COMPATIBILITY WITH PERSONAL COMPUTER

Personal computer input function : It can receive a 640 480 VGA PC signal!

Press PC button on the remote controller.

Set the display of the panel control in personal computer 640 480 VGA mode.

Connect TV with P.C using monitor cable.(Not Supplied)

Press menu button on the remote con-

troller

PRACTICAL APPLICATION

DOUBLE WINDOW FUNCTION

PRACTICAL APPLICATION

YUV TV

YUV VIDEO 2

(S-VHS 2)

YUV YUV

YUV VIDEO 1

YUV VIDEO 3

(S-VHS 3)

RGB VIDEO 1

RGB VIDEO 3

(S-VHS 3)

RGB TV

RGB VIDEO 2

(S-VHS 2)

RGB RGB

NOTE : It is imposseble to activate the above shadowed double window mode.

Use headphones to listen to sub-sound.

NOTE : In a certain Note-Book, there may become an unstable state be cause of incom-

patibility with a special graphic card!

PRACTICAL APPLICATION

COMPATIBILITY WITH PERSONAL COMPUTER

4. Adjustment of the horizontal and vertical position

Press VOL + / - button to adjust H and V position.

5. Adjustment of contrast and brightness

Press VOL + / - button to adjust the picture state.

6. To adjust the volume of headphone.

In P.C mode, you can enjoy not only the sound from main speaker but also the head-

phone sound.

Press VOL + / - button to adjust the volume of a headphone.

COMPATIBILITY WITH PERSONAL COMPUTER

1. Adjustment of the horizontal size

2. Adjustment of the vertical size

Press VOL + / - Button to adjust H size and V size.

3. Pincushion adjustment

Press VOL + / - button to adjust pincushion Barrel distortion.

PRACTICAL APPLICATION

H SIZE V SIZE

V-CHIP FUNCTION

The FCC adopted rules requiring all television sets with picture screen 13 inches or larg-

er to be equipped with features to block the display of television programming based

upon its rating.

This technology is known as the "V-CHIP".

The V-Chip reads information encoded in the rated program and blocks programs from

the set based upon the raing selected by the parent.

The V-Chip is available to help parents direct their children away from television they

deem inappropriate.

1. Press V-Chip button on the panel PIP.

2. Enter the access code (This initial access code is "0,0,0,0")

PRACTICAL APPLICATION

RECEIVING DIGITAL BROADCASTS

This ready TV can also receive digital broadcasts as well as a conventional analog broad-

casts by connecting with an ATSC Set-Top Box.

Digital Set-Top Box supporting ATSC system.

15Pin D-Sub connector

Digital Ready TV

1. Set an set-top box to the 640*480P mode. (P:Progressive)

2. Connect TV with set-top box using a monitor cable. (Not supplied)

3. Connect the audio input jacks of TV with the audio utput jacks of set-top box using an

audio cable (Not supplied)

4. Press PC button on the remote controller.

5. Use MUTE, VOL

, S.STD button in the PC mode.

PRACTICAL APPLICATION

NOTE : This ready TV supports only 640*480P mode and ntsc mode.

2 RGB IN

ANT

PC IN

PC terminal(PC IN)

V-CHIP FUNCTION : MPAA RATING

PRACTICAL APPLICATION

V-CHIP FUNCTION : MPAA RATING

This procedure allows parents to block programs which contain MPAA ratings that they

consider inappropriate.

1. Press VOL +, CH /button and select the rating which you wish to block.

2. Press VOL + button.

And then the color of the rating will change from blue to red.

3. When you change the rating, press CH /button and select N/A, and then press

VOL+ button.

PRACTICAL APPLICATION

RATING REMARKS

N/A(No rating) Not rated or not applicable program movie

has not been rated or ratings do not apply.

G(General audience) All ages admitted

PG(Parental guidance suggested) Some material may not be suitable for

children.

PG-13(Parents strongly cautioned) Some material may be inappropriate for

children under 13.

R(Restricted) Under 17 requires accompanying

Parent or adult guardian.

NC-17(No one 17 and under admitted)

X(Adults only)

NOTE

You do not need to block each MPAA rating individually.

For example, if you block movies with an R(restricted) rating, the V-chip will auto-

matically also block NC-17 and X rated movies.

In a like manner, passing(unblocking) the PG-13 rating would automatically also

pass PG and G ratings.

V-CHIP FUNCTION : TV PARENTAL GUIDE RATINGS

NONE(No Rating): Not rated or not applicable program.

Important note: You have the ability to block all programs which

are not rated, but you should be aware that such blocking may

have unintended consequences.

For example, the following types of non-rated programming might

be blocked: emergency bulletines, news, weather, religion, sports,

politics, local, unrated old movies, etc.

TV-Y(All Children): This program is designed to be appropriate for all children.

Whether animated or live-action, the themes and elements in this

program are specifically designed for a very young audience,

including children from ages 2~6.

This program is not expected to frighten younger children.

PRACTICAL APPLICATION

V-CHIP FUNCTION : TV PARENTAL GUIDE RATINGS

This procedure allows parents to block programs which contain TV parental guide rat-

ings that they consider inappropriate.

Refer to the rating and content label gides on the next page.

