the written permission of an authorized
representative of Nucomm, Inc.
Nucomm, Inc. has made every effort to ensure the accuracy of this material at the time of printing.
However, as the specifications, equipment, and this manual are subject to change without notice,
Nucomm, Inc. assumes no responsibility or liability what so ever for any errors or inaccuracies
that may appear in this manual, or for any decisions based on its use. This manual is supplied for
informational purposes only and should not be construed as a commitment by Nucomm, Inc.
Warranty
Equipment manufactured by Nucomm, Inc. is warranted to meet all customer specifications and
to be free from defects in material and workmanship within a period of two years from date of
shipment from Nucomm. The company’s liability under this warranty is limited to:
Servicing or adjusting equipment.
Replacement of defective parts.
Any equipment returned to the factory shall have the freight paid for by the buyer.
Equipment showing damage by misuse, abnormal conditions of operation, or attempts to repair by
other than authorized service personnel shall be excluded from this warranty. Nucomm, Inc. shall
in no event be responsible for incidental injury or property damage. Since Nucomm, Inc. has no
control over conditions of use, no warranty is made or implied as to suitability for the customer’s
intended use, beyond such performance specifications as are made part of the purchase order.
There are no warranties expressed or implied, except as stated herein. This limitation on
warranties shall not be modified by verbal representations.
Shipping Damage
Equipment shipped FOB Nucomm, Inc.; shall become the property of buyer upon delivery to and
receipt from carrier. Any damage in shipment should be handled by the buyer directly with the
carrier. Immediately request the carrier’s inspection upon evidence of damage in shipment.
GoPac
M13-0002-00A Rev D.3 4 User Manual
Field Service
Nucomm products are designed with easy access to components to facilitate service. However, to
prevent voiding of the Nucomm warranty that protects the equipment, please contact Nucomm
before servicing or making any repairs. When troubleshooting, the user is cautioned to read all
module descriptions in this manual. Some Nucomm modules cannot be serviced in the field.
Warnings are included in the circuit descriptions and on certain modules themselves.
Replacement Modules
Troubleshooting to the component level is often not cost-effective and frequently impossible.
Often the practical method of effecting field repairs is to substitute known good spare modules for
suspect units. Nucomm maintains an inventory of replacement modules for its standard line of
products.
Customer Service Information
Telephone Consultation
Customer Service technicians at Nucomm are available to extend technical assistance to
customers installing, operating or troubleshooting Nucomm equipment
Should there be a need for telephone consultation, please have your model number and serial
number available for the Customer Service technician.
Contact Information
Telephone:
During Nucomm business hours, 8:30am – 5:30pm EST (-5:00 GMT):
US: ..........................................................................(908) 852-3700
International:...........................................................001 - 1 - (908) 852-3700
24-Hour Hotline:
US: ..........................................................................(888) 531-3892
International:...........................................................001 - 1 - (888) 531-3892
GoPac
M13-0002-00A Rev D.3 5 User Manual
Equipment Returns
If equipment cannot be successfully restored through telephone consultation, the equipment may
be returned to the factory for repair. Loaner equipment is often available until Nucomm is able to
return the repaired unit(s).
For out-of-warranty equipment only: Nucomm evaluates all returned units, and then confers with
the client on corrective action. If no fault is found, or no corrective action is authorized, a
diagnostic fee may be charged.
Do not return any Nucomm product to the factory until you have received a return material
authorization (RMA) number and shipping instructions from Nucomm.
When returning equipment to Nucomm, it is very helpful to enclose a letter containing the
following:
RMA number.
Model number.
Serial number.
Frequency operating range (especially when returning modules only).
A detailed description of the problem.
Name of an engineer or technician we may contact in regards to this problem.
A “ship to” and “bill to” address.
Ship all returns to:
Nucomm, Inc
101 Bilby Rd
Hackettstown, NJ 07840, USA
Attn: RMA# (your RMA number)
(908) 852-3700
For International returns:
In addition to the instructions above, when shipping internationally Nucomm recommends the use
of a courier such as Federal Express, UPS, etc, and that the goods be shipped DOOR-TO-DOOR
PRE-PAID. This will reduce Customs costs, handling charges and delays. Enclose all the
information above, plus a statement that the equipment was manufactured in the United States
(the latter is needed to expedite customs processing).
