Response to CRN 18597
Document No. 230086, Revision B
28 March 2001
Page A-1
1 Introduction
The SAIC In-Vehicle Control Unit (ICU, Model Number LCM386-20531200006 is a
rugged computer developed by Symbol Technologies Inc. for Science Applications
International Corporation (SAIC) and is used as a platform for in-vehicle
communications. It provides wireless network communications, GPS positioning and
Remote Alert Capability See Figure 1
WARNING: To meet the FCC RF exposure requirement for mobile transmitters as specified in the
FCC’s Rules (47 CFR Section 2.1091) and specifically as it applies to BellSouth Fleet Manager
Vehicle equipment configuration ensure that the antenna is at least 7.9 inches (20 cm) away from the
vehicle operator or nearby persons when transmitting.
The ICU uses an 80386 processor and supports the MS-DOS, Operating System using
industry standard protocols.
Figure 1 Front Panel View and Rear Panel View of ICU
1.1 About This Guide
This manual describes how to:
1. Prepare and install the HCU and associated hardware
2. Program the Remote Alert Transmitter (RAT) Key Fobs
3. Perform troubleshooting and maintenance activities
