LG Innotek RNTDST01A IP Camera User Manual
LG Innotek Co., Ltd. IP Camera
User manual
REGULATION INFORMATION TO THE USER (FCC)
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Caution: Any changes or modifications to the equipment not expressly
approved by the party responsible for compliance could void user’s
authority to operate the equipment.
This appliance and its antenna must not be co-located or operation in
conjunction with any other antenna or transmitter.
A minimum separation distance of 20 ㎝ must be maintained between
the antenna and the person for this appliance to satisfy the RF
exposure requirements.
Home Security Camera
REGULATION INFORMATION TO THE USER (IC)
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
Cet équipement doit être installé et utilisé avec un minimum de 20 cm
de distance entre la source de rayonnement et votre corps
1. Product & Accessories
2. Operating Condition
- IP Network Camera : 32℉~104℉
3. Wall mount Installation
IP Network Camera, Adapter, Ethernet to Micro USB Cable
Anchor & Screw Quick Manual Non-slip pad
1. Tighten two screws to fix the bracket on the wall using screw driver.
2.Push and lock stand body to the bracket .
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that
may cause undesired operation of the device.
This equipment should be installed and operated with a minimum distance
of 20cm between the radiator and your body.
6. Mount SD Card(Optional)
Press and hold ‘Reset’ button more than 10 seconds until blink red of
Network LED
Reset Button 표현 그림 필요
9. Caution
1) This camera is an indoor good.(Don’t install outdoor)
2) Don’t cover vent hole
3) Don’t drop water or chemical substance.
4) Strong light is a cause of some image quality problem.
(sun light, headlight form automobiles, etc.)
Reset
5. Pairing the Device
4. Table-top installation
1. Attach the non-slip pad under mount bracket and lock the
camera body.
2. Adjust thecamera view direction
8. Factory Reset
LED
Status
Description
Camera Power LED
Blinking Green
Firmware updating
Pulsing Amber
Connecting to Server
Pulsing Green
Booting
Solid Amber
No Connectivity to Server
Solid Green
Working
Solid Red
Malfunction
Off
Power Off
Camera Network LED
Pulsing Green
Connecting to Router
Pulsing Red
No Connectivity to Router
Solid Green
Network Working
Solid Red
Network Working with weak
signal (RSSI < -80)
Off
Network Disabled
Camera Video LED
Solid Green
Recording
Off
Camera not Working
1. Plug in the camera.
2. Connect ethernet cable to controller ethernet port.
3. Please follow instructions on their controller.
Camera Video Led
7. LED Descriptioin
1. Insert a micro SD memory(be careful memory up/down side)
Camera Power Led
Camera Network Led