1. Press VOL +, CH /button and select the rating which you wish to block.

2. Press VOL + Button.

And then VIEW will change into LOCK and the color of one will change from blue to red.

3. When you change the ratings one by one, press CH /button and select the rating

which you wish to change, and then press VOL + button.

When you change the ratings at a time, press CH /button and select BLOCKING,

and then press VOL + button.

4. When you have finished setting the TV parental guide ratings, press MENU button

repeatedly.

PRACTICAL APPLICATION

V-CHIP FUNCTION : TV PARENTAL GUIDE RATINGS

TV-G(General audience): Most parents would find this program suitable for all ages.

Although this rating does not signify a program designed specifically for children, most

parents may let younger children watch this program unattended.

It contains little or no violence, no strong language and little or no sexual dialogue or sit-

uations.

TV-PG(D/L/S/V: Parental guidance suggested): This program contains material that par

ents may find unsutable for younger children.

Many parents may want to watch it with their younger children.

The theme itself may call for parental guidance and/or the program contains one or

more of the following:

Moderate violence(V), some sexual situations(S), infrequent coarse language(L), or

some suggestive dialogue(D).

PRACTICAL APPLICATION

V-CHIP FUNCTION : TV PARENTAL GUIDE RATINGS

TV-Y7(FV;Directed to older children): This program is designed for children age 7 and

above. children age 7 and above.

It may be more appropriate for children who have acquired the developmental skills

needed to distinguish between make-believe and reality.

Themes are elements in this program may include mild fantasy violence or comedic vio-

lence or may frighten children under the age of 7.

Therefore, parents may wish to consider the suitability of this program for their very

young children.

PRACTICAL APPLICATION

NOTE

For those program where fantasy violence may be more intense or more combative

than other programs in this category, such programs will be designated TV-Y7-FV.

V-CHIP FUNCTION : CONTENT LABEL

TV Parental guidelines may have one or more letters added to the basic rating to let par-

ents know when a show contains higher levels of potentially, offensive material.

Note that the content label should be considered in light of its associated rating.

For example, a "V" is likely to designate considerably more intense violence when asso-

ciated with a TV-MA rated program than when it is associated with a TV-PG rated pro-

gram.

PRACTICAL APPLICATION

V-CHIP FUNCTION : TV PARENTAL GUIDE RATINGS

TV-14(D/L/S/V: Parental strongly cautioned): This program contains some material that

many parents would find unsuitable for children under 14 years of age.

Parents are strongly urged to exercise greater care in monitoring this program and are

cautione against letting children under the age of 14 watch attended.

This program contains one or more of the following:

Intense violence(V), intense sexual situations(S), strong coarse

language(L), or intensely suggestive dialogue(D).

TV-MA(L/S/V: Mature audience only): This program is specifically designed to be viewed

by adults and therefore may be unsuitable for children under 17.

This program contains one or more of the following:

Graphic violence(V), explicit sexual activity(S), or crude indecent

language(L).

PRACTICAL APPLICATION

V Violence D Suggestive dialogue

S Sexual situations FV Fantasy violence

L Coarse or crude indecent language

NOTE

You do not need to block each TV parental guide rating individually.

The TV-Y and TV-Y7 ratings are handled as a group, and the TV-G, TV-PG, TV-14,

and TV-MA Ratings are handled as a group.

For example, if you choose a program with a TV-14 rating, the V-chip will automati-

cally also block TV-MA rated programs.

In a like manner, pasing(unblocking) the TV-MA rating would automatically also

pass TV-14 ratings.

Also note that you have the option of passing or blocking programs based on their

content label (D,L,S,V,FV) without necessarily blocking all programs that carry a

specific rating.

For example, you may pass some TV-PG programs, but not those which also carry

a "V"(moderate violence) content label.

In this case, the V-chip would automatically block Tv-14 and TV-MA rated programs

which carry the "V".

V-CHIP FUNCTION

BLOCK

After you set the rating, press VOL + button and set BLOCKING on.

CHANGING THE ACCESS CODE

This procedure allows you to choose a private 4-button access code.

The button for the access code is only 10 digit keys.

1. Press V-chip button on the panel pip.

2. Enter " 0 , 0 , 0 , 0 " in sequence.

3. Press CH /button and select CODE CHANGE!

4. Press VOL + button and then input numeric into a vacant space.

Write down a copy of your access code in a safe place.

PRACTICAL APPLICATION

56 57

SLEEP FUNCTION

The television automatically is turned off after an elapse of the set sleep time.

DISPLAY FUNCTION

Displays the current channel number, picture and sound state, MTS, and clock!

QUICK VIEW FUNCTION

Switches the current channel to the previously viewed channel!

MUTE FUNCTION

The volume of sound that you are listening to will be set to zero.

To restore the previous volume of sound, press mute button again or press VOL + button.

MISCELLANEOUS FUNCTIONS

NOTE

If you forgot the access code, the only way that you can clear the settings is to bring

the TV set to an authorized service center.

TROUBLE SHOOTING GUIDE

Before requesting service, please refer to the following chart for the symptom and possible

solution. For more information, see the corresponding page in this manual.

POSSIBLE SOLUTIONS

Make sure the power cord is plugged in.

Try another AC outlet.

Power is off. Check fuse or circuit breaker.
