MC121Functioninstruction

1. Electricalconfigurationdiagram：

2. FunctionPicture

1. Processoftest

1.1. HEADport

Connecttoheadactuator,controlbyremotesingle:

Clickhead upbuttonontheremote,headactuatormovesout,stopwhenreleased；

Clickheaddownbutton，headactuatormovesin,stopwhenreleased；

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

FCC ID:PCU-RF258GA

IC:21319-RF258GA

Issue department：Bedding Division Date： 2018-03-26

ProductFunction

instruction

Author： Kyle

No：

MC121 Version： 1.1

Page 2 of 3

2

1.4. MULTIFUNCTIONport

ConnectwiththesameOtheraccessories;

1.5. PowerLED&PAIRINGLED

Powersupplyforcontrolbox,PAIRINGLEDofcontrolboxflashesfor4times,andthenturnsoff,POWERLEDturns

on。

1.6. Power

Connecttothe29VDC;

1.7. PairFunction

Powerupcontrolbox，pairingLEDwillbeflash，thecontrolboxentersintomodeofcodeparing；

PressandholdtheparingLEDofRemote,thebacklightofparingLEDflashes,thebacklightofremoteflashes,the

remoteentersintomodeofcodeparing;

ThebacklightofparingLEDofremotestopsflashing,andtheparingledofcontrolboxstopflash,itindicatesthat

thecodeparingissuccessful;

Iffails,repeatalltheprocessesabove;

1.8. FLATfunction

PressandreleasetheFLAT buttononremote，theheadandfootactuatorsmovestolowerposition(whenthe

actuatorisfree,canturnoffthevibrationmotorandturnofftheindicatorlightwhenpressonce)，stopwhen

pressanybuton；

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

1.9. ZEROGpositionfunction

PressandreleaseZERO Gbuttononremote，theheadandfootactuatormovestopresetmemoryposition，stop

whenpressanybutton；

1.3. Massage

Connecttoheadmassage,controlbyremote:

Clickheadmassage+button,headmassagestrengthensbyonelevel;

Clickheadmassage‐button,headmassageweakenbyonelevel;

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

1.2. FOOTport

Connecttofootactuator,controlbyremotesingle:

Clickfoot up button，footactuatormovesout，stopwhenreleased；

Clickfoot downbutton，footactuatormovesin，stopwhenreleased；

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

Issue department：Bedding Division Date： 2018-03-26

ProductFunction

instruction

Author： Kyle

No：

MC121 Version： 1.1

Page 3 of 3

3

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.
